WALL-MOUNTED ELECTRICAL DISTRIBUTION

•

Pro-DB 125 and Pro-DB 250

•

ProPanel 2 400 and ProPanel 2 800

DIN MODULAR PROTECTION

•

Miniature Circuit Breakers

•

Residual Current Circuit Breakers

MOULDED CASE CIRCUIT BREAKERS

•

TemBreak 2 Moulded Case Circuit Breakers

•

Switch Disconnectors

•

Accessories

AIR CIRCUIT BREAKERS

•

TemPower 2 Air Circuit Breakers

•

Accessories

CONTACTORS

•

3P Contactors and Accessories

•

4P Contactors and Accessories

POWER FACTOR CORRECTION

METERS AND EARTH LEAKAGE PROTECTION

ADVANCED EXTERNAL DISPLAY and CHANGEOVER CONTROLLER

This

Quick Price

Guide

is a handy

reference tool.

It supports our main

price list – “Protection

and Distribution

1A to 6300A” –

which contains a

comprehensive list

of prices and order

codes.

Terasaki’s Terms and

Conditions of sale can

be Downloaded from:

http://www.terasaki.co.uk/

services/files/TC.pdf

QUICK REFERENCE

PRICE GUIDE

JULY 2015

Terasaki is a world

class specialist

in innovative

circuit protection,

control and system

products for

electrical energy

distribution. We

supply low-voltage

circuit breakers for

industrial, marine

and commercial

building projects.

27

24

22

19

10

8

4

28

Pro-DB 125A and Pro-DB 250A

Wall-Mounted Electrical Distribution

Enclosed Distribution Units

Busbar Assemblies

Number of

Outgoing Ways

125A 250A 125A 250A

4 £166.48 £110.91 6 £187.06 £124.64 8 £211.01 £254.42 £138.14 £151.95 12 £253.45 £303.12 £181.36 £199.51 16 £356.42 £395.38 £211.53 £232.69 18 £407.67 £460.01 £240.71 £264.76 24 £537.42 £633.00 £281.52 £309.68

Supply Connection Kits*

Pro-DB

Rating (A)

Supply

Connection Kit

Rating (A)

Poles

Switch

Disconnector

MCCB

30mA RCCB

or CBR

300mA RCCB

or CBR

125 100 3 £54.47 125 100 4 £81.84 £224.28 £227.62 125 125 3 £77.25 125 125 4 £97.85 250 250 3 £299.77 £383.70 250 250 4 £464.95 £464.95 £978.97 £978.97

* Includes links, shroud and device

Calculate a price for Pro-DB distribution boards or Pro-Panel 2 panelboards from the following tables.

Start by adding a supply connection kit to the distribution unit then add metering, extension boxes,

outgoing devices and accessories as required.

Pro-DB 250A is the only 250A three-phase distribution board which can be fitted with a CBR. The CBR

includes overload, short-circuit and residual protection (from electric shock and fire) within the frame of

a standard MCCB. No extension boxes, wiring or separate relays are required for this option.

Note that all quoted breaking capacities (kA) are for 400V AC.

250A CBR supply connection device includes overload, short

circuit, electric shock (30mA) and fire (300mA) protection.

Metering Kits

Pro-DB Multifunction Pulsed Multifunction Modbus kWh pulsed Dual for L2*

125A £890.49 £1026.38 £968.00 £2122.23

250A £1016.23 £1134.18 £1005.23 £2198.08

*Kit includes double-width enclosure, CTs, two meters and cabling. Two Pro-DB distribution boards are required

Top and Bottom Extension Boxes

Plain Door Glazed Door Cable Spreader Door Kit Pro-DB Rating (A) 1 Row, 16 Mod 2 Row, 32 Mod 1 Row, 16 Mod 2 Row, 32 Mod

Small Large Small Large

125A £120.29 £158.99 £141.51 £168.57 £86.22 £117.03 £138.69 £151.89

250A £120.27 £161.83 £146.51 £171.67 £91.67 £123.53 £138.69 £151.89

Load Protection Devices

Current Rating 1P 10kA MCB B, C, D 3P 10kA MCB B, C, D 1P RCBO B, C

6A £12.89 £54.37 £76.97

10A - 32A £11.51 £51.61 £76.97

40A £12.89 £54.37 £76.97

50A £17.16 £54.37

63A £17.16 £60.45

Side Extension Boxes

Outgoing Ways 125 250 4 £108.67 6 £118.68 8 £135.20 £135.20 12 £158.18 £158.18 16 £193.44 £193.44 18 Price on Application £215.21 24 Price on Application £236.26

Accessories

Meter Data Logger TCP/IP £1,487.49

Door Locking Kit for Type B DB 125 & 250A £14.27

Spare Label Pack 125 & 250A £6.32

Single Phasing Kit for 125A DB £22.61

Single Phasing Kit for 250A DB £30.91

Touch-up Paint £25.41

1P Busbar Blank £0.78

Mechanical Connection Kit Horizontal/Vertical £29.72

Top Tap Off Kit for 125A & 250A £43.53

Blue 100A Flexi Link 300mm £4.83

Brown 100A Flexi Link 500mm £7.43

Keylock for Type A DB £21.99

100A 1M Terminal Block for Type A £8.48

TP Earth Bar Kit High Integrity, 2 x 15 terminals £66.34

TP Earth Bar Kit Clean, 2 x 15 terminals £66.64

Pro-Panel 2 400A and 800A

Wall-Mounted Electrical Distribution

Enclosed Distribution Units

Busbar Assemblies

Number of 125A

Outgoing Ways

(TB2 Lite 160A

Frame)

Number of 250A

Outgoing Ways

(TB2 Lite 250A

Frame)

400A

800A

800A*

400A

800A

6 0 £900.70 £412.58 8 0 £995.12 £471.50 12 0 £1044.99 £533.82 16 0 £1355.59 £695.55 18 0 £1567.77 £766.21 4 2 £1029.07 £813.07 6 2 £1049.23 £831.99 4 4 £1053.90 £846.07 10 2 £1156.38 £1169.36 £875.94 8 4 £1168.15 £1260.33 £940.25 14 4 £1367.11 £1395.37 £1069.60 12 6 £1539.58 £1464.61 £1105.59

*Suitable for 800A MCCB Supply Connection Device

Supply Connection Kits*

Pro-Panel 2

Rating (A)

Supply Connection Kit

Rating (A)

Poles

Switch

Disconnector

MCCB

400 400 3 £617.00 £653.02 400 400 4 £823.29 £928.15 800 400 3 £631.14 £667.16 800 400 4 £842.05 £946.91 800 630 3 £1066.22 £1129.93 800 630 4 £1472.75 £1561.44

