For more than 30 years, PVC membranes have opened their way to all waterproofing sectors, thanks to their many advantages, such as flexibility and strong tearing resistance, combined with superior welding ability, low safety risks, ease of Installation and excellent whole life costs.

The Cefil range of waterproofing products have a long and successful history, produced under strict ISO9001 quality control standards. Cefil synthetic waterproofing membranes have been specifically developed to achieve a fast, sustainable, durable environmentally friendly and aesthetically pleasing waterproofing solution. Over 7.000.000 sqm of Cefil membranes are produced and distributed yearly by Ceplastik.

Carefully selected polyester and glass reinforcements are coated on each side by a superior blended PVC flexible plasticiser. These reinforcements considerably improve stability, strength, puncture resistance and long term durability. The result is a homogeneous high quality flexible membrane.

Cefil waterproofing membranes are available in a range of formats to suit almost any type of waterproofing concept for a building or structure. These formats can be broken down in to 4 main categories:

o RP Mechanically fixed self protected systems o RV Fully adhered self protected systems o ECO-ROOF - Green roof systems

o Inverted roof systems with additional protection.

These categories are all available in a range of colours with associated accessories to complete any architectural concept and to offer a complete warranted system for the most discerning of clients.

This brochure has been prepared to assist specifiers and Contractors in selecting the most appropriate products from the range available.

Introduction

‘Over

7.000.000 sqm

of

Cefil membranes

are

(6)

1. UV RESISTANCE - Cefil membranes are integrated with UV resistors at source during the manufacturing process. Exposed membranes therefore provide superior UV degradation resistance.

2. FIRE RESISTANCE - Cefil membranes are Fire resistant and self-extinguishing. In addition, they cannot be ignited by flying sparks. Cefil membranes have passed some of the most stringent European regulations including BS476: part 3. The use of Cefil membranes is therefore unrestricted under the current building regulations.

3. WATERTIGHT - Cefil membranes, when correctly heat welded, homogenise together to become one at molecular level. Therefore the join is at least as strong as the membrane itself with no weak points. The membrane has been rigorously tested for moisture resistance, behaviour under hydrostatic pressure and impact strength, and classed as leakproof. Under the European standard peel test, the Cefil membrane broke outside of the seam without any sign of weld failure.

4. FLEXIBILITY - Cefil membranes have all been produced to comply with the needs of today’s buildings with regard to structural and building movement. They are dimensionally stable and will repeatedly accommodate normal structural movement without fatigue. Low temperature flexibility has been tested down to -35 degrees C.

5. SUSTAINABILITY - Cefil membranes have been rigorously tested by many European testing establishments and have a proven successful history of providing long term waterproofing to a variety of building designs. The product life expectancy is documented as ‘in excess of 20 years’ and laboratory accelerated weathering tests have shown this to be even greater. Cefil materials are installed Worldwide in a variety of climatic extremes and show superior performance and durability - a crucial element of environmental sustainability.

6. GUARANTEE - Extensive roof assured warranty schemes are available that a client can trust for up to 10 years. Under correct installation conditions Cefil membranes have 10 years guarantee against any production fault.

7. QUALITY - Cefil membranes are produced strictly in accordance with ISO9001 quality standards. The calandering & lamination process is computerised to ensure consistent quality and all raw materials randomly tested prior to integration and development.

Reasons to select

(7)

8. ENVIRONMENTALLY FRIENDLY - Cefil synthetic membranes are produced in line with the ISO14001 environmental management system. This policy covers development, Raw materials, Production, Distribution, Installation, Service and recycling. The product provides a healthy long life expectancy and can be recycled at the end of its useful roofing life. Assembly and seam welding is rapid with a low energy output and the membranes lightweight construction minimises transport energy. Cefil products therefore represent a minimum burden on the environment, from conception to completion.

9. SAFETY - Cefil membranes are fast and easy to install and offer significant reductions in relation to risk with many alternative roofing systems. To compliment the membrane, all specifications are Safety conscious with the integration of polyurethane glues (CFC & HCFC free) and even self-adhesive Vapour barriers to avoid the use of hot bitumen boilers. This provides peace of mind to building owners and Installers and achieved preferred system status with some leading building Insurance underwriters.

10. AESTHETICS - Cefil roofing membranes come in standard light grey and lead grey. However, alternative colours are available on order request, blue, green, beige and red. All colours are tested for Colourfastness under UV and Sunlight accelerated procedures to ensure long term aesthetic performance.

11. TECHNICAL SUPPORT - Ceplastik can offer everything a specifier or building owner will need. Our team are available throughout the project to ensure complete client satisfaction.

(8)

(9)

(10)

Cefil RP

Mechanically fixed roofing system

Suitable for:

o Metal profiled decking

o Timber decking (Minimum 18mm plywood)

o Concrete deck (Subject to pull out resistance test)

o Roof refurbishment Formats available:

o Warm roof (Flat or tapered Insulation)

o Cold roof

o Inverted roof

o ‘Living’ or Bio-diverse roof Finishes available:

o Self protected smooth finish (Light or Lead grey as standard)

o Standing seam or lead effect raised profile finish

o Paving or ballast finish (Inverted roof)

o Intensive, extensive or Bio-diverse roof Specific Benefits:

o Lightweight

o Fast installation process

o Excellent wind uplift resistance capabilities

o Excellent whole life cost and economy of scale

o Low maintenance

ROOFING

*Note: Colour range listed is normally on stock, alternative colours and thicnesses including White, Blue, Red, Beige and Green are available subject to extended lead time and quantity required.

