(1)
(2)
(3)

Output1 Output2

Model Voltage Current Voltage Current Power

Single-output power supplies TOE8951-20

TOE8951-40 TOE8951-60 TOE8951-80 TOE8951-130

0- 20 V 0- 40V 0- 60 V 0- 80V 0-130 V

0-40 A 0-20A 0-14 A 0-10A 0- 6A

- 400W

400W 400W 400W 400W Dual-output power supplies

TOE8952-20 TOE8952-40 TOE8952-60 TOE8952-80 TOE8952-130

0- 20V 0- 40 V 0- 60V 0- 80 V 0-130V

0-20A 0-10 A 0- 7A 0- 5A 0- 3A

0- 20V 0- 40V 0- 60V 0- 80V 0-130V

0- 20A 0 - 10 A 0- 7A 0 - 5 A 0- 3A

2x 200W 2 x 200W 2x 200W 2 x 200W 2x 200W

(4)

Technical specifi cations Numberofsteps 1000

Stepdata Voltage, current,steptime Steptime 10msto100s,resolution5ms Curvetriggering

Internal Manual withkeyoroverbus withremotecontrol command External ViaTTLsignal or switchcontact Numberof blocks 10

(5)
(6)

Output TOE 8951-20 TOE 8951-40 TOE 8951-60 TOE 8951-80 TOE 8951-130

Voltage 0-20V 0-40V 0-60V 0-80V 0-130V

Current 0 -40A 0-20A 0-14 A 0-10 A 0- 6A

Power adjustableinrange 20-400W 20-400 W 20-400W 20 -400 W 20-400W

Settingresolution Voltage Current Power

5 mV 10 mA 0,1W

10 mV 5mA 0.1W

10 mV 2mA 0.1W

20 mV 2mA 0.1W

20 mV 1 mA 0,1W

Settingaccuracy Voltage

Current Power

0,1%+ 10 mV 0,2%+40mA 0,4%+ 1 W

0.1%+20mV 0.2%+20mA 0.4%+1W

0.1%+30mV 0.2%+15mA 0.4%+1W

0.1%+40mV 0.2%+10 mA 0.4%+1W

0,1%+60 mV 0,2%+5mA 0,4%+1W Deviationinregulation

with100%changeinload

Voltage Current

10-4+5mV 5 x10-4+ 20mA

10-4+5mV 5x10-4+10mA

10-4+ 5mV 5x 10-4+7mA

10-4+ 5 mV 5x10-4+5mA

10-4+ 5mV 5x 10-4+2mA

Withchangeinlinevoltage ±10%

5x10-5 5x10-5 5x10-5 5x10-5 5 x10-5

Regulationtimewithchangeinload from20%to

100 %Irated Tolerance: 0.2%Vrated

100 s 100 s 100 s 100 s 100 s

Settingtimeof output voltagewith changeinsetpoint

0 VtoVratedno-load/ full load Vrated to1Vno-load/ fullload

6ms/ 10ms 30 ms/ 8ms

8ms/ 10ms 50ms/ 10ms

10 ms/ 15ms 100ms/ 25ms

15ms/ 20ms 200 ms/ 50ms

50ms/ 60ms 1,5s/ 400 ms Residualripple(rms)

10 Hzto10 MHz

Voltage Current

3mV 12 mA

3mV 10 mA

6mV 7mA

10mV 5 mA

12mV 2 mA Measuringaccuracy Voltage

Current Power

0,1%+ 20 mV 0,2 %+ 60mA 0,4%+1W

0.1%+ 30mV 0.2%+30mA 0.4%+ 1 W

0.1%+45mV 0.2%+20mA 0.4 %+ 1W

0.1%+60mV 0.2%+15mA 0.4%+1W

0,1%+80 mV 0,2%+ 10 mA 0,4%+1W Temperaturecoefficient Voltage

Current

10-4/ K 10-4/ K

10-4/ K 10-4/ K

10-4/ K 10-4/ K

10-4/ K 10-4/ K

10-4/ K 10-4/ K Analoginterface

Controlvoltage

(referencepotentialisthenegativepoleof theoutput)

0-5Vfor 0 -5Vfor

0-20V 0-40A

0-40V 0-20A

0-60V 0-14 A

0-80V 0-10 A

0-130V 0- 6A

Protectionfunctions Adjustment rangeforOVP Adjustmentrangeforlimit

3-22V 0-20V

3 -44V 0-40V

3-66V 0-60V

3-88 V 0-80V

3-143V 0-130V Resistant tofeedback Voltage

Current

100V 40A

100 V 20A

100 V 14A

100 V 10A

160V 6A

(7)

Output TOE 8952-20 TOE 8952-40 TOE 8952-60 TOE 8952-80 TOE 8952-130

Voltage 2 x0-20V 2x0 -40 V 2x0-60 V 2 x0-80V 2x0-130V

Current 2x0-20A 2x0-10A 2x0-7A 2x0-5A 2x0-3A

Power adjustableinrange 2x10 -200 W 2x10-200W 2 x 10 -200W 2x10-200 W 2x10-200W Settingresolution Voltage

