SMARTVUE
CLOUD VIDEO SURVEILLANCE
HD Surveillance Innovation
Fastest to Install Cloud Solution for Any Cameras
One-Click Setup with Almost Any Cameras
Works Anywhere
Browser-based Apple/Windows plus Android, iOS, Win8 Apps
Easiest to Scale
Plug and Play Installation for Thousands of Locations
Simplest to Manage
Manage Thousands of Servers/Cameras from One Website
Super Extensible
Web API for Access Control, Analytics, RFID, and More
Reliable Performance on Any Network
Optimized to Work from 100kbps+
Easiest to Collaborate
Built-in Collaborative Sharing of Video
Simply Elegant Experience
Award-Winning Designs, Intuitive Interfaces
Easiest to Buy
Cost Effective Cloud Solutions
Smartvue® S9Q Servers (Up to 20 HD Cameras)
Smartvue® S9Q
• Supports up to 20 HD Cameras
• Hundreds of Camera Options
• 320GB to 1TB Integrated HDD
• Integrated 802.11N Wireless
• Apple or Windows Web Browser
• iPad, iPhone, Win8, and Android Apps
• Plug-and-Play Installation
• DVI Video Out
• Free Cloudvue Remote Monitoring
• On Demand Cloud Storage
• Linux Based Intel Network Appliance
• 3 Year Limited Warranty
HARDWARE
Size & Weight
Height: 0.07” (19mm) Length: 7.0” (180mm) Width: 10” (255mm) Weight: 2.2lbs (1kg) Construction Rugged Aluminium Fanless Silent Operation Connections
2 X Gigabit Intel Ethernet 4 X USB 1 X DVI 1 X RS232 Storage Internal: 320GB/500GB/1TB SATAII Backup: NAS/USB
Optional Cloud Data Plans:
Unlimited Storage On-Demand
Compliance
FCC (US & Canada) CE/CB/TUV/UL/VCCI RoHS/WEE
EnergyStar Level IV
Installation
Vesa Mount Included
Operating Environment Temperature -10/+60C (14/+140F) Operating System Linux Power External 20V Included SOFTWARE System Setup Plug-and-Play Installation Auto Camera Configuration Simple Cloudvue Setup Free Remote Cloud Access Automatic Date/Time Sync
Web Browser Based
No Software to Install Apple and Windows Tablets and Smartphones Apple, Android, Win8 Apps
Works with Almost Any Camera
Supports Existing Analog Cameras using Encoders
Supports Hundreds of IP Cameras from Axis, Vivotek, Sony, Pana-sonic, Canon, IQInvision, YCam, Cisco, and More
Autofocus, PTZ Support Supports 2-Way Audio / IO
User Support
Simultaneous Users (20) Live & Recorded Video
Supported Devices
Windows and Apple PCs Internet Explorer, Firefox, Safari, and Chrome Web Browsers iPhone - Native iPhone App iPad - Native iPad App Android - Native App Win 8 - Native App
Most Other Web Enabled Devices
Video Formats
Video: H.264, MP4, MJPEG Audio: AAC, GSM-AMR
Backup
NAS NFS CIFS/SMB External USB External Drive (FAT) Realtime Backup and Status
User Management
Unlimited Users/Roles Custom Defined Roles Individual Camera Access Administration Access
Scheduling
Day/Time/Camera Custom Video Recording
Motion Detection Email and Text Alerts
Live Video
High/Low Bandwidth Views Unlimited Custom Views Full Screen
Low/High Resolution Views Live Snapshot
Highlight Motion Detection Highlight Recording
Recorded Video
Record on Motion Detect Record on Schedule Playback Recorded Video Download Recorded Video Bookmark Recorded Video Notes for Recorded Video Search by Date and Time Search by Camera Search by Bookmark Search by Notes Quick Preview Hover Scrub Video
Motion Histogram Complete Date Histogram 2X, 4X, and 8X Playback Drag to Specific Time Full Screen Playback Volume Control Download Video File Zoom Recorded Video Download Direct to USB 128bit Encrypted Watermark
MultiServer
Single Login to Multiple Servers
Tours
Custom Live Camera Patrol Time and Camera Selections
Alerts Power On/Off Motion Detection System Error Camera Disconnect Backup Failure
User Login (Local/Remote) Email (with Snapshot) SMS (Text Message) MMS (Multimedia Message) Multiple User Alerts Multiple Schedule Alerts Default or Custom SMTP
Free Cloudvue Service
Verisign Secured Point and Click Setup
Remote View Multiple Servers Web Browser Based
iOS, Android and Win8 Apps View Live Video
Search/Play Recorded Video *10GB Free per Month
Audio
Enable/Disable Audio Sensitivity Settings Two Way Audio Support
Kiosk Mode
HDMI Out Direct Connect Attach USB Mouse/Keyboard Download Video Direct to USB
Networking
Dynamic or Static NIC
Software Updates
Automatic Firmware Upgrades On Demand Upgrades
Warranty
Three Year Limited
Cloudvue®
Cloud Powered Video Monitoring
Cloudvue offers simple, secure, and cost-effective
video monitoring for up to thousands of servers
and cameras from a single website. It includes
plug-and-play setup and eliminates the
complexi-ties of configuring and managing remote video
surveillance. Cloudvue optimizes video delivery for
any bandwidth connection from DSL to fiber.
