Garden Range
2009
w
w
w
.s
ti
ga
.c
om
2
CO
MB
I CA
RT
INC
LUD
ED!
*
Unique birthday package!
Join us in celebrating 75 years of garden excellence! Our birthday package
contains a special anniversary model of our popular Park rider. A flexible
front mower equipped with ergonomic control panel and mechanical servo
steering, powered by a Stiga engine producing 14 hp. For added value, the
limited 75th edition includes a Combi cutting deck and a combi cart.
Contact your dealer to get the most out of the deal!
PARK ANNIVERSARY
Limited jubilee edition, featuring 95 cm Combi deck, tipping comfort seat and the control panel placed right next to the driver for extra com-fort. Hydrostatic drive, i.e. speed is infinitely variably controlled, both forward and reverse. Wide range of implements for all seasons optional.
COMBI CART
Multi-purpose cart which hitches to the tow bar and can also be used as a wheelbarrow. 180 litres body volume. Body is manufactured from polymer providing a low overall weight.
32
40
20
26
10
Contents
58
62
75 years of garden excellence!
FRONT MOWERS
10
Park Pro
14
Park 18
THE COMBI DECK
20
VILLA
22
Primo
24
IMPLEMENTS 26
LAWN TRACTORS
32
Estate
34
Garden
38
LAWN MOWERS
40
Multiclip
42
Turbo
46
Freeclip
49
HANDHELDS
52
Trimmers & brushcutters
52
Hedgecutters
57
Chain saws
58
RECYCLING
62
Shredders
64
Scarifiers
65
Rotary cultivators
66
Blowers
68
TECHNICAL SPECIFICATIONS
70
The passion for gardening has taken us a long way since 1934. From the first walk behinds to the latest generation of four-wheelers, the Stiga brand remains faithful to the concept of providing home owners with all the machinery they need to make gardening enjoyable.
Job satisfaction is a key word. To achieve this, we combine innovative technology and high momentum while reducing the impact on environment and man. Low emis-sion engines, ethanol powered machines and four-stroke brushcutters reflect our ambi-tion – to hand down an earth in good condiambi-tion for generaambi-tions to come. Please, step up and join us for a ride through 75 years of garden excellence!
6
Gardening from the bird’s eye view.
Articulated steering – for better manoeuvrability.
The secret to our riders is spelled articulated steering. You sit above the pivot point and watch over the cutting deck ahead. Navigating around bushes, trees and fences come easy because the back wheels follow the tracks of those up front. You are really on top of things. It is an incredible feeling, almost as if it drives itself.
Wide range of implements – for year round use.
From brush units and trailers to snow blades and snow blowers. Park and Villa have a wide assortment of implements (see pages 26-31). Thanks to our new RAC quick connection, you easily transform your rider from lawn mower to sweeper or plow in no time at all.
Front-mounted cutting deck – for better accessibility. Because the cutting deck is at the front, nothing is missed. You can mow along fences, cut around trees and reach in under bushes, no aftertrimming required. It saves time and makes your garden-ing work liberatgarden-ingly simple. Besides, you get a better, more even cutting result.
4WD – to stop and go on slippery slopes.
Want to experience pure driving pleasure? Ask for 4WD, power steering and cruise control. Then you can easily stop and go on wet ground and slippery slopes without leaving skid marks. If you want to make life even more comfortable, ask for hydraulic implement lift and electric cutting deck engagement.
Sky-high living-room or playground for small feet. Nursery or strawberry patch for
tired souls. What are the main functions of your garden? Perhaps a mere joy to the
eye, framing the place where you and your family chose to plant yourselves. No matter
how you look at it, the garden, too, thirsts for attention and care. Let us see what your
favourite garden companion can do to make your efforts more gratifying!
And the worm’s eye view.
In the garden of our dreams the grass spreads like a green carpet, lush,
tightly-grown and well-cut. In real life the picture may appear somewhat different. What
the school book tells us is that the difference lies in nutrition, water and care. What
it sometimes forgets to mention is the shortcut called Multiclip, well familiar to
every earth-worm. What it boils down to is getting a more beautiful lawn with the
least amount of effort.
Multiclip – for a more beautiful lawn.
It normally takes three steps to get a good result: cut and remove the cuttings, water and add nutrition. At Stiga we have simplified the process so that you cut and fertilize in one go. In the same action, water binds to the roots so that the lawn can go longer without watering. In only a couple of days, the grass cuttings are broken down and become natural fertilizer. Because you skip the collection stage cutting is easier and faster. Despite spending mini-mal time on garden work, you can compete with the neighbours for the best lawn on the block. The secret is Stiga’s unique mulching technology, Multiclip.
Two-in-one cutting deck – for neater result.
Now we have launched the Combi deck, which takes the technol-ogy a step further and enables you to choose between Multiclip and rear discharge. Multiclip provides a neat, even cutting result and is recommended for regular, weekly use. Rear discharge works better with longer grass. The Combi deck is available in working widths from 85 to 125 cm.
The Multiclip advantage. While saving on water and fertilizer and skipping collection, you get a beautiful lawn with the least possible effort.
12
The benefits of a front mower.
MANOEUVRABILITY.The articulated steering means that the rear wheels follow exactly in the front wheel tracks. You have full control and can easily navi-gate around bushes and trees without running into them. LESS WORK AFTERWARDS.
Because the cutting deck is at the front, nothing is missed. You avoid having to trim afterwards.
VERSATILITY.
Park and Villa are year-round machines with large implement ranges (see pages 26-31). From brush units and trailers to snow blades and snow blowers.
ALL-TERRAIN.
The four-wheel drive which is fitted to several lawn mowers is recommended in hilly terrain.
Driving pleasure on slippery slopes.
Go for a Park with four-wheel drive to avoid slipping or leaving tracks. You can drive, stop and start again on wet grass or snow without losing control, the more powerful the engine the better! Garden size.
The wider the working width the faster you get the work done. The smaller the less storage space required. Primo’s working width is 78 cm. The Combi deck for Villa and Park ranges from 85 to 105 cm. Park’s pro decks range from 110 to 125 cm.
Obstacles.
Genuine articulated steering and front-mounted decks provide maximum manoeuvrability. You see where you are cutting and cut close to rockeries and under bushes.
The time factor.
With the Multiclip cutting technology you mow and fertilize in one go. The work is faster, quieter and requires less fuel. The Combi deck supplied with Villa and Park features two cutting methods: Multiclip and rear discharge.
Which to choose.
For extra driving pleasure, go for 4WD. For complete control from the driver’s seat, add
hydraulic tool lift and electric deck engagement. Then spread the cost over the year by
equipping your Park or Villa with sweeper for the spring, leaf blower for autumn and
snow blade for winter – to name a few of the implements available.
Genuine articulated steering and front-mounted implement provide maximum manoeuvrability all year round.
14
FRON T MOW ER S – PA R K
Think like a professional!
With the Stiga Park 4WD almost anything is possible. You can climb wet slopes unhindered, stop and start again, without slipping and causing damage. In addition, the front-mounted deck gives you full mowing control and can get really, really close-in to trees and under bushes. With genuine articulated steering the rear wheels follow the tracks of the front wheels. Precisely and every time, whether you are cutting grass in the summer or clearing snow in the winter.Tubular steel
A robust impact guard protects the deck. The space between the deck and the
machine is adapted so that you can ride directly up a slope, e.g. onto a trailer.
Pivot wheels make the machine easier to steer.
Hydraulic transmission both front and rear axles. Combi deck
Shift between Multiclip and rear discharge without having to use tools.
Lift for washing position Approx. 30 degrees, without removing the belt.
Front-mounted deck The cutting deck can be adjusted up and down independently of the tubular frame. You always have the correct cutting height for the best mowing results.
