June Panel vans

(1)

Panel vans

(2)

Over the years, we’ve worked hard to establish

Volkswagen Commercial Vehicles as a dependable,

well-respected Brand. There is an indefinable

robustness that distinguishes both our products

and our organisation from others. It’s founded

in the twin reality of premium quality vehicles

on the road, and down-to-earth assistance in our

day-to-day dealings with our customers. We want

you to have the confidence that wherever you are,

whatever business you’re in, Volkswagen can be

relied on to deliver.

But we’re not complacent. We are still working to

improve our network of Van Centres, the product

range and, of course, the level of customer care.

We want to help you find the right vehicle for your

business, and the right level of support for you.

So if you need assistance, please, just ask.

Welcome.

Contents.

Introduction.

Fold out for your quick reference guide.

03

02 04 07

02 - 07

Welcome to Volkswagen Commercial Vehicles, introduction and importantly your

quick reference guide.

08 - 13

The panel van range – which model is for me?

14 - 15

A summary of the panel van range.

58 - 59

Paint and upholstery for the panel van range.

60 - 67

Services, warranties, our dedicated Van Centre network and a useful ‘build your van’ removable fold out sheet. 16 - 25

The Volkswagen Caddy van, standard specifications, prices, factory options and technical data.

26 - 41

The Volkswagen Transporter panel van, standard specifications, prices, factory options and technical data.

42 - 57

The Volkswagen Crafter panel van, standard specifications, prices, factory options and technical data.

(3)

Introduction.

So you’re thinking about a new van. What does

it need to carry? How heavy is the load you will

put in it? How important is fuel consumption?

What about servicing, warranties, available

accessories and, of course, finance options?

All these, and many other questions, need to

be answered before you can make an informed

decision. One that’s right for your business.

And because the Volkswagen Commercial Vehicles

panel van range gives you such a wide choice,

you’re sure to get exactly what you need.

This brochure aims to make that process as

easy as possible. We suggest you keep the ‘Quick

reference guide’ and ‘Build your van’ pages open

as you browse to help you in your choice.

So let’s go to work…

Main image shows vehicles fitted with optional fog lights.

Panel van quick reference guide.

Model and price guide*

Caddy van £11,148.83 – £13,868.83

720

to

724

Volume m3 Payload range kg

Transporter short wheelbase with low roof

£14,588.83 – £19,408.83

802

to

1,383

Transporter short wheelbase with optional medium roof

£15,328.83 – £19,883.83

802

to

1,383

Transporter long wheelbase with low roof

£15,768.83 – £19,888.83

996

to

1,351

Crafter short wheelbase with low roof

£16,628.62 – £17,828.62

986

Transporter long wheelbase with optional medium roof

£16,158.83 – £20,363.83

996

to

1,351

Transporter long wheelbase with optional high roof

£16,438.83 – £20,758.83

996

to

1,351

Crafter medium wheelbase with high roof

£21,428.62 – £28,773.62

1,363

to

2,631

Crafter medium wheelbase with optional extra high roof

£22,488.62 – £30,093.62

Please note: Roof options alter payload, please ask your Volkswagen Van Centre.

Crafter long wheelbase with high roof

£21,978.62 – £29,373.62

1,229

to

2,465

Crafter long wheelbase with optional extra high roof

£23,038.62 – £30,693.62

Crafter long wheelbase maxi** with high roof

£23,428.62 – £29,873.62

1,177

to

2,418

Crafter long wheelbase maxi** with optional extra high roof

£24,488.62 – £31,193.62

* Prices exclude VAT, include OTR package and exclude optional equipment other than roof packs where applicable. ** Maxi = extended rear overhang.

Crafter Transporter

Caddy van

Crafter medium wheelbase with optional low roof

£20,628.62 – £27,973.62

(4)

The Volkswagen

panel van range.

Dependability is built into the very fabric of the

Volkswagen Commercial Vehicles’ offering. So is

quality. So you don’t have to worry about it – you

can be absolutely certain that whichever model you

finally choose, it’ll do the job, day in, day out.

So here are a few of the benefits that come

as standard:

• UK-wide Van Centre network support

• Finance options tailored to suit your business

• Payloads from 720kg all the way up to 2,631kg

• Load volumes from 3.2m

3

_{to 17.0m}

3

• Value-for-money parts

• LongLife servicing

• Free 3-year Volkswagen Roadside Assistance

• Wide range of accessories for all models

• High residual values*.

* According to industry influencers.

What a range this is! For starters, we’re the only

manufacturer with an automatic gearbox on a diesel

engine available across the whole of the range.

Not only that, but we have a whole host of engine

options, seating options, equipment options and so

on. But which one is the right vehicle to choose

from such a wide range? After all we have everything

from the compact Caddy to the enormous Crafter

extra high roof, long wheelbase maxi model – all

with different payloads and volumes.

09 08

(5)

Safety is a priority.

Your safety is such a vital factor that it is built-in, both with

the integral construction of the vehicles, and in the features

we include to protect the occupants. A long list of safety and

security features applies to every vehicle, but may vary

according to model specifications.

Features such as the 4MOTION

®

_{all wheel drive system to}

maintain traction in poor driving conditions, front and rear

parking sensors, and anti-theft protection for added security,

all offer particular assistance and protection when you’re out

on the road. Passive safety features include a driver’s airbag,

which is standard across the range with the option of passenger,

side and curtain airbags.

These are some of the safety features available, but please refer

to particular model specifications for which feature is available

on which model:

• ABS

*

• TCS

*

• EBC

*

• EBD

*

• Driver and passenger airbags

• Side and curtain airbags

• Third brake light

• Bulkhead as standard on Caddy and Crafter.

Add to all these independent suspension, stable road holding and

responsive engines and you can be sure that you’ll be as safe as

we can make you. The rest is up to you!

* Please refer to the glossary on page 65 of this brochure.

Image above shows a Crafter with optional towbar. Caddy image shows optional second side sliding door.

11 10

(6)

So which model is for me?

Image of Crafter shows optional side sliding door right and fog lights.

You probably already know roughly what you’ll need to carry.

What is the biggest thing you’ll need to get in your vehicle, or the

heaviest, or the longest or just the most awkward? If you’re a fleet

manager, then you’ll probably need a variety of options!

Having this in mind should help you get quickly to either the

Volkswagen Caddy, Transporter or Crafter ranges as a starting

point. Remember though that there is some cross-over between

the ranges, and for example, the smallest Crafter may be more

suitable than the biggest Transporter, or a Transporter may be

more suitable than the Caddy. The ‘Quick Reference Guide’ on

page 5 will come in handy, so will the fold-out ‘Build your van’

page at the back of this brochure.

Remember, this brochure only covers panel vans, together

with their factory-fitted options. There are separate brochures

available for our chassis and double cab, and passenger-carrier

ranges. There is also an accessories brochure for you to further

enhance your van.

Now let’s take a more detailed look at each model in the panel

van range so you can begin to make your choice…

13 12

(7)

Summary of the Volkswagen panel van range.

* Depending on engine and gearbox fitted.

†_{Maxi = extended rear overhang.}

Indicates models fitted with optional equipment.

15 14

(8)

Vehicle weights and dimensions are shown on

page 24. Other features and specifications are

detailed on pages 18 and 19.

The Volkswagen Caddy Maxi van is now also

available. For more information on this longer

Caddy variant, please contact your nearest

Volkswagen Van Centre and request the

‘Caddy Maxi range’ brochure.

The Volkswagen Caddy.

Although the Caddy is the most compact van in the

panel van range, it’s a very versatile vehicle, and

will carry loads up to 724kg. And with a choice of

three engines there’s plenty of scope for all sorts of

businesses to maximise their potential.

Getting your load in and out couldn’t be easier as

the Caddy has asymmetric twin rear doors and a

wide sliding side door. Added to which you can

specify a second sliding door on the off-side if

you want it.

