Browser-based access control
and time attendance system
Basic Mon–Fri 8:00-16:00 Warehouse Mon–Fri 6:15-18:00 Cleaners Mon–Fri 5:30-17:00 Office Mon–Fri 8:00-17:00 Representatives Mon–Fri 6:00-20:00 Management Tue–Thu 9:30-15:00 Security Mon–Fri 7:00-17:00 Maintenance Tue–Wed 11:00-14:00 Ascension Day Ascension Day Epiphany Christmas Eve Christmas Day New Year’s Day
Good Friday Easter Monday
Created by Finnish Hedengren Security, the Hedsam Novitas access control and time attendance system is the result of several years of product development and the latest technology. In addition to the top properties of all earlier Hedsam systems, Novitas offers features like a database platform, browser access and various language options. With browser access and mobile functions like mobile clocking, the system can be used, managed and maintained regardless of time and place.
Hedsam Novitas is an excellent fit for the access control and time attendance management of both small companies and large enter-prises with several thousand employees, from one-door applications to systems with more than 1,000 doors and up to 64,000 access cards!
Consisting of various components, the software structure suits a wide variety of applications. The modular structure of the system makes it easily adaptable to various applications and requirement levels throughout its lifecycle.
When Hedsam Novitas is integrated with Hedengren Security’s other security systems, such as HedGraphics, the result is a user-friendly system that takes building security to a whole new level. For reliable and safe access control, your best choice is Hedsam Novitas.
Benefits of the
Hedsam Novitas systemt
Browser access
• uses the free Firefox browser
Affordable
• a highly competitive price/quality ratio • low initial costs
Decentralised system
• independent, intelligent hubs
Light cabling
• only one pair per data bus
Software clarity and structure
• encrypted database • easy implementation • HConfig configuration
Well-known Finnish manufacturer
• reliability • customisation
Continuity
• delivered since 1985
Versatile
• several software options and integration opportunities
Authorised local representatives
• expert advice nearby
passerkontroll och tidsredovisning
Access control and time attendance
management
Hedsam Novitas – diverse features:
Access control
The access control system is a flexible, modern solu-tion for controlling the opening and closing of doors. The level of building security increases when you can determine access rights for people and see who goes where at each time. The building’s doors are equipped with electronic locks and readers. When necessary, the access control software raises an alarm when a door is left open or opened without authorisation. Events can be followed up, thanks to extensive reporting. Hedsam Novitas also proves its
cost efficiency in the long term: expensive lock rekeying is not neces-sary even if identifiers are lost.
Local controller
Hedsam Novitas, a hub-based solution (Cluster Controller), enables the control and maintenance of several sites over networks. Implemented like this, the Hedsam Novitas system can be utilised across a very large operating range. With the system’s central PC located on the main site, only local controllers can be used for remote sites if necessary. All access control system functionalities and any integration with other systems, such as intruder alarm system control, can be handled locally in real time by the cluster. The hub controls the groups of the intruder alarm system, detecting their status information.
The hub accommodates 64 Hedsam door units and up to 64,000 ac-cess cards. Several different user groups/clients can be located under the same server in, for example, shopping centres, and each client may have its own, individual cardspace managed and maintained by the user.
Access events with codes
In the Hedsam Novitas system, access to premises can also be allowed with door-specific codes without access cards. Eight four-digit opening codes can be specified for each door. Each code has a date and time range during which it is valid. This feature is very useful in situations where training/conference rooms are rented out for temporary use and you do not want to provide the users with access cards.
TA-2010
Access Touch
Time attendance management
The time attendance system enables easy monitoring of working hours, provides more specific attendance information (meeting, lunch, etc.) and provides the necessary information about ab-sences and return to the workplace. This way, the system serves various parties like customers, telephone exchange operators, col-leagues and payroll calculation. The time attendance software can be used to handle flexible working hours, shift work, overtime, etc. The information collected can be moved to, for example, external payroll software and documented using various reports.
Project and work phase monitoring
In order to be able to offer software that flexibly suits various ap-plications, we have integrated our software with the Finnish Necom Oy’s Promid software. Thanks to the integration, we can offer a competitive system for demanding applications involving shift work, hour bank, project and work phase monitoring, etc.
The Promid-Hedsam software enables effective monitoring of employees’ working hours and time spent on different projects. Special attention has been paid to the production of payroll data in accordance with collective labour agreements. The system includes ready-made collective labour agreements from various fields (e.g., chemistry, metal and food industry) that can be cus-tomised as necessary.
Clocking in and out takes place using a touch screen terminal with a built-in Hedsam system reader. Clocking stations can also be implemented using both WLAN and GPRS technology, so a fixed internet connection is not necessary. Entries can also be made by SMS using a mobile phone. The Promid-Hedsam software per-forms the necessary calculations and provides diverse reports. The software has flexible connectivity to external software (for example, payroll, ERP and manufacturing execution).
Image bank
The image bank makes it possible to check the cardholder’s iden-tity from a photo. This further increases the level of security during clocking in. If necessary, each access control entry can display the cardholder’s photo on a PC screen using the HedGraphics ap-plication. It can be specified separately for each door whether the person’s photo is to be displayed or not. The actual photo is located on the system’s file server. The image bank can also be used for printing access cards.
