Hosting Topology

In a hosting environment, you have a backend and a several front end (clients).

In the example below, there is a backend at the right side. At the left side you have the

clients in the customer domain. Each client must be able to communicate with the

backend.

The backend must be able to communicate with the customer´s Active Directory for

collecting the users to the SMS PASSCODE Database (LDAP(s)).

(3)

The Hosted Backend services

prerequisites are:

Component

Requirement

Database Service

Supported operating systems:



Windows Server 2003 (x86/x64)



Windows Server 2008 (x86/x64)



Windows Server 2008 R2 (x64)



Windows Server 2012 (x64)



Windows Server 2012 R2 (x64)

Web Administration Interface

Supported operating systems:



Windows Server 2003 (x86/x64)



Windows Server 2008 (x86/x64)



Windows Server 2008 R2 (x64)



Windows Server 2012 (x64)



Windows Server 2012 R2 (x64)



IIS 6.0+ required

(4)

same server as the Database Service component.

Transmitter Service

Supported operating systems:



Windows Server 2003 (x86/x64)



Windows Server 2008 (x86/x64)



Windows Server 2008 R2 (x64)



Windows Server 2012 (x64)



Windows Server 2012 R2 (x64)



An unused serial port (COM port) for each

GSM/CDMA modem or a Moxa box for

each modem (serial to Ethernet converter).



An active SIM card for each GSM modem

in use.

Load Balancing Service

Supported operating systems:



Windows Server 2003 (x86/x64)



Windows Server 2008 (x86/x64)



Windows Server 2008 R2 (x64)



Windows Server 2012 (x64)

In addition you need Microsoft .Net version 3.1 SP1 installed (feature in

2008R2/2012/2012R2).

Best practice is to use two (v)CPU kernels and have SMS PASSCODE Database as a

dedicated (virtual) server. Please make sure to add 256 MB of RAM, 100 MB of hard disk

and an additional 100 MB of hard disk space per 1000 users over the Microsoft

recommendation for the OS type chosen for the server.

For the servers having the Load Balancing/Transmitter services installed please make sure

to add 128 MB of RAM, 100 MB of hard disk and an additional 50 MB of hard disk space

per 1000 users over the Microsoft recommendation for the OS type chosen for the server.

(5)

Client Components

SMS PASSCODE

®

_{is composed of the following software components:}

SMS PASSCODE

®

Core Components

Authentication Clients

Add-on modules

[1]

 Database Service  Web Administration

Interface

 Transmitter Service  Load Balancing Service  Self Service Web Site

 Citrix Web Interface Protection

 RADIUS Protection

 Cloud Application Protection  IIS Web Site Protection  ISA/TMG Web Site

Protection

 Windows Logon Protection  Secure Device Provisioning

(for ActiveSync devices)

Password Reset Module

Component Description

Database Service Database for storing all SMS PASSCODE®_{user data and}

configuration data.

Web Administration Interface Web site for maintaining SMS PASSCODE®_{user data and}

configuration data.

Transmitter Service Service responsible for dispatching messages and validation of SMS PASSCODE®_{logons. Handles load balancing and}

failover between all GSM modems connected to the service.

(6)

Load Balancing Service Service responsible for handling load balancing and failover between all Transmitter services.

This optional service is recommended for enterprise installations where multiple Transmitter services are present. It should be installed in the following cases:

1) Advanced failover and load balancing of SMS messages between all Transmitter services is required, or

2) The usage of Load Balancing Policies is required. Self Service Web Site Web site that allows end-users to maintain some of their

personal SMS PASSCODE®_{account settings themselves.}

Citrix Web Interface Protection Integrates SMS PASSCODE®_{with Citrix Web Interface}

providing SMS PASSCODE®_{authentication for Citrix Web}

Interface users. It is optionally possible to run the Citrix Web Interface protection side-by-side with hardware-token based two-factor authentication systems, e.g. RSA SecurID®_or

SafeWord®_.

Both AD and NDS authentication is supported. RADIUS Protection Integrates with RADIUS systems providing SMS

PASSCODE®_{authentication for RADIUS clients. It is}

optionally possible to run this integration side-by-side with other RADIUS authentication systems, e.g. hardware-token based two-factor authentication systems.

When using Windows Server 2003, RADIUS protection is provided by means of an extension for the Microsoft Internet Authentication Service (IAS).

When using Windows Server 2008 or 2012, RADIUS protection is provided by means of an extension for the Microsoft Network Policy Server (NPS).

