CMA3000_User_Guide_09108217e

09108208

User Guide

CMA 3000

User Guide

CMA 3000

CE The CMA 3000 is CE-marked and complies with:

• EN 61326-1 : 2006

• EN300386 V1.3.3 (2005)

• EN61010-1

Reference Please read section 1.3, Warnings and take the recommendations there into consideration before using the instrument.

Software version This user guide covers SW version 4.3x.

Disclaimer The information contained in this document is subject to change without notice and does not represent any commitment on the part of Anritsu.

Title User Guide

Author Technical Documentation, Anritsu A/S, Denmark

Subject CMA 3000 SW version 4.3x

Order No. 09108217

Table of contents

1.1 Basic Instrument . . . 1 - 2 1.2 Symbols and Conventions . . . 1 - 3

1.2.1 Warnings . . . 1 - 3 1.2.2 Precautions . . . 1 - 3 1.2.3 Notes. . . 1 - 3 1.2.4 Hints . . . 1 - 3 1.2.5 Option . . . 1 - 3 1.3 Warnings . . . 1 - 4

1.3.1 General Service or Repair. . . 1 - 4 1.3.2 Information for Anritsu Authorized Personnel Only . . . 1 - 4 1.3.3 Mains Power . . . 1 - 5 1.3.4 Optical Laser . . . 1 - 5 1.3.5 Personal Warnings . . . 1 - 6

1.4 Precautions . . . 1 - 7

1.4.1 ESD (ElectroStatic Discharge) . . . 1 - 7 1.4.2 Radio Emissions . . . 1 - 8 1.4.3 Transportation . . . 1 - 8 1.4.4 Port Connectors . . . 1 - 8 1.4.5 Optical Surfaces . . . 1 - 9 1.4.6 Ventilation . . . 1 - 9 2 Configuration 2.1 Delivered Accessories . . . 2 - 2 2.1.1 Standard Accessories . . . 2 - 2 2.1.2 Optional Accessories . . . . 2 - 2

2.2 Mains Power Adapter . . . 2 - 3

2.2.1 Connecting Mains Power Adapter. . . 2 - 3

2.3 Rechargeable Battery . . . 2 - 4

2.3.1 Installing or Replacing Battery . . . 2 - 5 2.3.2 Charging Battery in Fast Mode . . . 2 - 6 2.3.3 Charging Battery in Normal Mode. . . 2 - 6 2.3.4 Battery Status Information. . . 2 - 7

2.4 Measurement Cables . . . 2 - 8

2.5.2 Carrying Strap (Optional) . . . .2 - 10

3 Man-Machine-Interface

3.1 Touch Screen Display . . . 3 - 2 3.2 Key Operation . . . 3 - 3

3.2.1 Power ON/OFF Key. . . 3 - 3 3.2.2 SHIFT Keys . . . 3 - 3 3.2.3 LED TRAP Key . . . 3 - 3 3.2.4 Start/Stop Key . . . 3 - 3 3.2.5 Error Key . . . 3 - 4 3.2.6 Volume Keys . . . 3 - 4 3.2.7 Navigation Keys. . . 3 - 4 3.2.8 Enter Key . . . 3 - 5 3.2.9 ESC Key . . . 3 - 5 3.3 LED Indicators . . . 3 - 6 3.4 Telephone Interface . . . 3 - 8 3.5 Earphone . . . 3 - 9 3.6 Back Panel Connectors. . . 3 - 10

3.6.1 Basic Instrument (2 Mbps). . . 3 - 10 3.6.2 Fully Equipped Instrument (Internally Mounted Modules) . . . 3 - 11 3.6.3 Ethernet 10/100/1000 Interface . . . 3 - 12 3.6.4 High Speed Single Port Interface. . . 3 - 13 3.6.5 High Speed Dual Port Interface . . . 3 - 14

3.7 Left Panel Connectors. . . 3 - 15 3.8 FrontSim Option . . . 3 - 16

3.8.1 Installation of FrontSim Software . . . 3 - 16 3.8.2 Connection and Setup . . . 3 - 16 3.8.3 Launching FrontSim. . . 3 - 16 3.8.4 Assigning Instruments to the List . . . 3 - 18 3.8.5 Selecting and Connecting Instruments From the List . . . 3 - 18

3.9 Command Based Remote Control Option. . . 3 - 19 3.10 External GPS Sensor. . . 3 - 20

3.10.1 Activating the GPS sensor. . . 3 - 21 3.10.2 Using the GPS service. . . 3 - 21 3.10.3 GPS status bar icon . . . 3 - 22 3.10.4 Setting the instrument time from the GPS sensor . . . 3 - 24

4 Graphical User Interface

4.1 General Handling of Screens . . . 4 - 2 4.2 Quick Start . . . 4 - 3

4.2.1 Loading, Renaming or Deleting a Setup . . . 4 - 3 4.2.2 Saving a Setup . . . 4 - 4 4.2.3 Load and Save Settings List . . . 4 - 4 4.2.4 Importing and Exporting Setups . . . 4 - 5

4.3 Interface > 2 Mbps. . . 4 - 6

4.3.1 Transmitter A and Transmitter B . . . 4 - 6 4.3.2 Receiver A and B . . . . 4 - 13 4.4 Interface > SDH . . . 4 - 17 4.4.1 Transmitter A. . . 4 - 17 4.4.2 Receiver A and B . . . . 4 - 19 4.5 Interface > E3/DS3. . . 4 - 20 4.5.1 Transmitter A and B . . . 4 - 20 4.5.2 Receiver A and B . . . . 4 - 22 4.6 Interface > E4. . . 4 - 23 4.6.1 Transmitter . . . 4 - 23 4.6.2 Receiver A and B . . . . 4 - 24 4.7 Interface > V-Series . . . 4 - 26 4.7.1 Codirectional Interface . . . 4 - 28 4.8 Interface > Ethernet . . . 4 - 31

4.8.1 Port Control Tab . . . 4 - 31 4.8.2 Port A/B setup > Traffic Sub-tab . . . 4 - 43 4.8.3 Port A/B setup > WAN Frame Sub-tab . . . 4 - 46 4.8.4 Port A/B Setup > Frame Content . . . 4 - 49 4.8.5 Port A/B Setup > Settings Sub-tab . . . 4 - 59 4.8.6 Port A/B setup > Filter Sub-tab . . . 4 - 61 4.8.7 Port A/B setup > Thresholds Sub-tab . . . 4 - 63 4.8.8 Port A/B setup > SyncE Sub-tab . . . 4 - 63 4.8.9 Port A/S setup > IEEE 1588v2 sub-tab . . . 4 - 65 4.8.10 Timing Tab. . . 4 - 69

4.9 Interface> T1 Unframed . . . 4 - 71

4.9.1 Transmitter A and Transmitter B . . . 4 - 71 4.9.2 Receiver A and Receiver B . . . 4 - 73

4.10 Application > Measurement . . . 4 - 75

4.10.1 General . . . 4 - 75 4.10.2 Signaling . . . 4 - 78 4.10.3 Filters (Log Measurement) . . . 4 - 79 4.10.4 Filters (Statistics Measurement) . . . 4 - 81

4.11 Application > Frame Relay . . . 4 - 82

4.11.1 Frame Relay . . . 4 - 82 4.11.2 Frame Relay BERT Load . . . 4 - 85 4.11.3 DLCI Statistics. . . 4 - 87 4.11.4 CIR Test . . . 4 - 88

4.11.7 Ping Test . . . 4 - 90 4.11.8 Ping Test Setup . . . 4 - 90 4.11.9 Ping Test Result. . . 4 - 91

4.12 Application > Auto Configure . . . 4 - 93 4.13 Application > Stimuli . . . 4 - 95 4.13.1 2 Mbps TxA and 2 Mbps TxB . . . 4 - 96 4.13.2 Frame Relay . . . 4 - 97 4.13.3 Codirectional . . . 4 - 98 4.13.4 ATM . . . 4 - 99 4.13.5 Frequency . . . 4 - 100 4.13.6 E3/DS3 TxA (TxB) . . . 4 - 101 4.13.7 SDH Alarm. . . 4 - 102 4.13.8 SDH Error . . . 4 - 103 4.13.9 AU4 Pointer . . . 4 - 104 4.13.10 TU3 and TU12 Pointer. . . 4 - 105 4.13.11 V-Series . . . 4 - 106 4.13.12 Ethernet . . . 4 - 107 4.13.13 Ethernet WAN . . . 4 - 108 4.13.14 Ethernet Timing . . . 4 - 109 4.13.15 Using Stimuli for Basic Transmission Line Test . . . 4 - 109

