INTRODUCTION

FRAS BELTS :

Certain working environments such as coal mines & sensitive petrochemical installations require V-belts having Fire Resistant properties in addition to normal Anti-static properties.

FRAS (Fire Resistant Antistatic Belts) belts are suitable for such environments. This construction is thoroughly tested during and after manufacture to comply with all aspects of

IS-2494 Part II and BS-3790. ‘PIX’ FRAS belts conforms to : II 2GD c IIB X (Test report no. IB-03-4-934)

HEAT RESISTANT BELTS

Continuous contact with oil & grease have harmful effects on the belt life. The Heat Resistant properties of regular construction belts allow drive operations in ambient

0 0

temperature up to 70 C. Ambient temperature above 70 C may lead to premature ageing of belts. For both these conditions PIX AOH belts are to be used. Its special Oil Resistant cover protects the belt from contamination. Also these belts have been developed to work in ambient

0

temperature up to 100 C. PIX AOH belts are also Anti-static.

FREE SET CONCEPT

Few good reasons for using it • No length code

• Low variation in length tolerance • Less Centre adjustment

• Low stretch

• Low variation in elongation within a set of belts • Power transmitted more evenly

• Longer life

• Longer maintenance intervals • Less inventory

WRAPPED & COGGED CONSTRUCTION V-BELTS Installation and maintenance

• The drive should always be inspected periodically. • Prior to installation, inspect sheave for dirt, rust, cracks

burrs etc.

• The belts should never be forced on the pulleys.

• Maintain proper belt tension to avoid slippage. Always use ‘PIX Tension Tester’ for tensioning/re-tensioning.

• Change your belts

-- If cracks are observed at the side wall or at the bottom. - If the cord is protruding out from the belt.

4. Place Tension Tester at the centre of the span of the belt. Apply force with the help of Tension Tester perpendicular to the span till the lower surface of the ring touches the string.

5. Read the deflection force value (N) on the Newton Scale by taking reading at the lower side of the upper ring. 6. Compare the deflection force value (N) with the values

given in the table ‘A’. The deflection force value (N) should lie between the minimum and maximum values given in the table ‘A’.

7. Deflection force less than minimum recommended value in the range indicates an under-tensioned drive and

deflection force higher than maximum recommended value indicates an over-tensioned drive.

POLY/RIBBED V-BELTS Installation procedure :

1. Switch off the main supply before beginning with the exercise of installation.

2. Bring the pulleys closer to each other so that the belt can be removed easily.

3. Inspect the pulley grooves for any scores, sharp edges, dirt and rust. Clean them as required.

4. Ensure the alignment of pulleys. Make sure that the shafts are also properly aligned.

5. Mount the ribbed belt with no tension. Make sure that the ribs have been properly seated in the grooves.

6. Tension the ribbed belts as per the procedure recommended.

7. Give some running time to the drive so that the belts are properly seated in the grooves.

8. Guard the drive properly.

Tensioning procedure :

1. Fit the belt on the pulleys with no tension

2. Draw two perpendicular lines across the belt at about 80% of the belt span between the pulleys as shown in the figure. Say for example the lines are placed 1000 mm apart. ( A ).

3. Increase the distance between two lines by 0.5 to 0.75% i.e. by 5 mm to 7.5 mm for an initial spacing of 1000 mm, so that the (A) now becomes 1007.5 mm.

RIGHT WRONG

Ensure perfect alignment of pulleys

WRONG

Do not pry or roll V-belts into the pulley grooves

A A

(3)

WEDGE SECTION : XPZ

PIX ‘X’ tra : Cut Edge V-Belts

Standard : BS 3790

Lp to La 13 Li to Lp 37 Li to La 50 Manufacturing Range 600 - 5080 mm Section XPZ Dimensions Top width (mm) 10 Thickness (mm) 8 Angle Degree 36 Rec. Min Pulley Dia. 54 dp (mm) Nominal Length : Pitch length Lp in mm

‘PIX’ FRAS belts conforms to : II 2GD c IIB X (Test report no. IB-03-4-934)

Belt Length Factor (mm) Weight per metre (Kgs)

0.069

Minimum Order Qty. (No. of V-Belts) 40 10 mm XPZ Section 8 mm Features : • Oil resistant 0 0 • Temperature range : -30 C to +90 C • Maximum belt linear speed : 50 m/sec • Available in Raw Edge Plain/Cogged Const. • ATEX certified FRAS belts are available