“N” AENOR

PRODUCT COLOUR THICKNESS WIDTH OUTDOORS REINFORCEMENT CERTIFICATE/

(mm) (M) CE MARKING

Cefil RP Grey / Dark grey 1,2 1 Yes Polyester net Yes Cefil RP Grey / Dark grey 1,2 1,5 Yes Polyester net Yes Cefil RP Grey / Dark grey 1,2 2 Yes Polyester net Yes Cefil RP Grey / Dark grey 1,5 1 Yes Polyester net Yes Cefil RP Grey / Dark grey 1,5 1,5 Yes Polyester net Yes Cefil RP Grey / Dark grey 1,5 0 Yes Polyester net Yes

(11)

Cefil RP

120 GREY/DARK GREY

Description:

Flexible sheet of PVC flexible, 1.2 mm of thickness with polyester reinforcement included. As required, microorganisms resistant.

Application:

Roof waterproofing. Useful for outdoor applications. It has got CE marking certificate corresponding to UNE EN 13956 normative, (nº 0099/cpd/a85/0033), and also N mark of quality product given by AENOR (nº 001/004659).

Cefil RP

Mechanically fixed roofing system

TEST METHOD USUAL VALUES UNE EN 13956

Thickness (mm) UNE 53.213-2 1.2 Nom. -5,+10%

Thickness in the net cross (mm) UNE 104302 0.4 ≥ 0.3

Width (mm) UNE EN ISO 426 Max. 2000 Nom. -0.5,+1%

Flatness (mm) UNE EN 13956 5 ≤ 10

Straightness (mm) UNE EN 13956 20 ≤ 50

Tensile strength (N/50 mm) EN 12311-2 L, T = 1000 MLV

Elongation (%) EN 12311-2 L, T = 15 MLV

Tear resistance (N) EN 12310-2 L, T = 250 MLV

Interlaminar adhesion (N/50 mm) UNE EN ISO 527-1 L, T = 100 MLV

Dimensional stability (%) EN 1107-2 0.2 MLV

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 MLV Shear resistance (N/50 mm) EN 12317-2 500 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV Exposure to uv radiation (foldability at low EN 1297 Pass Pass temperature after 1.000 H)

External fire performance EN 13501-5 BROOF (t1) BROOF (t1)

Reaction to fire EN 13501-1 E F

Resistance to impact (mm) (No cracks) EN 12691 1.000 MLV

Watertightness (10 KPA) EN 1928 (B) Pass Pass

Resistance to root penetration EN 13984 Not penetration Not penetration Resistance to static loading (20 Kg) EN 12730 No cracks MLV Determination of hail resistance (m/s) EN 13583 Support hard: > 21

Support soft: > 43

(12)

Cefil RP

150 GREY/DARK GREY

Description:

Flexible sheet of PVC flexible, 1.5 mm of thickness with polyester reinforcement included. As required, microorganisms resistant.

Application:

Roof waterproofing. Useful for outdoor applications. It has got CE marking certificate corresponding to UNE EN 13956 normative, (nº 0099/CPD/A85/0033), and also N mark of quality product given by AENOR (nº 001/004659).

Width (mm) UNE EN ISO 426 Max. 2000 Nom. -0.5,+1%

Tensile strength (N/50 mm) EN 12311-2 L, T = 1050 MLV

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 MLV Shear resistance (N/50 mm) EN 12317-2 500 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV Exposure to uv radiation (foldability at low EN 1297 Pass Pass temperature after 1.000 H)

External fire performance EN 13501-5 BROOF (t1) BROOF (t1)

Resistance to root penetration EN 13984 Not penetration Not penetration Resistance to static loading (20 Kg) EN 12730 No cracks MLV

(13)

Cefil RV

Fully adhered roofing system

Suitable for:

o Metal profiled decking

o Concrete deck

o Roof refurbishment Formats available:

o Cold roof

o Inverted roof Finishes available:

o Self protected smooth finish (Light or Lead grey as standard)

o Standing seam or lead effect raised profile finish

o Paving or ballast finish (Inverted roof) Specific Benefits:

o Lightweight

o Fast installation process

o No protruding fasteners

o Excellent wind uplift resistance capabilities (fully bonded)

o Excellent whole life cost and economy of scale

o Low maintenance

To enable superior performance of fully adhered single ply waterproofing, the carrier is required to provide different movement characteristics. A glass fibre mat is used, which is coated on both sides with plastisol. Cefil RV1 and RV2 are highly resistant to low and high temperatures and can easily accommodate cyclic structural movement whilst maintaining durability and flexibility in a bonded format.

Cefil RV1 and RV2 membranes are particularly suitable for roofs where mechanical fixing is not desirable, such as a Profiled metal decking with a powder coated underside as the finished product or certain types of concrete deck. It is also semi permeable to water vapour, and therefore provides an ideal solution to roof areas where interstitial condensation is

considered a higher risk than usual (e.g. over swimming pools).

Cefil RV1 and RV2 are normally installed as a complete system, including vapour barrier, Insulation and ancillary products.