4.14 Application > ATM . . . 4 - 111 4.14.1 Transmitter. . . 4 - 111 4.14.2 Receiver A/B . . . 4 - 113 4.14.3 VP/VC Filter . . . 4 - 114 4.14.4 Scan. . . 4 - 115 4.15 Application > APS . . . 4 - 116 4.16 Application > Pointer Movement . . . 4 - 118 4.17 Application > Tributary Scan . . . 4 - 122 4.18 Application > Ethernet RFC2544 . . . 4 - 124

4.18.1 Test setup . . . 4 - 124 4.18.2 Port A/B . . . 4 - 128 4.18.3 General . . . 4 - 129 4.18.4 Test Configuration > Throughput . . . 4 - 131 4.18.5 Test Configuration > Frame Loss. . . 4 - 133 4.18.6 Test Configuration > Throughput and Frame loss . . . 4 - 133 4.18.7 Test Configuration > Latency . . . 4 - 135 4.18.8 Test Configuration > Burst . . . 4 - 136 4.18.9 General Comments to Sub-tabs under Results Folder . . . 4 - 137 4.18.10 General Comments About the RFC2544 Graphs . . . 4 - 138 4.18.11 Results > Throughput . . . 4 - 139 4.18.12 RFC2544 Results > Frame Loss . . . 4 - 140 4.18.13 RFC2544 results > Throughput and Frame Loss . . . 4 - 141 4.18.14 RFC2544 Results > Latency . . . 4 - 142 4.18.15 RFC2544 Results > Burst . . . 4 - 143

4.19.2 Port A/B. . . 4 - 144 4.19.3 Frame Config . . . 4 - 145 4.19.4 Results . . . 4 - 146 4.19.5 Graphical Presentation . . . 4 - 147 4.20 Application > BERT. . . 4 - 148 4.20.1 BERT Control . . . 4 - 148 4.20.2 Traffic Port A/B . . . 4 - 150 4.20.3 Frame Content Port A/B . . . 4 - 151

4.21 Application > Channel Statistics . . . 4 - 152

4.21.1 Port A/B. . . 4 - 152

4.22 Application > Ethernet Traceroute . . . 4 - 155

4.22.1 Traceroute Setup . . . 4 - 155 4.22.2 Port A/B. . . 4 - 156 4.22.3 Results . . . 4 - 156

4.23 Application > Cable Test. . . 4 - 157

4.23.1 Time Domain Reflectometry Principle . . . 4 - 157 4.23.2 Wiring of Ethernet Cables . . . 4 - 157 4.23.3 Ethernet Cable Test Screen . . . 4 - 158 4.23.4 10/100 Switch/Hub . . . 4 - 159 4.24 Application > VoIP. . . 4 - 160 4.24.1 Port A/B. . . 4 - 160 4.24.2 Emulator Setup . . . . 4 - 166 4.24.3 Emulator Control . . . . 4 - 169 4.24.4 Address Book . . . 4 - 179

4.25 Application > WAN Pointer Movement . . . 4 - 181 4.26 Application > ISDN Emulator . . . 4 - 183

4.26.1 Emulator Setup . . . . 4 - 183 4.26.2 Emulator Control . . . . 4 - 186 4.26.3 ISDN Tests . . . 4 - 190

4.27 Application > Service Activation Test . . . 4 - 192

4.27.1 Control. . . 4 - 192 4.27.2 Services . . . 4 - 195 4.27.3 Services > Attributes . . . 4 - 197 4.27.4 Services > Steps . . . . 4 - 200 4.27.5 Result . . . 4 - 201

4.28 Result > Measurement Information . . . 4 - 204 4.29 Result > Result List (2 Mbps) . . . 4 - 205

4.29.1 Result List . . . 4 - 205 4.29.2 Display Filter . . . 4 - 209 4.29.3 Graphics . . . 4 - 210 4.29.4 2 Mbps G.821 . . . 4 - 211 4.29.5 2 Mbps Alarms and Errors . . . 4 - 212 4.29.6 2 Mbps BERT . . . . 4 - 212

4.30 Result > Result List (SDH) . . . 4 - 213

4.30.4 SDH M.2100.1 (M.2100) . . . 4 - 216

4.31 Result > Result List (Ethernet) . . . 4 - 218

4.31.1 Performance . . . 4 - 219 4.31.2 Frame Stat . . . 4 - 220 4.31.3 Burst Stat . . . 4 - 221 4.31.4 Size Distribution. . . 4 - 222 4.31.5 Transmit Stat . . . 4 - 223 4.31.6 Multistream Transmit Stat . . . 4 - 224 4.31.7 Multistream Throughput Stat . . . 4 - 225 4.31.8 Multistream Frame Loss . . . 4 - 226 4.31.9 Multistream Latency/Jitter . . . 4 - 227 4.31.10 BERT – Alarms & Errors . . . 4 - 228 4.31.11 WAN – Alarms & Errors . . . 4 - 229 4.31.12 WAN – Performance . . . 4 - 230 4.31.13 WAN – Test Mode . . . 4 - 231 4.31.14 SyncE . . . 4 - 232 4.31.15 IEEE 1588v2 . . . 4 - 233

4.32 Result > Result List (ATM) . . . 4 - 235

4.32.1 ATM Alarms and Errors . . . 4 - 235 4.32.2 ATM Cell Statistics . . . 4 - 237 4.32.3 ATM VPI/VCI . . . 4 - 238 4.32.4 ATM QoS . . . 4 - 239

4.33 Result > Results VoIP Calls . . . 4 - 241

4.33.1 Total Call Info . . . 4 - 241 4.33.2 Total Call Quality . . . 4 - 241 4.33.3 Total Voice Quality (Option) . . . 4 - 243 4.33.4 Call Info . . . 4 - 245 4.33.5 Call Log . . . 4 - 246 4.33.6 Call Quality . . . 4 - 247 4.33.7 Voice Quality (Option) . . . 4 - 248

4.34 Result > Result List (T1 Unframed) . . . 4 - 249 4.35 Result > IEEE 1588v2 Log . . . 4 - 250 4.36 Status > Physical . . . 4 - 251

4.36.1 2 Mbps Interface . . . . 4 - 251 4.36.2 E3/DS3 Interface . . . . 4 - 252 4.36.3 STM-1/4/16/64 Optical/Electrical Interface . . . 4 - 252 4.36.4 ATM Interface . . . 4 - 253

4.37 Status > Alarms and Errors . . . 4 - 254 4.38 Status > ATM Alarms and Errors . . . 4 - 255 4.39 Status > ATM IMA . . . 4 - 256 4.40 Status > SDH Capture . . . 4 - 257 4.41 Status > Alignment . . . 4 - 259 4.42 Status > CAS . . . 4 - 260 4.43 Status > Traffic . . . 4 - 262 4.44 Status > Audio . . . 4 - 265 4.45 Status > Frame Relay . . . 4 - 266 4.46 Status > V-Series . . . 4 - 267 4.47 Status > Ethernet Interface. . . 4 - 268

4.47.1 Ethernet Interface > Interface Status . . . 4 - 268 4.47.2 Ethernet Interface > Optical Status SFP . . . 4 - 269 4.47.3 Ethernet Interface > Optical Status XFP . . . 4 - 270 4.47.4 Ethernet Interface > WAN - Alarms and Errors . . . 4 - 271 4.47.5 Ethernet Interface > WAN - Capture . . . 4 - 272 4.47.6 Ethernet Interface > Timing. . . 4 - 274 4.47.7 Ethernet Interface > SyncE . . . 4 - 275 4.47.8 Ethernet Interface IEEE 1588v2 . . . 4 - 276

4.48 Status > T1 Unframed . . . 4 - 279

4.48.1 Status -> Physical . . . . 4 - 279

4.49 Misc. > Quick Start . . . 4 - 282 4.50 Misc. > Stored Measurement . . . 4 - 283 4.51 Misc. > Print Setup . . . 4 - 285

4.51.1 2Mbps Print Setup. . . 4 - 285 4.51.2 PDF Print Setup . . . . 4 - 286 4.51.3 Activating Print Setup Directly From a Screen . . . 4 - 287 4.51.4 Printing Directly to a USB Printer . . . 4 - 292 4.51.5 Loading a File From the USB Memory Stick . . . 4 - 293