Service position Deck can be folded through 90 degrees.
Lift chain for securing the deck in the washing position.
Adjustable steering wheel With power steering.
Hydrostatic drive Increases the speed steplessly.
Hydraulic implement lift Four-position lever. Lift, neutral, down press and down floating.
Hydraulic power steering Hydraulic implement lifter with stronger cylinder.
FRON T MOW ER S – PA R K
Ergonomically designed seat Comfortable sprung seat and seat adjustment with a single control lever.
Genuine articulated steering With genuine articulated steering the rear of the vehicle follows the tracks of the front wheels. Look ahead, the rear of the vehicle will not bump into anything.
Hydraulic pump that powers the steering, transmission and deck lift.
Engine with pressure lubrication
Lubricates even if the machine is tilting. In addition, the engine is located behind the rear axle, which provides better weight distribution and balance.
Powerful engines provide quieter operation and longer service intervals.
Transparent tank You can easily see how much fuel is left.
Easy to raise bonnet Facilitates daily maintenance, checking the oil level and cleaning the air filter.
Large 17 inch wheels With Stiga’s own tread pattern that ensures good grip and a comfortable ride. Chain steering gives
a longer service life.
Newly developed silencer reduces the engine noise output level by 3 dB(A), which halves the perceived noise level. Hour meter
For charging and service intervals.
16
So easy to manoeuvre,
almost like it drives itself.
Articulated steering
is the secret. You sit above the pivot point and look ahead over the
cutting deck. It is easy to turn and easy to navigate around bushes, trees and
fenc-es, because the back wheels follow the track of those at the front. It is an incredible
feeling, almost as if it drives itself. Test drive and experience the feeling of
free-dom! Combined with 4WD you can stop and go almost anywhere without
slip-ping, including slippery slopes and snow-covered driveways.
FRON T MOW ER S – PA R K PRO
PARK PRO 20 4WD
Has the same equipment, features and fantastic comfort as the Pro 25 4WD. The difference being that it has a Vanguard engine from Briggs & Stratton producing 20 hp.
PARK PRO 16 4WD
Has mechanical power steering, foot-controlled lift and electric deck
PARK PRO SVAN 4WD
Svan for the professional market. Specification as for Pro 25 4WD, but with a twin-cylinder Honda GXV 530 engine producing 16 hp. The engine is quiet with low emissions and is therefore one of the reasons why the model is Svan marked.
PARK PRO 25 4WD
Our ”top-of-the-range” machine with hydraulic four-wheel drive, power steering, hydrostatic gearbox and hydraulic implement lift. It has electric cutting height adjustment, electric cutter deck engagement and cruise control. Fantastic driver comfort. Kohler Command Pro engine producing 25 hp. Cutting width 95-125 cm.
RAC-System is included on all Park models.
18
PARK COMPACT 16 4WD
Our smallest 4WD is the perfect choice for those of you who wish to enter the wonderful world of four-wheel drive. It is a flexible Front mower with hydrostatic drive that you can easily manoeuvre around your garden, without leaving skid marks in the event of hill stops and starts. The engine is a Briggs & Stratton producing 15.5 hp.
PARK COMPACT 16
A powerful machine with a Briggs & Stratton engine producing 15.5 hp. Hydrostatic drive, i.e. speed is infinitely variably controlled, both forward and reverse. Tipping comfort seat with drainage and high backrest.
PARK COMPACT 14
As above, but with a 14 hp Stiga engine. Four-wheel drive
available on most Park models.
FRON T MOW ER S – PA R K
RAC-System is included on all Park models.
Peak performance.
Front-mounted cutting deck and genuine articulated steering are signatures of the Park
range, and the four-wheel drive – now available on all models – is an extra impressive
feature. If you need more reasons to choose Park, we suggest that you take a closer look
at the cutting width, engine power, instrument panel and controls. Everything,
includ-ing the cuttinclud-ing height settinclud-ing on the top models, is controlled from the driver’s seat,
with a lever or by pushing a button. Diesel or petrol power is a matter of taste while the
standard hydrostatic gearbox on all Park models is a question of comfort. In addition,
there is a vast range of implements, which means that you can use it all year round. To
plough, sand, sweep, collect leaves... you name it!
PARK DIESEL
A two-wheel drive machine featuring electric cutting height adjustment and hinged engine cover, with mechanical servo assisted steering, manual implement lift and pivot sprung seat. Equipped with a Hatz diesel engine for economical and demanding work. Available with Combi Pro deck with 125 cm cutting width.
PARK RESIDENCE 4WD
Same engine as used on the Comfort combined with 4WD to produce even better traction. Also featuring hydraulic power steering and electric height adjustment, which makes this model extremely versatile and easy to drive.
PARK COMFORT
Briggs & Stratton engine producing 15.5 hp and infinitely variable hydrostatic drive, forward and reverse. New high-performance Combi deck. Extremely comfortable with a single-lever control for adjusting the pivot comfort sprung seat, electric cutting height adjustment and hinged engine cover for easy access to the engine and re-fuelling.
PARK RANGER SVAN
Has a 2-cylinder Honda engine producing 16 hp with hydro-static drive. Extremely comfortable with hydraulic power steer-ing and a ssteer-ingle lever to adjust the pivot sprung seat. Electric cutting height adjustment and hinged engine cover for easy access to the engine and re-fuelling. Svan marked. PARK PRESTIGE 4WD
Prestige has a powerful Kohler engine producing 18 hp. Electric cutting height adjustment and hinged engine cover. Extremely comfortable with, pivot suspension, adjustable steering wheel and single-lever control for adjusting the comfort seat with its high back rest.
FRON T MOW ER S – PA R K
20
The two-in-one cutting deck.
Stiga has developed a range of high-performance cutting decks, which let you choose
between Multiclip and rear discharge. The Multiclip system recycles grass clippings,
and the grass becomes fertilizer for your lawn. Rear discharge deposits the grass behind
the machine, a method which is suitable when the grass is long. To get the perfect
cut-ting result, it is necessary to adjust the cutcut-ting height in small steps. These decks have
continuous electric cutting height adjustment or manual adjustment in 6 mm steps.
WASHING TIPS
Lawn mowers rarely fail due to use or age. If you suddenly notice that the functions of your mower have deteriorated, poor maintenance and corrosion are much more often the explanation. In order to reduce the risk of such problems arising, our mowers with front decks are designed in a way that makes the machines very easy to service and wash. 85 COMBI
Neat and smooth deck for Stiga Villa. Cutting width 85 cm. Two synchronised blades with replaceable blade tips. Manual cutting height adjustment controlled from the driver’s seat.
95 COMBI
Deck for Park and Villa. Cutting width 95 cm. Two synchronised blades with replaceable blade tips. Manual or continuous electric cutting height adjustment.
105 COMBI
Deck for Park and Villa. Cutting width 105 cm. Two synchronised blades with replaceable blade tips. Central cutting height adjustment electri-cally or manually controlled.
125 COMBI PRO
A wide and powerful deck for Park Pro models. Cutting width 125 cm. Three freely rotating blades. Suitable for cutting long grass quickly with rear discharge. Switch between Multiclip and rear discharge without having to use tools. Pivot wheels make it easier to turn. Powerful manual or infinitely variable electric cutting height adjustment.
110 COMBI PRO
Cutting deck in Pro version for Park and Park Pro. Cutting width 110 cm. Suitable for those want-ing to cut long grass quickly with rear discharge. Switch between Multiclip and rear discharge with-out having to use tools. Pivot wheels make it easier to turn. Powerful manual or infinitely variable elec-tric cutting height adjustment.
COM BI DECK
ROLLER 85C/95C/105C
Reinforced tubular steel frames protect deck if it comes into contact with obstacles. Up-turned rounded edges protect trees and bushes.