The installation method comprises of the laying out of 1 or 2m wide rolls with side and end overlaps of subsequent membrane, applied with an even coat of Cefil Membrane Adhesive to the membrane and to the surface that it is being applied to, i.e. deck or insulation. The laps are subsequently heat welded using semi automatic hot air welding equipment to form a homogeneous joint at the seam. In inverted or ballasted roof format, Cefil RV can be loose laid and laps subsequently welded.

*Note: Colour range listed is normally on stock, alternative colours and thicnesses including White, Blue, Red, Beige and Green are available subject to extended lead time and quantity required.

ROOFING

“N” AENOR

(mm) (M) CE MARKING

Cefil RV1 (MV) Grey / Dark grey 1,2 1 Yes Glass fibre Yes Cefil RV1 (MV) Grey / Dark grey 1,2 2 Yes Glass fibre Yes Cefil RV1 (MV) Grey / Dark grey 1,5 1 Yes Glass fibre Yes Cefil RV1 (MV) Grey / Dark grey 1,5 2 Yes Glass fibre Yes Cefil RV2 (RV) Black / Black 1,2 1 No Glass fibre Yes Cefil RV2 (RV) Black / Black 1,2 2 No Glass fibre Yes Cefil RV2 (RV) Black / Black 1,5 1 No Glass fibre Yes Cefil RV2 (RV) Black / Black 1,5 2 No Glass fibre Yes

(14)

Cefil RV1

120 GREY/DARK GREY

Description:

Flexible sheet of PVC flexible, 1.2 mm of thickness, with glass non-woven reinforcement included. As required, microorganisms resistant.

Application:

Width (mm) UNE EN ISO 426 Máx. 2.000 Nom. -0.5,+1%

Flatness (mm) UNE EN 13956 5 ≤ 10 mm

Straightness (mm) UNE EN 13956 20 ≤ 50 mm

Tensile strength (MPA) EN 12311-2 L, T = 11 MLV

Interlaminar adhesion (N/50 mm) UNE EN ISO 527-1 L,T = 100

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 MLV Shear resistance (N/50 mm) EN 12317-2 500 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV External fire performance EN 13501-5 Broof (t1) Broof (t1)

Watertightness (10 KPA) EN 1928 (B) Pass MLV

Resistance to root penetration EN 13984 Pass Pass

Resistance to static loading (20 KG) EN 12730 No cracks MLV

Exposure to UV radiation EN 1297 Pass Pass

(15)

Cefil RV1

150 GREY/DARK GREY

Description:

Application:

Exposure to UV radiation EN 1297 Pass Pass

(16)

Cefil RV2

120 BLACK/BLACK

Description:

Application:

Roof waterproofing. Not useful for outdoor applications. It has got CE marking certificate corresponding to UNE EN 13956 normative, (nº 0099/CPD/A85/0033), and also N mark of quality product given by AENOR (nº 001/004659).

(17)

Cefil RV2

150 BLACK/BLACK

Description:

Application:

(18)

Cefil SR

Ceplastik can also supply a wide range of non-reinforcement synthetic membranes (Cefil SR, Novater 80 and Urater) from 0.8 mm thickness to 1.5 mm and with a variety of widths : 1 metre, 1,5 and 2 metres width.

“N” AENOR

(mm) (M) CE MARKING

Cefil SR Black / Black 1,2 1 No No Yes

Cefil SR Black / Black 1,2 1,5 No No Yes

Cefil SR Black / Black 1,5 1,5 No No Yes

ROOFING

Cefil SR (calandered non-reinforced) membranes are specially useful for waterproofing small areas in the roof.

o Outdoors quality.

o High deformation capacity and good resistance to welding, and therefore, good behaviour when used to cover irregularities of the roof.

o Suitable for difficult areas such as chimneys, walls, etc.

(19)

Cefil SR

120 BLACK/BLACK

Description:

Flexible sheet of PVC flexible, 1.2 mm of thickness without any reinforcement included. As required, microorganisms resistant.

Application:

Cefil SR

Thickness (mm) UNE 53.213-2 1.2 -5, +10%

Width (mm) UNE EN ISO 426 Max. 2000 -0.5, +1%

Dimensional stability (%) EN 1107-2 2 MLV

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 MLV Shear resistance (N/50 mm) EN 12317-2 500 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV External fire performance EN 13501-5 BROOF (t1) BROOF (t1)

Resistance to static loading (20 kg) EN 12730 Pass MLV

(20)

Cefil SR

150 BLACK/BLACK

Description:

Flexible sheet of PVC flexible, 1.5 mm of thickness without any reinforcement included. As required, microorganisms resistant.

Application:

Thickness (mm) UNE 53.213-2 1.5 -5, +10%

Width (mm) UNE EN ISO 426 Max. 2000 -0.5, +1%

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 MLV Shear resistance (N/50 mm) EN 12317-2 500 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV External fire performance EN 13501-5 BROOF (t1) BROOF (t1)

Resistance to static loading (20 kg) EN 12730 Pass MLV

(21)

Novater

50-60-80 BLACK

Description:

Flexible sheet of PVC flexible, 0.5, 0.6, 0.8 mm of thickness, without any reinforcement included.

Application:

Not useful for outdoor applications.

