Benjamin BOILLOT. Research Engineer

1

Benjamin BOILLOT

Research Engineer [email protected]

2

Contents

• PV MARKET

– French context : Government policy and strategy

– Market and incentives

– BIPV policy

3

4

“Changing era” : title of a well attended

Conference and Exhibition on energy efficiency

and renewables, Paris, November 2008

• Going from centralized to decentralized

• Everybody can be an actor of CO2-free energy

production

• CEA changed its name : “alternative energies”

added

Today’s electricity production in France:

•

Nuclear 80 %

•

Hydroelectricity 15 %

•

Other 5 %

5

French energy policy context : decisions favourable to RES

• Energy framework Law (2005) and ‘Grenelle of Environment’

law (2009)

• Renewables will contribute to energy mix

• ADEME Agency is in charge of implementing government

policy

• Regional and departmental Councils are active in promotion

and development

National objectives :

• 5 400 MW

of PV installed by 2020

• 120 million m²

potential area of public sector buildings to

be equipped with PV

6

Government strategy for photovoltaics

• focus upon building applications

• make PV a common place construction element of

every building in the long term

– In relation to “positive energy building” concept

• allow deployment through stimulation measures

7

The French market : 3 to 400 MW grid-connected so far

• A very difficult context until 2006,

• A take-off in 2008, …

25 MW

269 MW

69 MW

8

Evolution of type of applications 1992-2009

0% 20% 40% 60% 80% 100% 1992 1994 1996 1998 2000 2002 2004 2006 2008 2010 Grid-connected Off-grid

Percentages of grid-connected and off-grid PV power in France

9

‘Feed-in’ tariffs to promote PV applications (1/2)

Application category Feed-in tariff (EUR/kWh) BASE: Any application (including

ground-based PV plants)

0,276

0,331

_0,370

BIPV existing large area

industrial/agricultural buildings

0,440

BIPV private dwellings P < 3 kW P > 3 kW, homes, schools, hospitals…

0,580

0,510

Table 1 – Photovoltaic purchase tariffs 2010-09-01 (continental France)

10

‘Feed-in’ tariffs to promote PV applications (2/2)

• contract established for 20 years by ERDF. Tariff adjusted

annually for inflation

• from 2012-01-01 tariffs for new projects will decrease 10

% per year

• financed through CSPE. A financial contribution paid by

electricity consumers and collected by EDF

11

Tax credits to promote residential PV < 3 kW

• Private income tax payers are untitled to tax credit and

feed-in tariffs

• 25 % of equipment cost tax deductible (installation labour

costs not taken into account) (max 16 000 EUR for a

couple)

• Low VAT on equipment: 5,5 % (instead of 19,6 %)

• No VAT and no income tax on PV electricity sales by

private PV owner (< 3 kW)

• Some Regional councils may add other type of support

12

Impact of market stimulation measures

on annual installation volume (MW per year)

0 50 100 150 200 250 300 350 400 2004 2005 2006 2007 2008 2009 2010 2004 2005 2006 2007 2008 2009 2010 Introduction base PV tariff + tax credit 40 % + tax credit 50 % + BIPV

BIPV fully applies

13

Impact of market stimulation measures in 2010

Source: ADEME, AC 2536 197 3131 271 2812 422 3550 614 0 500 1000 1500 2000 2500 3000 3500 4000 31 Décembre 2009

31 mars 2010 30 juin 2010 30 septembre 2010 file d'attente de raccordement (MW)

14

The breakdown per size

• Most installations < 3kW (tax credits) • Few large power plants > 3MW

0 10000 20000 30000 40000 50000 60000 70000 80000 1 2 3 6 18 36 120 250 500 1000 3000 5000 7500 10000 12000 402 17528 79302 3775 _{1930 2256} 870 340 17 31 18 5 2 3 1 N o mb re Puissance kW

15

The breakdown per size

• Most installations < 3kW (tax credits) • Few large power plants > 3MW

16

17

• a BIPV module is a construction element which produces electricity and carries out another function

• a BIPV element will become cheaper than a standard PV module on top of existing roof

• innovation is on-going to develop new products: 80 “BIPV” products available on French market

• 55 products are, so far, assessed suitable for use in building by CSTB (see below)

18

BIPV or not BIPV? That’s the question…

Newly formed

CEIAB Committee

Committee for the assessment of access to BIPV tariffs

19

BIPV or BIPV Simplified ?

