Please cite this article as follows:Mahmoudzadeh M, Rezaei-Soufi L, Farhadian N, et al. Effect of CO2 laser and fluoride varnish application Introduction
Orthodontic treatment has many advantages such as esthetic improvement, function and self-estimation enhancement.1 Orthodontic appliances make oral
hygiene more difficult and increase plaque accumulation. After installing fix orthodontic appliances in the mouth, Streptococcus mutans and Lactobacillus species increase. These bacteria release organic acid that causes dissolution of ions of calcium and phosphate from the enamel surface, which can lead to white spot lesions and this process can occur in 4 weeks.2 White spot lesions
are defined as enamel decalcification due to subsurface mineral loss; while 10 to 30 µm of enamel surface remains intact.3,4 The opaque appearance of the lesion is due to
variations in light scattering of decalcified porous enamel. Years after orthodontic treatment, white spot lesions may develop into esthetic problems, because demineralized enamel may absorb colors from drinks and foods.5,6
When the lesion progresses, remineralization gets tough and sometimes impossible5,7; hence, it is important to
prevent the formation of these lesions. Øgaard reported that 5 years after treatment, white spot lesions were more doi 10.15171/jlms.2018.10
Effect of CO2 Laser and Fluoride Varnish Application
on Microhardness of Enamel Surface Around
Orthodontic Brackets
Majid Mahmoudzadeh1, Loghman Rezaei-Soufi2, Nasrin Farhadian1, Seyed Farzad Jamalian3, Mahdi
Akbarzadeh4, Mohammadali Momeni5*,Masome Basamtabar6
1Orthodontics Department, Dental Research Center, Hamadan University of Medical Sciences, Hamadan, Iran
2Department of Restorative Dentistry, Dental Research Center, Hamadan University of Medical Sciences, Hamadan, Iran 3Private Practice, Hamadan, Iran
4Department of Biostatistics, Hamadan University of Medical Sciences, Hamadan, Iran
5Orthodontics Department, Dental Faculty, Shahrekord University of Medical Sciences, Chaleshtar, Shahrekord, Iran 6Orthodontic Department, Dental Faculty, Kermanshah University of Medical Sciences, Kermanshah, Iran
Abstract
Introduction: Orthodontic treatment has many advantages such as esthetic improvement and self-esteem enhancement; yet it has some disadvantages such as increasing the risk of formation of white spot lesions, because it makes oral hygiene more difficult. It is rational to implement procedures to prevent these lesions. The present study was aimed to assess the effect of CO2 laser and fluoride varnish on the surface of the enamel surface microhardness around the orthodontic braces.
Methods: Eighty extracted premolar teeth were selected, scaled, polished with nonfluoridated pumic and metal brackets were bonded to them. Then, they were randomly allocated to 5 groups: control (neither fluoride nor laser is used on enamel surfaces), fluoride (4 minutes fluoride varnish treatment of the enamel surfaces), CO2 laser (10.6 µm CO2 laser irradiation of the teeth), laser-fluoride (laser-fluoride application after laser irradiation) and laser-fluoride-laser (laser-fluoride was applied and then teeth were irradiated with laser). After surface treatment around brackets on enamel, the samples were stored in 0.1% thymol for less than 5 days and then they were exposed to a 10-day microbiological caries model. Microhardness values of enamel were evaluated with Vickers test. One sample of each group (5 teeth from 80 samples) was prepared for SEM (scanning electron microscopy) and the data from 75 remaining teeth were analyzed with analysis of variance (ANOVA) and chi-square tests (α = 0.05).
Results: Microhardness mean values from high to low were as follow: fluoride-laser, laser-fluoride, laser, fluoride and control. Microhardness in fluoride-laser group was significantly higher compared with that of the control group. Distribution adhesive remnant index (ARI) scores were significantly different between groups and most of bond failures occurred at the enamel-adhesive interface in groups 2 to 5 and at the adhesive-bracket interface in the control group.
Conclusion: Combination of fluoride varnish and CO2 laser irradiation can reduce enamel demineralization around orthodontic brackets.
