and the spinor dynamics-driven atom laser
Dissertation by
Nathan Eric Lundblad
In Partial Fulfillment of the Requirements
for the Degree of
Doctor of Philosophy
California Institute of Technology
Pasadena, California
2006
ii
c
2006
Nathan Eric Lundblad
For my parents
Acknowledgments
From all I hear of (Gottfried Wilhelm) Leibniz he must be very intelligent, and pleasant company in consequence. It is rare to find learned men who are clean, do not stink, and have a sense of humour.
Elisabeth Charlotte, Princess Palatine
A letter to Sophie Charlotte, 30 July 1705.
M
y time at Caltech and JPLhas been shaped by the presence ofsev-eral remarkable individuals. It is no exaggeration to say that this thesis
and the work documented within would not exist without their
influ-ence, for which I am profoundly grateful.
First and foremost, I would like to acknowledge my advisor at JPL, Lute Maleki,
who gave me an opportunity and a challenge five years ago to which I am proud to
think I have risen. His unending support and enthusiasm for my project were absolute
pillars when the experimental going was rough, and his optimism and guidance were
sustaining. I am particularly appreciative of his well-calibrated sense of timing—when
to leave me to seek answers myself, and when to intervene for the better.
Ken Libbrecht, my advisor at Caltech, has been both mentor and confessor to me,
and the existence of this thesis is a credit to his patient encouragement. My notions
of what it means to be a scientist have been heavily influenced by him, and I am
proud to call myself his student.
Most of what I know about being a practicing physicist is due to Rob Thompson.
His willingness to let me run amok in the early stages of the BEC experiment
rep-resented mentorship above and beyond the call of duty, and his constant open-door
policy for discussing matters of diverse stripe kept me time and again from reinventing
the wheel, and also illuminated research pathways that I otherwise would not have
seen. His insight and support were invaluable, and my gratitude for his scientific
fostering is considerable.
Among my co-workers I would especially like to thank Eric Burt and Bill Klipstein
for advice and helpful discussions over the years. An encouraging word at the right
time from them meant more than I suspect they know, and their influence on this
thesis was not small. The little village of Building 298 was a wonderful place to work,
and I feel lucky to have learned from so many people, including Nan Yu, Jim Kohel,
Dima Strekalov, Daphna Enzer, Meirong Tu, Bob Tjoelker, Jaime Ramirez-Serrano,
Brent Young, Vlad Iltchenko, Brana Jelenkovic, Maggie Beach, and John Dick. I
would like to recognize my fellow students: Dave Aveline, who I feel honored to pass
the torch to, Makan Mohageg, Ivan Grudinin, and Jim Kellogg. Naushad Khakoo
and Jeffrey Naecker were my summer students in 2002 and 2005, respectively, and
I hope they learned from me as I learned from teaching them. This thesis is also a
credit to my undergraduate mentors: Morgan Mitchell, Ray Chiao, Tim Bolton (at
KSU), and Carl Heiles, from all of whose considerate and effective teaching I continue
to reap benefits.
I cannot overstate the role played by my friends in the traversal of this long road.
Alex Papandrew and Ian Swanson are the finest of men—I’m honored to have them
as friends, and knowing them has made the vicissitudes of these years worthwhile.
Alan Smith, while always far away, has nevertheless been a rock of support. The
gentlemen of Caltech Rugby have been nothing short of outstanding as friends and
teammates, from the oldest ones who recruited me to the newest rookie. Mary Laura
Lind has been a treasured friend, and her ability to motivate the writing of this thesis
has only increased my appreciation of her friendship. Nelly Khidekel has been a
true friend from the very beginning. Jason Keith bettered my time at Caltech with
his loyalty and character, and I was glad for his presence both as my fellow prop
vi
confidante of the first order, for which I am grateful. Jane Khudyakov is a bright light
in the occasional murk of Caltech life, and for lending me strength when I was on
shaky ground I am in her debt. Allyson Beatrice bears a special responsibility for the
completion of this thesis; her efforts at keeping the group at JPL under control and
running smoothly have been superhuman, yet they are paltry in comparison to her
contributions as a friend, confidante, and general well-wisher. Mary Devlin has been
a wonderful roommate and friend, as have her cats, which have been essential to my
stress relief over the past year. Several people from my entry class deserve particular
mention, namely Parsa Bonderson, Andy Berglund, John Stockton, and especially
Megan Elizabeth Eckart; it is a fine profession indeed where I can know these people
both as friends and as colleagues. I am lucky to have a group of my oldest companions
within driving distance; Mike Hill and Ian and Megumi Hurst have been a constant
source of fun and encouragement. To the various gentlemen with whom I have had
the pleasure of sharing a poker table these last several years, my thanks—depending
on the stakes and the game they were either blessed or cursed with my presence, but
regardless, I looked forward to every one of those games. I cannot neglect to mention
Devin Sullivan and Rob Fergus, two good fellows who lit up my early years here, nor
two of my oldest friends, Jordan Zamir and Tater Read. I could not phrase it any
better:
Think where man’s glory most begins and ends, And say my glory was I had such friends.
Penultimately, it would be remiss of me not to cast thanks into the void toward Neal
Stephenson, whose recent books provided much more than the occasional epigram—
books that those readers who are amused by such things should read, and those who
think that I am too long-winded should weigh.
To bring these acknowledgements to a close, I would like to recognize the constant
flow of love and support from my family, to whom this thesis is dedicated: Mom, Dad,
O
ptical trapping as a viable means of exploring the physics of ultracolddilute atomic gases has revealed a new spectrum of physical phenomena. In
particular, macroscopic and sudden occupation of the ground state below
a critical temperature—a phenomenon known as Bose-Einstein condensation—has
become an even richer system for the study of quantum mechanics, ultracold collisions,
and many-body physics in general. Optical trapping liberates the spin degree of the
BEC, making the order parameter vectorial (‘spinor BEC’), as opposed to the scalar
order of traditional magnetically trapped condensates.
The work described within is divided into two main efforts. The first encompasses
the optical creation of a Bose-Einstein condensate in rubidium vapor. An
all-optical path to spinor BEC (as opposed to transfer to an all-optical trap from a
magnetic-trap condensate) was desired both for the simplicity of the experimental setup and also
for the potential gains in speed of creation; evaporative cooling, the only known path
to dilute-gas condensation, works only as efficiently as the rate of elastic collisions in
the gas, a rate that starts out much higher in optical traps. The first all-optical BEC
was formed elsewhere in 2001; the years following saw many groups worldwide seeking
to create their own version. Our own all-optical spinor BEC, made with a single-beam
dipole trap formed by a focused CO2 laser, is described here, with particular attention
paid to trap loading, measurement of trap parameters, and the use of a novel 780 nm
high-power laser system.
The second part describes initial experiments performed with the nascent
conden-sate. The spinor properties of the condensate are documented, and a measurement is
viii
made of the density-dependent rate of spin mixing in the condensate. In addition, we
demonstrate a novel dual-beam atom laser formed by outcoupling oppositely
polar-ized components of the condensate, whose populations have been coherently evolved
through spin dynamics. We drive coherent spin-mixing evolution through adiabatic
compression of the initially weak trap. Such dual beams, nominally number-correlated
through the angular momentum-conserving collision 2m0 m+1 +m−1 have been
proposed as tools to explore entanglement and squeezing in Bose-Einstein
