CipherLab Data Terminals
Maximum Benefits
for
Warehousing / Transportation & Logistics
Lisa ChenCorporate
Profile
•
Founded in 1988
•
Public listed on Taiwan OTC in
2002
Stock code 6160
•
Headquartered in Taipei, Taiwan
Branch offices established in
◦
Shanghai, China
◦
Dallas, USA
Americas Asia-Pacific
Globe Business
Coverage
EMEA USA Brazil Canada Argentina Chile Germany UK Denmark Italy Russia Poland S. Africa France Czech Hungary Spain Ukraine Romania Belgium Serbia Turkey Israel Lebanon Taiwan China Japan Australia Korea Hong Kong Singapore Thailand Philippines Indonesia Vietnam Malaysia Taiwan(Head Quarter) USA (Branch Office)Germany (Branch Office) UK
Denmark
Italy
China (Branch Office)
Japan
Australia
04 1704 / 1704DC 1861/1862 CP30 8000/ 8000H 8200/ 8200H Enterprise Mobile Computers 8300 8400 8700 CP50 CP60
Industrial Mobile Computers
9600 1000/ 1090+ 1070 1200 1662/1663 1166 1266 1664(H) 1660/ 1661(H) 1560 1100
Bluetooth Scanners Industrial Scanners General Scanners 9200 1500 Enterprise Mobile Computers 8600
Rugged
Gun-type
Pocket-size
RFID
Contact
1500/1500H Series 1861 1700 Series 1000/ 1090+ 1070 1100/1200 Series 1660/ 1661 1662/1663/1664General
Product Portfolio – Reader
1862
Industrial
Enterprise
Product Portfolio – Handheld
Terminal
cOS
8300 Series
8000 Series8200 Series 8600 Series8700 Series
9200
Win OS
9700 8400 Series New NewIndustrial
Enterprise
Product Portfolio – PDA
Win OS
CP30 CP50 CP60Android OS
Mercury CP55 New (Q4) NewGood reference for
Case Reference
Italy Pd Plants: 9200 x 170pcs
010
Case Reference
France Figaro Newspaper: 8400 x 850pcs
For Warehouse Management of their on-line shopping platform
011
Case Reference
Russia Gloria Jeans retail chain: CP50 x 1,000pcs
012
Case Reference
Taiwan Post: CP60 x 400pcs
013
Case Reference
Corning Glass (Taiwan, Japan & USA) : CP60 x 300pcs
014
Case Reference
Grands Moulins de PARIS, France : CP60 x 250pcs
What’s more
for the market…
- CP55
- 9700
- 1862
Page 16
2014 Product Launch Schedule
Q4
CP55 Mercury 1862 8600 9700Q3
Q2
Q1
Windows Mobile Computer – 9 & CP Series
9600,CP30, CP50,
New CP55
, CP60 , 9200 &
New
9700
Page 19
CP55
Features
• Powerful OMAP4 1.0Ghz Dual Core Processor • WinCE7.0 / WEH6.5
• Dual band 802.11 a/b/g/n
• IP65, multiple 1.5m drops to concrete • HTML 5 support
• Versatile Reader Options
(Linear Imager, Laser, Long-Range Laser, 2D, Optional HF RFID)
Model CP55 CN51
OS WEC 7/WEH6.5 WEH6.5 / Android 4.1
CPU OMAP4 1GHz dual core TI OMAP4470 1.5GHz
Memory 512MB x 4GB 1GB x 16GB
Display 3.5” QVGA/VGA 4" WVGA
Reader 1D/2D/LR Laser 2D(EA30/EA31)
Camera 5M AF/ LED 5 Mega Pixel(Option)
RFID HF RFID N/A
Battery 3300mAh 3.7V, 3900mAh
WLAN 802.11 a/b/g/n 802.11 a/b/g/n, CCXv4
WPAN Bluetooth v2.1 Bluetooth v4.0
WWAN HSPA+
(Voice & Data) UMTS / HSPA+ (Voice & Data)Flexible Network™ (Voice & Data)
GPS GPS/A-GPS GPS
Drop 1.5m 1.5m
IP IP65 IP64
Tumble 1000 (0.5m) tumbles 1,000(0.5m) tumbles
Weight 400g 350
Temperature O: -20°C to 50°C
S: -30°C to 70°C O: -10° C to 50° CS: -20° C to 70° C
Humidity 5 to 95% non-condensing Non-condensing, 95%
Remark Available on vehicle snap on charger and cradle
Primary
Market
Warehouse
Order Picking & Staging
Product
Labeling &
Tracking
Shipping &
Receiving
Mobile
Inventory
Manageme
nt
Secondary
Market
Manufactur
e
Replenishment
Quality
Controlling
Typical Applications
Page 23
9700
Handheld Terminal for Warehousing /Manufacture
Features
• Complete thin client solution
• Complete terminal emulation suites.