Thickness (mm) UNE 53.213-2 Nominal ±10%

Width (mm) UNE EN ISO 426 Máx. 2.000 ±1%

Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV

Shore A UNE EN ISO 868 63 ± 3

Reaction to fire UNE 104.305 Self-Extinguish

(22)

Urater

50-60-80 COLOUR

Description:

Flexible sheet of PVC flexible, 0.5, 0.6, 0.8 mm of thickness, without any reinforcement included.

Application:

Useful for outdoor exposure in accessories for roofing applications.

Thickness (mm) UNE 53.213-2 Nominal ±10%

Width (mm) UNE EN ISO 426 Max. 2000 ±1%

Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV

Shore A UNE EN ISO 868 63 ± 3

Reaction to fire UNE 104.305 Self-Extinguish

(23)

Cefil

Comprehensive range of Accessories

Cefil roofing solutions are more than just the membrane. An extensive selection of approved associated products to suit a multitude of functions are provided to suit specific needs.

Thermal Insulation: Cefil membranes have been tested and approved for use on many major manufacturers Insulation’s including Mineral wool, Polystyrene, Polyurethane, Cellular glass and Perlite to name a few. Thermal Insulation’s are available as part of the Cefil waterproofing system in warm or Inverted format as Flat and Tapered formats.

(24)

PRODUCT DESCRIPTION USE

Cefil SR 1.2mm unreinforced membrane For intricate detailing, forming pipe boots etc. Available in 20 x 1m rolls

Polyvap High density polyethylene film Vapour control layer (1000 Gauge) for mechanical fix systems Sureprime High bond keying agent Roof primer for bonded VCL membranes

Elastotorch V2 Polymer modified glass reinforced vapour Vapour control layer for concrete, plywood and low profile control layer metal decking

Elastotorch V3 Polymer modified glass reinforced vapour Vapour control layer for most structural decks, suitable for control layer temporary weathering of buildings before main Cefil

installation commences

Elastotorch V4 Polymer modified polyester reinforced Vapour control layer for large profiled metal decks

Elastotorch SAVC Polymer modified self adhesive vapour Vapour control layer for most structural decks, suitable for control layer temporary weathering of buildings before main Cefil

Elastotorch SAVB Polymer modified aluminium lined self Vapour barrier for most structural decks, suitable for adhesive vapour barrier temporary weathering of buildings before main Cefil

Cefleece 2G 200 g/m2 polyester fleece Separation layer between Cefil and plywood/ timber and brickwork abutments

Cefleece 3G 300 g/m2 polyester fleece Cushion layer between Cefil and substrate, ballast or separation from bitumen

Cefleece 4G 400 g/m2 polyester fleece Heavy duty cushion layer. Thermobond Solvent free polyurethane Adhesive Bonding compound for Insulation Cefil contact adhesive Polyurethane Adhesive Bonding compound for Cefil RV Cefil RVF adhesive Polyurethane adhesive Bonding compound for Cefil RVF

(25)

Green roof systems

The demand for sustainable and environmentally friendly Green roofs (also known as roof gardens or ‘living’ roofs) has increased dramatically in recent years. The purpose of this section is to provide information about environmentally friendly green roofing systems.

Environmental concerns and the reduction of Carbons are a high priority to many building designs. The increased pressures on Urban land and density levels in built up areas continue to reflect the adverse impacts on drainage, biodiversity, climate conditions, water abstraction and green space.

Simple Green roofs have been around for centuries, such as the Hanging Gardens of Babylon for example, constructed in 600 B.C. Today, modern green roofs need to meet the growing range of requirements attached to increasingly sophisticated building designs.

Formats available:

o Cold roof

o Inverted roof

Finishes available:

o Extensive - Thin lightweight growing medium - minimal maintenance

o Intensive - Deep growing medium (for plants, shrubs, trees, turf etc)

o Bio diverse - Recycled aggregate from site - generally left to colonise naturally or seeded with an annual

wild flower mix or local seed source.

The Cefil ECO-ROOF system has been designed to offer specifiers and building owners a technologically advanced, sustainable, environmentally friendly, aesthetically pleasing and harmonious Green roof solution which represents an excellent Whole life cost* analysis to a building.

Cefil eco-roof suitable for: o Metal profiled decking

o Concrete deck o Roof refurbishment

o

Cefil

ROOFING

Informative Section

(26)

Specific benefits of

Cefil

o Extended roof life - The Cefil synthetic waterproofing membrane as an exposed finish has a life expectancy of ‘at least 10 years as actual legislation requires’. As an ECO-ROOF system with a protected green roof, the membrane is not exposed to UV light or mechanical damage. In addition, the vegetation cover moderates the temperature extremes. Therefore the Life expectancy of a Cefil membrane as an ECO-ROOF can be expected to last as much as 50 Years, saving the client the cost of re-waterproofing during the average lifetime of a building and so represents excellent whole life costs.

o Rainwater management - The Cefil ECO-ROOF system retains, absorbs and re-cycles rainwater, thus considerably reducing the water run off returned to the drainage system. In heavy rainfall, excess water run off is delayed, thus reducing the impact on the urban sewerage network. In association with a collective irrigation system (also available as part of the Cefil ECO-ROOF system), excess rainwater can be collected and returned to the roof vegetation in times of drought.

