UNITOR VACUUM cleaners

(1)

UNITOR VACUUM

cleaners

(2)

(3)

The smallest unit in the Unitor range, the VCD15 is purpose-made for use on cruise and passenger vessels. The design is small and powerful, capable of handling hours of intensive use each day. The unit is easy to use and quiet in operation. An additional safety feature is the red power cord that is clearly visible on most types of carpet to help prevent tripping accidents.

Features and benefits

• 5 large wheels for better stability

• Low noise emission - less passenger irritation

• The power cord is stored on the handle making transport and storage easier and safer

• Highly visible power cord helps prevent tripping accidents

• Covers large work area thanks to 10m power cord

• Ergonomic, user friendly design gives less user fatigue

• Easy to operate with large and easy accessible start / stop button

• Dual-filter system gives excellent filtration

• Safe for walls and furniture, thanks to soft plastic top

Unitor VCD15

a compact, heavy-duty dry vacuum cleaner for accommodation areas

Technical data

PROPERTY VALUE

Power (Pmax) 1200 W Power (PIEC) 1000 W Air flow rate 3200 L/min

Vacuum 160 mbar

Noise level 62 dB (A) Container volume 15 L

Dimensions 400x400x400 L x W x H (mm)

Weight 6 kg

Accessories for the VCD15 Product No.

Filter element 431 665224

Filter bags (10 pack) 431 665216

Extension tube 431 665232

Deck and carpet nozzle 431 665240

Suction hose 3m 431 665257

Ordering information

The VCD15 Dry Vacuum Cleaner - 220V/50-60Hz 432 665380 (available from week 10 2004) - 110V/60 Hz 432 665404

The unit is supplied with:

Suction hose 2,5m Curved tube Extension tube

Deck and carpet nozzle Crevice nozzle

Filter element Filter bag

10 m cabel with plug Accommodation &

workshop kit 431 665265

Nozzle kit 431 665273

Small brush 431 665323

(4)

The Unitor VCWD18 is designed for the everyday cleaning tasks performed on board. The ability to handle wet and dry applications makes the unit ideal for both small spills as well as cleanup in the workshop during machining operations.

• Central carrying handle ensures easy transport of the unit

• Suited for extraction of non-toxic dust and nonflammable liquids – the unit has a hard plastic container that is capable of holding a variety of particles

• Permanent bellows filter for wet and dry cleaning – makes cleaning easy as there is no need to remove the filter if you switch form dry to wet cleaning

• Option of a paper filter bag for dry cleaning only - when used as a dry cleaner the paper bag can be used for easy removal of dirt from the container

• Safety float valve protects the motor from the liquid when the container is full

• Powerful 1200W turbine with separate motor cooling – the motor is protected from overheating when the unit is clogged with particles

• Blow function – the machine can be used to blow dirt from inaccessible spaces

• Storage of accessories on the machine – makes transport and storage of the unit simple and safe

• Vario floor nozzle – effective deck cleaning with 4 wheel nozzle

Unitor VCWD18

a general purpose vacuum cleaner for accommodation areas and work shops

Technical data

PROPERTY VALUE

Vacuum 160 mbar

Noise level 68 dB(A) Container volume 18 L

Weight 5,6 kg

Accessories for the VCD18 Product No.

Filter element 431 665398 Filter bags (5 pack) 431 665406 Suction hose 1,8m 431 665448 Curved tube 431 665455 Extension tube 431 681874 Deck and carpet nozzle 431 681872 Accommodation &

Water vacuum kit 431 665281

Ordering information Product. No.

The VCWD18 wet & dry

vacuum cleaner 220V/50-60Hz 432 681890 The unit is supplied with:

Suction hose 1,8m Curved tube Extension tube

(5)

The Unitor VCWD27 represents a new standard in powerful, compact and portable vacuum cleaners. The unit is designed to be an all-round machine for the toughest cleaning tasks while being compact and portable. This makes it ideal for use on- board.

• Low noise level – the unit can be used in environments where noise has to be held at a minimum

• Rubber enclosed power cord – the power cord stays flexible even in very low temperatures, and is resistant to ware and tare

• Ergonomic design – the unit can be used for longer periods of time due to lower user fatigue

• Large on/of switch – the unit can be started or stopped without taking the gloves off

• Large wheels – the unit is stable even on rough deck

• Hook for the power cord – the cord stays secured to the unit while in transit or in storage

Unitor VCWD27

a medium sized but very powerful all-round cleaner

Technical data

PROPERTY VALUE

Vacuum 230 mbar

Noise level 59 dB (A) Container volume 27 L

Weight 10 kg

Accessories for the VCWD27 Product No.

Filter element 431 681908

Filter bags (5 pack) 431 681916

Suction hose 3m 431 665257

(with curved tube)

Extension tube 431 665232

Deck and carpet nozzle 431 665240 Accommodation &

Water vacuum kit 431 665281

Ordering information Product No.

