1. Introduction

This blog is based on my experience in one of the projects that I have worked sometime ago!!!. It describes how to configure SAP Enterprise Portal to point to multiple backend clients in ESS/MSS scenarios.

Within EP 7.0 / ESS MSS 600, Web Dynpro ESS/MSS package is pre-configured by default for a unique Logical System. This causes severe restrictions in a multi-client environment.

2. Business Scenario

To support provider’s shared methodology, it must be possible to maintain ESS/MSS landscape in a manner that allows multiple customers to be implemented within multiple clients on the same system with a unique Portal. Below scenario shows a portal pointing to multiple clients from the same backend system containing ESS/MSS scenarios. It is a pre-requisite that the usernames in backend clients and portal should be the same. In this scenario, the users logged in to portal are able to access the backend using SSO logon tickets. And also, a Central User Administration (CUA) as to be implement in the landscape, one system or one client can dedicated for

ESS MSS Multi-Client Configuration - Part1

(2)

(3)

as well as the backend like setting up JCo, System landscape, ADS and so on. The entire set of standard configurations can be found here:

http://help.sap.com/saphelp_erp2005/helpdata/en/f6/263359f8c14ef98384ae7a2becd156/frameset.htm

4. Multi-Client Configuration Information

This document assumes that all the ESS/MSS scenarios are working for a single backend client (e.g.: 100). In the following steps we will configure the portal to point to a new client (200)

5. Implementation Multi-client steps

5.1 Set up JCo Destinations

Various JCo connections are already setup for client 100 on the Web Dynpro J2EE server on which the self-service components have been implemented. To create a new set of JCo connections for client 200, implement the steps provided in the following URL and ensure that the parameter for property ‘client’ is provided as 200: Suffix “CL2” with

(4)

the name as shown in below screenshot.

http://help.sap.com/saphelp_erp2005/helpdata/en/ca/115e4088dc0272e10000000a155106/content.htm

5.2 Business Package copy for the new client

The default downloaded ESS/MSS Business Package will be paced under:

Portal Content > Content Provided by SAP > End User Content > Employee Self-Service. Portal Content > Content Provided by SAP > line_manager > Manager Self-Service.

(5)

4/22/2014 ESS MSS Multi-Client Configuration - Part1 | SCN useSys=SAP_R3_Financials:CL2&sap-wd-arfc-useSys=SAP_R3_Financials_MetaData:CL2&sap-wd-arfc- useSys=SAP_R3_HumanResources:CL2&sap-wd-arfc- useSys=SAP_R3_HumanResources_Metadata:CL2&sap-wd-arfc- useSys=SAP_R3_HumanResources_MetaData:CL2&sap-wd-arfc- useSys=SAP_ECC_HumanResources:CL2&sap-wd-arfc-useSys=SAP_R3_SelfServiceGenerics:CL2&sap-wd- arfc-useSys=SAP_R3_SelfServiceGenerics_MetaData:CL2&sap-wd-arfc- useSys=SAP_R3_SelfServiceGenericsFIN:CL2&sap-wd-arfc- useSys=SAP_R3_SelfServiceGenerics_MetaDataFIN:CL2&sap-wd-arfc-useSys=SAP_R3_Travel:CL2&sap-wd- arfc-useSys=SAP_R3_Travel_MetaData:CL2&sap-wd-arfc-useSys=WD_MODELDATA_DEST:CL2&sap-wd- arfc-useSys=WD_RFC_METADATA_DEST:CL2&sap-wd-arfc- useSys=WD_RSDAS_MODELDATA_DEST:CL2&sap-wd-arfc-useSys=WD_RSDAS_RFC_METADATA_DEST:CL2

5.2.1 ‘Application Parameters’ property for newly copied Business Package

If ‘Multiple Property Replacement’ was not used to provide Application Parameter for iviews, navigate to the iviews belonging to e.g. client 200 Business Package and provide the Application Parameters that point to the newly created JCo connections (client 200) manually. This value will change as per the JCo Destinations created in the system, for each client.

