Data Centre
COST-EFFECTIVE,
HIGH QUALITY
SOLUTIONS FOR
FASTER BUILD
AND EARLIER
PROJECT
COMPLETION
Kingspan is a world-leader in high
performance integrated construction
solutions providing rapid build, value
engineered, tested and accredited
solutions for the global building industry.
Having already provided data centre construction solutions
to some of the world’s biggest names, our knowledge and
experience, combined with our comprehensive product
portfolio, allows us to offer a unique, single-source package
to meet the demand for high quality, fast build construction
solutions.
Our designers and project delivery teams will ensure your data
centre facility is co-ordinated and delivered to the highest level,
whether it be new build, extension or refurbishment.
Through the application of industry-leading data centre
benchmarking methodologies and processes, we can bring
significant value and consistent high quality solutions while
reducing build programme to facilitate earlier operation.
Key to the delivery of resilient data centre construction
is an understanding of the:
• IT solution;
• M&E solution;
• Facilities Management solution; and
• Green solution.
Single-Source
Construction Solutions
THE DEMAND FOR
DATA CENTRES
CONTINUES TO
REFLECT THE
GROWING AND
CHANGING NEEDS
OF A CONNECTING
WORLD.
Our systems and solutions seamlessly integrate with the modular
grid construction method specific to the data centre sector,
and our team of experts ensure our solutions meet, and even
exceed, stringent data centre criteria, design-build guidelines
and CSR agendas.
Incorporating the specific construction parameters required by
data centre specialists and operators, our product range offers:
• Systems and solutions supported by project cost
benchmarking both locally and globally;
• Minimal energy loss and improved PUE rating;
• Sustainable design and the ability to enhance BREEAM
and LEED ratings;
• Recommended specialist installation contractors;
• International fire test certification;
• Scalable design solutions;
• Flexibility and adaptability of componentry;
• Dimensional co-ordination;
• Key structural and loading requirement compliance;
• Resilient, secure and airtight environments;
• Utilisation of BIM process; and
• Incorporation of latest technologies.
Seamless
Integration
SOLUTIONS
FOR MAXIMUM
FLEXIBILITY,
SECURITY AND
RESILIENCE
Open up to our Range of
Advanced, High Performance
Construction Systems...
Roof System PV Walls & Facades Internal Walls Intermediate Floors
Secondary Steelwork Access Floors Cooling Solutions Ducting Internal Doors
Lighting
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
• Insulated Roof Panel Systems • Roof Systems • Height Safety Systems • Insulated Architectural Wall Panel Systems • Insulated Façade Systems• Fire Rated Internal Compartmentation Wall and Ceiling Systems
• Profiled Steel Floordeck • Fire Rated Door
Systems
INTERMEDIATE
FLOORS
INTERNAL
DOOR SYSTEMS
ROOF
SYSTEMS
WALL & FAÇADE
SYSTEMS
INTERNAL WALLS
& CEILINGS
DATA CENTRES REQUIRE
SECURE AND RESILIENT
OPERATING ENVIRONMENTS.
KINGSPAN PROVIDE INTEGRATED
HIGH PERFORMANCE
CONSTRUCTION SOLUTIONS TO
MEET STRINGENT DESIGN CRITERIA
AND THE INCREASING NEED FOR
ENERGY EFFICIENCY.
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
Roof System PV Walls & Facades Internal Walls Intermediate Floors
Secondary Steelwork Access Floors Cooling Solutions Ducting Internal Doors
Lighting
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
• Roof Mounted PV Solutions Infrastructure Pathways • Raised Access Floor Systems • Structural Grid Ceiling Systems Airflow Management • ContainAire® Aisle Containment Systems • SmartAire® In-Floor Cooling Systems • Intelligent LED Lighting • Purlins, Rails andChannels
SECONDARY
STEELWORK
SOLAR PV
SYSTEMS
ACCESS FLOORS
& COOLING
LIGHTING
SOLUTIONS
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
Shell & Core Solutions
Infrastructure
Pathways
& Airflow
HVAC Insulation
Lighting
Roof System
PV
Walls & Facades
Internal Walls
Intermediate Floors
Secondary Steelwork
Access Floors
Cooling Solutions
Ducting
Internal Doors
Lighting
• Insulated Ductwork • Insulation for PipeworkDUCTWORK &
PIPEWORK
Kingspan Integrated Data Centre Solutions
BENCHMARK
Fire Rated Façade Systems
Kingspan Fire Rated Insulated
Architectural Wall Panel Systems
BENCHMARK Kreate Integrated Façade System
BENCHMARK Evolution Range Louvre &
Curvewall Tramline & Plank Wave & Convex Mini-Micro & Flat-Stucco Flat & Euro-Box Micro-Rib
Kingspan Fire Rated Insulated Roof Panel Systems
Fire Rated Roof Systems
Topdek Insulated Membrane Roof Deck • Flat and pitched roofs
above 0.72° after deflection
• Curved roofs: convex 45m radius, concave 50m radius
• LPCB & FM Approved
Trapezoidal
