TECHNICAL CHARACTERISTICS

The FACI boilers for the production of warm water up to + 95°C they are built with a auto drive structure in a sheet of special steel of strong thickness of high mechanical resistance with a large combustion chamber, a hatch with crawl space for the manual loading of large chunks of combustible and for periodic cleaning of the brazier. The heat exchanger of the boiler is built with pipes like the SS boiler immersed in water.

The heat exchanger is subsequently connected to the openable smoke expansion chamber and can be inspected for periodic maintenance.

The base of the boiler is a refractory motar covered steel plate for high temperatures and for an excellent combustion. At the centre of the base is a perforated cast iron grate that allows the passage of primary air and gives oxygen to the material during the combustion.

All the FACI boilers are provided with a general electric panel for the control of the various functioning cycles. They are com-pletely caulked with anti radiant material and totally covered with painted steel oven panels. They can be predisposed for the application of the gas or gas-oil burner.

A particular attention is reserved to the ﬁ nish of the boilers with the veriﬁ cation of all the components and testing the mechanical functioning in the respect of the CEE directives.

There has been in the last years, a notable increase in the use of indu-strial and civil heating plants, working on scrap wood with auto feed, this increase is determined by the possibility to use the boilers with automated feeding systems and endowed with very reliable sensors allowing an automatic management of the plants with the constant control of the combustion values, and guaranteeing an operation in the respect of the laws.

(3)

BOILER ROOM AND PLANT SIZING

Another important aspect to be considered is the availability of space for the storage of the thermal plant combustible that has to be situated in the immediate proximities of the same plant.

The boiler room has to be spacious and well ventilated.

Besides the boiler, the thermal plant should be able to accommodate the inertial accumulator, the sanitary boiler, the digital panel and the whole hydraulic plant design.

It is a good norm to leave a free space of at least 60cm around the boiler; altogether leave a surface of around 8 - 10 square meters. For the plants of 35kW, the norm foresees that they are endowed with an independent access door from the outside.

For this type of plant it is necessary to deposit the thermal plant plans to the ofﬁ cers of the local ﬁ re brigade and to communicate to the institute for the safety of workers.

Particular attention must be devoted to the sizing of the plant, keeping in mind that boilers unlike

those to gas or gas-oil must, as far as possible, work continuously and without interruptions.

Accordingly, the overloading of the boiler must be avoided in that it could have negative

consequences on the same; in fact forced interruption of the combustion, owed to the brutal

arrest of the ﬂ ow of combustive air, produce greater smoke production inside the boiler and of

the ﬁ replace, in this way getting a lesser middle-seasonal output of the boiler with an useless

increase of the functional costs.

The FACI wood chip boilers use automatically loaded virgin

chipped wood of the dimension of a few centimetres.

The combustible used can be of material from different origin,

i.e. chopped pruning, wastes of chopped wood from sawmills,

biomasses deriving from the wood culture activities

(cut of the wood copse, thinning out, cuts of conversion, etc.).

The wood chip plants other than for the civil residences are

par-ticularly suited for the heating of buildings of medium to large

dimensions such as hotels, schools, condominiums, hospitals

and shopping centres.

(4)

1) HYDRO FIRE - VALVE.

2) AUTOMATIC ASH EXTRACTOR.

3) REFRACTORY BRICKS.

4) AUTOMATIC SWITCH ON.

OPTIONAL

CONE COLLECTOR WITH REAR SIDE HINGE

MOD. FSS from 7 to 100

7 10 13 16 20 30 40 50 60 70 100 70.000(81) 100.000(115) 130.000(151) 160.000(186) 200.000(232) 300.000(348) 400.000(465) 500.000(581) 600.000(598) 700.000(814) 1.000.000(1.163) 90.000(104) 128.000(148) 168.000(195) 204.000(237) 264.000(306) 360.000(418) 480.000(558) 600.000(698) 720.000(837) 840.000(977) 1.200.000(1.395) 400 400 400 400 400 400 400 400 400 400 1.000 2.350 2.450 2.610 2.810 3.550 4.150 3.950 4.250 4.250 4.450 4.450 700 830 830 830 1.000 1.000 1.250 1.250 1.500 1.500 1.500 1.250 1.250 1.250 1.250 1.500 1.500 1.500 1.500 2.100 2.100 2.100 930 1.100 1.250 1.460 1.400 2.000 1.780 2.100 2.190 2.390 2.390 1.350 1.450 1.550 1.900 1.850 2.450 2.330 2.650 2.890 3.090 3.090 200 220 220 220 250 250 250 250 450 450 500 1"½ 2" 2" 2"½ 2"½ 2"½ 3˝ 3˝ 4˝ 4˝ 4˝ 1"½ 2" 2" 2"½ 2"½ 2"½ 3˝ 3˝ 4˝ 4˝ 4˝ Mod. FSS Pot. resa Kcal/h(KW) Pot. bruciata Kcal/h(KW) H2 A L G P B K F1 F2 MISURE D’INGOMBRO

INCLUDED MA

TERIALS

1) BOILER COMPLETE WITH:

- SUPERIOR HATCH.

- INFERIOR HATCH.

- DIGITAL PANEL.

- SMOKE STACK.

- PANELS.

- BASE.

2) DOUBLE FALL BURNER.

3) CONE COLLECTOR WITH

STAR AGITATOR MOTOR AND

REDUCER.

The descriptions and illustrations of the FACI production intends you furnish to simple indicative title. The Firm reserves the right to bring possible changes for any demand of constructive and commercial character.

(5)

INCLUDED MA

TERIALS

3 4 5 29.000(34) 40.000(47) 50.000(58) 35.000(41) 48.000(56) 66.000(77) 250 250 250 2.000 2.000 2.000 630 630 630 1.350 1.350 1.350 550 680 930 950 1.080 1.350 200 200 200 1"½ 1"½ 1"½ 1"½ 1"½ 1"½ Mod.

FSS Kcal/h(KW)Pot. resa Pot. bruciataKcal/h(KW) H2 A L G P B K F1 F2

MISURE D’INGOMBRO

OPTIONAL

CONE COLLECTOR WITH RIGHT SIDE HINGE

MOD. FSS 3-4-5

The descriptions and illustrations of the FACI production intends you furnish to simple indicative title. The Firm reserves the right to bring possible changes for any demand of constructive and commercial character.

1) BOILER COMPLETE WITH:

- SUPERIOR HATCH.

- INFERIOR HATCH.

- DIGITAL PANEL.

- SMOKE STACK.

- PANELS.

- BASE.

- CONE COLLECTOR COMPLETE WITH:

AGITATOR, MOTOR AAND REDUCER.

2) CLEANING BRUSH FOR PIPE CLEANING.

3) 80cm COCHLEA COMPLETE WITH:

MOTOR AND REDUCER.

1) HYDRO - FIRE VALVE.

2) HEATING COIL SANITARY

WATER.
