Secure encrypted data
Encryption Access Control
Security HDD XOR encryption
128 bit AES in ECB mode
256 bit AES in CBC mode
256 bit AES in XTS mode
RFID token
fingerprint reader
enter password by keyboard
PIN
smart card + PIN
Who generated it?
Where is it stored?
How can it be destroyed? 1-2-3-4-5-6-7-8 smart card + 8-digit PIN Authentication ...invoice.pdf crm.sql... ...emails.pst fina... ...J!$T%ä... ...u%r\I6... Hardware Crypto-Engine totally encrypted or RFID key
Plain Data Transmission Encrypted Data Transmission
The most important criteria
Data privacy and data security are extremely sensitive issues for companies. Again and again, business processes require the mo-bile availability of research, financial, customer or account information. For the storage and the transport of the data a company must be able to rely on absolute security. To ensure this, the main criteria are:
Encryption
The choice of an appropriate encryption is essential for data security. For high standards of data security, it is recommended to use at least an AES encryption with a key length of 256 bit in CBC mode.
Access control
The access control can range from a simple password to complex multi-factor authentication methods. A complex access method with a two-factor authentication (e.g. by smart card and PIN) offers a very high level of data security.
Administration of the cryptographic key
It should be known, how the cryptographic key was produced and if during the production or on the way to the user a copy of the key could have been made. It‘s also important to know where and how safe the key is stored for the use. In addition, it should be checked, if the cryptographic key can be destroyed, if it is necessary. Highest security provide storage devices on which the cryptographic key is stored externally and the user can generate, change and destroy the key by himself.
Unique selling points of
DIGITTRADE security storage devices
• widest portfolio of encrypted storage devices including high security external HDD/SSD • storage devices are customized for different
security requirements
• wide range: from a secure basic solution for private users to professional solutions for companies and government agencies
• user-friendly handling and plain user manuals • all DIGITTRADE security storage devices are
Overview of the DIGITTRADE security storage devices
The DIGITTRADE GmbH develops and produces external hard drives, SSDs and USB sticks with hardware encryption to protect business and private data extensively and securely against unauthorized access.
DIGITTRADE USB Security Stick USS256 – Secure solution for companies and private user
Password protected access control, 256 bit AES hardware encryption in CFB mode, encrypted storage of the cryptographic key in the flash memory
DIGITTRADE RFID Security HDD/SSD RS64 - Secure basic protection for private users
Triple data protection: RFID access control, XOR hardware encryption, S.M.A.R.T. lock HDD lock, encrypted storage of the cryp-tographic key on the HDD
DIGITTRADE RFID Security HDD/SSD RS128 – Secure solution for private users
RFID access control, 128 bit AES full disk hardware encryption in advanced ECB mode, encrypted storage of the cryptographic key on the HDD
DIGITTRADE RFID Security HDD/SSD RS256 – Secure solution for companies and private users
RFID access control, 256 bit full disk hardware encryption in XTS mode, encrypted storage of the cryptographic key on the HDD, robust aluminum enclosure, integrated silicone Anti-Shock protectors, USB 3.0
DIGITTRADE High Security Festplatten HS128 und HS256 – Professional solution for companies
2-factor authentication by smart card and PIN code, certified full disk hardware encryption according to 128 bit AES in ECB mode or 256 bit AES in CBC mode, external and encrypted storage of the cryptographic key on the smartcard
DIGITTRADE High Security Festplatte HS256S – Professional solution for government and companies
DIGITTRADE USB Security Stick USS256
secure solution for companies and private users
The high resistance of the classy and robust metal case protects the DIGITTRADE USS256 stick additionally from light impacts.
Features:
• password protected access control • 256 bit AES hardware encryption in CFB
mode
• encrypted storage of the cryptographic key in the fl ash memory
• all data will be stored automatically encrypted by the hardware encryption
module in real-time
• epoxy sealing protects the hardware against manipulations and humidity
• freely selectable number of password misen-tries
• automatic delection of data after the preset number of password misentries is exceeded • indicator for password security
• write protection switch for safe usage on different computers
DIGITTRADE USB Security Stick USS256
To increase the safety of the USS256 it has a kind of self destruction mechanism. If an unauthorized access occurs and the preset number of password misentries is reached, the data stored on the stick will be destroyed and the USS256 will reset to factory defaults.
The epoxy sealing protects the hardware against manipula-tions and humidity.
With the DIGITTRADE USB Security Stick USS256 it is easy to guarantee a high level of data security.
