Shortest Superstring in DNA Sequencing

(1)

Shortest Superstring in DNA Sequencing

Rongdeep Pathak

Department of Computer Application

Assam Engineering College

Guwahati, Assam, INDIA

Bichitra Kalita

Department of Computer Application Assam Engineering College

Guwahati, Assam, INDIA

ABSTRACT

In this paper, a new algorithm has been developed applying graph theoretical approach to study the shortest superstring from a DNA spectrum having variable and fixed length of fragments.

Keywords

DNA sequencing, DNA spectrum, fragments, directed weighted graph, overlap matrix

1. INTRODUCTION

DNA computing is an area where it overlaps computer science, mathematics and molecular biology. In DNA computing, it is generally used biological techniques to efficiently do the computation where the data are represented using the strands of DNA. Computation with the DNA molecule has many advantages over conventional computing methods used in digital computer. In DNA computing, the synthetic DNA molecules are used as information storage and the technique of molecular biology such as gel electrophoresis, enzymatic reactions, polymerase chain reactions etc. are used as computational operations for copying, storing and splitting/ concatenating the information in the DNA molecules respectively. A DNA reaction is much slower than the cycle time of silicon based computer, but it can execute billions of operations simultaneously. The massive parallelism of DNA processing provides the solution of NP complete problems. Therefore DNA computing can be applied to solve large complex computational, optimization, Boolean circuit development, scheduling and many other real life problems such as travelling salesman problem etc. It was first represented that a DNA polymerase which incorporates an enzyme function for copying DNA is very similar with the function of a Turing machine [1].DNA is a molecule which encodes the genetic information used in the development and functioning of all known living organism and many viruses. DNA molecules are polymers which are built from simple monomer called nucleotides. A nucleotide consists of three components – sugar, phosphate and a base. Nucleotides may differ only by their bases, which are Guanine (G), Adenine (A), Thymine (T) and Cytosine(C). The bases have a pair wise affinity i.e. a pair with T and C pair with G. This is called Waston – Crick complimentarily and it is the central to the formation of double stranded DNA molecule. Recently many theoretical research works has been done to realize general computation using DNA molecules. A method has been discussed for solving a directed Hamiltonian path problem with seven cities using DNA molecule [1]. Again, it is found that [4] a computational model to realize (via experimental operation of DNA molecule) operations on multiple set of character strings following the encoding of finite alphabet characters into DNA molecules. Further, a new DNA encoding method in which thermodynamic properties of

DNA are used to represent numerical values and this method has been applied to solve TSP [8].

In DNA computing the main challenge is encoding data into a DNA sequence. Again in DNA sequencing the main problem is to determine a sequence of nucleotides from an unknown DNA fragment [2, 3]. Generally the input data comes from a biological hybridization experiments which is a set (called spectrum) of words (called fragments/oligonucleotides) over the alphabet {A, C, G, T}. These fragments may have fixed or varying length and usually have overlaps. The main aim is to reconstruct the original DNA sequence of a known length n on the basis of these overlapping words/fragments.

In molecular biology Sequencing By Hybridization (SBH) technique is used in DNA Sequencing. The DNA sequencing problem can be stated as the problem of constructing a string over ∑ = {A, C, G, T} from a given spectrum S= { s1,s2,…..sn} so that the resulting string is the shortest string

which contain as many of the fragments in the spectrum as possible. This problem is called shortest superstring problem. Several methods for DNA sequencing problems with constant length oligonucleotide have been discussed with the help of Graph theory [7]. An algorithmic approach has been given to find the shortest superstring for ideal spectrum and fragments with constant length by applying the theoretical approach of graph theory [10]. A spectrum without any error is called ideal spectrum. A spectrum may contain positive error that is oligonucleotide present in the spectrum but absent in the original sequence and negative error if oligeonucleotides not present in the spectrum but possible to distinguish in the original sequence. Repetitions of fragments or oligeonucleotides are also treated as negative error.

In this paper, a new algorithm has been discussed to find the shortest superstring from a given spectrum having variable or fixed length of fragments.

This paper is organized as follows – the section 1 focuses some previous works of DNA computing and preliminaries of DNA sequencing. In section 2, a new algorithm has been developed to compute the shortest superstring from a given DNA spectrum. The spectrum may have fixed or varying length of fragments. In section 3, some examples are cited which clarify the algorithm. Section 4 includes the conclusion of this paper.

2. A NEW ALGORITHM TO COMPUTE

THE SHORTEST SUPERSTRING FROM

A GIVEN SPECTRUM OF FIXED OR

VARYING LENGTH OF FRAGMENTS

Here, a directed weighted graph G (V, E, W) has been drawn from a given DNA spectrum. In this spectrum the fragments may have fixed length or varying length.

