Welding and cleaning machines

(1)

W elding and cleaning machines

Machines for processing aluminium and PVC profiles

(2)

Pertici Industries, was founded in 1965 by Leto Pertici as Costruzioni Meccaniche Pertici.

Originally, the Company started off with the production of traditional wood-working machines and subsequently developed the production of machinery for the aluminium and PVC door and window industry.

Pertici has always been a competent and reliable supplier of machinery for the production of windows and doors with a range of products constantly developed and improved.

The volume growth and the extension of the production site, accompanied by a production cycle completely controlled inside, allowed Pertici to offer solutions of the highest quality and reliability able to meet the needs of every type of customer.

Thanks to these characteristics, since the eighties, Pertici has been the protagonist of a strong international expansion that allowed the creation of a solid distribution network around the world. In nearly fifty years of work, Pertici has installed tens of thousands of plants in Europe, America, Africa, Asia and Australia.

Today Pertici Industries is a world leader in the design and construction of machines and systems for the processing of aluminium and PVC profiles. Pertici develops and implements cutting-edge technology guaranteeing a global customer service which includes servicing, maintenance, installation, support and timely educational training.

The expertise and experience embedded in all the staff together with the strong presence in the global market are essential elements of the company constant development strategy.

THE COMPANY

(3)

PERTICI WORLDWIDE

(4)

(5)

PVC

Automatic double-head welding machine

^pag

Automatic double-head welding machine WM2LH - WM2L 6

Automatic single-head welding machine

^pag

Automatic single-head welding machine WM1LH - WM1L 7

Corner cleaning machine

^pag

Corner cleaning machine CM1S 8

Welding and cleaning machines

(6)

WM2L

■ Left head fixed – Right head moveable

■ 90° welding on both heads

■ Possibility to weld angles from 40° to 180° only with fixed head

■ Removable knives for welding seal limitation (heated knives only for WM2LH)

■ Limitation of standard welding seal thickness at 0,4 mm or 2 mm (0,2 mm only for WM2LH)

■ Reduction of 3 mm of the welded profile length for each welded profile side

■ Automatic temperature control of the fusion plate by thermoregulator

■ Automatic temperature control of the welding seal limitation knives only for lower knives (for WM2LH)

■ Automatic control of fusion times

■ Automatic control of welding times

■ Separated adjustment of fusion pressure for each welding head

■ Integral protection of working area, welding plates and clamping devices

■ Working cycle and other functions controlled by PLC and limit switch

■ Quick change for counter profiles

■ Possibility to repeat the profile clamping operation, in case of wrong positioning

■ Profile supporting arms

■ Maximum welding length 2500 mm

A utomatic double-head welding machine WM2LH - WM2L

■ Power supply: 3,5 kW

■ Air consumption: 88 Nl/'

■ Dimensions (length x depth x height):

- 3200 x 1800 x 1850 mm

■ Weight: 790 kg

(7)

WM1LH

■ Possibility to weld angles from 40° to 180°

■ Removable knives for welding seal limitation (heated knives only for WM1LH)

■ Limitation of standard welding seal thickness at 0,4mm or 2mm (0,2mm only for WM1LH)

■ Reduction of 3 mm of the welded profile length for each welded profile side

■ Automatic temperature control of the fusion plate by thermoregulator

■ Automatic temperature control of the welding seal limitation knives only for lower knives (for WM1LH)

■ Automatic control of fusion times

■ Automatic control of welding times

■ Adjustment of fusion pressure

■ Integral protection of working area, welding plates and clamping devices

■ Working cycle and other functions controlled by PLC and limit switch

■ Quick change for counter profiles

■ Possibility to repeat the profile clamping operation, in case of wrong positioning

■ Profile supporting arms

- 1700 x 1300 x 1700 mm

■ Weight: 200 kg

A utomatic single-head welding machine WM1LH - WM1L

(8)

CM1S

■ 1 group of milling cutters at a time

■ Pneumatic quick change-over for milling cutter group.

■ Cutting devices to remove the welding seams from the upper and lower sides

■ Automatic device for frame positioning

■ Automatic device to start the working cycle

■ Working cycle controlled by an electronic unit (PLC)

■ Possibility to inhibit upper and lower cutting devices

■ Couple of cutting devices for the upper and lower cleaning, for white profiles

■ Fixed profile supporting arms

■ Cutter sets diameter: 260 mm

■ Maximum profile dimensions: 100 mm height, 120 mm width

■ Motor power: 1,1 kW

■ Blades speed: 2830 rpm

- 500 x 850 x 1450 mm

■ Weight: 230 kg

Options

■ Hydraulic decelerator with a 20 mm stroke

■ Couple of cutting devices for coated profiles

■ Set of milling (as per sample)

C orner cleaning machine CM1S

(9)

N OTE

(10)

N OTE

(11)

Data contained in this catalogue are not binding. PERTICI reserves the right to carry out any modifications deemed necessary to this catalogue for technical and commercial reasons.

(12)

Pertici Industries

Via delle Città,41/43 50052 Certaldo (Firenze) Italy

Telefono +39 0571 652365 Fax +39 0571 652991

S7 - Complete Catalogue R03
