Influence of viticultural and winemaking practices on wine composition and quality: research past, present and future.

(1)

Anita Oberholster

Influence of viticultural and winemaking

practices on wine composition and quality:

(2)

Background – phenols in wine

• Main phenols (flavonoids) in red wine

– Anthocyanins responsible for red color – Flavan‐3‐ols (ex. catechin, epicatechin) • Oligomers and polymers of flavan‐3‐ols, so called proanthocyanidins (PA) or condensed tannins Fig 1

• Extraction during wine making

– Seed PA (mDP ~ 10) – Skin PA (mDP ~ 30) – Anthocyanins from skins Anthocyanin

(3)

Figure 1: Proanthocyanidins

Extension units

(4)

Background – phenols in wine

• Main phenols (flavonoids) in red wine

– Anthocyanins responsible for red color – Flavan‐3‐ols (ex. catechin, epicatechin)

• Oligomers and polymers of flavan‐3‐ols, so called proanthocyanidins (PA) or condensed tannins Fig 1

• Extraction during wine making

– Seed PA (mDP ~ 10) – Skin PA (mDP ~ 30)

– Anthocyanins from skins

(5)

Background – phenols in wine

• During wine maturation and ageing

– Anthocyanins and PA polymerise with each other by different mechanisms Fig 2 • Influenced by grape composition, presence of wood (hydrolyzable) tannins

• Sensory properties of proanthocyanidins (PA)

– Main contributors to bitterness and astringency – Ratio of astringency to bitterness increase with mDP – ‘Coarseness’ and ‘dryness’ of astringency increase with galloylation

Gawel et al. (1998) Austr. J. Grape Wine Res.(6) 74 Vidal et al. (2003) J. Sci . Food Agric. (83) 564

(6)

Figure 2: Wine pigments

Direct condensation

Mateus et al., (2003) J. Agric. Food Chem. 51: 1919‐1923; Reynolds (2010) Managing wine quality.

(7)

Background – phenols in wine

• During wine maturation and ageing

– Anthocyanins and PA polymerize with each other by different mechanisms Fig 2 • Influenced by grape composition, presence of wood (hydrolyzable) tannins

• Sensory properties of proanthocyanidins (PA)

– Main contributors to bitterness and astringency – Ratio of astringency to bitterness increase with mDP – ‘Coarseness’ and ‘dryness’ of astringency increase with galloylation

Gawel et al. (1998) Austr. J. Grape Wine Res.(6) 74 Vidal et al. (2003) J. Sci . Food Agric. (83) 564

(8)

Chemical and sensory properties of red

wine pigments

• Characterization of polymeric pigments

– Comparing the polymeric pigment profile of 6 month old and 5 year old Syrah wine from the same vineyard •  conc. of polymeric pigments, methylmethine and vinyl‐linked pigments • mDP of wine 4  10 – Development of the mouth‐feel wheel Fig 3 – Determined the mouth‐feel of different white wine treatments Fig 4

(9)

Figure 3: Mouth‐feel wheel

(10)

Chemical and sensory properties of red

wine pigments

• Characterization of polymeric pigments

– Comparing the polymeric pigment profile of 6 month old and 5 year old Syrah wine from the same vineyard •  conc. of polymeric pigments, methylmethine and vinyl‐linked pigments • mDP of wine 4  10 – Development of the mouth‐feel wheel Fig 3 – Determined the mouth‐feel of different white wine treatments Fig 4

(11)

Figure 4: Mouth‐feel of different

white wine treatments

Oberholster, Francis, Iland, Waters (2009) Austr. J. Grape Wine Res. (15) 59‐69

White free run juice White free run juice + anth Red wine White free run juice + white skins and seeds + anth White free run juice + white skins + seeds White free run juice + red skins and seeds W WA WS WSA WRS RS

(12)

Mouth‐feel of different white

wine treatments

Oberholster, Francis, Iland, Waters (2009) Austr. J. Grape Wine Res. (15) 59‐69

• W: white free run juice • WA: white free run juice + anth • WS: white free run juice + white skins and seeds • WSA: white free run juice + white skins and seeds + anth • WRS: white free run juice + red skins and seeds • RS: red wine

(13)

Saucier et al. (1997) Phytochem. 46: 229‐234; Zoeklein et al. (1995) Wine analysis and production. Chapman & Hall.

Exogenous/Commercial Tannins

• _{Commercial tannin extracted from nutgalls,}

tannin rich wood and grape seeds

(Resolution Oeno, 2002)

• _{Classification of commercial tannin}

– Condensed tannin (catechin > 50 mg/g or proanthocyanic tannin content > 0.5 mg/g) – Nutgalls (digallic acid content 4 – 8 mg/g) – Oak (scopoletine content > 4 g/g)

• _{Commercial tannin extracted with EtOH,}

water, ether or steam

(Zoecklein, 2005; Saucier et al. 1997)

(14)

Use of Exogenous/Commercial

Tannin

• _{Tannin addition for following purposes or}

problem correction:

– Contribute to mouthfeel/taste – Protect against oxidation enzymes, – Assist to precipitate proteins, – Modify aromas including vegetative aromas – Increase aging potential – Stabilize wine color

