Outdoor LED Lighting \

(1)

®

\2020-2021

Outdoor LED Lighting

(2)

LED FLOOD LIGHT

APPLICATIONS

A floodlight is a broad-beamed, high-intensity artificial light. They are often used to illuminate outdoor playing fields while an outdoor sports event is being held during low-light conditions.

BENEFITS OF LED FLOOD LIGHT

Long Life:LEDs last up to 10 times longer than other filament or gas-based lights and remain operational for almost 50,000 hours

Energy Efficient

Controlled Heat Emission: LED floodlights limit heat emissions as they convert and conserve maximum amount of electricity.

Environment-friendly:LED flood lights are free from various toxic elements. Unlike traditional lighting solutions, they don’t contain carbon, mercury, lead or glass

Cost-Efficient:LED flood lights are highly cost-efficient as compared to HID lamps or halogen

lights. Lesser electricity consumption, low maintenance costs, longer life, etc.

(3)

Hylumen LED FLOOD LIGHT

• LED FLOOD LIGHT 50/100/150/200/300W Front Choke

• LED FLOOD LIGHT 50/100/150/200/300W/360W/420W BACK Choke

Technical Specification

Input Voltage 110V to 285V AC

310V Auto Cut-off 440V Protection

Power Consumption 50W/100W/150W/200W

Lumens 140 Lm/W

Light Source 1 Watt, 3030

LED Life => 50,000 Hrs*

Colour Temperature Cool White 6500K, Warm White 2700-3000K System Efficiency >90%

Colour Index (CRI) >80%

Beam Angle 120 Degrees

Power Factor (PF) >0.95%

Protection Short Circuit, Open Circuit, Over Voltage Under Voltage Protection

THD <=10%

Electronic Efficiency >=85%

Working Temp. -40°C + 80°C

Surge withstand 4 Kv

Enclosure

Pressure die cast aluminium with efficient heat dissipation design & Coating

Connecting Cable 3 Core (minimum 0.5mm2)

Driver

Driver Internal

Qty 1/2/3/4/5

Optical Parameter

LED Brand OSRAM

LED Used 1W 3030

No. of LED 50/100/150/200/300 LED

Housing Parameters

Shape Rectangular

Protection IP66

Glass Toughened Glass

Material Aluminium Die Cast

(4)

APPLICATIONS LED STREET LIGHT

An LED street light or road light is an integrated light-emitting diode light fixture that is used for street lighting

LED lights reach full brightness instantly - They do not require time to warm up, which makes them a flexible light source. Far more environmentally friendly –

They do not contain lead or mercury and do not omit any poisonous gases.

They also give off less CO2 emissions.

Long and predictable lifetime: The projected lifetime of LED street lights is usually 10 to 15 years(50000 Hours), two to four times the life of currently prevalent HPS.

Low maintenance costs: LED streetlights do not need extra investments for maintenance. They have a solid structure and long life span

BENEFITS OF LED STREET LIGHT

(5)

• LED STREET LIGHT GLASS 18W/24W/36W/50W/72W/100W

• LED LENS STREET LIGHT 24W/30W/36W/50W

Technical Specification

Input Voltage 110V to 285V AC

310V Auto Cut-off 440V Protection

Power Consumption As per Wattage Capacity

Lumens 140 Lm/W

Light Source 1 Watt, 3030

LED Life => 50,000 Hrs*

Colour Temperature Cool White 6500K, Warm White 2700-3000K

System Efficiency >90%

Colour Index (CRI) >80%

Beam Angle 120 Degrees

Power Factor (PF) >0.95%

Protection Short Circuit, Open Circuit, Over Voltage Under Voltage Protection

THD <=10%

Electronic Efficiency >=85%

Working Temp. -40°C + 80°C

Surge withstand 4 Kv

Enclosure Pressure die cast aluminium with efficient heat dissipation design & Coating

Connecting Cable 3 Core (minimum 0.5mm2)

Driver

Driver Internal

Size As per wattage

Qty As per Wattage

Optical Parameter

LED Brand OSRAM

LED Used 1W 3030

Current 1500 mA

No. of LED As per Wattage

Housing Parameters

Shape Rectangular

Protection IP65

Glass Toughened Glass

Material Aluminium Die Cast

HYLUMEN LED STREET LIGHT

(6)

HYLUMEN LED HIGH BAY LIGHT

LED HIGH BAY LIGHT 60W/100W/120W/150W/180W

Made of strong material and have the capacity of working efficiently in high-temperature conditions with maximum lumens perwatt.

