Caterpillar Parts Manuals include illustrations of

the groups or assemblies which make up the

machine. These illustrations show the standard

components plus many of the attachments

available for the machine.

The alphabetical index located in the front part of

the book should be used to determine the page

number on which specific illustrations are shown.

Reference to those pages will identify each of the

individual serviceable parts.

Captions

The caption under each illustration identifies the

part number and name of the group or assembly

shown. If more than one illustration is included for

any group, the caption identifies the specific

machine serial numbers to which each illustration

applies. In some cases it is not possible to

determine the specific machine serial numbers to

which different illustrations are applicable. In

those cases the caption identifies the illustration

as “First Type”, “Second Type”, etc. Reference to

the actual group or assembly is necessary in those

cases to determine which illustration should be

used.

Captions provide additional information such as

page numbers where illustrations of sub

assemblies are shown, information regarding

quantities used and other information intended to

assist the user in determining parts needs.

This information indicates the effective serial

number or effective date on which changes

became effective.

Example :

D95.05- : Applicable on and after May 1995

D indicates the nineteen hundreds.

T00.05- : Applicable on and after May 2000

T indicates the two thousands.

Within each illustration is a parts list identifying

each serviceable part in the illustration. When a

part name is indented in this list, it means that

serviceable item is a part of the serviceable item

under which it is indented.

Abbreviations and Symbols

R.H.

Right Hand

Refers to the side of

L.H.

Left Hand

the machine as viewed

from the operator's

compartment.

L

Length

T

Thickness

Z

Number of Gear Teeth

O.D.

Outside Diameter

I.D.

Inside Diameter

O.S.

Over Size

U.S.

Under Size

N/S

Not Serviced

AS

Assembly

NOM

Nominal

Note

Continuing improvement and advancement of

product design may cause changes to your

machine which may not be included in this

publication. Each publication is reviewed and

revised, as required, to update and include these

changes in later editions.

Whenever a question arises regarding your

Caterpillar product, or this publication, please

consult your Caterpillar dealer for the latest

available information.

Abbreviations of Wire Colors

RD :Red

WH :White

OR :Orange

YL :Yellow

PK :Pink

BK :Black

GY :Gray

PU :Purple

BR

:Brown

GN :Green

BU

:Blue

T

:Tan

DK/BU :Dark Blue

DK/GN:Dark Green

LT/BU :Light Blue

LT/GN :Light Green

(3)

PAGE PAGE PAGE

MODEL VIEW

㧫

Counterweight ... 300

㧬

Aftercooler ... 79.01

㧭

Engine Hood ... 276

㧮

Radiator & Oil Cooler ... 78

㧯

Battery ... 118

㧰

Air Cleaner ... 90

㧱

Control Valve ... 550

㧲

Operator Seat ... 680

㧳

Hydraulic Tank ... 357

㧴

Cab ... 616

㧵

Control Lever ... 533

㧶

Fuel Tank ... 112

㧷

Storage Box ... 291

㧸

Swing Bearing ... 306

㧹

Swivel ... 532

㧺

Boom Cylinder ... 386

㧻

Boom ... 728

㧼

Stick Cylinder ... 387

㧽

Stick ... 734

㧾

Bucket Cylinder ... 388

㧿

Link ... 746

㨀

Rod ... 746

㨁

Bucket ... 761

㨂

Track ... 350

㨃

Idler ... 326

㨄

Track Adjuster ... 332

㨋

Track Roller ... 341

㨌

Carrier Roller ... 341

㨍

Final Drive ... 265

㨎

Pump ... 369

㨏

Swing Drive ... 517

㨐

Return Filter ... 358

㨑

Engine ... 11

(4)

QTY. PAGE

DESCRIPTION PART NO. USED NO.

The following chart provides a convenient listing of those items which require occasional replacement during normal operation or maintenance.

REPLACEMENT ITEMS

Belt

ޓAlternator & Air Conditioner

1834494

1

53 Filter

ޓAir Conditioner Filter

2457823

1

705 ޓ

709 ޓAir Filter

ޓޓPrimary Filter Assembly

1421339

1

90.01 ޓޓSecondary Filter Assembly

1421404

1

90.01 ޓCab Air Filter

4 I

1278

1

711 ޓEngine Oil Filter

1R

1808

1

63 ޓFuel Filter

1R

0762

1

107 ޓHydraulic Oil Drain Filter

0937521

1

362 ޓHydraulic Oil Pilot Filter

5 I

8670

1

363 ޓHydraulic Tank Return Filter

1799806

1

365

(5)

Consists of: Page The following chart provides a convenient listing of attachments

with their reference page numbers as a quick reference for parts ordering.

