IP Cameras & Edge Devices
5
Digital Recording & Network
Video Systems
17
Analogue Dome Systems
31
Analogue Cameras
39
Integrated Camera Assemblies
43
Matrix Systems
47
Monitors
51
Housings
53
Mountings
55
Lenses
57
Miscellaneous
59
Index
73
HDExpress Range
27
Professional Services
65
Terms of Trading
67
IP Cameras & Edge Devices
Vicon network cameras, available in both megapixel and standard resolution models, connect directly
to your IP network, and may be remotely viewed and controlled through video management software.
Many models are ONVIF compliant and offer a choice of transmission modes, including H.264, MPEG
-4 and M-JPEG compression, minimizing bandwidth and storage requirements.
Plus, using Vicon cameras in conjunction with ViconNet software offers a huge long-term financial
benefit not available elsewhere. There are no licensing fees when you use Vicon cameras as part of
your network! Only the combination of Vicon's quality IP cameras used within a ViconNet video
man-agement system can offer you that.
Use video from these cameras within a wide range of applications, including HD command and
con-trol centres using Vicon's virtual matrix display concon-troller, video management with integrated access
control or license plate recognition software, and with Vicon's video many video analytic detection
modules.
SurveyorHD Camera Dome Systems
5” compact dome system includes variable speed drive, housing, integral 720p or 1080p day/night camera/lens module with 18x optical zoom, lower dome and 24VAC power supply. Indoor lower domes are grey tint, outdoor are clear. Automatic or manual switching of day/night colour/mono on camera for low light conditions. With an on-board ViconNet TCP/IP video transmission mod-ule for direct connection to an IP network.
Unit will be supplied with most current version of ViconNet (presently V6) unless requested at time of order placement.
SN118C Indoor Surveyor HD, 720P, 18x, ONVIF, WDR, Privacy Masks, Schedules, in-ceiling housing.
SN118D Indoor Surveyor HD, 720P, 18x, ONVIF, WDR, Privacy Masks, Schedules, pendant housing,
SN118W Outdoor Surveyor HD, 720P, 18x, ONVIF, WDR, Privacy Masks, Schedules, weatherproof pendant housing.
SN118M Outdoor Surveyor HD, 720P, 18x, ONVIF, WDR, Privacy Masks, Schedules, maximum security housing.
SN118P Outdoor Surveyor HD, 720P, 18x, ONVIF, WDR, Privacy Masks, Schedules, pressurised pendant housing.
SN220C Indoor Surveyor HD, 1080P, 18x, ONVIF, WDR, Privacy Masks, Schedules, in-ceiling housing .
SN220D Indoor Surveyor HD, 1080P, 18x, ONVIF, WDR, Privacy Masks, Schedules, pendant housing.
SN220M Outdoor Surveyor HD, 1080P 18x, ONVIF, WDR, Privacy Masks, Schedules, maximum security housing.
SN220P Outdoor Surveyor HD, 1080P, 18x, ONVIF, WDR, Privacy Masks, Schedules, pressurised pendant housing.
-FM Integral media convertor for multi-mode fibre (add to dome price above) -IPC Integral media convertor for Ethernet over Coax (add to dome price above)
Cruiser PTZ Dome System
Economical PTZ Network Dome Camera with 4.3" diameter dome assembly. Includes high speed drive and integral 4CIF day/night camera module. Clear lower dome and black inner mask.
SN663V-P HD Cruiser Network PTZ Dome, 22x [3.9-85.8mm], 1080P, surface mount, vandal-proof, IP66, TDN, 8 Privacy Masks, Motion Detection, Triple Stream, H.264/MPEG4/ MPEG, ONVIF, PoE/24 VAC, MicroSD.
V660-HDB243 Wall-mount arm for indoor camera domes.
V660-HCM150 Corner Mount adapter for V660-HDB243 & V660-HDB242-VS8 - requires V600-HCM154 or V660-HCM155 depending on wall-mount used.
V660-HCM151 Pole-mount adapter for Impact Resistant domes. Used with V660-HVPWCB2.
V660-HCM154 Adapter Plate for use with V660-HCM150 or V660-HCM151.(compatible with V660-HDB242-VS8 only)
V660-HCM155 Adapter Plate for use with V660-HCM150 or V660-HCM151.(compatible with V660-HDB243 only)
V660-HDB242-VS8 Wall-Mount bracket for SN663V-P, S660V-P, S660-P, V661D & V66xV domes.
Mounting Accessories:
SN680D-WNIR 1080P Network PTZ camera. 30x Zoom. Integrated IR LED (150m range). Colour: 0.5 lux, B/W: 0.11 lux. WDR. 2 way audio, Power: 12VDC (36W). Image stabilization. Privacy Masks.
SVFT-C23-V5-C Indoor 5” compact dome system, in-ceiling housing, 23x zoom SVFT-P23-V5-C Indoor 5” compact dome system, pendant housing, 23x zoom SVFT-W23-V5-C Outdoor 5” compact dome system, pendant housing, 23x zoom
Surveyor VFT Day/Night Camera Dome Systems
5” compact dome system includes variable speed drive, housing, integral day/night cam-era/lens module with 23x or 35x optical zoom, lower dome and 24VAC power supply. In-door lower domes are grey tint, outIn-door are clear. Automatic or manual switching of day/ night colour/mono on camera for low light conditions. With an on-board ViconNet TCP/IP video transmission module for direct connection to an IP network.
SVFT-W36-VP Outdoor 5” compact dome system, pendant housing, 36x zoom
Unit will be supplied with most current version of ViconNet (presently V6) unless requested at time of order placement.
V660-HCS300 In-Ceiling Mount for SN660V-P
V660-HDA202 NPT-pipe adapter for Impact Resistant domes.
V660-HCM152 Corner/Pole Mount Adapter Plate; allows the V660-HPB024 Wall Mount arm to mount to V660-HCM150 or V660-HCM151.
V660-HDB242 Pendant Arm for SN680 & S660VW PTZ.
V660-HDB241 Pole for SN680 & S660VW PTZ.
Surveyor VFT Impact-Resistant Camera Dome Systems
Dome system with all the features and appearance of the Surveyor VFT but with an aluminium upper housing and polycarbonate lower dome to provide excep-tional protection against vandalism. Systems include variable speed drive, exterior housing, integral camera/lens, clear polycarbonate lower dome and 24VAC power supply. Standard Surveyor brackets are used for mounting. With an on-board ViconNet TCP/IP video transmission module for direct connection to an IP network.
SVFT-M23-V5-C DAY/NIGHT 23x camera/lens, impact-resistant dome system
SVFT-M36-VP DAY/NIGHT 36x camera/lens with wide dynamic range and image stabilisation, impact-resistant dome system
Unit will be supplied with most current version of ViconNet (presently V6) unless requested at time of order placement.
Surveyor VFT Pressurised Camera Dome Systems
Dome system with all the features of the Surveyor VFT but with a sealed and
pressurised housing that is environmentally controlled using a thermostatically
controlled heater & fan assembly. Systems include variable speed drive,
hous-ing, integral camera/lens, clear lower dome and 24VAC power supply. With an
on-board ViconNet TCP/IP video transmission module for direct connection to
an IP network.
SVFT-PRS23-V5-C DAY/NIGHT, 23x zoom, camera pressurised dome system with sealed, pendant housing. IP67
Complete dome systems:
Unit will be supplied with most current version of ViconNet (presently V6) unless requested at time of order placement.
SVFT-PRS36-VP DAY/NIGHT, 36x zoom, wide dynamic range, image stabilisation, camera pressurised dome system with sealed, pendant housing. IP67
SVFT-PRC2-IP IP Cable assembly for SVFT-PRS. 2 ft 4 twisted pairs outdoor weatherproof IP cable. Male and female connectors.
Surveyor Dome Mounting Options
SVFT-UWM Wall mount bracket for Surveyor VFT or Mini domes. V24CMB Corner mount bracket for use with SVFT-UWM.
SVFT-WM Short wall mount bracket for Surveyor VFT or Mini domes.
SVFT-UCM Ceiling bracket for Surveyor VFT or Mini domes.