Continuous electrical cutting height adjustment or manual in 6 mm steps.
Replaceable blade tips with shear bolts. Larger deck volume and new
shape give better cut and better Multiclip finish.
Aerodynamically designed cutting deck and blades provide a perfect Multiclip finish.
Rear rollers and newly designed suspension device give much better rear floating and flexibility. Rear rollers make it easy to raise the deck into the washing and service position.
Rubber strip guides the grass from the rear discharge position.
Combi-plug for change between Multiclip and rear discharge.
Strong bearing boxes and forged 25 mm shaft give better durability.
Pivot wheels with ball bearings with robust plastic wear surfaces.
Aerodynamically designed cutting deck and blades provide a perfect Multiclip result.
Replaceable wear plates.
The deck can be tilted through 30 degrees for cleaning without ha-ving to remove the belt (deck for Park 4WD).
Freely rotating blades. Guide rails to distribute
the cut grass evenly.
Rubber strip. Combi-plug for tool-free change between Multiclip and rear discharge.
Lifting handle facilitates raising into cleaning position.
Reinforced bearing boxes.
With a front-mounted deck you can drive much closer. The blades are near the chassis to maximise the cutting width. Reinforced
protective frame.
22
FRON T MOW ER S – V I L L A
Your year round companion.
Excellent manoeuvrability. Good cutting results. Impressive range of implements. The
home owner’s faithful companion, Villa, combines the Front mower’s cutting
perform-ance with the small rider’s agility. Engines in the Villa series range from 12.5 to 15.5
hp, with either manual gearbox or hydrostatic transmission. All models are equipped
with the new Combi deck, which lets you switch between Multiclip and rear discharge.
VILLA 12
The engine is a Stiga engine producing 12.5 hp. The manual gearbox has five forward gears and one reverse. A new high-performance Combi cutting deck with a 85 cm cutting width gives a choice of Multiclip and rear discharge. High driver comfort is assured with an adjustable ergonomic seat.
VILLA 16 HST
HST means that the machine has a hydrostatic drive, i.e. the speed is infinitely variably controlled, both forwards and reverse. It’s unbelievably smooth and ideal if you have a garden with trees, bushes and plants to mow around. The engine is a powerful Briggs & Stratton producing 15.5 hp, featuring electric continuous cutting height adjustment controlled from the front panel for easy selection of the right cutting height. The 105 cm working width, high-performance Combi cutting deck provides both Multiclip and rear discharge.
VILLA 14 HST
As above, but with a 13.5 hp B&S engine, 95 cm Combi deck and foot-controlled deck lift. Featuring hydrostatic transmission (HST) for easy manoeuverability.
FRON T MOW ER S – V I L L A
RAC-System is available for all Villa models.
24
Forget the chores.
Think driving pleasure!
Primo represents a new generation of compact Front mowers from Stiga aimed at
design-conscious homeowners. Featuring rear-wheel steering and easy-to-use single
hand controls, it reduces the time and effort spent in the garden.
The idea was to create a vehicle, which is manoeuvred and mows as well as the big
Front mowers, and which you can be proud to park on your driveway. Material and
construction, comfort and convenience, road grip and performance – the thinking
is the same as in a modern car. Primo is the name, since it is one of a kind.
PRIMO
Primo is built on a self-supporting frame in com-posite material cast in a single piece, which imparts strength to the construction. Integrated design is the key word. Excellent maneouvrability and high cutting capacity come with the factory-mounted 78 cm combi cutting deck. Stiga 12.5 hp engine.
FRON T MOW ER S – PR I MO
26
1.
3. 4.
2.
Thanks to the wide range of implements your Park or Villa becomes a year round
companion. So think ahead. Choose a machine that fits your needs, now and in the
future. Consider what implements you may want to add, now or later. And play it
safe by choosing 4WD, so that you can get a road grip on all kinds of surfaces.
Note! Some of these implements fit the Estate tractors as well.
RAC QUICK CONNECTION
Enables you to change implements in one easy movement, without the use of any tools! Just click on and off. RAC quick connection is standard on all Park models, and available for all Villa models.
From mower to sweeper
in a minute. Max!
28
I M PL E M E N TS
TOW RAKE ESTATE
Clears paths and gardens from thatch and moss, dead leaves and grass clippings. Twenty tines, heat-treated and spring-loaded, with 102 cm working width.
SWEEPER
Front-mounted with sideways adjustment to three positions. The wheel system allows the operator to find just the right amount of ground pres-sure for every task. Sweeps leaves, snow, gravel and last year's grass with a neat and clean result. 85 cm for Villa, 95 cm for Park and 110 cm for Estate. Dust protection available as an option.
GRASS AND LEAF COLLECTOR
Towed, with a 8,5:1 wheel-to-brush rotation. 107 cm working width. Easy to empty from the driver's position. Aluminum wheel transmission and heavy-duty bag stretcher. Also available in 96 cm working width.
FLAIL MOWER – LAWN RAKE
Operates at 3000 rpm, has a 92 cm working width and electric height adjust-ment. Also available with mechanical height adjustadjust-ment. Cuts rough grass and weeds up to 100 cm tall. Scrub and overgrown areas are easily controlled by the flail mower. An optional lawn rake rotor is also available.
SPRING HOE
For efficient weed removal. Weeds are cut off at the roots, and the working depth is easily set using three screw adjusters. Ideal for combining with the rake tool. Working width 95 cm. FERTILISER SPREADER
Towed with a 30 litre capacity, spreading diameter of 2.5-3 metres.
PLASTIC ROLLER
When ballasted with water, the roller will level out the ground and make the lawn perfectly flat. Light weight when storing.
EDGE CUTTER
Can be mounted on the frame or with a cutting deck. Adjustable angle and depth of cut, self-propelled.
I M PL E M E N TS
SNOW THROWER (1-STAGE)
Snow thrower with auger operates at 1200 rpm, powerful snow removal equipment. Chute allows adjustment of discharge angle and ejection distance.
PRO CART
Galvanized steel, removable rear tailgate and good dump angle, 200 kg load capacity.
SNOW THROWER (2-STAGE)
The auger collects the snow and blows it out via a fan housing to where you want to deposit it – up to 12 m away from the discharge chute. Electrically adjustable discharge chute to carry out safe and controlled work. Working width 90 cm.
COMBI CART
Multi-purpose cart which hitches to the tow bar and can also be used as a wheelbarrow, 180 litres capacity. Body is manufactured from polymer giving a low overall weight.
BLOWER
With adjustable air stream (left and right), controlled from the driver’s seat. Blows away leaves, light snow and dry grass clippings.
SAND SPREADER
Perfect for gravel, sand or salt. Now with more outlets for a more even result. Rear-mounted, it is controlled electrically from the control panel. Working width 100 cm.
SNOW BLADE
Controlled from the driving seat. The blade has skid shoes as well as an automatic control to prevent overloading. Scraper bars
PRO SNOW CHAINS
Provides traction even on ice thanks to transverse links fitted with spikes.
SNOW CHAINS
D-shaped galvanized manganese steel, these snow-chains provide
30
FRAME WEIGHTS
Improve balance and provide ultimate traction to the mower, 2x17 kg for Park and 2x13.5 kg for Villa. DEFLECTOR
Fits the deflector on your Estate or Garden Combi to convert from collector to rear discharge.
FRONT WEIGHT/ REAR WEIGHT ESTATE
Easily fitted on the front or rear of your tractor, the weight kit increases stability of the machine when using it with towed or front-mounted implements. Front weight: 11.5 kg
Rear weight: 23 kg (ballasted with sand)
TOW BAR
The trailer hitch kit for Estate lawn tractors permits you to fit towed implements to your machine.