LIST OF ATTACHMENTS

2344620

ADDITIONAL GEAR TRAIN FOR AUXILIARY PUMP ...

3 8 1

2299079

AIR CONDITIONER ...

7 0 1

2403769

AIR PREFILTER ...

9 1

2311771

ALARM, TRAVEL ...

2 4 4

BOOM

2291908

ޓMBOOM, MASS 6.18M ...

7 2 0

2291905

ޓRBOOM, REACH 6.5M ...

7 1 9

2291907

ޓRBOOM, REACH 6.5M (Heavy Duty) ...

7 1 9

BUCKET

ޓEXCAVATION (X)

2392698

ޓޓDB Family 1472MM Wide1.4Cu.M.Adapter Size J400 ...

7 5 1

2392701

ޓޓDB Family 1559MM Wide1.5Cu.M.Adapter Size J400 ...

7 5 1

2298040

ޓޓTB Family 1360MM Wide1.6Cu.M.Adapter Size J460 ...

7 5 4

2298043

ޓޓTB Family 1560MM Wide1.9Cu.M.Adapter Size J460 ...

7 5 5

2392859

ޓޓTB Family 1628MM Wide2.0Cu.M.Adapter Size J460 ...

7 5 4

ޓޓFor Hammer

2298031

ޓޓޓDB Family 1585MM Wide1.5Cu.M.Adapter Size J460 ...

7 5 3

ޓޓFor Quarry

2298028

ޓޓޓDB Family 1500MM Wide1.4Cu.M.Adapter Size J460 ...

7 5 3

ޓMASS EXCAVATION (MX)

2392704

ޓޓDB Family 1538MM Wide1.6Cu.M.Adapter Size J400 ...

7 5 2

2298037

ޓޓDB Family 1780MM Wide1.9Cu.M.Adapter Size J400 ...

7 5 2

BUCKET LINKAGE

2403733

ޓDB FAMILY ...

7 2 6

2403735

ޓTB FAMILY ...

7 2 6

CAB

2299096

ޓSKYLIGHT HATCH CAB ...

6 1 6

2783811

COUNTERWEIGHT (Without Lifting Eye) (KAB1Up, LDR1Up) ...

3 0 4

FILM

2403775

ޓHAMMER (PCK1Up) ...

7 9 2

2403777

ޓHAMMER (RDA1Up) ...

7 9 3

2403773

ޓQUARRY (PCK1Up) ...

7 9 4

2403774

ޓQUARRY (RDA1Up) ...

7 9 5

(6)

Consists of: Page

LIST OF ATTACHMENTS

2477500

FINE SWING LESS ...

4 6 5 . 0 1

FLOORMAT

2405071

ޓBASIC ...

6 6 8

2457794

ޓCOMBINED FUNCTION ...

6 7 0

2405073

ޓSINGLE FUNCTION ...

6 6 9

GUARD

2378754

ޓBOTTOM, HEAVY DUTY (KAB1Up, LDR1Up) ...

2 9 8

1262123

ޓBUCKET CYLINDER ...

4 0 3

1640534

ޓCAB FRONT (Full Net) ...

6 6 0

1640535

ޓCAB FRONT (Half Net) ...

6 6 2

1785549

ޓFOGS ...

6 5 6

1717485

ޓޓCab Front ...

6 5 8

1640497

ޓޓCab Top ...

6 5 7

2670118

ޓSIDE RUBBER BUMPER (KAB1Up, LDR1Up) ...

3 4 0

1348887

ޓSWIVEL (KAB1Up, LDR1Up) ...

2 9 9

ޓTRACK GUIDE

2012772

ޓޓFull Length (KAB1Up) ...

3 3 5

1893860

ޓޓFull Length (LDR1Up) ...

3 3 6

2012773

ޓޓTrack End Guide (KAB1Up) ...

3 3 7

2012774

ޓޓTrack End Guide (LDR1Up) ...

3 3 8

2555870

HAND CONTROL PATTERN CHANGER (4 Ways) ...

4 6 5

2457949

HEATER & DEFROSTER ...

7 0 1

HYDRAULIC SYSTEMS, AUXILIARY

ޓBOOM LINE GROUPS

ޓޓMBoom (6.18M)

2373197

ޓޓޓDrain Lines ...