(2)

V= S, vertex vi corresponds to fragment si

E = {(Vi ,Vj ) , if there is a overlap between fragment Si and fragment Sj where i ≠j

W(Vi ,Vj ) = overlap ( Si ,Sj ) = |wij | if i ≠j

Overlap (Si , Sj ) means the longest prefix of Sj that matches a suffix of Si

For example, let X= ACTGCC and Y= GCCTCAC ACTGCC

GCCTCAC Overlap(X, Y) = 3.

After having the directed weighted graph from the given spectrum an overlap matrix M of size (V X V) has been constructed. The entry of the overlap matrix M is as follows-

M=Aij=

w Vi , Vj , where there is an edge from Vi to Vj 0, if here is no edge between Vi to Vj and i ≠ j NO Value if i = j

This overlap matrix M gives the values of overlap between two vertices i.e. the number of overlap between two fragments of the given spectrum.

Now, from this overlap matrix M try to find a path or sequence of vertices, which gives the maximum overlap value. Main objective is to generate sequence of vertices which gives maximum overlap value and should also contain all the vertices of the directed graph. This maximum value sequence is our Shortest Superstring (SS) of the given spectrum.

To compute the Shortest Superstring, an algorithm called Compute_Shortest_Superstring has been used, which gives a set of sequences and the corresponding overlap value. In the algorithm Compute_Shortest_Superstring, one stack,

called stack_of_string, a table, called

table_of_complete_sequence and a pointer pointing to the top of the stack_of_string has been used. In the stack_of_string, contains some uncompleted sequences or tours and in the table table_of _complete_ sequence contains complete sequences or tours.

In this approach N, the numbers of ordinary stacks is used where N is the number of vertices i.e the total number of fragments of the given spectrum. Each stack contains values of each rows of the overlap matrix in ascending order without any duplicate value and top of the stack holds the highest value. Also N number of pointers has been used pointing top elements of each stack.

In the algorithm Compute_Shortest_Superstring, the following procedures have been used:

POP () – this procedure remove top element from the stack of string. Returns top element of the stack.

PUSH(X) - insert the string X into the top of the stack of string

Get-last-string(X) - returns the last element of the string X. Find-max-entry (Ri N) - searches the item N in the ith row of

the matrix and if the item is found stores the position in an array. If there is no match then nothing is stored in the array. Returns a pointer to the array.

Find-length(X) – return the size of the array pointing by the pointer X.

Find-max(X) – returns the top element of the Xth ordinary stack if the stack is not empty otherwise returns an error value.

COPY(X) – store the string X into the table_of_complete_sequence.

For each vertex, follow the steps of the algorithm Compute_Shortest_Superstring. The initial value of the stack of string is the input vertex and a $ symbol. The input vertex is on the top of the stack. Initially the pointer PTR pointing to the input vertex. The algorithm terminates when the top of the stack is $, i.e. when PTR points to the $ symbols.

ALGORITHMCompute_Shortest_Superstring : Input: an input vertex

Output: Sequence of vertices 1. String Str; 2. Char LAST;

3. Int Size,N,COUNT=0; 4. Char * M;

5. Str = POP();

6. LAST = Get-last- string(Str); 7. N= find –max(LAST);

8. If (N==Error) then COPY(Str) and go to step 15 9. Else

10. M= find-max-entry(LAST,N); 11. Size=Find-length(M);

12. If (Size==0) then COPY(Str) and Exit; 13. Else if

14. For I = 0 to Size 15. If (Str П *(M+I) ==Ф 16. Then

17. Str1=Str U *(M+ I) 18. PUSH(Str1); 19. COUNT++; 20. End if

21. End Else if 22. If (COUNT == 0) 23. Then go to step 4 24. End if

25. If (Ptr ≠$) then goto step 2 26. END

The above algorithm gives a set of sequence store in the table_of_complete_ sequence. From these sequences the overlap value for each sequence can be computed. Lets us take Vi VjVKVl is a sequence.

(3)

overlap between Vk and V l is z . Therefore, the total overlap

value of the sequence Vi V j VK Vl is (x + y + z).

Now, after go through the steps of the above algorithm, a set of sequences and corresponding overlap value has been found. From this information the Shortest Superstring can be computed.

First, separate out the sequences having the maximum value from the table_of_complete_sequence and store these sequences into a new table called Max_Table and follow the following steps:

Case A: (Maximum value sequence having all the vertices or all the fragments of the spectrum)

For each maximum value sequence the following steps has to be followed:

1. Let the maximum value is MAX 2. Find the starting vertex of the sequence

3. Check whether there is a path or overlap from this vertex to the starting vertex of other sequences of table of complete sequence (the starting vertex should not present in the sequence) then adds this starting vertex to the sequence as start vertex. 4. If the total overlap value is new sequence is ≥ MAX

then copy this new sequence to the table Max_table After processing each and every maximum value sequence remove all duplicate sequences and separate out the sequences having highest value and store into a new table called Final_max_table.