• Pitched roofs of 4° or more after deflection • LPCB & FM Approved
KingZip IP Insulated Standing Seam
• Pitched roofs of 1.5° or more after deflection • LPCB Approved
Kingspan KingZip SF Standing Seam
• Pitched roofs of 1.5° or more after deflection • Convex and concave
curved • Class 0 BS476 Fire Rating Morzip Standing Seam* • Pitched roofs of 1.5° or
more after deflection • Convex and concave
curved
* When used with a fire rated insulation core
Kingspan
Secondary Steelwork
Kingspan
Intermediate Floors
Shell & Core Solutions
Kingspan Thermaroof®
TR26 LPC/FM • Insulation board for
flat roof applications • LPCB & FM Approved
Internal Fire Rated
Compartmentation
Wall & Ceiling
Systems
• 60 to 180 minutes fire ratings
Kingspan Integrated Data Centre Solutions
Micro-Rib Ultra Range
Kingspan Energy Rooftop Solar PV
Shell & Core Solutions
Kingspan Thermaroof®
TR26 LPC/FM • Insulation board for
flat roof applications • LPCB & FM Approved
Kingspan Height
Safety Systems
Saferidge Safetraxx SafesideInternal Fire
Rated Doors
• 60 to 180 minutes fire ratingsKingspan Access Floor Systems
• 15kN/m2 UDL
• 4.5kN/m2 Point Load
• Class 0 BS476 Fire Rating • Pedestal height 150mm – 1200mm
Kingspan Smart-Lite High Bay
Kingspan Access Floor Systems
• 15kN/m2 UDL
• 4.5kN/m2 Point Load
• Class 0 BS476 Fire Rating • Pedestal height 150mm – 1200mm
FDEB 38 Alpha III pedestal CS600
Access Floors & Airflow Management
Tate Airflow Cooling Solutions
• SmartAire® MZ automatic airflow controls
• DirectAire® panel – cools over 19kW per rack
• ContainAire® aisle containment solutions – FM Global compliant
SmartAire® MZ
automatic VAV damper DirectAire
® high capacity
airflow panels
ContainAire® hot aisle
containment systems ContainAire
® cold aisle
containment systems Tate Structural Ceiling
Grid Systems
Kingspan Insulated
Ductwork &
Insulation for
Pipework
Kooltherm® FireSleeve &
Insulated Pipe Supports Kooltherm
® FM
Pipe Insulation Kooltherm
® FM &
Therma Duct Insulation
HVAC Insulation
Kingspan LED Lighting Solutions
Kingspan Smart-Lite Linear Kingspan Smart-Lite Recess
Lighting
Shell & Core
Solutions
single component
single component
insurer certified superior
allows up to up to installation installation systems 60 to 180 minutes and weathertightness internal fit-out faster on-site installation time faster on-site
single-fix
single-fix
firesafe
fire rated
airtightness
earlier
External Building Envelopes
Kingspan insulated roof, wall & façade systems offer significant advantages over conventional site-assembled systems.
High quality, factory-engineered solutions, they provide fast installation with high thermal performance, 100� insulation continuity and minimal air leakage.
Internal Compartmentation Walls, Ceilings & Doors
Kingspan internal compartmentation panels are suitable for the construction of non-loadbearing internal partition walls and ceilings. With proven fire ratings to perform as internal firewalls, ceilings or compartmentation walls, the panels integrate with our doors for a complete fire rated solution.
50�
KINGSPAN
INSULATED PANELS’
PRODUCTS CAN
SIGNIFICANTLY
CONTRIBUTE
DIRECTLY TO BOTH
BREEAM & LEED
ACCREDITATION
class-leading promotes requires faster capacity up to 240 minutes construction components than other systemsload
fire rated
faster
fewer
Intermediate Floors & Secondary Steelwork
A range of high performance structural products including profiled, galvanised steel floordecks, purlin and cladding rail systems and pre-engineered channel sections.
Multibeam Purlins and Rails & Multichannel
Multideck Profiled Steel Floordeck
Kingspan Energy Rooftop Solar PV
Kingspan Energy offers a comprehensive range of roof mounted PV solutions for the optimisation of on-site power generation, either client-financed or fully-funded, with a unique 25 year combined roof and PV system guarantee.
Part of the Kingspan Group of companies, with over
50 years of experience in the industry, Tate is the largest
raised access floor manufacturer in North America, and the
leading authority on underfloor service distribution
and data centre airflow management.
To date, Tate has installed in excess of 200 million square feet of raised access floors in data centres worldwide and cools over 120,000 new IT racks every year.
As a foremost authority on data centre airflow management, Tate has created a global brand of innovative next generation airflow management solutions called Tate Airflow Tate Airflow products efficiently manage the airflow in the data centre by eliminating by-pass air to maximise capacity and reduce costs. Easily installed in existing or new data centres our products offer cost-effective and energy efficient solutions to maximise airflow and create flexible self-monitoring cooling infrastructure that is prepared for the future.