Here is an example of a complete Iview Application Parameter:

sap-wd-arfc-useSys=SAP_BPS:CL2&sap-wd-arfc-useSys=SAP_BPS_MetaData:CL2&sap-wd-arfc- useSys=SAP_cProjects:CL2&sap-wd-arfc-useSys=SAP_cProjects_MetaData:CL2&sap-wd-arfc- useSys=SAP_ECC_Financials:CL2&sap-wd-arfc-useSys=SAP_ECC_Financials_MetaData:CL2&sap-wd-arfc- useSys=SAP_R3_Financials:CL2&sap-wd-arfc-useSys=SAP_R3_Financials_MetaData:CL2&sap-wd-arfc- useSys=SAP_R3_HumanResources:CL2&sap-wd-arfc-useSys=SAP_R3_HumanResources_Metadata:CL2&sap- wd-arfc-useSys=SAP_R3_HumanResources_MetaData:CL2&sap-wd-arfc- useSys=SAP_ECC_HumanResources:CL2&sap-wd-arfc-useSys=SAP_R3_SelfServiceGenerics:CL2&sap-wd-arfc-

(6)

useSys=SAP_R3_SelfServiceGenerics_MetaData:CL2&sap-wd-arfc-

useSys=SAP_R3_SelfServiceGenericsFIN:CL2&sap-wd-arfc- useSys=SAP_R3_SelfServiceGenerics_MetaDataFIN:CL2&sap-wd-arfc-useSys=SAP_R3_Travel:CL2&sap-wd-arfc- useSys=SAP_R3_Travel_MetaData:CL2&sap-wd-arfc-useSys=WD_MODELDATA_DEST:CL2&sap-wd-arfc- useSys=WD_RFC_METADATA_DEST:CL2&sap-wd-arfc-useSys=WD_RSDAS_MODELDATA_DEST:CL2&sap-wd-arfc-useSys=WD_RSDAS_RFC_METADATA_DEST:CL2

5.3 Set up Systems / Aliases

Navigate to System Administration > Portal Content > and define a new system object that points to client 200. Please note that already a system object should be available for client 100. It is simple to make a copy of the same and point the new one to client 200. (as seen in below screenshot). Also change the name of the system object. (E.g: SAP_ECC_BP3_CL2).

(7)

5.4 UWL Configuration

Navigate to System Administration > Universal Worklist & Workflow > Universal Worklist – Administration. Here you can define connections to systems as item providers for the Universal Worklist. Add the newly created system alias here (as mentioned in the screenshot below).

Please note that ‘WebDynpro Launch System’ is the system alias of the system which contains the Web Dynpro ESS/MSS Business Packages. Usually it will be the same system as the Portal. So this system alias (as per above

(8)

screenshot example: WebDynpro_XSS) refers to the Enterprise Portal system which contains the deployed Web Dynpro ESS/MSS applications.

In Order to restrict access to the corresponding Universal Worklist System, we need to register each system with a specific System Configuration Group, to make it easier we will use the name, ie SAP_WebDynpro_XSS for client 100, SAP_WebDynpro_XSS_CL2 for 200…

http://help.sap.com/saphelp_nw70/helpdata/EN/92/a88931f2dd4631b9e8d530697d89c9/frameset.htm

Then restrict the role to use the corresponding System Configuration Group:

(9)

(10)

Set the value(SAP_WebDynpro_XSS) for the parameter ‘System Configuration Group’. Above screenshot is for client 100.

For Client 200, open the ‘Manager Self Service’ role from the below path and set the value (SAP_WebDynpro_XSS_CL2)

(11)

5.5 PCD Location Replication in SPRO

The PCD location of ESS/MSS client 200 iviews should be the same as the resource attribute ‘URL of PCD Page’ in SPRO. To make these two configurations point to the same URL, navigate to any iview belonging to the ESS/MSS client 200 Business Package. Open the iview object and copy the url from ‘PCD location’.

After copying the URL, open the backend system SPRO configurations for ESS from SAP logon and open the resource object that corresponds to the particular iview e.g:

EMPLOYEE_CHANGEOWNDATA_SERVICE05. Paste the url at ‘URL of PCD Page’ and save. (Refer to screenshot below):

(12)

5.6 XML Configuration upload for UWL

For the PCRs of different clients to work in Portal, we need to upload a custom xml file with Jco parameters specific to the client.