* Includes links, shroud, device and supply-side terminal cover

Metering Kits

Pro-Panel 2 Rating (A)

Multifunction Pulsed

400A

£921.65

Extension Boxes

1 Row 34 Mod DIN Ext Box 300mm £237.87

2 Row 68 Mod DIN Ext Box 450mm £286.35

Small Spreader Box 300mm Door Kit £95.87

Small Spreader Box 300mm £212.84

Large Spreader Box 450mm Door Kit £111.19

Large Spreader Box 450mm £228.09

6 Way Side Metering Box £587.10

8 Way Side Metering Box £370.50

Load Protection Devices

16kA

25kA

25kA

40kA

3P

1P

3P

3P

Frame Reference

In (A)

TB2 Lite 160

25, 40, 63, 80 £105.68 £77.58 £133.62 £151.84 100 £103.19 £77.58 £137.27 £154.26 125 £112.97 £82.88 £145.77 £163.99

TB2 Lite 250

50, 63 £156.88 £165.14 £173.39 100, 125, 160 £199.53 £210.03 £220.53 200 £275.22 £289.70 £304.19 250 £309.62 £325.91 £342.21

Accessorie

s

3P 250A Busbar Side Terminal Cover (required) £4.46

3P 250A Load Terminal Cover (optional) £13.20

1P 125A Load Terminal Cover (optional) £6.03

3P 125A Load Terminal Cover (optional) £13.20

1P Blanking Plate for 125A (3 per 3 pole MCCB) £6.12

3P Blanking Plate for 250A (1 per 3 pole MCCB) £12.41

Key lock with one key for PB (optional) £15.30

Allen Key Set (optional) £31.48

Touch Up Paint 30ml for PB (optional) £17.96

End Plate for 400/800 PB (optional) £30.52

TD3 Miniature Circuit Breakers

DIN Modular Protection

TD3M10 10kA Types B, C & D

1 Pole

2 Pole

3 Pole

4 Pole

In (A)

6 £12.89 £41.07 £54.37 £98.51 10 £11.51 £38.36 £51.61 £92.95 16 £11.51 £38.36 £51.61 £92.95 20 £11.51 £38.36 £51.61 £92.95 25 £11.51 £38.36 £51.61 £92.95 32 £11.51 £38.36 £51.61 £92.95 40 £12.89 £41.07 £54.37 £98.51 50 £17.16 £41.07 £54.37 £98.51 63 £17.16 £43.71 £60.45 £98.51

TD3XA 10kA Type C

80 £58.40 £142.02 £223.43 £296.44

100 £61.54 £157.09 £227.84 £331.20

125 £95.79 £165.87 £238.83 £348.37

TD3XA 10kA Type D

80 £89.41 £180.01 £250.08 £391.70

100 £109.55 £202.93 £263.79 £405.39

125 £112.66 £213.55 £301.48 £413.39

Accessories for TD3M10 & TD3XA

Auxiliary Switch 1NC+1NO 230V AC £27.93

Alarm Switch 1NC+1NO 230V AC £27.93

Shunt Trip 230-415V AC, 110-130V DC £34.23

Shunt Trip 24-48V AC, 12-48V DC £34.23

Undervoltage Release 230V AC £40.99

Overvoltage Release 230V AC £47.85

Padlock Device £18.16

Our range of DIN modular protection products covers ratings from 0.5A to 125A

Note that all quoted breaking capacities (kA) are for 400V AC

TD3 RCCB

Type

2 Pole

4 Pole

In (A)

25 AC 30mA £84.56 £129.63 40 AC 30mA £88.52 £132.87 63 AC 30mA £107.48 £164.92 80 AC 30mA £189.68 100 AC 30mA £126.58 £243.28 25 AC 100mA £129.64 40 AC 100mA £88.52 £132.87 63 AC 100mA £107.48 25 AC 300mA £100.40 £129.64 40 AC 300mA £102.55 £132.87 63 AC 300mA £118.31 £164.92 80 AC 300mA £189.68 100 AC 300mA £243.28 63 AC 100mA £164.92 100 AC 100mA £243.28 25 A 30mA £101.54 40 A 30mA £108.75 £154.12 63 A 30mA £183.27 25 Ai 30mA £107.28 40 Ai 30mA £111.91 63 Ai 30mA £186.71 100 A 30mA £188.43 100 A 300mA £188.43 40 AC S 300mA £159.88 100 AC S 300mA £233.05 40 S-Ai 30mA £148.45 40 S-Ai 300mA £162.16 £151.87 63 S-Ai 300mA £187.28 100 S-Ai 300mA £189.56

Accessories for TD3 RCCB

Auxiliary Switch 1NC+1NO 230V AC £35.02

TD3 RCBO Types B&C. 30mA and 300mA

1 Pole (10kA) £76.97

2 Pole (6kA) £103.01

ALSO AVAILABLE:

MCBs <6A • MCBs 6kA • Comb busbar • MCB residual-current add-on blocks • DIN modular switches • DIN modular contactors, timers, meters, surge arresters (refer to our complete order code and price list “Protection & Distribution 1A to 6300A”, ref: PL00515

TemBreak 2 is a complete system of MCCBs and accessories.

They protect circuits of up to 1600A from overload currents,

short-circuit currents, ground-fault currents, residual currents

and DC fault currents.

Select a price based on the protection type, fault rating, current

rating and number of poles from the tables below.

Note that all quoted breaking capacities (kA) are for 400V AC

Moulded Case Circuit Breakers

16kA

25kA

36kA

40kA

50kA

3P

4P

3P

4P

3P

4P

3P

4P

3P

4P

Frame Reference In (A) TB2 Lite 160 25, 40, 63, 80 £105.68 £126.82 £133.62 £160.34 £151.84 £212.58 100 £109.32 £131.20 £137.27 £164.72 £154.26 £215.98 125 £112.97 £135.56 £145.77 £174.92 £163.99 £229.59 160 £140.90 £169.10 £182.21 £218.65 £212.58 £297.61 TB2 Lite 250 50, 63 £156.88 £219.64 £165.14 £231.19 £173.39 £242.75 100, 125, 160 £199.53 £279.35 £210.03 £294.05 £220.53 £308.75 200 £275.22 £385.30 £289.70 £405.58 £304.19 £425.86 250 £309.62 £433.47 £325.91 £456.27 £342.21 £479.08 TB2 S125 20, 32, 50, 63 £163.79 £193.96 100 £166.75 £221.25 125 £172.41 £249.99 TB2 S250 20, 32, 50, 63 £179.58 £301.71 100, 125, 160 £218.38 £330.43 160,200 £301.71 £431.01 250 £344.81 £560.31 TB2 S/H/L 250 20, 32 50, 63, 125 125 160 160 250 TB2 E/S 630 250, 400 £524.39 £744.21 £538.77 £775.82 £574.69 £790.19 TB2 1000 630 £859.38 £1255.68 £905.11 £1321.78 800 £1091.89 £1452.32 £1149.36 £1528.65