o Energy Management - The Cefil ECO-ROOF system slows a buildings heat gain and loss. The vegetation layer and the trapped air prevent rapid air exchange and high heat gain on the roof surface which improves the energy performance of the building. In addition to the more ambient temperatures of the roof surface, plants transform heat (energy from the sun) and soil moisture into humidity through evapotransporation processes, naturally cooling the building. The result is a reduction of cooling in the building, an extended life span of the roof system, a reduction of heat reflection in to the atmosphere and lower heating and cooling energy costs over the lifetime of the building. Lower energy means less CO2 emitted in to the atmosphere.

o Urban ecology - The Cefil ECO-ROOF can help satisfy a psychological and sociological need by creating a re-assuring planted environment to counter the aggressiveness of city life. Air Quality is improved by the natural aspect of the ECO-ROOF vegetation filtering the air and absorbing polluting particles and a reduction of the heat Island effect, which is the main cause of Ozone pollution. Cefil ECO-ROOFS also provide biodiversity and wildlife for a wide variety of animals, insects and invertebrates.

o Noise and sound reduction - The Cefil ECO-ROOF system can reduce external sound by 8-10db compared with a conventional roof system. The Vegetation barrier and entrapped air within the vegetation acts as a sound Insulation barrier and sound waves are absorbed, reflected or deflected.

o Recyclable materials - Many of the products used within the Cefil ECO-ROOF system are recyclable or made from recyclable building materials, rubber or plastic. Where possible, dependant on project location, the Cefil ECO-ROOF system can re-use secondary aggregates.

o Single source of responsibility - All Cefil ECO-ROOF system components are supplied by Cefil UK ltd, from roof primer to finished planting varieties. Our technical field team and specialist consultants inspect the quality of material and workmanship on a regular basis throughout the contract works. Once the system is complete, our commitment to our clients does not end. Cefil UK will re-inspect the ECO-ROOF plants and vegetation during the buildings retention period (usually 12 months) to ensure establishment

o

ROOFING

(27)

Extensive

System Description

Green roofing with a thin growing medium requiring minimal maintenance and usually no Irrigation. The vegetation use is resilient and forms a carpet like self-sustaining plant community on the roof. The Cefil Extensive ECO-ROOF system is available as a sedum mat or plug and plant (pre germinated sedum), substrate based roof. Extensive ECO-ROOF systems are much lighter than Intensive and are available for application to Timber and Metal decks as lightweight green roof solutions.

Sedum mats are supplied with a selection of sedum plants including Lydium, Hybrium, Album, Acre, Reflexum, Sexangulare and Spurium which are already cultivated on to a root retention/ substrate layer. The varieties are carefully selected to provide colour and variety throughout the year and offer an ‘instant greening’ of the roof finish. The root retention/ substrate comprises a coir-backed membrane with polypropylene mesh for strength, crushed lava rock and specially formulated soil compound. NB: Sedum blankets require the minimum of long-term maintenance.

Typical System build up o Cefil high bond roof primer

o Cefil glass fibre 2mm polymer modified bituminous vapour control layer, applied by torch on method (alternative self adhesive available)

o Cefil eco-therm RV, CFC, HCFC free and Zero Ozone depletion rated Rigid urethane Insulation, bonded in Cefil adhesive (Insulation thickness to suit required thermal value).

o Cefil RP150, High quality BBA certified synthetic waterproofing membrane and complementary fixings.

o Cefleece 3g - non woven polyester fleece, loose laid

o Cedrain - Drainage and reservoir board - loose laid

o Cefilter - geotextile filtration layer, loose laid

o Multi layered fertile extensive soil mix (approx 80- 120mm)

o Sedum and plant variety mix to suit project location and requirements

o

Exa

_mpl

e of

e

x

ten

s

i

v

e ro

of

sy

s

t

em

ROOFING

Informative Section

(28)

Intensive

System Description

Green roofing with a deep growing medium which can sustain Plants, shrubs, planters, trees, paving and turf. Intensive ECO-ROOF requires artificial irrigation and should be treated like any garden with regular maintenance and care. The Intensive ECO-ROOF solutions are the heavier of the two systems due to soil depth and therefore extra structural design is required to sustain the saturated weight and imposed loadings to a building.

Typical System build up o Cefil high bond roof primer

o Cefil glass fibre 2mm polymer modified bituminous vapour control layer, applied by torch on method (alternative self adhesive available)

o Cefil eco-therm RV, CFC, HCFC free and Zero Ozone depletion rated Rigid urethane Insulation, bonded in Cefil adhesive (Insulation thickness to suit required thermal value).

o Cefil RP150, High quality BBA certified synthetic waterproofing membrane and complementary fixings.

o

ROOFING

(29)

Cefil synthetic roofing systems have been used extensively through specification

via architects or as the product of choice for building owners, main contractors and

specialist roofing contractors. This is a small selection of successfully completed

projects that are protected with Cefil waterproofing roof systems.

