Simulation and Design Route Development for ADEPT-SiP

(1)

Simulation and Design Route

Development for ADEPT-SiP

Alaa Abunjaileh, Peng Wong and Ian Hunter The Institute of Microwaves and Photonics School of Electronic and Electrical Engineering

The University of Leeds Malcolm Edwards

(2)

Outline

HDI/ Substrate Architecture

Passive Components Modelling

Resistors

Capacitors

Inductors

Transmission lines/resonators

Work Plan and Developments

End Users Demonstrators

(3)

ADEPT-SiP Architecture

embedded passives ADEPT-SiP module HDI substrate active devices encapsulation motherboard

(4)

ADEPT-SiP PCB Substrate Architecture

• The ADEPT-SiP printed circuit board architecture involves:

– 6-layer board construction with 2 conductor layer core

sequential build-up.

– High Density Interconnect (HDI) layers on either side of this

core.

(5)

Design Rules –

HDI/Microvia

• Outer Layer ¾ Track width>100μm

¾ Distance track-track width>125μm

• Inner Layer ¾ Track width>100μm

¾ Distance track-track width>100μm

• Microvia

¾ Standard - padΦ=300μm

¾ Stacked - padΦ=300μm

(6)

Design route development

• Well-defined process architecture • Stable process & known capabilities

• Produce component characterisation boards

• RFOW measurements

• S-parameter extraction • Model generation

• Design kit integration

Ground Signal Ground Ground Signal Ground

(7)

Design route application

• design specification

• schematic capture - hierarchical • simulation & optimisation

• component generation • circuit layout

• re-simulation

• design tolerance & yield

• design for test, reliability.... • mask layout • verification - DRC, LVS • design documentation Design Specification Circuit Description Component & Layout Libraries Analysis Optimisation Layout Verification Fabrication Models Design Rules

(8)

Passive Components Simulations

• Test Vehicle 1 (TV1) Modelling and Simulations

Summery:

– 30 Microstrip transmission lines (including coplanar)

– 48 Spiral Inductors ( Square and Circular)

– 56 Capacitors (PTF and Prepreg)

(9)

(10)

(11)

Transmission lines

Interconnect coupon is divided into four 25x25mm areas, where the line lengths are 5, 10 and 20mm.

Zo(Ω) Tx line type Structure Line width (μm)

(w-width, s-spacing)

50 Microstrip M1M3 (M1 trace, M3 ground) w50+15=>170

i.w50=>185

ii.w50-15=>200 50 Microstrip M2M3 (M2 trace, M3 ground) w50+15=>113

i.w50=>98

50 CPW M2 coplanar w=1880, s=100

50 CPW M1 coplanar w=1080, s=100

(12)

Transmission Lines and Resonators

• Coplanar Waveguide ¾ M1 (Ground Plane), t= 36 μ m ¾ Zo = 100Ω ¾ l = 5, 10, 20mm, h=60 μ m ¾ εr=5.4, tangent loss=0.035

• Supported Coplanar Waveguide*

¾ M2 (Ground Plane), t= 9 μ m

¾ Zo = 50 Ω, 100Ω

¾ l = 5, 10, 20mm, h=60 μ m

¾ εr=5.4, tangent loss=0.035

.

*S. S. Bedair and I. Wolff, “Fast, Accurate and Simple Approximate Analysis Formulas for Calculating the Parameters of Supported Coplanar Waveguides for MMIC’s,” IEEE Trans. Microwave Theory Tech., Vol.40, No.

(13)

Polymer Thick Film Resistors

• 100Ω/square carbon based inks are used.

Length(mm) Width (mm) 0.5 1 1.5 3 5 0.5mm width family 100 Ω 200 Ω 300 Ω 600 Ω 1000 Ω 1.0mm width family 50Ω 100 Ω 150 Ω 300 Ω 500Ω 2.0mm width family 25Ω 50Ω 75Ω 150 Ω 250Ω 3.0mm width family 16.6 7Ω 33.3 Ω 50Ω 100 Ω 166.6 7Ω

(14)

Capacitors

• Two classes of capacitors:

– Polymer Thick Film Capacitors – Prepreg Capacitors

(15)

PTF Capacitors

•Thickness 20um •Dielectric constant = 40 •Capacitance 16pF/mm2

(16)

Prepreg

Capacitors

– Thickness 50um

– Dielectric constant = 4 – Capacitance 1pF/mm2

(17)