Apart from the standard safety features such as

built-in bulkhead protection and 6 load-lashing

rings to save your load shifting about, the Caddy is

great to drive! There’s a host of features (including

a CD player as standard) that are too many to

mention here. A full list of all these features can

be found on the following pages, but this is an

overview of what the Caddy has to offer:

• Load volume 3.2m

3

• Payload up to 724kg

• Asymmetric rear doors

• Heated rear windows

• Wide sliding side door

• Bulkhead with mesh upper

• Choice of three diesel engines

• ABS, EBC, EBD* and TCS*.

Load fl oor showing accommodation of euro-pallet.

Image 01 shows optional second side sliding door right. Image 02 shows load area with optional second side sliding door.

02

01

17 16

(9)

Body.

Caddy van standard specifications.

Interior.

Functional.

Technical.

Safety and security.

Bulkhead. Image shows optional second side sliding door. Radio/CD player. Overhead storage. Rear wing doors. Load lashing rings. Side sliding door.

• 60 litre lockable fuel tank • Black wheel centre caps

• Externally adjustable exterior mirrors: - Convex on passenger’s side - Aspherical on driver’s side

• Front and rear towing eyes • Glazed asymmetric rear-wing doors • Grey bumpers

• Heat reflective glass

• Jack and tool kit with steel spare wheel

• Partially galvanised all-steel body • Roof load rack preparation • Side sliding door on left

Cab area:

• 2 folding and pivoting sun visors • Driver’s seat with height, reach and

rake adjustment

• Grab handles on roof frame • ‘Inca’ fabric seat covers • Interior light in headliner

• Passenger seat with reach and rake adjustment

• Rubber floor covering • Storage:

- 2 storage trays in dash panel

- 4 drinks holders and storage compartment in centre console

- Open glove compartment - Overhead storage

Rear:

• 2 door-activated interior lights • Full height bulkhead - solid lower and

plastic mesh upper

• Half-height load side lining in painted hardboard

• Interior roof trim in hardboard • Load sill protection

• Sheet steel flooring

• 12V socket • Digital clock

• Dimmable dashboard illumination • Heated rear window with rear wash/wipe

on larger rear door

• Manually controlled heating system with dust and pollen filter and air recirculation • Radio/single CD player, MP3 compatible

with 4 speakers

• Remote central locking with deadlocks, internal locking switch and 1 remote key

• Rev counter

• Warning buzzer for lights left on

• Windscreen wiper with variable intermittent delay and wash/wiper system

• Front and rear axle:

- Anti-roll bars, front and rear - Front McPherson strut suspension - Rear rigid axle with single layer leaf springs - Telescopic shock absorbers

• Hydraulic brake system with disc brakes and ABS: Anti-lock Braking System • Hydraulic power steering

• Steel wheels: 6.0J x 15 (on 69PS and 104PS versions) 6.0J x 16 (on 140PS version) • Tyres: 195/65 R15 (on 69PS and 104PS versions) 205/55 R16 (on 140PS version) • 3rd brake light

• ABS: Anti-lock Braking System • Breaksafe steering wheel lock • Driver's airbag

• EBC: Engine Braking Control

• EBD: Electronic Brakeforce Distribution

• Electronic immobiliser ‘Transponder’ • Halogen main headlights with range control • Height adjustable head restraints

• Height and rake adjustable safety steering column

• Load lashing rings (6)

• Rear fog lights

• Rear-view mirror with anti-dazzle function • TCS: Traction Control System

• Three-point, height adjustable and tensioning inertia reel seat belts

19 18

(10)

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP Model excluding VAT £ † Ins. group** including VAT £ †

Total retail including OTR*

Caddy van.

Volkswagen Caddy recommended retail prices.

Driver’s airbag. Third brake light. Load side lining.

*OTR (on the road) package includes the following:

Delivery to retailer £443.83 Number plates £20.00

VAT £81.17

Road fund licence £180.00 First registration fee £55.00

Total £780.00

† _{Calculated at}_17.5_{% on all products}_.

** Insurance group: As advised by the Association of British Insurers (ABI). Please see www.abi.org.uk/carinsurance for more information.

C20 69PS SDI PD 2.0l 2KAA32 10,450.00 1,828.75 12,278.75 11,148.83 13,058.75 3E-T2 104PS TDI PD 1.9l 2KAA42 11,370.00 1,989.75 13,359.75 12,068.83 14,139.75 3E-T2 104PS TDI PD DSG 1.9l 2KAA43 12,370.00 2,164.75 14,534.75 13,068.83 15,314.75 3E-T2

140PS TDI PD 2.0l 2KAA64 13,170.00 2,304.75 15,474.75 13,868.83 16,254.75 4A-T2

21 20

(11)

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP

Paint options.

15" alloy wheels. Fog lights. Rubber fl oor covering. Ladder fl ap.

Caddy van

Factory fitted options.

‘Climatic’ air conditioning. Towbar. • Options.

- Not available.

†_{Calculated at 17.5% on all products.}

Options packs.

Airbag packs.

Bulkhead packs.

Door packs.

Heating and ventilation.

Seat packs.

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP Caddy van

Caddy van factory options.

Metallic and pearl paint • 300.00 52.50 352.50

Black paint - 9000 • 260.00 45.50 305.50

Danish blue paint - 9506 • 100.00 17.50 117.50

Friesen green paint - 9644 • 100.00 17.50 117.50

1_{Appearance pack:}_{Restricted colours, please confirm availability with}

your Volkswagen Van Centre.

2_{ESP plus:}_{Includes Driver Steering Response (DSR) and trailer}

stabilisation function.

3_{Satellite navigation:}_{Replaces radio, includes RDS radio function with single}

CD (audio CDs cannot be played when using navigation function).

4_{Satellite navigation:}_{Replaces radio, navigation DVD covers western Europe,}

includes RDS radio function with single CD (audio CDs cannot be played when using navigation function).

5_Towbars:_{An adaptor is available from Van Centres, to allow connection to}

twin 7 pin sockets.

6_{Cab comfort pack:}_{Cab carpet, height adjustable front seats, storage under}

front seats, vanity mirrors and dash tray with cover.

Alloy wheels - 15", 4 with steel spare (not 140PS) • 365.00 63.88 428.88

Alloy wheels - 16", 4 with steel spare (140PS only) • 630.00 110.25 740.25

Appearance pack - body coloured bumpers and wing mirrors

(only with electric pack) 1_•_{185.00 32.38 217.38}

Cruise control • 170.00 29.75 199.75

ESP plus 2 _• _245.00 _{42.88 287.88}

Fog lights - front (included in visibility pack A) • 100.00 17.50 117.50

Key - 2nd, for remote locking (included with alarm packs A and B) • 10.00 1.75 11.75

Ladder flap - in roof (only with side door pack A, not with rear door pack B) • 195.00 34.13 229.13

Load floor cover - rubber • 75.00 13.13 88.13

Parking sensors - rear • 215.00 37.63 252.63

Satellite navigation A - monochrome screen, includes trip computer

(not with steering wheel - leather trimmed) 3 _• _775.00 _{135.63 910.63}

Satellite navigation B - colour DVD, includes trip computer 4_• _1,440.00 _{252.00 1,692.00}

Steering wheel - leather trimmed, multi-function with trip computer

(only with satellite navigation B) • 275.00 48.13 323.13

Towbar - fixed ball with 13 pin socket 5_•_305.00 _{53.38 358.38}

Trip computer (included with satellite navigation and steering wheel - leather) • 110.00 19.25 129.25

Tyres - all weather • 100.00 17.50 117.50

Alarm pack A - perimeter with back-up horn

(includes 2nd key for remote locking) • 130.00 22.75 152.75

Alarm pack B - with interior (cab only) and tow away protection

(includes 2nd key for remote locking) • 160.00 28.00 188.00

Cab comfort pack 6_•_215.00 _{37.63 252.63}

Electric pack - electric windows and electrically heated and adjustable mirrors • 260.00 45.50 305.50

Smoking pack - ashtray and cigarette lighter • 15.00 2.63 17.63

Visibility pack A - front fog lights, headlight washers, heated washer jets

and washer fluid level indicator • 270.00 47.25 317.25

Visibility pack B - rain sensor, automatic dimming rear view mirror

and ‘coming home’ function • 100.00 17.50 117.50

Airbag pack A - front passenger with deactivation • 175.00 30.63 205.63

Airbag pack B - front passenger with deactivation and side airbags • 325.00 56.88 381.88

Bulkhead pack A - deleted • 0.00 0.00 0.00

Rear door pack A - wing doors with opaque glass,

without heated rear window and wash/wipe • 0.00 0.00 0.00

Rear door pack B - tailgate with heated rear window

and wash/wipe (not with ladder flap) • 0.00 0.00 0.00

Side door pack A - left and right • 235.00 41.13 276.13

Air conditioning - ‘climatic’, semi-automatic • 735.00 128.63 863.63

Seats - leatherette upholstery • 20.00 3.50 23.50

Seats - Robust upholstery • 30.00 5.25 35.25

Seat pack A - heated driver and front passenger seats • 190.00 33.25 223.25

23 22

(12)

Caddy van.