This storage device captivates also with its elegant and ro-bust design. In addition, the DIGITTRADE USS256 is deliv-ered with the Acronis True Image OEM Quick Backup soft-ware. This software can be used for backup and recovery of data.
The USS256 offers a storage capacity of up to 16 GB. Due to its numerous security features this stick offers a high degree of security for your data.
At home, at the offi ce or during transport the USS256 protects sensitive data against unwanted looks. All data is stored by a 256 bit encryption according to AES in CFB mode. Thereby all data is protected against unwanted looks even in case of loss of the device.
Features:
• RFID access control
• XOR full disk hardware encryption
• S.M.A.R.T. lock HDD lock (activates an ATA password which prevents from a readout of the HDD outside of the security enclosure) • encrypted storage of the cryptographic key
on the HDD
• no access to the DIGITTRADE Security HDD and your data without one of the two included RFID key
• automatic lock of the DIGITTRADE Security HDD as soon as it is disconnected from the PC
• all data will be stored automatically encryp-ted by the hardware encryption module in real-time
• bootable and independent of operating systems
• compatible to USB 1.1 and 2.0
• available with 320GB, 500GB, 640GB, 750GB and 1TB as HDD and 120GB, 240GB as SSD • available in black and white color
• 2 years guarantee
The user authentication takes place by RFID access con-trol with the included RFID keys. To lock or unlock the DIGITTRADE RS64 one of the RFID key will be placed above the RFID reader integrated in the HDD.
Thanks to the combination of the hardware-based encryp-tion module and RFID access control the security storage device works independent of any operating system and can be used fl exibly.
In addition, the DIGITTRADE RS64 is delivered with the Acronis True Image OEM Quick Backup software. This software can be used for backup and recovery of data. All data stored on the
DIGIT-TRADE RS64 is protected against unauthorized access by three essential safety functions. A combination of data encryp-tion, S.M.A.R.T. lock and RFID access control offers private users and small companies a secure basic protection for portable data.
The integrated hardware encryption module stores data en-crypted and in real-time.
The S.M.A.R.T. lock function is automatically activated, if the HDD is removed from the enclosure, turns off or is locked by the RFID key. In this case an ATA password will be generated automatically to prevent from a readout of the HDD outside of the enclosure. The ATA password is not stored at any time and therefore it cannot be readout. The unauthorized access to the data will be complicated signifi cantly.
DIGITTRADE RFID Security HDD RS128
secure solution for private users
Features:
• RFID access control
• 128 bit AES full disk hardware encryption in advanced ECB mode
• encrypted storage of the cryptographic key on the HDD
• no access to the DIGITTRADE Security HDD and your data without one of the two included
RFID key
• automatic lock of the DIGITTRADE Security HDD as soon as it is disconnected from the PC • all data will be stored automatically
encryp-ted by the hardware encryption module in real-time
• bootable and independent of operating systems
• compatible to USB 1.1 and 2.0
• mini USB and integrated USB connector • available with 320GB, 500GB, 640GB, 750GB
DIGITTRADE RFID Security external HDD/SSD RS128
dent of any operating system and can be used fl exibly. In addition, the DIGITTRADE RS128 is delivered with the Acronis True Image OEM Quick Backup software. This software can be used for backup and recovery of data. The DIGITTRADE RS128 RFID Security HDD
protects sensitive data reliably against unwanted looks.
The encryption of all data takes place with 128 bit AES in advanced ECB mode. In the process every sector uses additionally a different encryption vector.
The integrated hardware encryption module stores data encrypted and in real-time.
The user authentication takes place by RFID access con-trol with the included RFID keys. To lock or unlock the DIGITTRADE RS128 one of the RFID keys will be placed above the RFID reader integrated in the HDD.
indepen-DIGITTRADE RFID Security HDD RS256
secure solution for companies and private users
Features:
• RFID access control
• 256 bit AES full disk hardware encryption in XTS mode
• encrypted storage of the AES key on the HDD • no access to the DIGITTRADE Security HDD
and your data without one of the two included RFID key
• automatic lock of the DIGITTRADE Security HDD as soon as it is disconnected from the PC • all data will be stored automatically
encryp-ted by the hardware encryption module in real-time
• integrated silicone Anti-Shock protectors • robust aluminium enclosure protects against
mechanical infl uences and electromagnetic waves
• bootable and independent of operating systems
• compatible to USB 3.0 and 2.0
• available with 320GB, 500GB, 750GB and 1TB as HDD and 120GB, 240GB as SSD
concussions and impacts.