Front weight Rear weight
RAKE TOOL 100/130
For gravel paths. Choose between the 130 cm rake for gravel (10-20 mm size stones) and the 100 cm rake also suitable for weed removal (2-10 mm size stones). The spring-loaded long tines offers a gentle way to bring thatch to the top of the lawn.
GRADER BLADE For levelling gravel paths.
Rake tool 100
Rake tool 130
REAR TOOL LIFT 3000
The equipment to make use of the rear of the Park Pro, press down and lift up the aerator, grader blade and rakes. Controlled by an electric actuator from the driver’s position.
AERATOR
Perforates the lawn providing oxygen and water to the grass roots. Loosens the soil and and makes the lawn healthy.
PROTECTIVE COVER
Cares for your mower in adverse weather conditions such as rain and snow.
I M PL E M E N TS
I M PL E M E N TS
Pa rk P ro 2 5 4 W D Pa rk P ro 2 0 4 W D Pa rk P ro 1 6 4 W D Pa rk P ro Sv an 4 W D P ar k P res tige 4W D P ark R esidence 4 W D P ar k R ange r S va n Pa rk C o m fo rt P ar k A n n iv ersa ry P ark Di es el Pa rk C o mp ac t 1 6 4 W D Pa rk C o mp ac t 1 6 Pa rk C o mp ac t 1 4 V il la 1 6 H S T V il la 1 4 H S T Vi ll a 12 G ar d en C o mbi H S T Gar d en Co m b i G ar d en C o m p ac t Et ha n o l Gar d en Co m p act EV E st ate O verl an d 2 5 E E st ate O verl an d 2 0 E st at e P ro H 2 5 E E st at e P ro H 2 0 E st ate R o ya l E E st ate R o ya l E st ate Pr es iden t E st ate S enat o r E st ate T o rn ad o H S T E st ate T o rn ad o13-0922-11 Snow thrower 2-stage Park Pro* X X X X
13-0974-11 Snow thrower 1-stage X X X X X X X
299900520/0 Snow thrower Estate** X X
299900600/0 PTO kit Estate X X
13-0993-61 RAC Quick connection 4WD X X X X X X X 13-0992-61 RAC Quick connection 2WD X X X X X X
13-0994-61 RAC Quick connection Villa X X X 13-0981-61 Wheel axle attachment Villa X X X 13-0977-11 Sweeper Park X X X X X X X X X X X X X
13-0980-11 Sweeper Villa X X
299900500/0 Sweeper Estate** X X
13-0973-11 Blower Park X X X X X X X X X 13-0991-11 Rear tool lift 3000 X X X X
13-0961-11 Rake tool 100 cm X X X X 13-0962-11 Rake tool 130 cm X X X X 13-0988-11 Aerator X X X X 13-0989-11 Grader blade X X X X
13-3905-11 Grass and leaf collector 38" X X X X X X X X X X X X X X X X 13-1950-13 Grass and leaf collector 42" X X X X X X X X X X X X X
13-0979-13 Snow blade 120 cm X X X X X X X X X X X X X
13-0967-61 Snow blade metal scraper bar 120 cm X X X X X X X X X X X X X X X X X X 13-1958-62 Snow blade rubber scraper bar 120 cm X X X X X X X X X X X X X X X X X X 13-0990-11 Snow blade 107 cm X X X
13-3904-61 Snow blade rubber scraper bar 107 cm X X X
299900405/0 Snow blade 120 cm Estate X X X 299900400/0 Snow blade 120 cm Estate X X
13-0921-62 Frame weight 2 x 13,5 kg Villa X X X 13-0939-61 Frame weight 2 x 17 kg Park X X X X X X X X X
13-0936-61 Snow chains 16" Wide X X X X X X X X 13-0937-61 Snow chains 17" Park Pro X X X X
13-0940-61 Snow chains 16" X X X X
299900470/0 Snow chains 18" Estate X X X X X X 299900460/0 Snow chains Pro 18" Estate X X X X X X 13-1936-62 Dust protection sweeper Park X X X X X X X X X X X X X
13-1937-62 Dust protection sweeper Villa X X
299900505/0 Dust protection sweeper Estate X X 13-1975-14 Sand spreader Park X X X X
299900100/M Protective cover (8 pcs)
Estate/Park/Villa X X X X X X X X X X X X X X X X X X X X X X X X X X X X X 13-0952-11 Combi cart X X X X X X X X X X X X X X X X X X X X X X X X X X 13-3903-11 Pro Cart galvanized X X X X X X X X X X X X X X X X
13-0970-61 Roller 85C+95C+105C X X X X X X X X X X X X X X X X
299900260/0 Plastic roller X X X X X X X X X X X X X X X X X X X X X X X 13-0978-11 Spring hoe X X X X X X X X X X X X X
13-0976-11 Flail mower X X X X X X X 13-3902-11 Flail mower, electric X X X X X X X 13-0975-11 Lawn rake X X X X X X X 13-3901-11 Lawn rake, electric X X X X X X X
13-0955-11 Fertiliser spreader X X X X X X X X X X X X X X X X X X X X X X X X X X 13-0949-11 Edge cutter 4WD X X X X X X X
13-0957-11 Edge cutter 2WD X X X X X X
299900061/0 Bumper Estate X X X
299900150/0 Rear weight Tractors X X
299900029/0 Collector kit Garden X X
299900024/0 Collector kit Estate X X
299900026/0 Collector kit Estate X X X X 299900028/0 Collector kit Estate X X
299900016/0 Deflector Estate X X
299900051/0 Deflector Estate X X
299900006/0 Tow bar Estate X X
299900085/0 Tow bar Estate Tornado HST X
299900081/0 Tow bar Estate X X
299901006/0 Tow bar Estate X X X X
299900385/0 Tow bar Estate X
32
L AW N T R ACTOR S
CAPACITY
A lot of engine and cutting capacity for the money, particularly effective on open spaces. We recommend the Garden model for up to 1000 m2. For larger areas, go for Estate.
COMPACT
Thanks to the compact format, it operates well in tight spaces and requires minimal storage area.
LONG SEASON
With the large range of implements Estate tractors also earn their keep as leaf and snow clearers in autumn and winter.
NEAT RESULT
Both Multiclip and collection are included on Garden and Estate as standard. If the grass gets too long between cuts, add a deflector and run with rear discharge.
EASY COLLECTING
With wider and straighter chutes and an even more spacious col-lector, you can suck up every last blade of grass. You can empty the collector from the seat. Certain models have an electric lift, so it is enough just to press the button.
Stay on top!
The benefits of a garden tractor.
34
L AW N T R ACTOR S
The first 4WD tractor...
A really good lawn tractor is light to steer, easy to use and comfortable to drive.
Our professional tractors Overland and Pro meet all these criteria. Designed for
large green areas, they let you carry out all jobs around the garden. All are true
3-in-1 machines, combining rear discharge and integrated 360-litre collector with
Multiclip – hybrid collecting/mulching blades and plug fitted as standard.
NE
W!
Steering wheel to select the cutting height from 25 to 100 mm, with memorisation of the chosen height.
Twin control pedals and strong steel foot panels.
Storage space
The brand new 4WD system permits you to work even in critical conditions having full control of your tractor on slippery grounds, with ice or wet mud and slopes. Better performances also when cutting grass on uneven surfaces, no loss of grip means better result for a regular lawn.
ESTATE OVERLAND 20
Twin cylinder 20 hp Kohler engine and 102 cm working width. 360-litre collector. Good steering control and reduced steering circle thanks to pro 4WD.
ESTATE OVERLAND 25 E
Powerful twin cylinder 25 hp Kohler engine and 122 cm cutting deck, for heavy duty tasks. Pro 4WD with good steering control for better traction and reduced steering circle. Electromagnetic blade clutch and 360-litre collector, easy to empty thanks to powered dump.
