Triton and Triton DTS Innovative Features

New Innovation for

Suite of clinical resources include detailed color photos for traction setup and belting, an anatomical library, and an easy to read color interface.

MADE IN

Ordering Information

4739 – Triton®_{Traction Unit}

Standard Accessories

48083 – Patient Interrupt Switch

27465 – Patient Data Cards (5X)

Optional Accessories

4766 – sEMG Initiated Traction Module

2768 – Patient Data Management System (PDMS) Includes: software, card reader and five patient data cards (see page 5)

Traction therapy is the proven classic modality for the relief of painful pressure on muscular and skeletal structures. In 1977 Chattanooga Group introduced its first line of clinical traction devices to the physical medicine market and changed how mechanical

Technical Specifications

Traction Period: 1-99 Min, 1 Min Increments Hold Period: 0-99 Sec,

1 Second Increments Rest Period: 0-99 Seconds, 1 Second Increments Traction Tension: 0-200 lbs

(0 kg/0 N) - (90 kg/890 N) 1 lb (1 kg/5 N) Increments Pretension 0-30 lbs (14 kg/133 N), 0-60 Sec Progressive Steps: 1 Step - 9 Steps

1 Step Increments Regressive Steps: 1 Step - 9 Steps 1 Step Increments Mains Power: 100 – 240 V, 50/60 Hz Power Consumption: 75 VA

Current Consumption: 3.2 Amps Max Weight: 30 lbs (14 kg)

Dimensions: 17.5”L x 9.5”W x 17.5”H (45 cm x 24 cm x 45 cm) Electrical Safety Class: Class 1, Type B

Safety Tests: Meets Directive 93/42/EEC IEC/UL/EN: 60601-1, 60601-1-2,

CAN C22.2 no. 601.1-M90w/A2

• Complete control of all phases of pull patterns • Pretension Mode prior to traction initiation • Separate timers for Pretension, Progression, Traction, Intermittent Traction, and Regression • Variable speed motor for increased flexibility – 30%, 50% and 100% speed setting parameters • Oscillation Mode

• Traction in Static, Intermittent or Cycling • Optional sEMG module for target initiated traction

• Easy to operate 270° pivoting high resolution color Touch Screen Interface

(4)

Moving Rehabilitation Forward™

• Patient Data Cards record up to 14 treatment sessions, including patient pain mapping, pain scales and pain types

• Detailed color photos of treatment setup • Store up to 80 user defined protocols-20 each for Cervical, Lumbar, Hip and Wrist traction treatments

• Clinical Resources Library with full color anatomical and pathological libraries • Indications to quickly retrieve preset treatment parameters

• Clinical Protocols, complete with treatment rationale for Cervical, Lumbar, Hip and Wrist traction

a Classic Therapy

DTS

traction is delivered. With over 20,000 systems sold to date, we have led the world in traction therapy knowledge, experience and history, and we continue to expand upon our success with functions never seen before. Recommendations from clinical professionals have helped us create traction systems far beyond what was believed possible.

Today, Chattanooga Group is the world leader in clinical traction devices, tables and accessories, and continues to lead the way in traction therapy with the introduction of the most advanced traction units available: Triton and Triton DTS traction systems. Using the most advanced technology the Triton and Triton DTS deliver pull patterns previously only available by hand. Pretension, controlled speed, pull force, timing and gradients, the Triton traction units can mimic many of the most popular manual traction patterns. All packaged in an easy to use system, the Triton family of traction devices makes delivering traction therapy

easy, quick and simple. _{Enhanced Modulated DTS Pull Patterns}

REF: 8250K

• Triton DTS Traction Unit • TRT-550 Treatment Table

• Saunders Cervical Traction Device • Carpal-Trac

• Carpal Tunnel Stretch (Right and Left) • HVP High Volt Stimulator

• Durastick®_{II 2.75” (7 cm) Round Electrodes}

• Stabilizer™ Pressure Biofeedback

• QuikWrap™ Deluxe Universal Belt System

• Deluxe Pneumatic Therapy Stool • Traction Knee and Ankle Bolsters • Traction Face Pillow

• Cervical Halter

• 17” (43 cm) Stainless Steel Spreader Bar • Complete educational training

Triton

®

DTS

™

Advanced Package

Triton DTS Innovative Features

• Gradient Pull Patterns

• Enhanced Modulated DTS Pull Patterns

• Continual Speed Variant Progression Mode

• Progressive Range of Motion Pull Pattern

• sEMG Target Initiated Traction

(5)

Triton®_TRT-550

• Four sections

• Turret mounted traction unit pedestal • Head and foot sections incline up to 90°. • Head section lowers to 25°.