Keywords: CO2 laser; Fluoride varnish; Demineralization; Orthodontic bracket. *Correspondence to
Mohammadali Momeni, Orthodontics Department, Dental faculty, Hamadan University of Medical Sciences, Shahid Fahmideh Blvd. Hamadan, Iran Tel: +98 9194886113; Fax: +98 8138381085
Email: ortho.momeni@gmail.com
Published online 26 December 2017
Lasers
prevalent in orthodontic patients compared with non-treated patients.8 It is obvious that this responsibility
falls on the orthodontist to make patients aware of the demineralization risks.5 Modern dentistry concentrates
more on prevention of lesions than their operation.9
Orthodontists should assess patients’ risk factors throughout the treatment to prevent white spot lesions. Presence of the following factors increases the probability of white spot lesions occurrence: inappropriate oral hygiene, caries history or high decay missing filled surfaces (DMFS), and lack of preventive methods, such as fluoride or antibacterial compositions.10 Fluoride plays
an important role in preventing demineralization during orthodontic treatment. Fluoride effects with different mechanisms: It joins the crystalline structure of hydroxy apatite and creates fluoride hydroxy apatite that is less soluble and more resistant to acidic attack, it increases the remineralization process and has antibacterial effects.11-13
There are different types of fluoride with different pH, concentration and releasing systems such as varnish, gel, mouth-rinse and tooth paste. Complete compliance of patients with fluoride regimen at home is unlikely. Fluoride varnish is easy to use and does not depend on patient’s cooperation.11,14
For patients with moderate to high risk of caries, fluoride regimen should be used at office every six months.10 Since
the intervention of ruby crystal laser by Maiman in 1960, different lasers have been assessed in dentistry fields.15
Different types of lasers such as Er: YAG, Nd: YAG and CO2 with various adjusting parameters have been administrated for caries prevention. CO2 lasers are useful without hazardous side effects and they keep surface temperature at safe levels. CO2 lasers (with 9.3, 9.9, 10.3 and 10.6 µm wavelengths) should be considered as main laser in caries prevention because the absorption bands of dentin, enamel, hydroxyle, carbonate and phosphates groups are in the range of 9-11 µm. Irradiation of CO2 laser with 10.6 µm wavelength and continuous beam causes significant decrease in the dissolving rate of enamel. After laser absorption, surface and near surface layer temperature increases which in turn causes structural and chemical changes in enamel. These changes include decomposition of organic matrix, decrease in carbonate compounds and fusion and recrystallization of hydroxyapatite crystals that causes a more resistant enamel to acid solution.16-22 It has been demonstrated that
the effects of laser irradiation and topical fluoride may be synergistic.23
Methods
A total of 100 human extracted premolar teeth with no caries, defects or hypoplastic enamel, were gathered and stored in saline. Scaling was done in order to removing calculus or tissue remnant. The buccal surface of the teeth was covered with acid-resistant varnish; however, a 4×6-mm window was left unexposed for bracket bonding and
microhardness test. Twenty samples were used for pilot study which evaluated microbiological model efficacy for demineralization. Also, 5 samples were prepared for SEM and the data of the 75 remaining teeth were analyzed. Bonding of Brackets
Enamel was etched by 37% phosphoric acid (3 M Unitek, Monrovia, USA), rinsed with water and dried with oil-free air for 15, 30 and 20 seconds, respectively, in order to obtain the appearance of a frosty white surface. Stainless-steel brackets (Dentaurum, Ispringen, Germany) were bonded to premolars with the Transbond XT composite resin (3M Unitek, Monrovia, USA). Manufacturer’s instructions were followed precisely in every stage. Brackets was placed in the correct position. The composite resin was cured for 40 seconds with an LED light-curing unit (Kerr, DEMI plus, USA).22
Then, the samples were randomly assigned to the following 5 experimental groups (16 teeth in each group): Group 1 (control): Neither fluoride nor CO2 laser was applied on the enamel surface at the gingival edge of brackets.
