THE EXPERTISE OF MANY.
THE POWER OF ONE.
Eaton-Williams has been creating and sustaining artificially created indoor environments for over 70 years. These products can provide climate-controlled solutions for almost any environment, including data centers, hospitals, commercial offices and everything in between. And it’s all backed up with 24/7 service and maintenance.
For 75 years, the Governair brand has been the industry leader in custom industrial and commercial HVAC systems. Each system—from the simplest units to the most complex—is designed to meet the needs of each project. Governair product lines include custom air handlers, energy recovery units, low sound condensers and FANWALL TECHNOLOGY®.
Since 1993, the Huntair brand has specialized in air handler systems used in mission-critical applications. Solutions include: Huntair® custom air handlers and
cleanroom systems, data center and server cooling systems; CLEANPAK® custom cleanroom systems;
SERVICOR® modular cleanroom systems; FANWALL
TECHNOLOGY® fan array systems and CLEANSUITE®
modular ceiling diffuser system for operating rooms.
The Mammoth brand has provided custom packaged HVAC systems which have delivered high quality, energy efficient solutions for the entire life cycle of the facilities they serve since 1935. Mammoth product lines include chillers and chiller plants, custom packaged DX systems, replacement rooftop systems, vertical self-contained systems, standard and geothermal water source heat pumps, retrofit solutions and FANWALL TECHNOLOGY®.
Engineers have considered the Temtrol brand synonymous with quality, dependability and flexibility since 1955. Experts in the design and manufacturing of their custom HVAC products, Temtrol offers robust product lines that include custom air handlers, compact air handlers, knock-down technology, FANWALL TECHNOLOGY®,
OEM coils and replacement coils.
The Ventrol brand has been a leader in innovative custom air handling solutions for retrofit and new construction commercial applications since 1998. Ventrol’s products include custom air handlers, compact air handlers, knock-down construction, OEM and replacement cooling and heating coils, fan upgrades and retrofits and FANWALL TECHNOLOGY®.
Since 1952, the Venmar CES brand has delivered innovative energy recovery solutions for the commercial ventilation market. Venmar CES product lines include custom-built ventilation equipment, light commercial energy recovery ventilation, vertical unit ventilators, air-cooled or water-cooled condensing units, water/ ground source heat pumps, variable refrigerant control (VRC) and FANWALL TECHNOLOGY®.
Nortek Air Solutions
provides critical infrastructure for the world’s leading data centers through cooling solutions that meet the unique efficiency, redundancy and scalability requirements of data centers. The innovative technologies behind those solutions include our patented FANWALL TECHNOLOGY®, direct/indirect evaporative freecooling units, air and water- side economizers, advanced controls, and data center information man-agement (DCIM) software.
STANDARD IDEC UNIT
DESIGNED FOR DATA CENTERS
HIGHLIGHTS
Reduces humidity fluctuations and filtration requirements for white space
Available in rooftop, end-on and stacked configuration units
Rooftop and end-on units do not take up room in the white space
200, 300 and 400 kW standard unit sizes
Compact unit design reduces unit size and weight
200 and 300 kW units ship in one piece for simplified transport and installation
Makeup air unit option
COOL
3
™INDIRECT EVAPORATIVE
COOLING (IDEC)
The new Nortek Air Solutions Cool3 .IDEC unit is a proven
approach for highly efficient, cost effective data center cooling, offering these core benefits:
Highest water efficiency
Ultra-energy efficient unit with typical pPUE below 1.1
Maximum economizer utilization
Compact size
Flexible configuration
Available in three configurations to fit
most data center designs:
– End-on
– Rooftop
– Stacked
ENERGY
– Three operating modes optimize efficiency savings year-round
• Air Economizer: Winter– Heat exchanger device covers 100% of load; DEC and DX are off • Evaporative Cooling: Summer
– DEC turned on, providing indirect evaporative cooling, DX is off • Evaporative Cooling + DX: Extreme heat and humidity
– Mechanical cooling trim in extreme outdoor conditions
WATER
– significantly less water usage than other IDEC systems due to
• Less evaporation hours during a year
• Higher water usage efficiency at the same operating conditions
SUPERIOR SAVINGS
ON OPERATING COSTS
ANNUAL AVERAGE pPUE COMPARISON BY CITY
Location pPUE Water Consumption
(Gal x 103) for each unit
Operating Mode Hours
Economizer Evap Evap + DX
Frankfurt, GE 1.04 78 7622 891 247 London, UK 1.04 44 8070 638 52 Seattle, WA 1.05 64 7851 833 76 San Jose, CA 1.05 107 7072 1497 191 Beijing, CH 1.06 186 5572 1031 2157 Las Vegas, NV 1.06 553 4539 3378 843 Secaucus, NJ 1.06 183 6132 1134 1494 Dulles, DC 1.06 161 6093 756 1911 Shanghai, CH 1.07 124 5157 564 3039 Dallas, TX 1.09 408 3909 887 3964 Notes:
For 400kW IDEC unit running @ 75°F cold aisle supply and 100°F hot aisle return
The calculations were done for a 2MW data center (totally 6 units are required based on N+1 arrangement) The data are presented for normal data center operation (N+1 units running)
Used COC = 3 for water consumption
Nortek Air Solutions
offers both cus-tom and packaged air handlers optimized for the demanding environments of data centers. For more than 30 years our cus-tom and packaged air handling systems have set the bar for innovation, custom flexibility and quality in mission critical facilities. Just as no two data centers are the same, each air handling system is de-signed to meet specific efficiency, filtration, air flow capacity and unit configuration requirements.Our computer room air handlers
take advantage of air or water-side economizers or adiabatic cooling options to optimize efficiency. These units are available in larger air flow volumes of 50kw CFM and higher. For N+1 redundancy these units are available with our patented FANWALL TECHNOLOGY® which provides the evenairflow distribution required for data center and cleanroom environments. Other benefits include a compact footprint, redundancy, and easy serviceability.