The height measurements listed here can differ by approx. ± 50mm depending on equipment.

Gross vehicle weight

Model kg Engine

Axle load limit front / rear kg Trailer weight braked / unbraked* kg Gross train weight kg Unladen weight kg Payload kg

The payload includes the driver at 75kg. Actual weights may vary by model specification. Roof load limit: Caddy van 100kg.

Trailer nose weight limit: Caddy van 80kg. * For 12% gradient.

Weights are for vehicles with standard specification. The addition of factory options or Volkswagen Van Centre fitted accessories may affect unladen weight and payload.

69PS SDI PD

Electrics.

• Available - Not available

1_{The 104PS TDI PD diesel engine with}

6 speed DSG semi-automatic gearbox is equipped with a Diesel Particulate Filter (DPF) as standard torque ( Nm) engine speed (rpm) output torque

10 4P

S

output ( PS ) engine speed (rpm) output torque

69 P

S

output ( PS ) _{torque (} Nm)

Direct Shift Gearbox.

Caddy van engine specifi cations.

Caddy van dimensions and weights.

69PS SDI PD 2.0l 53.3 (5.3) 20.1 88 104PS TDI PD 1.9l 55.4 (5.1) 13.0 103 104PS TDI PD DSG 1.9l 50.4 (5.6) 13.0 103 140PS TDI PD 2.0l TBC 10.1 116

Caddy van.

Acceleration mph 0-62 Top speed

(where the law permits) mph

Engine

Constant 56mph (90km/h) mpg (l/100km)2

The award winning and highly acclaimed Direct Shift Gearbox

(DSG) is unique to the commercial vehicle market and operates

with two automatic clutches – while one is engaged, the other is

ready and to accept the next gear. This twin clutch technology

means you can change gear much faster than with a standard

automatic gearbox – actually in less than four hundredths of

a second.

This means that for stop-start round city work the DSG comes

into its own, making life much easier for the driver. Of course

you can still change gear manually if you prefer!

104PS TDI PD 140PS TDI PD 1000 2000 3000 4000 5000 6000 0 20 40 60 80 100 120 160 140 100 50 150 200 250 300 350

140P

S

output ( PS ) engine speed (rpm) output torque torque ( Nm) Wheelbase 2,682

Load compartment length1_1,781

width 1,558

height 1,257

volume 3.2m3

Lateral sliding door width 700

height 1,108

Rear wing doors width 1,181

height 1,116

Turning circle (wall to wall) 11.1m

1 _{With bulkhead (half-height, with plastic}

mesh upper).

Dimensions in mm unless otherwise indicated.

C20 2,185 69PS SDI PD 2.0l 1,050 / 1,230 1,325 / 720 3,500 1,465 720

2,211 104PS TDI PD 1.9l 1,065 / 1,230 1,425 / 740 3,500 1,491 724

2,240 104PS TDI PD DSG 1.9l 1,090 / 1,230 1,425 / 750 3,500 1,520 720

2,222 140PS TDI PD 2.0l 1,075 / 1,230 1,500 / 740 3,500 1,471 751

Engine type Transverse, water cooled in line Transverse, water cooled in line, variable geometry turbocharger with intercooler Mixture preparation/injection method Unit injector pump direct injection

Exhaust emission standard EU 4

No. of cylinders 4

Cubic capacity, cm3_{1,968 1,896 1,968}

Output, PS at rpm 69 at 4,200 104 at 4,000 140 at 4,000

Torque, max. Nm/rpm 140/2,200 250/1,900 320/1,800 – 2,500

Diesel Particulate Filter (DPF) - -1 _•

5-speed manual gearbox • •

6-speed manual gearbox - - •

6-speed semi-automatic

DSG gearbox - •

-Front wheel drive • • •

Alternator (all variants) 110A

Battery 61Ah (330A)

Caddy van fuel consumption and performance.

2_{With 50% payload.}

The figures listed apply to vehicles without optional extras.

25 24

(13)

Main features of the Transporter range include:

• Load volumes from 5.8m

3

_{to 9.3m}

3

• Payloads from 802kg up to 1,383kg

• 4 TDI PD diesel engines from 84PS to 174PS

• Short or long wheelbase

• Low, medium or high roof

• Solid twin rear doors as standard or

optional tailgate

• Left side sliding door as standard

• Dual passenger seat with folding backrest

provides additional load length.

More detailed specifications and options can be

found on the following pages.

The Volkswagen Transporter.

The world-renowned Transporter has grown a

solid reputation from year to year, winning many

awards along the way. Packed full of innovative

ideas, the latest Transporter is even better

equipped than any of its predecessors. And that’s

not surprising. You’d be hard pushed to fault this

vehicle - its versatility, features, specification and

overall good looks make it a winner for all kinds

of businesses, and for all kinds of reasons.

As an example of the outstanding technology

that has been invested in this range, there are

four innovative and extremely economical TDI

‘Pumpe Duese’ (PD) diesel engines. These provide

outstanding load-pulling capability, great fuel

economy, and make the Transporter an absolute

pleasure to drive.

Load fl oor showing accommodation of euro-pallets.

4,890mm (5.8m3_{) (Short wheelbase)}

5,290mm (9.3m3_{) (Long wheelbase)}

Image 01 shows optional half-height bulkhead, second side sliding door right and full height load side lining. Image 02 shows optional second side sliding door right and medium roof.

01

02

27 26

(14)

Body.

• 80 litre lockable fuel tank • Black wheel centre caps

• Externally adjustable exterior mirrors: - Convex on passenger’s side - Spherical on driver’s side

• Front and rear towing eyes • Galvanised full steel body • Grey bumpers

• Heat reflective glass

• Jack and tool kit (heavy duty on T32 models) with steel spare wheel

• Unglazed rear wing doors

Transporter panel van standard specifications.

Interior.

Cab area:

• 2 folding and pivoted sun visors • Dash mounted gear lever • Driver's seat with height, lumbar,

reach and rake adjustment

• Dual passenger seat with storage box and folding seat backrest (fixed backrest with optional bulkheads)

• ‘Inca’ fabric seat covers • Interior light

• Rubber floor covering

• Storage:

- 2 storage compartments in dash panel - 2 storage compartments in driver’s door - 2 storage compartments in passenger door - Drinks holder

- Lockable glove compartment

- Open storage compartment in dash panel including mobile phone holder

- Overhead storage

- Storage net on lower dash passenger side

Rear:

• 2 door–activated interior lights (3 with optional high roof)

• Half height load side lining in hardboard • Interior entry step

• Interior roof trim in painted hardboard (low roof only)

• Load lashing rings (SWB: 6, LWB: 8) • Rear door interior release lever • Sheet steel flooring

• Side sliding door on left

Functional.

• 12V socket • Digital clock

• Manually controlled heating system with dust and pollen filter and air recirculation

• Radio/single CD player (2 DIN) with 2 speakers

• Remote central locking with deadlocks and 2 remote keys

• Rev counter

• Warning buzzer for lights left on

Technical.