4.52 Misc. >Touch Screen Calibrate . . . 4 - 294 4.53 Misc. > System Configuration . . . 4 - 295

4.53.1 Instrument Information . . . 4 - 295 4.53.2 Service Interfaces . . . . 4 - 296 4.53.3 Display Setup . . . 4 - 300 4.53.4 Global Configuration . . . 4 - 301 4.53.5 Local Access Configuration. . . 4 - 304 4.53.6 Remote Access Configuration. . . 4 - 305

5 Specifications

5.1 Specifications, Basic Instrument . . . 5 - 2

5.1.1 2 Mbps interface, Transmitters . . . 5 - 2 5.1.2 2 Mbps interface, Receivers . . . 5 - 3 5.1.3 Results . . . 5 - 4 5.1.4 Memory Capacity . . . 5 - 5 5.1.5 Service Interfaces . . . 5 - 5 5.1.6 Other Interfaces . . . 5 - 5 5.1.7 Miscellaneous . . . 5 - 6

5.2 Specifications, SDH Test Option . . . 5 - 9

5.2.1 Specifications. . . 5 - 9 5.2.2 Results . . . 5 - 12

5.3 Specifications, E3 Test Option . . . 5 - 14

5.3.1 Specifications. . . 5 - 14 5.3.2 Results . . . 5 - 15

5.4 Specifications, E4 Test Option . . . 5 - 16

5.4.1 Specifications. . . 5 - 16 5.4.2 Results . . . 5 - 17

5.5 Specifications, V-Series Option . . . 5 - 18

5.5.1 Data Interfaces . . . 5 - 18 5.5.2 Results . . . 5 - 18 5.5.3 Test Patterns . . . 5 - 19 5.5.4 Miscellaneous . . . 5 - 20

5.6 Specifications, Ethernet Option . . . 5 - 21

5.6.1 Ethernet Test Interfaces. . . 5 - 21 5.6.2 Reflector Delays . . . 5 - 21 5.6.3 Ethernet Measurements . . . 5 - 21 5.6.4 Ethernet Results . . . 5 - 25 5.6.5 Ethernet Multistream Option . . . 5 - 27 5.6.6 IP Channel Statistics Option . . . 5 - 27 5.6.7 VoIP Call Emulation Options . . . 5 - 29 5.6.8 MPLS Option . . . 5 - 31 5.6.9 Stacked VLAN Option . . . 5 - 31 5.6.10 10 GigE WAN Option . . . 5 - 31 5.6.11 Miscellaneous . . . 5 - 32 5.6.12 Synchronous Ethernet Option . . . 5 - 33

5.7 Specifications, ATM Option . . . 5 - 36

5.7.1 Specifications. . . 5 - 36 5.7.2 Traffic Generation . . . 5 - 36 5.7.3 ATM Layer Traffic Analysis . . . 5 - 37

5.8 Specifications, ISDN PRI Call Emulation Option . . . 5 - 39

5.8.1 General . . . 5 - 39 5.8.2 Results . . . 5 - 41 5.8.3 Miscellaneous . . . 5 - 42

5.9 Specifications, Unframed T1 option . . . 5 - 43

5.9.1 Transmitters . . . 5 - 43 5.9.2 Receivers . . . 5 - 44 5.9.3 Results . . . 5 - 45

6 Support

6.1 Maintenance and Cleaning. . . 6 - 2

6.1.1 Maintenance . . . 6 - 2 6.1.2 Cleaning . . . 6 - 2

6.2 Support and Service Assistance . . . 6 - 3

6.2.1 Before you obtain assistance . . . 6 - 3 6.2.2 Obtaining Support or Service Assistance . . . 6 - 3 6.2.3 Download . . . 6 - 3

6.3 Packing and Shipping. . . 6 - 5

6.3.1 Packing . . . 6 - 5 6.3.2 Shipping . . . 6 - 6

6.4 Anritsu Offices . . . 6 - 7 6.5 Special Information . . . 6 - 10

6.5.1 Licensing Information . . . 6 - 10 6.5.2 Availability of Source Code . . . 6 - 10

6.6 Declarations. . . 6 - 19

6.6.1 Disposal According to WEEE Recycling . . . 6 - 19 6.6.2 Information for the Chinese Market Only . . . 6 - 20

Fig. 2.1 The 18 V DC power connector. . . 3

Fig. 2.2 CMA 3000 battery. . . . 4

Fig. 2.3 Battery compartment lock screw. . . . 5

Fig. 2.4 Press the notch to release battery door. . . 5

Fig. 2.5 The battery status information screen.. . . 7

Fig. 2.6 Rear panel connectors for measurement cables. . . 8

Fig. 2.7 Optional Ethernet 10/100/1000 Interface Module mounted.. . . 8

Fig. 2.8 Optional High Speed Single Port Interface and Ethernet 10/100/1000 Interface Module mounted.9 Fig. 2.9 Optional High Speed Dual Port Interface and Ethernet 10/100/1000 Interface Module mounted.. 9

Fig. 2.10 The support stand extracted. . . . 10

Fig. 2.11 Releasing the spring lock before installing the hook. . . 10

Fig. 3.1 Operating the touch screen. . . 2

Fig. 3.2 Illustration of the 3 screen sections. . . . 5

Fig. 3.3 Examples of the LED overlay explanation.. . . 6

Fig. 3.4 Setting up the normal/slim LED indicator layout.. . . 7

Fig. 3.5 Connector for optional telephone. . . 8

Fig. 3.6 Headphones/earphones is connected to this socket. . . . 9

Fig. 3.7 Back panel on basic instrument. . . . 10

Fig. 3.8 Back panel connectors presented. . . 11

Fig. 3.9 The externally mounted Ethernet 10/100/1000 Module.. . . 12

Fig. 3.10 The externally mounted High Speed Single Port Interface Module.. . . 13