Copyright © 2007 Prepreg Capacitor 0 2 4 6 8 10 12 14 1 1.5 2 2.5 3 3.5 4 Dimensions (Squared mm) C a p a c ita n c e (p F ) M1M2_THRU_M3_KEEPOUTS-Cal M1M2_THRU_M3_KEEPOUTS-Sim M1M2_THRU_M3_GROUNDED-Cal M1M2_THRU_M3_GROUNDED-Sim M1M2_COMMON_ELECTRODE_THRU_M3_KEEPOUTS-Sim

(18)

Prepreg Capacitor 0 2 4 6 8 10 12 14 16 1 1.5 2 2.5 3 3.5 4 Dimensions (Squared mm) R es ona nt Fre q ( G H z) M1M2_THRU_M3_KEEPOUTS-Res M1M2_COMMON_ELECTRODE_THRU_M3_KEEPOUTS-Res M1M2_THRU_M3_GROUNDED-Res

(19)

(20)

Inductors

• TV1 include Square and Circular Spiral inductor classes.

• The inductor spirals are defined on Conductive Layer 1 (M1) and the underpass on Conductive Layer 2 (M2).

(21)

Inductors

Inductors; Circular Spirals with Gnd keep outs of 125, 250 and 500um 0 20 40 60 80 100 120 0 1 2 3 4 5 6 7 8 No. of Turns In d u ct an ce n H 0 5 10 15 20 25 30 Q u al it y F act o r L125 L250 L500 L_Q_250 L_Q_125 L_Q_500

(22)

Inductors

Inductors; Circular Spirals with Gnd keep outs of 125, 250 and 500um with the respective cutoff frequency

0 20 40 60 80 100 120 0 1 2 3 _{No. of Turns}4 5 6 7 8 Induc ta nc e nH 0.5 1.5 2.5 3.5 4.5 5.5 6.5 7.5 8.5 9.5 Fr e q ( G H z) L125 L250 L500 L_CF_125 L_CF_250 L_CF_500

(23)

(24)

TV 1 Inductors Coupon

Inductance Line width

Spacing

Number of Turns Rin

Quality Factor Line width

Total length Conductivity

Self resonance frequency Substrate dielectric constant

Substrate thickness Total length

(25)

(26)

Future Developments

• Improve inductors performance (L, Q, Fres). • Study various configurations for embedded

(27)

TV 2 Calibration Coupon

• Transmission lines (also resonators)

– Short – Open – Loaded – Terminated • Coupled Lines • Ring resonators – At 3 and 5GHz

(28)

(29)

(30)

TV2 Partners Contribution

• Filtronic

(31)

AWR Design Environment

• The Designers View … mixed technology

M1 M1 Cap_PTF_M1M1 ID=Cap_PTF1 L=1000 um W=1000 um C=17.7 pF IND ID=L1 L=1 nH IND ID=L2 L=3 nH VIA ID=V1 D=127 um H=1651 um T=17.78 um RHO=0.7 VIA ID=V2 D=127 um H=1651 um T=17.78 um RHO=0.7 SMD Embedded Passive

(32)

AWR Design Environment

• The Designers View … 2D and 3D views

2D View 3D View

The Process Design Kit (PDK) defines

(33)

AWR Design Environment

<SUMMARY>This file contains data for the Wurth Elektronik 6 Layer HDI Process</SUMMARY> <COMPONENT Name="CAP PTF M1M1">

<DESC>PTF Capacitor with 2 Pins and integrated vias to M1</DESC> <SYMBOL>[email protected]</SYMBOL>

</COMPONENT>

Points to a parametric cell (pCELL) located in DLL Points to model located in DLL

Initial Parameter used to define the component

(34)

AWR Design Environment

• Parametric Cells …

– The AWR Design Environment supports ‘CALL BACK’

– Models can report back to the schematic symbol

M1 M1 Cap_PTF_M1M1 ID=Cap_PTF1 L=1000 um W=1000 um C=17.7 pF Edit the size

of the capacitor M1 M1 Cap_PTF_M1M1 ID=Cap_PTF1 L=1000 um W=500 um C=8.85 pF Editing can be conducted using the layout editor

(35)

AWR Design Environment

• The AWR Design Environment supports multiple

technology … load more than one PDK!

SMD Embedded Passive

GaAs MMIC

(36)

Conclusion

• TV2 Should include components with optimum

performance (R, L, C, Q and Fres). Various

configurations will be studied to obtain the best performance.

• The modelled components and results will be

built into the AWR-Process Design Kit (PDK), to design microwave devices (filters, baluns…etc) and partners demonstrators.
