What s New? EXPANDED COMPETITIVE OFFERINGS LOOKING FOR PLENUM CABLES? ALARM & SECURITY SOLUTIONS SHEER WIRE PRODUCTS ARMORED ELECTRONICS PRODUCTS

(1)

(2)

(3)

Cross-Reference & Online Spec Sheets

We have expanded our Carol®_{Brand Electronics offering and now have more} competitive crosses than anyone. Many of these cables are in stock and ready for immediate shipment from one of our stocking distributors. For questions on any of the Carol Electronics cables, detailed spec sheets are now available online at www.generalcable.com/Products/Electronics/Product Specification Sheets.

Carol®_{Brand has added the Sheer Wire}™_{line of cable for Lighting Control & Touch} Panel Systems to its already expansive electronics offering. For more information, see page A2 or call 866-295-5896 today for your FREE Sheer Wire catalog.

What’s New?

E X P A N D E D C O M P E T I T I V E O F F E R I N G S

S H E E R W I R E

™

P R O D U C T S

The Carol®_{Electronics Catalog has been revamped, with Plenum Cables now} being featured in the Communications & Control Multi-Conductor and Multi-Paired sections. If you’re still not sure what you’re looking for, please contact our Customer Service associates at 866.295.5896 today!

L O O K I N G F O R P L E N U M C A B L E S ?

General Cable has increased the information in its Alarm & Security Solutions Guide, with the addition of Sheer Wire™_{Cables for Lighting Control & Touch} Panel Systems, Bundled Composite Access Control Cables, Command®_Series Home Entertainment Cables and our line of Carol®_{Brand Helix/Hi-Temp}®_Data Communications Cables. To view the updated guide, see pages 114-116 in the catalog.

A L A R M & S E C U R I T Y S O L U T I O N S

Carol Brand Electronics products are now offered with an interlock armored

A R M O R E D E L E C T R O N I C S P R O D U C T S

(4)

Carol

®

Brand Alarm & Security Solutions

Applications:

Lighting Controls Window Controls Audio Level Controls Video Controls

Computer/Internet Controls

Cable

Solution Description

1618SVA1 18/4 16/30 BC 20 AWG 10/30 + 16/1 PR 26/30 BC (UL) CL3R 1822AXL0 22/1PR 7/30 + 18/2 7/26 (UL) CL3R FT-4

1822CCD8 Touch Panel Composite: 1 Control Element + 2 5e Elements 1822CCT8 Touch Panel Composite: 1 Control Element + 2 5e Elements + 2 RG 6 1822CDC8 22C 5E: (1)I18/22CRT-89/04, (1)I181VQ6-09, I181VQ6-00, (2) Cat 5e

1822CRT8 Comp 4C 2E: 22/1PR 7/30 BC 24 AWG 7/32 TC Drain + 1/2C 7/26 BC (UL) CL3R 1822KYP1 Comp 4C 2E: 18/2C 16/30 BC + 22/1PR 7/30 BC Shielded

182LUTDS 18/2 7/26 BC PVC NYLON (UL) TC for Lutron Dimmer & Switch 184LUTDS 18/4 7/26 BC PVC Nylon O/A AM SHLD 20 AWG 7/36 TC Drain PVC 222LUTDS 22/2 7/30 BC PVC O/A AM SHLD 24 AWG 7/32 TC Drain PVC 164LTCH0 16/4 65/34 BC .012" PVC Lite Touch

224SLTCH 22/4 7/30 BC .015 PVC, O/A AM SHLD, 24 7/32 TC Drain/A 0.35 PVC Lite Touch EF24C0021000 24/2 Conductor Shielded Low Cap Type CMP

Sheer Wire™ Lighting Control and Touch Panel Systems

FREE COMPLETECall today for your

SHEER WIRE

™

CATALOG

1.866.295.5896

(5)

Product Section Locator

Section

PageS

1 Hook-Up Wire

1-7

2 communication & control cable, Multi-conductor

8-41

3 communication & control cable, Multi-Paired

42-66

4 computer cable

67-84

5 coaxial cable

85-112

6 Fire alarm/Life Safety cable

113-129

7 Sound, alarm & Security cable

130-145

8 audio/Video & Home entertainment cable

146-177

(6)

Section

PageS

1 Hook-Up Wire

1-7

UL 1007, UL 1569, CSA TR-64 ... 2

UL 1015, CSA TEW ... 3

MIL-W-76B ... 4

UL Types MTW, TFF, AWM & CSA TEW ... 5

Heavy Wall UL Types MTW, AWM & NEC Type THW ... 6

Rubber/PVC/Polyethylene ... 7

2 Communication & Control Cable, Multi-Conductor

8-41

Multi-Conductor, Unshielded ... 9-17

Multi-Conductor, Unshielded (CSA) ... 18-20

Multi-Conductor, Rubber, Unshielded ... 21

Power-Limited Tray Cable, Unshielded ... 22

Multi-Conductor, Foil Shield ... 23-28

Multi-Conductor, Foil Shield (CSA)... 29-31

Power-Limited Tray Cable, Foil Shield ... 32

Multi-Conductor, Spiral Shield ... 33

Multi-Conductor, Braid Shield ... 34-37

Multi-Conductor, Foil/Braid Shield ... 38

Multi-Conductor, Foil & TC Braid Shield ... 39

Multi-Conductor, Rubber, Braid Shield ... 40

Multi-Conductor, Carolprene

®

, Braid Shield ... 41

3 Communication & Control Cable, Multi-Paired

42-66

Multi-Paired, Unshielded ... 43-45

Multi-Paired, Foil Shield ... 46-52

Multi-Paired, Foil Shield (CSA) ... 53-54

Multi-Paired, Foil Shield, Mid-Cap ... 55

Multi-Paired, Foil Shield, Lo-Cap

®

... 56

Multi-Paired, Overall Foil & TC Braid Shield, Lo-Cap

®

... 57

Multi-Paired, Individually Shielded ... 58

(7)

