2018 TRAIL BRIDGE LOOKBOOK

(1)

2018 TRAIL BRIDGE LOOKBOOK

A photo journey: FiberSPAN trail bridges by Composite Advantage

(2)

What Defines a FiberSPAN Trail Bridge?

• Long lasting



Zero maintenance



Corrosion resistant materials

• Aesthetic look

• Prefabricated for quick installation



Beams, deck and railing included

(3)

NEW 2018

Standard FiberSPAN Trail Bridge Features

• NEW standard product to lower cost and reduce lead times

• Up to 50 ft Long

• Fiberglass Reinforced Polymer (FRP) deck

(4)

Sara Lee Arnovitz Preserve Bridge 1: Xenia, OH

Bridge size: 45 ft x 6 ft Bridge weight: 8900 lb

Requirements: 90 psf live load

Notes: First of three bridges on the walking trail at Sara Lee Arnovitz Preserve.

(5)

Sara Lee Arnovitz Preserve Bridge 2: Xenia, OH

Notes: Second of three bridges on the walking trail at Sara Lee Arnovitz Preserve built to replace a bridge damaged in a storm.

(6)

Sara Lee Arnovitz Preserve Bridge 3: Xenia, OH

Notes: Third of three bridges on the walking trail at Sara Lee Arnovitz Preserve to replace a damaged bridge.

(7)

Red Lion-5 Points: Springboro, OH

Notes: This trail bridge is part of a new trail the town of Springboro is creating along Red Lion-Five Points Road.

(8)

Jackson’s Grant: Indianapolis, IN

Requirements: 90 psf live load, 4000 lb utility vehicle

Notes: This new trail bridge is an addition to a new private development being built in Indianapolis.

(9)

Apartment Complex: Mason, OH

Requirements: 90 psf live load; 7500 lb vehicle

Notes: This zero-maintenance bridge is part of a walking trail at an upscale apartment complex.

(10)

Phillips Park: Beavercreek, OH

Bridge size: 45 ft x 6 ft Bridge weight: 13,500 lb

Features: Bridge and wear surface color match weathering steel. Notes: Bridge delivered as prefabricated unit for easy installation.

(11)

Centennial Park: Oakwood, OH

Bridge size: 35 ft x 8 ft Bridge weight: 5600 lbs Requirements: 90 psf

Features: Epoxy non-slip wear surface.

Notes: Wooden curbs compliment natural surroundings.

(12)

Crawford Town Park: Crawford, NY

Bridge size: 24 ft x 8.5 ft Bridge weight: 4500 lbs

Features: Aluminum railings, concrete abutments

Notes: The steel beams are fully encapsulated by fiberglass to ensure the longest life and lowest maintenance costs.

(13)

Germantown MetroPark: Germantown, OH

Bridge size: 20 ft x 5 ft Bridge weight: 2000 lbs

Requirements: 90 psf live load; 10,000 lb vehicle Features: Steel railings, Ashton Gray color match

Notes: Easy install, even in mid-winter – drag and drop.

(14)

Winona Lake Fire Department: Newburgh, NY

Bridge size: 17 ft x 3.5 ft Bridge weight: 1300 lbs

Notes: We created a lightweight, prefabricated bridge that Winona Lake FD installed themselves.

(15)

Trail bridge, Germantown, OH

Bridge span: 20 feet Bridge weight: 2000 lbs

Requirements: 90 psf live load. 10,000 lb vehicle Railing type: Steel

Custom color: Ashton Gray

Notes: Easy install, even in mid-winter – drag and drop!

Boone County National Forest: Morehead, KY

Features: Epoxy non-slip coating, custom color (Bahama Brown), concrete abutment Notes: Connects to US Forest Service visitor center. Installed in two hours to minimize access disruption.

(16)

East Loveland Nature Preserve: Loveland, OH

Bridge size: 50 ft x 7.7 ft Bridge weight: 22,000 lb

Features: Concrete abutment with Helical Piles

Notes: Bridge and three beams molded together as one unit.

(17)

Bridge Owners Agree

“As a trail designer, I find that the Composite Advantage

FiberSPAN bridges are cost competitive with other designs. I

find the FiberSPAN bridges can be designed to meet

individual needs for weight capacity and length. The helical

pier footers make installation faster, easier and less

expensive than standard footer and pier construction.

Durability and length of service for the FiberSPAN bridges

can't be matched by other materials. The variety of color

choices and deck surfaces allow me to fit a bridge into any

environment.”

(18)

2018 TRAIL BRIDGE LOOKBOOK