Project

Porfolio

(30)

ROOFING

Project Porfolio

PROJECT MATERIAL USED YEAR OF SYSTEM USED QUANTITY USED

APPLICATION

Group of Houses in Den Haag Cefil RP 1,2 1997 Mechanically fixing 4.000 mt2

(Netherlands)

“Barones” Commercial Center, Cefil RP 1,2 1.995 Mechanically fixing 6.000 Mt2

Breda (Netherlands)

“Franklin” Industrial Pavillion, Cefil RP 1,5 1.998 Mechanically fixing 12.000 Mt2

Dortmund (Germany)

“Tulip” Head Quarters, Cefil RP 1,2 1.997 Mechanically fixing 5.000 Mt2

Utritch (Netherlands)

“Chasse” Theater, Cefil RP 1,2 1.994 Mechanically fixing 9.000 Mt2

Breda (Netherlands)

Offices Building Rotterdam Cefil RP 1,5 2.000 Mechanically fixing 4.000 Mt2

(Netherlands)

“Sittard” Station, Cefil RP 1,5 2.001 Mechanically fixing 2.000 Mt2

Breda (Netherlands)

Topsport Stadium, Cefil RP 1,2 2.002 Mechanically fixing 8.000 Mt2

Den Haag (Netherlands)

Eroski, Cefil RP 12 2.002 Mechanical systems 14.000 Mt2

Abadiño, Spain

Olympic Swimming Pool for Cefil DW RP 1,5 2.003 Mechanically fixing 6.000 Mt2

the World Championship, Buildt in 3 weeks

Barcelona, Spain New system that allows

to insert a swimmingpool in a Multisports Stadium

“La Roca Village” Commercial Center, Cefil RV 1,5 2.003 Ballasted roof 7.500 Mt2

Barcelona, Spain

Palacio de Exposiciones y Congresos Cefil RV 1,2 2.001 Ballasted roof 8.000 Mt2

de Merida, Merida, Spain

Control Points. Barajas Airport Cefil RV 1,2 Grey 2.003 Ballasted roof 12.500 Mt2

Madrid, Spain

“Ciudad de las Artes y las Ciencias” Cefil RV 1,2 2.000 Ballasted roof Parking 9.000 Mt2

Valencia, Spain

Bilbao Exhibition Center Cefil T 150 Transparent 2.002/2.003 Foundations 50.000 Mt2

(31)

ROOFING

Cefil roof assured

Warranty Schemes

Cefil Roof Assured Warranty Schemes

are available for all installations and

pro-vide specifiers and building owners with

comprehensive cover and peace of mind to

back their judgement in selecting a Cefil

Waterproofing Solution.

(32)

(33)

The ultimate Mercedes Benz experience

Mercedes Benz world is the UK’s largest automotive brand experience centre. Located at Surrey’s world famous

Brooklands circuit, the birthplace of British Motorsport and Aviation, this impressive destination offers visitors

simula-tor rides, interactive challenges, enthralling exhibits and the opportunity to drive high performance Mercedes-Benz

vehicles around 2.5km of handling circuits. Over 10,000m2 of Cefil synthetic membranes were selected to provide the

waterproofing solutions to this prestigious project.

Where beauty and knowledge intertwine

The Valencia City of Arts and Science is a futuristic ‘city within a city’ and demonstrates some of Europe’s most awesome

architectural achievements. The breathtaking structures are home to the science museum, oceanarium, planetarium

and opera house and attract millions of visitors every year. Cefil waterproofing membranes were chosen for the

(34)

(35)

(36)

Cefil

RESERVOIRS

Cefil reservoirs (calandered non-reinforced) membranes suitable for waterproofing reservoirs and ponds, even in contact with drinking water.

o Outdoors quality

o PVC membrane, not reinforced, 1,2 mm thickness, outdoors quality, for waterproofing the bottom area of the pond.

o PVC membrane, polyester reinforced, 1,2 mm thickness, outdoors quality, to be placed in the slopes and deck areas.

CEFIL RESERVOIRS

*Note: Colour range listed is normally on stock, alternative colours and thicnesses including White, Blue, Red, Beige and Green are available subject to extended lead time and

“N” AENOR

(mm) (M) CE MARKING

Cefil RP Grey or Blue 1,2 2 Yes Polyester Net Yes Cefil RP Grey or Blue 1,5 2 Yes Polyester Net Yes

Cefil SR Grey or Blue 1,2 2 Yes No Yes

Cefil SR Grey or Blue 1,5 2 Yes No Yes

Cefil DW

Grey 1,2 2 Yes No Yes

(37)

Cefil RP

120

Description:

Flexible sheet of PVC flexible, 1.2 mm of thickness, with polyester reinforcement included. As requiered, microorganisms resistant.

Application:

Geosynthetic barriers. Useful for outdoor applications. It has got CE marking certificate corresponding to UNE EN 13361, (nº 0099/CPD/ A86/0006), and also N mark of quality product given by AENOR (nº 001/004669).

Cefil

RESERVOIRS

CEFIL RESERVOIRS

Width (mm) UNE EN ISO 426 Máx. 2000 Nom. -0.5,+1%

Tensile strength (N/50 mm) EN 12311-2 L,T = 1000 MLV

Tear resistance (N) EN 12310-2 L,T = 250 MLV

Interlaminar adhesion (N/50 mm) UNE EN ISO 527-1 L,T = 100 MLV

Dimensional stability (%) UNE 104302 0.2 MLV

Static puncture (N) EN ISO 12236 1500 MLV

Wheatering resistance (3000 hours) EN 12224 15 ≤ 25%

Oxidation (%) (85ºC, 90 days) EN 14575 15 ≤ 25%

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 Shear resistance (N/50 mm) EN 12317-2 500 Foldability at low temperature (-30ºC) EN 495-5 No cracks

--Colours:

(38)

Cefil RP

150 AZ

Description:

Flexible sheet of PVC flexible, 1.5 mm of thickness, with polyester reinforcement included. As requiered, microorganisms resistant.