Fig. 3.11 The externally mounted High Speed Dual Port Interface Module. . . 14

Fig. 3.12 Left panel connectors presented. . . 15

Fig. 3.13 The FrontSim intro screen launched.. . . 17

Fig. 3.14 Connection management screen. . . 17

Fig. 3.15 FrontSim remote control panel. . . 18

Fig. 3.16 External GPS Sensor . . . 20

Fig. 3.17 External GPS sensor connected to CMA 3000 . . . 21

Fig. 3.18 GPS icon on status bar. . . 22

Fig. 3.19 GPS information pop-up box. . . 23

Fig. 3.20 Adjust date and time pop-up box. . . 24

Fig. 4.1 Press OK or Cancel to accept or reject, respectively. . . . 2

Fig. 4.2 The Quick start screen. . . . 3

Fig. 4.3 Choosing a setup file from the list. . . 3

Fig. 4.4 The save setup menu.. . . 4

Fig. 4.5 On-screen keyboard launched.. . . 4

Fig. 4.6 Export menu launched. . . . 5

Fig. 4.7 Setup parameters for 2 Mbps transmitter. . . 6

Fig. 4.8 The Sa-bits setup screen. . . 7

Fig. 4.9 Pattern Time Slots menu screen. . . 8

Fig. 4.10 Different types of User Pattern setup. . . 9

Fig. 4.11 Channel Time Slot screen. . . 11

Fig. 4.12 Subchannel Number screen. . . . 11

Fig. 4.13 The receiver A screen. . . 13

Fig. 4.14 Receiver Pattern Time Slot. . . 15

Fig. 4.15 Channel Time Slot screen. . . 15

Fig. 4.16 Subchannel Number screen. . . . 16

Fig. 4.17 Audio Time Slot screen. . . . 16

Fig. 4.18 Audio Subchannel screen. . . 16

Fig. 4.19 The SDH transmitter setup screen launched.. . . 17

Fig. 4.20 Example shows the SOH editor screen.. . . 18

Fig. 4.21 The SDH receiver setup screen launched. . . 19

Fig. 4.22 Setup parameters for E3 transmitter. . . 20

Fig. 4.23 Setup parameters for E3 receiver. . . 22

Fig. 4.24 Setup parameters for E4 transmitter. . . 23

Fig. 4.28 Port Control tab launched. . . 31

Fig. 4.29 Monitor/Generate selected in Port Control.. . . 32

Fig. 4.30 Port Control screen with multistream shown. . . 33

Fig. 4.31 Pass through selected. . . 34

Fig. 4.32 Port control pass through . . . 34

Fig. 4.33 Reflector mode selected. . . 36

Fig. 4.34 Selecting either quick or advanced setup menu. . . 36

Fig. 4.35 Quick setup menu launched. . . 37

Fig. 4.36 The two Advanced Setup menus. . . . 38

Fig. 4.37 The ‘Forced’ setup launched. . . . 39

Fig. 4.38 The ‘Auto Detect’ running. . . 39

Fig. 4.39 Optical Setup launched. . . 40

Fig. 4.40 Optical Setup menu.. . . 41

Fig. 4.41 Traffic screen. . . . 43

Fig. 4.42 Ramp setup . . . 44

Fig. 4.43 Ramp modes . . . 44

Fig. 4.44 Traffic screen appearing with Multistream option. . . 45

Fig. 4.45 WAN setup screen.. . . 46

Fig. 4.46 SOH Editor popup. . . . 47

Fig. 4.47 POH Editor popup. . . . 48

Fig. 4.48 Frame Content screen found in Port A/B setup. . . . 49

Fig. 4.49 The Ethernet field. . . 50

Fig. 4.50 The [ ! ] softkey appears when pressing the [ARP] softkey. . . 51

Fig. 4.51 The MPLS field . . . 51

Fig. 4.52 The EoMPLS field . . . 52

Fig. 4.53 The VLAN field. . . 52

Fig. 4.54 The stacked VLAN field . . . 53

Fig. 4.55 The stacked VLAN field when the level count is 2. . . 53

Fig. 4.56 The IPv4 field. . . 54

Fig. 4.57 DHCP setup screen. . . 55

Fig. 4.58 The IPv6 field. . . 56

Fig. 4.59 The UDP field.. . . 56

Fig. 4.60 The TCP field. . . 57

Fig. 4.61 Settings screen. . . . 59

Fig. 4.62 Filter screen. . . . 61

Fig. 4.63 Setup of the ‘Filter and mask’ field. . . . 62

Fig. 4.64 Encapsulation types selection. . . 62

Fig. 4.65 Thresholds screen. . . 63

Fig. 4.66 Port Setup SyncE . . . 64

Fig. 4.67 IEEE 1588v2 setup screen . . . 65

Fig. 4.68 IEEE 1588v2 - Transport Protocol setup screen . . . 66

Fig. 4.69 Timing setup screen . . . 69

Fig. 4.70 T1 Unframed Transmitter Setup . . . 71

Fig. 4.71 T1 Unframed Receiver Setup . . . 73

Fig. 4.72 The General screen of the Application folder.. . . 75

Fig. 4.73 Delayed start setup menu. . . 76

Fig. 4.74 Duration setup menu.. . . 76

Fig. 4.75 Evaluation Item menu.. . . 77

Fig. 4.76 Part of the Signaling screen. . . . 78

Fig. 4.77 Log Filter screen. . . 79

Fig. 4.78 The Statistics Filters setup screen.. . . 81

Fig. 4.79 Example of a ‘Counts’ drop-down menu. . . 81

Fig. 4.82 Frame relay BERT load screen launched. . . 85

Fig. 4.83 DLCI statistics setup screen launched. . . . 87

Fig. 4.84 CIR Test screen.. . . 88

Fig. 4.85 The Ping Test setup screen. . . 90

Fig. 4.86 Auto configuration screen launched. . . 93

Fig. 4.87 Example showing collapsed interface-structure. . . 94

Fig. 4.88 The ‘please wait’ screen launched. . . 94

Fig. 4.89 Stimuli setup screen. . . . 95

Fig. 4.90 2 Mbps TxA or TxB stimuli setup. . . 96

Fig. 4.91 Frame Relay stimuli setup. . . . 97

Fig. 4.92 Codirectional stimuli setup. . . 98

Fig. 4.93 ATM stimuli setup. . . . 99

Fig. 4.94 Frequency stimuli setup. . . 100

Fig. 4.95 E3/DS3 TxA (TxB) stimuli setup. . . 101

Fig. 4.96 SDH Alarm stimuli setup. . . 102

Fig. 4.97 SDH Error stimuli setup. . . 103

Fig. 4.98 AU4 Pointer stimuli setup. . . . 104

Fig. 4.99 TU3 (TU12) stimuli setup. . . . 105

Fig. 4.100 V-Series Interface stimuli setup. . . 106

Fig. 4.101 Ethernet stimuli setup. . . 107

Fig. 4.102 WAN stimuli setup. . . 108

Fig. 4.103 Ethernet Timing stimuli setup . . . 109

Fig. 4.104 Monitoring received frequency vs. transmitted frequency. . . 110

Fig. 4.105 The ATM Transmitter screen. . . 111

Fig. 4.106 Examples of traffic profiles. . . . 112

Fig. 4.107 The ATM Receiver setup screen.. . . 113

Fig. 4.108 O.191 setup screen launched. . . . 114

Fig. 4.109 The VP/VC Filter setup screen launched. . . 114

Fig. 4.110 The Scan screen. . . . 115

Fig. 4.111 The APS test setup screen launched. . . 116

Fig. 4.112 Pointer movements screen launched.. . . 118

Fig. 4.113 Using a finger or stylus pen to select zoom area. . . . 120

Fig. 4.114 Selected area expanded.. . . 120

Fig. 4.115 Using view all function to zoom out. . . . 121

Fig. 4.116 Whole plot area displayed (custom y-scaling). . . 121

Fig. 4.117 Tributary Scan screen launched. . . 122

Fig. 4.118 Tributary details presented for VC12#2 in this example. . . 123

Fig. 4.119 RFC2544 Test Setup screen. . . 124

Fig. 4.120 Quick Setup launched. . . 125

Fig. 4.121 RFC2544 config Port setup tab. . . . 128

Fig. 4.122 General setup screen. . . 129

Fig. 4.123 Average throughput. . . . 131

Fig. 4.124 Throughput setup screen.. . . 131

Fig. 4.125 Latency setup screen.. . . 135

Fig. 4.126 Burst setup screen. . . 136

Fig. 4.127 Results presentation in graphs. . . . 138

Fig. 4.128 RFC2544 results throughput screen. . . 139

Fig. 4.129 RFC2544 results frame loss screen.. . . 140

Fig. 4.130 RFC2544 results throughput and frame loss screen. . . 141

Fig. 4.131 RFC2544 results latency screen. . . 142

Fig. 4.132 RFC2544 results burst screen. . . 143

Fig. 4.133 Ping control screen. . . 144

Fig. 4.134 Frame config screen. . . 145

Fig. 4.135 Results screen of ping test. . . . 146

Fig. 4.136 Graphical presentation of the ping test. . . 147

Fig. 4.140 Port A/B Channel Statistics screen launched. . . 152

Fig. 4.141 Channel Statistics Port setup . . . 153

Fig. 4.142 Traceroute Setup screen launched. . . . 155

Fig. 4.143 Traceroute results screen. . . . 156

Fig. 4.144 The Ethernet Cable Test screen. . . . 158

Fig. 4.145 Test of a 10/100 Mbps switch. . . 159

Fig. 4.146 The Port B setup screen launched.. . . 160

Fig. 4.147 The Ethernet field. . . 161

Fig. 4.148 The [ ! ] softkey appears when pressing the [ARP] softkey. . . 161

Fig. 4.149 The MPLS field . . . 162

Fig. 4.150 The EoMPLS field . . . 162

Fig. 4.151 The VLAN field. . . 163

Fig. 4.152 The stacked VLAN field . . . 163

Fig. 4.153 The IPv4 field. . . 164

Fig. 4.154 DHCP setup screen. . . 164

Fig. 4.155 The UDP field . . . 165

Fig. 4.156 The Emulator Setup screen launched. . . 166

Fig. 4.157 White List . . . 167

Fig. 4.158 The Emulator Control screen launched. . . . 169

Fig. 4.159 Info tab launched. . . . 171

Fig. 4.160 Log tab launched . . . 172

Fig. 4.161 Quality tab launched. . . 173

Fig. 4.162 Voice tab launched. . . . 174

Fig. 4.163 Thresholds tab launched. . . 175

Fig. 4.164 Emulator tab shown . . . 176

Fig. 4.165 Generator tab shown. . . 178

Fig. 4.166 The Address Book screen launched. . . 179

Fig. 4.167 WAN Pointer Movement Screen. . . . 181

Fig. 4.168 ISDN Emulator Setup screen. . . 183

Fig. 4.169 ISDN Emulator Control - Emulator section launched. . . . 186

Fig. 4.170 ISDN Tests - Bear. Cap. Test launched.. . . 190

Fig. 4.171 Service Activation Test Control screen . . . 192

Fig. 4.172 The Service Activation Test Services screen. . . 196

Fig. 4.173 The Service Activation Test Attributes screen . . . 197

Fig. 4.174 The Service Activation Test Frame Size popup in constant mode . . . 199