SVFT-USN-PM Pole mounted swan-neck bracket for Surveyor VFT or Mini domes.
SVFT-UPM-1 Parapet mount for Surveyor VFT or Mini domes
SVFT-URM-1 Roof mount for Surveyor VFT or Mini domes.
IP Box Cameras
Powerful IP video source for a digital video management system, with ONVIF compliance. The box cameras are fully compatible with V6.5 ViconNet® and are capable of remote management and control from ViconNet workstations or Kollector digital recorders. 25fps of high quality VGA, 720p or 1080p video across the network using H.264 compression. Power over Ethernet (PoE) eliminates need for separate power supply.
V960-N VGA IP Camera. TDN. C/CS Mount. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V961-N 720P IP Camera. TDN. C/CS Mount. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V962-N 1080P IP Camera. TDN. C/CS Mount. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V923-N-IP 3MP IP Camera. TDN. C/CS Mount. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
Unit is compatible with ViconNet Version 6.5 or newer.
Hemispheric Fixed Domes
4 megapixel dome camera with a 180 degree fisheye lens that allows the camera to capture the entire environment. Software inside of the camera removes the distortion and streams panoramic video or virtual camera streams. The camera can be configured to electronically track objects.
V9360 H.264/MPEG-4/MJPEG, 4 Megapixel ONVIF Day/Night CMOS PoE/DC 12v Hemispheric 180°/360° Panoramic IP Camera Fisheye Lens, internal plastic enclosure.
V9360W H.264/MPEG-4/MJPEG, 4 Megapixel ONVIF Day/Night CMOS PoE/DC 12v Hemispheric 180°/360° Panoramic IP Camera Fisheye Lens, IP66 enclosure.
V9360-WM Wall-mount bracket for V9360/V9360W. V9360-FMK Flush-mount kit for internal V9360.
IP Bullet Cameras
Powerful IP video source for a digital video management system, with ONVIF compliance. The external fixed bullet cameras with integral IR illumination are fully compatible with V6.5 ViconNet® and are capable of remote management and control from ViconNet workstations or Kollector digital recorders. 25fps of high quality VGA, 720p or 1080p video across the network using H.264 compression. Power over Ethernet (PoE) eliminates need for separate power supply.
Unit is compatible with ViconNet Version 6.5 or newer.
V960B-IR312 IP fixed bullet camera, includes day/night camera with IR and 3-12mm varifocal autoiris lens, VGA resolution.
V961B-IR312M IP fixed bullet camera, includes day/night camera with IR and 3-12mm motorised varifocal P-iris lens, 720p resolution.
V962B-IR312M IP fixed bullet camera, includes day/night camera with IR and 3-12mm motorised varifocal P-iris lens, 1080p resolution.
V962B-IR922M IP fixed bullet camera, includes day/night camera with IR and 9-22mm motorised varifocal P-iris lens, 1080p resolution.
Mounting Accessory
V960D-KIT Flush mounting kit for recessed mounting of V960D series of indoor domes. V960D-N312M VGA Indoor IP Dome. TDN. 3.3-12mm motorize focus/zoom P-Iris. Dual
Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V960D-N922M VGA Indoor IP Dome. TDN. 9-22mm motorize focus/zoom P-Iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V961D-N312 720P Indoor IP Dome. TDN. 3.3-12mm auto-iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V961D-N312M 720P Indoor IP Dome. TDN. 3.3-12mm motorize focus/zoom P-Iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V961D-N922M 720P Indoor IP Dome. TDN. 9-22mm motorize focus/zoom P-Iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V962D-N312 1080P Indoor IP Dome. TDN. 3.3-12mm auto-iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V962D-N312M 1080P Indoor IP Dome. TDN. 3.3-12mm motorize focus/zoom P-Iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
V962D-N922M 1080P Indoor IP Dome. TDN. 9-22mm motorize focus/zoom P-Iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
IP Internal Fixed Domes
Powerful IP video source for a digital video management system, with ONVIF compliance. The internal fixed dome cameras are fully compatible with V6.5 Vi-conNet® and are capable of remote management and control from ViconNet workstations or Kollector digital recorders. 25fps of high quality VGA, 720p or 1080p video across the network using H.264 compression. Power over Ethernet (PoE) eliminates need for separate power supply.
V960D-N312 VGA Indoor IP Dome. TDN. 3.3-12mm auto-iris. Dual Stream. H.264/MPEG. ONVIF. 12VDC/24VAC/POE.
Roughneck Fixed Domes
Roughneck® V920D series of IP dome cameras, with ONVIF compliance. IP66 and IK10 rated enclosures designed for demanding security installations. Compatible with ViconNet V6.5. 25fps at D1, 720p or 1080p using H.264 compression. Power over Ethernet (PoE) supported if heater is not required. 12VDC/24VAC for external use.
Unit is compatible with ViconNet Version 6.5 or newer.
V920D-N39-IP IP SURFACE MOUNT INDOOR/OUTDOOR DOME CAMERA; SD (D1, 0.3 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night cam-era with DNR; 3-9 mm varifocal autoiris lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF
V920D-N39IR-IP IP SURFACE MOUNT INDOOR/OUTDOOR DOME CAMERA; SD (D1, 0.3 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris lens; PoE, 24 VAC or 12 VDC capa-bility; IR Illuminators; heater and clear dome. ONVIF
V921D-N39-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME CAMERA; 720p (1 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF
V921D-N39M-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME CAMERA; 720p (1 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF V921D-39D-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME
CAMERA; 720p (1 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with WDR; 3-9 mm varifocal autoiris lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF
V921D-N39MIR-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME CAMERA; 720p (1 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; IR Illuminators; heater and clear dome. ONVIF
V922D-N39-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME CAMERA; 1080p (2 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF.
V922D-N39M-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME CAMERA; 1080p (2 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF V922D-39MD-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME
CAMERA; 1080p (2 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with WDR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF V922D-N39MIR-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME
CAMERA; 1080p (2 megapixel) maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; IR Illuminators; heater and clear dome. ONVIF
Roughneck Cell Camera
V-CELL-HD 1080p HD Corner mount cell camera in a high security housing. 850nm IR LED. microphone & speaker.2.6mm lens. privacy module. Triple Stream. H.264/MPEG4/H.264. 24VAC/12VDC/PoE. ONVIF
V923D-N39M-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME CAMERA; 3 megapixel maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR and WDR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; heater and clear dome. ONVIF V923D-N39MIR-IP IP SURFACE MOUNT INDOOR/OUTDOOR VANDAL-RESISTANT DOME
CAMERA; 3 megapixel maximum resolution; includes 1/2.8-in. high-resolution day/night camera with DNR and WDR; 3-9 mm varifocal autoiris motorized (zoom/ focus) lens; PoE, 24 VAC or 12 VDC capability; IR Illuminators; heater and clear dome. ONVIF
Mounting Accessories:
V920-PH
Indoor/Outdoor pendant housing for use with V920 camera systems.
Permits use with SVFT brackets.
V920-ICD
In-Ceiling Mounting Kit: indoor dropped ceiling for V920 camera domes.
Steel construction
V920-ICH
In-Ceiling Mounting Kit: indoor hard ceiling for V920 camera domes. Steel
construction
Mini-Cube Network Camera
V905-CUBE H.264 2MP mini-cube camera. 3.6mm fixed focal length lens. Triple stream. Microphone & Speaker. PIR and LED light. Privacy Masking. ONVIF compliant. Micro SD. PoE. 1600x1200 pixels.
HD resolution network camera designed for indoor security installations. Incorporates integral IR illumination and motion detection.
ViconNet IP Video Encoders
Digital video servers. Collect video from local analogue inputs and send streamed video over the network to any Kollector Elite or ViconNet PC workstation. Include 24 VAC power supply.
Unit will be supplied with most current version of ViconNet (presently V6) unless requested at time of order placement.
VN-901T H.264 1-channel video server. Accepts 1 analogue video input (NTSC/PAL) for transmission over IP networks 25fps (PAL). PoE/12VDC/24VAC. ONVIF. Bi-directional Audio: G.711
H264-ENCDR-RK8 Rack Kit for use with H264-ENCDR server. Mounts up to 8 H264-ENCDR servers in a standard 19" rack. 5U space.