Current Power

5mV 5 mA 0,1W

10mV 2mA 0.1W

10 mV 1mA 0.1W

20mV 1 mA 0.1 W

20mV 1mA 0,1W Settingaccuracy Voltage

Current Power

0,1%+10mV 0,2%+20 mA 0,4%+1W

0.1%+20mV 0.2%+ 10mA 0.4%+1W

0.1%+30mV 0.2%+ 7mA

0.4%+1W

0.1%+40mV 0.2%+5mA 0.4%+1W

0,1%+60mV 0,2%+ 3 mA

0,4%+1W Deviationinregulation

with100 %changeinload

Voltage Current

10-4+5mV 5x10-4+ 10 mA

10-4+5mV 5x10-4+ 5 mA

10-4+5mV 5x10-4+ 3mA

10-4+5mV 5x10-4+2mA

10-4+5mV 5x10-4+ 1,5 mA Withchangeinlinevoltage

± 10%

5x10-5 5x 10-5 5x10-5 5x10-5 5x10-5

Regulationtimewithchangeinload from20%to100%Irated Tolerance: 0.2%Vrated

100 s 100 s 100 100 100

Settingtimeof output voltagewith changeinsetpoint

0 VtoVratedno-load/ full load Vratedto1Vno-load/ full load

6ms/ 10 ms 30ms/ 8ms

8 ms/ 10ms 50ms/ 10 ms

10ms/ 15ms 100ms/ 25 ms

15 ms/ 20 ms 200 ms/ 50ms

50ms/ 60 ms 1,5s/ 400ms Residual ripple(rms)

10Hzto10MHz

Voltage Current

3mV 10mA

3 mV 5mA

6mV 3mA

10mV 2mA

10mV 1,5mA Measuring accuracy Voltage

Current Power

0,1%+20 mV 0,2%+30 mA 0,4%+1W

0.1%+ 30 mV 0.2%+ 10mA 0.4%+ 1W

0.1%+45mV 0.2%+ 7mA

0.4 %+ 1W

0.1%+ 60 mV 0.2%+5mA 0.4%+1W

0,1%+ 80 mV 0,2%+ 5 mA

0,4%+ 1 W Temperature coefficient Voltage

Current

10-4/ K 10-4/ K

10-4/ K 10-4/ K

10-4/ K 10-4/ K

10-4/ K 10-4/ K

10-4/ K 10-4/ K Analoginterface

Control voltage

(referencepotentialisthenegativepoleof theoutput)

0-5Vfor 0-5Vfor

0-20V 0-20 A

0-40V 0 -10A

0-60V 0-7A

0-80V 0-5A

0-130V 0-3A

Protectionfunctions Adjustment rangeforOVP Adjustment rangeforlimit

3-22 V 0-20V

3-44V 0-40V

3 -66V 0-60V

3-88 V 0-80V

3-143 V 0-130V Resistanttofeedback Voltage

Current 100

V 20 A

100V 10 A

100V 7 A

100V 5A

160 V 3A

(8)

General data Output Insulation

Floatingandelectricallyisolated ±250Vagainst ground RS 232 interface

Interface Transfer rate Settingrate Measuringrate Software

9-pinD-SUBconnector,

electrically isolatedfrommainoutput 110 to57,600baud

Approx.20settings/ s Approx. 15 measurements/ s Commandsequenceinaccordancewith IEEE488.2; SCPI

Analog interface Control voltage Inputimpedance

0-5Veachfor0-Vmaxand0-Imax Approx. 10 kOhm

Line voltage 115 Vor230V± 10 %, 47 -63 Hz, theunit setsitself automaticallytothe existinglinevoltage

Power consumption Approx.680VA

Protective measures Protectionclass1inaccordancewith DINEN61010-1

EMC EN61326

Operating temperature 0°Cto40 °C Storage temperature -20°Cto70°C Reference temperature 23 °C ± 1°C Dimensions

withfeet

224 x88 x405mm(WxHxD) 224x103x405mm(WxHxD) 19 system ½19 ,2HU

Weight Approx.5kg

(9)

Arbitrary function in the unit TOE9151 ForTOE8951-xx TOE9152 For TOE8952-xx PC software for curve generation TOE9751 For TOE8951-xx TOE9752 ForTOE8952-xx GPIB interface

TOE8951/ 015 ForTOE8951-xx TOE8952/ 015 For TOE8952-xx USB interface

TOE8951/ 025 For TOE8951-xx TOE8952/ 025 ForTOE8952-xx Single-output power supplies TOE8951-20 TOE8951-40 TOE8951-60 TOE8951-80 TOE8951-130 Powersupply Powersupply Powersupply Powersupply Powersupply

20 V/40 A 40V/20A 60 V/14 A 80V/10A 130V/ 6 A

Dual-output power supplies TOE8952-20 TOE8952-40 TOE8952-60 TOE8952-80 TOE8952-130 Powersupply Powersupply Powersupply Powersupply Powersupply

2x 20V/20A 2x 40V/10A 2x 60V/ 7A 2x 80V/ 5A 2x130V/ 5A

Interlock option TOE 8950/ 101 Controlvia contact Close Open Controlvia TTLsignal Low High Powersupply output On Off Inhibit option TOE 8950/ 102 Control via

contact Close Open

Control via TTLsignal Low High

Power supply output Off On

TOE9101 USB/ GPIBadapter TOE9009 IEEE-488cable, 2 m

TOE9521 19 adapter, 2HUasymmetricfor single installation

TOE9522 19 adapter,2HUparallel installation set for 2 units