Group 2 (fluoride varnish):A thin layer of Fluoride varnish (5% sodium fluoride varnish, Pascal, USA) was applied on the enamel surface using an applicator at the gingival edge of brackets. The varnish was left for 4 minutes and after 6 hours, teeth were cleaned with a toothbrush and distilled water.
Group 3 (CO2 laser): CO2 laser (DEKA Laser Technologies, Florence, Italy) was irradiated to the enamel surface with the 5 Hz frequency, 10.6 µm wavelength, 0.4 W output power, 0.9 seconds pulse time and 0.2 mm spot size by an experienced operator with a uniform scanning motion with 5 mm distance away from the enamel surface for 20 seconds totally. After irradiation, the samples were washed with distilled water.
Group 4 (laser before fluoride varnish): At first, the enamel surface at the gingival edge of bracket was irradiated with CO2 laser as explained for third group. Afterwards, fluoride varnish was applied according to the explained protocol of second group.
Group 5 (laser through fluoride varnish):Fluoride varnish was applied on the enamel surface at the gingival edge of brackets and laser irradiation was done 3 minutes later with the aforementioned parameters defined for third group through the varnish for 20 seconds. Afterwards, the teeth were rinsed with distilled water.
Finally, all samples were soaked in artificial saliva for a month.18
One sample from each group (5 teeth from 80 samples) was prepared for scanning electron microscopy (SEM) to observe the enamel surface (Figure 1).
Demineralization Process
At first, in order to prevent non-experimental bacteria contamination, 10 teeth were soaked in 0.1% thymol
solution24; afterwards, caries model was used in order to
simulate demineralization challenge.25
Streptococcus mutans (Clarke, ATCC® 35668TM Manassas, Virginia, USA) was chosen to grow biofilms on teeth and demineralize enamel. Culture medium was prepared by adding isolated S. mutans in 5 mL of tryptic soy agar (TSB) with 0.5 McFarland turbidity to 80 mL of sterile brain-heart solution containing 5% sucrose. The samples were rinsed two times in a sterile plate with 0.9% saline near a flame and then placed in culture tubes in a jar with 10% partial CO2 at 37°C. Every 24 hours, washing was repeated twice to remove loosely bound material from the enamel structure. Then, they were returned to the new culture medium. The continuation of the process was 10 days.25
Surface microhardness of the aforementioned teeth were compared to 10 non-exposed control teeth by surface microhardness test. The root of the teeth was cut 1mm below CEJ and the crowns were placed in self-cured acrylic resin (Figure 2). Vickers microhardness testing machine (Micromet 1, Buehler LTD, Lake Bbluff, Illinois, USA) using a 300-g load with a dwell time of 15 seconds assessed the microhardness. Three indentations were
made on each sample in order to calculate the mean hardness as Vickers hardness number (VHN).
There was a statistically significant difference between exposed and non-exposed teeth (P < 0.05, mean difference = 85), and this pilot study showed that, as mentioned, microbiological model is effective in demineralizing the teeth.
Then 75 samples in 5 groups were demineralized through this method for 10 days.
Surface Microhardness Test
After the demineralization process, brackets were debonded and adhesive remnant index (ARI) was rated by an individual investigator according to the following protocol:
1 = the adhesive was remained on the enamel surface completely.
2 = more than half of the adhesive remnant observed on the surface of enamel.
3 = more than half of the adhesive remnant observed on the base of bracket.
4 = the adhesive remained on the bracket base completely.19
Then, the roots of the samples were cut 1 mm below the CEJ and the crowns were washed with distilled water and were mounted in self-cured acrylic resin in a way that the buccal surface was parallel to the horizon. A Vickers microhardness tester was used as explained previously and VHN was recorded. The indenter was positioned on a 2×4-mm non-bonded exposed surface of enamel.