Specifications

Input Voltage:110V to 285V AC Power: 60/100/120/150/180 W Lumens: 140 Lm/Watt

Body: LED well glass with pressure die cast housing duly powder coated with polycarbonate diffuser suitable for ceiling .

• IP65 Protected

• Uniform Lighting

• Suspended in Nature

• Glare-Free

• High-Quality Lighting

• HYLUMEN LED WELL GLASS LIGHT

LED WELL GLASS LIGHT 30/60/90/120W

Technical Specification Input Voltage

Power Consumption Lumens

Light Source LED Life

Colour Temperature System Efficiency Colour Index (CRI) Beam Angle Power Factor (PF) Protection

THD

Electronic Efficiency Working Temp.

Surge withstand Enclosure Connecting Cable

110V to 285V AC 310V Auto Cut-off 440V Protection

As per WattageCapacity 140 Lm/W

1 Watt,3030

=> 50,000 Hrs*

Cool White 6500K, Warm White2700-3000K

>90%

>80%

120 Degrees

>0.95%

Short Circuit, Open Circuit, Over Voltage Under VoltageProtection

<=10%

>=85%

-40°C + 80°C 4 Kv

Pressure die cast aluminium with efficient heat dissipation design & Coating 3 Core (minimum 0.5mm2)

Driver

Driver Size Qty

Internal As per wattage As per Wattage Optical Parameter

LED Brand LED Used Current No. of LED

OSRAM 1W 3030 1500 mA As per Wattage

Housing Parameters Shape

Protection Glass Material

Rectangular IP65

Toughened Glass Aluminium Die Cast

.

(7)

LED GLASS STREET LIGHT

LED Street Light Lens

Model Name Wattage Colour Body

HYLESL24W 24 Watt White Aluminium

HYLESL30B 30 Watt Black Body(Eco) White Aluminium

HYLESL50WB 50 Watt Black Body(Eco) White Aluminium

LED Slim Flood Light

HYSLFL50W 50 Watt White Aluminium

LED LENS STREET LIGHT

LED SLIM FLOOD LIGHT

LED Street Light Glass

Model Name Wattage Colour Body

HYGLSL18W 18 Watt White Aluminium

HYGLSL50WE 50 Watt Eco White Aluminium

HYGLSL100W 100 Watt White Aluminium

(8)

LED BACK CHOKE LIGHT

LED Back Choke Flood Light

HYDCFL50W 50 Watt White Aluminium

LED High Bay Light

HYHB60W 60 Watt White Aluminium

LED Well Glass Light

Model Name Wattage Colour

Body

HYWG30W 30 Watt White

Aluminium

LED HIGH BAY LIGHT

LED WELL GLASS LIGHT

(9)

ABOUT US

Hylumen is well recognized brand name in LED Lighting. An ISO 9001:2015 Certified organization is a pioneer in the field of LED based Lighting Systems and has been engaged in manufacturing and exporting of LED based Lighting Systems, Consumer goods and other Industrial Products. The company is managed by the team of professionals from Electronics and Lighting Industry whose only goal is to design and manufacture world class lighting products. Our products are precisely manufactured as per the highest electrical specifications to ensure highest performance, aesthetics as well as functionality. With this, in a short span of time we have been able to deliver our services to some of the most well-known and discerning clients in India and have set up a strong reference list of clients and projects. We are one of the largest manufacturers of LED Lighting products in India. We have manufacturing facilities in Ahmedabad Gujarat, with complete infrastructure for R&D, Manufacturing and Testing. We would like to draw your kind attention to the main features of our LED based indoor and outdoor lights.

Advantages of Hylumen LED Lights

1.Long life

2.Energy efficiency

3.High brightness and intensity

4.Exceptional color range

5.Low radiated heat

6.Reliability

7.Instantaneous illumination

8.Directional lighting

(10)

CERTIFICATES

We are ISO 9001:2015 Certified .We are CE ,ROHS Certified which makes our led very safe to use .We are also Registered with MSME.

CE CERTIFIED ISO 9001:2015 CERTIFIED

ROHS CERTIFIED MSME REGISTERED