TemBreak 2 Adjustable Thermal Magnetic Protection

65kA

70kA

85kA

125kA

200kA

3P

4P

3P

4P

3P

4P

3P

4P

3P

4P

Frame Reference In (A) TB2 Lite 160 25, 40, 63, 80 100 125 160 TB2 Lite 250 50, 63 100, 125, 160 200 250 TB2 S125 20, 32, 50, 63 £179.58 £215.50 100 £184.98 £247.12 125 £188.55 £271.55 TB2 S250 20, 32, 50, 63 £186.76 £306.02 100, 125, 160 £229.88 £351.99 160,200 £330.43 £488.49 250 £359.18 £617.77 TB2 S/H/L 250 20, 32 £244.22 £287.35 £294.17 £301.71 50, 63, 125 £280.17 £287.35 £294.17 £301.71 125 £380.73 £498.54 £399.74 £523.46 160 £431.01 £560.31 £452.56 £588.33 160 £545.95 £725.53 £627.84 £834.37 250 £703.99 £919.48 £809.58 £1077.23 TB2 E/S 630 250, 400 £660.89 £862.01 £693.92 £950.37 TB2 1000 630 £950.37 £1387.87 800 £1206.83 £1605.09

Moulded Case Circuit Breakers

36kA

50kA

65kA

70kA

3P

4P

3P

4P

3P

4P

3P

4P

Frame

Reference

In (A)

TB2 S/H/L

250

40 £265.00 £368.00 £285.00 £389.00 £308.00 £419.00 125 £265.00 £368.00 £285.00 £389.00 £308.00 £419.00 160 £380.00 £499.00 £395.00 £502.00 £460.00 £550.00 250 £527.00 £695.00 £565.00 £715.00 £619.00 £775.00

TB2 E/S 630

250, 400 £632.14 £833.28 £675.25 £861.01 250, 400 with G* £747.10 £1020.17 £790.19 £1048.60 630 £876.39 £1012.86 £1009.64 £1289.42 £1027.89 £1301.58 630 with G* £991.32 £1199.64 £1124.60 £1476.19 £1142.83 £1488.36

TB2 H/L 400

250, 400 250, 400 with G*

TB2 1000

630, 800 £1205.10 £1581.36 £1586.20 £1843.70 630, 800 with G* £1373.44 £1768.13 £1772.02 £2347.39 1000 £1622.25 £2070.30 £1782.31 £2352.65 1000 with G* £1785.86 £2205.61 £1897.26 £2539.42

TB2 H/L 800

630 630 with G* 800 800 with G*

TB2 1250

1250 £1776.75 £2461.70 £2007.56 £2675.71 1250 with G* £1940.49 £2679.61 £2122.50 £2790.65

TB2 1600

1600 £2614.80 £3088.91 1600 with G* £2729.74 £3275.68

TemBreak 2 Electronic Protection with Selectable LSI Characteristics

16kA

25kA

40kA

3P

4P

3P

4P

3P

4P

Frame Reference

In (A)

TB2 Lite 160

16, 20, 25, 32, 40, 50, 63, 80 £95.11 £133.16 £120.26 £168.36 £129.07 £180.70 100 £98.40 £137.76 £123.54 £172.96 £131.13 £183.59 125 £101.67 £142.35 £131.20 £183.67 £139.39 £195.14 160 £126.34 £176.86 £163.99 £229.59 £180.70 £252.97

TB2 Lite 250

50, 63 £141.18 £197.67 £148.62 £208.07 £156.05 £218.47 100, 125, 150, 175 £179.59 £251.40 £189.03 £264.66 £198.48 £277.87 200 £247.69 £346.77 £260.73 £365.03 £273.77 £383.27 225, 250 £278.66 £390.12 £293.33 £410.65 £307.98 £431.19

TemBreak 2 Lite Fixed Thermal Magnetic Protection

TemBreak 2 Electronic Protection with Selectable LSI Characteristics

85kA

125kA

200kA

3P

4P

3P

4P

3P

4P

Frame

Reference

In (A)

TB2 S/H/L

250

40₁₂₅ £479.28_£479.28 £494.40_£494.40 160 £504.70 £633.78 250 £699.00 £934.65

TB2 E/S 630

250, 400 £709.02 £905.11 250, 400 with G* £829.69 £1101.22 630 630 with G*

TB2 H/L 400

250, 400 £1074.65 £1220.39 £1474.65 £804.49 250, 400 with G* £1201.07 £1407.06 £1472.62 £1991.27

TB2 1000

630, 800 630, 800 with G* 1000 1000 with G*

TB2 H/L 800

630 £1854.77 £1926.62 £1947.51 £2022.94 630 with G* £1969.71 £2113.38 £2062.44 £2137.88 800 £2244.12 £2984.01 £2356.33 £3133.22 800 with G* £2359.06 £3098.95 £2471.26 £3319.99

TB2 1250

1250 £2189.57 £2858.61 1250 with G* £2304.51 £3045.38

TB2 1600

1600 £3448.07 £3708.00 1600 with G* £3563.01 £4065.85

*G - Ground Fault Protection. If the MCCB is 3P an external neutral CT is required.

External Neutral CTs

400A £386.81 630A £386.81 800A £421.76 1000A £421.76 1250A £661.86 1600A £777.77

Moulded Case Circuit Breakers

TemBreak 2 Electronic Protection with Measurement & Data Communication

36kA

50kA

70kA

125kA

200kA

3P

4P

3P

4P

3P

4P

3P

4P

3P

4P

Frame Ref. In (A) TB2 S/H/L 250 40 £1032.57 £1273.00 £1114.97 £1355.40 125 £1032.57 £1273.00 £1114.97 £1355.40 160 £1032.57 £1273.00 £1114.97 £1355.40 250 £1042.61 £1283.04 £1125.01 £1365.44 TB2 E/S 630 250, 400 £1094.09 £1282.94 £1158.28 £1340.84 250, 400 with G* £1308.02 £1345.88 £1372.21 £1410.08 630 £1908.69 £2095.67 £1982.37 £2171.21 £2122.11 £2297.13 630 with G* £1928.69 £2116.27 £2002.97 £2212.41 £2142.71 £2338.33 TB2 H/L 400 250, 400 £1842.62 £2389.60 £2157.38 £2441.10 250, 400 with G* £1863.22 £2430.80 £2177.98 £2482.30 TB2 1000 630, 800 £1812.99 £1918.81 £2529.31 £2787.71 630, 800 with G* £1875.95 £1981.77 £2592.27 £2850.67 1000 £2554.42 £2885.19 £2681.11 £3061.19 1000 with G* £2617.38 £2918.15 £3008.86 £3138.75