H264-ENCDR-RK2 Double-wide unit rack mount kit for H264-ENCDR . Mounts 2 H264-ENCDR units in a standard 19" rack.
H264-ENCDR-WM Wall mount bracket for H264-ENCDR .
H264-ENCDR H.264 4-channel video server. Accepts 4 analogue video inputs for transmission over IP networks. 100fps (PAL). 4x Audio inputs.
H264-16CH-ENCDR H.264 16-channel video server. Accepts 16 analogue video inputs for transmission over IP networks. 400fps (PAL). 8x Audio inputs. 8x Alarm Inputs.
Power Supplies
VC12PS-DC Converts 240 VAC to 12 VDC
VC24PS-240 Power adaptor, converts 240 VAC to 24 VAC @ 500 mA S24-PS 24VAC power supply. Converts 240VAC to 24VAC. 2.5 amps S12-PS 12VDC power supply. Converts 240VAC to 12VDC. 5 amps.
Uninterruptible Power Supplies
V5130-UPS-RM 7919-01 Single phase UPS, 1.25kVA, rack mount
Network Switches
NETSWITCH-8-1000 Network switch, 8-channel LAN connections, 10/100/1000 auto-sensing ports.
NETSWITCH-16-1000 Network switch, 16-channel LAN connections, 10/100/1000 auto-sensing ports.
NETSWITCH-8-POE Network switch, 8-channel LAN connections (up to 8 PoE @ 7.7W, 4 PoE @ 15.4W), 10/100/1000 auto-sensing ports.
NETSWITCH-24-POE Network switch, 24-channel LAN connections (up to 24 PoE ), 10/100/1000 auto-sensing ports.
Digital Recording & Network Video
Systems
ViconNet is an open-architecture, feature-rich video management software solution that delivers
com-plete access to live and recorded security video across your network. Supporting industry-standard
compression and transmission formats, including H.264, ViconNet displays and records clear,
high-resolution video while minimizing bandwidth and storage requirements. Megapixel and IP cameras
from Vicon and other major manufacturers can be viewed and controlled using ViconNet software,
which is managed using one of several intuitive interfaces: a standard web browser-based option, a
PC workstation drag-and-drop GUI, or a virtual matrix display controller that supports multiple
moni-tors in a command-and-control setting.
ViconNet’s video management functions can be easily integrated with those of other security
solu-tions, including access control, video analytics and license plate recognition. A unique, events
man-agement feature allows integrators and end-users to tie events from third-party software to
corsponding video within ViconNet, and to program macros that perform any number of actions in
re-sponse, such as initiating recording, adjusting the recording speed, changing a video display, sending
an email, playing an audio file and displaying a public or private URL. In addition, ViconNet stores the
event along with the related video for future retrieval and forensic reporting. By combining the power
of ViconNet with other software, you can create a robust, integrated security system that is easily
managed over a single network, often from a single interface, and is tailored to your specific needs.
Make installation and maintenance easier with pre-loaded NVRs, DVRs and workstations.
ViconNet is PC-based software that can run on any off-the-shelf hardware that meets our
specifica-tions. However, we offer the convenience of NVRs, hybrid DVRs and workstations that are preloaded
with ViconNet and ready to connect to your network. Models are available with a wide range of
proc-essing speeds, hard drives, and internal and external storage options.
ViconNet Video Management Software
VN-NVR-SW ViconNet V6 NVR Software. Single site license. Full ViconNet functionality. Requires separate third party camera licences.
VN-SW-ZONE-24 ViconNet V6 NVR Software for use with up to 24 IP cameras. Single site license. Full ViconNet functionality. Requires separate third party camera licences.
VN-SW-ZONE-16 ViconNet V6 NVR Software for use with up to 16 IP cameras. Single site license. Full ViconNet functionality. Requires separate third party camera licences.
VN-SW-ZONE-9 ViconNet V6 NVR Software for use with up to 9 IP cameras. Single site license. Full ViconNet functionality. Requires separate third party camera licences. VN-CAM-LIC Connection Licence for non-ViconNet cameras to ViconNet V6 system. One
camera licence.
VN-WS-SW VICONNET WORKSTATION SOFTWARE; for use with ViconNet Digital Recorders, Video Encoders and ViconNet IP Cameras. Full ViconNet functionality except recording. Single PC license.
VN-NUC-SW ViconNet Nucleus Software for system management purposes. Requires a dedicated PC. Single server license.
VN-WEB+MOBILE-SW VICONNET WEB SERVICE AND MOBILE APPLICATION SOFTWARE; software package for PC being used as a standalone Web Service or with mobile application. Single server license.
VN-HIRSCH-INTV5 VICONNET-HIRSCH INTEGRATION SOFTWARE; to use ViconNet version 5.6 on a Hirsch Velocity access control workstation.
VN-LENEL-INTV6 VICONNET-LENEL INTEGRATION SOFTWARE; to use ViconNet version 6 on a Lenel Onguard access control workstation.
VN-SWH-INTV6 VICONNET-SOFTWARE HOUSE INTEGRATION SOFTWARE; to use Vicon-Net version 6 on a Software House C-CURE 9000 access control workstation VMDC-SW Virtual Matrix Display Controller Software (installation on 3rd party server)
Single Site Licence.
VN-NVR-SWV6-UPGRADE
UPGRADE FOR NVR RECORDING SOFTWARE; single server licence
VN-WS-SWV6-UPGRADE
UPGRADE FOR WORKSTATION SOFTWARE; single server licence
VN-DVR-SWV6-UPGRADE
UPGRADE FOR DVR RECORDING SOFTWARE; single server licence
VMDC-SW-UPGRADE UPGRADE FOR VMDC WORKSTATION SOFTWARE; single server licence
VN-WEB/MOB-UPGRADE
UPGRADE FOR WEB/MOBILE SOFTWARE; single server licence
VN-NUC-SWV6-UPGRADE
UPGRADE FOR NUCLEUS; single server licence
CD-ViconNet Nucleus & Operator Control
A ViconNet Nucleus PC is recommended for use with multiple Kollector units. ViconNet Workstations are avail-able for use at operator control and review/archiving positions.
VN-NUC ViconNet Nucleus. Fully configured rack-mount PC running VN-WS-SW Workstation software. Recommended for use with multiple Kollector Force and Strike digital recorders. Includes Event Management for XML based integration with 3rd party systems.
VN-WS-PC ViconNet Workstation. Includes fully configured Tower PC and VN-WS-SW Work-station software V6. No recording facility. For use with Kollector Force and Strike digital recorders and all ViconNet server products. Includes LCD monitor. VN-WS-PC-R ViconNet Workstation. Includes fully configured Rack-mounted PC and
VN-WS-SW Workstation software V6. No recording facility. For use with Kollector Force and Strike digital recorders and all ViconNet server products.
VN-WEB-SYSTEMR Fully configured Rack-mounted Web Server for ViconNet systems
V1500X-SCCS System Console Control Station. Used to control Pilot control systems and ViconNet digital video management systems, including Virtual Matrix Display Controller (VMDC).
VMC-V1411J Desk-top keypad (V1411J-DVC) with RS232-RS422 converter to enable use with ViconNet Workstation. USB-RS232 converter available separately for use with Kollector Strike.
ViconNet Network Video Recorders
Network Video Recorders come with preloaded ViconNet version 6 NVR software to view, record and configure ViconNet IP devices and recorders and are external RAID ready.
VN-NVR ViconNet Network Video Recorder. Includes fully configured Tower PC and VN-NVR-SW NVR and Workstation software V6. For use with all ViconNet server products. With 2TB internal storage. Includes LCD monitor.
VN-NVR-ZONE-9R ViconNet ZONE 9-channel Network Video Recorder. Rack-mount PC. 1TB Stor-age.
VN-NVR-ZONE-16R ViconNet ZONE 16-channel Network Video Recorder. Rack-mount PC. 1TB Storage.
