LandWarNet Initial Capabilities Document NetOps Tools Convergence Strategy Update

(1)

LandWarNet Initial Capabilities Document

NetOps Tools Convergence Strategy

Update

11 September 2013

Al Morrison

TCM GNE

Signal CDID

(2)

2

UNCLASSIFIED 2

1. LandWarNet Initial Capabilities Document

(LWN ICD)

LandWarNet ICD is the Army Enterprise

requirements package!

(3)

3 LWN ICD Scope

The

LWN ICD

describes the direct and supporting

capabilities of the Army Enterprise Network at and above the

Combined/Joint Task Force (C/JTF), “

outside the tactical

formation.

”

The

Network Enabled Mission Command (NeMC) ICD

describes how a networked capability for information

exchange integrates warfighting and generating force

(4)

4

UNCLASSIFIED

GIG 2.0 ICD

29 MAY 2009

GIG IA ICD

6 MAR 2006

LWN ICD Scope (updated)

LWN – “Above the seam” Enterprise Services, Installation Capabilities, Authoritative Data Sources, Enterprise transport, universal ID management, messaging, collaboration services… WfF Requirement Documents

Nested Army Unified NETOPS and Network Policies/Standards LWN ICD “En a b le s th e Ed g e ” “T he E dg e” NeMC ICD WIN-T CDD JTRS ORD NT, NETOPS, C/EM Contest, Intelligence CBAs

(5)

5 LWN ICD GAPs:

Sources

GIG 2.0/GIG IA ICD

C/EM CBA

(NetOps Gaps)

• GAP 1 (Common Standards)

• GAP 2 (C2)

• GAP 11 (Enterprise Network)

• GAP 15 (MC Transition)

• GAP 17 (Single Identity)

• GAP 19 (JIIM Integration)

• GAP 20 (Defense in Depth)

• GAP 24 (Information Services)

LWN ICD

(updated annually) • GAP 1 (Common Standards)

• GAP 2 (Enterprise Network)

• GAP 3 (MC Transition)

• GAP 4 (Single Identity)

• GAP 5 (JIIM Integration)

• GAP 6 (Defense in Depth)

• GAP 7 (Information Services)

• Gap 8 (SCI Network Services)

NETOPS CBA NT CBA EMSO CBA NeMC CBA

Intelligence CBA

• Gap 6 (Intelligence Enterprise (IE)

•Gap 7 (Information Collection Sync.

(6)

6

UNCLASSIFIED

LWN ICD Current Staffing Timeline

LWN ICD to ARCIC TBD 04 Mar 2011 3-Star AROC Review 11 Jun – 18 Sept 13 AROC Published TRADOC/ ARCIC Validation ARCIC G3 Gatekeeper Review 07 Mar – 07 Apr 11 25 Oct – 09 Feb 12 HQDA Review-1Star ARCIC Adjudication Review 06 Jul – 11 Jul 12 08 – 21 Apr 11 TCM GNE Adjudicate Comments AROC Approval/Validation 24 Oct 11 – 30 Aug 12 HQ TRADOC/ARCIC Validation 04 Mar 11 – 23 Oct 11 JROC Validation TBD ARCIC Dir. Validation 22 Apr – 23 Oct 11 G3 Gatekeeper 2nd_{Review /} TRADOC Re-adjudication 12 Jul 12 – 09 Apr 13 As of 15 August 2013 TCM GNE Adjudicate Comments 13 Feb – 05 Jul 12

(7)

7

Enterprise Management IS CDD DCO IS CDD Enterprise Information Services IS CDD Electromagnetic Battle Management CDD

LWN ICD

One or more RDPs One or more RDPs One or more RDPs • Host Security CD

•Joint Security Arch CD

• CD…

• Core Data Centers CD

• Thin/Zero Client CD

• CD…

Requirements Document Strategy (notional)

NeMC

ICD

Infrastructure Business Case Business Case Documents •ICAN • Installation Processing Nodes •WAN •WAN Diversity

•Land Mobile Radio

COLOR CODE:

Approved Document - Black > HQDA Staffing - Blue

< SIGCoE Development– Red

C-IED Joint Capability Technology Demo (JCTD) Multiple CPDs •Spectrum Sensing • EW Integration • CPD… • Network Mgmt CD •SATCOM Mgmt CD • CD … Two CDDs and an IS ICD will refine

LWN ICD capability requirements. The IS ICD points to the NeMC and LWN ICDs as well as GIG ICDs. The EMBM CDD points to the JCTD. Multiple CPDs or RDPs (as needed) further refine ICD/CDD

requirements for procurement. CDs/CPDs are written and updated incrementally in line with CIO/G6, NETCOM, CERDEC and ARCYBER priorities.

All CPDs/RDPs/CDs require synchronization within the

Signal CDID to ensure interoperability.