ESTATE PRO H25 E
Powerful twin cylinder 25 hp Kohler engine and 122 cm cutting deck, for heavy duty tasks. Good steering control and reduced steering circle. Heavy duty iron cast front axle. Electromagnetic blade clutch and 360-litre collector, easy to empty thanks to powered dump.
ESTATE PRO H20
Twin cylinder 20 hp Kohler engine and 102 cm working width. 360-litre collector.
L AW N T R ACTOR S
NE
W!
Pro and Overland features:
r%JBHOPTUJDEBTICPBSEXJUI-&%BOEBO-$%EJTQMBZ r$PNGPSUTFBUBOEMPOHFSUXJOQFEBMTGPSCFUUFSFSHPOPNJDT
and easy hydrostatic control.
r/FXDVUUJOHIFJHIUBEKVTUNFOULOPCmDVUUJOHIFJHIU BEKVTUBCMFJOQPTJUJPOTĚPNNNUPNN r4USPOHTUSVDUVSFBOETPMJEGPPUQBOFMT
r)PMEFSGPSBCPUUMFPSBNPCJMFQIPOFBOEUIFOFX
12V power take out.
r&MFDUSPNBHOFUJDDMVUDIGPSFBTZEFDLFOHBHFNFOUDPOUSPMMFE ĚPNESJWFSTTFBU r#JHHFSXIFFMT uuGPSDPNGPSUBCMFESJWJOHPOVOFWFO surfaces. r 8% 0WFSMBOE r*SPODBTUĚPOUBYMFPO8%NPEFMT
36
Step up and work comfortably!
Designed for medium to large greens areas, our Estate tractors are built on a strong structure,
equipped with reliable engines and fitted with Multiclip function – in combination with
col-lection or rear or side discharge – for optimum cutting result. Our best tip: Add implements
for spring, autumn and winter and spread the cost over the year!
ESTATE TORNADO HST
Built around a Stiga WM 14 hp engine and a 98 cm Multiclip cutting deck, the Tornado HST features hydrostatic speed control (HST), cutting height adjustment (25-80 mm) and a removable rear compartment for small tools. Big wheels (18" and 15") and petrol lever indicator for the 6-litre petrol tank also come as standard.
Rear compartment ESTATE ROYAL E
Full control from driver’s seat thanks to electric dump, electro-magnetic blade engagement and cutting height adjustment (30-90 mm). Powerful Kohler 18 hp engine and 102 cm cutting deck speed up the work. Hydrostatic speed control (HST) and adjustable comfort seat provide extra comfort. 320-litre collector and Multiclip plug included as standard, rear discharge optional.
ESTATE ROYAL
As above but with manual dump.
/PUFUIFFYDMVTJWFEFTJHOPGUIFCPEZBOE
the bonnet with its integrated headlights and distinctive front grille.
PTO-KIT
Increased year-round functionality thanks to PTO system, which allows you to mount powered accessories to the front of your machine. Thanks to an innovative system, power from the engine is directed through a belt to the front accessory. Designed for Estate Royal and Royal E models.
L AW N T R ACTOR S
ESTATE TORNADO
Compact and easy to use tractor with 98 cm working width, built around a 14 hp Stiga WM engine on a new, extra strong structure. Manual transmission with 5 gears forward, 1 reverse. The improved side discharge chute features an extra wide mouth to efficiently handle tall grass. Electromagnetic blade engage-ment, cutting height adjustment (25-80 mm) and tipping seat provide driver comfort. Multiclip plug and trailer hitch are included as standard.
ESTATE SENATOR
As above with Stiga WM 13.5 hp engine and gear transmission (5 forward, 1 reverse).
*OOPĂBUJWF-&%EJBHOPTUJDEJTQMBZ
ESTATE PRESIDENT
Powered by a reliable Kohler Courage 16 hp engine, the President provides two cutting systems in one: 260-litre collector and Multiclip (plug included). Features a 92 cm cutting deck with cutting height adjustment (25-80 mm) and electro-magnetic clutch for blade engagement. Innovative 6 LED diagnostic display indicates the status of your machine while working. Hydrostatic speed control (HST) is standard.
NE
W!
Also featuring: r*OUFHSBUFETJEFDPNQBSUNFOUGPSCPUUMFPSNPCJMFQIPOF r$FOUSBMDPNQBSUNFOU r .JOJNVNUVSOJOHSBEJVTL AW N T R ACTOR S
38
Think green. Buy yellow!
The Garden tractor range meets the needs of small garden owners who passionately
care for their lawns. Great design, high quality and versatility – thanks to the
inte-grated mulching function – are winning features. Thanks to hydrostatic or the new
variator transmission you also get smoother operation.
GARDEN COMBI HST
Compact, lightweight and easy to manoeuvre around trees and bushes thanks to 72 cm cutting deck and hydrostatic speed control. Combines 170-litre collector with Multicilip for perfect cutting result. Powered by a 12.5 hp Stiga engine. An adjustable comfort seat is standard.
GARDEN COMBI
As above but with gear transmission (5 forward and reverse).
)ZESPTUBUJDTQFFEDPOUSPM
L AW N T R ACTOR S
GARDEN COMPACT EV
As compact as it gets, with a 63 cm cutting deck and 140-litre collector, which can be emptied from the driver’s seat. The new variator transmission allows continuous adjustment of the speed, providing better fuel economy and less emissions. Powered by a RM 65 ES Stiga engine, with electric starter and adjustable seat.
Now with variator transmission
for a smoother drive.
r "MMPXTZPVUPDIPPTFUIFTQFFECZZPVSTFMGXJUIPVUDMVUDIQVTIJOH
r 4NPPUIFSTQFFEMFWFS
r &BTZUPESJWFCFUXFFOUSFFTBOECVTIFT
GARDEN COMPACT ETHANOL V
The most ecological lawn rider on the market, built around the unique STIGA REM 70 ethanol-powered engine. Otherwise specified as Garden Compact EV.
L AW N T R ACTOR S
NE
W!
40
Lawn mowers
L AW N MOW ER S
The secret of garden excellence.
In the garden of our dreams we all have a lush green, tightly-grown and well-cut lawn. In real
life the picture may be somewhat different. What the school book tells us is that the difference
lies in nutrition, water and care. What it forgets to mention is the shortcut called Multiclip.
All ethanol or petrol powered Stiga lawnmowers – and some electric – feature the special Stiga
mulching method, Multiclip. Either by itself or combined with collection and rear discharge.
This is what distinguishes each product line.
Multiclip. Better cutting result with less effort. With hood and knives designed to finely chop and spread the clippings. Cuts and fertilizes in one go, retaining water at the grass roots so that the lawn can go longer without watering. The secret is Stiga’s unique mulching technology, Multiclip. Since no collection is needed cutting is easier and faster.
Freeclip. Keeps lawn and body in shape. Extremely quiet, no emissions, no fuel required. Classical rotor mower for small plots and truly environmentally minded gardeners.
Turbo. Professional line for long and arduous work. Our top-of-the-line selection, designed for maximum efficiency and comfortable working under professional conditions. Featuring Stiga’s cutting method, Multiclip, in combination with rear discharge and collection (handling up to 70 l of grass clippings or leaves). Best choice if you from time to time want to ”sweep” the lawn clean of debris.
42
L AW N MOW ER S – M U LT ICL I P
Why some lawns are more
beautiful than others.
All Multiclip models feature Stiga’s unique mulching technology, which transforms
grass clippings into fertilizer in a few days, and provides an exceptional finish. Because
you skip the collection stage, cutting is easier and faster. Choose engine capacity and
cutting width (up to 51 cm) according to the size of your lawn. Options available
include mains electric, ethanol or petrol engine with recoil or electric start and for
added convenience self-propulsion.
