Noncontact Three-Dimensional Diffuse Optical

Imaging of Deep Tissue Blood Flow Distribution

Guoqiang Yu

University of Kentucky, [email protected]

Yu Lin

University of Kentucky, [email protected]

Chong Huang

University of Kentucky, [email protected]

Right click to open a feedback form in a new tab to let us know how this document benefits you.

Follow this and additional works at:

https://uknowledge.uky.edu/cbme_patents

Part of the

Biomedical Engineering and Bioengineering Commons

This Patent is brought to you for free and open access by the Biomedical Engineering at UKnowledge. It has been accepted for inclusion in Biomedical Engineering Faculty Patents by an authorized administrator of UKnowledge. For more information, please [email protected].

Recommended Citation

Yu, Guoqiang; Lin, Yu; and Huang, Chong, "Noncontact Three-Dimensional Diffuse Optical Imaging of Deep Tissue Blood Flow Distribution" (2018).Biomedical Engineering Faculty Patents. 14.

c12)

United States Patent

Yu et al.

(54) NONCONTACT THREE-DIMENSIONAL

DIFFUSE OPTICAL IMAGING OF DEEP TISSUE BLOOD FLOW DISTRIBUTION (71) Applicant: University of Kentucky Research

Foundation, Lexington, KY (US) (72) Inventors: Guoqiang Yu, Lexington, KY (US); Yu

Lin, Lexington, KY (US); Chong Huang, Lexington, KY (US) (73) Assignee: UNIVERSITY OF KENTUCKY

RESEARCH FOUNDATION, Lexington, KY (US)

( *) Notice: Subject to any disclaimer, the term ofthis patent is extended or adjusted under 35 U.S.C. 154(b) by 72 days.

(21) Appl. No.: 15/078,403 (22) Filed: Mar. 23, 2016

(65) Prior Publication Data

US 2016/0278715 Al Sep. 29, 2016

Related U.S. Application Data

(60) Provisional application No. 62/136,707, filed on Mar. 23, 2015. (51) Int. Cl. A61B 5/026 A61B 5/00 (52) U.S. Cl. (2006.01) (2006.01) (Continued) CPC ... A61B 517275 (2013.01); A61B 5/0075 (2013.01); A61B 5/0091 (2013.01); (Continued) las;ef l'vim-e:r : lt1Sldl· (aJ I Ro:::llion: ;hi�

I IIIII IIIIIIII Ill lllll lllll lllll lllll lllll lllll lllll lllll 111111111111111111

_{US009861319B2}

(IO)

Patent No.:

US 9,861,319 B2

Jan.9,2018

(45)

Date of Patent:

(58) Field of Classification Search

CPC ... A61B 5/0075 See application file for complete search history.

(56) References Cited

CN WO

U.S. PATENT DOCUMENTS 5,075,561 A 12/1991 Rioux

6,370,422 Bl 4/2002 Richards-Kortum et al. (Continued)

FOREIGN PATENT DOCUMENTS 103163111 A

2012053908 6/2013 4/2012 OTHER PUBLICATIONS

Lin, et al., Noncontact diffuse correlation spectroscopy for nonin­ vasive deep tissue blood flow measurement, Journal of Biomedical Optics, Jan. 2012 • vol. 17(1).

(Continued) Primary Examiner - Kennedy Schaetzle

(74) Attorney, Agent, or Firm - King & Schickli, PLLC

(57) ABSTRACT

The present invention provides for three-dimensional reflec­ tance diffuse optical imaging of deep tissue blood flow distribution that removes the need for probe-tissue contact, thereby allowing for such technology to be applied to sensitive, vulnerable, damaged, or reconstructive tissue. The systems utilize noncontact application and detection of near-infrared light through optical lens and detection through a linear array or two-dimensional array of avalanche photodiodes or a two-dimensional array of detectors pro­ vided by charge-coupled-device (CCD). Both further feature a finite-element-method (FEM) based facilitation to provide for three-dimensional flow image reconstruction in deep tissues with arbitrary geometries.

11 Claims, 34 Drawing Sheets