25kA

36kA

65kA

3P

4P

3P

4P

3P

4P

Frame Reference In (A)

TB2 S125

20, 32, 50, 63

£452.74 £520.59 £458.92 £529.24 £474.95 £555.14

100

£456.45 £555.14 £462.60 £561.30 £484.82 £571.95

125

£492.22 £592.15 £497.94 £598.32 £518.13 £629.15

TB2 S250

160

£559.92 £715.51 £565.65 £721.68 £592.15 £732.39

250

£789.54 £937.56 £795.71 £947.44 £900.56 £1,048.59

350V DC

600V DC

750V DC

1000V DC

3P

4P

3P

4P

3P

4P

3P

4P

Frame

Reference

In (A)

TB2 Lite 160

25, 32, 40,

63, 80

£203.37 £223.71

100

£228.68 £251.54

125

£262.12 £288.34

160

£283.25 £317.24

TB2 Lite 250

100

£288.19 £317.01 POA POA

125, 160

£300.35 £328.16 POA POA

200

£300.35 £355.97 POA POA

250

£300.35 £377.54 POA POA

TB2 S250

50, 63

100

125

160

250

TB2 E/S 630

250, 400

£815.60 £815.60

TB2 H/L 400

250

£846.60 £991.42

400

£902.30 £1047.11

TB2 1000

630

£1123.13 £1123.13

800

£1331.80 £1331.80

1000

£2277.15

TB2 H/L 800

630

£2418.85 £2474.62

800

£2418.85 £2474.62

TB1 1250

1250

£2755.30

TB1 1600

1600

£5343.63

TemBreak 2 Circuit Breakers for use above 250V DC

3P

4P

Frame Reference In (A)

TB2 Lite 160 160 £170.36 £226.26 TB2 Lite 250 250 £218.08 £290.32 TB2 S125 125 £136.50 £181.03 TB2 S250 250 £229.88 £306.02 TB2 E/S 630 400 £502.75 £670.95 630 £718.34 £958.28 TB2 1000 800 £795.68 £1166.99 1000 £1241.15 £1545.00 TB2 1250 1250 £1293.02 £1719.73 TB2 1600 1600 £1867.70 £2484.05

TemBreak 2 Switch Disconnectors

70kA at 690V

3P

Frame Reference In (A)

TB2 S/H/L 250 20, 32, 50, 63,100 £475.28

125 £475.28

TB2 H/L 400 250, 400 £2073.37 TB2 H/L 800 630, 800 £2360.09

TemBreak 2 Circuit Breakers with Icu = 70kA at 690V AC

4kA at 1100V

3P

Frame Reference In (A) TB2 S125 20, 32 £444.57 50, 63, 100 £517.32 125 £548.49 TB2 S250 160 £556.56 250 £714.74

TemBreak 2 Circuit Breakers for 1000V AC

Straight

Extension Bars

Long

Terminal Cover

Spread

Extension Bars

Spread

Terminal Cover

Rear

Connections

3 Bars

4 Bars

3P

4P

3 Bars

4 Bars

3P

4P

3 Studs 4 Studs

Frame Reference TB2 Lite 160 £12.79 £15.57 £13.20 £17.18 £20.09 £25.52 £13.20 £17.15 £30.60 £41.20 TB2 Lite 250 £18.91 £27.81 £22.96 £30.60 £13.20 £18.48 £33.37 £44.50 TB2 S125 £20.12 £27.58 £22.99 £30.65 TB2 S250 £20.16 £28.64 £13.21 £18.50 £27.11 £37.69 TB2 S/H/L 250 £20.16 £28.64 £13.21 £18.50 £27.11 £37.69 TB2 E/S 630 £25.12 £33.04 £24.42 £32.47 £25.12 £33.04 £24.42 £32.47 £56.85 £79.32 TB2 H/L 400 £25.12 £33.04 £24.42 £32.47 £25.12 £33.04 £24.42 £32.47 £56.85 £79.32 TB2 1000 £42.44* £46.68* £32.70 £44.15 £132.18 £175.29 TB2 H/L 800 £32.70 £44.15 £132.18 £175.29 TB2 1250 £33.14 £44.14 £182.64 £245.79 TB2 1600

*Price for 800A version only

Plug-in

Base

Plug-in

Conversion

Terminal Cover for Rear

and Plug-in

Connections

Plug-in Control Wiring

Socket per Internal

Accessory

3P

4P

3P

4P

3P

4P

MCCB

Side

Base Side

Frame Reference TB2 Lite 160 £11.88 £15.84 TB2 Lite 250 £13.20 £18.48 TB2 S125 £57.45 £76.63 £31.61 £42.03 £11.90 £15.86 £11.48 £11.57 TB2 S250 £79.32 £104.43 £35.69 £47.60 £13.21 £18.50 £11.48 £11.57 TB2 S/H/L 250 £79.32 £104.43 £35.69 £47.60 £13.21 £18.50 £11.48 £11.57 TB2 E/S 630 £185.61 £246.78 £78.00 £95.18 £24.42 £32.47 £11.48 £11.57 TB2 H/L 400 £185.61 £246.78 £159.14 £190.96 £24.42 £32.47 £11.48 £11.57 TB2 1000 £509.23 £602.45 £203.21 £310.88 £30.07 £40.10 £11.57 £11.57 TB2 H/L 800 £509.23 £602.45 £203.21 £310.88 £30.07 £40.10 £11.57 £11.57 TB2 1250 £1115.46 £1438.45 £247.20 £309.00 £26.52 £26.52 TB2 1600

TemBreak 2 Accessories

continued...