Application:

CEFIL RESERVOIRS

Width (mm) UNE EN ISO 426 Máx. 2000 Nom. -0.5,+1%

Tensile strength (N/50 mm) EN 12311-2 L,T = 1000 MLV

Tear resistance (N) EN 12310-2 L,T = 250 MLV

Dimensional stability (%) UNE 104302 0.2 MLV

Wheatering resistance (3000 hours) EN 12224 15 ≤ 25%

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 Shear resistance (N/50 mm) EN 12317-2 500 Foldability at low temperature (-30ºC) EN 495-5 No cracks

--Colours:

(39)

Cefil SR

120 AZ

Description:

Flexible sheet of PVC flexible, 1.2 mm of thickness, without any reinforcement included. As requiered, microorganisms resistant.

Application:

CEFIL RESERVOIRS

Width (mm) UNE EN ISO 426 Máx. 2.000 -0.5,+1%

Wheatering resistance (3000 hours) EN 12224 15 ≤ 25 %

Oxidation (%) (85ºC, 90 days) EN 14575) 15 ≤ 25 %

Joint strength: Peel resistance (N/50 mm) EN 12316-2 250 MLV Shear resistance (N/50 mm) EN 12317-2 600 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV

Colours:

(40)

Cefil SR

150 AZ

Description:

Flexible sheet of PVC flexible, 1.5 mm of thickness, without any reinforcement included. As requiered, microorganisms resistant.

Application:

CEFIL RESERVOIRS

Thickness (mm) UNE 53.213-2 1.5 -5,+10%

Width (mm) UNE EN ISO 426 Máx. 2.000 -0.5,+1%

Wheatering resistance (3000 hours) EN 12224 15 ≤ 25 %

Oxidation (%) (85ºC, 90 days) EN 14575) 15 ≤ 25 %

Joint strength: Peel resistance (N/50 mm) EN 12316-2 250 MLV Shear resistance (N/50 mm) EN 12317-2 600 MLV Foldability at low temperature (- 30º C) EN 495-5 No cracks MLV

Colours:

(41)

Cefil DW

120 GREY

Description:

Soft PVC membrane of 1.2 mm of thickness, without any reinforcement included. Useful for contact with drinking water.

Application:

Building of drinking water recervoirs (outdoors aplications). It has got CE marking certificate corresponding to UNE EN 13.361 Normative, (nº 0099/CPD/A86/0006), and also N mark of quality product given by AENOR. Global migration according to european standard 96/11/CEE for materials in contact to drinking water.

CEFIL RESERVOIRS

Thickness (mm) UNE 53.213-2 1.2 Nom. 1.2,±10%

Width (mm) UNE EN ISO 426 Nom. ± 1% Nom. ± 1%

Tensile strenght (MPa) EN 12311-2 L= 18, T= 16 L,T≥ 15

Elongation at break (%) EN 12311-2 350 L,T≥ 250

Tear resistence (N) EN 12310-2 L= 70, T= 65 L≥ 60, T≥50 Adherence between layers (N/50 mm) UNE EN ISO 527-1 L,T = 100 L,T≥90

Dimmensional stability (%) UNE 104302 L,T= 1.5 ≤ 2

Cold bending (-20ºC) EN 495-5 Whithout cracks Whithout cracks

Exposure to uv radiation (3.000 hours) EN 12224 15 ≤ 25%

Statiic puncture test EN ISO 12236 1500 MLV

Joint strength: Peel resistance (N/50 mm) EN 12316-2 200 Shear resistance(N/50 mm) EN 12317-2 500

(42)

(43)

(44)

Cefil

ALL THE POSSIBILITIES

CHARACTERISTICS

CEFIL T membranes offer the following advantages: Variety of range:

CEFIL T membranes are offered in transparent and black (inc. yellow signal layer) finishes. The thickness of the membranes are 1,5 and 2 mm ,fulfilling the European Regulations.

Guarante:

Due to the certified quality of our membranes, we offer in our range a self-life guarantee of 10 years.

Service:

Our policy for customer service is reflected in that delivery terms are adapted to the needs of every project

Quality:

Our membranes have been certified not only in the Spanish but also in several European markets.

TUNNELS

CEFIL T membranes offer easy solutions to complex problems for every tunnel waterproofing system as well as channels and civil engineering

TENSILE

PRODUCT COLOUR THICKNESS WIDTH % ELONGATION STRENGTH CE MARKING FUNGICIDE

(mm) (M) MPa TREATMENT

Cefil T SIGNAL Yellow / Black 1,5 2 250 15 Yes No Cefil T SIGNAL Yellow / Black 2 2 250 15 Yes No

Cefil T SIGNAL ELO Yellow / Black 1,5 2 300 15 Yes No Cefil T SIGNAL ELO Yellow / Black 2 2 300 15 Yes No

Cefil T TRANS Transparent 1,5 2 350 15 Yes No

Cefil T TRANS Transparent 2 2 350 15 Yes No

Cefil T TRANS FUNG Transparent 1,5 2 350 15 Yes Yes Cefil T TRANS FUNG Transparent 2 2 350 15 Yes Yes

(45)

Cefil T

SIGNAL Yellow-Black

Description:

Flexible sheet of PVC flexible. Not resistant to bitumen.

