A Complete Solution

(2)

Clipper was designed and developed around three fundamental principles: Simplicity, Speed and Design.

The aluminum profiles clip together easily, ensuring a seamless and efficient installation.

COMPANY HISTORY|

Clipper partitions are part of the Saint-Gobain Group, one of the worldwide leaders in the construction products industry.

They are a market leader in the demountable office partition sector in Europe, Asia and Africa.

The product offers a wide choice of profile finishes, single and double glazing, finished panels, doors and hardware. It has the flexibility to adapt to special requirements and offers a high acoustical performance in diverse environments.

(3)

Single Glazed with Frameless Swing Door Single Glazed with Frameless Sliding Door and Frameless Corner

RANGE A | SINGLE PANEL

Single Glazed with Frameless Swinging Door

Single Glazed with Frameless Sliding Door

Single Glazed with Framed Sliding Doors Single Glazed with Frameless

Corner

OVERVIEW |

(4)

RANGE i | DOUBLE PANEL

OVERVIEW | GLAZED

This stick built, double glazed demountable partition system was designed to provide maximum acoustic performance while still maintaining a slim profile. The use of different glass thicknesses allows for higher STC ratings. All door types are available. Range i can easily be transformed into a single glazed system by adding a cover plate. This creates long term flexibility as a second glazed panel can be added with ease.

Double Glazed with Frameless Sliding Doors Double Glazed with Framed Sliding Doors

(5)

Double Glazed with Framed Sliding Doors and Eko Panels with Clerestory

Back Painted White Glass and Eko Panels

OVERVIEW | COMBINATION

This system allows for solid and glazed panels to be incorporated together. This highly modular option opens up a wealth of configuration possibilities for full height walls that are economical and easily demountable. The materials can be glass and/or solid to allow for the passage of light and yet provide maximum acoustic performance.

Back Painted White Glass and Eko Panels Eko Panels with Clerestory and Double Glazed Front with Framed Sliding Door

RANGE i | DOUBLE PANEL

Double Glazed Panels with Blinds and Eko Panels

(6)

Framed Self Closing Swing Doors Framed Swing Door

DOOR | FRAMED, GLAZED

OVERVIEW |

Full height sliding and swing doors are available.

SLIDING DOORS | The sliding track is concealed along the top extrusion and contains self closers so the door eases to a closed position. Brush strips are installed to achieve the ultimate seal and acoustic privacy.

SPECIFICATIONS |

SWINGING DOORS |

• Swing doors available with either hinges or pivot hardware • Door stile size: 3-1/4”W x 1-9/16”D

• Maximum glass thickness: 3/8”

• Acoustic seals between door frame and glass infill • Drop seals available to maximize acoustic privacy

• Standard widths: 36” and 42”. Custom widths available upon request • Hardware includes locking and non-locking lever sets and ladder pulls

SLIDING DOORS |

• Door stile size: 3-1/4”W x 1-9/16”D • Maximum glass thickness: 3/8”

• Soft-close mechanism feature standard on sliding doors for quiet and effortless operation

• Acoustic seals between door frame and glass infill

• Standard widths 36” and 42”. Custom widths available upon request • Hardware includes locking and non-locking ladder pulls

• Brush strips available at doorway for ultimate seal and acoustic privacy

SWINGING DOORS | Hardware is available with or without self closers. Additional acoustical performance can be achieved with a plinth base that creates a seal from underneath the door frame to the floor. This feature is only available with hinged doors.

(7)

Frameless Sliding Door

DOOR | FRAMELESS, GLAZED

OVERVIEW |

Full height sliding, pivot and hinged doors are available in both Ranges A & I. SLIDING DOORS |

The sliding track is concealed along the top extrusion and contains self closers so the door eases to a closed position. Felt and brush fills are installed to achieve the ultimate seal.

SPECIFICATIONS |

SWINGING DOORS |

•Swing doors available with either hinges or pivot hardware •Maximum glass thickness: 1/2”

•Standard widths: 36” and 42”. Custom widths available upon request •Hardware includes locking and non-locking lever sets and ladder pulls

SLIDING DOORS |

•Maximum glass thickness: 1/2”

•Soft-close mechanism feature standard on sliding doors for quiet and effortless operation

•Standard widths 36” and 42”. Custom widths available upon request •Hardware includes locking and non-locking ladder pulls

•Brush strips available at doorway for added acoustic privacy SWINGING DOORS |

Are available with or without self closers.

(8)

Veneer Swinging Doors

DOOR | SOLID & VENEER

OVERVIEW |

Solid core veneer doors are available for both of Clipper Wall’s Ranges A & I, with pivot or hinged hardware. Custom finishes can be accommodated.

SPECIFICATIONS |

SWINGING DOORS |

•Drop seals available to maximize acoustic privacy

•Standard widths: 36” and 42”. Custom widths available upon request •Hardware includes locking and non-locking lever sets and ladder pulls

•Full height solid and veneer doors available in Range I only. SLIDING DOORS |

•Soft-close mechanism feature standard on sliding doors for quiet and effortless operation

•Standard widths 36” and 42”. Custom widths available upon request •Hardware includes locking and non-locking ladder pulls

•Brush strips available at doorway for ultimate seal and acoustic privacy

(9)

• Stick built, slim profile aluminum partition system with glass or solid panels

• Aluminum channel dimensions: Single Glazed 1-7/8”W x 1-7/8”H, double Glazed 3-1/4”W x 1-3/4”H

• Glass thickness range: ¼” to ½”, single or double glazed

• Clear tempered, low iron, laminated, and specialty glass available • Vertical connections between glass panels are provided by a 1/8” thick transparent adhesive gasket

• Recyclable, cost effective solid wall materials available in a variety of materials and finishes

• Stock or custom branded distraction / privacy film available to meet code requirements

• Sound transmission is affected by a variety of factors including door type, glazing thickness, floor and ceiling materials and construction methods.

• Clipper walls are available in many configurations depending on project requirements, providing STC ratings between 24 and 44.

PRODUCT FEATURES

STC RATINGS

Combination Of Materials:

Total width 3-1/4"

Solid Wall:

Total width 3-1/4" Solid Eko Panel/Oak Finish Insulation Double glazed with 5/16" and

3/8" thicknesses 3M adhesive transparent gasket 1/8" thick Total width 3-1/4"

Double Glazed:

3M adhesive transparent gasket 1/8" thick Bottom channel A, 1-7/8" tall Bottom channel A, 1-7/8" wide

Single Glazed:

Edge to edge clear tempered single glazing thickness 3/8" to 1/2" depending on the glass height

(10)

PRODUCT FINISHES

Solid Eko Panels:

Grey Pearl Ivory Pearl Beige

Woven Beige Woven Sienna

Veneer Eko Panels:

Brushed

Aluminum White Pearl

Medium

Wenge Light Wenge Wenge

Maple

Walnut Pear

DEMOUNTABLE WALL SOLUTIONS

USA DISTRIBUTOR OF CLIPPER WALL 225 Park Avenue South, 2nd Floor New York, NY 10003

P 212.647.6290 | 800.270.4204 info@clipper-dws.com

www.clipperwall.com

Advisory Note: Finishes shown here are for reference only.

Painted Metal Finishes:

Clear

Silver BrushedSilver Metallic Silver High Gloss

White Matte White

Anodized Metal Finishes:

Bronze Light

Bronze

Medium Bronze Dark Noir Statuary Medium Bronze Statuary Dark Bronze Matte Black

From date of installation, 10 years on Clipper product and 1 year on installation.

Standard lead time is 6 to 12 weeks dependent upon finish selection.