BIPV “Simplified” : 36 ct€/KWh

20

BIPV tariff applies

21

22

BIPV “simplified” tariff applies

PV System on a sport centre in Challes-les-Eaux (Savoie Department) – 203 kW (Courtesy: Edisun Power)

23

24

Parking lot of a shopping centre: 1,15 MW, Saint-Aunès (concept Sunvie.eu)

PV in the built environment triggers creativity

25

Positive effects of Government policy

• Since 2006, in addition to historical actors new operators are emerging

• From 3 to 10 PV module manufacturers

• From 10 to 150 PV companies

• Jobs increased to 8 500 (+ 80 %/ 2008)

• Utilities EDF ENR, Poweo, Solaire Direct, Juwi,

Séchilienne Sidec, etc. are operating large warehouse roofs and ground-based PV plants

• 60 MW of ground based PV plant so far

Source: ADEME national survey report for IEA PVPS www.iea-pvps.org

26

Actors of photovoltaics in France (1/2)

• Institutional

– Ministry of Ecology, Energy, Sustainable development and the Sea (MEEDDM)

– ADEME Agency, ANR Agency, OSEO Agency

– Regional councils and Departmental councils (local authorities) • Industry

– Manufacturers of PV materials, PV components, PV systems, equipments – Developers, implementers, installers, roofers, utilities, …

– Professional associations …

• Research and technological development • Certification bodies and testing labs

27

The French industrial companies involved in PV :

Some are big players worldwide

Silicon Ingots Wafers Cells Modules Systems Installation

Ferropem ECM FEE Solarezo Emix Tenesol Photowatt Solaire Direct Sillia Energie Vesuvius Air Liquide : 50% Solems Cyberstar PV Alliance First Solar EDF St Gobain : 30% Schneider Sun Land 21 Adixen Sunnco Carbonne Lorraine Apex BP Solar

Arkema : 30% Total GDF Suez

Soprema Clipsol Urbasolar

8500 jobs, 150 enterprises, 5000 installers :

28

Quality Policy

CSTB Technical Assessment Certificate for PV elements

‘QualiPV’ label for PV installers

‘Consuel’ safety conformity control

Useful references:

29

Partners of quality policy for PV applications in buildings

• ADEME

implements the government Environment policy in

energy efficiency and Renewables including Photovoltaics

• CSTB

brings its know-how in quality assessment to assist the

construction sector

• CERTISOLIS (CSTB, LNE) and

BV-LCIE test and certify PV

modules and components

• INES (Institute for solar energy) performs component testing

and R&D

• professional associations SER/SOLER, Quali’PV, etc. are

partners of quality policy

30

CSTB’s Technical Assessment (ATec) and Pass’Innovation

• Technical assessment

(ATec) and Pass’innovation

assess suitability of PV

modules for use in buildings

– voluntary procedure. Validity is time limited

• these certificates give confidence to building sector, users and

insurance companies

– 8 PV ATec and 47 PV Pass’Innovation issued (as of September 2010)

– Some products are developed in partnership with Chinese PV cells/laminates (Suntech, Trina, Yingli, …)

31

QUALI PV Label

• QUALI PV

: quality label for PV

installers

• A branch initiative, provided by SER professional

Association

• Qualiphoton platform for training technicians

• Commitment of installers to respect the 10-point Charter

• More than 5 600 installation companies have received the

label

32

Conclusion on PV

• Political support essential to promote energy efficiency and renewable energy sources

• Government policy has:

- Created a dynamic market;

- Structured industrial and professional offerings; - Created skilled jobs.

• The recent readjustments of tariffs and tax measures could create a crisis of investor confidence

• BIPV applications

– Make PV modules a standard construction element – Contribute to higher environmental quality buildings – Stimulate innovation in PV industry and building sector

• CSTB’s PV Technical Assessment Certificate (ATec) is recommended to reach building sector and give confidence to insurance companies

• Quality of components, PV systems and installation a prerequisite to sustainable and successful business.

33 0 1 000 000 2 000 000 3 000 000 4 000 000 5 000 000 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 S u rf ace d e cap teu rs i n st al lés an n u el lem en t ( m ²) AT BE BG CH CY CZ DE DK EE ES FI FR GR HU IE IT LT LU LV MT NL PL PT RO SE SI SK UK

34 0 50000 100000 150000 200000 250000 300000 350000 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 S u rf ace d e cap teu rs ( m ²) 0 35000 70000 105000 140000 175000 210000 245000 Co llect o r ar ea ( kW ) CESI SSC Collectif

35

• Market Increase :

– x 4 between 2000 and 2008

– x 2 between 2005 and 2008

• But …

– Decrease in France and Germany in 2009

• PV Market ?

• International Crisis ?

– In 2010 in France, it’s not good

36 0 0.5 1 1.5 2 2.5 3 3.5 4 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 Ma rc hé a nnue l (Mi ll ion de m ²) Collectif Individuel