Belt Reference Datum/Pitch Length (mm) XPZ 612 XPZ 630 XPZ 637 XPZ 662 XPZ 670 XPZ 687 XPZ 710 XPZ 722 XPZ 737 XPZ 750 XPZ 762 XPZ 772 XPZ 775 XPZ 780 XPZ 787 XPZ 800 XPZ 807 XPZ 812 XPZ 825 XPZ 837 XPZ 850 XPZ 860 XPZ 862 XPZ 875 XPZ 887 XPZ 892 XPZ 900 XPZ 912 XPZ 917 XPZ 925 XPZ 937 XPZ 940 XPZ 950 XPZ 962 XPZ 987 XPZ 1000 XPZ 1010 XPZ 1012 XPZ 1024 XPZ 1030 XPZ 1034 612 630 637 662 670 687 710 722 737 750 762 772 775 780 787 800 807 812 825 837 850 860 862 875 887 892 900 912 917 925 937 940 950 962 987 1000 1010 1012 1024 1030 1034

XPZ / 10x8

Belt Reference Datum/Pitch Length (mm) XPZ 1037 XPZ 1060 XPZ 1077 XPZ 1080 XPZ 1087 XPZ 1112 XPZ 1120 XPZ 1137 XPZ 1140 XPZ 1150 XPZ 1162 XPZ 1180 XPZ 1187 XPZ 1200 XPZ 1202 XPZ 1212 XPZ 1217 XPZ 1220 XPZ 1225 XPZ 1237 XPZ 1250 XPZ 1262 XPZ 1270 XPZ 1280 XPZ 1287 XPZ 1300 XPZ 1312 XPZ 1320 XPZ 1337 XPZ 1340 XPZ 1347 XPZ 1362 XPZ 1387 XPZ 1400 XPZ 1412 XPZ 1420 XPZ 1437 XPZ 1450 XPZ 1462 XPZ 1470 XPZ 1487 1037 1060 1077 1080 1087 1112 1120 1137 1140 1150 1162 1180 1187 1200 1202 1212 1217 1220 1225 1237 1250 1262 1270 1280 1287 1300 1312 1320 1337 1340 1347 1362 1387 1400 1412 1420 1437 1450 1462 1470 1487

XPZ / 10x8

Belt Reference Datum/Pitch Length (mm) XPZ 1500 XPZ 1512 XPZ 1520 XPZ 1537 XPZ 1548 XPZ 1550 XPZ 1557 XPZ 1562 XPZ 1587 XPZ 1600 XPZ 1612 XPZ 1637 XPZ 1662 XPZ 1700 XPZ 1750 XPZ 1762 XPZ 1800 XPZ 1850 XPZ 1900 XPZ 1950 XPZ 2000 XPZ 2030 XPZ 2120 XPZ 2160 XPZ 2240 XPZ 2280 XPZ 2360 XPZ 2410 XPZ 2500 XPZ 2540 XPZ 2650 XPZ 2690 XPZ 2800 XPZ 2840 XPZ 3000 XPZ 3150 XPZ 3170 XPZ 3350 XPZ 3550 1500 1512 1520 1537 1548 1550 1557 1562 1587 1600 1612 1637 1662 1700 1750 1762 1800 1850 1900 1950 2000 2030 2120 2160 2240 2280 2360 2410 2500 2540 2650 2690 2800 2840 3000 3150 3170 3350 3550

XPZ / 10x8

(4)

WEDGE SECTION : XPA

PIX ‘X’ tra : Cut Edge V-Belts

Standard : BS 3790

Belt Reference Datum/Pitch Length (mm) XPA 630 XPA 690 XPA 732 XPA 750 XPA 757 XPA 775 XPA 782 XPA 800 XPA 807 XPA 832 XPA 850 XPA 857 XPA 875 XPA 882 XPA 900 XPA 907 XPA 925 XPA 932 XPA 950 XPA 957 XPA 975 XPA 982 XPA 1000 XPA 1007 XPA 1030 XPA 1060 XPA 1070 XPA 1082 XPA 1090 XPA 1107 XPA 1120 XPA 1132 XPA 1142 XPA 1150 630 690 732 750 757 775 782 800 807 832 850 857 875 882 900 907 925 932 950 957 975 982 1000 1007 1030 1060 1070 1082 1090 1107 1120 1132 1142 1150

XPA / 13x10

Features : • Oil resistant 0 0 • Temperature range : -30 C to +90 C • Maximum belt linear speed : 50 m/sec • Available in Raw Edge Plain/Cogged Const. • ATEX certified FRAS belts are available