4 3 9

2373195

ޓޓޓHigh Pressure Lines ...

4 1 6

2373196

ޓޓޓMedium Pressure Lines ...

4 2 6

ޓޓRBoom (6.5M)

2373193

ޓޓޓDrain Lines ...

4 3 8

2373191

ޓޓޓHigh Pressure Lines ...

4 1 4

2373192

ޓޓޓMedium Pressure Lines ...

4 2 4

ޓSTICK LINE GROUPS

ޓޓM2.15TB Stick & R2.15TB Stick

2536610

ޓޓޓDrain Lines ...

4 4 8

2536607

ޓޓޓHigh Pressure Lines ...

4 2 2

2536608

ޓޓޓMedium Pressure Lines ...

4 3 6

(7)

Consists of: Page

LIST OF ATTACHMENTS

ޓޓM2.55TB Stick

2536606

ޓޓޓDrain Lines ...

4 4 6

2536603

ޓޓޓHigh Pressure Lines ...

4 2 1

2536604

ޓޓޓMedium Pressure Lines ...

4 3 4

ޓޓR2.8DB Stick

2536602

ޓޓޓDrain Lines ...

4 4 4

2536599

ޓޓޓHigh Pressure Lines ...

4 2 0

2536600

ޓޓޓMedium Pressure Lines ...

4 3 2

ޓޓR3.2DB Stick

2536496

ޓޓޓDrain Lines ...

4 4 2

2536611

ޓޓޓHigh Pressure Lines ...

4 1 9

2623147

ޓޓޓMedium Pressure Lines ...

4 3 0

ޓޓR3.9DB Stick

2536597

ޓޓޓDrain Lines ...

4 4 0

2536594

ޓޓޓHigh Pressure Lines ...

4 1 8

2536595

ޓޓޓMedium Pressure Lines ...

4 2 8

ޓTOOL CONTROL

ޓޓAdditional Circuit

2551927

ޓޓޓDrain Circuit ...

5 1 5 . 0 1

2398641

ޓޓޓHammer Return Filter Circuit ...

4 6 5

ޓޓCombined Function

2555768

ޓޓޓ2 Pump ...

4 6 3

2555770

ޓޓޓ2 Pump (Medium Pressure) ...

4 6 4

ޓޓSingle Function

2555767

ޓޓޓ1 Pump ...

4 6 2

2555769

ޓޓޓ2 Pump ...

4 6 2

2597707

JOYSTICK ...

5 3 3

LIGHT

ޓCAB WORKING (Time Delay)

2381628

ޓޓFor Use With Cab Guard ...

2 4 8

2381627

ޓޓWithout Cab Guard ...

2 4 6

2346500

LUNCH BOX COVER ...

6 4 1

2277581

MACHINE SECURITY SYSTEM ...

6 5 0

OPTIONAL SEAT

2405064

ޓKAB 86/E4P SEAT (With Seat Heater) ...

6 8 0

2405056

ޓKAB E1P SEAT (Vinyl) ...

6 9 0

2405060

ޓHEADREST (For KAB E1P Vinyl Seat) ...

6 9 9

2405037

(8)

Consists of: Page

LIST OF ATTACHMENTS

Product Link Japan

2753674

ޓCONTROL ARRANGEMENT ...

2 1 0

2783573

ޓCOVER (For Air Prefilter) ...

2 8 9

RADIO

2510540

ޓAM ...

6 5 2

2510536

ޓAM/FM ...

6 5 3

1613750

RAIN PROTECTOR, CAB FRONT ...

6 5 5

1013083

SIDEBAR PROTECTOR ...

7 6 9

SIDECUTTER

1122481

ޓDB FAMILY ...

7 6 8

7Y2148

ޓTB FAMILY ...

7 6 8

2510542

START SWITCH PANEL ...

1 7 6

STARTING, COLD WEATHER

2403770

ޓFILM (32WR Hydraulic Oil Package) ...

7 9 6

2753748

ޓSTARTING AID ...

1 8 3

STICK

ޓFOR THE MASS (6.18M) BOOM ONLY

2373223

ޓޓM2.15TB Stick (Auxiliary) ...

7 2 5

2373219

ޓޓM2.55TB Stick (Auxiliary) ...

7 2 4

ޓFOR THE REACH (6.5M) BOOM ONLY

2373215

ޓޓR2.15TB Stick (Auxiliary) ...

7 2 4

2373211

ޓޓR2.8DB Stick (Auxiliary) ...