- Anti-roll bars, front and rear (T26 front only)

- Front McPherson strut suspension - Independent suspension - Rear miniblock springs - Telescopic shock absorbers

• Hydraulic brake system with ventilated disc brakes

• Power steering

• Rear differential lock (4MOTION®_only)

• Steel wheels: 6.5J x 16

• Tyres: 205/65 R16

(on 84 and 102PS versions) 215/65 R16

(on 130 and 174PS versions)

Safety and security.

• 3rd brake light

• ABS: Anti-lock Braking System • Breaksafe steering wheel lock • Driver and passenger airbags

• EBC: Engine Braking Control (not 4MOTION®₎

• EBD: Electronic Brakeforce Distribution

• Electronic immobiliser ‘Transponder’ • Halogen main headlights with range control • Height adjustable head restraints

• Height adjustable, tensioning seat belts for all outer cab seats

• Height and rake adjustable safety steering column

• Rear fog light

• TCS: Traction Control System (not 4MOTION®₎

• Three-point inertia reel seat belts for all seats

Radio/CD player. Rear wing doors. Dash mounted gear lever. Storage in driver and front passenger doors. Side sliding door. Driver and passenger airbags.

29 28

(15)

See the passenger carrier brochure for more information.

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP Model excluding VAT £ † Ins. group** including VAT £ †

Panel van short wheelbase.

Panel van long wheelbase.

Transporter panel van recommended retail prices.

The Transporter with optional kombi pack.

Main features include:

• Carries up to 5 passengers (plus driver)

plus your load

• Short or long wheelbase

• Tailgate as standard, rear doors optional

• Heated rear window

• Left side sliding door with windows

• 3 TDI PD diesel engines from 102PS to 174PS

• Low, medium or high roof

• ABS and driver and passenger airbags.

The Transporter window van with optional kombi

pack is the dual-purpose passenger/load carrying

combination. If you need to carry up to 5 passengers

and take loads of other equipment with you in the

back, then this option is for you. This way you can

delete the rear side windows to conceal the load,

and add a second row of seats to take additional

passengers. Just specify a kombi pack on the T32

Transporter window van.

*OTR (on the road) package for panel vans includes the following:

VAT £81.17

Total £780.00

** Insurance group: As advised by the Association of British Insurers (ABI). Please see www.abi.org.uk/carinsurance for more information.

T26 84PS TDI PD 7HAA62 13,890.00 2,430.75 16,320.75 14,588.83 17,100.75 5E-T2

T28 84PS TDI PD 7HAB62 14,240.00 2,492.00 16,732.00 14,938.83 17,512.00 6E-T2

102PS TDI PD 7HAB72 14,960.00 2,618.00 17,578.00 15,658.83 18,358.00 6E-T2

130PS TDI PD 7HAB01 16,160.00 2,828.00 18,988.00 16,858.83 19,768.00 6E-T2

174PS TDI PD 7HAB11 17,640.00 3,087.00 20,727.00 18,338.83 21,507.00 6E-T2

T30 84PS TDI PD 7HHC62 15,070.00 2,637.25 17,707.25 15,768.83 18,487.25 6E-T2

102PS TDI PD 7HHC72 15,790.00 2,763.25 18,553.25 16,488.83 19,333.25 6E-T2

130PS TDI PD 7HHC01 16,990.00 2,973.25 19,963.25 17,688.83 20,743.25 6E-T2

130PS TDI PD Tiptronic 7HHC03 17,990.00 3,148.25 21,138.25 18,688.83 21,918.25 6E-T2

130PS TDI PD 4MOTION® ₇_HHC₀₅ _19,190.00 _3,358.25 _22,548.25 _19,888.83 _23,328.25 _6E-T2 174PS TDI PD 7HHC11 18,470.00 3,232.25 21,702.25 19,168.83 22,482.25 6E-T2

T32 102PS TDI PD 7HHD72 16,140.00 2,824.50 18,964.50 16,838.83 19,744.50 7E-T2

130PS TDI PD 7HHD01 17,340.00 3,034.50 20,374.50 18,038.83 21,154.50 7E-T2 T30 84PS TDI PD 7HAC62 14,590.00 2,553.25 17,143.25 15,288.83 17,923.25 6E-T2

102PS TDI PD 7HAC72 15,310.00 2,679.25 17,989.25 16,008.83 18,769.25 6E-T2

130PS TDI PD 7HAC01 16,510.00 2,889.25 19,399.25 17,208.83 20,179.25 6E-T2

130PS TDI PD Tiptronic 7HAC03 17,510.00 3,064.25 20,574.25 18,208.83 21,354.25 6E-T2

130PS TDI PD 4MOTION® ₇_HAC₀₅ _18,710.00 _3,274.25 _21,984.25 _19,408.83 _22,764.25 _6E-T2 174PS TDI PD 7HAC11 17,990.00 3,148.25 21,138.25 18,688.83 21,918.25 6E-T2

T32 102PS TDI PD 7HAD72 15,660.00 2,740.50 18,400.50 16,358.83 19,180.50 6E-T2

130PS TDI PD 7HAD01 16,860.00 2,950.50 19,810.50 17,558.83 20,590.50 7E-T2

31 30

(16)

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP T32 LWB SWB

Paint options.

16" ‘Miyato’ alloy wheel. 17" ‘Solace’ alloy wheel. Cruise control. Full-height load side lining.

T30 T32 T30 T28 T26

Factory fitted options.

Options packs.

T30 T32 T30 T28 T26

Roof load rack preparation. Satellite navigation system. • Options.

- Not available.

Transporter panel van factory options.

Airbag packs.

Metallic and pearl paint • • • • • • 460.00 80.50 540.50

Black paint - 9000 • • • • • • 265.00 46.38 311.38

Danish blue paint - 9506 • • • • • • 100.00 17.50 117.50

Stone blue paint - 9544 • • • • • • 100.00 17.50 117.50

1_{Battery - second:}_{72Ah with dual passenger seat, 80Ah with single passenger seat.}

2_ESP:_{Also includes Active Rollover Protection (ARP), maximum brake support (more}

braking power for fully loaded vehicles), prefill (to reduce stopping distance/time), fading brake support and improved hydraulic brake assist.

3_{Load side lining:}_{Side panels covered to roof, tailgate/rear doors only half-height.}

4_Towbars:_{An adaptor is available from Van Centres, to allow connection to twin}

7 pin sockets. Only one front towing eye with towbars.

5_{Battery uprated to 80Ah on 84/102PS engines, 95Ah on 130/174PS engines.}

6_{Alarm pack B:}_{Battery uprated to 95Ah.}

7_{Cab comfort pack:}_{‘Box’ fabric seat trim, carpet in cab, storage compartments in}

outer side of driver and passenger seats, vanity mirrors, sunglasses holder, interior light delay, 2 reading lights, instrument dimmer, grab handle at ‘A’ pillar (left), two tone horn and additional noise suppression measures.

8_{It is not possible to select alternative equipment to that specified.}

9_{Satellite navigation A:}_{Replaces radio/in-dash CD player, includes RDS radio}

function with single CD and CD changer control, where fitted (audio CDs cannot be played when using navigation function).