(Together with various TE physical keypads layout) • RDP
• Browser • HTML 5
• Modular reader
Easy to fulfill different environments.
Page 24
Accessory
Charging &
Communication Cradle
Snap On Cable Pistol Grip
Page 25
Why 9700?
Manufactur
er CipherLab Intermec Intermec Honeywell Model 9700 CK3X CK3R 6500 Operating
System 6.0/WEH6.5WCE WEH6.5 WEH6.5 WCE 5.0/WEH 6.5
CPU OMAP3 1GHz OMAP3 1GHz OMAP3 1GHz PXA300 624 MHz
RAM/ROM 512MB/4GB 256MB/1GB 256MB/512MB 256MB/256MB
Display 3.5“ QVGA 3.5" QVGA 3.5” QVGA 3.5” QVGA
Barcode
Reader XL Laser/ XL 2DLaser/ 2D 2D/ XL 2D 2D Laser / 2D
Battery 3.7V, 3600/5400
mAh 5100/ 5200mAh3.7V, 2000/ 5100/ 5200mAh3.7V, 2000/ 3.7 V, 2200/ 3300mAh
WLAN 802.11 a/b/g/n, CCX 802.11 a/b/g/n, CCX 802.11 b/g/n, CCX 802.11b/g, CCX Dimensions 210x85x30 216 x 83 x 36 216 x 83 x 28 200 x 83 x 44 Weight 400g 499g (5100) 401g (2000) 360g (2200) Op Temp -20° C to 50° C -10° C to 50° C -10° C to 50° C -10° C to 50° C Ruggednes
UHF RFID reading and writing capabilities. Compatible with Bluetooth® mobile devices.
IP64 rating and 1.5 m/ 5 ft. drop resistance. Sustains 1,000 tumbles at 1 m/ 3.3 ft.
Optional snap-on mount integrates your mobile computer and 1861 handheld RFID reader into one robust device.
Max. reading range: 1 m/ 3.3 ft; max. writing range: 0.5 m/ 1.6 ft.
026
Handheld RFID Reader – 1860 series
1861 provides you flexibility by empowering your current mobile devices
UHF RFID data capture capabilities
Target vertical: Warehousing,
Transportation & Logistics
,
Field
Mobility
,
Enterprise Asset Management and Retail Inventory
Management.
Page 27
Product Development Div. II
CP50 Mount
9600 Mount
Universal Mount
Page 28
Product Development Div. II
Xperia Z
iPhone 5S Galaxy Note
Page 29
1862 RFID Reader
Handheld RFID Reader for Retail / Warehousing
Features
• High-performance UHF module • Extend reading range (3~5m)
• Multi-tag capture performance • Selectable receive sensitivity • Antenna automatic tuning
Page 30
Mercury
Android Smartphone for Field Sales, Field Service
Features
• Cortex A7 1.3Ghz Quad-Core Processor • Android 4.3 Platform
• 4.7” IPS QHD Display, Corning Gorilla Glass • IP67, multiple 1.2m drops to concrete
• 802.11 b/g/n , Bluetooth V4.0, NFC • Optional CCD/Laser/2D barcode reader
Page 31
2014 Product Launch Schedule
Q4
CP55 Mercury 1862 8600 9700Q3
Q2
Q1
Page 32
Special Offer for Partner Day!
59% off from List Price with limitet QTY 30pcs
54%off from List Price