Fig. 4.175 The Service Activation Test Frame Size popup in EMIX mode . . . 200

Fig. 4.176 The Service Activation Test Steps screen . . . 200

Fig. 4.177 The Service Activation Test Result screen . . . 201

Fig. 4.178 The measurement information screen.. . . 204

Fig. 4.179 Example showing Log - Result list.. . . 205

Fig. 4.180 Part of result list showing specific contents. . . 206

Fig. 4.181 Example showing Signaling - Result list. . . 206

Fig. 4.182 Part of result list showing specific contents. . . 207

Fig. 4.183 Message presented as Hex code. . . 207

Fig. 4.184 Message shown as detailed information. . . 208

Fig. 4.185 Examples on different message types.. . . 208

Fig. 4.186 Display filter screen. . . 209

Fig. 4.187 Graphics screen.. . . 210

Fig. 4.188 Example showing G.821 result . . . 211

Fig. 4.189 Example showing Alarms & Errors result. . . 212

Fig. 4.190 Example showing BERT result.. . . 212

Fig. 4.191 Example showing Alarms and errors result. . . 214

Fig. 4.194 Example showing SDH M.2101 screen. . . 216

Fig. 4.195 Tabular presentation of Ethernet Performance. . . 219

Fig. 4.196 Graphical presentation of Ethernet Performance. . . 219

Fig. 4.197 Tabular presentation of Ethernet Frame Stat. . . . 220

Fig. 4.198 Graphical presentation of Ethernet Frame Stat.. . . 220

Fig. 4.199 Tabular presentation of Ethernet Burst Stat. . . 221

Fig. 4.200 Graphical presentation of Ethernet Burst Stat results.. . . 221

Fig. 4.201 Tabular presentation of Ethernet Size Distribution. . . . 222

Fig. 4.202 Graphical presentation of Size Distribution. . . 222

Fig. 4.203 Tabular presentation of the Ethernet Transmit Stat. . . . 223

Fig. 4.204 Tabular presentation of the Multistream Transmit Stat. . . . 224

Fig. 4.205 Tabular presentation of the Multistream Throughput Stat. . . 225

Fig. 4.206 Graphical presentation of the Multistream Frame Loss. . . 226

Fig. 4.207 Tabular presentation of the Multistream Latency/Jitter. . . . 227

Fig. 4.208 BERT – Ethernet Alarms & Errors screen - Scroll top.. . . 228

Fig. 4.209 BERT – Ethernet Alarms & Errors screen - Scroll down.. . . 228

Fig. 4.210 WAN – Alarms & Errors screen. . . 229

Fig. 4.211 WAN – Performance screen. . . 230

Fig. 4.212 WAN – Test screen. . . 231

Fig. 4.213 SyncE result screen . . . 232

Fig. 4.214 IEEE 1588v2 result screen. Port A is Master and port B is slave . . . 233

Fig. 4.215 Result screen showing ATM alarms and errors. . . . 235

Fig. 4.216 Result screen showing ATM cell statistics. . . 237

Fig. 4.217 Result screen showing ATM VPI/VCI channel results.. . . 238

Fig. 4.218 Result screen showing ATM VPI/VCI parameter results. . . 239

Fig. 4.219 ATM QoS results . . . 240

Fig. 4.220 The Total Call Info result tab displayed . . . 241

Fig. 4.221 The Total Call Quality result tab displayed . . . 242

Fig. 4.222 The Total Voice Quality result tab displayed. . . 243

Fig. 4.223 The Call Info result tab displayed . . . 245

Fig. 4.224 The Call Log result tab displayed . . . 246

Fig. 4.225 The Call Quality result tab displayed . . . 247

Fig. 4.226 The Voice Quality result tab displayed . . . 248

Fig. 4.227 T1 Unframed result . . . 249

Fig. 4.228 IEEE 1588v2 Log screen. Port B has Ext. log enabled. . . . 250

Fig. 4.229 Example shows 2 Mbps Alarms and Errors screen. . . . 254

Fig. 4.230 ATM Alarms and Errors. . . 255

Fig. 4.231 Example showing SDH capture results. . . . 257

Fig. 4.232 Detailed frame information launched. . . 258

Fig. 4.233 Alignment example . . . 259

Fig. 4.234 The CAS screen. . . . 260

Fig. 4.235 Red pattern setup menu launched. . . 261

Fig. 4.236 Traffic screen. . . . 262

Fig. 4.237 Traffic screen displaying ‘TS Content’. . . . 264

Fig. 4.238 Audio Channel screen.. . . 265

Fig. 4.239 Frame relay status screen. . . 266

Fig. 4.240 The V-Series status screen. . . . 267

Fig. 4.241 Ethernet Interface Status screen. . . 268

Fig. 4.242 Ethernet Optical Status SFP screen. . . . 269

Fig. 4.243 Ethernet Optical Status XFP screen. . . 270

Fig. 4.244 Example shows WAN Alarms and Errors screen . . . 271

Fig. 4.245 Example showing WAN Capture screen . . . 272

Fig. 4.246 Detailed frame information launched. . . 273

Fig. 4.247 Ethernet Timing status screen . . . 274

Fig. 4.248 Ethernet SyncE status screen . . . 276

Fig. 4.252 Stored measurement information screen. . . . 283

Fig. 4.253 The Print setup screen.. . . 285

Fig. 4.254 SDH Alarms and Errors screen launched. . . 287

Fig. 4.255 Printout menu for Log measurement. . . . 288

Fig. 4.256 Animated icon during pending state. . . 289

Fig. 4.257 Name field. . . . 289

Fig. 4.258 Please wait pop-up launched during printing. . . 290

Fig. 4.259 The animated printer icon . . . 291

Fig. 4.260 Stop printer process menu. . . . 291

Fig. 4.261 Printer status/cancel pop-up. . . 292

Fig. 4.262 Printout example.. . . 293

Fig. 4.263 Touch Screen Calibration screen launched.. . . 294

Fig. 4.264 Instrument Information screen launched. . . . 295

Fig. 4.265 Service Interfaces screen launched. . . 297

Fig. 4.266 IP Address numeric key pad. . . 298

Fig. 4.267 Example on mounted USB storage device. . . 299

Fig. 4.268 The Display Setup screen launched. . . . 300

Fig. 4.269 The Global Configuration screen launched. . . . 301

Fig. 4.270 Set measurement name . . . 302

Fig. 4.271 Optional fields on the Global Configuration screen. You may need to use the scrollbar to view these.303 Fig. 4.272 The Local Access Configuration screen launched. . . 304

Fig. 4.273 The Remote Access Configuration screen launched. . . . 305

Fig. 4.274 The soft version of the front panel keys. . . 307

1

Introduction

The introduction chapter contains brief description of how this guide is structured and explains the symbols and conventions used.

1.1

Basic Instrument

The CMA 3000 is a battery-powered multipurpose telecommunications test instrument for field use. The CMA 3000 is a tool for a wide range of applications from fast first aid troubleshooting to comprehensive, depth analysis of transmission problems. With the optional modules in-stalled the CMA 3000 will turn from a full-featured transmission line qual-ity tester into an advanced signaling analyzer.

The basic CMA 3000, with its two 2 Mbps receivers and transmitters, supports framed and unframed testing and monitoring of 2 Mbps sys-tems. The instrument is thus ideal for both in-service and out-of-service transmission-quality measurement. For fast troubleshooting, the CMA 3000 displays alarms and transmission link status on LED indica-tors. The instrument's two inputs permit immediate monitoring of the two sides of a line and allow comparison of simultaneously recorded results. With options added the CMA 3000 tests a large variety of interfaces and systems, like SDH interfaces, frame relay lines and the A-bis interface of GSM/GPRS networks. Yet other options turn the CMA 3000 into a very powerful signaling analyzer for GSM/GPRS/EDGE, SS7 and ISDN pro-tocols.

Results are easily read from the large color LCD display, where the colors and graphical symbols facilitate interpretation. Together with the touch screen operation, this makes the CMA 3000 very user-friendly in opera-tion. The CMA 3000 can automatically configure to the received signal, eliminating time-consuming instrument set-up. Set-ups supporting partic-ular applications may be stored in the instrument. The instrument has the following interface for data transfer and external communication: LAN in-terface and two USB ports.

Fault location is greatly facilitated by the high degree of portability of the robust CMA 3000, allowing measurements to be taken at any suitable measuring point. The instrument is powered by rechargeable and re-placeable intelligent high-capacity LiIon batteries. The CMA 3000 can also be powered via an external mains adapter for long-term measure-ments.