Works with Windows or Apple web browsers and
Apps for iPad, iPhone, Win8, and Android devices.
Free with any Smartvue server (1GB/month).
Cloudvue® Storage
Secure Cloud Storage
Store video online or backup any Smartvue cloud
server quickly and reliably. Search, playback, and
download video online from any web browser on
almost any Apple or Windows computer. *Requires
Data Plan
Sharevue
®
Sharevue®
Collaborative Video Sharing
Sharevue makes online video sharing fast, secure,
and cost-effective.
Share individual video clips with anyone quickly
and securely using Sharvue. Click on the Share
button and enter the email address. Sharevue
users can play, fast-forward, digitally zoom-in,
make comments, download, and view associated
HD video clips. *Requires Data Plan
J11 Customer at PC Customer at PC Customer at PC
Main Entry Incident Main Entry Incident Main Entry Incident Main Entry Incident
Commandvue
®
Commandvue®
Enterprise Management and Reporting
Commandvue makes remote management, reporting, and
trouble-shooting of one to thousands of servers and cameras fast,
easy and cost-effective. *Requires Data Plan
• Live Dashboard - Visual Status of Servers and Cameras
• Plug and Play - Easy Integration with any Smartvue Server
• Effortless to Scale - Thousands of Cameras and Servers
• Enterprise Operations - Upgrade All Servers with One Click
• Alerts - Get Instant SMS and E-mail Alerts on Status Change
• Manage Licenses and Users - Manage Services and Users
• Support - Easy Remote Surveillance Support Platform
• Reporting - On Demand and Daily Emailed Reports
• Secure - Secured Online Service
Smartvue® Solutions
Model S9i128 S9i256 S9Q32 S9Q50 S9Q1 S9Z1 S9Z2 S9Z3 S9Z4 S9Z5 S9Z6 S9Z7 S9Z8 S9R3 S9R6 S9R12 S9R24 S9R36 S9R72 S9R96 S9R144 CV100 CMV1 # of Cameras and mbps Supported 10/40mbps 10/40mbps 20/40mbps 20/40mbps 20/40mbps 20/40mbps 20/40mbps 20/40mbps 30/60mbps 30/60mbps 30/60mbps 30/60mbps 30/60mbps 64/128mbps 64/128mbps 64/128mbps 100/200mbps 100/200mbps 100/200mbps 100/200mbps 100/200mbps Unlimited Unlimited Storage Capacity Included 128GB SSD 256GB SSD 320GB 500GB 1TB 1TB 2TB 3TB 4TB 5TB 6TB 7TB 8TB 3TB 6TB 12TB 24TB 36TB 72TB 96TB 144TB 100GB Download Data/Mo. Included 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 1GB 10GB 10GB Rack Size -1U 1U 1U 2U 2U 4U 4U 4U Network 1X1000 1X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 2X1000 Cloudvue Service Included Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes*Features Subject to Change Without Notice