7 2 3

2403732

ޓޓR2.8DB Stick (Auxiliary/Heavy Duty) ...

7 2 3

2291912

ޓޓR3.2DB Stick ...

7 2 1

2373207

ޓޓR3.2DB Stick (Auxiliary) ...

7 2 2

2291917

ޓޓR3.2DB Stick (Auxiliary/Heavy Duty) ...

7 2 2

2373203

ޓޓR3.9DB Stick (Auxiliary) ...

7 2 1

1613751

SUN VISOR ...

6 5 4

TIP

ޓADAPTER SIZE J400

8E0837

ޓޓAbrasion, Heavy Duty ...

7 7 2

1270716

ޓޓLong ...

7 7 0

6Y5472

ޓޓLong, Heavy Duty ...

7 7 0

8E0838

ޓޓPenetration ...

7 7 2

8E0840

ޓޓSharpCenter ...

7 7 3

8E0839

ޓޓSharpCorner ...

7 7 3

1270715

ޓޓShort ...

7 7 1

8E0836

ޓޓWide ...

7 7 1

(9)

Consists of: Page

LIST OF ATTACHMENTS

ޓADAPTER SIZE J460

8E3758

ޓޓAbrasion, Heavy Duty ...

7 7 6

9N4562

ޓޓLong ...

7 7 4

9N4563

ޓޓLong, Heavy Duty ...

7 7 4

9N4564

ޓޓPenetration ...

7 7 6

9N4566

ޓޓSharpCenter ...

7 7 7

9N4565

ޓޓSharpCorner ...

7 7 7

9N4561

ޓޓShort ...

7 7 5

9N4560

ޓޓWide ...

7 7 5

1762676

TOOL KIT ...

7 7 8

TRACK

ޓDOUBLE GROUSER

2609453

ޓޓ600MM (KAB1Up, PCK1Up) ...

3 5 3

2609452

ޓޓ600MM (LDR1Up, RDA1Up) ...

3 5 3

2609451

ޓޓ700MM (KAB1Up, PCK1Up) ...

3 5 4

2153087

ޓޓ700MM (LDR1Up, RDA1Up) ...

3 5 4

ޓTRIPLE GROUSER

2164026

ޓޓ600MM (KAB1Up, PCK1Up) ...

3 5 0

2164027

ޓޓ600MM (LDR1Up, RDA1Up) ...

3 5 1

2609577

ޓޓ700MM (KAB1Up, PCK1Up) ...

3 5 1

2410985

ޓޓ700MM (LDR1Up, RDA1Up) ...

3 5 0

2609456

ޓޓ800MM (KAB1Up, PCK1Up) ...

3 5 2

2609454

ޓޓ800MM (LDR1Up, RDA1Up) ...

3 5 2

2299086

WIPER, LOWER WINDSHIELD ...

6 4 3

(10)

Name Page Name Page

INDEX

A

ACCUMULATOR GP ... 382

ACTUATOR GP - PISTON PUMP... 380

ADJUSTER GP - BUCKET ... 766

ADJUSTER KIT - LOWER SLIDE ... 689

ADJUSTER KIT - UPPER SLIDE ... 686

ADJUSTMENT GP - HYDRAULIC TRACK ... 332

AIR CLEANER AR ... 91

AIR CLEANER GP ... 90

92 AIR CONDITIONER & MOUNTING GP... 702

AIR CONDITIONER GP... 701 704 708 ALARM GP ... 153 ALARM GP - TRAVEL... 244 ALTERNATOR GP - CHARGING ... 222 ARM AS - WIPER ... 639 ARMREST GP ... 675 678

B

BATTERY & WIRING GP... 118

BATTERY & WIRING GP - COLD WEATH ... 184

BLOCK GP - HYDRAULIC... 366

BOOM AR ... 720

BOOM AR - 1 PIECE LONG... 719

BOOM GP ... 728

BOX & MTG GP - STORAGE ... 291

BOX GP - STORAGE ... 292

BRACKET KIT - CONSOLE... 687

BUCKET & ADJUSTER GP... 756

BUCKET AR ... 751

BUCKET AS - EXCAVATION ... 761

763 BUCKET AS - MASS EXCAVATION... 762

BUMPER GP - SIDE... 339

C

CAB GP ...616 CAB GP (BASIC) ...618 CAB GP - EXTERIOR...622 CAB GP - INTERIOR ...620 CABLE AS ...136 186 CAMSHAFT GP ...25 COMPRESSOR GP - REFRIGERANT ...718

