EDITORIAL
MAN/ COMPUTER' INTERFACE
A few days ago, a friend of mine received the following response from a magazine publisher (names have been changed) :
Thank you for the subscription to ABC Magazine that you entered through XYZ Clearing House.
To serve you in the most efficient way possible, we are converting our fulfillment service to one that employs the most modern automated computer available today.
Because of this, delivery of your first issue may be de-layed. You will of course receive the full term of the subscription you ordered.
In other words, "to serve you in the most efficient way pos-sible . . . your first issue may be delayed" and, instead of starting your subscription when you wanted it, impliedly it may start late!
Is this a typical case? Is it necessary that the changeover from noncomputer methods to computer methods lead to dis-tortion of customers' wants and delay in fulfilling them?
Recently I was talking with an able member of Project MAC at Mass. Inst. of Technology about the playing of games of skill with a computer. Among other things we dis-cussed to some extent methods for translating a list of some 50 principles of strategy in chess into the problem-oriented computer language LISP. Examples of the principles are:
Bring all your pieces to bear.
Accumulate small advantages - in position, mobility, de-velopment, etc.
Prefer lasting advantages to temporary ones.
In a tournament, if you see a good move, look five min-utes for a better one.
Place your pieces if possible where they cannot be dis-turbed or removed.
Develop first; attack afterwards.
Attack only if based on a better position and a heavier force.
Aim to effectively isolate. the king. Beware of bait.
(If any reader would like a copy of the full strategy list, please designate 1 on the Readers' Service card.)
We agreed that it would take an enormous amount of effort to· convert these principles, which many clever human chess
COMPUTERS and AUTOMATION for May, 1966
players can understand and apply, into principles that a com-puter could understand and apply. In fact, we agreed that a good human chess-player would continue to beat a good computer program for playing chess, for a number of years -just because it would be much easier for him than the com-puter to apply strategic principles of this kind.
Is this a typical case? Is it necessary that it be very difficult to translate such concepts as these principles of strategy in chess, into computer language?
Both these cases are examples of the intellectual interface between men and computers, which as machines for handling information have very different equipment. Both these cases are examples of the hard work of changing operations and operation principles from a language and behavior which a human being understands into a language and behavior which a computer understands. For example, how do you tell a computer what is "bait"?
Is it necessary that the intellectual interface between men and computers be so hard to pass through?
Looked at historically, the intellectual barrier between men and computers is being broken more and more and more. In the long run, there is no doubt that the interface will be as easy to pass through as is the interface between man locomo-tion and motorized locomolocomo-tion.
But in the short run there is a vast demand for study and work. One thing that would certainly help would be a dic-tionary of several thousand ideas expressed in words and propositions, each associated with the guidelines for convert-ing that idea into problem-oriented computer programmconvert-ing languages. Of course, ALGOL, COBOL, and some similar languages have begun in this area. But it would be good to have something like a Roget's Thesaurus adapted for transla-tion of human ideas into computer language.