VN-NVR-ZONE-24R ViconNet ZONE 24-channel Network Video Recorder. Rack-mount PC. 2TB Storage.
VN-NVR-R ViconNet Network Video Recorder. Includes fully configured Rack-mounted PC and VN-NVR-SW NVR and Workstation software V6. For use with Kollector Force and Strike digital recorders and all ViconNet server products.
VN-NVR-ZONE-9 ViconNet ZONE 9-channel Network Video Recorder. Desktop PC. 1TB Storage. VN-NVR-ZONE-16 ViconNet ZONE 16-channel Network Video Recorder. Desktop PC. 1TB
Storage.
VN-NVR-ZONE-24 ViconNet ZONE 24-channel Network Video Recorder. Desktop PC. 2TB Storage.
Vicon's free mobile app allows connection to a ViconNet system from an iPhone, iPad or Android device. For Apple devices, the app is available at the Apple App store; go to Google play for Android devices.
ViconNet Network Video Recorder Shadow with Internal RAID
Network Video Recorders come with preloaded ViconNet version 6 NVR software to view, record and configure ViconNet IP devices and recorders. With integral RAID5 storage. Now using 4TB drives for extended storage.
VN-NVR-8TBV6-R5 ViconNet Network Video Recorder with preloaded ViconNet version 6 software: view, record and configure ViconNet IP devices and recorders; internal RAID with 8TB RAID5 usable storage Rack-mount. 711mm deep chassis.
VN-NVR-16TBV6-R5 ViconNet Network Video Recorder with preloaded ViconNet version 6 software: view, record and configure ViconNet IP devices and recorders; internal RAID with 16TB RAID5 usable storage Rack-mount. 711mm deep chassis.
VN-NVR-20TBV6-R5 ViconNet Network Video Recorder with preloaded ViconNet version 6 software: view, record and configure ViconNet IP devices and recorders; internal RAID with 20TB RAID5 usable storage Rack-mount. 711mm deep chassis.
VN-NVR-40TBV6-R5 ViconNet Network Video Recorder with preloaded ViconNet version 6 software: view, record and configure ViconNet IP devices and recorders; internal RAID with 40TB RAID5 usable storage Rack-mount. 711mm deep chassis.
VN-NVR-56TBV6-R5 ViconNet Network Video Recorder with preloaded ViconNet version 6 software: view, record and configure ViconNet IP devices and recorders; internal RAID with 56TB RAID5 usable storage Rack-mount. 711mm deep chassis.
The Shadow is also available with RAID6 configuration for the same price. Note that the usable storage will be reduced.
ViconNet Virtual Matrix Control
ViconNet V6 Virtual Matrix Display Controller offers 2, 4 or 6 monitor outputs. Up to a maximum of 150 streams (frame rate and video quality dependent)
VMDC-6R ViconNet Virtual Matrix Display Controller with 6 display outputs. Single license. Rack mount.
VMDC-4R ViconNet Virtual Matrix Display Controller with 4 display outputs. Single license. Rack mount.
VMDC-2R ViconNet Virtual Matrix Display Controller with 2 display outputs. Single license. Rack mount.
VMDC-6 ViconNet Virtual Matrix Display Controller with 6 display outputs. Single license. Tower.
VMDC-4 ViconNet Virtual Matrix Display Controller with 4 display outputs. Single license. Tower.
VMDC-2 ViconNet Virtual Matrix Display Controller with 2 display outputs. Single license. Desk-top
Kollector Strike Digital Recorders
Superior performance hybrid digital video recording system with full network capabilities. 1U chassis. Maximum 864 x 586 pixel resolution. Optimised MPEG-4 compression, H.264 or M-JPEG. 4 audio channels, 4 alarm inputs. Automatic operation programmed through macros and executed by Scheduler. 100fps, 200fps and 400fps models (PAL). Single storage drive supported (4TB maximum - contact Sales Office for 2TB-4TB versions). Complete with 16-channel viewing software and ViconNet version 6 master control software. Can access, control, configure and record from any Kollector unit on a network and up to 8 additional IP channels. Use of UPS is strongly recommended.
100 fps models.
KS1B1-1000V6 Kollector Strike hybrid DVR; preloaded ViconNet Version 6, 16-channel networked digital video recorder, 100fps (50fps using H.264), internal OS HD, 1TB data HD and DVD drive, 4-channel audio, up to 8 additional IP channels at 25fps each. NTSC/ EIA and PAL/CCIR
KS1-SANV6 Kollector Strike hybrid DVR; for use with external SAN-RAID only; preloaded Vicon-Net Version 6, 16 analogue channels at 100 fps (ViconVicon-Net compression) or 50 fps (H.264 compression); no internal HD, NTSC/EIA and PAL/CCIR
200 fps models.
KS2B1-1000V6 Kollector Strike hybrid DVR; preloaded ViconNet Version 6, 16-channel networked digital video recorder, 200fps (100fps using H.264), internal OS HD, 1TB data HD and DVD drive, 4-channel audio, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR
KS2-SANV6 Kollector Strike hybrid DVR; for use with external SAN-RAID only; preloaded Vicon-Net Version 6, 16 analogue channels at 200 fps (ViconVicon-Net compression) or 100 fps (H.264 compression); no internal HD, NTSC/EIA and PAL/CCIR
400 fps models.
KS3B1-1000V6 Kollector Strike hybrid DVR; preloaded ViconNet Version 6, 16-channel networked digital video recorder, 400fps (200fps using H.264), internal OS HD, 1TB data HD and DVD drive, 4-channel audio, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR
KS3-SANV6 Kollector Strike hybrid DVR; for use with external SAN-RAID only; preloaded Vicon-Net Version 6, 16 analogue channels at 400 fps (ViconVicon-Net compression) or 200 fps (H.264 compression); no internal HD, NTSC/EIA and PAL/CCIR
V1500X-SCCS System Console Control Station. Used to control both Pilot control systems and ViconNet digital video management systems, including Virtual Matrix Display Controller (VMDC).
VN-DECODER-2 ViconNet 2-Channel Digital Video Decoder, for use with Virtual Matrix Controller
Kollector Force Digital Recorders
Superior performance hybrid digital video recording system with full network capabilities. 3U chassis. Maximum 864 x 586 pixel resolution. Optimised MPEG-4 compression, H.264 or M-JPEG. 16x4 analogue matrix. 16 audio channels, 16 alarm inputs and 8 relay alarm outputs. Full video looping and dual monitor outputs. Automatic operation programmed through macros and executed by Scheduler. 200fps and 400fps models (PAL). Up to 3 additional internal hard disks for up to 10TB storage. Complete with 16-channel viewing software and ViconNet V6 master control software. Can access, control, con-figure and record from any Kollector unit on a network and up to 8 additional IP channels. Use of UPS is strongly recommended.
200 fps model.
KF2-1000V6 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16-channel networked digital video recorder, 200fps (100fps using H.264), internal OS HD, 1TB data HD and DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
400 fps model.
KF3-1000V6 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16-channel networked digital video recorder, 400fps (200fps using H.264), internal OS HD, 1TB data HD and DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
Additional Hard Drive Capacity: Additional Hard Drive Capacity:
HDD-2000S Ultra high capacity 2000GB (2Tb) Enterprise Hardened SATA hard drive . Additional hard drive pre-installed and pre-configured in a Kollector Strike. HDD-3000S Ultra high capacity 3000GB (3Tb) Enterprise Hardened SATA hard drive
. Additional hard drive pre-installed and pre-configured in a Kollector Strike. HDD-4000S Ultra high capacity 4000GB (4Tb) Enterprise Hardened SATA hard drive
. Additional hard drive pre-installed and pre-configured in a Kollector Strike. Important note:
The models listed above incorporate the latest version 6 ViconNet software. For expansion of existing version 5, 4, 3 or 2 ViconNet systems please contact the Sales Office.
Important note:
The models listed above incorporate the latest version 6 ViconNet software. For expansion of existing version 5, 4, 3 or 2 ViconNet systems please contact the Sales Office.