CONDENSER & MTG GP - REFRIGERANT ...716

CONDENSER GP - REFRIGERANT ...717

CONSOLE GP ...672

676 CONSOLE GP - OPERATOR ...671

CONTROL & MTG GP - ELECTRONIC ...209

CONTROL & MTG GP - ENGINE ELEK ...212

CONTROL & MTG GP - JOYSTICK...533

CONTROL AR...210

CONTROL AR - AUXILIARY...462

CONTROL GP ...650

CONTROL GP - ELECTRONIC ...208

CONTROL GP - HYDRAULIC ...543

CONTROL GP - PILOT OPERATED HYD...536

540 COOLER GP - ENGINE OIL ...72

COUNTERWEIGHT GP ...300 COUPLING GP - PUMP...370 COVER AS...285 287.01 289.01 641 COVER GP ...288 625 COVER GP - CYLINDER BLOCK ...22

COVER GP - FLYWHEEL HOUSING...48

COVER GP - FRONT HOUSING ...41

COVER GP - VALVE MECHANISM ...39

CRANKSHAFT GP...23

CYLINDER & LINES GP - BOOM ...383

(11)

Name Page Name Page

INDEX

CYLINDER & SEAL GP - BOOM... 386

CYLINDER & SEAL GP - BUCKET... 388

CYLINDER & SEAL GP - STICK... 387

CYLINDER BLOCK AS ... 20 CYLINDER BLOCK GP ... 18 CYLINDER GP - BOOM ... 390 CYLINDER GP - BUCKET ... 394 CYLINDER GP - STICK ... 392 CYLINDER HEAD AS ... 30 CYLINDER HEAD GP... 27

D

DAMPER & PULLEY GP ... 49

DOOR AS ... 284 DOOR GP - CAB ... 628 DOOR GP - HOOD ... 282 DRIVE GP - ACCESSORY ... 381 DRIVE GP - FAN... 59 DRIVE GP - SWING ... 517 DUCT GP - AIR ... 710

E

ELBOW GP - AIR INLET... 87

ELECTRONICS GP ... 207

ENGINE AR... 11

ENGINE AR - CORE... 16

F

FAN GP - SUCTION ... 80

FASTENER GP - CYLINDER HEAD ... 32

FASTENER GP - DAMPER & PULLEY... 54

FASTENER GP - FRONT HOUSING... 42

FASTENER GP - SWING & FINAL DR ... 268

FASTENER GP - VALVE COVER ... 55

FENDER & COVER GP ... 294

FILM GP ... 792

FILTER AR ... 465

FILTER GP... 108

FILTER GP - ENGINE OIL ... 62

FILTER GP - HYDRAULIC ... 362 367 FINAL DRIVE GP ...264 FLOORMAT ...668 FLYWHEEL GP ...50 FRAME AS - UNDERCARRIAGE ...322 FRAME GP - UPPER ...318 FUMES DISPOSAL GP ...66

G

GAUGE AS ...361

GAUGE GP - OIL LEVEL (DIPSTICK)...68

GEAR & BEARING GP - SWING ...306

GEAR GP - FRONT ...44

GUARD AR - OVERHEAD ...656

GUARD GP - BOTTOM ...296

GUARD GP - CYLINDER ...403

GUARD GP - FRONT WINDOW ...658

GUARD GP - OVERHEAD ...657

GUARD GP - SWIVEL...299

GUARD GP - TRACK GUIDE...334

GUARD GP - TRAVEL MOTOR ...348

H

HANDHOLD GP ...295 HARNESS AS...130 146 156 162 174 180 196 204 206 258 HATCH AS ...637 HATCH GP ...636 HEAD GP - PUMP ...378 HEADREST AS ...699

HEATER & MTG GP - CAB...706

(12)

Name Page Name Page

INDEX

HEATER GP - STARTING AID... 229

HOOD & GUARD GP ... 270

HOOD AS - ENGINE ... 281 HOOD GP ... 287 HOOD GP - ENGINE ... 280 HORN GP - ELECTRIC ... 663 HOUSING GP - FLYWHEEL... 46 HOUSING GP - FRONT ... 40

I

IDLER GP - FRONT... 326 INJECTOR GP - FUEL ... 102

K

KNOB AS ... 537

L

LAMP GP - FLOOD ... 254 LEVER AS ... 626 674 LIFTING GP - ENGINE... 34 LIGHTING GP - BOOM ... 250 LIGHTING GP - CAB ... 246 LIGHTING GP - CHASSIS... 245

