HARDWARE INFRASTRUCTURE
SOLUTIONS
DATA
The nature of the data that enterprises capture, store and analyze is changing. Enterprises are
challenged with managing the complexity and volume of their data. As technology and resources
change, not all data fits neatly into rows and columns of a table. It comes from many sources in
multiple formats. These large data streams are exceeding the capacity of conventional database
systems. Enterprises are challenged with finding resources to tame the volume, velocity and
variability of massive data in order to analyze and profit from this valuable resource. Enterprises
must choose an alternative approach to current conventional methods in order to unlock the value
of their Big Data. Implementing the right combination of IT hardware, software and analytical
expertise is critical to effectively manage, manipulate and interpret Big Data.
BIG DATA. BIG CHALLENGES. BIG OPPORTUNITY.
How do you manage the
VOLUME , VELOCITY & VARIABILITY
of complex data
streams in order to find
VALUE?
APACHE HADOOP an alternative approach to conventional database management
.
Apache Hadoop is a powerful open source data storage and processing platform designed for
sophisticated analysis of both structured and unstructured complex data. This technology offers
maximum flexibility, scalability and seamlessly integrates into an enterprise’s operation, running
on a cluster of commodity servers. With Apache Hadoop, enterprises can easily explore complex
data using custom analyses tailored to their information, questions and needs. This technology
can help reveal the value of Big Data.
HIGH-PERFORMANCE ENTERPISE HADOOP INFRASTRUCTURE
MODEL
815 Name Node
815 Data Node
(4x 3.5" HDDs)
827 2U Twin Data Node
(6x 3.5" HDDs per Node)
Key Features -Optimized Hadoop Name Node - IPMI 2.0+ KVM with dedicated LAN for remote management
- Cost effective, high performance, power efficient
- Flexible UIO controller or I/O NIC cards
- 4x3.5" hot swap drive bays - Redundant 700W Gold Level 93% efficiency power supplies
-Optimized Hadoop Name Node - IPMI 2.0+ KVM with dedicated LAN for remote management
- Cost effective, high performance, power efficient
- Flexible UIO controller or I/O NIC cards - 4x3.5" hot swap drive bays
- Redundant 700W Gold Level 93% efficiency power supplies
-Optimized Hadoop Twin Data Node - IPMI 2.0 + KVM with dedicated LAN for remote management
- Cost effective, high performance, power efficient
- Two 6x HDD Nodes in 2U of rack space - 6x 3.5" hot swap drive bays per node - Redundant 920W Platinum Level 94% efficiency power supplies
Processor Support
Intel® Xeon® processor E5-2600 Intel® Xeon® processor E5-2600 Intel® Xeon® processor E5-2600 family
Chipset Intel® C602 chipset ; QPI up to 8.0GT/s Intel® C602 chipset ; QPI up to 8.0GT/s Intel® C602 chipset; QPI up to 8.0GT/s
System Memory (Max)
Up to 512GB DDR3 1600MHz ECC Registered DIMM; 16x DIMM sockets
Up to 512GB DDR3 1600MHz ECC Registered DIMM; 16x DIMM sockets
Up to 256GB DDR3 1600MHz ECC Registered DIMM; 8x DIMM sockets Per Node (2 nodes per system)
Expansion Slots 1 x PCI-E 3.0 (x32) left hand side
riser card support 1 x PCI-E 3.0 (x32) left hand side riser card support 3x PCI-E 3.0 (x8) slots (1x low-profile and 2x full-height full-length)
OnBoard & AOC
HBA Controllers 2x SATA 3.0 ports (6Gbps) 8x SATA 2.0 ports (3Gbps) 2x SATA 3.0 ports (6Gbps) 8x SATA 2.0 ports (3Gbps) 6x SATA 3.0 ports (6Gbps) 1x SATA 2.0 ports (3Gbps)
Networking/VG A/ Audio
Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
1x Realtek RTL8211E PHY (dedicated IPMI)
Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
1x Realtek RTL8211E PHY (dedicated IPMI)
Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
1x Realtek RTL8201N PHY (dedicated IPMI)
Manageability IPMI 2.0 + KVM with dedicated LAN IPMI 2.0 + KVM with dedicated LAN IPMI 2.0 + KVM with dedicated LAN Drive Bays 4x 3.5" SAS/SATA hot-swap HDD bays
- 4x 300GB 15K HDD
4x 3.5" SAS/SATA hot-swap HDD bays - 4x 300GB 15K HDD
6x Hot-swap 3.5" SATA3 HDD Bays
Power Supply Redundant (1+1) 700W Gold Level (93%)
high-efficiency power supplies w/PMBus Redundant (1+1) 700W Gold Level (93%) high-efficiency power supplies w/PMBus 1280W Redundant High-efficiency Digital Power Supplies w/ PMBus