AIR HANDLERS AND PACKAGED DX
PERIMETER, IN-ROW & CEILING
Cooling Solutions
Cooling Solutions
Chilled Water (CW) • • Direct Expansion (DX) • •
FANWALL TECHNOLOGY® • •
Air Side Economizer • • Water Side Economizer • • Direct Evaporative Cooling • • Indirect Evaporative Cooling • • IDEC with Free Cooling Modules • •
Chilled Water (CW) • • • Direct Expansion (DX) • •
Pumped Refrigerant •
FANWALL TECHNOLOGY® •
Air Side Economizer •
Water Side Economizer • • •
AIR HANDLING UNIT TYPE
Custom Perimeter Packaged Ceiling In-Row Fr ee C ool ing Fr ee C ool ing
NEXT GEN
COOLING SOLUTIONS
REAR DOOR HEAT EXCHANGERS & IT PODS
Nortek Air Solutions cooling
distribu-tion units
(CDU)provide close controlled water cooling for up to 24 rear door heat exchangers delivering 260kW of cooling in less than a 1m². It includes unique dew point monitoring and control. Our rear door heat exchangers provide close coupled heat removal directly from individual racks from 4 to 50kW. The range includes passive doors and active doors for every rack. These units are capable of up to 100% heat rejection and allow full access to the rear of the equipment.Condensing Units
Cooling Solutions
Chilled Water (CW) • • Direct Expansion (DX) • Pumped Refrigerant • FANWALL TECHNOLOGY® •Air Side Economizer • Water Side Economizer • • Direct Evaporative Cooling • Indirect Evaporative Cooling •
Rear Door
Heat Exchanger IT Pod
Fr
ee C
ool
W
E UN
DE
RS
TA
N
D
M
ISS
IO
N
-C
RI
TI
C
A
L D
AT
A
C
EN
TE
R A
PPL
IC
AT
IO
N
S
QUIET AND EFFICIENT
A new enterprise data center for RenaissanceTechnologies in New York used an Ultraline®
packaged system with FANWALL TECHNOLOGY® to meet both low
sound and high efficiency requirements.
WORLD’S FIRST
CARBON–NEUTRAL
DATA CENTER
Verne Global’s co-location data center in Keflavik, Iceland uses a unique fresh air free cooling system based around CTF model perimeter units to provide year-round precision control with no mechanical cooling and no chillers.
NEXT GEN
COOLING SOLUTIONS
Cooling Solutions
Modular Data CenterFr ee C ool ing Chilled Water (CW) • Direct Expansion (DX) • Pumped Refrigerant • FANWALL TECHNOLOGY® •
Air Side Economizer • Water Side Economizer • Direct Evaporative Cooling • Indirect Evaporative Cooling • IDEC with Free Cooling Modules •
MODULAR DATA CENTERS
These all-inclusive modules
incorporate a cooling system, server racks, lighting and power wiring. With process air cooling of up to 20kW per rack, this high density solution uses in-row and/or rear door cooling. This system provides the ultimate in scalability and compact configuration to deploy the module where and when you need it. Once these all-inclusive modules arrive on the jobsite, they can be rapidly deployed to meet fast track schedules.
CHILLERS, CHILLER PLANTS & CONDENSING UNITS
Our ability to meet special
requirements –
an impossibly small or awkward footprint, virtually no sound emitted from the unit, super high efficiency– plus our quality construction are hallmarks of our chiller systems. Your benefits can include lower installation costs, more leasable indoor space, centralized maintenance and service with ample access, and low total cost of ownership.Cooling Solutions
CHILLERSAir
Cooled WaterCooled Evaporative Condensing Modular Condensing Units
REAR DOOR HEAT
EXCHANGERS AT
HIGH DENSITY
COMPUTING CENTER
An Eaton-Williams system enabled Warwick University in Coventry, England, to expand with high density equipment while achieving zero thermal impact in a limited space in its Centre for Scientific Computing.