• Integrated gull wing locking caster system

• 400 lb (181 kg) lift capacity MADE IN

Triton DTS traction system includes the Triton DTS traction unit, TRT550 traction table, Quikwrap belting system and a complete accessory package to make application quick, easy and effective. Included in the New Triton DTS traction unit is the unique Pull Pattern Package delivering, Oscillatory, Gradient, and Progressive Range of Motion Pulls with Continual Speed Variant Progression Mode. Add to that the standard sEMG Initiated Traction feature, and you have a system that rivals all competitors. Our Triton DTS traction system delivers the ultimate in patient comfort, operator consistency, and reproducible results at a fraction of the cost of competitive devices.

The Finest Traction System

Available Today

Triton

®

_DTS

TM

Traction System

DTS

sEMG Target Initiated Traction Technical Specifications: Mains Power: 120 V, 50 Hz Current: 1.6 A Power Input: 200 W Weight: 140 lbs (64 kg) Shipping Weight: 200 lbs (91 kg) Table Dimensions: 77”L x 28”W x 21.5” to 41.5”H (196 cm x 71 cm x 55 cm to 105 cm) Overall Length: 105” (267 cm)

• Adjustable height range between 21½” to 41½” (55 cm to 105 cm) • Friction free pelvic cushion with spring recoil

• Pivoting traction mount for angular pulls • Stone Blue is the standard color on the Triton DTS package.*

REF: 8245K

• Triton DTS Traction Unit • TRT-550 Treatment Table • Saunders Cervical Traction Device

• QuikWrap™ Deluxe Universal

Belt System

• Traction Knee and Ankle Bolsters and Face Pillow • Complete educational training

Triton

®

DTS

™

(6)

REF: TRT400

• Turret mounted traction unit pedestal • Pivoting traction mount allows for angular pulls.

• Four sections

• Head and foot sections incline up to 90°. • Head section lowers to 25°

• Friction free pelvic cushion

• 27” (71 cm) wide cushions with nose cut-out • Integrated caster system

• 400 lb (181 kg) lift capacity • Adjustable height range between 21½” to 41½” (55 cm to 105 cm) • Choice of hand or foot control • Quiet electric motor

• Available in choice of standard, designer or Rhino Hyde®_{colors (see page 21).}

Triton®_TRT-400 Technical Specifications: Mains Power: 120 V, 50 Hz Current: 1.6 A Power input: 200 w Weight: 140 lbs (64 kg) Shipping Weight: 200 lbs (91 kg) Dimensions: 77”L x 27”W x 21.5” to 41.5”H (196 cm x 69 cm x 55 cm to 105 cm) Electrical Safety Class: Class 1, Type B

Mobile Traction

Stand

REF: 3600

• Allows traction unit to be used with most tables. • Fully adjustable • Traction unit sold separately. MADE IN MADE IN Page 21 REF: 2768 A unique optional software program that allows the clinician to organize, store, display and print patient traction therapy information from the Triton unit to the PC. This system, that includes software and card reader, uses information stored on

the patient data cards to create reports that document treatment outcomes.

treatmentreview

sessionnotes painprofiles

Patent D513,615

Triton

®

TRT-400

Patient Data Management

System (PDMS)

(7)

TX®_{Innovative Features}

• Easy to operate • 270° Pivoting Interface

• Digital Monochromatic Touch Screen Interface • Patient Data Cards store up to 14 treatment sessions. • Store up to 10 user defined protocols.

• Intermittent, Static and Cyclic traction programs • Progressive and Regressive settings

• User-defined Hold, Rest and Treatment times • Traction tension parameters 0 – 200 lbs. • Built-in safety features

- Patient Interrupt Switch

- Cervical maximum poundage warning - Audible signal at the end of treatment and if Patient Interrupt Switch is activated

Ordering Information

4759 – TX® _{Traction Device}

Standard Accessories

48082 – Patient Interrupt Switch

27465 – Patient Data Cards (5x)

Patient Data Management System 2790 –Patient Data Management System (PDMS): includes software, card reader and 5 patient data cards

Mobile Traction Stand

3600 – Mobile Traction Stand (page 5)

In 1977 Chattanooga Group introduced the TX line of clinical traction devices to the physical medicine market. Today, Chattanooga Group is the world leader in clinical traction devices, tables and accessories. Innovative features and an easy to use digital touch screen interface make the redesigned TX traction unit a true innovation to this classic therapy.

Technical Specifications

Mains Power: 100 – 240 V, 50/60 Hz Power Consumption: 75 V

Current Consumption: 3.2 Amps Max Weight: 30 lbs (14 kg)

Dimensions: 17.5”L x 9.5”W x 17.5”H

(45 cm x 24 cm x 45 cm)

Electrical Safety Class: Class 1, Type B IEC/UL/EN: 60601-1

60601-1-2, CAN C22.2 No. 601.1-M90w/A2

clinicallibrary

painmap userprotocols

MADE IN ®

(8)

TX

®

Traction Tables