10_{Satellite navigation B:}_{Replaces radio/in-dash CD player, includes RDS radio}

function and CD changer control, where fitted (audio CDs cannot be played). Alloy wheels - ‘Miyato’ 16" with 215/65 R16 tyres,

4 with steel spare (84/102PS engines only) • • • - • - 425.00 74.38 499.38

Alloy wheels - ‘Miyato’ 16", 4 with steel spare

(130/174PS engines only) - • • - • - 335.00 58.63 393.63

Alloy wheels - ‘Solace’ 17" with 235/55 R17 tyres, 4 with steel

spare (130/174PS engines only, not with tyres - all weather) - • • - • - 885.00 154.88 1,039.88

Battery - second1 _{• • • • • •}_120.00 _{21.00 141.00}

CD changer - six disc • • • • • • 245.00 42.88 287.88

Cruise control • • • • • • 155.00 27.13 182.13

ESP2 _{• • • • • •}_285.00 _{49.88 334.88}

Fog lights - front • • • • • • 130.00 22.75 152.75

Load floor cover - rubber, with step light (SWB only) • • • • - - 115.00 20.13 135.13

(LWB only) - - - - • • 130.00 22.75 152.75

Load side lining - full-height hardboard3 _(SWB_only) _{• • • • - -}_{140.00 24.50 164.50}

(LWB only) - - - - • • 165.00 28.88 193.88

Mud flaps - front and rear • • • • • • 85.00 14.88 99.88

Parking brake - hill hold control (includes ESP) • • • • • • 325.00 56.88 381.88

Parking sensors - rear • • • • • • 180.00 31.50 211.50

Roof load rack preparation

(not with medium or high roof packs) • • • • • • 65.00 11.38 76.38

Smoking pack - ashtray, cigarette lighter and cup holder • • • • • • 15.00 2.63 17.63

Sunroof - glass, electric, front (not with roof

ventilation/extraction - rear compartment, medium or high roof

packs, bulkhead packs A, B, C, E, F or G, or side door pack A) • • • • • • 430.00 75.25 505.25

Tachograph - digital, includes console on dash • • • • • • 430.00 75.25 505.25

Towbar - fixed ball with 13 pin socket4 _{• • • • • •}_330.00 _{57.75 387.75}

Towbar - removable ball with 13 pin socket4 _{• • • • • •}_410.00 _{71.75 481.75}

Trip computer (included with satellite navigation) • • • • • • 100.00 17.50 117.50

Tyres - all weather, 215/65 R16 (84/102PS engines only) • • • • • • 180.00 31.50 211.50

Tyres - all weather (130/174PSengines only,

not with alloy wheels - ‘Solace’ 17") - • • • • • 85.00 14.88 99.88

Alarm pack A - perimeter with back-up horn5 _{• • • • • •}_120.00 _{21.00 141.00}

Alarm pack B - with interior (cab only) and tow away protection (not with medium or high roof packs

or roof ventilation/extraction)6 _{• • • • • •}_140.00 _{24.50 164.50}

Cab comfort pack7 _{• • • • • •}_240.00 _{42.00 282.00}

Electric pack B - electric windows, electrically heated and

adjustable mirrors and internal central locking control • • • • • • 310.00 54.25 364.25

Electric pack C - electric windows, electrically heated, adjustable

and folding mirrors and internal central locking control • • • • • • 385.00 67.38 452.38

S pack - alarm pack A, bulkhead pack A, electric pack B8 _{• • • • • •}_470.00 _{82.25 552.25}

SE pack - air conditioning pack A, alarm pack A, bulkhead pack A,

electric pack B, seat pack A8 _{• • • • • •}_1,020.00 _{178.50 1,198.50}

Satellite navigation A - monochrome screen, includes

trip computer 5, 9 _{• • • • • •}_1,130.00_197.75_1,327.75

Satellite navigation B - colour screen, includes

trip computer 5, 10 _{• • • • • •}_1,720.00 _{301.00 2,021.00}

Visibility pack A - headlamp washers, fluid level indicator

and heated washer jets • • • • • • 155.00 27.13 182.13

Visibility pack B - rain sensor and automatic dimming

rear view mirror • • • • • • 80.00 14.00 94.00

Airbag pack C - side and front curtain airbags (only with seat pack B) • • • • • • 225.00 39.38 264.38

33 32

(17)

Parking sensors. Bulkhead - full-height. Air conditioning. Headlight cleaning system. Comfort seats for driver and front passenger. Tailgate. Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP T32 LWB SWB

Door packs.

T30 T32 T30 T28 T26

Heating and ventilation.

Roof packs.

Seat packs.

T30 T32 T30 T28 T26

Bulkhead packs.

• Options. - Not available.

Transporter panel van factory options. (continued)

11_{Vehicles with through vision have a rear view mirror with anti-dazzle function.}

12 _{Bulkhead packs:}_{Dual passenger seat has fixed backrest with optional bulkheads.}

13_{Uprated alternator:}_{120A on 84/102PS engines, 150A on 130/174PS engines.}

14_{Roof packs:}_{Please confirm availability with your Volkswagen Van Centre.}

15_{Comfort seat:}_{Adds armrest (height adjustment and lumbar support standard for}

driver’s seat).

16_{Comfort seats:}_{Add armrests for both front seats, passenger height adjustment and}

lumbar support (height adjustment and lumbar support standard for driver’s seat). Rear doors - 250° hinges (not with rear door packs A or B) - - - - • • 235.00 41.13 276.13

Rear door pack A - tailgate with heated rear window

and wash/wipe (not with high roof packs) 11 _{• • • • • •} _-30.00 _{-5.25 -35.25}

Rear door pack B - tailgate without window (not with high roof packs) • • • • • • -120.00 -21.00 -141.00

Rear door pack C - wing doors with heated rear windows

and wash/wipe (included with roof packs E and F) 11 _{• • • • • •} _90.00 _{15.75 105.75}

Side door pack A - right only (no left door), manual (not with sunroof) • • • • • • 0.00 0.00 0.00

Side door pack B - left and right, manual (not with high roof packs) • • • • • • 380.00 66.50 446.50

Air conditioning pack A - manual, dash13 _{• • • • • •}_620.00 _{108.50 728.50}

Charcoal canister - for ventilation system • • • • • • 15.00 2.63 17.63

Roof ventilation/extraction - rear compartment

(not with alarm pack B or sunroof) • • • • • • 265.00 46.38 311.38

Roof pack A - medium, white (not with alarm pack B, roof load

rack preparation or sunroof)14 _{- • • - • •}_390.00 _{68.25 458.25}

Roof pack B - medium, body-coloured (not with alarm pack B,

roof load rack preparation or sunroof)14 _{- • • - • •}_475.00_83.13_558.13

Roof pack C - high, white, includes high rear wing doors without windows (not with alarm pack B, roof load rack preparation,

sunroof or side door pack B) (not with T30 LWB 102PS)14 _{- - - - • •}_670.00 _{117.25 787.25}

Roof pack D - high, body-coloured, includes high rear wing doors without windows (not with alarm pack B, roof load rack

preparation, sunroof or side door pack B) (not with T30 LWB 102PS)14 _{- - - - • •}_780.00 _{136.50 916.50}

Roof pack E - high, white, includes high rear wing doors with heated rear windows and wash/wipe (not with alarm pack B, roof load rack preparation, sunroof or side door pack B)

(not with T30 LWB 102PS)11, 14 _{- - - - • •}_760.00 _{133.00 893.00}

Roof pack F - high, body-coloured, includes high rear wing doors with heated rear windows and wash/wipe (not with alarm pack B, roof load rack preparation, sunroof or side door pack B)

(not with T30 LWB 102PS)11, 14 _{- - - - • •}_870.00 _{152.25 1,022.25}

Seats - leatherette upholstery • • • • • • 25.00 4.38 29.38

Seats - robust upholstery (only with seat pack B) • • • • • • 75.00 13.13 88.13

Seats - ‘Duo’ cloth upholstery (only with seat pack B,

not with bulkhead packs A, B, C, E, F or G) • • • • • • 110.00 19.25 129.25

Seat pack A - driver’s comfort seat15 _{• • • • • •} _50.00 _{8.75 58.75}

Seat pack B - driver and single passenger comfort seats16 _{• • • • • •} _15.00 _{2.63 17.63}

Seat pack F - heated driver’s seat13 _{• • • • • •}_105.00 _{18.38 123.38}

Seat pack G - heated driver and front passenger seats13 _{• • • • • •}_210.00 _{36.75 246.75}

Bulkhead pack A - high, without window

(not with ‘Duo’ upholstery or sunroof)12 _{• • • • • •} ₁₄₀_.00_{24.50 164.50}

Bulkhead pack B - high, with window

(not with ‘Duo’ upholstery or sunroof)11, 12 _{• • • • • •} _170.₀₀_29.75 _199.75