• Few scientific publications about effect of

commercial tannin addition

(15)

Influence of commercial tannins on red

wine phenol composition and quality

Keulder, Oberholster, Du Toit (2006)

Treatment and source Type of tannin according to the supplier

Dosage (mg/L)

Tanenol Rouge (TR) Condensed & hydrolysable 100 300

Oenotan (Oeno) Hydrolysable 100 300

QCTN Hydrolysable 100 300

Tanin VR Supra (VR S) Condensed & hydrolysable 300 500 1000

Tanin VR Supra NF (VR NF)

hydrolysable 300 500 1000

Control (Cntrl)

• Addition of different commercial tannins to wine (Merlot, Cabernet Sauvignon, Syrah) before fermentation (2004-5)

(16)

Addition of commercial tannins to

wine after fermentation

• Effect of different phenol content wines

– Merlot and Cabernet Sauvignon (3 tannins, 100 mg/L)

» pressed at 6°Brix

» 10 days extended maceration

– No signf diffr compared with controls

– Addition of tannins did decrease diffr between wines made with and without extended maceration

• When O₂ addition (0, 3 and 8 mg/L oxygen) were combined with tannin addition

– Clear that O₂ had greater effect on phenol composition

(17)

Micro‐oxygenation (MOX)

Del Ãlamo et al., (2010) Anal. Chim. Acta 660:92‐101. Gómez‐Plaza and Cano‐López (2011) Food Chem. 125: 1131‐1140.

• _{Used to enhance color density and}

stabilization, similar effect to barrel

maturation

• MOX before MLF 10‐30 mg/L/month,

after MLF 2‐5 mg/L/month

• O₂ penetration through the barrel estimated at 1.66 and 2.5 ml.L‐1_.month‐1 •  Color density, similar to barrel aging (Gómez‐Plaza and Cano‐López, 2011)

(18)

Investigation of the effect of MOX

before MLF on color density

Geldenhuys, Oberholster, Du Toit (2009) Treatment Before MLF CD (AU) After MLF CD (AU) 0x Seeds control 8.9 ± 0.1a 8.3 ± 0.1a 16 mg/L 12.9 ± 0.3b _{8.7 ± 0}a 1x Seeds control 17.4 ± 0.1c 13.4 ± 0.1b 16 mg/L 19.3 ± 0.1d _{13.7 ± 0.2}b 2x Seeds control 20.9 ± 0.3e 14.9 ± 0.2g 16 mg/L 23.8 ± 0.3f _{13.8 ± 0.5}b • Effect of different oxygen dosages wines made with different grape seed concentrations after 2 months • Color density (CD) increased with amount of seeds and MOX (2 months)

(19)

Investigation of the effect of MOX

before MLF on Pinotage wine

Geldenhuys, Oberholster, Du Toit (2009)

3.2m

Control 16 mg/L O₂ 32 mg/L O₂

• Aged for 2 months in tanks at 20 °C (68°F)

• Samples taken at different tank levels were similar • MOX improved color stabilization, no signf difference

(20)

Fining and cross‐flow

microfiltration

• Reasons for fining

– Clarification and stability (sterilization) – Reducing wine astringency

• Filtration

• Clarification and stability (sterilization)

• Does cross‐flow microfiltration reduce

astringency?

• Replace fining

(21)

Control Gelatin (100 mL/hL) Egg Albumin (10 g/hL) Cross‐flow microfiltration Pinotage wine after MLF • 3 Bottles per tank • Analysis: 0 and 3.5 months

Influence of fining and cross‐flow

microfiltration on Pinotage wine

Carstens, Du Toit, Oberholster (2010)

(22)

Influence of fining and cross‐flow

microfiltration on Pinotage wine

Carstens, Du Toit, Oberholster (2010) • Fining and cross‐flow microfiltration (CF) mDP by 25% • CF removed the most color • CF only treatment perceived as different after 3.5 months of bottle aging using difference testing 0 5 10 15 20 25 30 35 40 45

Control Gelatin Egg Albumin Cross‐Flow Microfiltration

Turbidity

(NTU)

Treatments

(23)

Oberholster, Botes, Lambrechts (2010), J. Int. Sci. Vigne Vin. Special issue Macrowine, 33‐40.

Determine opt ripeness in Cab

Sauv grapes~wine quality

• Study over 4 years in partnership with

Distell

• _{Vineyards in 4 climatic zones (}

Cabernet Sauvignon

)

• _{Sampled weekly}

• _{Measurements included color and}

phenols (RP‐HPLC, spectrophotometric)

• Grape skin extract and wine tastings

(24)

Oberholster, Botes, Lambrechts (2010), J. Int. Sci. Vigne Vin. Special issue Macrowine, 33‐40.