MULTICLIP PRO 53 S SVAN
Professional Multiclip aluminium model with a cutting width of 51 cm. Central height adjustment to five levels. Aluminium wheels with professional radial ball bearings. Equipped with AVS. The chassis is laterally offset, which facilitates cutting along walls and obstacles. Self-propelled. Honda GCV 160 OHC Autochoke engine.
MULTICLIP PRO 53 4S SVAN
4-speed model with aluminium chassis and with 205 mm aluminium wheels with ball bearings. 51 cm cutting width. Multiclip Pro handle and equipped with a Honda GCV 190 OHC Autochoke engine.
MULTICLIP 53 S RENTAL
Self-propelled with a cutting width of 51 cm to suit those who have a larger lawn. Central height adjustment to five levels. The chassis is laterally offset, which facilitates cutting along walls and obstacles. Equipped with AVS. Powered by the B&S 675 series XVS engine. Also available with a STIGA SA 65 OHV engine.
MULTICLIP 53 S ETHANOL RENTAL
Specification as for 53 S Rental but with the new ethanol engine SEA 60 OHV for reduced environmental impact.
MULTICLIP 53 4SE RENTAL
4-speed model with electric start and central height adjustment. Equipped with a STIGA SA 65 OHV ES engine.
MULTICLIP PRO 50 SVAN
Easy running aluminium wheels with ball bearings. Equipped with AVS and galvanized cutting deck. Cutting width 48 cm. Central cutting height adjustment to five levels. Honda GCV 135 OHC.
MULTICLIP PRO 50 S SVAN
L AW N MOW ER S – M U LT ICL I P
MULTICLIP 53 S PLUS
This is the lawn mower for those with a slightly bigger lawn. Self-propelled for convenience and with a cutting width of 51 cm. With 28 mm Pro handle, featuring height and lateral adjustment. Central height adjustment to five levels. Wheel size 190 mm in diameter. Equipped with a new Stiga SA 55 OHV or a B&S 625 series XVS.
MULTICLIP 53 S H
Self-propelled with aluminium chassis and with 51 cm cutting width. 28 mm Pro handle, featuring height and lateral adjustment. Central height adjustment to five levels. Wheel size 190 mm on ball bearings. Honda GCV 160 OHC Autochoke engine.
MULTICLIP 50 S INOX H
Specifications as for Multiclip 50 but with stainless steel chassis for less maintenance and higher durability. Equipped with a Honda GCV 160 OHC Autochoke engine.
44
L AW N MOW ER S – M U LT ICL I P
MULTICLIP 50 RENTAL
The top-of-the-range model for those who wish to push. 210 mm diameter wheels with double ball bearings. Cutting width 48 cm. Central cutting height adjustment to five levels. A B&S 500 series XMH or the new STIGA SA 55 OHV engine.
MULTICLIP 50 S RENTAL As above, but self-propelled. MULTICLIP 50 SE RENTAL
As Multiclip 50 S Rental, but with electric starter and a B&S 650 series XVS engine.
MULTICLIP 50 4SE RENTAL
4-speed model with electric starter and with a STIGA SA 55 OHV ES engine.
MULTICLIP 50 4S INOX RENTAL
48 cm stainless steel chassis. 4-speed model with 210 mm wheels with ball bearings. Equipped with B&S 625 series XVS or STIGA SA 55 OHV.
MULTICLIP PRO 50 4S INOX SVAN
48 cm stainless steel chassis. 4-speed model with 210 mm alumini-um wheels with ball bearings. Powered by a Honda GCV 160 OHC Autochoke engine.
MULTICLIP 50 4S SILENT RENTAL
4-speed model with size of 205 mm aluminium wheels and 48 cm cutting width. Multiclip Pro handle. Equipped with the new STIGA SA 55 OHV engine.
L AW N MOW ER S – M U LT ICL I P
MULTICLIP 50 PLUS
This is the entry model to the Plus range. The cutting width is 48 cm and the cutting height is adjustable to four levels. Galvanized deck and ball bearings for all wheels. STIGA SA 45 OHV engine. MULTICLIP 50 S PLUS
As above, but self-propelled.
MULTICLIP 50 S ETHANOL PLUS
Same as 50 Plus, but self-propelled and with the new Stiga SEA 60 OHV ethanol engine for reduced environmental impact. MULTICLIP 50 S INOX PLUS
Specifications as for Multiclip 50 S Plus but with stainless steel chassis for less maintenance and higher durability. Equipped with a B&S 500 series XMH engine or the new STIGA SA 45 OHV engine.
MULTICLIP 50 H
The cutting width is 48 cm and the cutting height is adjustable to five levels. Equipped with a Honda GCV 135 OHC engine. MULTICLIP 50 S H
Specifications as for Multiclip 50 but self-propelled. MULTICLIP 50 S SILENT PLUS
New innovations and materials make Silent unique. There is today no other product like this on the market. A self-propelled model with 210 mm wheels on ball bearings and a 48 cm cutting width. Equipped with the new STIGA SA 55 OHV engine.
46
L AW N MOW ER S – T U R BO
TURBO EXCEL 50 4S
Four-in-one cutting methods (multiclip, collecting, rear and side dis-charge). Galvanized steel chassis with 48 cm cutting width. Washing link for easy cleaning. Variable 4-speed, 300 mm big rear wheels and 75 litre collector for comfortable work . New Stiga SA 55 OHV engine. TURBO EXCEL 50 SE
Self-propelled, single speed with electric start and 260 mm rear wheels, otherwise as above.
Extra everything!
Turbo is our top-of-the-range selection, designed for maximum efficiency and comfortable working
even under tough conditions. Worth noting is the vibration damping (AVS) and the ergonomic
OPC lever, which allows you to adjust the handle to your body height. All Turbo models feature
three or four cutting methods in one machine: Multiclip and Collecting combined with Rear
Discharge – the new Turbo Excel selection topped with Side Discharge. An environmentally
friendly engine is available as an option.
TURBO EXCEL 50 S INOX H BBC
Professional machine powered by a GCV 160 OHC Autochoke engine. Providing 4-in-1 cutting methods (Multiclip, collecting, rear and side discharge) for maximum flexibility. Built on new stainless steel platform with 48 cm cutting width. Washing link for easy cleaning. 300 mm big rear wheels for comfortable work. Spacious 75 litre collector. Blade break clutch, stopping knives with engine running when passing gravel path. TURBO EXCEL 50 S H BBC
Same features and same engine as the model above, built on a galvanized steel chassis.
TURBO EXCEL 50 4S INOX
Four-in-one cutting methods (multiclip, collecting, rear and side dis-charge). Stainless steel chassis with 48 cm cutting width. Washing link for easy cleaning. 300 mm big rear wheels. Variable 4-speed and anti-vibration system for comfortable work. 75 litre collector. Powered by a Honda GCV 160 OHC Autochoke engine.
TURBO EXCEL 50 S INOX
B&S 650 series XVS Ready Start engine. One speed self propelling. Otherwise as above, but without anti-vibration system.
TURBO EXCEL 50 S
Four-in-one cutting methods (multiclip, collecting, rear and side dis-charge). Galvanized steel chassis with 48 cm cutting width. Washing links for easy cleaning. 75 litre collector and 260 mm rear wheels. New Stiga SA 55 OHV engine. Also available with 300 mm big rear wheels together with B&S 625 series XVS or Honda GCV 160 OHC Autochoke engine. Honda model is fitted with anti-vibrating system too.
TURBO EXCEL 50
Push model with New Stiga SA 45 OHV engine. Also available with B&S 500 series XMH engine. Otherwise as above.
NEW!
NEW!
NEW!