Bulkhead pack C - high, with sliding window

(not with ‘Duo’ upholstery or sunroof)11, 12 _{• • • • • •}_205.00_{35.88 240.88}

Bulkhead pack D - low 11, 12 _{• • • • • •} ₈₀_.00_{14.00 94.00}

Bulkhead pack E - high, without window, includes load lashing rails (not with ‘Duo’ upholstery, load side lining - full-height

hardboard or sunroof)12

(SWB only) • • • • - - 455.00 79.63 534.63

(LWB only) - - - - • • 510.00 89.25 599.25

Bulkhead pack F - high, with window, includes load lashing rails (not with ‘Duo’ upholstery, load side lining - full-height hardboard or sunroof) 11, 12

(SWB only) • • • • - - 485.00 84.88 569.88

(LWB only) - - - - • • 540.00 94.50 634.50

Bulkhead pack G - high, with sliding window, includes load lashing rails (not with ‘Duo’ upholstery, load side lining - full-height hardboard or sunroof) 11, 12

(SWB only) • • • • - - 520.00 91.00 611.00

(LWB only) - - - - • • 575.00 100.63 675.63

35 34

(18)

Panel van long wheelbase low, medium and high roof.

Model kg Engine

Axle load limit front / rear kg Trailer weight braked / unbraked* kg Gross train weight kg Unladen weight** kg Payload*** kg

Panel van short wheelbase low and medium roof.

Model kg Engine

Axle load limit front / rear kg Trailer weight braked / unbraked* kg Gross train weight kg Unladen weight** kg Payload*** kg

Transporter panel van dimensions and weights.

low med high Roof height

low med

Roof height

Wheelbase 3,000 3,000

Load compartment length 2,570 2,570

width 1,692 1,692

height 1,410 1,626

area 4.3m2 _4.3m2

volume 5.8m3_6.7m3

Width

(between wheel housings) 1,244 1,244 Lateral sliding door width 1,020 1,020

height 1,284 1,284

Rear doors width 1,485 1,485

height 1,305 1,305

Turning circle (wall to wall) 11.9m 11.9m

T30 3,000 84PS TDI PD 1,575 / 1,625 2,200 / 750 4,800 1,829 1,171 102PS TDI PD 1,575 / 1,625 2,200 / 750 4,900 1,829 1,171 130PS TDI PD 1,575 / 1,625 2,500 / 750 5,200 1,903 1,097 130PS TDI PD Tiptronic 1,575 / 1,625 2,500 / 750 5,200 1,903 1,097 130PS TDI PD 4MOTION® _{1,575 / 1,625} _{2,500 / 750} _5,300 _2,004 ₉₉₆ 174PS TDI PD 1,575 / 1,625 2,500 / 750 5,200 1,903 1,097 T32 3,200 102PS TDI PD 1,650 / 1,720 2,200 / 750 5,200 1,849 1,351 130PS TDI PD 1,650 / 1,720 2,500 / 750 5,200 1,919 1,281

Roof load limit and trailer nose weight are both 100kg.

Vehicles with medium or high roof have no provision for roof loads. * For 12% gradient.

** Unladen weight includes full tank of fuel, excludes crew.

*** Payload with full tank of fuel, excluding crew. Payload = gross vehicle weight - unladen weight.

Weights are for vehicles with standard specification. The addition of factory options or Volkswagen Van Centre fitted accessories may affect unladen weight and payload.

T26 2,600 84PS TDI PD 1,400 / 1,400 2,200 / 750 4,800 1,798 802 T28 2,800 84PS TDI PD 1,450 / 1,550 2,200 / 750 4,800 1,798 1,002 102PS TDI PD 1,450 / 1,550 2,200 / 750 4,900 1,798 1,002 130PS TDI PD 1,575 / 1,550 2,500 / 750 5,200 1,872 928 174PS TDI PD 1,575 / 1,550 2,500 / 750 5,200 1,872 928 T30 3,000 84PS TDI PD 1,500 / 1,625 2,200 / 750 4,800 1,798 1,202 102PS TDI PD 1,500 / 1,625 2,200 / 750 4,900 1,798 1,202 130PS TDI PD 1,575 / 1,625 2,500 / 750 5,200 1,872 1,128 130PS TDI PD Tiptronic 1,575 / 1,625 2,500 / 750 5,200 1,872 1,128 130PS TDI PD 4MOTION® _{1,575 / 1,625} _{2,500 / 750} _5,300 _1,972 _1,028 174PS TDI PD 1,575 / 1,625 2,500 / 750 5,200 1,872 1,128 T32 3,200 102PS TDI PD 1,630 / 1,720 2,200 / 750 5,200 1,817 1,383 130PS TDI PD 1,650 / 1,720 2,500 / 750 5,200 1,891 1,309

The height measurements listed here may differ by approx ± 50mm

depending on equipment fitted. Please note vehicle drawings are not to scale.

Wheelbase 3,400 3,400 3,400 Load compartment length 2,970 2,970 2,970

width 1,692 1,692 1,692

height 1,410 1,626 1,940

area 5.0m2 _5.0m2 _5.0m2

volume 6.7m3_7.8m3_9.3m3

Width

(between wheel housings) 1,244 1,244 1,244 Lateral sliding door width 1,020 1,020 1,020

height 1,284 1,284 1,284

Rear doors width 1,485 1,485 1,485

height 1,305 1,305 1,694

Turning circle (wall to wall) 13.2m 13.2m 13.2m

Indicates optional roof height. Indicates optional roof height.

37 36

(19)

84PS TDI PD 102PS TDI PD 130PS TDI PD 174PS TDI PD

Electrics.

1000 2000 3000 4000 5000 0 10 20 30 40 50 60 70 80 90 100 100 120 140 160 180 200 1000 2000 3000 4000 5000 0 20 40 60 80 100 120 140 130 170 210 250 290 1000 2000 3000 4000 5000 0 20 40 60 80 100 120 140 180 240 300 360 1000 2000 3000 4000 5000 0 20 40 60 80 100 120 140 160 180 200 150 200 250 300 350 400 • Available - Not available • Optional

84 P

S

output ( PS ) _{torque (} Nm) engine speed (rpm) output torque

102P

S

130P

S

17 4P

S

All variants 84PS TDI PD 43.5 (6.5) 23.6 91

102PS TDI PD 46.3 (6.1) [44.1 (6.4)] 18.4 [18.6] 99 [96]

130PS TDI PD 44.8 (6.3) 15.3 104

130PS TDI PD Tiptronic** 41.5 (6.8) 15.4 102

130PS TDI PD 4MOTION® † _{40.4 (7.0)} _16.3 ₁₀₃

174PS TDI PD 43.5 (6.5) 12.2 117

Panel van with low roof.

(all variants short and long wheelbase, T26, T28, T30 and T32*)

Acceleration mph 0-62

Top speed

(where the law permits) mph

Engine Model

Constant 56mph (90km/h) mpg (l/100km) ††

All variants 84PS TDI PD 43.5 (6.5) 24.1 88

102PS TDI PD 44.8 (6.3) [42.8 (6.6)] 18.9 [19.0] 96 [94]

130PS TDI PD 43.5 (6.5) 15.5 101

130PS TDI PD Tiptronic** 40.4 (7.0) 15.6 99

130PS TDI PD 4MOTION®†_39.2_(7.2) _16.4 ₉₉

174PS TDI PD 42.2 (6.7) 12.4 113

Panel van with medium roof.

(all variants short and long wheelbase, T28, T30 and T32*)

All variants 84PS TDI PD 39.2 (7.2) 24.7 85 102PS TDI PD - [40.4 (7.0)] - [19.3] - [91] 130PS TDI PD 40.4 (7.0) 15.8 98 130PS TDI PD Tiptronic** 37.7 (7.5) 15.9 96 130PS TDI PD 4MOTION®†_36.7_(7.7) _16.6 ₉₆ 174PS TDI PD 39.2 (7.2) 12.6 108

Panel van with high roof.