HDD-2000S Ultra high capacity 2000GB (2Tb) Enterprise Hardened SATA hard drive . Additional hard drive pre-installed and pre-configured in a Kollector Strike. HDD-3000S Ultra high capacity 3000GB (3Tb) Enterprise Hardened SATA hard drive
. Additional hard drive pre-installed and pre-configured in a Kollector Strike. HDD-4000S Ultra high capacity 4000GB (4Tb) Enterprise Hardened SATA hard drive
Kollector Force Digital Recorders with Internal RAID
Superior performance hybrid digital video recording system with full network capabilities. 4U chassis. Maximum 864 x 586 pixel resolution. Optimised MPEG-4 compression, M-JPEG & H.264. 16x4 analogue matrix. 16 audio channels, 16 alarm inputs and 8 relay alarm outputs. Full video looping and dual monitor outputs. Automatic operation programmed through macros and executed by Scheduler. 200fps and 400fps models (PAL). Internal RAID stor-age - 1 to 3TB versions available. Complete with 16-channel viewing soft-ware and ViconNet V6 master control softsoft-ware. Can access, control, config-ure and record from any Kollector unit on a network and up to 8 additional IP channels. Use of a UPS is strongly recommended.
200 fps models.
KF2-1000V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel networked digital video recorder, 200fps (100fps using H.264), cold-swappable removable OS HD, 1.0TB usable RAID5 data, hot-cold-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
KF2-2000V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel networked digital video recorder, 200fps (100fps using H.264), cold-swappable removable OS HD, 2.0TB usable RAID5 data, hot-cold-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
KF2-3000V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel net-worked digital video recorder, 200fps (100fps using H.264), cold-swappable removable OS HD, 3.0TB usable RAID5 data, hot-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
400 fps models.
KF3-1500V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel networked digital video recorder, 400fps (200fps using H.264), cold-swappable removable OS HD, 1.5TB usable RAID5 data, hot-cold-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
KF4-1500V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel networked digital video recorder, 400fps (using H.264), cold-swappable re-movable OS HD, 1.5TB usable RAID5 data, hot-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
KF3-3000V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel networked digital video recorder, 400fps (200fps using H.264), cold-swappable removable OS HD, 3.0TB usable RAID5 data, hot-cold-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
KF4-3000V6-R5 Kollector Force hybrid DVR; preloaded ViconNet Version 6, 16 channel networked digital video recorder, 400fps (using H.264), cold-swappable removable OS HD, 3.0TB usable RAID5 data, hot-swappable HDD, no DVD drive, 16-channel audio, 16x4 analogue video matrix, up to 8 additional IP channels at 25fps each. NTSC/EIA and PAL/CCIR.
RAID storage systems
External mass storage for extended recording times. iSCSI-to-SATA RAID subsystem, single controller only, two-six host channel Gigabit Ethernet ports (model dependant), including 512MB DDR RAM, Redundant PSUs and fans.
KOL-iRAID12-20000 20TB RAID5 Array for use with ViconNet. 2U 12-bay rack mount. 12 x 2TB drives for hotspare (x1) and storage/parity (x11).
KOL-iRAID16-28000 28TB RAID5 Array for use with ViconNet. 3U 16-bay rack mount. 16 x 2TB drives for hotspare (x1) and storage/parity (x15).
KOL-iRAID24-66000 66TB RAID5 Array for use with ViconNet. 4U 24-bay rack mount. 24 x 3TB drives for hotspare (x1) and storage/parity (x23).
For our full range of external RAID sizes, including SAN & NAS solutions, please contact the Sales Office.
Network Switches
NETSWITCH-8-1000 Network switch, 8-channel LAN connections, 10/100/1000 auto-sensing ports.
NETSWITCH-16-1000 Network switch, 16-channel LAN connections, 10/100/1000 auto-sensing ports.
NETSWITCH-8-POE Network switch, 8-channel LAN connections (up to 8 PoE @ 7.7W, 4 PoE @ 15.4W), 10/100/1000 auto-sensing ports.
NETSWITCH-24-POE Network switch, 24-channel LAN connections (up to 24 PoE ), 10/100/1000 auto-sensing ports.
Uninterruptible Power Supplies
VDR4-DVC Desk-top intelligent keypad with built-in 3-axis joystick. Provides complete switching and control functions for single and multiple VDR-4xx or VDR-7xx re-corders.
VDR400-MAC Optional matrix interlinking/audio input cable for VDR-4xx or VDR-7xx recorders.
Non-ViconNet Digital Video Recorders
H.264 Digital recorder and multiplexer, quadraplex operation, single audio channel, alarm inputs, motion detection. Real-time recording with frame rates adjustable from 1 to 400 fps. Utilises hard drives optimised for digital video recording. Onboard storage up to 3Tb. Network matrix function. Mouse and keypad controllable.
VDR-704C-500 H.264 Digital Recorder, 4 channel, DVD drive and 500GB hard drive with VGA output. Supplied with network viewing software. Includes remote controller. PAL/ NTSC.
VDR-708C-500 H.264 Digital Recorder, 8 channel, DVD drive and 500GB hard drive with VGA output. Supplied with network viewing software. Includes remote controller. PAL/ NTSC.
VDR-708C-1000 H.264 Digital Recorder, 8 channel, DVD drive and 1TB hard drive with VGA output. Supplied with network viewing software. Includes remote controller. PAL/ NTSC.
VDR-716C-500 H.264 Digital Recorder, 16 channel, DVD drive and 500GB hard drive with VGA output. Supplied with network viewing software. Includes remote controller. PAL/ NTSC.
VDR-716C-1000 H.264 Digital Recorder, 16 channel, DVD drive and 1TB hard drive with VGA output. Supplied with network viewing software. Includes remote controller. PAL/ NTSC.
VDR-716C-2000 H.264 Digital Recorder, 16 channel, DVD drive and 2TB hard drive with VGA output. Supplied with network viewing software. Includes remote controller. PAL/ NTSC.
HDExpress Range
HDExpress Network Video Recording System
Embedded NVR. Plug-and-play operation. Supplied without hard drives. Optimised for use with V992 camera range. Web interface and mobile phone applications (iPhone, iPad & Android).
HDXPRES-4 4-channel embedded NVR, 1U case, HDMI/VGA. 120FPS Recording and Display @1080P. Embedded POE ports for 4 cameras. (Max: 40W). Storage (2 internal drive bays): Max: 8TB internal storage + external eSATA
HDXPRES-4-2TB 4-channel embedded NVR, 1U case, HDMI/VGA. 120FPS Recording and Display @1080P. Embedded POE ports for 4 cameras. (Max: 40W). Storage 2TB
HDXPRES-8 8-channel embedded NVR, 1U case, HDMI/VGA. 240FPS Recording and Display @1080P. Embedded POE ports for 8 cameras. (Max: 72W). Storage (2 internal drive bays): Max: 8TB internal storage + external eSATA
HDXPRES-8-4TB 8-channel embedded NVR, 1U case, HDMI/VGA. 240FPS Recording and Display @1080P. Embedded POE ports for 8 cameras. (Max: 72W). Storage 4TB HDXPRES-4-4TB 4-channel embedded NVR, 1U case, HDMI/VGA. 120FPS Recording and Display
@1080P. Embedded POE ports for 4 cameras. (Max: 40W). Storage 4TB HDXPRES-4-6TB 4-channel embedded NVR, 1U case, HDMI/VGA. 120FPS Recording and Display
@1080P. Embedded POE ports for 4 cameras. (Max: 40W). Storage 6TB
HDXPRES-8-6TB 8-channel embedded NVR, 1U case, HDMI/VGA. 240FPS Recording and Display @1080P. Embedded POE ports for 8 cameras. (Max: 72W). Storage 6TB
HDXPRES-16 16-channel embedded NVR, 2U case, HDMI/VGA. 480FPS Recording and Display @1080P. Embedded POE ports for 8 cameras. (Max: 72W Internal for 8 cameras and 60W for 8 port external hub included). Storage (5 internal drive bays): Max: 20TB internal storage + external eSATA
HDXPRES-16-8TB 16-channel embedded NVR, 2U case, HDMI/VGA. 480FPS Recording and Display @1080P. Embedded POE ports for 8 cameras. (Max: 72W Internal for 8 cameras and 60W for 8 port external hub included). Storage 8TB
HDXPRES-16-15TB 16-channel embedded NVR, 2U case, HDMI/VGA. 480FPS Recording and Display @1080P. Embedded POE ports for 8 cameras. (Max: 72W Internal for 8 cameras and 60W for 8 port external hub included). Storage 15 TB
HD-EXPRES-HUB8 8 CH (IEEE802.3af) hub, 15.4W Max per port, 60W total. 2 x 1000 BASE-T Port (Up-Link to NVR)
Fixed Camera Assemblies
V992-N525 1080P Mini-camera with integrated 5x lens. H.264/MJPEG IP day/night camera, 5 -25mm megapixel motorized focus/zoom lens, PoE.