The data transmission and power supply can be made via a fast USB 3.0 connection.
Thanks to the combination of the hardware-based encryption module and RFID access con-trol the security storage device works independent of any operating system and can be used fl exibly. In addition, the DIGITTRADE RS256 is delivered with the Acronis True Image OEM Quick Backup software. This software can be used for backup and recovery of data. The DIGITTRADE RFID Security HDD RS256 is a secure
solution for companies and private users.
The computer magazine CHIP appreciated the mobile RFID Security HDD with the test result „excellent“ (6/2012) and the PC WELT magazine has chosen the RS256 as the award winner and the „best 2.5-inch hard drive with USB 3.0“ (7/2012).
All data on the DIGITTRADE RS256 is stored by a 256 bit full disk encryption according to AES in advanced XTS mode. The integrated hardware encryption module stores data encrypted and in real time.
The user authentication takes place by RFID access con-trol too. Thereby the access is only with one of the two included RFID keys possible.
In addition the smart and robust aluminium enclosure protects the RS256 against mechanical infl uences and electromagnetic waves. The specifi cally developed silicone protectors increase the resistence against to
DIGITTRADE High Security HDD HS128/HS256
professional solution for companies
Certifi ed by The National Institute of Standards and Technology of the United States of America (NIST)
Features:
• 2-factor authentication by smart card and 8-digit PIN
• certifi ed full disk hardware encryption according to AES 128 bit in ECB mode or AES 256 bit in CBC mode
• external and encrypted storage of the crypto-graphic key on the smart card (prevents from
the readout of the key from the HDD)
• access protection onto the smartcard with the 8-digit PIN
• certifi ed encryption method (NIST: FIPS 197) • all data will be stored automatically
encryp-ted by the hardware encryption module in real-time
• automatic lock of the DIGITTRADE High Security HDD as soon as it is disconnected from the PC • bootable and independent of operating systems • compatible with USB 1.1, USB 2.0 and
FireWire 100 / 200 / 400 / 800
Thanks to the full disk hardware encryption according to the AES and the two-factor authentication, the DIGIT-TRADE HIGH SECURITY HDD combines the benefi ts of portable storage devices with highest security standards for data privacy.
In addition, the DIGITTRADE HS128/HS256 is delivered with the Acronis True Image OEM Quick Backup software. This software can be used for backup and recovery of data. The DIGITTRADE High Security HDDs/SSDs use the
world-wide unique 2-factor authentication to access the data. The 2-factor authentication works according to the „having and knowing“ principle:
Factor 1 (Having): It is verifi ed, if the user has a smartcard
with the correct cryptographic key. This verifi cation is done by inserting the smart card into the HDD enclosure.
Factor 2 (Knowing): It is verifi ed, if the user knows the
correct 8-digit PIN and consequently is authorized to use this smart card. This verifi cation is done by the entry the 8-digit PIN.
In case of any manipulation the smart card will be irrevoca-bly destroyed and disabled. In that case the access to the data is prevented.
If the HS128/HS256 has been unlocked successfully by smart card and PIN, the data will be transmitted like to a normal hard disk – without a delay or an additional program.
DIGITTRADE High Security HDD HS256S
professional solution for government and companies
Certifi ed by The National Institute of Standards and Technology of the United States of America (NIST) and in certifi cation process of the Ger-man Federal Offi ce for Information Security (BSI).
Features:
• 2-factor authentication by smart card and 8-digit PIN
• 256 bit AES full disk hardware encryption in CBC mode
• external and encrypted storage of the crypto-graphic key on the smart card
• administration of the cryptographic key by the user (generate, change, copy and destroy) • access protection onto the smart card with the
8-digit PIN
• certifi ed encryption method (NIST: FIPS 197), in certifi cation process of the BSI (BSI-DSZ-CC-0825)
• smart card Oberthur Cosmo 64 v5.4D certifi ed according to FIPS 140-2 Level 3
• optionally available: smart card NXP J3A081 v2.4.1 R3 certifi ed by BSI according to EAL 5 (Certifi cation ID: BSI-DSZ-CC-0675-2011) • bootable and independent of operating systems • compatible to USB 1.1, USB 2.0 and
FireWire 100 / 200 / 400 / 800
• available with 500GB and 1TB as HDD and 120GB, 240GB and 512GB as SSD
DIGITTRADE High Security external HDD/SSD HS256S
and PIN, the HS256S provides the possibility to adminis-trate the cryptographic key independently of computer or software on the storage device.
