TIMBER DEFECT DETECTION BASED ON SYSTEMATIC FEATURE ANALYSIS AND ONE CLASS CLASSIFIER
UMMI RABA’AH BINTI HASHIM
A thesis submitted in fulfilment of the requirements for the award of the degree of
Doctor of Philosophy (Computer Science)
Faculty of Computing Universiti Teknologi Malaysia
DEDICATION
ACKNOWLEDGEMENT
In the name of Allah, most gracious, most merciful. Praise to Allah, for guiding me in the right path, blessing me with the best in this life. It takes the efforts and supports of many to bring this research study to completion. I am indebted to the dozens of people guiding and supporting me throughout this study. I would like to express my gratitude to the following special individuals:
1. My supervisor and co-supervisor, Assoc. Prof. Dr. Siti Zaiton binti Mohd Hashim and Assoc. Prof. Dr. Azah Kamilah Muda, for their wonderful guidance and continuous encouragement during the progression of my study. 2. Academicians of UTM, for their valuable teaching, comment, idea and
motivation for this research.
3. Industry experts from Hasro Malaysia, Teras Puncak and Elegant Success (Malaysian wood products manufacturers) for their co-operation, invaluable consultation and kind support.
4. Universiti Teknikal Malaysia Melaka (UTeM) and Ministry of Education Malaysia for their generous financial support.
5. My husband and children, for their patience and love. 6. My parents and brothers, for their blessing and care.
ABSTRACT
Substantial research effort has been done in the automation of timber defect detection to improve the quality of timber products, optimise raw material resources, increase productivity and reduce error related to human labour. This study extends the work on automated inspection of timber boards to Malaysian timber species hoping that the outcome will benefit the local wood product industries. This study aims to propose a timber surface defect detection approach which is robust in detecting various defects on multiple timber species using significant texture features, validated using data from local timber species. In the experiments, defective samples from Malaysian Hardwood are collected and labelled under supervision of industry experts. Additionally, this work gives new insight into the characterisation of timber defect images by using statistical texture from orientation independent Grey Level Dependence Matrix (GLDM) with appropriate parameter analysis. A Systematic Feature Analysis (SFA) which includes exploratory and confirmatory multivariate analysis was performed to investigate the discriminative power of the proposed feature set. The SFA produces a feature set of timber surface defects capable of providing significant discrimination between defects and clear wood classes. Finally, a new concept in the domain of timber defect detection based on outlier detection concept was introduced to overcome the problem of imbalanced data. This study proposes a robust Mahalanobis one class classifier (MC) with Fast Minimum Covariance Determinant estimator (MC-FMCD) for species independent timber defect detection. The experimental results show that the proposed approach achieved superior performance over the classical Mahalanobis Distance (MD) and robust in detecting many types of defects across timber species.