Mobile clocking
With the mobile clocking feature, GSM phones can be used as ac-cess cards in the Hedsam system. The Hedsam software can be used to determine the cardholder’s GSM number to correspond to his/her access card, granting the phone number the same rights that have been set for the access card. This mobile feature is very useful for applications like controlling gates and barriers at produc-tion facilities and monitoring hours in remote work.
Hedsam Router is a device that contains a GSM modem. It enables time attendance clocking by SMS and opening doors or gates by either phone call or SMS. The door to be opened and the time to keep it open are specified in the message. Hedsam Router is con-nected to a COM/UDP port on the server or PC.
Registration plate identification, vehicle reader
and parking software
Integration with Mirasys and Asan software enables registration plate identification for vehicles.
By using a vehicle reader and parking software in the Hedsam Novitas system, it can be used to pay for, for example, parking or gym exercise.
Lifts
The use of lifts can be monitored and limited with a card reader installed in the lift cabin, providing different users with access rights to different floors and thus preventing unauthorised access. Alter-natively, a call reader can be installed on each floor that activates the lift call button.
Alarm graphics and door display
The HedGraphics application shows the floor plan of the build-ing, indicating the alarm points and door environments with their controls. The application enables the administration and location of doors, thus facilitating the work of security guards in the control room, for example.
Integration with other systems
Intruder alarm control HHL CCTV control
Payroll software ERP software
LAN
RS485 buses 2 pcs - max 32 Hedsam-5.3 /bus 24 V DC Calculation instructions:about 7 door environments/5 A power supply, 10 A version also available Hedsam POW power supply with batteries Cluster Controller, CC hub
included in the system whenever you need:
A. HHL integration and/or
B. More than 900 identifiers (cards)
System server:
- software- encrypted database
- interfaces with external systems - administration
Hedsam time attendance terminal control card
RS232-bus
Hedsam EXTOUT relay cards for lift control
- connected to the Hedsam-5.3 card (max. 2 pcs)
- max. 16 floors controlled by one Hedsam5 card and two EXTOUT-8 cards
Door environments:
- readers, locks, opening buttons - magnetic contactsHHL
mg
mg
Room detectors, input, max. 16Hedsam-IN16 cards for
the monitoring of premises
Access control of branch offices with hubsWAN
Lift machinery
room
Lift cabin
ASR-603B remote reader KIT-603B installation platform
Lift logic Lift machinery
Lift floor selector
Lift shaft
Interface to the exchange information system:
- Merex, Ericsson MD-110, etc.Hedsam door control card
Floor controls
Workstations:
- system maintenance - management (time
attendance, access rights, identifiers, etc.) - reception services - security - telephone exchange
Idesco EPC IA
Vehicle identification
- maintenance-free, passive identifiers - reading distance about 10–15 m - protection IP67
Gate, barrier or
door control
Hedsam door control card
Hedsam door control card
Hedsam door control card HHL integration
via CC hub
TA-2010
Access Touch intelligent touch screen display
LAN
VEHICLE WITH EPC-WINDSHIELD
OR
Server
Management and TA clocking also via the browser user interface (Firefox) Hedsam-router GSM controls and TA clocking
WAN
EPC-METAL Browser user interface Readers: - Indala - Farpointe - iClass Identifiers: - Indala - Farpointe - iClass IT network technology If a CC hub is not needed, the bus connection (RS485) is implemented using: MD16/485 bus connection cards UDS-1100 terminal serversTime attendance terminals and
restaurant payment terminals
Operating principle of the Hedsam Novitas access control and time attendance system
Structural components of the Hedsam system
1. PC with software and database 2. Connections between the PC and field equipment • cabling • amplifiers • converters • networks 3. Field equipment • hubs
• electronic cards, power supplies, etc. 4. Readers, clocking terminals 5. Remote identifiers
Lauttasaarentie 50, FI-00200 Helsinki, Finland Tel. +358 207 638 000
[email protected] www.hedengrensecurity.fi
hedsam
Browser-based access control
and time attendance system
Basic Mon–Fri 8:00-16:00 Warehouse Mon–Fri 6:15-18:00 Cleaners Mon–Fri 5:30-17:00 Office Mon–Fri 8:00-17:00 Representatives Mon–Fri 6:00-20:00 Management Tue–Thu 9:30-15:00 Security Mon–Fri 7:00-17:00 Maintenance Tue–Wed 11:00-14:00 Ascension Day Ascension Day Epiphany Christmas Eve Christmas Day New Year’s Day
Good Friday Easter Monday
• up to 64,000 users • more than 1,000 doors • access control
• time attendance management • intelligent access control hub • project and work phase
monitoring • image bank • browser clocking • mobile clocking
• encrypted database
• registration plate identification • alarm graphics
• lunch monitoring
• telephone exchange connection • integration with other systems • browser user interface
• language options (fi, se, en, est, rus) • touch screen TA&RU terminal