The user is able to generate, change, copy and in case of emergency to destroy the encryption key. The cryptograph-ic key whcryptograph-ich is needed for de- and encryption is created and stored encrypted on the smart card. Thereby the cryp-tographic key is physically separated from the encrypted data. So it is impossible to read it out of the DIGITTRADE HS256S or to decrypt the stored data.
With it‘s special security features this encrypted external storage device offers a lot of solutions for single users, companies and government agencies.
In addition, the DIGITTRADE HS256S is also delivered with the Acronis True Image OEM Quick Backup software. This software can be used for backup and recovery of data. The external High Security HS256S protects government,
business and private data comprehensively and securely against unauthorized access. It had been developed according to the lastest requirements of the BSI (Federal Office for Information Security) for portable storage media and it is in the process of the certification BSI (BSI-DSZ-CC-0825).
Data stored on the DIGITTRADE HS256S is protected against unauthorized access with regard to the data confidentiality, e.g. if the DIGITTRADE HS256S is lost, misplaced or stolen, as well as in the event of logical or physical attacks.
The DIGITTRADE HS256S ensures the data confidentiality with these security mechanisms:
- Encryption - Access control
- Administration of the cryptographic key
Examples for special application possibilities of the HS256S:
• Secured and cost-effective data transport: If sensitive data needs to get from one location to another it is possible to send the HS256S easily by post. The matching smart cards are
stored at the sender and the recipient and both know the matching PIN(s). If the HS256S gets lost during the transport, no one will have access to the data because the cryptographic key is not available but stored encrypted on the smart cards.
• Separating of storage device and authentication attributes:
Multiple application possibilities of the DIGITTRADE security storage devices
Independent of operating systems
Because of the hardware encryption the security storage device can be used with every device that supports USB (computer, multimedia devices, machines etc.)
DIGITTRADE offers with it‘s security storage devices solutions for different security requirements, which permit a broad data security in everyday working life without a big effort.
Traveling and field work
If the storage device gets lost, no one will be able to access the data, because it is always stored encrypted.
Business secrets
It is possible to control which persons are able to access the security storage devices by selective handover of the authentication features (smart card and PIN, RFID key).
Data security in case of break-ins
In case of a break-in into an office, it is not possible to access the encrypted data.
Mobile Back-Up device
With the help of the included Acronis Quick Backup software data can be synchronized easily and fast.
Bootable
Acronis Backup Software
All DIGITTRADE security storage devices are delivered with the Acronis True Image OEM
Quick Backup software.
This program is not an encryption software but a special feature for a fast and easy data backup and recovery.
Acronis True Image OEM Quick Backup is a program compilation for the preservation of all information on your computer. It can save the operating system, installed application, settings and all your data. In addition several partitions or complete HDDs can be saved. If the storage device is damaged or deseased by a virus or malware, the data can be restored quickly and easily.
Glossary
RFID - Radio Frequency Identification, is used for the access to the DIGITTRADE RFID security devices.
Cryptographic key - the key which is needed for the
de- and encryption of the data.
Smart card - High Security storage on which the
crypto-graphic key for DIGITTRADE High Security HDDs/SSDs is encrypted stored. It is part of the 2-factor authentication.
Backup - refers to the copying and archiving of computer
data so it may be used to restore the original after a data loss event.
BSI - German Federal Office for Information Security
XOR - exclusive-or operation, “either or“
AES - Advanced Encryption Standard, symmetric encryp-tion system, approved in the USA for top secret informaencryp-tion
CFB Mode - Cipher Feedback Mode, is an operation mode
for block encryptions, that generate a chaining of the blocks.
ECB Mode - Electronic Codebook Mode, is an operation
mode for block encryptions. The plaintexts are encrypted separately from each other.
CBC Mode - Cipher Block Chaining Mode, is an operation
mode for block encryptions. The plaintext is “XORed“ with the privious ciphertext before being encrypted.
XTS Mode - XEX-based tweaked codebook mode with
Service and Support
DIGITTRADE GmbH
Ernst-Thälmann-Str. 39
06179 Teutschenthal
Web:
www.digittrade.de
Phone:
+49 / 345 / 2 31 73 53
Fax:
+49 / 345 / 6 13 86 97
E-Mail:
support
@
digittrade.de
DIGITTRADE is member of the IT Security Association Germany (TeleTrusT)
Our consulting team can be reached during weekdays between 8.00 and 18.00 h via
e-mail or telephone.
Source of supply:
Austria