Navigate to System Administration > Universal Worklist & Workflow > Universal Worklist – Administration. Click on the link – ‘Click to Administrate Item Types and View Definitions’. Here, you can upload a new configuration xml with nodes pointing to specific tasks in swfvisu (backend table). In this configuration, we pass a <dynamicparameter> property with the value of Jco pointing to the desired client. An example is provided below.

(13)

4/22/2014 ESS MSS Multi-Client Configuration - Part1 | SCN <Actions>

<Action name="launchWebDynPro" groupAction="" handler="SAPWebDynproLauncher" returnToDetailViewAllowed="yes" launchInNewWindow="yes"

launchNewWindowFeatures="resizable=yes,scrollbars=yes,status=yes,toolbar=no,menubar=no,location=no,directories=no"> <Properties>

<Property name="WebDynproDeployableObject" value="sap.com/pcui_gp~isr"/> <Property name="newWindowFeatures"

value="resizable=yes,scrollbars=yes,status=yes,toolbar=no,menubar=no,location=no,directories=no"/> <Property name="DynamicParameter" value="sap-wd-arfc-useSys=SAP_R3_SelfServiceGenerics:CL2"/> <Property name="openInNewWindow" value="yes"/>

</Actions> </ItemType>

5.7 ‘IView – Resource Key Mapping’ to change PCD Location

Below is the example of iview list with the corresponding service key in spro. The ‘PCD location’ parameter of these iviews and the related service keys should be the same.

ESS:

Benefits and Payment

Benefits and Payment EMPLOYEE_BENEFITPAY_ERP2005_PAG Benefits Participation EMPLOYEE_BENPARTICIPATION_SERVICE05 Enrollment EMPLOYEE_GENERICENROLLMENT_SERVICE05

Paycheck Inquiry Service EMPLOYEE_PAYCHECK_SERVICE05 Print Enroll EMPLOYEE_GENERICENROLL_PRINT_SERVICE05 Total Compensation EMPLOYEE_TOTALCOMP_SERVICE05

Deferred Compensation (Country) EMPLOYEE_DEFERREDCOMP_SERVICE05 Net Calculation (Country) EMPLOYEE_NETCALCULATION_SERVICE05 Semiretirement (Country) EMPLOYEE_SEMIRETIREMENT_SERVICE05 Valueentitle (Country) EMPLOYEE_VALUEENTITLE_SERVICE05

Career and Job

Candidate Applications EMPLOYEE_CANDIDATE_APPLICATIONS_SRV05 Career and Job EMPLOYEE_CAREER_PAG

(14)

Data Overview EMPLOYEE_CANDIDATE_DATA_OVERVIEW05 Direct Service EMPLOYEE_CANDIDATE_DIRECT_APPL_SERVICE05 Job Favorites EMPLOYEE_CANDIDATE_FAVORITES_SERVICE05 Personal Settings EMPLOYEE_CANDIDATE_PERSONAL_SETTINGS05 Profile Release EMPLOYEE_CANDIDATE_PROFILE_RELEASE0 Profile Service EMPLOYEE_CANDIDATE_PROFILE_SERVICE05 Search Jobs EMPLOYEE_CANDIDATE_SEARCH_JOBS_SERVICE05 Skills Profile EMPLOYEE_SKILLSPROFILE_SERVICE05

Corporate Information

Code of Conduct Application EMPLOYEE_CORPORATE_CONDUCT_SERVICE05 Corporate Information EMPLOYEE_CORPORATEINFO_ERP2005_PAG

Employee Search

Change Own Data EMPLOYEE_CHANGEOWNDATA_SERVICE05 Employee Search EMPLOYEE_SEARCH_ERP2005_PAG

OrgChart EMPLOYEE_ORGCHART_SERVICE05 Who Is Who EMPLOYEE_WHOISWHO_SERVICE05

Life and Work Events

Benefits (Country) EMPLOYEE_LIFEWORK_BENEFITS_SERV_US

Birth of Child (Country) EMPLOYEE_LIFEWORK_BIRTHCHILD_DE_SERVICE Birth/Adoption (Country) EMPLOYEE_LIFEWORK_BIRTH_SERV_US