L AW N MOW ER S – T U R BO
TURBO HD 60 MB
Self-propelled machine with speed control and central cutting height adjustment (26-76 mm), easily accessible on the ergonomically designed Gaby handle. ”Dead mans grip” (OPC) and steel brake. Aluminium deck. Ball bearing pro-tyres on aluminium rims, 200 mm front and 250 mm rear. Spacious (80 litre) collector and professional blades with 50.5 cm cutting width. Equipped with Briggs & Stratton
TURBO HD 60 MHV
This top model features the BBC (Blade Brake Clutch) which allows the engine to remain turned on while blade is stopped, for professional use. Aluminium deck. It is self propelled and has a 3 speed control. Cutting width is 50.5 cm. Powered with a Honda GSV 190 engine. Otherwise equipped as the machine to the left.
48
L AW N MOW ER S – T U R BO
TURBO PRO 55 4S
This is the flagship model of the collecting categories. It manages very tall grass and has a cutting width of 53 cm. 4-speed. Central cutting height adjustment to nine levels. Aluminium wheels. The collector has a capacity of 70 litres. Equipped with AVS. The chassis is laterally offset, which facilitates cutting along walls and obstacles. Honda GCV 190 OHC Autochoke engine.
TURBO 55 4S RENTAL
A Combi with aluminium deck. Self-propelled with 4-speed transmission and aluminium wheels. 53 cm cutting width. Central height adjustment to nine levels. Aluminum wheels. 70-litre collector. B&S 700 series DOV Ready Start engine or the new STIGA SA 65 OHV.
TURBO 55 4SE RENTAL
A Turbo 55 as above, but with electric starter. The new STIGA SA 65 OHV ES engine.
L AW N MOW ER S – T U R BO
TURBO 53 S BW INOX PLUS
Same as the Turbo 53 S BW Plus but with stainless steel chassis for less maintenance and higher durability. Equipped with new SA 55 OHV engine.
TURBO 53 4S BW SILENT RENTAL
Featuring the new aerodynamic design, which forces the noise down into the ground. It features an insulating cover and a double-skin grasscatcher, both help to reduce noise level. A 4-speed with high torque and good fuel economy, powered by the new STIGA SA 55 OHV engine. Built on a steel chassis with 51 cm cutting width. Large rear wheels.
TURBO 53 S BW PLUS
Self-propelled machine with 210 mm front wheels and large 300 mm rear wheels with ball bearings. Galvanized deck and 51 cm cutting width. Equipped with a B&S 625 series XVS or the new STIGA SA 55 OHV engine.
TURBO 53 4S BW INOX RENTAL
New Stiga SA 65 OHV engine on a stainless steel chassis of 51 cm cutting width. 4-speed with 60 l collector. Front 210 rear 300 mm wheels on ball bearings. Central cutting height adjustment in 6 positions (30-90 mm). Also equipped with B&S 675 series XVS Ready Start.
50
L AW N MOW ER S – T U R BO
TURBO 48 S BW PLUS
Self-propelled machine with galvanized deck. 210 mm front wheel and large, 300 mm rear wheels with ball bearings. Cutting width 46 cm. Height adjustment to five levels with single point adjustment. 60-litre collector. B&S 500 series XMH engine or the new STIGA SA 45 OHV engine.
TURBO 45 S RENTAL
A self-propelled Turbo with aluminium deck. Cutting width 43 cm. Central height adjustment to nine levels. 50-litre col-lector. B&S 500 series XMH or STIGA SA 45 OHV engine. TURBO 50 S RENTAL
A self-propelled Combi with aluminium deck. Cutting width 48 cm. Central cutting height adjustment to nine levels. 70-litre collecor. B&S 675 series XVS Ready Start or STIGA SA 55 OHV engine.
TURBO 50 SE RENTAL
Same as above, but with electric start and STIGA SA 55 OHV engine.
TURBO PRO 50 S H
Mulching technique, rear discharge and collection. With the Combi machine you can decide on a cutting technique to suit the height of the grass. Cutting width 48 cm. Central cutting height adjustment to nine levels and aluminium wheels. Collector capacity of 70 litres. Self-propelled Honda GCV 160 OHC Autochoke engine.
TURBO 41 EL
Quiet, environmentally friendly and electri-cally powered. Cutting width 39 cm. Central height adjustment between 21 and 60 mm. 45 litre collector. Wheels with ball bearings. 1600 W motor.
TURBO 48 EL S BW
Electrically powered, environmentally friendly and quiet. Selfpropelled with 210 mm front wheels and 300 mm rear wheels with ball bearings. 1800 W motor.
TURBO 39 EL
This is a quiet, environmentally friendly and electrically powered machine for the smaller lawn. Now with folding, telescopic and ergo-nomic handle. Cutting width 37 cm with cen-tral height adjustment between 18 and 60 mm. 40-litre textile/plastic collector and ball bearing wheels. 1500 W motor.
TURBO 45 S H
Self-propelled machine with aluminum 170 mm front and 190 mm rear wheels on ball bearings. Aluminum chassis with 43 cm cuttingh width. Equipped with a Honda GCV 135 OHC engine.
FREECLIP
It is a pleasure mowing with Freeclip. It moves freely thanks to Freeclip technology. It is also quiet with its helical blades. Being made of alu-minium it is extremely strong and durable. The cutting width is 38 cm, and the cutting height can be set steplessly between 15 and 50 mm.
HANDYCLIP
Manual cylinder mower featuring 40 cm cutting width and stepless cutting height adjustment 15-32 mm. A cost-efficient and environmentally friendly alternative for small gardens. 28-litre collector available as an option.
L AW N MOW ER S – T U R BO A N D SM A L L SI Z E
NE
W!
52
Handhelds
SB 425 H
Environmentally friendly brushcutter for all types of garden jobs. Modern four-stroke engine producing 0.8 kW. Extremely quiet and easy to start. Vibration-damped mono handle. Trimmer head with double 2.4 mm lines and grass blade. SB 425 HD
As above, but with bike handle. SB 435 H
Powerful brushcutter with environmentally friendly 4-stroke, 35 cc engine. As well as low emissions, the engine consumes approximately 30% less fuel and is significantly quieter. Vibration-damped mono handle. Supplied with trimmer head, 4-tooth blade and single harness. SB 435 HD
As above, but with bike handle.
When brute force
is required.
Good power-to-weight ratio. Effective anti-vibration.
High torque. This is what distinguishes Stiga’s heavy-duty
brushcutters and make them ideal for semi-professional
use. If environmental concerns rank highly, the low fuel
consumption, low emissions and low sound-level speak in
favour of a four-stroke engine. If higher torque is top
pri-ority, the two stroke engine model is an excellent
alterna-tive. All are built for long and arduous use.
Double harness
Comfort harness
3T brushcutter blade for thick grass.
Saw blade Tap & Go nylon line trimmer for grass. Single harness
4T brushcutter blade for thick grass.
BRUSHCU T T ER S
SB 43 FS
The entirely new back pack model distributes the weight evenly across the user’s back for maximum comfort. Easy start system and 42.7 cc devibrated engine, ideal for mowing steep banks and overgrown slopes. Note the flexible connection between handle and shaft, with incorporated controls.
SB 43 DS
Semi-professional model with bike handle, well balanced with adjustable weight distribution and integrated controls, for long and tedious work. Easy to use with strong and robust 42.7 cc engine. Featuring easy start, interchangeable cutting heads, SB 51 FS
The new back pack design for maximum comfort. Easy start system and 47.1 cc/1.80 kW vibration-damped engine, ideal for long work sessions in tough terrain. Flexible connection between handle and shaft, with incorporated controls, makes it easy to use.
SB 51 DS
Ergonomic bike handle with incorporated controls and adjustable settings for the new padded comfort harness. Suitable for long work sessions with devibrated 47.1 cc petrol engine producing 1.80 kW Easy start system. Interchangeable cutting heads and saw blade included.