1.2 Symbols and Conventions

1.2

Symbols and Conventions

A number of typographical conventions are used for easy spotting of in-formation. Examples below are shown in grey boxes in this section only to indicate that they are ‘examples’.

1.2.1

Warnings

1.2.2

Precautions

Precautions indicate that a specific procedure needs to be followed

cor-rectly to avoid damage to or malfunction of the instrument. When the symbol used in this example is found either in this manual or on any item, special attention should be paid concerning Electrostatic sensitive devic-es.

1.2.3

Notes

The Note symbol indicates information, procedures or recommendations that need to be followed to make correct measurements etc. Note text is written in italic to separate the information from the other text elements on a page.

1.2.4

Hints

The Hint symbol indicates information that should be treated as hints, suggestions, recommendations etc. Hint text is written in italic to sepa-rate the information from the other text elements on a page.

1.2.5

Option

The Option symbol indicates that the information described covers an option (hardware and software) and that this option must be installed be-fore use. Text is written in italic to separate the information from the other text elements on a page.

!

1.3

Warnings

This section contains warnings which should be followed to avoid per-sonal injury, product damage, as well as damage to the environment.

1.3.1

General Service or Repair

To avoid personal injury/damage to the equipment or environment, al-ways leave any service or repair to authorized Anritsu personnel.

1.3.2

Information for Anritsu Authorized Personnel Only

This CMA 3000 contains a lithium battery. Always pay special attention when handling this battery.

!

FOR CALIFORNIA USA ONLY

This product contains a CR Coin Lithium Battery which contains Perchlorate Material - special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate

!

!

1.3 Warnings

1.3.3

Mains Power

To maintain the protection provided by the equipment always:

1.3.4

Optical Laser

If the instrument is installed with optical interfaces, it contains Class 1 la-ser transmitters transmitting at wavelengths of 850 nm, 1310 nm or 1550 nm, which is invisible to the human eye. Output power is typically more than -10 dBm giving an IEC 60825-1:2007 classification as a class 1 laser product.

CMA 3000 equipped with SDH, Ethernet 10/100/1000 modules and/or High Speed Interface modules contain optical interfaces that use:

!

!

Anritsu Part No. 01582600.

!

!

1.3.5

Personal Warnings

To avoid personal injury due to hazardous voltages when installing and/ or configuring the CMA 3000, always:

• Turn off power and disconnect power cable from CMA 3000

• Disconnect all signal cables from the CMA 3000

!

!

1.4 Precautions

1.4

Precautions

This section contains some precautions which should be followed to avoid damage or malfunction due to incorrect use, handling and trans-portation of the CMA 3000.

1.4.1

ESD (ElectroStatic Discharge)

Modules and options for the CMA 3000 contain electronic devices that are sensitive to ESD (ElectroStatic Discharge). Therefore, all ESD sensi-tive items are delivered from Anritsu A/S in antistatic shielding packages. Electrostatic discharge during installation can result in destruction or degradation of these devices. The damage may lead to equipment failure later. When you install or remove modules, it is your responsibility to con-trol ESD. To concon-trol ESD take the issues described below into consider-ation.

Avoid build-up of electrostatic charge

• Keep your workplace clear of any item that can generate

electrostat-ic charges e.g. all items that are not made of antistatelectrostat-ic materials.

Minimize the exposure to ESD

• Keep ESD sensitive items in antistatic shielding packaging as long

as possible.

• Do not remove ESD sensitive items from equipment or the antistatic

shielding packaging unless you are connected to the equipment with a grounding wrist strap (as described later).

• Return ESD sensitive items to antistatic shielding packaging.

Keep equipment, the ESD sensitive items and yourself at same stat-ic potential

• If your workplace is already prepared for handling ESD sensitive

items, then follow your usual procedure. If not, you should follow the procedure below using a ground wrist strap.

• Attach the wrist end of the wrist strap firmly around your wrist and

the other end to the equipment chassis or ground plug.

• Keep the wrist strap on while you install or remove ESD sensitive

items. Do not remove the wrist strap until the ESD sensitive parts are either installed or returned to the antistatic shielding package.

1.4.2

Radio Emissions

This device has been tested and found to comply with the limits for Class A according to CISPR 22/European Standard EN 55022.

1.4.3

Transportation

Always handle and transport the CMA 3000 carefully, as it contains deli-cate components.

1.4.4

Port Connectors

Please note the following warnings regarding the CMA 3000 Port con-nections.

!

!

!

!

1.4 Precautions

1.4.5

Optical Surfaces

The optical interfaces - transmitter as well as receiver - are very sensitive to contamination. Be aware that contamination of the optical surfaces may result in severe loss of signal.

1.4.6

Ventilation

Depending of the installed options, the instrument can have build-in fan(s), to prevent the temperature to raise inside the instrument.

!

!

2

Configuration

This chapter contains information about the included accessories and the basic configuration. You will find information about how to connect the mains adapter, about the battery used and how to charge it.

2.1

Delivered Accessories

The instrument is delivered in a shipment container together with various accessories depending on the order. When unpacking the first time, it is recommended to check these accessories from the list(s) below.

2.1.1

Standard Accessories

The following standard accessories are delivered with the instrument:

• User Guide (this book)

• Rechargeable battery

• Mains adapter

• Mains cable

• Stylus Touch Pen

2.1.2

Optional Accessories

The following optional accessories may be delivered with the instrument (if included in the order):

• Instrument carrying strap

• Carrying case

• Soft bag

2.2 Mains Power Adapter

2.2

Mains Power Adapter

The CMA 3000 can be powered from the supplied AC mains adapter.

2.2.1

Connecting Mains Power Adapter

To connect the mains power adapter to the CMA 3000, follow the proce-dure below.

• Insert the mains adapter’s DC power plug into the socket connector

marked ‘18 V DC’. The DC input connector is located on the left pan-el of the CMA 3000.

• Connect the AC plug of the mains adapter to the mains and switch

on the mains wall outlet.

Fig. 2.1 The 18 V DC power connector.

!

2.3

Rechargeable Battery

CMA 3000 is delivered with a 10.8 V intelligent Li-Ion rechargeable and replaceable battery. The typical operation capacity (with a fully charged battery) will for the basic instrument be more than 10 hours with ‘Power-Save’ enabled, or more than 6 hours with ‘Power‘Power-Save’ disabled.

Fig. 2.2 CMA 3000 battery.

Initial charging The battery will normally be partially or fully discharged on delivery. It is recommended to charge the battery as the first thing after delivery and unpacking. In Stand By Mode, the ON/OFF LED indicator will stop flash-ing when the battery is fully charged.

If the battery happens not to be used for a longer period of time it is rec-ommended that it contains at least 20% capacity. Charge the battery be-fore storage, if necessary.

Temperature When charging is in process, the temperature of the battery will increase. The intelligence of the battery will ensure that the charging takes place at the correct temperature.

!

2.3 Rechargeable Battery

2.3.1

Installing or Replacing Battery

To install or replace the battery in the CMA 3000 follow the procedure be-low:

• Place the instrument on its front on a plain surface and unscrew the

battery compartment lock screw, as shown in Fig. 2.3.

Fig. 2.3 Battery compartment lock screw.

• To release the battery compartment door - press down at the notch,

while dragging it outwards.

• Pull out the battery from the compartment using the strap fixed to it.

• When installing the battery, note the direction of the battery

termi-nals. With the instrument placed on its front - and the battery com-partment in front of you - the terminals should be in the upper left corner.

• Re-install the battery compartment door and tighten the lock screw.

2.3.2

Charging Battery in Fast Mode

Power is applied from the external AC mains adapter - and the CMA 3000 is switched OFF during the charging (Stand By Mode). To charge the CMA 3000 battery using the fast charge mode follow the procedure below.

• Switch OFF the CMA 3000

• Connect mains adapter, as described in Connecting Mains Power

Adapter on page 2-3

ON/OFF indicator When connected, the ON/OFF indicator will after approx. 30 seconds flash indicating that charging is in progress. When the flashing stops, the charging is complete. If the battery is defect - the ON/OFF indicator will also light. Therefore, the best way to check the battery status is to switch on the CMA 3000 and observe the status indicator at the bottom of the screen, or click the status indicator as described in Battery Status

Infor-mation on page 2-7.

2.3.3

Charging Battery in Normal Mode

Power is applied from the external AC mains adapter - and the CMA 3000 is switched ON during the charging.

A normal charge of the battery is taking place every time the instrument is in use and connected to the mains adapter.