LINES & CONTROL GP - FRONT ... 492

LINES & CONTROL GP - REAR ... 496

LINES GP - AIR ... 86

LINES GP - AIR CONDITIONER ... 712

LINES GP - AUXILIARY HYDRAULIC... 414

LINES GP - BOOM... 404

LINES GP - BOOM CYLINDER ... 398

490 LINES GP - BUCKET CYLINDER... 401

LINES GP - COOLING ... 82

LINES GP - DRAIN ... 97

438 515.01 LINES GP - ENGINE OIL ... 64

LINES GP - FRONT... 500

LINES GP - GREASE...743

LINES GP - HEATER ...714

LINES GP - HYDRAULIC OIL COOLER ...458

LINES GP - OIL DRAIN...71

LINES GP - PILOT ...466

LINES GP - PUMP ...456

LINES GP - STICK ...408

LINES GP - STICK CYLINDER ...400

LINES GP - SWING MOTOR ...516

LINES GP - TRAVEL MOTOR...450

LINES GP - TURBOCHARGER OIL...65

LINES GP - TURBOCHARGER WATER ...76

LINES GP - WATER ...75 LINK AS - TRACK ...355 LINKAGE AR - BUCKET ...726 LINKAGE GP - BUCKET...746 LITERATURE GP ...698

M

MANIFOLD GP - EXHAUST...85

MIRROR GP - REAR VIEW ...665

MONITOR & MTG GP - OPERATOR ...648

MONITOR GP - OPERATOR ...649

MOTOR GP - TRAVEL ...527.01 MOTOR & MTG GP - SWING...520

MOTOR & MTG GP - TRAVEL...525

MOTOR AS - WINDOW WIPER...640

MOTOR GP - SWING ...521

MOTOR GP - TRAVEL ...526

MOUNTING GP ...211

624 MOUNTING GP - ENGINE ...60

MOUNTING GP - ENGINE OIL FILTER ...70

MOUNTING GP - GREASE GUN ...290

MOUNTING GP - PLATFORM ...666

MOUNTING GP - VALVE ...547

MUFFLER GP ...94

P

PAN GP - OIL...57

(13)

Name Page Name Page

INDEX

PISTON & ROD GP... 26

PLATE & FILM GP... 780

PLATFORM GP - OPERATOR... 667

PLUG GP... 580

PLUG GP - CONNECTOR ... 230

PLUG GP - ENGINE... 58

PLUG GP - WATER LINES ... 84

PROTECTOR GP - SIDEBAR... 769

PULLEY GP... 52

PUMP & MTG GP - MAIN HYDRAULIC ... 369

PUMP GP - ENGINE OIL ... 61

PUMP GP - FUEL INJECTION ... 100

PUMP GP - FUEL PRIMING... 110

PUMP GP - MAIN HYDRAULIC... 372

PUMP GP - PISTON... 376

PUMP GP - PISTON & GEAR ... 371

PUMP GP - UNIT INJECTOR HYD ... 98

PUMP GP - WATER... 73

R

RADIATOR & HYD OIL COOLER GP... 78

RADIO GP - AM... 652

RADIO GP - AM/FM ... 653

ROCKER ARM GP ... 37

ROLLER AR - TRACK & CARRIER... 341

ROLLER GP - TRACK CARRIER ... 345

ROLLER GP - TRACK - DOUBLE FLANGE ... 347

ROLLER GP - TRACK - SINGLE FLANGE ... 346

ROTATING GP - PUMP ... 530

S

SCREEN GP ... 360 SEAL GP - CRANKSHAFT ... 24 SEAT BELT GP... 696 SEAT GP ... 680 690 SEAT KIT ... 683 695 SENSOR GP - ENGINE ... 231 SENSOR GP - PRESSURE ... 234 242 SENSOR GP - SPEED...239 SENSOR GP - TEMPERATURE ...228 232 SHEET AS ...286 SIDECUTTER GP ...768 SPRING GP - RECOIL ...333 SPROCKET GP - NONSEGMENTED...263

STARTING AID GP - ETHER ...187.01 STARTING AR - COLD WEATHER ...183

STARTING MOTOR GP - ELECTRIC ...213

STICK AR...721 STICK AR - HOE...721 STICK GP - HOE ...734 SUPPORT AS ...286.08 287.01 SUPPORT GP - SEAT...679 693 SUPPORT KIT - SEAT ...694