Also Available: MCCBs >1600A • Settings sealing facility • Temperature Monitor and Alarm • OCR checker • Automatic Changeover Controller • Slide-type mechanical interlocks • Extension terminals and covers for plug-in MCCB • 1P MCCBs • Normally open or normally closed auxiliary switches • Terminal blocks • IP5X Breaker-Mounted handles • IP65 Panel-Mounted handles • Red emergency operating handles• Handle locks • Extra interpole barriers • DIN rail adapters • MCCBs with Magnetic trip only • MCCBs with Low Instantaneous Trip for Generator • CBR with Residual Monitor and Remote Trip

(refer to our complete order code and price list: “Protection & Distribution 1A to 6300A” ref: PL0515)

Moulded Case Circuit Breakers

Auxiliary Switch,

Changeover Type

Alarm Switch,

Changeover Type

Shunt

Trip

Undervoltage

Trip

Motor

Operator

IP3X Breaker

Mounted Handle

IP55 Panel-

Mounted Handle

Link Mechanical

Interlock per MCCB

Wire Mechanical

Interlock perMCCB

1m Cable for Wire

Mechanical

Interlock

Frame Ref. TB2 Lite 160 £15.79 £15.79 £51.63 £64.56 £50.06 £61.46 TB2 Lite 250 £15.79 £15.79 £51.63 £64.56 £502.91 £64.52 £61.46 £68.88 £206.89 £37.02 TB2 S125 £15.81 £15.81 £51.72 £64.66 £359.18 £42.44 £69.40 £67.53 £193.96 £37.02 TB2 S250 £15.81 £15.81 £51.72 £64.66 £503.60 £50.34 £69.40 £68.98 £206.89 £37.02 TB2 S/H/L 250 £15.81 £15.81 £51.72 £64.66 £503.60 £50.34 £69.40 £69.98 £206.89 £37.02 TB2 E/S 630 £15.81 £15.81 £51.72 £64.66 £667.28 £68.22 £97.15 £117.90 £349.01 £37.02 TB2 H/L 430 £15.81 £15.81 £51.72 £64.66 £667.28 £68.22 £97.15 £117.90 £349.01 £37.02 TB2 1000 £15.81 £15.81 £51.72 £68.13 £839.61 £78.71 £124.89 £165.07 £488.11 £37.02 TB2 H/L 800 £15.81 £15.81 £51.72 £68.13 £839.61 £78.71 £124.89 £165.07 £488.11 £37.02 TB2 1250 £15.81 £15.81 £51.72 £68.13 £886.02 £91.28 £147.05 £360.71 £37.02 TB2 1600 £15.81 £15.81 £51.72 £68.13 £886.02 £91.28 £147.05 £360.71 £37.02

Neutral Link

Shroud for

Neutral Link

Door Flange for

Toggle Opera

-tion

Door Flange for Motorised

Operation

Cable Clamps

Terminal

Cover for Cable

Clamps

3P

4P

3P

4P

Frame Ref. TB2 Lite 160 TB2 Lite 250 £43.04 £57.39 £13.20 £18.48 TB2 S125 £15.12 £11.93 £15.12 £38.11 £21.56 £28.74 £11.90 £15.86 TB2 S250 £15.12 £11.93 £15.12 £38.11 £43.10 £57.45 £13.21 £18.50 TB2 S/H/L 250 £15.12 £11.93 £15.12 £38.11 £43.10 £57.45 £13.21 £18.50 TB2 E/S 630 £34.89 £38.18 £13.59 £53.86 £71.83 £95.79 £24.42 £32.47 TB2 H/L 400 £34.89 £38.18 £13.59 £53.86 £71.83 £95.79 £24.42 £32.47 TB2 1000 £81.77 £38.75 £13.59 £53.86 TB2 H/L 800 £72.41 £38.75 £13.59 £53.86 TB2 1250 TB2 1600

TemBreak 2 Accessories

Air Circuit Breakers

TemPower 2 ACBs offer high

specifications with guaranteed

reliability. Use the three pricing tables

in sequence to calculate the total price:

Table ACB1

: body, chassis, connections

+

Table ACB2

: Protection Relays +

Table

ACB3

: Accessories

Rated

Current

ACB Type

Breaking

Capacity

No Poles

Fixed ACB

(No Chassis

Required)

Drawout

Body

Chassis

Vertical or

Horizontal

Connections: Full Set

Front

Connections:

Full Set

800A AR208S 65kA 3 £2,234.13 £2,195.85 £898.67 £171.82 £480.94 800A AR208S 65kA 4 £2,943.85 £2,850.94 £1,148.96 £229.12 £637.46 1250A AR212S 65kA 3 £2,304.96 £2,358.71 £898.67 £171.82 £480.94 1250A AR212S 65kA 4 £3,051.46 £2,996.80 £1,148.96 £229.12 £637.46 1250A AR212H 80kA 3 £2,791.89 £2,786.83 £943.60 £192.38 --1250A AR212H 80kA 4 £3,622.84 £3,469.65 £1,206.43 £256.54 --1600A AR216S 65kA 3 £2,424.14 £2,660.13 £943.60 £192.38 £876.38 1600A AR216S 65kA 4 £3,235.75 £3,674.77 £1,206.43 £256.54 £1,124.64 1600A AR216H 80kA 3 £2,915.64 £3,063.32 £943.60 £192.38 --1600A AR216H 80kA 4 £3,963.81 £4,107.25 £1,206.43 £256.54 --1600A AR316H 100kA 3 £3,294.08 £3,106.24 £1,484.58 £313.54 --1600A AR316H 100kA 4 £4,321.62 £4,216.99 £1,811.40 £418.02 --2000A AR220S 65kA 3 £3,427.04 £3,723.27 £943.60 £192.38 £876.38 2000A AR220S 65kA 4 £4,382.79 £4,933.63 £1,206.43 £256.54 £1,124.64 2000A AR220H 80kA 3 £4,191.71 £4,402.43 £943.61 £192.38 --2000A AR220H 80kA 4 £5,416.45 £5,882.28 £1,206.40 £256.54 --2000A AR320H 100kA 3 £4,638.84 £4,402.47 £1,484.58 £313.54

2000A AR320H 100kA 4 £5,874.79 £5,836.50 £1,811.40 £418.02 --2500A AR325S 85kA 3 £4,049.15 £4,201.32 £1,360.49 £313.54 £1,248.34 2500A AR325S 85kA 4 £5,521.40 £5,891.56 £1,811.40 £418.02 £1,664.40 2500A AR325H 100kA 3 £5,886.60 £5,918.91 £1,484.58 £313.54 --2500A AR325H 100kA 4 £7,176.55 £7,452.49 £1,811.40 £418.02 --3200A AR332S 85kA 3 £5,532.32 £6,902.12 £1,360.48 £313.54 £1,248.34 3200A AR332S 85kA 4 £7,357.59 £8,895.91 £1,597.36 £418.02 £1,664.40 3200A AR332H 100kA 3 £7,402.74 £8,694.87 £1,484.58 £313.54 --3200A AR332H 100kA 4 £9,553.82 £11,225.58 £1,811.40 £418.02 --4000A AR440SB 100kA 3 -- £10,435.82 £1,557.74 £312.54* --4000A AR440SB 100kA 4 -- £13,628.28 £1,781.14 £389.34* --5000A AR650S 120kA 3 -- £19,008.52 £2,702.53 £390.70* --5000A AR650S 120kA 4 -- £23,262.98 £3,558.16 £486.68* --6300A AR663S 120kA 3 -- £24,452.81 £2,725.40 £488.34* --6300A AR663S 120kA 4 -- £29,208.96 £3,586.61 £608.34*