The battery status can be checked in the status line at the bottom of the screen - or in the miscellaneous screen, as described in Battery Status

2.3 Rechargeable Battery

2.3.4

Battery Status Information

The battery status is indicated as an icon in the status bar at the bottom of the screen. One of the 4 icons shown below will be displayed. Icon indicates that the battery is charging. CMA 3000 is using the net adapter as power source.

Icon indicates that the battery is fully charged. CMA 3000 is using the net adapter as power source.

Icon indicates that there is no battery in the CMA 3000 (or the battery is malfunctioning). CMA 3000 is using the net adapter as power source.

Icon indicates that CMA 3000 is using the battery as power source. The net adaptor is not connected.

There is a delay of several seconds until the battery status is updated.

A more detailed battery status information is launched when clicking the

Battery symbol found in the status bar. The example in Fig. 2.5 shows the

status screen of a battery under charging.

2.4

Measurement Cables

When connecting the CMA 3000 to the line to be tested or monitored - it is recommended always to use shielded cables of good quality, to avoid the possibility of corrupting the measuring results. For the same reason, the mains adapter, if used, should be connected to the instrument and switched on before starting the measurement.

For connection of the CMA 3000 to different types of equipment, different cables are available. Please request your Anritsu representative for infor-mation.

2.4.1

Connecting Measurement Cables

Measurement cables are connected to the input and output connectors located on the rear panel of the instrument. Various connector types: Un-balanced, balanced and optical types are available.

Fig. 2.6, shows rear panel equipped with three internally installed

op-tions: Data Option,10/100 Ethernet option and SDH test option.

Fig. 2.6 Rear panel connectors for measurement cables.

Fig. 2.7, shows rear panel equipped with two internally installed options,

2.4 Measurement Cables

Fig. 2.8, shows rear panel equipped with the High Speed Single Port In-terface and Ethernet 10/100/1000 InIn-terface.

Fig. 2.8 Optional High Speed Single Port Interface and Ethernet 10/ 100/1000 Interface Module mounted.

Fig. 2.9, shows rear panel equipped with the High Speed Dual Port Inter-face and Ethernet 10/100/1000 InterInter-face.

Fig. 2.9 Optional High Speed Dual Port Interface and Ethernet 10/100/ 1000 Interface Module mounted.

2.5

Support Stand and Carrying Strap

2.5.1

Support Stand

CMA 3000 is equipped with a support stand keeping the instrument in a convenient angle during operation. To extract the stand: pull out the bracket underneath the instrument - it automatically stays in this position.

Fig. 2.10 The support stand extracted.

2.5.2

Carrying Strap (Optional)

The optional carrying strap can easily be mounted for your convenience when transporting the CMA 3000.

The carrying strap is equipped with self-closing hooks for easy installa-tion. Pull back the spring part to open the hook, and place it around the lock pin on the instrument.

3

Man-Machine-Interface

Man-Machine-Interface (MMI) covers the relation between the user and the instrument, in other words - the information you get from the instru-ment combined with the action you add to the instruinstru-ment.

The informative parts are the TFT display and the LED indicators. The parts susceptible to influence are function keys and the touch-active lay-er of the screen. Connections made to the input and output connectors are included in the MMI as well.

The optional FrontSim software that makes remote operation of the CMA 3000 is also part of the MMI.

3.1

Touch Screen Display

The 8 ¼ inch active TFT display with VGA resolution (640x480 pixels) is used for setups and presentation of results. As the display includes touch screen functionality it is possible to navigate and operate directly from it.

Fig. 3.1 Operating the touch screen.

The touch screen display is constructed to be operated by the tip of your fingers or by the included Stylus Touch Pen (Anritsu part No. 97600800), only. The touch screen surface is made of delicate material and is easily scratched or damaged, if handled incorrectly.

!

!

!

3.2 Key Operation

3.2

Key Operation

The physical operator keys on the front are described in this section.

3.2.1

Power ON/OFF Key

This key has a combined function, which is activated the following way: Press power (ON/OFF) key directly, to switch on power.

Press the (SHIFT) key followed by the power (ON/OFF) key to switch off power.

3.2.2

SHIFT Keys

These keys enable the shift function. Pressing a (SHIFT) key followed by another key having a dual function - will activate this other function. The dual function is indicated by the ‘orange colored text’ on the key.

3.2.3

LED TRAP Key

This key enables the TRAP function. All alarms since last reset are dis-played in the LED indicators.

Press the (LED TRAP) key activate the TRAP function.

The LED adjacent to the trap key flashes if any alarm has been trapped. Press (SHIFT) followed by (LED TRAP) key to reset the alarm trap func-tion.

3.2.4

Start/Stop Key

This key has a combined function, which is activated the following way: Press (START/STOP) key to start a measurement.

3.2.5

Error Key

This key is directly activated.

Press the (ERROR) key to insert an error in the transmitted signal. The type of error depends on the current setup.

3.2.6

Volume Keys

These keys are used for control of sound level (volume) of the built in speaker or the connected earphones (optional).

Press the key to decrease the volume.

Press (SHIFT) followed by the key to mute.

Press the key to increase the volume.

Press (SHIFT) followed by the key to unmute.

3.2.7

Navigation Keys

These keys are used for navigation and operation of the menus dis-played on the touch screen.

Press the (UP) navigator key to move the cursor upwards. Press the (DOWN) navigator key to move the cursor downwards. Press the (RIGHT) navigator key to move the cursor to the right. Press the (LEFT) navigator key to move the cursor to the left.

Press (SHIFT) followed by (UP) or (DOWN) to move the cursor between the 3 screen sections. See the illustration Fig. 3.2.

UP

DOWN RIGHT LEFT

3.2 Key Operation

Fig. 3.2 Illustration of the 3 screen sections.

3.2.8

Enter Key

This key is an integrated part of the navigation keys.

Press the (ENTER) key (centre of the navigator key) to accept the selec-tions. This function will act the same way as the [OK] softkey in the screen menus.

3.2.9

ESC Key

This key covers the escape function.

3.3

LED Indicators

The functionality of the LED indicators is dynamic, i.e. that the individual LED has no permanent function, but its function will be dedicated to it dy-namically dependant on the actual mode of operation. Fig. 3.3 shows ex-amples on this function. When pressing the first tab to the left on the screen, the ‘LED overlay’ screen part will appear showing the reason be-hind the physical LED on the front of the instrument.

3.3 LED Indicators

As shown in Fig. 3.3, it is possible to select a normal or a slimmer LED indication layout. The slim layout makes more screen space available for general purpose.

The change of the LED layout is done from the Global Configuration screen found under the Misc. > System configuration folder.

The figure below shows this screen setup.

3.4

Telephone Interface

With the optional telephone available from Anritsu (P/N 07530010) con-nected to the telephone interface of the CMA 3000, it is possible to listen and insert speech in the audio channels available in the system The telephone is connected to the connector (marked with a telephone symbol) at the back panel of the CMA 3000.

3.5 Earphone

3.5

Earphone

With the optional earphone (P/N 80701200) available from Anritsu, it is possible for you to listen to speech channels in the telephone network.

The adjustment of the output level is controlled from the ‘Audio’ keys on the front of the CMA 3000. The built-in loudspeaker is automatically dis-connected when the jack connector of the headphones is dis-connected to the socket on the left panel of the CMA 3000.

Headphones or earphone is connected to the socket marked with a headset symbol.

Fig. 3.6 Headphones/earphones is connected to this socket.

!

earphones capable of producing sound levels that could cause permanent hearing loss. Do not operate for a long period of time at high volume level or at a level that is un-comfortable.

3.6

Back Panel Connectors

All connections concerning the Test interface are placed at the back pan-el of the CMA 3000.

The exact look of the CMA 3000 back panel and number of connectors depends on the optional interfaces installed.

3.6.1

Basic Instrument (2 Mbps)

Below the back panel of a basic instrument (equipped with 2 Mbps only) is shown.

Fig. 3.7 Back panel on basic instrument.

The table below describes where the different connectors are located.

* Note 1 Aux connector is used for External Clock In/Out. The input can be used as external input for a master clock signal to e.g. make the CMA 3000 in sync with a network. The output can generate an output clock, e.g. to be used as master clock in a network to get sync between more instruments.