V992-WM Wall-mount bracket for V992-N525.
V992D-N4 1080P Indoor Mini-Dome. 4mm fixed lens. H.264/MJPEG IP day/night camera. PoE. Vandal Resistant. ONVIF
V992D-N2 1080P Indoor Mini-Dome. 2mm fixed lens. H.264/MJPEG IP day/night camera. PoE. Vandal Resistant. ONVIF
Note: V920, V960 and Cruiser series network cameras can also be used with an HDExpress NVR. V992B-IR 1080P Mini bullet camera. 4mm fixed lens. H.264/MJPEG IP day/night camera,
Integrated IR LEDs (distance 10m), PoE. IP66 rated
V992D-IR4 1080P Indoor Mini-Dome. 4mm fixed lens. H.264/MJPEG IP day/night camera. Integrated IR LEDs (distance 8m) PoE. Vandal Resistant. ONVIF
Analogue Domes
Just because you’re using an IP-based video management system doesn’t mean that you need to
rely exclusively on network cameras. Vicon offers analogue cameras for every application, and the
analogue versions of our high-performance Surveyor VFT camera domes, offering up to 35X optical
zoom, continue to be used in some the world’s tightest security settings. Use our cameras with the
video management system of your choice, or, integrate them within your ViconNet system through the
use of a Kollector hybrid DVR or one of our encoder products. Either way, the video from these
cam-eras will be fully compatible with the transmission and compression formats used by your ViconNet
system.
Surveyor VFT 23x Zoom Day/Night Camera Dome Systems
5” compact dome system includes variable speed drive, housing, integral day/night camera/ lens module with 23x optical zoom, lower dome and 24VAC power supply. Indoor lower domes are grey tint, outdoor are clear. Automatic or manual switching of day/night colour/ mono on camera for low light conditions. (Domes can be ordered with optional on-board video transmission module for Twisted Pair - see opposite).
SVFT-C23-C INDOOR 5” compact dome system, IN-CEILING housing
SVFT-P23-C INDOOR 5” compact dome system, PENDANT housing
SVFT-W23-C OUTDOOR 5” compact dome system, WEATHERPROOF PENDANT housing
Surveyor VFT 36x Zoom Day/Night Camera Dome Systems
5” compact dome system includes variable speed drive, housing, integral day/night camera/ lens module with wide dynamic range and image stabilisation and 36x optical zoom, lower dome and 24VAC power supply. Clear lower domes. Automatic or manual switching of day/night colour/mono on camera for low light conditions. (Domes can be ordered with optional on-board video transmission module for Twisted Pair - see opposite).
SVFT-W36-P OUTDOOR 5” compact dome system, WEATHERPROOF PENDANT housing
Cruiser PTZ Dome System
Economical PTZ Network Dome Camera with 4.5" diameter dome assembly.
S660-P Cruiser PTZ Dome, 22x [3.9-85.8mm], 580TVL, surface/flush mount, TDN, 8 Privacy Masks, Motion Detection, 24 VAC, MicroSD, PAL.
S660V-P Cruiser PTZ Dome, 22x [3.9-85.8mm], 580TVL, surface mount, vandal-proof, IP66, TDN, 8 Privacy Masks, Motion Detection, 24 VAC, MicroSD, PAL
S660VW-P Cruiser PTZ Dome, 22x [3.9-85.8mm], 580TVL, surface mount, vandal-proof, IP66, TDN, 8 Privacy Masks, Motion Detection, 24 VAC, MicroSD, PAL., Includes heater/ sunshield.
Surveyor VFT Impact-Resistant Camera Dome Systems
Dome system with all the features and appearance of the Surveyor VFT but with an aluminium upper housing and polycarbonate lower dome to provide exceptional protection against vandalism. Systems include variable speed drive, exterior housing, integral camera/lens, clear polycarbonate lower dome and 24VAC power supply. Standard Surveyor brackets are used for mounting. (Domes can be ordered with optional on-board video transmission module for Twisted Pair - see below).
SVFT-M23C DAY/NIGHT 23x camera/lens, impact-resistant dome system
SVFT-M36P DAY/NIGHT 36x camera/lens with wide dynamic range and image stabilisation, impact-resistant dome system
Optional on-board video transmission modules.
T Option TWISTED PAIR OPTION for Surveyor VFT Internal, External and Impact-Resistant domes. Enables video transmission down twisted pair wire. Add "-T" to model number of dome system.
Note: ViconNet TCP/IP video transmission modules for direct connection to an IP network are listed in the IP
Cameras and Edge Devices section.
Surveyor VFT Pressurised Camera Dome Systems
Dome system with all the features of the Surveyor VFT but with a sealed and
pressurised housing that is environmentally controlled using a thermostatically
controlled heater & fan assembly. Systems include variable speed drive,
housing, integral camera/lens, clear lower dome and 24VAC power supply.
(Domes can be ordered with optional on-board video transmission module for
Twisted Pair - see below).
SVFT-PRS23C DAY/NIGHT, 23x zoom, camera pressurised dome system with sealed, pendant housing. IP67
SVFT-PRS36P DAY/NIGHT, 36x zoom, wide dynamic range, image stabilisation, camera pressurised dome system with sealed, pendant housing. IP67
Complete dome systems:
Accessories:
SVFT-PR-WMA WALL MOUNT for pressurised dome
SVFT-PR-P PIPE ADAPTER for mounting pressurised dome to 1½ inch diameter pipe SVFT-PRC12 Pre-wired coaxial cable assembly for use with the Surveyor VFT Pressurised
dome, 12ft
SVFT-PRC12T Pre-wired twisted pair cable assembly for use with the Surveyor VFT Pressurised dome, 12ft
Optional on-board video transmission modules:
Note: ViconNet TCP/IP video transmission modules for direct connection to an IP network are listed in the IP
Cameras and Edge Devices section.
T Option TWISTED PAIR OPTION for Surveyor VFT Internal, External and Impact-Resistant domes. Enables video transmission down twisted pair wire. Add "-T" to model number of dome system.
Dome Controllers
V1411X-DVC Keypad with built-in joystick for control and programming of Surveyor domes.
V1411J-DVC Keypad as above but with 3-axis joystick with twist lens zoom feature.
V1411A Video switching system to control up to 8 Surveyor domes. 2 monitor outputs. Must be used with V1410X-DVC, V1411X-DVC or V1411J-DVC keypad. Coax or twisted pair telemetry or a combination of both.
Surveyor Dome Mounting Options
SVFT-UWM Wall mount bracket for Surveyor VFT or Mini domes. V24CMB Corner mount bracket for use with SVFT-UWM.
SVFT-UCM Ceiling bracket for Surveyor VFT or Mini domes.
SVFT-USN-PM Pole mounted swan-neck bracket for Surveyor VFT or Mini domes.
SVFT-UPM-1 Parapet mount for Surveyor VFT or Mini domes
SVFT-URM-1 Roof mount for Surveyor VFT or Mini domes.
SVFT-IC-KT Surveyor VFT dome in-ceiling mounting rail kit for extra support
Surveyor VFT Indoor Lower Dome Options
Acrylic dome, 5.88" diameter.
Compact Vandal Resistant Fixed Camera Domes
Vandal Resistant IP66 fixed camera dome systems. Includes a high-resolution colour/ monochrome camera, clear lower dome with black inner mask. Surface or In-ceiling mount. Internal or External Use. 3 Year Warranty.