--TemPower 2 Table ACB 1 Body, Chassis and Connections

Standard Specification | Padlockable close & open buttons | Terminal Block for Accessories | Terminal Cover | Protection Relay Cover | IP20 Door Flange | Drawout Only: Control Circuit Shutters | Drawout only: Position Indicator | Drawout only: Drawout Handle | *Vertical only

Air Circuit Breakers

Standard

Protection

Relay

Ground Fault

Protection

Relay*

Optional Functions

Neutral

Protection

Modbus

Communications

Zone

Interlocking

Contact

Temperature #

Restricted

Ground Fault #

Protection*

Phase

Rotation #

Protection

Non-automatic (no protection) £212.43

Standard relay with dial adjustment £778.90 £963.01* £212.43

LCD relay with ammeter £948.84 £1196.52* £212.43 £679.76 £495.67 £184.10 LCD relay with power and energy meter £2124.29 £2478.34* £212.43 £679.76 £495.67 £1557.78 £495.67 £184.10

*External neutral CTs required #Only one function from three can be selected for each ACB

Number of External Neutral CT’s required

Type of Ground Fault Protection

Number of poles Ground Fault Protection Restricted Ground Fault Protection

3 1 2

4 0 1

Primary Current Rating

Price of External Neutral CT’s

Up to 2000A £410.69

2000A to 4000A £538.14

5000A to 6300A £627.00

7AB Auxiliary Switches (Industrial Use) £146.68

10AB Auxiliary Switches (Industrial Use) £203.05

Position Switches (Max 2 positions) £105.84

Position Switches (Max 4 positions) £201.72

Shunt Trip Continuously Rated £103.25

Double Shunt Trip 24V DC and 240V AC £160.62

Short Rated Shunt Trip (When UVT Fitted) £603.57

Shunt Trip Capacitor 48V DC £360.05

Undervoltage Trip Instantaneous £215.14

Undervoltage Trip Fixed Time Delay £418.56

Open / Close Counter £90.68

Trip Indication Switch - Standard £20.76

Auto Discharge Device £306.24

Insertion Prevention Device £36.24

Motor Operator with Closing Coil £743.68

Closing Coil Only £109.05

Double Closing Coil only 24V DC £352.28

Spring Charge Up Switch - Standard £38.87

Door Flange IP31 £80.29

Transparent Cover IP55 £274.74

AR ACB Lifter Loader AWR-1B £5100.00

AR ACB Lifter Loader AWR-2B £6327.92

IP3X Chassis Protection Cover £53.61

Storage Drawout Handle £77.36

Fixing Bolts for Drawout ACBS £104.10

Step Down Transformer 440V to 220V £115.33

Lifting Plates £16.00

OCR Checker £912.34

Interpole Barriers 3P £68.01

Interpole Barriers 4P £90.68

Door Interlock £111.38

Cylinder Lock and Key £69.96

Castell Lock and Key (Factory Fitted) £229.75

Castell Fitting Only £63.74

Lock in Off Position £69.96

Mechanical Interlocks - 2 ACBs £680.66

Mechanical Interlocks - 3 ACBs Type A £1061.96

Mechanical Interlocks - 3 ACBs Type B £1143.90

Mechanical Interlocks - 2 ACBs £664.11

AR208 - AR332 Shutter Padlock £36.27

AR440 Shutter Padlock £61.10

TemPower 2 Table ACB 3 Accessories

Also Available: Earthing devices • Undervoltage alarm • Pre-trip alarm • Shunt trip + UVT on one ACB • Capacitor Shunt Trip • Generator protection curve • SI, VI, EI curves (refer to our complete order code and price list “Protection & Distribution 1A to 630A ref: PL0613)

TemContact 2 is a new range of magnetic contactors

and thermal overload relays. Current ratings from 9A

to 800A AC3 are available across 9 frame sizes and

in 3 or 4 pole versions.

Contactors

TemContact 2

3P Contactors and Accessories

AC3 @ 415V AC (A)

AC1 @ 415V AC (A)

Side Auxiliary (2NO 2NC) includ

-ed

Contactor

Thermal Overload Relay

Front Mount Auxiliary

(2 Contacts)

Front Mount Auxiliary

(4 Contacts)

Side Mount Auxiliary

(optional)

Interlock Kit

Wiring Kit

Capacitor Unit

Surge Unit

Safety

Cover

9 25 yes* £25.12 £31.97 £6.59 £7.36 £6.70 £14.30 £6.70 £17.84 £8.79 £0.94 12 25 yes* £29.69 £31.97 £6.59 £7.36 £6.70 £14.30 £6.70 £17.84 £8.79 £0.94 18 32 yes* £38.83 £31.97 £6.59 £7.36 £6.70 £14.30 £6.70 £17.84 £8.79 £0.94 22 40 yes* £45.68 £31.97 £6.59 £7.36 £6.70 £14.30 £6.70 £17.84 £8.79 £0.94 32 50 yes £74.23 £31.97 £6.59 £7.36 £6.70 £14.30 £6.70 £17.84 £8.79 £0.94 40 60 yes £97.06 £31.97 £6.59 £7.36 £6.70 £14.30 £6.70 £17.84 £8.79 £0.94 50 70 yes £131.33 £54.82 £6.59 £7.36 £6.70 £14.30 £12.88 £26.54 £8.79 £0.94 65 100 yes £159.88 £54.82 £6.59 £7.36 £6.70 £14.30 £12.88 £26.54 £8.79 £0.94 75 110 yes £177.01 £93.34 £6.59 £7.36 £6.70 £14.30 £21.12 £26.54 £8.79 £0.94 85 135 yes £239.80 £93.34 £6.59 £7.36 £6.70 £14.30 £21.12 £26.54 £8.79 £0.94 100 160 yes £285.49 £93.34 £6.59 £7.36 £6.70 £14.30 £21.12 £26.54 £8.79 £0.94 130 160 yes £342.59 £216.98 £6.59 £7.36 £6.70 £14.30 £0.94 150 210 yes £399.68 £216.98 £6.59 £7.36 £6.70 £14.30 £0.94 185 230 yes £513.88 £228.39 £8.79 £41.17 £0.94 225 275 yes £570.98 £228.39 £8.79 £41.17 £0.94 265 300 yes £746.66 £329.41 £8.79 £41.17 £0.94 330 350 yes £913.56 £329.41 £8.79 £41.17 £0.94 400 450 yes £1141.95 £329.41 £8.79 £41.17 £0.94 500 580 yes £1278.11 £439.21 £8.79 £469.30 £0.94 630 660 yes £1372.54 £439.21 £8.79 £469.30 £0.94 800 900 yes £2740.69 £439.21 £8.79 £469.30 £0.94 *1NO 1NC only