Change Employment Status EMPLOYEE_LIFEWORK_CHANGESTATUS_SERV_US Divorce EMPLOYEE_LIFEWORK_DIVORCE_SERV_US

Life and Work Events EMPLOYEE_LIFEWORKEVENTS_ERP2005_PAG Marriage EMPLOYEE_LIFEWORK_MARRIAGE_SERV_US

Maternity Leave EMPLOYEE_LIFEWORK_MATLEAVE_DE_SERVICE My First Days EMPLOYEE_LIFEWORK_FIRSTDAYS_SERV_US

Terminate Employment EMPLOYEE_LIFEWORK_TERMINATEEMP_SERV_US Termination EMPLOYEE_LIFEWORK_TERMINATION_DE_SERVICE

(15)

Purchasing

Purchasing EMPLOYEE_PURCHASING_ERP2005_PAG

Travel and Expenses

Cancel Trip EMPLOYEE_TRAVEL_CANCELTRIP_SRV05

Create Expense report EMPLOYEE_TRAVEL_EXPENSES_SRV05 Create Travel Plan EMPLOYEE_TRAVEL_PLANNING_SRV05 Create Travel Request EMPLOYEE_TRAVEL_REQUEST_SRV05

Delete Expense Report EMPLOYEE_TRAVEL_EXPENSES_DELETE_SRV05 Delete Travel Request EMPLOYEE_TRAVEL_REQUEST_DELETE_SRV05 Display Trip Form EMPLOYEE_TRAVEL_TRIPFORM_SRV05

My Alerts EMPLOYEE_TRAVEL_MYALERTS_SRV05

My Credit Card Receipts EMPLOYEE_TRAVEL_CCIMPORT_SRV05 My Travel Profile EMPLOYEE_TRAVEL_PROFILE_SRV05

My Trips and Expenses EMPLOYEE_TRAVEL_ALLMYTRIPS_SRV05 Personalize Data EMPLOYEE_TRAVEL_PERSONALIZATION_SRV05 Route Planning EMPLOYEE_TRAVEL_ROUTING_SRV05

Switch Personnel Number EMPLOYEE_TRAVEL_CHANGE_PERSNO_SRV05 Travel and Expenses EMPLOYEE_TRAVEL_ERP2005_PAG

Travel Information EMPLOYEE_TRAVEL_COMPANYTIP_SRV05

Unlock Personnel Number EMPLOYEE_TRAVEL_UNLOCK_PERSNO_SRV05

Work Environment

Equipment Monitor EMPLOYEE_EQUIPMENTCARD_SERVICE05 Work Environment EMPLOYEE_WORKENVIRONMENT_ERP2005_PAG

Working Time

Clock-In/Out Correction EMPLOYEE_TIMECORRECTION_SERVICE05 Leave Request EMPLOYEE_LEAVEREQUEST_SERVICE05

Leave Request: Approval EMPLOYEE_LEAVEREQUESTAPPROVER_SERVICE05 Record Working Time EMPLOYEE_RECORDWORKTIME_SERVICE05

Release Working Time EMPLOYEE_RELEASEWORKTIME_SERVICE05 Time Accounts EMPLOYEE_WORKTIME_EFFREPORTING_DISPLAY05 Time Statement EMPLOYEE_TIMESTATEMENT_SERVICE05

Time Statement, Periodic EMPLOYEE_TIMESTATEMENTPER_SERVICE05 Overview EMPLOYEE_WORKTIME_ERP2005_PAG

Certify Actual Effort (Country) EMPLOYEE_WORKTIME_EFFREPORTING_CERTIFY05 Change Effort plan (Country) EMPLOYEE_WORKTIME_EFFREPORTING_CHANGE05 Create Effort plan (Country) EMPLOYEE_WORKTIME_EFFREPORTING_CREATE05

(16)