V661D-312N-P Vandal Resistant (IK10) Dome; Day/night with DNR, 600TVL resolution, 2.8-12mm varifocal auto-iris lens, 0.1/0.04lux, IP66, Surface/In-ceiling mount, 12VDC/24VAC PAL.
V661D-312D-P Vandal Resistant (IK10) Dome, WDR Day/night with DNR, 600TVL resolution, 2.8-12mm varifocal auto-iris lens, 0.14/0.03lux, IP66, Surface / In-ceiling mount, 12VDC/24VAC PAL.
V661D-312IR Vandal Resistant (IK10) Dome, WDR Day/night with DNR, 600TVL resolution, 2.8-12mm varifocal auto-iris lens, 0.14/0.03lux, IP66, Surface / In-ceiling mount, 12VDC/24VAC PAL.
Compact Heavy Duty Vandal Resistant Domes
V661V-312N-P Heavy Duty Vandal fixed camera dome. 600 TVL, 0.14/0.03 lux, day/night camera, auto-iris 2.8-12mm varifocal lens, IK10 aluminium housing, IP66.
V661V-922N-P-1 Heavy Duty Vandal fixed camera dome with 600 TVL, 0.14/0.03 lux, day/night camera, auto-iris 9-22mm varifocal lens, IK10 aluminium housing, IP66.
V662V-312D-P Heavy Duty Vandal fixed camera dome. Sony® Super HAD™II PS 960H CCD. 650 TVL, WDR, Day/Night, 0.4/0.04 lux, auto-iris 2.8-12mm varifocal lens, IK10 IP66 Aluminium housing.
V662V-922D-P-1 Heavy Duty Vandal fixed camera dome. Sony® Super HAD™II PS 960H CCD. 650 TVL, WDR, Day/Night, 0.4/0.04 lux, auto-iris 9-22mm varifocal lens, IK10 IP66 Aluminium housing.
V661V-312IR Heavy Duty Vandal fixed camera dome. 600 TVL, Day/Night, WDR, 0.14 / 0.03 lux, auto-iris 2.8-12mm varifocal lens, 30 LEDs, IK10 IP66 Aluminium housing.
Heavy Duty IP66 Vandal Resistant camera dome systems. External or internal use. Includes a choice of high-resolution colour, wide dynamic range colour or day/night colour/mono camera. Complete with auto-iris 2.8-12mm or 9-22mm varifocal lens, clear lower dome with black inner mask. 3 Year Warranty.
Note: V661D Series domes require a VC24PS-240 power supply (ordered separately).
Fixed Dome Mounting Options
V660-HDB243 Wall-Mount bracket for SN660V-P, S660V-P, S660-P, V661D & V66xV domes.
V660-HVPWCB2 Wall/Ceiling mount kit for Impact Resistant domes.
V660-HCM150 Corner-mount adapter for Impact Resistant domes. Used with V660-HVPWCB2.
V660-HCM151 Pole-mount adapter for Impact Resistant domes. Used with V660-HVPWCB2. V660-HCM154 Adapter Plate for use with V660-HCM150 or V660-HCM151.(compatible with
V660-HDB242-VS8 only)
V660-HCM155 Adapter Plate for use with V660-HCM150 or V660-HCM151.(compatible with V660-HDB243 only)
V660-HDA202 NPT-pipe adapter for Impact Resistant domes.
V660-HT202VF Heater Accessory for V660 series outdoor vandal proof domes. Extends unit's low range temperature to -30°C.
V660-HCS300 In-Ceiling Mount for SN660V-P
V660-HPB024 Wall-mount bracket with power box for S660VW-P
Power Supplies
VC12PS-DC-1A Converts 240 VAC to 12 VDC @ 1A
VC24PS-240 Power adaptor, converts 240 VAC to 24 VAC @ 500 mA S24-PS 24VAC power supply. Converts 240VAC to 24VAC. 2.5 amps V660-HDB242 Pendant Arm for SN680 & S660VW PTZ.
Analogue Cameras
Just because you’re using an IP-based video management system doesn’t mean that you need to
rely exclusively on network cameras. Use our cameras with the video management system of your
choice, or, integrate them within your ViconNet system through the use of a Kollector hybrid DVR or
one of our encoder products. Either way, the video from these cameras will be fully compatible with
the transmission and compression formats used by your chosen system.
Super-High Resolution Day/Night Camera
V661-N-P Day/night camera, 1/3" format with DNR, 600TVL resolution, 12VDC/24VAC, PAL. 3 year warranty. Requires VC24PS-240 or VC12PS-DC Power Supply.
V661-N-PM Day/night camera, 1/3" format with DNR, 600TVL resolution, 230VAC, PAL. 3 year warranty
A durable fixed camera that provides superior resolution of 600 TV lines with ICR (Infrared Cut Removable Filter) and digital wide dynamic range capabilities. Lightweight and compact, it can be mounted in a variety of lo-cations where space is at a premium.
V662-D-P-1 WDR camera, Sony® Super HAD™II PS 960H CCD, day/night with DNR, 650TVL resolution, 12VDC/24VAC, PAL. 3 year warranty. Requires VC24PS-240 or VC12PS-DC Power Supply.
V662-D-1-PM WDR camera, Sony® Super HAD™II PS 960H CCD, day/night with DNR, 650TVL resolution, 230 VAC, PAL. 3 year warranty
Camera Mounting Bracket
VWA-2CCD/S Indoor wall/ceiling silver plastic bracket for fixed cameras, 3 Kg max load
IR LED Day/Night Bullet Camera package
V660B-488IR-P Outdoor bullet camera, 1/4-inch Sony Super HAD II CCD. 600 TVL. Day/Night D-WDR camera, 4-88mm varifocal motorized focus/zoom autoiris lens, 12VDC / 24VAC, PAL. 78 LED's, 3 year warranty. Requires VC24PS-240 or VC12PS-DC Power Supply.
WDR Day/Night Camera
A durable fixed camera offering superior resolution of 650 TV lines, to pro-vide high-quality images. The extended wide dynamic range is
ideal for difficult lighting situations. The camera is designed for easy instal-lation and setup.
Power Supplies
VC24PS-240 Converts 240 VAC to 24 VAC, 0.5 amps. VC12PS-DC Converts 240 VAC to 12 VDC. 0.5 amps
S24-PS 24VAC power supply. Converts 240VAC to 24VAC. 2.5 amps.
Roughneck Cell Camera
V-CELL-P Corner mount cell camera in a high security housing, 24VAC, integrated LED Infra red illuminator, 850nm, microphone & speaker and day/night camera with 2.5mm lens and privacy module. 24VAC/12VDC. Requires VC24PS-240 or VC12PS-DC Power Supply. V-CELL-REM Remote Control for V-CELL-P
Integrated Camera Assemblies
Commander Integrated Fully Functional Camera Assembly
Day/night high speed ruggedised PTZ camera with continuous rotation. Sealed to IP67 and designed to be installed in harsh and challenging environments or areas where the camera unit may be liable to experience physical abuse. Includes PSU, Tower Mount and 10m cable.
COM-DN36-W Pan & Tilt. 36:1 Optical Zoom WDR, 530TVL colour/mono camera, with wiper. Vandal resistant IP67. White.
COM-DN36-B Pan & Tilt. 36:1 Optical Zoom WDR, 530TVL colour/mono camera, with wiper. Vandal resistant IP67. Black.
COM-IR18-W Pan & Tilt. 18:1 Optical Zoom WDR, 530TVL colour/mono camera, with wiper. 100m Range IR LED. Vandal resistant IP67. White.
COM-IR18-B Pan & Tilt. 18:1 Optical Zoom WDR, 530TVL colour/mono camera, with wiper. 100m Range IR LED. Vandal resistant IP67. Black.
COM-IR28-W Pan & Tilt. 28:1 Optical Zoom WDR, 530TVL colour/mono camera, with wiper. 100m Range IR LED. Vandal resistant IP67. White.