SUPPORT KIT - TILT...684

SUSPENSION GP - SEAT ...685

SUSPENSION KIT - SEAT ...688

SWITCH AS ...262 SWITCH AS - DISCONNECT ...168 SWITCH AS - MAGNETIC ...169 225 SWITCH AS - PRESSURE...262.01 SWITCH AS - ROLLER ...262 SWITCH AS - ROTARY...182 SWITCH GP - START ...181 SWIVEL GP ...532

T

TANK & FILTER GP - HYDRAULIC ...358

TANK & LINES GP - HYDRAULIC ...454

TANK & MTG GP - FUEL...112

TANK & MTG GP - HYDRAULIC...357

TANK GP - FUEL ...113

TIMER AS ...257

TIP GP ...773 777

(14)

Name Page Name Page

INDEX

TIP GP - ABRASION ... 772 776 TIP GP - LONG... 770 774 TIP GP - PENETRATION ... 772 776 TIP GP - SHORT ... 771 775 TIP GP - WIDE... 771 775 TOOL AR... 778 TOOL GP ... 779 TRACK GP ... 350 TURBOCHARGER GP ... 88

V

VALVE & MOUNTING GP ... 548

VALVE AR - 4 WAY ... 465 VALVE AR - SWING... 465.01 VALVE AS - BALL ... 613 VALVE GP ... 571 VALVE GP - CHECK... 609 VALVE GP - CONTROL ... 554 564 573 VALVE GP - CUSHION CROSSOVER RLF... 601.01 VALVE GP - FLOW CONTROL & RELIEF ... 576

VALVE GP - FUEL BYPASS... 109

VALVE GP - MAIN CONTROL ... 550

VALVE GP - PILOT ... 534

538 546 582 589 VALVE GP - PILOT RELIEF ... 561

579 588 VALVE GP - PRESS REDUCING SOL ... 591

VALVE GP - PRESSURE COMPENSATOR ...531

VALVE GP - PRESSURE REDUCING...598

VALVE GP - RELIEF...524 529 552 560 572 577 606 VALVE GP - SELECTOR...593 VALVE GP - SHUTTLE...610 VALVE GP - SOLENOID ...570 600 602 VALVE GP - TRACTION CONTROL ...528

VALVE MECHANISM GP ...35

VISOR GP - PROTECTION - RAIN ...655

VISOR GP - SUN ...654

W

WASHER GP - WINDOW...646 WINDOW GP ...632 635 WINDOW GP - CAB ...634 WINDOW GP - DOOR ...630

WIPER & WASHER GP - WINDOW...644

WIPER AR - WINDOW ...643 WIPER GP - WINDOW...638 WIRING GP...189 200 205 WIRING GP - CAB ...138 198 WIRING GP - CONSOLE ...159

WIRING GP - ELECTRONIC CONTROL ...226

WIRING GP - FINE SWING ...172

WIRING GP - HEATER ...224

WIRING GP - LOWER WIPER ...188

(15)

Consists of : Page

ENGINE ARRANGEMENT

MUFFLER GP...

ENGINE AR...

H 9 1 4 3 3 E 0 2

2331230 ENGINE AR

(16)

Consists of :

Page

ENGINE ARRANGEMENT

ENGINE ARCORE...

BASIC ENGINE

COVER GPCYLINDER BLOCK ...

COVER GPFLYWHEEL HOUSING...

COVER GPFRONT HOUSING ...

COVER GPVALVE MECHANISM ...

DAMPER & PULLEY GP ...

FASTENER GPDAMPER & PULLEY ...

FASTENER GPFRONT HOUSING ...

FASTENER GPVALVE COVER...

FLYWHEEL GP...

HOUSING GPFLYWHEEL ...

LIFTING GPENGINE ...

PAN GPOIL...

PLUG GPENGINE ...

PULLEY GP...

SEAL GPCRANKSHAFT ...

H 9 0 8 0 1 E 0 3

2358136 ENGINE AR (1/3)

Part of 2331230Page11

(17)

Consists of :

Page

ENGINE ARRANGEMENT

LUBRICATION SYSTEM

FILTER GPENGINE OIL ...

FUMES DISPOSAL GP ...

GAUGE GPOIL LEVEL (DIPSTICK) ...

LINES GPENGINE OIL...

LINES GPTURBOCHARGER OIL ...

COOLING SYSTEM

LINES GPTURBOCHARGER WATER ...

LINES GPWATER...