Infrastructure Pathways
Raised Access Floors
Tate ConCore access floor panels are epoxy coated unitised shells consisting of a flat steel top sheet welded to a formed steel bottom sheet filled with a highly controlled mixture of lightweight cement. Manufactured to exact tolerances these solid panels deliver the ultimate in design, performance, plenum integrity, service and usability.
Structural Ceiling Grid
Tate Airflow Ceiling Grid is a continuously thread along grid that allows for support of building infrastructure at any location in data hall (white space) areas. An integrated solution for supporting containment structures, cable trays, caging and power distribution systems, Ceiling Grid supports up to 167 kg/m.
TATE ACCESS
FLOORS PROVIDE
FLEXIBLE SYSTEMS
FOR FUTURE-PROOF
DATA CENTRE
DESIGN
Access Floors
Airflow Management
Directional Airflow Panels
Tate Airflow has a full line of directional airflow panels to cater to all your data centre cooling needs, almost doubling the cooling capacity for the same amount of airflow.
Providing virtual containment without limiting flexibility, directional airflow panels eliminate bypass air in excess of 85�. This precise delivery of air offers many financial benefits for both new and existing facilities.
Airflow Sensors & Controls
SmartAire® MZ automated multi-zone damper offers automatic
balancing by delivering the right amount of air to the equipment at the right time, ensuring the correct inlet temperature is maintained. Failsafe in operation and continuously self-balancing, SmartAire® MZ adjusts cooling independently
to 4 separate zones of a rack to allow for server idle mode, equipment refresh and rapid deployment without overcooling. The SenseAire sensor network provides visual indicators for over/under cooled equipment and real time remote monitoring of data centre conditions with a log of historical data.
ContainAire
®Aisle Containment Systems
The ContainAire® aisle containment system range features: soft
partitions; hard partitions, single and dual sliding doors; strip doors; rigid roofs; and custom solutions.
Cold & Hot Aisle Containment
A cold aisle containment system physically encloses an aisle, trapping the supply air inside the aisle. Containing an entire row of air can improve capacity and energy efficiency by reducing by-pass airflow.
Hot aisle containment isolates hot air from the room and provides a return paths to the plenum. The entire room can be cooled while the exhaust air is isolated to keep it from mixing with the cool air in the rest of the room.
SmartAire® MZ automated damper DirectPerf 32� DirectAire SenseAire sensor network ContainAire®
cold aisle containment
Cabinets & Enclosures
IsoFlo®
The IsoFlo cabinet completely isolates the IT cooling and exhaust flow from the rest of the facility. An energy-efficient, future-proofed system, IsoFlo® easily accommodates
expanding ASHRAE thermal guidelines.
The IsoFlo® system features: raised floor supply; ceiling return; and, enclosed cabinet.
An optional pressure controlled damper system is available.
TATE AIRFLOW
MANAGEMENT
SOLUTIONS DELIVER
THE RIGHT AMOUNT
OF AIR, AT THE
RIGHT PLACE, AT
THE RIGHT TIME
ContraFlo®
The ContraFlo® cabinet turns airflow upside down to offer an alternative to
hot aisle containment without overhead obstructions. Using a raised floor plenum as the return plenum, ContraFlo can simplify the requirements needed to successfully isolate hot exhaust air.
The ContraFlo® system features raised floor return and enclosed cabinet.
Insulation for
HVAC and Pipework
Kingspan KoolDuct
®The Kingspan KoolDuct® system comprises
non-fibrous, premium performance insulation, coupling systems and a complete line of accessories to produce pre–insulated rectangular ductwork.
Kingspan Kooltherm
®FM
Duct Insulation
Kingspan Kooltherm® FM Duct
Insulation comprises a non–fibrous phenolic insulation core,
faced on external side with an aluminium vapour barrier foil, and on the internal side with a glass tissue
based facing.
Kingspan Kooltherm
®
FM Pipe Insulation
The Kooltherm® FM Pipe Insulation System comprises high
performance FM Approved Kooltherm® Pipe Insulation,
Kooltherm® Insulated Pipe Support Inserts and Kooltherm®
FireSleeves.
The system achieves a BL-s1, d0
European Fire Classification and a 2 hour fire rating as a fire sleeve.
Kingspan Therma
™Duct Insulation
Kingspan Therma™ Duct Insulation comprises a high
performance PIR insulation core, faced on both sides with a low emissivity
composite foil during manufacture.
M&E Zones
Electrical Mechanical
Data Hall (or ‘white space’) Office
KINGSPAN
PRE-INSULATED
DUCTING
SYSTEMS FOR
FAST, SINGLE-FIX
INSTALLATION
For global enquires:
email: [email protected]
Locations in 100 countries, for local contacts visit:
www.kingspan.com
Or contact:
UK, Ireland & RoW: +353 (0) 42 9698500
North America:
Insulated Panels:
+1 (386) 626 6789
Tate Access Floors:
+1 (410) 799 4200
Australia:
+61 (0) 2 8889 3000
Germany:
+49 (0) 281 95250-0