One or more

(8)

8

UNCLASSIFIED 8

PROBLEM STATEMENT: The Expeditionary Force lacks the ability to plan,

operate, and defend a responsive network with end-to-end transparency due to a

nonintegrated approach to Network Operations (NetOps).

(9)

9 NetOps Convergence

(Terms of Reference)

WIN-T NMS WIN-T NMS WIN-T NMS WIN-T NMS WIN-T NMS

• Convergence: Consolidation to a single set of “tools;” packaging of toolset based on required function and DOTMLPF.

• Integration: Items/tools included as inherent elements within larger WIN-T application; common user interface

• Federation: Items/tools run on WIN-T

hardware, but preserve their native interfaces. They “appear” and are accessed as services on the network.

• Assimilation: Items here are allocated SWAP in the NOSC (i.e., 2 separate laptops, just co-located )

• Absorption: Functionality is achieved using a different tool.

(10)

10

UNCLASSIFIED

Converge

Expeditionary Force NetOp

Tools

NIE 12.2

NIE 13.1

NIE 13.2

Capability Set

13-14

14-15

IOC Date 3QFY12. (WIN-T Inc 2) NMS 1QFY14 (TSS/LUT) NMS 1QFY15 (LUT) NMS Net Management ENP/ENM MCPTI/CNMPS SNMPc NetMRI NetFlow SolarWinds Putty *JENM HCI (NCW) SXXI EZ Radio Mfr BSM NCW Eng Tool/PT RAPTer ENP/ENM MCPTI/CNMPS SNMPc NetMRI NetFlow SolarWinds Putty *JENM HCI (NCW) SXXI EZ Radio Mfr BSM NCW Eng Tool/PT RAPTer ENP/ENM MCPTI/CNMPS NetFlow Putty JENM Content Management vSphere SCOM/SCCM vSphere SCOM/SCCM vSphere IA/CND SKL

CS-MARS  Nitro ESX HBSS MGR Retina

Hercules REM/Retina

Microsoft IAS

SKL

Hercules REM/RetinaMicrosoft

IAS

SKL

HBSS MGR Retina

Hercules

REM/RetinaMicrosoft IAS

Integrated

,

Federated

,

Assimilated

,

Absorbed

*Does not include non-proponent tools e.g. Trogan, CSS VSAT, etc.

COMSEC GEMX SLVD LCMS TKMS JACS/ACES GEMX SLVD LCMS TKMS JACS/ACES GEMX SLVD LCMS TKMS JACS/ACES KMI EMSO SXXI CJSMPT BSM SXXI CJSMPT BSM BSM Start Point 32 toolsets under review 10

(11)

11 Converge

Expeditionary Force NetOp

Tools

NIE 14.1

NIE 14.2

NIE 15.1

Capability Set

15-16

16-17

17-18

IOC Date 3QFY12. (WIN-T Inc 2) NMS 1QFY14 (TSS/LUT) NMS 1QFY15 (LUT) NMS Net Management ENP/ENM MCPTI/CNMPS SNMPc NetMRI NetFlow SolarWinds Putty *JENM HCI (NCW) SXXI EZ Radio Mfr BSM NCW Eng Tool/PT RAPTer ENP/ENM MCPTI/CNMPS SNMPc NetMRI NetFlow SolarWinds Putty *JENM HCI (NCW) SXXI EZ Radio Mfr BSM NCW Eng Tool/PT RAPTer ENP/ENM MCPTI/CNMPS NetFlow Putty JENM Content Management vSphere SCOM/SCCM vSphere SCOM/SCCM vSphere IA/CND SKL

Hercules REM/Retina

Microsoft IAS

SKL

Hercules REM/RetinaMicrosoft

IAS

SKL

HBSS MGR Retina

Hercules

REM/RetinaMicrosoft IAS

Integrated

,

Federated

,

Assimilated

,

Absorbed

*Does not include non-proponent tools e.g. Trogan, CSS VSAT, etc.

COMSEC GEMX SLVD LCMS TKMS JACS/ACES GEMX SLVD LCMS TKMS JACS/ACES GEMX SLVD LCMS TKMS JACS/ACES KMI EMSO SXXI CJSMPT BSM SXXI CJSMPT BSM BSM Start Point 22 Tools approved

(12)

12

UNCLASSIFIED

• Team effort:

– SIGCoE

– ASA(ALT) PEO’s & PM’s

– CIO/G-6 – LWN MC/Rand – CERDEC – TRAC-WSMR – ATEC

• Objectives

–

Functional analysis/evaluation of iSEP recommendations

• Analyze capabilities within existing tools; identify redundancies and tools that overlap

• Providing an operationally based systems engineering supportable recommendation

–

Assess MOS training and implementation

• Completing a workload analysis by MOS

• Make informed recommendation for future FSR Requirements

• NIE 12.2 assessment completed awaiting formal release of RAND Study results.

NetOps Convergence informed by NIE 12.2 results

12

(13)

13