1 2 3 4 5 6 7 8 9

1 TxB, unbalanced Unbalanced transmitter B output 2 TxB, balanced Balanced transmitter B output 3 TxA, unbalanced Unbalanced transmitter A output 4 TxA, balanced Balanced transmitter A output 5 RxB, unbalanced Unbalanced receiver B input 6 RxB, balanced Balanced receiver B input 7 RxA, unbalanced Unbalanced receiver A input 8 RxA, balanced Balanced receiver A input 9 Aux Auxiliary connector *Note 1

3.6 Back Panel Connectors

3.6.2

Fully Equipped Instrument (Internally Mounted Modules)

Below the back panel of a instrument equipped will all internally installed modules is shown.

Fig. 3.8 Back panel connectors presented.

The table below describes where the different connectors are located.

* Note 1 Aux connector is used for External Clock In/Out. The input can be used as external input for a master clock signal to e.g. make the CMA 3000 in sync with a network. The output can generate an output clock, e.g. to be used as master clock in a network to get sync between more instruments.

* Note 2 A proprietary interface. This 37-pin layout is not a V.36 (or similar) interface. Use Anritsu cables to convert to selected interface e.g. V.35 or X21.

1 2 3 4 5 6 7 8 9

10 11 12 13 14 15 16

1 TxB, unbalanced Unbalanced transmitter B output 2 TxB, balanced Balanced transmitter B output 3 TxA, unbalanced Unbalanced transmitter A output 4 TxA, balanced Balanced transmitter A output 5 RxB, unbalanced Unbalanced receiver B input 6 RxB, balanced Balanced receiver B input 7 RxA, unbalanced Unbalanced receiver A input 8 RxA, balanced Balanced receiver A input 9 Aux Auxiliary connector *Note 1 10 Optical A Optical connector A (optional) 11 Optical B Optical connector B (optional)

12 STM-1, Tx Electric STM-1 transmitter connector (optional) 13 STM-1, RxA Electric STM-1 receiver A connector (optional) 14 STM-1, RxB Electric STM-1 receiver B connector (optional)

15 Data Data interface (37-pin D-sub) connector (optional) *Note 2 16 10/100 LAN Local Area Network (LAN) connector 10/100 (optional)

3.6.3

Ethernet 10/100/1000 Interface

The optional and externally mounted Ethernet 10/100/1000 Interface Module is equipped with two electrical and two optical connectors divided in Port A and Port B.

Fig. 3.9 The externally mounted Ethernet 10/100/1000 Module.

Table below describes the location of the port connectors.

1 2 3 4

1 Electrical A Electrical Port A 2 Optical A Optical Port A 3 Electrical B Electrical Port B 4 Optical B Optical Port B

3.6 Back Panel Connectors

3.6.4

High Speed Single Port Interface

The optional and externally mounted High Speed Single Port Interface and Ethernet 10/100/1000 Module is equipped with two electrical and three optical connectors divided in Port A and Port B.

Fig. 3.10 The externally mounted High Speed Single Port Interface Module.

Table below describes the location of the port connectors.

1 2 3 4 5

1 Optical A Optical Ethernet 100/1000 Port A 2 Optical B Optical Ethernet 100/1000 Port B 3 Electrical A Electrical Ethernet 10/100/1000 Port A 4 Electrical B Electrical Ethernet 10/100/1000 Port B 5 Optical A Optical Ethernet 10G and STM-64 Port A

3.6.5

High Speed Dual Port Interface

The optional and externally mounted High Speed Dual Port Interface and Ethernet 10/100/1000 Module is equipped with two electrical and four op-tical connectors divided in Port A and Port B.

Fig. 3.11 The externally mounted High Speed Dual Port Interface Mod-ule.

Table below describes the location of the port connectors.

1 2 3 4 5 6

1 Optical A Optical Ethernet 100/1000 Port A 2 Optical B Optical Ethernet 100/1000 Port B 3 Electrical A Electrical Ethernet 10/100/1000 Port A 4 Electrical B Electrical Ethernet 10/100/1000 Port B 5 Optical A Optical Ethernet 10G and STM-64 Port A 6 Optical B Optical Ethernet 10G and STM-64 Port B

3.7 Left Panel Connectors

3.7

Left Panel Connectors

All connections concerning the Service interfaces are located at the left panel of the CMA 3000.

Fig. 3.12 Left panel connectors presented.

USB The two USB connectors are e.g. used for connection of printers with

USB interface. Another convenient use of this interface is the exchange of information to and from the instrument, i.e. by using USB storage de-vices.

LAN The LAN connector is used for connecting the CMA 3000 to a Local Area

Network, e.g. to remotely operate the instrument from a PC.

Telephone The Telephone connector is for connecting an optional telephone as de-scribed in Telephone Interface on page 3-8.

Earphone The Earphone connector is used for connecting an optional earphone as described in Earphone on page 3-9.

Serial The IOIOI connector is a serial interface used for connection of a serial printer, or for an external GPS sensor (see ).

DC Power The DC Power connector is used for connection of 18 V DC power deliv-ered from the AC Adapter as described in Mains Power Adapter on page

2-3.

USB LAN Telephone Serial

3.8

FrontSim Option

With the FrontSim option installed, your PC is capable of supporting re-mote access to CMA 3000. FrontSim simulates the front of the instru-ment allowing you to operate and view results on a PC through a LAN or Internet connection. If more instruments are linked to a network they can be remotely controlled by the same PC, each at a time.

Operation requires installation of both the optional FrontSim instrument part and PC part.

3.8.1

Installation of FrontSim Software

Installation of FrontSim is performed as described in the ‘FrontSim.pdf’ document found on the CD-ROM delivered with the FrontSim software package.

3.8.2

Connection and Setup

To connect and setup the FrontSim for operation:

• Connect an Ethernet network cable to the LAN connector on your

CMA 3000 and link this to a Local Area Network

• Assign an IP address to the CMA 3000. See how to setup IP

ad-dress in Service Interfaces on page 4-296. For further information about how to assign IP addresses to the instrument and the connect-ed PC, it is recommendconnect-ed to read the Application Note ‘Remote

op-eration with the FrontSim option’ available from your Anritsu

representative

3.8.3

Launching FrontSim

FrontSim software is launched by pressing the CMA 3000 FrontSim icon. This icon can be found from Start -> Programs -> Anritsu FrontSim

CMA 3000, if you have accepted to install program in the default folder

as suggested during the program installation.

When FrontSim is launched you will see the FrontSim intro screen shown in Fig. 3.13 next page.

3.8 FrontSim Option

Fig. 3.13 The FrontSim intro screen launched.

Press the [telephone] softkey at the upper part of the screen. This will open the Connection Management setup screen.

3.8.4

Assigning Instruments to the List

To be able to remote control an instrument, it needs to be assigned in the

Connection Management list:

• Fill in a name for the specific instrument in the Name field

• Fill in the IP address you already have assigned to the instrument,

in the Address field

• Press the [Save] softkey to save the settings

3.8.5

Selecting and Connecting Instruments From the List

To remote control a specific instrument on your network:

• Select instrument from the Defined connection list found in the

Con-nection Management screen

• Press [Connect] softkey to load the front panel of the instrument

When the instrument is connected and its Quick start screen is launched, close the Connection Management screen.

The FrontSim is now ready to remote control the selected CMA 3000.

3.9 Command Based Remote Control Option

3.9

Command Based Remote Control

Op-tion

With the Command Based Remote Control Option installed, CMA 3000 becomes a fully automated measurement instrument.

• The CMA 3000 remote control communication functions support the

built-in Ethernet service interface.

• Software specifications are in conformity with the IEEE488.2

stand-ard and SCPI version 1999 (Standstand-ard Commands for Programma-ble Instruments).

• Ethernet drivers for National Instruments LabView are available.

All remote control features are described in a seperate document: CMA 3000, Command Based Remote Control, Operation Manual (Anritsu order number 09914401).

3.10

External GPS Sensor

It is possible to connect an external GPS sensor, part no. 01475090, available from Anritsu A/S. The GPS sensor is used for:

• Precise time synchronization, when making one way Frame

Trans-fer Delay measurements as part of the Ethernet Service Activation Test, see 4.27.

• Clock source in an IEEE 1588 system, see section 4.8.9.

• Timing source for synchronizing Ethernet transmitters, see section

4.8.10 .

• Reference source for Ethernet bit rate measurements.

Fig. 3.16 External GPS Sensor

The 3 connectors of the GPS sensor must be plugged in to the CMA 3000:

• The USB connector to one of the CMA 3000 USB ports on the left

panel (for power supply)

• The 9 pin sub D connector to the 9 pin serial connector on the left

panel (for communication).

• The 15 pin sub D connector to the 15 pin AUX connector on the back