The set of sequence or sequence of Final_max_table gives the Shortest Superstring of the given spectrum.

Case B: (Maximum value sequence not contain all the vertices or the fragments of the spectrum)

Case B.1: (Maximum value sequence contain same set of vertices or the fragments of the spectrum)

For each maximum value sequence the following steps has to be followed:

1. Same steps as case A

2. Check is there is any path or overlap from the last vertex to the start vertex then remove the last vertex and placed it at the beginning of the sequence. 3. If the total overlaps value of this new sequence is ≥

MAX then store into Max_table.

After processing each maximum value sequence remove all duplicate sequence and store the highest overlap value sequence into a new table called Max1_table.

Now, separate out all those sequences from the table of complete sequence not containing the vertices of Max1_table. Same steps follows as above and store the highest overlap value sequence into a table Max2_table.

This process continues until all the vertices are included. Finally, some tables has been found, like Max1_table, Max2_table and so on. Each table gives shortest substring. By performing computational process the Shortest Superstring of the given spectrum can be computed.

For example, let table Max1_table contains sequence X, Max2_table contains sequence Y and Max3_table contains sequence Z. Sequences X, Y and Z contains all the fragments of the given spectrum. After computational process, the Shortest Superstrings of the given spectrum are as follows: XYZ, XZY, YXZ, YZX, ZXY and ZYX.

Case B.2: (Maximum value sequence may not contain same set of vertices or the fragments of the spectrum)

Arbitrarily choose any one sequence or set of sequence having same set of vertices or fragments.

Apply same steps as Case B.1

3. JUSTIFY THE ALGORITHM WITH

SOME SUITABLE EXAMPLE

Example 1: (Case A)

Suppose the original sequence be s= ACTCTGG and an errorless hybridization experiment generates the ideal spectrum S = {ACT, CTC, CTG, TGG, TCT} [1].

Applying the algorithm, we can reconstruct the original sequence s

Now, draw a directed weighted graph G from the above spectrum S and the vertex set V= {V1, , V2, V3,, V4, V5},

where

V1 = ACT V2 = CTC V3 = CTG V4 = TGG V5 = TCT

2 1 2

1

2

1

2

[image:3.595.316.476.367.639.2]

1

Figure 1: Directed weighted graph for the above spectrum

V1

V2 V3

V4

(4)

Table 1: Overlap Matrix

V1 V2 V3 V4 V5

V1 No_val_ue 2 2 1 1

V2

_O

No_val

ue 1

O

2

V3

_O

1 No_val

ue 2

O

V4

_O

No_val_ue

_O

V5

O

2 2 1 No_val_ue

By applying the algorithm, some set of sequences has been

found. The following table 2 is the

table_of_complete_sequence, which contains the sequences of the spectrum S and the corresponding overlap value.

Table 2: Table_of_complete_sequence

Sequence

Overlap value

V1 V 2V5 V3 V4

8

V1 V 3V4 4

V2 V5 V 3 V4 6

V3 V 4 2

V5 V2V3V4 5

V5 V3V4 4

[image:4.595.48.285.74.236.2]

Now, applying the steps of Case A, the sequences that are found, stored in the Max_table. The following table 3 gives the Max_Table and the Final_max _table, which store the shortest superstring of the above spectrum S that is shown in the table 4. Table 3: Max_table

Table 4: Final_max _table Shortest Superstring V1 V 2V5V3V4 From the final_max_table, the Shortest Superstring of the above spectrum S = {ACT, CTC, CTG, TGG, TCT} can be computed. The Shortest Superstring is s = V1V2V5V3V4 = ACTCTGG

Example 2: (Case A)

Suppose a hybridization experiment generates the spectrum S= {ACCGT, GTTCGT, CGTGTG, GTGCGT, TCGTG}. From this spectrum, we have to compute the Shortest Superstring s. Now, we draw a directed weighted graph G from the above spectrum S and the vertex set V= {V1, V2, V3, V4, V5}, where V1 = ACCGT V2 = GTTCGT V3 = CGTGTG V4 = GTGCGT V5 = TCGTG

2 2 1 3

3

1

1 4 3 4

2 2 3

1

3

Figure 2: Directed weighted graph for the above spectrum Figure 2, gives the directed weighted graph of the above spectrum S. Now, from this graph construct the overlap matrix. The following table 5 gives the overlap matrix of the graph G. Sequence Overlap value V1 V 2V5 V3 V4 8

V1 V 2V5V3V4 8

V1

V2 V3

[image:4.595.67.254.600.680.2]

(5)

V1

V2

V3

V4

V5

V1

No_val ue

2

3

2 1

V2

O

No_val ue

3

2 4

V3

O

1

No_val ue

3 O

V4

O

2

3

No_val ue

1

V5

O

1

4

3

No_val ue

By applying the algorithm, some set of sequences have been

[image:5.595.337.526.343.679.2]

Table 6: Table_of_complete_sequence

Sequence Overlap value V1 V 3V4 V2 V5 12

V2 V 5V3 V4

11

V3 V4 V 2 V5

9

V4 V 3V 2 V5

8

V5 V3 V4 V2

9

Now, applying the steps of Case A, some new sequences have been found which are stored in the Max_table. The following table 7 gives the Max_Table and finally, the Final_max _table stores the shortest superstring of the above spectrum S as shown in table 8.

