It seems like my shop is always in a
state of change. I find myself rearranging tools and carts fairly often to make room to complete the assembly of a large project. Or I’m sifting through drawers and cabinets trying to find a piece of hardware — sound familiar? If that’s the case, then there are a number of projects to check out in this issue.IN THE SHOP. If keeping track of hardware and other small items leaves you at wits’ end, have a look at the shop organizer on page 26. It’s a handy project for storing a wide range of hardware or other hard-to-corral items all in one spot. And since it’s mobile, you can roll it right where you need it instead of carry-ing handfuls of hardware. The options for storcarry-ing and organizcarry-ing range from simple plastic hardware bins and metal trays to larger shop-built drawers and adjustable cubbies for hard-to-store rods, dowels, and other long items.
OUTSIDE THE SHOP.Speaking of moving things around, one big challenge I used to have is working outside the shop. I’d gather up what I needed and then try to figure out how to get everything to where I was working. The tool tote on page 42 is my solution. The versatile storage options keep things organized even when each new outing requires a different set of tools and hardware. Besides being practical, it features some interesting woodworking techniques. The end result is a great-looking tote you won’t mind carrying to the next job.
IN YOUR HOME.We didn’t just focus on things for the shop. Check out the medicine cabinet that begins on page 18. A medicine cabinet is a super way to organize all your bathroom odds and ends, making them easy to find. A project like this needs to match your décor, so we started with a basic cabinet. After that, you can choose from three different design details to match your home.
FOR YOUR GARDEN. Finally, gardeners have organizing and storage needs, too. On page 34 you’ll find a dream bench for any gardener. It not only keeps tools close at hand, but the design keeps the mess down, as well. Storage bins under a pair of flip-up tops hold potting mix, making it easy to quickly pot a plant in a container without making a mess all over your benchtop.