table of contents

Section

PageS

4 Computer Cable

67-84

Multi-Conductor, Foil Shield ... 68-69

Multi-Conductor, Foil/Braid Shield ... 70-71

Multi-Conductor, Foil/Braid Shield, Lo-Cap

®

... 72

Multi-Paired, Foil Shield ... 73

Multi-Paired, Foil Shield, Lo-Cap

®

... 74

Multi-Paired, Foil/Braid Shield ... 75

Multi-Paired, Foil/Braid Shield, Lo-Cap

®

... 76-79

Multi-Paired, Individually Foil Shielded ... 80-82

Multi-Paired, Individually Foil Shielded, Lo-Cap

®

... 83

Multi-Paired, Individually Foil/Braid Shielded, Lo-Cap

®

... 84

5 Coaxial Cable

85-112

Coaxial Solutions Guide ... 86-87

RG 6/U Type ... 88-93

RG 8/U Type ... 94-95

RG 11/U Type ... 96-99

RG 58/U Type ... 100

RG 59/U Type ... 101-108

RG 62/U Type ... 109

RG 174/U Type ... 110

RG 213/U Type ... 111

Twinaxial Cables ... 112

6 Fire Alarm/Life Safety Cable

113-129

Alarm & Security Solutions Guide ... 114-116

Multi-Conductor, Unshielded, Non-Plenum ... 117

Multi-Conductor, Unshielded, Non-Plenum (CSA) ... 118

Multi-Conductor, Shielded, Non-Plenum ... 119

Multi-Conductor, Shielded, Non-Plenum (CSA) ... 120

Multi-Conductor, Unshielded, Plenum ... 121-122

Multi-Conductor, Shielded, Plenum ... 123-124

Mid-Capacitance, Unshielded, Non-Plenum ... 125

(8)

table of contents

Section

PageS

7 Sound, Alarm & Security Cable

130-145

Composite Access Control Cable ... 131

Composite Access Control Cable, Plenum ... 132

Composite Access Control Cable, Riser ... 133

Multi-Conductor, Unshielded, Riser ... 134

Multi-Conductor, Shielded, Riser ... 135

Multi-Conductor, Unshielded, Plenum ... 136

Multi-Conductor, Shielded, Plenum ... 137

Telephone Station/Intercom & Speaker/Burglar Alarm ... 138

Antenna Rotor ... 139

Low-Voltage Sprinkler Wire ... 140

Thermostat Wire Type LVT ... 141

Thermostat Wire Type CL2 ... 142

Thermostat Wire, Unjacketed ... 143

Carol

®

Helix/Hi-Temp

®

Category 6 Cable ... 144

Carol

®

Helix/Hi-Temp

®

Category 5e Cable... 145

8 Audio/Video & Home Entertainment Cable

146-177

Command

®

Series Home Entertainment Cables Guide ... 147-148

Command

®

Series Cruise Ship Cables Guide ... 149-150

Command

®

Series Speaker Cable ... 151-155

Speaker Wire ... 156

Superflex

®

Speaker Wire ... 157

Pro Audio Speaker Wire ... 158

Special Audio, Communication & Instrumentation ... 159-161

Low Skew 4-Pair UTP ... 162

SmartWrap™ Bundled Cable ... 163

Direct Burial, Audio & Communication ... 164-165

Digital Audio Snake Cable ... 166

Analog Audio Snake Cable ... 167-168

(9)

Section

PageS

9 Specialty Cable

178-185

Armored Electronics Products Guide ... 179-180

Wind Energy ... 181

Fluorobus Cable ... 182

Fire Wire ... 183

Computer Cable ... 184

Composite Data and Control Cable ... 185

10 Technical Information

186-247

Insulation & Jacket Properties ... 187

Decimal Conversion Factors ... 188

Unit Conversion Factors ... 189

Temperature Conversion Chart ... 190

Conduit Capacity Chart ... 191

Coax Connector Cross Reference ... 192-199

AWG Conductor Chart ... 200

Cable Design Equations—Braid Shield ... 201

Cable Design Equations—Coaxial Cable ... 202

Cable Design Equations—Balanced Pair ... 203

Engineering Prefixes ... 204

Glossary ... 205-215

Abbreviations & Acronyms ... 216-218

Product Finder—Hook-Up Wire ... 219

Product Finder—Multi-Conductor Cable ... 220-222

Product Finder—Multi-Paired Cable ... 223-225

NEC/CEC Substitution Chart ... 226-227

Agency Symbols ... 228

Agency Approval Index ... 229

Put-Ups and Color Codes ... 230

Applications Index ... 231-233

Belden-to-General Cable Carol

®

Brand Cross Reference Index ... 234-239

Part Number Index ... 240-246

Notes ... 247
