Mellanox Cloud and Database

Acceleration Solution over

Windows Server® 2012 SMB Direct

Increased Performance,

Scaling and Resiliency

July 2012

(2)



New class of enterprise file storage



Low latency, high throughout, low CPU overhead (50% lower versus Ethernet)



Fibre Channel replacement at a lower cost and higher performance



Leverages Windows Server 2012 integrated Mellanox Ethernet and InfiniBand RDMA



Accelerates Microsoft HyperV-SMB and SQL-SMB solutions

Microsoft Windows Server 2012 and SMB Direct

File Client File Server

SMB Client User Kernel Disk RDMA Adapter Network w/ RDMA support RDMA Adapter

*Preliminary results based on Windows Server 2012 RC

SMB Server Network w/ RDMA support NTFS SCSI Application

(3)



Remote Direct Memory Access Protocol

• Accelerated IO delivery model which works

by allowing application software to bypass most layers of software and communicate directly with the hardware



RDMA benefits

• Low latency

• High throughput

• Zero copy capability

• OS / Stack bypass



Mellanox RDMA based Interconnects

• InfiniBand

• RoCE: RDMA over Converged Ethernet

(4)

SMB Direct over InfiniBand and RoCE

1.Application (Hyper-V, SQL Server) does not need to change.

2.SMB client makes the decision to use SMB Direct at run time

(5)

Mellanox End-to-End VPI Solution



Mellanox provides end-to-end InfiniBand and Ethernet

connectivity solutions (adapters, switches, cables)

• Connecting data center servers and storage



Up to 56Gb/s InfiniBand and 40Gb/s Ethernet per port

• Low latency, Low CPU overhead, RDMA

• InfiniBand to Ethernet Gateways for seamless operation



Windows Server 2012 exposes the great value of

Mellanox Interconnect Solution for storage traffic,

virtualization and low latency

• InfiniBand and Ethernet (with RoCE) integration

(6)

(7)

Microsoft Delivers Low-Cost Replacement to High-End Storage

FDR 56Gb/s InfiniBand delivers 5X higher throughput

with 50% less CPU overhead vs. 10GbE

(8)

File Client (SMB 3.0)

Measuring SMB Direct Performance in Virtualized

Environment

Single Server

(9)

SMB Direct Performance in Virtualized Environment

(10)



At least one node and storage always available, despite failure or

replacement of any component.



Dual power domains



Internal interconnect between nodes, controllers



Flexible PCIe slot for LAN options



External SAS ports for JBOD expansion



Office-level power and acoustics for entry-level NAS

Microsoft’s Cluster in the Box (CiB) Reference Design

Server Enclosure x4 SAS through midplane x4 SAS through midplane Additional JBODs … 1/10G Ethernet cluster connect B port s A port s x8 PCIe Server B Server A x8 PCIe x4 SAS External JBOD x8 PCIe x4 SAS x8 PCIe

Mellanox VPI Interconnect Solutions 10GbE, RoCE or InfiniBand

(11)



Remote Storage Systems



Windows Server 2012 with SMB 3.0



PCI Express 3.0 based Servers - HP DL380p G8



Mellanox 56Gb/s FDR InfiniBand adapters and switches

Products Announced: X-IO Storage

(12)



Hyper-V with Windows Server 2012 RC



Supermicro PCIe 3.0 based Servers, File Server & JBOD



LSI MegaRAID SAS 9285 storage controllers with LSI FastPath

I/O acceleration software



OCZ’s Talos 2R SSDs

Products Announced: Supermicro

(13)



Together with Microsoft we deliver 10X performance acceleration for

Remote File Server under physical or virtual environment that boosts next generation Cloud and database applications



The first time we demo record performance for remote file server under Hyper-V using 2 FDR ports that delivers more than 10GB/sec using less than 5% CPU overhead



Mellanox RDMA interconnect solution integrated with SMB Direct in Widows Server 2012 delivers the most cost effective solution for File Server

replacing FC and TCP/IP Ethernet.



Now with Microsoft and Mellanox integrated solution, remote file server delivers no less performance than native storage.



Customers already announced products using Mellanox RDMA enabled interconnect demonstrated extreme performance

Summary