13 mm XPA Section 10 mm Belt Reference Datum/Pitch Length (mm) XPA 1157 XPA 1172 XPA 1180 XPA 1207 XPA 1220 XPA 1232 XPA 1250 XPA 1257 XPA 1272 XPA 1282 XPA 1307 XPA 1320 XPA 1332 XPA 1357 XPA 1382 XPA 1400 XPA 1432 XPA 1450 XPA 1457 XPA 1482 XPA 1490 XPA 1500 XPA 1507 XPA 1522 XPA 1532 XPA 1550 XPA 1557 XPA 1582 XPA 1600 XPA 1607 XPA 1632 XPA 1657 XPA 1682 XPA 1700 1157 1172 1180 1207 1220 1232 1250 1257 1272 1282 1307 1320 1332 1357 1382 1400 1432 1450 1457 1482 1490 1500 1507 1522 1532 1550 1557 1582 1600 1607 1632 1657 1682 1700

XPA / 13x10

Belt Reference Datum/Pitch Length (mm) XPA 1732 XPA 1750 XPA 1757 XPA 1782 XPA 1800 XPA 1850 XPA 1857 XPA 1882 XPA 1900 XPA 1932 XPA 1950 XPA 1957 XPA 1982 XPA 2000 XPA 2032 XPA 2057 XPA 2060 XPA 2082 XPA 2120 XPA 2180 XPA 2240 XPA 2282 XPA 2360 XPA 2432 XPA 2500 XPA 2650 XPA 2682 XPA 2800 XPA 2840 XPA 2882 XPA 3000 XPA 3150 XPA 3350 XPA 3550 1732 1750 1757 1782 1800 1850 1857 1882 1900 1932 1950 1957 1982 2000 2032 2057 2060 2082 2120 2180 2240 2282 2360 2432 2500 2650 2682 2800 2840 2882 3000 3150 3350 3550

XPA / 13x10

Lp to La 18 Li to Lp 45 Li to La 63 Manufacturing Range 600 - 5080 mm Section XPA Dimensions Top width (mm) 13 Thickness (mm) 10 Angle Degree 36 Rec. Min Pulley Dia. 80 dp (mm) Nominal Length : Pitch length Lp in mm

0.112

Minimum Order Qty. (No. of V-Belts)

(5)

WEDGE SECTION : XPB

PIX ‘X’ tra : Cut Edge V-Belts

Standard : BS 3790

Features :

• Oil resistant

0 0

• Temperature range : -30 C to +90 C • Maximum belt linear speed : 50 m/sec • Available in Raw Edge Plain/Cogged Const. • ATEX certified FRAS belts are available

17 mm

XPB Section

14 mm

WEDGE SECTION : XPC

PIX ‘X’ tra : Cut Edge V-Belts

Standard : BS 3790

Features :

• Oil resistant

0 0

• Temperature range : -30 C to +90 C • Maximum belt linear speed : 50 m/sec • Available in Raw Edge Plain/Cogged Const. • ATEX certified FRAS belts are available

22 mm XPC Section 18 mm Belt Reference Datum/Pitch Length (mm) XPB 1000 XPB 1060 XPB 1120 XPB 1180 XPB 1250 XPB 1260 XPB 1320 XPB 1340 XPB 1400 XPB 1410 XPB 1450 XPB 1480 XPB 1500 XPB 1510 XPB 1525 XPB 1590 1000 1060 1120 1180 1250 1260 1320 1340 1400 1410 1450 1480 1500 1510 1525 1590

XPB / 17x14

Belt Reference Datum/Pitch Length (mm) XPB 1600 XPB 1620 XPB 1650 XPB 1690 XPB 1700 XPB 1750 XPB 1800 XPB 1850 XPB 1900 XPB 2000 XPB 2020 XPB 2120 XPB 2150 XPB 2180 XPB 2240 XPB 2280 1600 1620 1650 1690 1700 1750 1800 1850 1900 2000 2020 2120 2150 2180 2240 2280

XPB / 17x14

Belt Reference Datum/Pitch Length (mm) XPB 2360 XPB 2410 XPB 2500 XPB 2530 XPB 2650 XPB 2680 XPB 2800 XPB 2840 XPB 2990 XPB 3000 XPB 3150 XPB 3170 XPB 3340 XPB 3350 XPB 3550 2360 2410 2500 2530 2650 2680 2800 2840 2990 3000 3150 3170 3340 3350 3550

XPB / 17x14

Belt Reference Datum/Pitch Length (mm) XPC 2000 XPC 2120 XPC 2240 XPC 2360 2000 2120 2240 2360

