Extensions to the standard ransac algorithm for efficiency and robustness

*Corresponding author: Wenyan Ci ISSN: 0976-3031

Research Article

EXTENSIONS TO THE STANDARD RANSAC ALGORITHM FOR EFFICIENCY AND

ROBUSTNESS

Wenyan Ci., Jue Wang., Mingxiang Zhu and Aiyu Dou

School of Electric Power Engineering, Nanjing Normal University Taizhou College,

Taizhou, China

DOI: http://dx.doi.org/10.24327/ijrsr.2018.0912.2942

ARTICLE INFO ABSTRACT

Over the past decade, many improvements have been made to RANSAC, each of which addresses the specific weaknesses of the original algorithm. However, there are relatively few comprehensive studies on these developments. The purpose of this paper is to fill this gap by researching related technologies, so as to promote the development of new algorithms. This paper first introduces the standard RANSAC algorithm, and discusses its mechanism and limitations. Then, some extensions of RANSAC algorithm are introduced in detail. These extensions solve the limitations of robustness and efficiency. By combining these ideas, the performance of the algorithm can be further improved in terms of real-time performance and robustness.

INTRODUCTION

The RANSAC algorithm proposed by Fischler and Bolles (Fischler and Bolles, 1987) is a well-known method for estimating model parameters in the presence of outliers. It is based on iteration and hypothesis verification framework, and has robustness to contaminated observation data. The basic idea of RANSAC algorithm is to randomly extract a sample set from the complete set, calculate the model parameters, and then verify the other data points in the complete set with the obtained model parameters. After many iterations, the model parameters that can obtain the highest consistency in the data points are regarded as the solution of the model, while those data points which are inconsistent with the model parameters are regarded as the outliers. The size of the sample set is usually set to the minimum value that can be used to solve the model parameters. For example, the value is usually 3 in stereo vision. The standard RANSAC framework consists of hypothesis and verification stage, which are iterated over a set of observations. In the first stage, a set of randomly selected points is used to instantiate the model, in which the cardinality of the sampling set is equal to the minimum number of points needed to determine the parameters of the model, so the sampling set is also called the minimum set. The second stage of the algorithm is to determine the observation values

consistent with the model, which constitute a consistent set. The consistency here is usually defined based on some predefined error thresholds. After several iterations, the algorithm returns to the model that obtains the maximum consistent set.

RANSAC algorithm is an uncertain algorithm, i.e., the results of each execution of the algorithm may be different. It obtains reasonable results with a certain probability. The more iterations, the greater the probability. In fact, RANSAC algorithm has become a general method of excluding outliers in visual navigation system (Maimone et al., 2007, Deigmoeller and Eggert, 2016). In recent years, some improved versions of RANSAC algorithm have appeared. Proposed methods which focus on consensus measure, sampling strategy, hypotheses verification are discussed in the paper.

Consensus Measure

The loss function of RANSAC algorithm sets the value of inliers to 0, without considering the difference of error between inliers. When the setting of



2 is larger, more solutions of the same

C

will be generated, which makes the estimation of the model worse. This section introduces two robust consistency measurement methods.