The VCWD27 wet & dry

vacuum cleaner -220V/50-60Hz 432 681924 The unit is supplied with:

Suction hose 3m Curved tube Extension tube

(6)

The Unitor VCWD70 heavy duty vacuum cleaner is the most advanced unit in the Unitor range. The machine is equipped with a stainless steel container and a built-in pump for easier liquid removal from e.g. small tanks, double bottoms or engine rooms. With the available accessories it can also remove liquid from the deck areas.

• Built-in submerged pump – can operate without removing or lifting the container

• Heavy duty stainless steel container – capable of removing a wide range of liquids without damaging the container

• Two large wheels at the back – ensure great stability during transport and storage

• Brakes on the front wheels – the units remains stable when in use or in storage

• Heavy duty steel frame protects the unit from damage during transport and use

• Power supply socket for connection of electric tools – when the pump is not in use the socket can be used to power a drill or other power tool

• Cable holder ensures safe transport and storage

• Tube holder – a handy place to store the tubes when not in use

• Soft start – limits the starting power to save fuses and reduce wear and tear on the motor

• Dirt basket – when vacuuming dirty liquids the basket makes sure that the particles stay inside the unit when the liquid is pumped out

Unitor VCWD70

a high volume, wet & dry cleaner for heavy-duty liquid removal and deck cleaning

Technical data

PROPERTY VALUE

Power (Pmax) 1500+640 W Power (PIEC) 1200+640 W Air flow rate 3600 L/min

Vacuum 230 mbar

Noise level 59 dB(A) Container volume 70 L

Weight 32 kg

Accessories for the VCWD70 Product No.

Large deck cleaning kit 431 681940 Liquid removal kit 431 681957

Ball valve 431 681932

4 m suction hose 431 681965 Extension tube 100 cm 431 681973 Aluminium deck nozzle 431 681981 Large rolling nozzle for

liquid removal 431 721951

Ordering information The VCWD70 wet & dry

vacuum cleaner 220V/50-60Hz 432 721944 The unit is supplied with: 7,5 m cable with plug Large deck cleaning kit 431 681940

1. Spare rubber lips for aluminum deck nozzle item 6

2. Crevice nozzle 3. Brush 4. Extension tube 100cm

5. 4 m suction hose

6. Aluminum deck nozzle 1

2

3 4

5

6

Large rolling nozzle

(7)

An effective and reliable unit for cleaning all types of carpet on board passenger vessels. The unit is designed with ease of use in mind and is equipped with a detachable waste water container. The machine is very low and stable so its not prone to tipping over.

• All-in-one cleaner, chemical application and removal in one movement which simplifies the cleaning operation

• Sturdy wheels – stable and easy to transport

• Heavy-duty hose, tube and nozzle – all accessories are designed to an industrial standard of endurance

• Low centre of gravity – low and wide design prevents unit from tipping over

Technical data

PROPERTY VALUE

Power (Pmax) 1100 W Working width 26 cm Solution tank 15 L Recovery tank 15 L Pump pressure 2,3 bar Water flow 3 L/min

Air flow 2400 L/min

Dimensions 380x360x420 LxWxH (mm)

Weight 20 kg

Accessories for the VCCW24 Product No.

Water hose & suction hose 431 682013 Carpet nozzle 431 682021 Deck scrubbing adapter 431 682039 Ordering information

The VCCW24 wet

carpet cleaner 220V/50 432 682047 The unit is supplied with:

Water hose Suction hose Carpet nozzle

Unitor VCAD200

a highly versatile air driven cleaner

The Unitor VCAD200 is capable of handling particles and liquids that would stop a normal electric vacuum cleaner dead in its tracks. The unit has no moving parts and is designed to be fitted on a standard 200 litre drum. The unit can be used for a variety of tasks such as removing water, oil spillage and chemicals etc.

• The unit attaches on top any 200L drum – no need to store a big container when not in use, the unit will use any obsolete drum

• Air driven – no danger of sparks

• No moving parts – the unit is virtually maintenance free

• Oil resistant – the unit can be used for small oil spills on board

• Versatile – the unit can be used as a transfer pump, if needed Ordering information Product No.

The VCAD200 - air driven cleaner 432 682054 The unit is supplied with:

Suction hose, Crevice nozzle, Coarse dirt deck nozzle, Tubes

Technical data

PROPERTY VALUE

Air consumption at 6 bar 3600 L/min Air flow rate 3600 L/min

Vacuum at 6bar 390 mbar

Noise level 80 dB(A)

Weight 5 kg Air connection equipment for the Unitor VCAD200 20SM socket with 1/4” male thread 405 191726 40PH plug with hose stem 1/2” 405 191841 40SH socket with hose stem 1/2” 405 191692 Air hose PVC 1/2”, 50m 401 671719 Hose clip set for 1/2” hose, 50pcs 401 671842

Unitor VCCW24

a practical wet carpet cleaner for accommodation

and public areas on cruise and passenger vessels

(8)
