Windows File Server Protocol Test Suite Cross Platform

Windows File Server Protocol Test Suite

Cross Platform

Vivian Tian, Senior Software Engineer

Victor Ding, Software Engineer II

2

Agenda

Background

File Server Protocol Test Suites Cross Platform

Demo

Background

4

Background

…

.NET Core

PowerShell

Core

WSL

Shell/

C / Java

/Python

Control

Adapter

• Explorer cross platform experience gradually

• Test Suite 4.20.9.0

• PTF 2.0.0

File Server Protocol Test Suites Cross Platform

6

Protocol Test Framework

Protocol Test Framework

Features .NET Framework Version

Supported Features .NET Core VersionEnabled Features Release GitHub MSI NuGetPackage

Install Explicitly install MSI Side-by-side with test suites WiX Dependency Yes No

Spec Explorer Yes No

Test Environment ✓ ✓

Configuration (ptfconfig) ✓ ✓

Checking ✓ ✓

Power Shell Adapter ✓ ✓ Managed Adapter ✓ ✓ Shell Adapter ✓ Interactive Adapter ✓ File Logging ✓ ✓ Console Logging ✓ ✓ Beacon Logging ✓ ETW logging ✓ Automatic Network Capturing ✓

Protocol Test Framework

8

Protocol SDK

Protocol

SDK

Remove

Spec Explorer

dependency

Rewrite

SSP & SSPI

with C#

Fix .NET Core

Incompatible APIs

File Server Test Suite

▪

Migrated to .NET Core 3.1

▪

Removed Spec Explorer dependency

▪

Removed WiX dependency

Protocol Test Suites

FSA

SMB2

SQOS

Auth

DFSC

RSVD

10

PTM / PTMCli

PTM/PTM Cli

.NET Framework Test Suite

.NET Core Test Suite

Similar Experience as Before:

GUI, Auto Detect, Run case, Profile, etc.

PTM

Windows

Windows

Linux

macOS

Run case, Profile

File Server Protocol Test Suites Cross Platform

Significant Changes

Cross Platform Support

PTF

SDK/File Server Test Suite PTMCli

Less Dependencies

No SE dependency No WiX dependency

No VS dependency Only .NET Core SDK dependency

12

How to use ? -

Build and Run from Scratch

Install

Clone

Config

Build

Run

•Install .NET Core SDK 3.1

•Clone source code from GitHub

repo

•Modify ptfconfig file

•Run with Scripts, PTMCli or PTM (Windows)

•RunTestCasesByFilter.sh "TestCategory=BVT&TestCategory=SMB311" •RunTestCasesByFilter.ps1 "TestCategory=BVT&TestCategory=SMB311"

•PtmCli.exe <-p|--profile profileName> [-s|--selected] [--categories categories] [-r|--report reportFile]

•Build test suite

•Install .NET Core SDK 3.1

•Download and extract the latest test suite package

Install

•Modify ptfconfig file

Config

•Run with Scripts, PTMCli or PTM (Windows)

•RunTestCasesByFilter.sh "TestCategory=BVT&TestCategory=SMB311" •RunTestCasesByFilter.ps1 "TestCategory=BVT&TestCategory=SMB311"

•PtmCli.exe <-p|--profile profileName> [-s|--selected] [--categories categories] [-r|--report reportFile]

Run

14

How to use ? – Run with Docker

Host

Host\VM OS files & libs

Container (test suite instance1) Container (test suite instance 2) Container (test suite instance 3) Unassigned

•Install Docker Desktop

•

snap install docker

•Download Configuration Files

•

Wget https://github.com/microsoft/WindowsProtocolTestSuites/releases/download/4.20.9.0/fileserver-docker-ptfconfig.tar.gz

•Run Test Cases

•

Docker run

•

–hostname <hostname>

•

--network host

•

-v <ptfconfig path>

•

-I <image name>

•Pull image from Docker Hub & Config Network

•

docker pull mcr.microsoft.com/windowsprotocoltestsuites:fileserver

Install

Pull

Download

Config

Run

16

Domain Controller

SUT 2 Driver 2 SUT 1 Driver 1

Meetup Environment

Demo SUT Demo Driver

Protocol Testing Environments on Azure

VPN Gateway

Meetup Environment Topology

1.

Dial In Azure Test Environment via VPN

2.

Remote to Driver Computer

3.

Run Cases on Driver Computer against SUT

Run Test

Run Test

PTM (Windows)

DEMO

Run FS Test Suite with

PTMCli

on Linux Driver

Run FS Test Suite with

Docker Image

on Linux Driver

18

QA & Thank You

For Test Suites support: GitHub aka.ms/wpts