AC3 @ 415V AC (A)

AC1 @ 415V AC (A)

Side Auxiliary (2NO 2NC) included

Contactor

Side Mount Auxiliary

(optional)

Front Mount Auxiliary

(2 Contacts)

Front Mount Auxiliary

(4 Contacts)

Interlock Kit

Surge Unit

Safety Cover

7 25 no £29.28 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 9 25 no £30.83 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 12 25 no £36.53 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 18 40 no £41.11 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 22 40 no £62.81 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 32 50 no £137.04 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 40 60 no £148.45 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 50 80 no £182.71 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 65 100 no £228.39 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 75 110 no £256.94 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 85 135 no £285.49 £6.59 £6.59 £7.36 £14.30 £8.79 £0.94 105 150 yes £456.78 £8.79 £41.17 £0.94 120 155 yes £474.35 £8.79 £41.17 £0.94 150 200 yes £513.88 £8.79 £41.17 £0.94 185 230 yes £570.98 £8.79 £41.17 £0.94 225 260 yes £1027.75 £8.79 £41.17 £0.94 265 300 yes £1141.95 £8.79 £41.17 £0.94 330 350 yes £1256.15 £8.79 £41.17 £0.94 400 420 yes £1941.32 £8.79 £41.17 £0.94 500 630 yes £2343.20 £8.79 £469.30 £0.94 630 660 yes £2740.69 £8.79 £469.30 £0.94 800 800 yes £3197.47 £8.79 £469.30 £0.94

Description

Stage kVAR

Stages

Total

Price

25 kVAR 400V 50Hz Mod Unit 25 1 25 £303.06

50 kVAR 400V 50Hz Mod Unit 50 1 50 £457.75

50 kVAR 400V 50Hz Mod Unit 25 2 50 £463.18

100 kVAR 400V 50Hz Mod Unit 50 2 100 £818.39

75 kVAR 400V 50Hz Mod Unit 25 3 75 £721.28

100 kVAR 400V 50Hz Mod Unit 25 4 100 £829.95

Modular Tray with Busbar Connections

Modular Tray without Busbar Connections

Description

Stage kVAR

Stages

Total

Price

25 kVAR 400V 50Hz Mod Unit 25 1 25 £252.21

50 kVAR 400V 50Hz Mod Unit 50 1 50 £380.01

50 kVAR 400V 50Hz Mod Unit 25 2 50 £378.32

100 kVAR 400V 50Hz Mod Unit 50 2 100 £655.10

75 kVAR 400V 50Hz Mod Unit 25 3 75 £621.19

Description

Stage kVAR

Stages

Total

Price

12.5kVAR 400V 50Hz Mod Unit 12.5 1 12.5 £563.90

12.5kVAR 400V 50Hz Mod Unit 12.5 2 25 £994.01

25kVAR 400V 50Hz Mod Unit 25 1 25 £590.15

50kVAR 400V 50Hz Mod Unit 50 1 50 £871.66

Modular Tray with Busbar System and Reactors

Description

Stage kVAR

Stages

Total

Price

25 kVAR 400V 50Hz Mod Unit 25 1 25 £247.58

50 kVAR 400V 50Hz Mod Unit 50 1 50 £377.90

Narrow-fit Modular Tray

Power Factor Correction

We offer modular cassettes for switchboard installation and

prefabricated freestanding automatic capacitor banks.

Quality and reliability of our equipment is guaranteed.

Capacitors are designed to meet the requirements of IEC

60831-1/2, IEC 60871-1 and IEC 60871-2. End-users like Pirelli, VATech

and Michelin rely on our range for power factor correction.

Description

Stage kVAR

Price

6 Stage PFC Control Relay 6 £215.01

8 Stage PFC Control Relay 8 £332.29

12 Stage PFC Control Relay 12 £377.90

Description

Price

12.5 kVAR 400V 50HZ REACTOR £316.46 25 kVAR 400V 50HZ REACTOR £359.89 50 kVAR 400V 50HZ REACTOR £461.66

When using reactors please consult main catalogue P. 52 to ensure correct capacitor sizing.

Control Regulators

Reactors

Description

Price

2.5 kVAR 400V 50HZ 1PH £12.01 3.33 kVAR 400V 50HZ 1PH £13.43 4.16 kVAR 400V 50HZ 1PH £14.58

PRM - Capacitors (1P)

Description

Price

2.5 kVAR 400V 50HZ 3PH £31.65 3.0 kVAR 400V 50HZ 3PH £32.57 4.0 kVAR 400V 50HZ 3PH £33.14 5.0 kVAR 400V 50HZ 3PH £33.71 7.5 kVAR 400V 50HZ 3PH £37.14 10.0 kVAR 400V 50HZ 3PH £38.10 15.0 kVAR 400V 50HZ 3PH £44.29 20.0 kVAR 400V 50HZ 3PH £49.68 25.0 kVAR 400V 50HZ 3PH £53.69 50.0 kVAR 400V 50HZ 3PH £147.54

PRT - Capacitors (3P)

Description

Stage kVAR

Stages

Total

Price

20 kVAR 400V 50Hz Equipment 20 1 20 £651.92 25 kVAR 400V 50Hz Equipment 25 1 25 £670.21 30 kVAR 400V 50Hz Equipment 30 1 30 £680.00 40 kVAR 400V 50Hz Equipment 40 1 40 £763.19 50 kVAR 400V 50Hz Equipment 50 1 50 £771.17 60 kVAR 400V 50Hz Equipment 60 1 60 £787.13 70 kVAR 400V 50Hz Equipment 70 1 70 £1169.78

Fixed-Output Wall-Mounted Version

Description

Stage kVAR

Stages

Total

Price

7.5 kVAR 400V 50Hz Equipment 2.5/5 2 7.5 £732.26 12.5 kVAR 400V 50Hz Equipment 2.5/5 5 12.5 £733.51 17.5 kVAR 400V 50Hz Equipment 2.5/5/10 3 17.5 £765.49 20 kVAR 400V 50Hz Equipment 5/10 3 20 £800.76 25 kVAR 400V 50Hz Equipment 5/10 3 25 £834.08 30 kVAR 400V 50Hz Equipment 5/10 4 30 £896.10 35 kVAR 400V 50Hz Equipment 5/10/20 3 35 £945.58 50 kVAR 400V 50Hz Equipment 10/20 3 50 £960.05