COM-IR28-B Pan & Tilt. 28:1 Optical Zoom WDR, 530TVL colour/mono camera, with wiper. 100m Range IR LED. Vandal resistant IP67. Black.
Commander Integrated Thermal Imaging Camera Assembly
COM-TI36DA-40-B Dual head 25Hz 40° field of view, 550m/350m range thermal optical rugged PTZ camera. 320x240 thermal plus 36x zoom video. Black
COM-TI36DA-16-B Dual head 25Hz 16° field of view, 1000m range thermal optical rugged PTZ cam-era. 320x240 thermal plus 36x zoom video. Black
COM-TI36H-12-B Dual head 25Hz 12° field of view, 1500m range thermal optical rugged PTZ cam-era. 640x480 thermal plus 36x zoom video. Black
COM-TI36H-35-B Dual head 25Hz 35° field of view, 650m range thermal optical rugged PTZ cam-era. 640x480 thermal plus 36x zoom video. Black
Day/night high speed ruggedised PTZ camera with continuous rotation. Sealed to IP67 and de-signed to be installed in harsh and challenging environments or areas where the camera unit may be liable to experience physical abuse. Includes PSU, Tower Mount and 10m cable.
COM-WM-W Wall-mount bracket for Commander fully functional assembly. White finish. COM-WM-B Wall-mount bracket for Commander fully functional assembly. Black finish. COM-SN-W Swan-neck bracket for Commander fully functional assembly. White finish. COM-SN-B Swan-neck bracket for Commander fully functional assembly. Black finish. COM-PM-W Pendant Pole bracket for Commander fully functional assembly. White finish. COM-PM-B Pendant Pole bracket for Commander fully functional assembly. Black finish. COM-CM-W Corner-mount bracket for Commander fully functional assembly. White finish. COM-CM-B Corner-mount bracket for Commander fully functional assembly. Black finish. COM-SS-W Sunshield for Commander fully functional assembly. White finish.
COM-SS-B Sunshield for Commander fully functional assembly. Black finish. Accessories:
Matrix Systems
The most trusted name in analogue switching technology has enhanced its product offerings with the
Pilot series of matrix switchers designed for system scalability and ease of expansion. From
conven-ience stores to casinos, there is a Pilot system to suit every application and allow for virtually
unlim-ited growth potential. Although overall capacity has been expanded, system programming has never
been easier with an intuitive, internal graphic configurator.
As a complete solutions provider, Vicon has everything needed for integrated video switching and
control systems. Variable speed joystick keypads such as the V1410 and V1411 series allow for total
system control from a compact, desktop console. The V1500X-SCCS System Controller with
touch-sensitive LCD display controls camera call-up and pan-tilt-zoom functions for any Pilot model, as well
as any ViconNet device including the Virtual Matrix Controller (VMC).
External receivers and interface cards are available and data signals are distributed by Vicon’s
V1400X-IDL intelligent data-distribution line or V422-VI for Vicoax control. Hard-wired alarm inputs
are also easily connected via the alarm interface module, model V1300X-IA.
Nova V1411 Systems
Range System Model Max Inputs Max Outputs Alarm Inputs Max No. Keypads RS-232 Interface Pre-pac available V1411A 16 4 16 4 no n/aPilot Select V1566 512 64 512 16 yes yes
Pilot Ultra V1599 8192 512 8192 512 yes no
V1411A Maximum 8 cameras and 2 monitors. Use with programmable keypad.
Video switching system for up to 16 inputs by 4 outputs. Must be used with V1410X-DVC, V1411X-DVC or V1411J-DVC keypad. Coax or twisted pair telemetry or a combination of both.
Matrix Switching Systems
Pilot Select V1566 Matrix Switching System
Up to 512 camera inputs by 64 monitor outputs
The Pilot Select™ V1566 Digital Control and Matrix Switching System is a full-featured, digital control unit and matrix switcher for systems with up to 512 cameras and 64 monitors (using 4 card cages). The V1566 consists of one, two or four Pilot66/99 card cages that are populated with internal CPU, time/date/titler, switcher cards, or other control cards depending upon con-figuration. The system is designed for rack mounting and multiple units can be mounted in a large rack.
To order V1566 systems use a model number made up as follows: PS-[no of cameras]X[no of monitors] PS-32X16 32 camera inputs, 16 monitor outputs.
PS-64X16 64 camera inputs, 16 monitor outputs. PS-96X16 96 camera inputs, 16 monitor outputs. PS-128X16 128 camera inputs, 16 monitor outputs. PS-160X16 160 camera inputs, 16 monitor outputs. PS-192X16 192 camera inputs, 16 monitor outputs. PS-224X16 224 camera inputs, 16 monitor outputs. PS-256X16 256 camera inputs, 16 monitor outputs. PS-32X32 32 camera inputs, 32 monitor outputs PS-64X32 64 camera inputs, 32 monitor outputs PS-96X32 96 camera inputs, 32 monitor outputs PS-128X32 128 camera inputs, 32 monitor outputs PS-160X32 160 camera inputs, 32 monitor outputs
PS-192X32 192 camera inputs, 32 monitor outputs PS-224X32 224 camera inputs, 32 monitor outputs PS-256X32 256 camera inputs, 32 monitor outputs
For prepac systems with more than 256 cameras inputs or more than 32 monitor outputs please call the Sales Office.
Pilot Ultra V1599 Network Switching & Control System
Capable of addressing over 8000 cameras and 500 monitors and keypad stations. Operation over a LAN/WAN environment.
Please call the Sales Office for a quotation
Keypad Controllers
V1411X-DVC Desk-top intelligent keypad with built-in joystick. Provides complete switching and control functions for variable and fixed speed camera stations.
V1411J-DVC Desk-top intelligent keypad with built-in 3-axis joystick with twist lens zoom feature. Provides complete switching and control functions for variable and fixed speed camera stations.
V1500X-SCCS Desk-top multifunction controller; works with ViconNet, including VMC, and Pilot matrix systems; touch-sensitive LCD, 3-function joystick and jog/shuttle wheel.
Other Equipment
V1400X-IDL RS-422 data distributor enables the creation of a star configuration of up to 10 keypads or receivers from the CPU. Cascadable.
V422-VI Translator. Converts RS-422 telemetry to coaxial control, 16 channels. 2
12 Function AC Receivers
V1306R Compact, 12 function receiver, no pre-set, 230 VAC input, 24 VAC output. V1306R-MVI Mains voltage interface to enable the use of V1306R receiver with 230 VAC
Monitors
High resolution cameras and high-performance software lose their effectiveness if security personnel
are hindered by a fuzzy on-screen image. Vicon offers a wide selection of LCD monitors that deliver
clear, crisp video. Our selection includes several wide-screen, high definition models that display the
detail captured by megapixel cameras and allow for multi-camera displays with exceptional size and
detail provided for each video feed. Combine multiple monitors with Vicon’s virtual matrix display
con-troller to create sophisticated command centres.
LCD & LED Monitors
VM-719E 18.5” TFT LCD screen, 1366 x768, input sources: analogue RGB, HDMI, PC stereo in. 100-240 VAC 50/60 Hz, PAL or NTSC
VM-6215LED 21.5” TFT LCD screen, 1366 x1024, input sources: analogue RGB, HDMI, PC stereo in/out 16:9 ratio. 100-240 VAC 50/60 Hz, PAL or NTSC
VM-722P 21.5” TFT LCD screen, 1680 x1050 (WSXGA), input sources: 2x composite BNC, analogue RGB, HDMI, PC stereo, 16:10 ratio. 100-240 VAC 50/60 Hz, PAL or NTSC.
VM-632LED 32" LED Monitor; resolution up to 1920 x 1080 (depending on scan rate); HDTV; stereo; accepts NTSC/PAL, HDMI/DVI Inputs.
VM-742LED 42" LED Monitor; resolution up to 1920 x 1080 (depending on scan rate); HDTV; stereo; accepts NTSC/PAL.
Vicon offers a wide selection of LCD & LED monitors that deliver clear, crisp video. Our selection includes several wide-screen, high definition models that display the detail captured by megapixel cameras and allow for multi-camera displays with exceptional size and detail provided for each video feed.