NE
W
CO
MP
LET
E
RA
NG
E
SB 51 SOur top-of-the line brush cutter, strong and robust for semi-professional use. Powered by a 47.1 cc petrol engine producing 1.80 kW. Anti-vibration system, easy start and comfortable loop handle with inte-grated controls. Interchangeable cutting heads and the single harness included.
SB 43 S
Semi-professional model, ideal for removing tough scrub and thinning out overgrown bushes. Easy to use with powerful 42.7 cc/1.27 kW engine, easy start and comfortable loop handle with integrated
54
SB 32
A highly versatile and good-value brushcutter with a straight shaft. The trimmer head and the 4-toothed grass blade come as standard. The engine is 30 cc/0.89 kW. A single strap harness is included.
SB 32 D
A highly versatile and good-value brushcutter with a straight shaft. The trimmer head and the 4-toothed grass blade come as standard. The engine is 30 cc/0.89 kW. A single strap harness is included.
BRUSHCU T T ER S
SB 29 S
Stable brush cutter with 25.6 cc/0.8 kW petrol engine with good power-to-weight ratio. Easy start and integrated controls on comfortable loop handle. Comes with Tap & Go trimmer head and 3-tooth brush cutter blade. Single harness included. SB 35 S
Devibrated brush cutter with powerful 32.6 cc/0.97 kW engine and excellent power-to-weight ratio. Easy start and loop handle with integrated controls. Single har-ness, Tap & Go trimmer head and 4-tooth brush cutter blade included.
SB 35 DS
Well-balanced, vibration-damped brush cutter for heavy duty work. Easy start and 32.6 cc/0.97 kW engine. Featuring ergonomic bike handle with integrated controls and double harness with adjustable settings. Tap & Go trimmer head and 4-tooth brush cutter blade included.
SB 29 DS
The same easy start brushcutter which easily reaches under bushes and fences thanks to the rigid, straight shaft. 25.6 cc/ 0.8 kW petrol engine. Controls integrated on the ergonomic bike handle. Tap & Go trimmer head, 3-tooth cutter blade and double harness included.
NE
W
CO
MP
LET
E
RA
NG
PET ROL T R I M M ER S & BRUSHCU T T ER S
ST 425 HJ
Environmentally friendly petrol trimmer with modern four-stroke engine producing 0.8 kW. Extremely quiet and easy to start. Lower emissions and approximately 30 % less fuel consumption than conventional engines. Trimmer head with double lines of 2.4 mm.
ST 27 J
A lighter model with a detachable split shaft, making it easy to transport. Equipped with clutch and very easy to start 26 cc engine. Dual-line head.
SB 27 JD
As SB 32 D, but with 26 cc/0.74 kW and split shaft.
ST 29 S
Well-balanced trimmer with good power-to-weight ratio in new design. Comfortable loop handle with integrated controls. Featuring easy start, and 25.6 cc petrol engine producing 0.80 kW. Comes with 2-line nylon trimmer head, Tap & Go, ideal for grass trimming.
NE
W!
NE
W!
SB 27 J
A highly versatile and good-value brushcutter with a split shaft. The trimmer head and the 3-toothed grass blade come as standard. The engine is 26 cc/0.74 kW. A single strap harness is included.
Blower attachment
Hedge cutter attachment
Pruner saw attachment ATTACHMENTS FOR SB 27 JD, SB 27 J AND ST 27 J.
56
Where grass meets gravel.
The trimmer ”adds the finishing touches” to your garden by removing those irritating
tufts of grass around trees, along paths and fences. The electric trimmer is the tool of
preference for the smaller garden. It is quiet, easy to use and environmentally friendly.
ST 1200 BATTERY
With a 12-volt battery and a trimmer head with a single line, swivels 180 degrees to facilitate edge cutting. Cutting width 24 cm. Adjustable length and handle. Single harness included.
ST 1100
Powerful electric grass trimmer, 1100 W. An impressive 36 cm cut-ting area. The double-line trimmer head has a rapid line feed. Single harness included.
ST 750
Powerful 700 W electric trimmer with motor mounted up by the rear handle. Trimmer head with double lines of 2.4 mm. Front height-adjustable handle.
ST 350 J
Lightweight, joinable grass trimmer with twin grips. Powerful 300 W electric motor and 24 cm working width. Tap & Go trim-mer head with double threads.
ST 500
Versatile with a 500 W electric motor. Note the telescopic handle, adjustable cutting head angle and swivel action for cutting edges. Tap & Go trimmer head with double threads and 30 cm working width.
ST 900 J
Ideal for hobbyists who want an efficient brushcutter with the con-venience of use provided by the 850 W electric motor. Weighing only 5.5 kg, it is perfect for trim-ming around flowerbeds and trees. ESB 1000 J
Powerful but extremely light in weight and easy to use brushcutter. Powered by a 1000 W electric motor. It is supplied with a two-line nylon head that can trim near stones and trees. Strap for comfortable use. Brushcutter blade included.
E L ECT R IC T R I M M ER S
H E DGECU T T ER S
SH 60 PRO
600 W motor with a gearbox that produces powerful cutting torque. Asymmetrical bar ensures reduced vibrations. Extra safety contact breaker so that you can hold the underneath of the hedgecutter and reach higher. Copes with 27 mm branches. The blade measures 60 cm.
SH 54
Powerful hedgecutter with 500 W electric motor. 55 cm laser cut hardened blade that cuts branches up to 18 mm. The ergonomic handle provides maximum comfort. Overload protection.
SH 47
Base model with 45 cm hardened blade. It has a 450 W
Light and easy to handle.
Our hedge trimmers combine ergonomic design with high quality and excellent cutting
performance. Double or rotating handles facilitate your work by providing an ergonomic
cutting position. Double sided reciprocating blades improve manoeuvrability. Effective
anti-vibration dampeners reduces stress on the user’s arms and hands.
SHM 180
Single sided hedge cutter with 75 cm blade, especially developed for tall hedges. Petrol driven 26 cc engine. Easy start, comfortable double grip and blade plate, which helps the cuttings slide off to the side.
SH 160
Petrol driven hedgecutter with 55 cm blade. 26 cc engine. Rear handle that can be adjusted to five different positions for maximum comfort. Hardened precision blade for reduced vibration and cuts branches up to 27 mm.
SHM 170
Petrol driven hedgecutter with 60 cm blade, handling branches up to 28 mm. Hardened precision blade and anti-vibrated 25.6 cc engine for maximum comfort. Easy start. Rear handle adjustable in five positions provides ergonomic working position at all times.
SH 606 R
Electric 600 W motor with stable handle and 50 cm blade for 24 mm branches and rotating handle (180°) to make sidecutting easier.
SH 505
Electric 450 W motor with stable handle and 50 cm blade, coping with branches up to 24 mm.
58
You define the purpose.
We provide the tools.
Feel how it sits in your hand! See how easy it is to tension the chain or replace the air filter! Start
it and experience how well we have succeeded in damping the vibrations! The harder you work,
the more important it is to have good tools. Stiga, as always, combines innovative technology
and excellent power with low weight and minimal impact on the individual and the environment.
This includes our chainsaw range, which for the sake of simplicity is divided into three categories:
Electric saws
Hobby saws for domestic use, ideal for home carpentry and low-scale wood cutting.
General-purpose saws
User-friendly utility saws for farmer work. Ideal for wood cutting, garden work, lighter forestry, etc. Well-balanced with low kick-back. Equipped with primer and electronic ignition for easy starting. Added safety for the inexperienced.
Chainsaws for semi-professional use
Petrol powered chain saws for forestry and other specialized applications such as pruning. Well balanced with an excellent power-to-weight ratio. Special attention given to vibration damping. Air filters easy to clean and replace.