Determine opt ripeness in Cab

Sauv grapes~wine quality

R2_{= 0.7376} R2 = 0.6956 R2_{= 0.6365} 0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0

Jan 5 Jan 15 Jan 25 Feb 4 Feb 14 Feb 24 Mar 5 Mar 15 Mar 25 Apr 4

Sample date m g an th / be rry 2003 2004 2005 26°B 26°B 26°B • Strong relationship between °Brix, color and grape and wine quality • Seasonal differences result in larger variance then vineyards in different climatic zones

(25)

Blancquaert‐Witbooi, Oberholster, Da Silva, Deloire (current)

Projects 2011‐2012

• _{Study in South Africa investigating the}

effects of temp and light on grape skin

and seed tannin composition

– Determine the tannin structure during the green berry phase and ripening phase – Determine whether the tannin structure is modified during the ripening phase by vine water status and berry water content through bunch exposure (light and temperature)

(26)

Effect of abiotic factors on tannin

development

Shaded Exposed Exposed_+ 95% UV net Shaded + 95% UV net West Focus: Bunch microclimate, light quality, quantity and temperature Blancquaert‐Witbooi, Da Silva, Oberholster, Deloire (current)

(27)

B

Effect of abiotic factors on tannin

development

Blancquaert‐Witbooi, Da Silva, Oberholster, Deloire (current) C A D A) STD B) STD + UV C )LRW D) LRW + UV

(28)

Blancquaert‐Witbooi, Da Silva, Oberholster, Deloire (current)

(29)

Effect of abiotic factors on tannin

development

Blancquaert‐Witbooi, Da Silva, Oberholster, Deloire (current) 0.00 5.00 10.00 15.00 20.00 25.00 30.00 35.00 40.00 45.00 STD LRW+UV mDP of Skin Tannin with Ripening mDP Date 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 8.00 9.00 10.00 STD LRW+UV Date mDP mDP of Seed Tannin with Ripening

(30)

Projects 2011‐2012

• Study in South Africa investigating the

effects of temp and light on grape skin

and seed tannin

• _{Investigation the use of cold stabilization}

alternatives such as CMC

– Cold stabilization vs CMC addition • Sauvignon blanc and Chardonnay • Chemical panel, filterbility, tartrate stability, turbidity

(31)

Projects 2011‐2012

• Study in South Africa investigating the

effects of temp and light on grape skin

and seed tannin

• _{Investigation the use of cold stabilization}

alternatives such as CMC, tannin

additions

• _{Study with E&J Gallo – investigating}

extraction kinetics and impact of temp

gradients in red wine making (DEB, ALW,

DOA, CB, RRB)

(32)

Cap management

• Investigate effects of temperature gradients on cap extraction

– 12 treatments ‐ diffr pump‐over regimes, fermentation temp, cap and must temp • Evaluate spatial heterogeneity of phenolic profiles in a pilot‐scale wine fermentor with two‐phases and natural temperature gradients E&J Gallo funding

(33)

(34)

Projects 2011‐2012

• Study in South Africa investigating the

effects of temp and light on grape skin and

seed tannin

• Investigation the use of cold stabilization

alternatives such as CMC, tannin additions

• Study with E&J Gallo – investigating

extraction kinetics and impact of temp

gradients in red wine making (DEB, ALW,

DOA, CB, RRB)

• Barrel trial investigating the effect of barrel

maturation on phenol composition and

mouth‐feel

(35)

Barrel maturation, MOX and wood

alternatives

Barrel maturation + + + vs Stainless steel tank + O2 + staves Stainless steel tank + O₂+ chips Stainless steel tank + O₂ Stainless steel tank MOX MOX MOX + +

(36)

• Red wine blend for 6 month maturation – 63% Cab Sauv, 27% Merlot, 10% Malbec • Analyses after 1 month of bottle aging – Phenolic profile – Tannin analysis • Isolation of tannin using SPE • Phloroglucinolysis (determine composition and mDP) • LC‐MS (identify polymeric pigment and possible ellagitannin derivatives) – UV‐vis (color intensity) – Sensory analysis • Mouth‐feel and aroma • Preference testing

Barrel maturation and wood

alternatives

(37)

• Comparing barrel maturation, micro‐

oxygenation and maturation in stainless

steel tank directly

– Investigate the influence of wood tannins and oxygen • Color intensity and stability • Polymerization reactions • Mouth‐feel properties of the wine

• Comparison between the use of wood

alternatives (staves and chips) and barrel

maturation

– Ellagitannin extraction differences into wine – Difference in mouth‐feel, aroma and quality

Barrel maturation and wood

alternatives

(38)

• Investigating the impact of pectolytic

enzymes and commercial tannin on wine

made from different quality grapes

• Investigating the use of grape berry sugar

loading to build a predictive model for the

determination of optimal ripeness for a

specific wine style in a changing climate

• The effect of the re‐use of winery

wastewater for irrigation on soil, vine, grape

composition and wine quality

• Investigating changes in wine composition

and quality with different settings of optical

berry sorting

Future Projects

(39)

Concluding remarks

• Running survey “Current Issues in

Managing Cost and Quality in Wine

Production”

– http:\\wineserver.ucdavis.edu/survey/ • Contact details: Anita Oberholster – RMI North, room 3146 – [email protected] – Tel: (530) 754‐4866 – http://wineserver.ucdavis.edu