(long wheelbase, T30 and T32*)

Transporter panel van engine specifi cation.

Transporter panel van fuel consumption and performance.

4MOTION

®

_{– gets to grips with hard work.}

_{Tiptronic gearbox.}

Fully automatic gear changes or fully manual gear changes

at the tip of your finger – you choose!

The Tiptronic gearbox allows you the choice of moving from

automatic to manual gear changes simply by moving the gear

lever into a second shift gate. This then allows you to change

up or down manually through the gears which gives you greater

control under certain driving conditions.

Available on the 130PS engine, the Tiptronic gearbox even

features a sports mode to maximise responsiveness to

engine power.

Tiptronic – it’s the best of both worlds!

The Transporter 4MOTION

®

_{all wheel drive system is designed}

to maintain traction in poor surface conditions like rain, snow,

mud or gravel. By distributing drive to the wheels with the most

grip, 4MOTION

®

_{offers stable road-holding and enhanced safety,}

reacting to the slightest loss of traction in milliseconds.

Available with the 130PS engine, 4MOTION

®

_{is linked}

through control units to the vehicle’s dynamic sensors,

engine management system and gearbox, and is designed

to be compatible with ABS. All vehicles fitted with 4MOTION

®

also have a locking rear differential for additional traction in

extreme circumstances.

Engine type Transverse, water cooled in line variable turbine geometry turbocharger with intercooler Mixture preparation/injection method Unit injector pump direct injection

Exhaust emission standard EU 4

No. of cylinders 4 5

Cubic capacity, cm3_1,896 _2,460

Output, PS at rpm 84 at 3,500 102 at 3,500 130 at 3,500 174 at 3,500

Torque, max. Nm/rpm 200/2,000 250/2,000 340/2,000 400/2,000

Diesel particulate filter • • • •

5-speed manual gearbox • • -

-6-speed manual gearbox - - • •

6-speed Tiptronic auto - - •

-Front wheel drive • • • •

4MOTION®_{all wheel drive} _- _- _•

-Alternator 90A 150A

Battery 61Ah (330A) 72Ah (380A)

Figures in square brackets are for T32 models, where different. * 84PS not available on T32 models.

** Tiptronic not available on T32 models.

†_4MOTION®_{only available on T30 models.}

††_{With 50% payload and 80 litre fuel tank capacity.}

39 38

(20)

The Transporter Sportline.

Working hard never looked so good.

The Transporter Sportline range is designed to complement your lifestyle. These exciting models combine

desirability and practicality with the performance of a very capable 174PS diesel engine.

For more information, a Sportline brochure is available from your nearest Volkswagen Van Centre.

www.volkswagen-vans.co.uk/sportline

41 40

(21)

And these features are standard across the range:

• ABS

*

• ESP

*

_{(load adjusting)}

• TCS

*

• Class-leading side door - loads a

euro-pallet sideways

• Full height steel bulkhead

• Load-lashing rings

• Thatcham category 1 alarm system.

Other features and options are listed on the

following pages.

The Volkswagen Crafter.

The latest and largest addition to the Volkswagen

range, the Crafter’s chunky good looks only partially

reveal its underlying strengths. Powerful engines

with enough torque to satisfy the most demanding

business uses, enough space to fit in the most

awkward objects, and an array of features to

satisfy the most discerning of customers – all make

the Crafter the vehicle of choice for a huge range

of businesses.

And it is choice that marks the Crafter out as

special. Whatever your basic load-carrying

requirement is, be it length, weight or size, there is

a model in the Crafter range which will do the job.

We detail more of those choices on the following

pages, but these are the primary choices you get

from the Crafter panel van range:

• Load volumes from 7.5m

3

_{to 17.0m}

3

(load area takes up to 5 euro-pallets)

• Payloads from 986kg up to 2,465kg

• Low, high or extra high roof

• Completely new range of 4 TDI

common-rail diesel engines

• 3 wheelbase options

• 4 load lengths available.

Load fl oor showing accommodation of euro-pallets.

5,240mm (7.5m3_{) (Short wheelbase)}

5,905mm (11.5m3_{) (Medium wheelbase)} 6,940mm (15.0m3_{) (Long wheelbase)}

7,340mm (17.0m3_{) (Long wheelbase maxi)}

43 42

(22)

Body.

• 75 litre fuel tank with lockable cap • Black bumpers with integrated front step • Black wheel centre caps

• Externally adjustable external convex mirrors with indicators

• Front and rear towing eyes, (front only on CR50) • Heat reflective glass

• Jack and tool kit (CR30 and CR35 models) with steel spare wheel

• Lateral side marker lights (LWB and LWB maxi) • Sheet steel flooring • Side sliding door on left

• Tyre repair kit and compressor (CR50 models) • Unglazed rear wing doors

Crafter panel van standard specifications.

Interior.

Cab area:

• 2 folding and pivoted sun visors • Ashtray

• Driver’s seat with height, reach and rake adjustment

• Dual passenger seat with storage box and folding tray in backrest

• Grab handles

• ‘Inca’ fabric seat covers

• Interior light (including 2 reading lights) • Rubber floor covering

• Storage:

- 5 drinks holders

- Document holder on centre console - Glove compartment

- Overhead storage (max load 5kg) - Storage compartment in right step - Storage compartments (open and closed)

in doors

- Storage tray in centre console - Storage tray on dashboard

Rear:

• Door-activated interior lighting

• Full height steel bulkhead without window • Interior side door entry step

• Load lashing rings - 2 on ‘B’ pillar • Load lashing rings - floor mounted

(SWB: 6, MWB: 8, LWB: 10, LWB maxi: 12) • Rear door interior release lever

Functional.

• 12V socket with cigarette lighter • Digital clock

• Digital tachograph (CR50 only) • Dimmable dashboard illumination • Electric windows

• Manually controlled heating system with charcoal filter and air recirculation • Parking lights (SWB and MWB) • Radio/single CD player with 5 speakers • Remote central locking with 2 remote keys

• Rev counter

• Speed limiter 56mph (90km/h) (CR50 models) • Warning buzzer for lights left on

Technical.

- Anti-roll bar, front (front and rear on all CR50 and LWB CR35 panel van) - Front transverse leaf spring

independent suspension - Rear rigid axle with leaf springs

(CR30 and CR35 panel van only - single leaf, CR50 - triple leaf)

- Telescopic shock absorbers

• Hydraulic brake system with front ventilated and rear solid disc brakes (front and rear ventilated on CR50)

• Power steering • Rear wheels:

- Single: CR30 and CR35 - Twin: CR50

• Steel spare wheel (CR30 and CR35)

Note: replaced by tyre repair kit with optional full width rear step

• Steel wheels: 51/2J x 16 (CR30 and CR50 only) 61/2J x 16 (CR35 only) • Tyres: 205/75 R16C (CR30 only) 235/65 R16C (CR35 only) 195/75 R16C (CR50 only)

Safety and security.

• 3rd brake light

• ABS: Anti-lock Braking System • Brake pad wear, failure and fluid

level indicators • Driver’s airbag

• EBA: Electronic Brake Assist

• EBD: Electronic Brakeforce Distribution • EDL: Electronic Differential Lock • ESP: Electronic Stabilisation Programme

- load adjusting

• Electronic steering wheel lock • Engine immobiliser ‘Transponder’ • Halogen main headlights with headlight

range control

• Height adjustable head restraints • Height adjustable seat belts for all outer

cab seats • Rear fog light

• Seat belt warning light for driver • TCS: Traction Control System

• Thatcham Category 1 alarm with interior (front and rear) and tow-away protection and back-up horn

• Three point inertia reel seat belts for all seats

Alarm system. Shows sliding bulkhead optional. Fold down tray - integral to dual passenger seat. Full height steel bulkhead. Overhead console with two reading lights. Overhead storage. Radio/CD player.