Table 7: Max_Table

Table 8: Final_max _table

Shortest Superstring

V1 V 2V5V3V4

From the final_max_table, the Shortest Superstring of the above spectrum S= {ACCGT, GTTCGT, CGTGTG, GTGCGT, TCGTG} has been computed.

The Shortest Superstring is s = V1V2V5V3V4

= ACCGTTCGTGTGCGT

Example 3 :( Case B)

Suppose, a hybridization experiment generates the spectrum S= {ACAT, TACA, ATGCAT, TCAAT, CGTGC, GCTACG} Now,draw a directed weighted graph G from the above spectrum S and the vertex set V= { V1,, V2, V3,, V4, V5 ,V6},

Where

V1 = ACAT V2 = TACA V3= ATGCAT V4= TCAAT V5= CGTGC V6 = GCTACG

3 1 1 2

1 1

1 1 2

2 2

Figure 3: Directed weighted graph for the above spectrum

Figure 3, gives the directed weighted graph of the above spectrum S. Now, from this graph construct the overlap matrix. The following table 9 gives the overlap matrix of the graph G.

Sequence Overlap value

V1 V 3V4 V2 V5 12

V1 V 2V5V3V4 13

V1 V 3V4 V2 V5 12

V1

V2

V3

V4

V5

[image:5.595.84.252.450.566.2] [image:5.595.82.271.633.752.2]

(6)

V1 V2 V3 V4 V5 V6

V1 No_v

alue

1 2 1 O O

V2 3

No_v

alue 1 O O O

V3 O 1

No_v

alue 1 O O

V4 O 1 2

No_v

alue O O

V5 O O O O

No_v alue 2

V6 O O O O 2

No_v alue

By applying the algorithm, some set of sequences have been

Table10: Table_of_complete_sequence

Sequence Overlap value

V1 V3 V2 3

V1 V3 V 4V2 4

V 2V1 V3 V 4 6

V3 V2 V1V 4 5

V3 V4 V2 V 1 5

V4 V3 V2 V1 6

V5 V6 2

V6 V5 2

[image:6.595.54.281.90.328.2]

Now, applying the steps of Case B.1, the tables Max1_table and Max2_table have been found, which contains all the shortest sub strings as shown in the following Table 11 and Table 12. Table 11: Max1_table Sequence Overlap value V2V1V3V4 6

V4V3V2V1 6

V4V2V1V3 6

Table 12: Max2_table Sequence Overlap value V5 V6 2

V6 V5 2

By performing computational process, the shortest superstring of the above spectrum S can be computed. The following table 13 gives all the shortest Super string of the spectrum

S= {ACAT, TACA, ATGCAT, TCAAT, CGTGC,

GCTACG}

Table 13: Shortest Superstring

Sequence Shortest superstring

V2 V1 V3 V4

V5V6

TACATGCATCAATCGTGCTACG

V2 V1 V3 V4

V6V5

TACATGCATCAATGCTACGTGC

V5V6 V2 V1 V3

V4

CGTGCTACGTACATGCATCAAT

V6V5 V2 V1 V3

V4

GCTACGTGCTACATGCATCAAT

V4 V3 V2 V1

V5V6

TCAATGCATACATCGTGCTACG

V4 V3 V2 V1

V6V5

TCAATGCATACATGCTACGTGC

V5V6 V4 V3 V2

V1

CGTGCTACGTCAATGCATACAT

V6V5 V4 V3 V2

V1

GCTACGTGCTCAATGCATACAT

V4 V2 V1 V3

V5V6

TCAATACATGCATCGTGCTACG

V4 V2 V1 V3

V6V5

TCAATACATGCATGCTACGTGC

V5V6 V4 V2 V1

V3

CGTGCTACGTCAATACATGCAT

V6V5 V4 V2 V1

V

[image:6.595.310.547.94.315.2] [image:6.595.311.547.392.770.2]

(7)

4. CONCLUSION

This paper mainly focuses a new algorithm to find the shortest superstring of a given DNA spectrum having variable or fixed length of fragments. In this algorithm the graph theoretical approach has been used. This algorithm gives all the possible shortest superstrings that may be present in a given DNA spectrum of fixed or varying length of fragments.