Cooling System 4x 4cm heavy duty counter-rotating fans
4x 4cm heavy duty counter-rotating fans 4x 8cm heavy duty fans with PWM fan speed control
Form Factor 1U rackmount chassis (25.6” depth) 17.2"W x 1.7"H x 25.6"D (437 x 43 x 650mm)
1U rackmount chassis (25.6” depth) 17.2"W x 1.7"H x 25.6"D (437 x 43 x 650mm)
2U rackmount chassis (28.5” depth) 17.2"W x 3.47"H x 28.5"D (438 x 88 x 724mm)
MODEL
825 Data Node
(8x 3.5" HDDS)
826 Data Node
(12x 3.5" HDDs)
1GbE & 10GbE Ethernet Switches
Key Features -Optimized Hadoop Data Node - IPMI 2.0+ KVM with dedicated LAN for remote management
- Cost effective, high performance, power efficient
- Flexible UIO controller or I/O NIC cards
- 8x3.5" hot swap drive bays - Redundant 740W Gold Level 93% efficiency power supplies
-Optimized Hadoop Data Node - IPMI 2.0 + KVM with dedicated LAN for remote management
- Cost effective, high performance, power efficient
- Flexible UIO controller or I/O NIC cards - 12x 3.5" hot swap drive bays
- Redundant 1200W Gold Level 93% efficiency power supplies
Key Features:
-Layer 2 / 3 Ethernet Switching - Link aggregation (LACP) - Jumbo frames
- VLAN support
Configuration Flexibility: SSE-G24-TG4
-24 ports of RJ45 1Gbps Ethernet with 4 SFP Combo ports
- 4 ports 10Gbps Ethernet (CX4, XFP, or SFP+)
- Stacking
XG0440DC
- 40 ports of RJ45 1Gbps Ethernet with 4 SFP+ 10GbE ports4 ports
- Provides “fan out” capability for 1GbE server connectivity in compact 1RU high form factor
- Data Center-grade switch with built-in dual hot swappable power supplies
- Provides an easy upgrade path for environments transitioning to 10GbE - 40 1GbE ports with 4 10GbE SFP+ ports - SFP Plus Form Factor
XG2600
-26 ports 10Gbps Ethernet (SFP+) - Offers industry-leading low latency in 10GbE Switching (as low as 300ns latency) -Delivers up to 520Gbps
-Available as 26-port SFP+ optical solution in compact 1RU high form factor
-Flexible SFP+ interfaces (Copper Twinax, SR and LR) allow you to build the ideal network architecture for your requirements -Flexible airflow (front-to-rear and rear-to-front airflow)
-Power consumption under 5 watts per port Processor
Support Intel
® Xeon® processor E5-2600 Intel® Xeon® processor E5-2600
Chipset Intel® C602 chipset; QPI up to 8.0GT/s Intel® C602 chipset; QPI up to 8.0GT/s
System Memory (Max)
Up to 512GB DDR3 1600MHz ECC Registered DIMM; 16x DIMM sockets
Up to 512GB DDR3 1600MHz ECC Registered DIMM; 16x DIMM sockets
Expansion Slots 1 x PCI-E 3.0 x16 slot 6 x PCI-E 3.0 x8 slots
2x PCI-E 3.0 x16 slots 4x PCI-E 3.0 x8 slots
SATA / SAS Via Cable for SATA controller SATA 2.0 3Gbps with RAID 0, 1, 5, 10 SATA 3.0 6Gbps with RAID 0, 1, 5, 10 SAS2 from LSI 2208
HW RAID 0, 1, 5, 6, 10, 50, 60 support
Via Cable for SATA controller SATA 2.0 3Gbps with RAID 0, 1, 5, 10 SATA 3.0 6Gbps with RAID 0, 1, 5, 10 SAS2 (6Gbps) via LSI 2308
SW RAID 0, 1, 10 support
Networking/VG
A/ Audio Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
1x Realtek RTL8201N PHY (dedicated IPMI)
Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead
Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
1x Realtek RTL8201N PHY (dedicated IPMI)
Manageability IPMI 2.0 + KVM with dedicated LAN IPMI 2.0 + KVM with dedicated LAN IPMI Server Management
-HW fault alerts – email or SNMP - Redundant access for management - Support for open standards (SMASH 2.0, LDAP, WSMAN)
- VLAN support
- KVM and Virtual Media and SOL (no additional license needed)
-Easy Maintenance (Command line flash tools for firmware update)
Drive Bays 8x Hot-swap 3.5" HDD Bays;
Support SAS2 HW RAID via LSI 2208 12x 3.5" SAS/SATA hot-swap HDD bays - 1/2TB HDD Power Supply Redundant (1+1) 740W Gold Level
(93%) high-efficiency power supplies w/PMBus
Redundant (1+1) 1200W Gold Level (93%) high-efficiency power supplies w/PMBus Cooling System 3x 8cm 7k RPM middle fans 3x 80mm 4-pin 6300 RPM PWM fans
Form Factor 2U rackmount chassis (25.5" depth) 17.2"W x 3.5"H x 25.5"D (437 x 89 x 648mm)
2U rackmount chassis (25.5” depth) 17.2”W x 3.5”H x 25.5”D (437 x 89 x 648mm) xg2600 (26 10GbE Ports) XG0440DCR (40 1GbE Ports) SSE-G24-TG4 (24 1GbE Ports)