Application:

Geosynthetic barriers. Used as a fluid barrier in the construction of tunnels and underground structures. It has got CE marking certificate corresponding to UNE EN 13491, (nº 0099/CPD/A86/006),.

Cefil

ALL THE POSSIBILITIES

TUNNELS

ESPECIFICATION

Thickness (mm) EN 1849-2 ≥1.2 MLV

Nom. -5,+10%

Width (mm) EN 1848-2 1000-2000 Not applies

Nom. -0.5,+1%

Flatness (mm) EN 1848-2 ≤ 5 Not applies

Straightness (mm) EN 1848-2 ≤ 25 Not applies

Tensile strength (N/50 mm) EN 12311-2 L,T≥ 15 MLV

Elongation (%) EN 12311-2 L,T ≥ 250 MLV

Tear resistance (N) EN 12310-2 L,T ≥ 220 MLV

Interlaminar adhesion (N/50 mm) UNE EN ISO 527-1 L,T ≥ 90 Not applies Dimensional stability (%) EN 1107-2 ≤ 2.0 Not applies Joint strength: Peel resistance (N/50 mm) EN 12316-2 ≥ 200 Not applies Shear resistance(N/50 mm) EN 12317-2 ≥ 500 Not applies

Static puncture test (KN) EN 12236 ≥ 2.2 MLV

Resistance to oxidation (85ºC, 90 days) EN 14575 ≤ 15% ≤ 25% (loss of mechanical properties)

Foldability at low temperature EN 495-5 No cracks Pass

≤ - 20º C

Resistance to root penetration EN 13948 Pass MLV

(46)

TUNNELS

Description:

Application:

Geosynthetic barriers. Used as a fluid barrier in the construction of tunnels and underground structures. It has got CE marking certificate corresponding to UNE EN 13491, (nº 0099/CPD/A86/006). Maximum elongation.

ESPECIFICATION

Nom. -5,+10%

Width (mm) EN 1848-2 1000 - 2000 Not applies

Nom. -0.5,+1%

Tensile strength (N/50 mm) EN 12311-2 L,T ≥ 16 MLV

≤ - 20º C

Waterproof resistance (72 hours, 4 bar) DIN 16726-5.11 Waterproof Waterproof

Cefil T

(47)

Cefil T

TRANSPARENT

Description:

Application:

Geosynthetic barriers. Used as a fluid barrier in the construction of tunnels and underground structures. It has got CE marking certificate corresponding to UNE EN 13491, (nº 0099/CPD/A86/006),.

TUNNELS

ESPECIFICATION

Nom. -5,+10%

Nom. -0.5,+1%

≤ - 20º C

(48)

TUNNELS

Description:

Flexible sheet of PVC flexible. Not resistant to bitumen. Resistant to contact with microorganisms.

Application:

Geosynthetic barriers. Used as a fluid barrier in the construction of tunnels and underground structures. It has got CE marking certificate corresponding to UNE EN 13491, (nº 0099/CPD/A86/006).

Cefil T

TRANSPARENT FUNG

ESPECIFICATION

Nom. -5,+10%

Nom. -0.5,+1%

≤ - 20º C

Waterproof resistance (72 hours, 4 bar) DIN 16726-5.11 Waterproof Waterproof

(49)

List of References

TUNNELS

Description:

Application:

Geosynthetic barries. Used as a fluid barrier in the construction of tunnels and underground structures. It has got CE marking certifi-cate corresponding to UNE EN 13491, (nº 0099/CPD/A86/006),.

PROJECT MATERIAL USED YEAR OF QUANTITY USED

APPLICATION

Tunnel of High Speed Train Cefil T 200 2.000 120.000 mt2

Tarragona (Spain)

Tunnel of High Speed Train in Oroso Cefil T 200 1.999 82.000 Mt2

(Spain)

Tunnel of Villaviciosa Cefil RP T 200 2.001 240.000 Mt2

(Spain)

Tunnel of High Speed Train Cefil T 200 2.003 145.000 Mt2

Matorell (Spain)

Tunnel Piedrafita Cefil T 200 2.000 65.000 Mt2

(Spain)

Tunnel Ave Alora-Malaga Cefil T 300 2.003 70.000 Mt2

(Spain)

Tunnel del Pino Cefil T 150 2.004 5.000 Mt2

Nerja-Almuñecar (Spain)

Bilbao Metro (Line B) Cefil T 200 2.002 25.000 Mt2

Bilbao (Spain)

Tunnel of Bierzo -- 1.997 20.000 Mt2

(Spain)

Tunnel of Mejorada -- 1.999 17.000 Mt2

(50)

Edicar Plasticos

manufacturing process

We make use of the most avanced technology

At Edicar Plasticos SL we are aware of the needs for

continuous improvement in our equipment. That is

why we follow a policy for progressive renivation

which allows us to maintain a leading position in

the market. For such aim we have sophisticated

equipment, incluiding 2 calenders, 2,10m wide, with

the most advanced technology.

They allow us to manufacture up to 20.000 tones/year

with the highest quality.

We believe quality is not controlled but produced.

That is why, from the reception of the raw materials,

(51)

Following this idea, our CEFIL materials, used for

waterproofing applications, are approved by AENOR

Spanish Certification Association and European

prestigious institutes such as BDA, KOMO or SKZ among

others, focusing this product line internationally.

Edicar Plasticos

approved quality

(52)