Description

Stage kVAR

Stages

Total

Price

100 kVAR 400V 50Hz Equipment 25/50 4 100 £4611.94 150 kVAR 400V 50Hz Equipment 25/50 6 150 £5511.99 200 kVAR 400V 50Hz Equipment 25/50 8 200 £7604.47 250 kVAR 400V 50Hz Equipment 50 5 250 £9084.31 300 kVAR 400V 50Hz Equipment 50 6 300 £10968.30 350 kVAR 400V 50Hz Equipment 50 7 350 £11917.08 400 kVAR 400V 50Hz Equipment 50 8 400 £12734.10 450 kVAR 400V 50Hz Equipment 50 9 450 £13257.02 500 kVAR 400V 50Hz Equipment 50 10 500 £15579.73

Automatic Freestanding Version with Reactors and Door Interlock

Description

Stage kVAR

Stages

Total

Price

60 kVAR 400V 50Hz Equipment 10/20 6 60 £1282.23 70 kVAR 400V 50Hz Equipment 10/20 7 70 £1429.64 80 kVAR 400V 50Hz Equipment 20 4 80 £1478.52 100 kVAR 400V 50Hz Equipment 20 5 100 £1704.22 125 kVAR 400V 50Hz Equipment 25 5 125 £1833.72 150 kVAR 400V 50Hz Equipment 25 6 150 £1979.05 175 kVAR 400V 50Hz Equipment 25 7 175 £2093.14

Automatic Wall-Mounted Version with Door Interlock

Description

Stage kVAR

Stages

Total

Price

125 kVAR 400V 50Hz Equipment 25/50 5 125 £2741.74 150 kVAR 400V 50Hz Equipment 25/50 6 150 £2959.75 175 kVAR 400V 50Hz Equipment 25/50 7 175 £3177.75 200 kVAR 400V 50Hz Equipment 25/50 8 200 £3395.76 225 kVAR 400V 50Hz Equipment 25/50 9 225 £3935.01 250 kVAR 400V 50Hz Equipment 25/50 10 250 £4140.10 275 kVAR 400V 50Hz Equipment 25/50 11 275 £4345.22 300 kVAR 400V 50Hz Equipment 25/50 12 300 £4550.32 325 kVAR 400V 50Hz Equipment 25/50 13 325 £5341.54 350 kVAR 400V 50Hz Equipment 25/50 14 350 £8221.07 400 kVAR 400V 50Hz Equipment 25/50 16 400 £9116.27

Automatic Freestanding Version with Door Interlock

Meters and Earth Leakage Protection

Terasaki’s range of electrical multimeters and

analysers measure the main electrical parameters

in three-phase systems. Pulsed output and RS485

versions are available.

Multi-range Earth Leakage Relays for DIN rail or

panel mounting are available.

Description

Price

35mm, 110/240/415 VAC £122.57 60mm, 110/240/415 VAC £130.22 80mm, 110/240/415 VAC £145.56 110mm, 110/110/240/415 VAC £158.17

Description

Price

110/240/415 VAC £113.17

Description

Price

TCS-2/110/240/415 VAC £120.86

Description

Price

CT1M-External Multiplier £158.17 (x10 sensitivity)

Description

Price

CT-1/35mm £45.77 CT-1/60mm £52.47 CT-1/80mm £69.11 CT-1/110mm £76.93 CT-1/210mm £173.80 CTA-1/110mm £165.00 CTA-1/210mm £237.99

Description

Price

110/240/415 VAC £121.49

ELR-1E Panel Mount Relay

Standard CTs for ELR-1E

ELRC-1 with Built in CT

ELR-3C Din Modular

Trip Supervision Relays (TCS)

Multiplying CT

Description

Price

TEMM-R4-HP Multimeter £186.14 TEMM-R4 Multimeter with

485 £233.90

Description

Price

TEMA 90 - Analyser £763.70 TEMA 90H - Analyser (Harmonics) £906.93

Description

Price

NRG 2 Software £115.21 NRG 4 Software £356.20 NRG 8 Software £415.97 NRG 16 Software £475.72 NRG 32 Software £890.56 NRG 64 Software £1852.33 NRG 128 Software £2137.33

NRG Software

Advanced External Display

Special Features:

View circuit values and breakers data safely from the outside

• Easy direct connection from breaker to T2ED

(communication module is inside the breaker)

• Easy direct connection from T2ED to Modbus

(no need for additional external communication module)

• Analogue, numerical and bar graph views

Technical Characteristics:

• Rated voltage: DC24V (Applicable range of voltage:

DC18 to DC 31V)

• Consumption (at DC24V): 50mA

• Dimensions

• (96 x 96 x 50) mm

• Serial Interface: RS485

• Protocol: Modbus-RTU

• Transmission method: Two-wire half duplex

Monitoring and Communication: T2ED

T2ED is a new Terasaki external display for TemPower 2 ACBs and TemBreak 2 MCCBs with integrated communication options. It displays circuit

measurements and information about the installed breaker in an easily readable way. T2ED may be used as a stand-alone local display.T2ED is also able to

transfer all this information directly to a Modbus network.

Host Network / Commercial Gateway

Address 1 Address 2 Address 3 Address 127

T2ED

T2ED

Electronic Display £315.00

TemTransfer 2

Automatic Changeover Controller £573.46 Power Supply £110.20 Interface Kit (optional) £ 56.77

TemTransfer 2 Automatic Changeover Controller for TemPower 2 ACBs, TemBreak 2 MCCBs and TemContact 2 Contactors

TemTransfer 2 is fully configurable Automatic Changeover Controller (ACC) for use in standby power applications. The module will monitor the voltage and frequency of the incoming AC mains (utility) supply and in the event of a failure will issue a start command to the generator control system.

• Back-lit LCD with 4 line text display • Real time clock

• PC / Front panel • Volt-free relays • Configurable timers • 5 configurable outputs • 10 configurable outputs • Event log

• Auto start inhibit • Load inhibit

CAT REF: QPG0715

© Terasaki Electric (Europe) Ltd, 2013.

Ratings and specifications mentioned in this Guide are subject to change without notice.

Terasaki Electric (Europe) Ltd.

80 Beardmore Way

Clydebank Industrial Estate

Glasgow G81 4HT,

SCOTLAND

www.terasaki.com

0141 941 1940

[email protected]

ISO 9001: 2008

We have a network of Regional Sales

Managers covering the UK and Ireland