45 44

(23)

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP Model excluding VAT £ † Ins. group# including VAT £ †

Crafter panel van recommended retail prices.

Total retail including VAT £ † VAT £ † Basic retail excluding VAT £ † Manufacturer’s RRP CR50 high roof LWB maxi CR30 CR35 CR50 CR35 CR50 CR35 LWB MWB low roof SWB

Paint options.

Factory fitted options.

Multi-function steering wheel. Full width rear step. Sliding and tilting sunroof.

Crafter panel van factory options.

• Options. - Not available. s Standard equipment.

†_{Calculated at}₁_{7.5% on all products.}

Panel van short wheelbase.

Panel van medium wheelbase high roof.

Panel van long wheelbase high roof.

Panel van long wheelbase maxi

**

high roof.

*OTR (on the road) package for CR30 and CR35 panel vans includes the following:

VAT £86.38

Total £815.00 *OTR (on the road) package for CR50 panel vans (HGV, Band A) includes the following:

VAT £86.38

Total £800.00

Deep black paint- 3902 • • • • • • • 370.00 64.75 434.75

Metallic paint - (includes wooden load floor cover)

SWB • - - - 880.00 154.00 1,034.00

MWB - • • - - - - 940.00 164.50 1,104.50

LWB - - - • • - - 1,000.00 175.00 1,175.00

LWB maxi - - - • • 1,060.00 185.50 1,245.50

Pearl effect paint - (includes wooden load floor cover)

SWB • - - - 920.00 161.00 1,081.00

MWB - • • - - - - 980.00 171.50 1,151.50

LWB - - - • • - - 1,040.00 182.00 1,222.00

LWB maxi - - - • • 1,100.00 192.50 1,292.50

Danish blue paint- 9506 • • • • • • • 100.00 17.50 117.50

Alloy wheels - 16" (235/65 R16C) (CR30 only) • - - - 530.00 92.75 622.75

Alloy wheels(CR35 only) - • - • - • - 400.00 70.00 470.00

Alternator - uprated 180A (not with battery - uprated or heated

windscreen, included with air conditioning) • • • • • • • 110.00 19.25 129.25

Alternator/Battery - uprated

(not with heated windscreen, tachograph - digital or CR50) • • - • - • - 135.00 23.63 158.63

Battery - uprated 110Ah (not with alternator - uprated,

heated windscreen or tachograph - digital, not CR50) • • s • s • s 25.00 4.38 29.38

CD changer (only with satellite navigation,

not with tachograph - digital or CR50 models) • • - • - • - 235.00 41.13 276.13

Cruise control • • • • • • • 180.00 31.50 211.50

Electric mirrors- heated and adjustable • • • • • • • 135.00 23.63 158.63

Fog lights- front, integrated in bumper • • • • • • • 95.00 16.63 111.63

Headlight washers(included with visibility pack) • • • • • • • 175.00 30.63 205.63

Heated windscreen (only with visibility pack, not with alternator

- uprated, alternator/battery uprated or battery - uprated) • • • • • • • 135.00 23.63 158.63

Keys- 2 additional keys • • • • • • • 50.00 8.75 58.75

Load floor cover - wooden - (not with load lashing rings - deleted)

SWB1 _{• - - -} _225.00 _{39.38 264.38}

MWB1 _{- • • - - - -} _285.00 _{49.88 334.88}

LWB1 _{- - - • • - -} _345.00 _{60.38 405.38}

LWB maxi1 _{- - - • •} _405.00 _{70.88 475.88}

1 _{Load floor cover:}_{Standard with metallic/pearl effect paint.}

CR30 88PS TDI 2EA0A5 15,900.00 2,782.50 18,682.50 16,628.62 19,497.50 7E

109PS TDI 2EA0B5 17,100.00 2,992.50 20,092.50 17,828.62 20,907.50 N/A

CR35 88PS TDI 2ED1A5 20,700.00 3,622.50 24,322.50 21,428.62 25,137.50 9E

109PS TDI 2ED1B5 21,900.00 3,832.50 25,732.50 22,628.62 26,547.50 9E

109PS TDI ShiftMatic 2ED1BA 22,650.00 3,963.75 26,613.75 23,378.62 27,428.75 9E

136PS TDI 2ED1C5 22,800.00 3,990.00 26,790.00 23,528.62 27,605.00 9E

136PS TDI ShiftMatic 2ED1CA 23,550.00 4,121.25 27,671.25 24,278.62 28,486.25 9E

163PS TDI 2ED1D5 24,000.00 4,200.00 28,200.00 24,728.62 29,015.00 10E CR50 109PS TDI 2ED2B5 26,200.00 4,585.00 30,785.00 26,913.62 31,585.00 N/A

109PS TDI ShiftMatic 2ED2BA 26,950.00 4,716.25 31,666.25 27,663.62 32,466.25 N/A

136PS TDI 2ED2C5 27,130.00 4,747.75 31,877.75 27,843.62 32,677.75 N/A

136PS TDI ShiftMatic 2ED2CA 27,880.00 4,879.00 32,759.00 28,593.62 33,559.00 N/A

163PS TDI 2ED2D5 28,060.00 4,910.50 32,970.50 28,773.62 33,770.50 N/A

CR35 88PS TDI 2EH1A5 21,250.00 3,718.75 24,968.75 21,978.62 25,783.75 9E

109PS TDI 2EH1B5 22,450.00 3,928.75 26,378.75 23,178.62 27,193.75 9E

109PS TDI ShiftMatic 2EH1BA 23,200.00 4,060.00 27,260.00 23,928.62 28,075.00 9E

136PS TDI 2EH1C5 23,350.00 4,086.25 27,436.25 24,078.62 28,251.25 9E

136PS TDI ShiftMatic 2EH1CA 24,100.00 4,217.50 28,317.50 24,828.62 29,132.50 10E

163PS TDI 2EH1D5 24,550.00 4,296.25 28,846.25 25,278.62 29,661.25 10E CR50 109PS TDI 2EH2B5 26,800.00 4,690.00 31,490.00 27,513.62 32,290.00 N/A

109PS TDI ShiftMatic 2EH2BA 27,550.00 4,821.25 32,371.25 28,263.62 33,171.25 N/A

136PS TDI 2EH2C5 27,730.00 4,852.75 32,582.75 28,443.62 33,382.75 N/A

136PS TDI ShiftMatic 2EH2CA 28,480.00 4,984.00 33,464.00 29,193.62 34,264.00 N/A

163PS TDI 2EH2D5 28,660.00 5,015.50 33,675.50 29,373.62 34,475.50 N/A

CR35 109PS TDI 2EX1B5 22,700.00 3,972.50 26,672.50 23,428.62 27,487.50 9E

109PS TDI ShiftMatic 2EX1BA 23,450.00 4,103.75 27,553.75 24,178.62 28,368.75 9E

136PS TDI 2EX1C5 23,600.00 4,130.00 27,730.00 24,328.62 28,545.00 9E

136PS TDI ShiftMatic 2EX1CA 24,350.00 4,261.25 28,611.25 25,078.62 29,426.25 10E

163PS TDI 2EX1D5 24,800.00 4,340.00 29,140.00 25,528.62 29,955.00 10E

CR50 109PS TDI 2EX2B5 27,300.00 4,777.50 32,077.50 28,013.62 32,877.50 N/A

109PS TDI ShiftMatic 2EX2BA 28,050.00 4,908.75 32,958.75 28,763.62 33,758.75 N/A

136PS TDI 2EX2C5 28,230.00 4,940.25 33,170.25 28,943.62 33,970.25 N/A

136PS TDI ShiftMatic 2EX2CA 28,980.00 5,071.50 34,051.50 29,693.62 34,851.50 N/A

163PS TDI 2EX2D5 29,160.00 5,103.00 34,263.00 29,873.62 35,063.00 N/A

#_{Insurance group: As advised by the Association of British Insurers (ABI).}

Please see www.abi.org.uk/carinsurance for more information. ** Maxi = extended rear overhang.

47 46