Results
Surface Microhardness
Kolmogorov-Smirnov test revealed normal distribution of surface microhardness of the teeth in the 5 study Figure 1. Enamel Surface of the Groups Observed in SEM Photomicrographs. A: group 1 (control) shows shallow depressions and small porosities without any surface deposits. B: group 2 (fluoride varnish) demonstrates numerous granular particles of fluoride on the enamel. C: group 3 (CO2 laser) with typical melting appearance, cracks and craters with discontinuities. D: group 4 (laser before fluoride varnish) shows a view similar to those of third group along with granular and globular particles. E: group 5 (laser trough fluoride varnish) demonstrates a relatively smoother and more homogeneous surface than those of the third group, with cracks and granular particles.
groups. Means and 95% CIs microhardness within the study groups are shown in Figure 3.
Microhardness mean values from high to low were as follow: fluoride-laser, laser-fluoride, laser, fluoride and control (Table 1).
The results of analysis of variance (ANOVA) revealed that there was a statistically significant difference among the 5 study groups (P=0.03). Tukey post hoc test indicated that microhardness was statistically significantly higher in the fluoride-laser group compared with that of the control. (Table 2)
Adhesive Remnant Index
The results of ARI scores for ranking adhesive remnants on the enamel surfaces are shown in Table 3. According to chi-square analysis (χ2 = 21.8, P = 0.03), there were
significant differences among the 5 groups in case of ARI scores. ARI scores of 3 and 4 were more prevalent in all experimental groups except for the control in which ARI score of 1 was higher. This indicated that bonding failure distributions were more at the adhesive–enamel interface in group 2 to 5 and at the bracket-adhesive interface in group 1.
Discussion
Orthodontic appliances make plaque removal and oral hygiene more difficult and so, increase the risk of white
Figure 3. Differences in Vickers Hardness Values Between the Groups.
spot lesions. Clinically visible white spot lesions are observed in 50% of patients who received orthodontic treatment.21 In the present in vitro study, the effect of
fluoride and CO2 laser irradiation on microhardness of enamel around orthodontic brackets were assessed. The mean values of microhardness from high to low were: fluoride-laser, laser-fluoride, laser, fluoride and control. Various methods have been used for assessing human tooth hardness, such as abrasion, scratch and indentation techniques.24 In the present study, Vickers microhardness
test was utilized to assess changes in enamel surface as an indirect test that is capable of measuring the variations in surface structural strength from demineralization.26
In in vitro studies different methods are used for demineralization such as acidic solutions (citric acid, lactic acid), cariogenic solutions (Tencate) and microbiological models.12,21,25-27 In this study, a microbiological caries
model with S. mutans was used. Microbiological caries models appear to be more appropriate than chemical Table 1. Mean and Standard Deviations of Microhardness in 5
Groups Groups Mean (KgN/mm2) SD Control 317.86 135.13 Fluoride 432.20 113.85 Laser 447.46 146.29 Laser-fluoride 460.64 150.64 Fluoride-laser 484.06 185.78
Table 2. Pairwise Comparisons Between Groups by Post Hoc Tukey Test for Vickers Hardness
Group 1 Group 2 Mean Difference (1-2) SE P Value 95% CI
Upper Bound Lower Bound
Control Fluoride -114.33 54.12 0.22 -265.87 -37.21 Laser -129.60 54.12 0.12 -281.14 -21.94 Laser-fluoride -142.80 54.12 0.07 -294.34 -8.74 Fluoride-laser -166.20 a 54.12 0.02 -317.74 14.65 Fluoride Laser -15.26 54.12 0.99 -166.81 136.27 Laser-fluoride -28.46 54.12 0.98 -180.01 123.07 Fluoride-laser -51.86 54.12 0.87 -203.41 99.67 Laser Laser-fluoride -13.20 54.12 0.99 -164.74 138.34 Fluoride-laser -36.60 54.12 0.96 -188.14 114.94 Laser-fluoride Fluoride-laser -23.40 54.12 0.99 -179.94 128.14
Abbreviation: SE, standard error.
models because they concentrate more on relevant biofilm aggregation instead of physiochemical aspects.21 We did a
pilot study and it revealed that this microbial model can be effective in demineralizing the enamel.