XPC / 22x18

Belt Reference Datum/Pitch Length (mm) XPC 2500 XPC 2650 XPC 2800 XPC 3000 2500 2650 2800 3000

XPC / 22x18

Belt Reference Datum/Pitch Length (mm) XPC 3150 XPC 3350 XPC 3550 3150 3350 3550

XPC / 22x18

Lp to La 28 Li to Lp 60 Li to La 88 Manufacturing Range 600 - 5080 mm Section XPB Dimensions Top width (mm) 17 Thickness (mm) 14 Angle Degree 36 Rec. Min Pulley Dia. 128 dp (mm) Nominal Length : Pitch length Lp in mm

0.194

Minimum Order Qty. (No. of V-Belts) 25 Lp to La 30 Li to Lp 83 Li to La 113 Manufacturing Range 600 - 5080 mm Section XPC Dimensions Top width (mm) 22 Thickness (mm) 18 Angle Degree 36 Rec. Min Pulley Dia. 180 dp (mm) Nominal Length : Pitch length Lp in mm

0.332

Minimum Order Qty. (No. of V-Belts)

20

(6)

HIGH CAPACITY NARROW V-BELTS : 3VX

PIX ‘X’ tra : Cut Edge V-Belts

Standard : RMA IP 22, DIN 2215

3VX / 9.7x8

Features :

• Oil resistant

0 0

• Temperature range : -30 C to +90 C • Maximum belt linear speed : 50 m/sec • Available in Raw Edge Plain/Cogged Const.

Lp to La 13 Li to Lp 37 Li to La 50 Manufacturing Range 24 - 200 inches Section 3VX Dimensions Top width (mm) 9.7 Thickness (mm) 8 Angle Degree 36 Rec. Min Pulley Dia. 55 de (mm) Nominal Length : Belt no /10 = outside length in inches

0.069

Minimum Order Qty. (No. of V-Belts) 40 9.7 mm 3VX Section 8 mm Belt Reference Outside Length (mm) 3VX 250 3VX 260 3VX 265 3VX 280 3VX 300 3VX 315 3VX 335 3VX 350 3VX 355 3VX 370 3VX 375 3VX 400 3VX 425 3VX 450 635 660 673 711 762 800 851 889 902 940 953 1016 1080 1143

3VX / 9.7x8

Belt Reference Outside Length (mm) 3VX 475 3VX 500 3VX 520 3VX 530 3VX 560 3VX 600 3VX 617 3VX 630 3VX 670 3VX 710 3VX 750 3VX 800 3VX 850 3VX 900 1207 1270 1321 1346 1422 1524 1567 1600 1702 1803 1905 2032 2159 2286

3VX / 9.7x8

Belt Reference Outside Length (mm) 3VX 950 3VX 960 3VX 1000 3VX 1060 3VX 1120 3VX 1180 3VX 1250 3VX 1320 3VX 1400 3VX 1425 3VX 1450 3VX 1500 2413 2438 2540 2692 2845 2997 3175 3353 3556 3620 3683 3810

HIGH CAPACITY NARROW V-BELTS : 5VX

PIX ‘X’ tra : Cut Edge V-Belts

Standard : RMA IP 22, DIN 2215

5VX / 16x14

Lp to La 25 Li to Lp 60 Li to La 85 Manufacturing Range 24 - 200 inches Section 5VX Dimensions Top width (mm) 16 Thickness (mm) 14 Angle Degree 36 Rec. Min Pulley Dia. 112 de (mm) Nominal Length : Belt no /10 = Outside length in inches

0.186

Minimum Order Qty. (No. of V-Belts) 25 Features : • Oil resistant 0 0 • Temperature range : -30 C to +90 C • Maximum belt linear speed : 50 m/sec • Available in Raw Edge Plain/Cogged Const.

16 mm 5VX Section 14 mm Belt Reference Outside Length (mm) 5VX 500 5VX 530 5VX 560 5VX 600 5VX 630 5VX 670 5VX 710 5VX 750 1270 1346 1422 1524 1600 1702 1803 1905

5VX / 16x14

Belt Reference Outside Length (mm)

5VX / 16x14

Belt Reference Outside Length (mm) 2032 2159 2286 2413 2540 2692 2845 2997 5VX 800 5VX 850 5VX 900 5VX 950 5VX 1000 5VX 1060 5VX 1120 5VX 1180 5VX 1250 5VX 1320 5VX 1400 5VX 1500 5VX 1600 5VX 1650 3175 3353 3556 3810 4064 4191