Besides VPN systems the RADIUS protection component is also useful for protecting access to Microsoft SharePoint Portal servers using application gateways, e.g. using Microsoft Intelligent Application Gateway, Microsoft Unified Access Gateway, Citrix Access Gateway Enterprise Edition or Juniper SA.

(7)

Cloud Application Protection Integrates with Microsoft Active Directory Federation Services (AD FS) 2.0 providing SMS PASSCODE®_{authentication for}

cloud applications protected by AD FS 2.0.

Cloud applications are supported that use form-based authentication, and use any of the following protocols for authentication:

 SAML 2.0

 WS-Federation

 WS-Trust

ISA/TMG Web Site Protection Integrates SMS PASSCODE®_{with Microsoft ISA/TMG}

Server, providing SMS PASSCODE®_{authentication for web}

sites directly on an ISA/TMG Server. The web sites are required to be published through the ISA/TMG server using a Web Listener.

Currently the following types of web sites are supported:

 Microsoft Outlook Web Access

 Microsoft Terminal Service Web Access (TS Web Access)

 Microsoft SharePoint Portal Server

 IIS web sites using authentication delegation

 Any web site not requiring any pass-through authentication (authentication delegation) SMS PASSCODE®_{authentication can be enabled and}

disabled for each specific Web Listener in the ISA/TMG server.

ISA/TMG Web Site protection is provided by means of an ISA/TMG filter.

(8)

IIS Web Site Protection Integrates SMS PASSCODE®_{with Microsoft Internet}

Information Server (IIS) providing SMS PASSCODE®

authentication for IIS Web Sites. Currently the following types of Web Sites are supported:

 Microsoft Outlook Web Access 2007, 2010 and 2013[2]

 IIS Web Sites using Basic or Integrated Windows Authentication5

 Microsoft Terminal Service Web Access (TS Web Access), Windows Server 2008 only.

 Microsoft Remote Desktop Web Access

(RD Web Access), Windows Server 2008 R2 only.

SMS PASSCODE®_{authentication can be enabled/disabled}

for each specific IIS web site – it is even possible to

configure different settings for specific URL’s and/or specific client IP addresses.

IIS Web Site protection is provided by means of an ISAPI filter.

Windows Logon Protection Integrates SMS PASSCODE®_{with Windows Logon, thereby}

providing SMS PASSCODE®_{authentication for users logging}

on Windows. This is for example useful for protecting Microsoft Terminal Service / Remote Desktop server environments, or VMware View virtual clients.

It is possible to enable and disable SMS PASSCODE®

authentication for each specific RDP Listener.

Windows Logon integration is provided by means of a custom GINA (Windows XP and Windows Server 2003) and a custom Credential Provider (Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 and Windows Server 2012 R2).

(9)

Secure Device Provisioning (for ActiveSync devices)

Integrates SMS PASSCODE®_{with Microsoft Exchange}

Server’s built-in functionality for provisioning of ActiveSync Devices, thereby providing secure, multi-factor authentication based self-provisioning of such devices.

The integration is provided by means of two components:

 The SMS PASSCODE®_{Monitoring Module, which is}

an HTTP Module that monitors the ActiveSync traffic on each server with the Exchange CAS role.

 The SMS PASSCODE®_{Secure Device Provisioning}

Web Site, to which users will be redirected for performing secure self-provisioning of new ActiveSync devices.

Password Reset Module  Password Reset Web Site  Password Reset Backend

Service

Add-on module providing a web site where SMS

PASSCODE®_{users that have forgotten their AD password}

can reset this password in a secure way.

The module consists of two components. Install the

components on separate servers or on the same server: The SMS PASSCODE®_{Password Reset Web Site and the SMS}

PASSCODE®_{Password Reset Backend Service.}

The Password Reset Web Site provides the user interface of the Password Reset module. It acts as a proxy for the actual Password Reset logic, which is performed by the Password Reset Backend Service.

The components Database Service, Web Administration Interface and Transmitter Service

are

required

components – i.e. they must always be present in an SMS PASSCODE

®

installation. The remaining components are optional.

The term

SMS PASSCODE

®

_{core component}

_{is used in the subsequent sections of}

this documentation to denote one of the components: Database Service, Web

Administration Interface, Transmitter Service, Load Balancing Service or Self Service

Web Site.

The term

SMS PASSCODE

®

_{Authentication client}

_{is used in the subsequent sections of}

this documentation to denote one of the components: Citrix Web Interface Protection,

RADIUS Protection, Cloud Application Protection, ISA/TMG Web Site Protection, IIS

Web Site Protection, Windows Logon Protection or Secure Device Provisioning

(10)

Page 10 of 10