There is consensus that fluoride decreased demineralization and increased demineralization via physical and chemical intervention, but its effect is partial and cannot prevent demineralization completely. So, the effect of their combination has been evaluated. They seem to have a synergistic effect on each other.28 According to the
present study when fluoride is applied on the enamel and then laser irradiate through it, microhardness of enamel increases significantly compared with the control. It is reported that laser increased fluoride uptake.29,30 Stangler
et al,31 Nakagaki et al32 and Featherstone et al33 assessed the
effect of CO2 laser and fluoride combination and reported it to be more than fluoride or laser alone. With respect to the order of fluoride and laser in the combination, Esteves-Oliveira et al34 found that when fluoride is used before
laser irradiation, it increased enamel microhardness more than when laser is used before fluoride application. In Steiner-Oliveira et al,25 Tagliaferro et al35 and Seino et al36
studies, the combination of fluoride and laser had not any additional effect compared with using them alone. Using different methods for demineralization and evaluation of enamel surface changes may cause these results to be different from those of the present study. In our study, microhardness of laser-fluoride group was higher than in the control, but it was not significantly different. Fluoride varnish remained at the tooth surface for hours after its consumption and released fluoride ions. Fluoride declined demineralization with its antibacterial effect while creating fluoride hydroxyl apatite which is more resistant to acidic attacks compared with hydroxyapatite.13
Effect of applying fluoride varnish alone has not been significantly different from control, which is similar to the study of Esteves-Oliveira34 in 2011. Melo et al37
evaluated the effect of different composites containing fluoride on prevention of demineralization around brackets using microbiological model and found that there was no significant difference between them. Todd et al38 reported that fluoride varnish caused 50% decrease
in demineralization. They used polarized microscope Table 3. ARI Scores Frequency and Results of Chi-Square Comparison of the 5 Groups
ARI Scores 1 2 3 4
No. (%) No. (%) No. (%) No. (%)
Control 5 (33.3) 2 (13.3) 4 (26.7) 4 (26.7) Fluoride 0 (0) 2 (13.3) 7 (46.7) 6 (40) Laser 1 (6.7) 1 (6.7) 6 (40) 7 (46.7) Laser-fluoride 1 (6.7) 1 (6.7) 11 (73.3) 2 (13.3) Fluoride-laser 0 (0) 3 (20) 5 (33.3) 7 (46.7) df = 12, χ2 = 21.88, P value = 0.03
for assessing enamel changes. Different types of lasers with various setting adjustments have been used for the purposes of preventing tooth caries. CO2 laser is effective and without hazardous side effects.30 CO
2 laser caused
structural and supra-structural changes in enamel.28 In the
present study, laser group had more microhardness values than the control but it was not significantly different. In the study of Steiner-Oliveira in 2010, using laser alone could not prevent enamel or dentin erosion.25 Miresmaeili
et al22 reported that clinically, laser can increase enamel
microhardness around brackets.
Present study showed a statistically significant difference between groups regarding the distribution of ARI scores and more bond failure distributions were at the enamel-bracket interface in groups 2 to 5 and at the enamel- bracket-adhesive interface in the control group. The results of Ladhe et al11 and Leódido et al39 studies about ARI were
similar to ours.
While in the present study, microbiological model was used for demineralization to simulate clinical situation, saliva components and temperature conditions of the oral cavity can affect the effect of caries preventive materials. On the other hand, interaction of different species of aerobic and anaerobic bacteria in oral cavity with cariogenic species affects their operation and perhaps the pattern of demineralization. This study gives a point of view for using substrates clinically with the purposes of preventing enamel demineralization around brackets in orthodontic patients who are at the risk of caries.
Conclusion
Irradiating CO2 laser at wavelength of 10.6 µm through fluoride varnish consumption on enamel around orthodontic brackets, increased enamel microhardness and so it can be used to prevent enamel demineralization in orthodontic patients.
In all of the treated groups, fracture of composite resins was occurred at composite‒enamel interface. Further clinical trial studies are recommended to clarify these findings.
Conflict of Interests
The authors had no conflict of interest.
Ethical Considerations
There was no ethical consideration since the study was in vitro.