Display Effort plan (Country) EMPLOYEE_WORKTIME_EFFREPORTING_DISPLAY05 MSS:

Record Working Time MSS_HCM_SERV_RELACTIVITY_ESS_CA

Clock-In / Out Corrections MSS_HCM_SERV_RELACTIVITY_ESS_WTCOR Total Compensation Statement MSS_HCM_SERV_RELACTIVITY_ESS_TCS Personal Data MSS_HCM_SERV_RELACTIVITY_ESS_PDATA_DE

Addresses MSS_HCM_SERV_RELACTIVITY_ESS_ADDR_DE Bank Information MSS_HCM_SERV_RELACTIVITY_ESS_BANK_DE

Family Members / Dependents MSS_HCM_SERV_RELACTIVITY_ESS_FAM_DE Skills Profile MSS_HCM_SERV_RELACTIVITY_ESS_SKL

Trips and Expenses MSS_HCM_SERV_RELACTIVITY_ESS_TRA_EXP Credit Card Receipts MSS_HCM_SERV_RELACTIVITY_ESS_TRA_CRE Create Travel Request MSS_HCM_SERV_RELACTIVITY_ESS_TRA_REQ Create Travel Plan MSS_HCM_SERV_RELACTIVITY_ESS_TRA_PLAN Travel Profile MSS_HCM_SERV_RELACTIVITY_ESS_TRA_PROF Start Processes MSS_HCM_SERV_RELACTIVITY_START_PROCESSES Search Processes MSS_HCM_SERV_RELACTIVITY_SEAR_PROCESSES

5.8 Leave Request specific setup Multi-client

Below is the process to setup the leave request approval process from the UWL in the new client. Existing configuration for Client 100

1. SAP standard workflow for Leave Request is WS12300111 which is already configured for client 100.The task TS12300097 is the approver step in the workflow template WS12300111. This approver step is configured in the transaction SWFVISU in the backend in client 100 as follows.

(17)

New configuration for Client 200

(18)

transaction PFTC.

Copy the task TS12300097 for ex: TS99900140

Now Replace the task TS12300097 from Workflow WS99900235 with the new task TS99900140 Create a new entry in transaction SWFVISU with the task id TS99900140 as shown below:

(19)

(20)

5.9 Provide Relevant Portal Roles for the new Client

(21)

5.10.1 ISR Server URL

The ISR Server URL is client specific. This needs to be changed/created in the new client. ISR Server URL is

necessary to be maintained as this URL helps in displaying the created PCR form in the Action box of the HR Admin. Here are the steps to maintain the URL:

1. Go to transaction SM30. Enter view name V_ISRSERVER

2. Maintain an entry in view V_ISRSERVER as follows: Entry type in Web: “Entry Using Adobe PDF”

Server Call of ISR Forms: http://hostname:<port>/webdynpro/dispatcher/sap.com/pcui_gp~isr/

5.10.2 Maintain HR Admin for new client

HR Admin is needed as part of the PCR form approval process. The PCR form after the approval form the approving manager is sent to the HR Admin who updates the data from the form into the backend.

HR Admin is configured in the following path in SPRO:

Personnel Managementà Personnel Administration à Organizational Dataà Organizational Assignment à Define Administrator

(22)

(23)

Once the HR Admin is configured in the SPRO then this HR Admin is assigned to the employee in transaction PA30 infotype 0001 as shown in the below screen:

(24)

5.10.3 Pre-requisites

Ensure that the following forms are activated.

Time statement form activation:

ESS Path: ESSàWorking timeàTime Statement

When creating new client sometimes the smartforms used for “time statement” are inactive in the backend which needs to be activated. Here are the steps to activate the forms.

(25)

Following info types need to be maintained: 0003

0012 0012 0008

Once all the infotypes are maintained, and then execute the following report. SAP Easy Menu à HR à Payroll à Europe à Germany à Start Payroll.

Head Count / Head Count (FTE):

BI Reports that needs to be activated under MSS: MSS Path:

MSS à Overview à Team à Head count MSS à Overview à Team à Head count ( FTE )

Part 2 of this blog can be found at ESS MSS Multi-Client Configuration - Part2