MODULAR DATA
CENTER COOLING
FOR COLOCATION
EXPANSION
Cooling modules help COLT quickly expand data center capacity as their colocation business grows. The data center was designed as modules of 500m² which can be constructed in less than four months, offering customers a highly power-efficient, turnkey solution.
INNOVATIVE
EVAPORATIVE
COOLING SYSTEM
USING OUTDOOR AIR
FANWALL® array, coils and
condensing units are part of an internet company’s “penthouse” cooling system, which uses an upper floor as a cooling plenum for cooling, filtering and controlling fresh air to cool the data center.
Free Cooling
Adiabatic Assisted Water Cooled • • • Adiabatic Assisted Air Cooled • • • •
Compressor Types
Frictionless Magnetic Bearing Centrifugal • • •
Screw • • • •
Scroll • • • •
Units Include:
• Evaporative condensing—50 to 1000+ tons • Chiller plants—20 to 2000+ tons• Air-cooled—20 to 400+ tons • Water-cooled—20 to 2000+ tons
FANWALL TECHNOLOGY
FANWALL TECHNOLOGY
®is a patented, integrated system of fans,motors, controls and cabinetry that provides the benefits of redundancy, quiet and vibration-free operation, optimized energy efficiency from design minimum to maximum flow, and low cost maintenance and service. FANWALL® systems
are only available from Nortek Air Solutions brands.
LEADING EDGE
FREE COOLING
Free Cooling
offers some of the biggest savings for data center cooling systems by using the natural evaporative effect of cool outdoor air instead of mechanical cooling. Nortek Air Solutions brands offer several types of free cooling alternatives including indirect evaporative cooling units (IDEC), air side economizers and water side economizers. Our free cooling solutions include advanced controls, humidification management and filtration options to take the best advantage of free cooling opportunities. Nortek Air Solutions has the application and manufacturing expertise to help you optimize your operating cost savings.LEADING EDGE
TECHNOLOGY & INNOVATION
RETROFIT & UPGRADE SOLUTIONS
Solutions for renovation, expansions and upgrades
are a specialty of Nortek Air Solutions brands. The compact unit footprints, custom configura-tions, knockdown options and modular construction possible with our systems can help reduce installation and replacement costs where access or space is limited. And that can result in more white space in a data center. In addition, the energy efficiency of our systems will help you reduce the operating costs compared to outdated, inefficient equipment.DATA CENTER INFRASTRUCTURE MANAGEMENT
sEnergy Thermal is an advanced energy-centric platform
that increases data center energy efficiency, asset utilization and uptime. sEnergy EMS offers the tools to integrate active monitoring of white space and rack-level temperature and airflow into the controls of mechanical cooling equipment, either using third-party building management systems or on a standalone basis, to optimize cooling operation.The sEnergy EMS platform features the unique ActiveCFD® module—with capabilities
for real-time and continuous monitoring of white space, rack level temperatures and airflow — for critical facilities in a platform that performs sophisticated what-if analysis for evaluating future changes to data center infrastructure.
HADRON COLLIDER PROJECT
France
VERNE GLOBAL DATA CENTER
Iceland
WARWICK UNIVERSITY’S CENTRE
FOR SCIENTIFIC COMPUTING (CSC)
United Kingdom
Process cooling of data server cabinets for world’s largest experiment
Free cooling, modular system developed in partnership with Colt for the world’s first zero carbon data center
High density cooling rear door heat exchangers
DATA CENTER COOLING
SUCCESSES
Photo courtesy of CERN
Photo © copyright 2013 Verne Global
Nortek Air Solutions
is the leading custom HVAC
manufacturer in North America with a combined total of more than
400 years of experience, 6 manufacturing facilities, and 150 sales
representative offices. Nortek Air Solutions, LLC is a subsidiary of
Nortek, Inc., a global diversified company with sales of $2.5 billion
whose many market-leading brands deliver broad capabilities and a
wide array of innovative, technology-driven products and solutions for
lifestyle improvement at home and at work.
N
OR
TE
K A
IR
S
OL
U
TI
O
N
S
Crit
ical Infr
astructur
e for t
he
W
orld
’s L
ead
ing Data
C
enters
The following are trademarks and registered brand names of Nortek Air Solutions: Cool3, Eaton-Williams, FANWALL, FANWALL TECHNOLOGY, Governair, Huntair,
Mammoth, Temtrol, Ultraline, Venmar CES, Ventrol, Webco.
© 2015 Nortek Air Solutions, LLC NAS-DC-SB-10A
July 2015
Nortek Air Solutions is a leader in innovative custom and engineered HVAC solutions for commercial, industrial and critical environments. Nortek Air Solutions, LLC is a subsidiary of Nortek, Inc., a global diversified company whose many market leading brands deliver broad capabili-ties and a wide array of innovative, technology-driven products and solutions for lifestyle improvements at home and at work.