PLUG GPWATER LINES ...

PUMP GPWATER...

AIR INLET AND EXHAUST SYSTEM

ELBOW GPAIR INLET...

MANIFOLD GPEXHAUST ...

FUEL SYSTEM

LINES GPFUEL ...

H 9 0 8 0 2 E 0 3

2358136 ENGINE AR (2/3)

(18)

Consists of :

Page

ELECTRICAL AND STARTING SYSTEM

ALTERNATOR GPCHARGING ...

CONTROL & MTG GPENGINE ELEK ...

HEATER GPSTARTING AID ...

PLUG GPCONNECTOR...

SENSOR GPENGINE...

SENSOR GPSPEED ...

STARTING MOTOR GPELECTRIC ...

WIRING GPELECTRONIC CONTROL ...

WIRING GPHEATER ...

OPERATOR STATION

COMPRESSOR GPREFRIGERANT ...

H 9 0 8 0 3 E 0 3

2358136 ENGINE AR (3/3)

(19)

(20)

Consists of : Page

BASIC ENGINE

CAMSHAFT GP...

CRANKSHAFT GP ...

CYLINDER BLOCK GP ...

CYLINDER HEAD GP...

FASTENER GPCYLINDER HEAD ...

GEAR GPFRONT ...

HOUSING GPFRONT ...

PISTON & ROD GP...

VALVE MECHANISM GP ...

LUBRICATION SYSTEM

PUMP GPENGINE OIL...

COOLING SYSTEM

COOLER GPENGINE OIL ...

H 9 0 6 8 7 E 0 0

2364285 ENGINE ARCORE (1/2)

(21)

Consists of :

Page

ENGINE ARRANGEMENT

AIR INLET AND EXHAUST SYSTEM

TURBOCHARGER GP ...

FUEL SYSTEM

PUMP GPFUEL INJECTION ...

PUMP GPUNIT INJECTOR HYD...

ELECTRICAL AND STARTING SYSTEM

ELECTRONICS GPENGINE RATINGS

H 9 0 6 8 8 E 0 0

2364285 ENGINE ARCORE (2/2)

(22)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME 5 PLUG 9 SLEEVE ) SEALORING (ID=7.14mm) ; BLOCK GP 8 DOWEL 0 DOWEL

Y㧙SEE SEPARATE ILLUSTRATION

H 9 0 5 9 0 E 0 8

1613406 CYLINDER BLOCK GP

(23)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME

BASIC ENGINE

SEAL

LINER

; BLOCK AS

H 9 0 5 9 1 E 0 0

2201952 CYLINDER BLOCK GP

(24)

H 9 0 5 9 6 E 0 0

2213248 CYLINDER BLOCK AS

(25)

BASIC ENGINE

. PLUG $ PLUG ( PLUG BOLT (L=160mm) BEARING BEARING CAP BEARING : WASHER H 9 0 5 9 6 E 0 0

2213248 CYLINDER BLOCK AS

(26)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME COVER GASKET BREATHER AS ' BOLT (L=160mm) 8 BOLT (L=50mm) 8 BOLT (L=25mm) ( SEALORING (ID=78.74mm) / WASHER H 8 8 4 6 8 E 0 2

2023301 COVER GPCYLINDER BLOCK

(27)

BASIC ENGINE

BEARING CRANKSHAFT AS $ ޓKEY 9 ޓGEAR (Z=50) ; ޓSLEEVE PLATE H 9 0 6 0 1 E 0 3

1646148 CRANKSHAFT GP

(28)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME BOLT AS 4 SEAL SEALORING SEAL GP SEAL GP H 8 8 4 6 9 E 0 4

1783899 SEAL GPCRANKSHAFT

(29)

BASIC ENGINE

PLATE CAMSHAFT AS $ ޓKEY ޓGEAR (Z=100) 8 BOLT (L=25mm) H 9 0 5 6 3 E 0 0

2420674 CAMSHAFT GP

(30)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME BEARING ROD AS ޓBEARING ޓBOLT PIN RING CROWN AS RING TUBE AS RING SKIRT 8 BOLT (L=25mm) : RING H 9 0 6 3 2 E 0 0

2651400 PISTON & ROD GP

(31)

BASIC ENGINE

# PLUG

GASKET AS

; HEAD GP

H 9 0 6 0 2 E 0 0

2420672 CYLINDER HEAD GP

(32)

H 9 0 6 1 0 E 0 0

2528439 CYLINDER HEAD GP

(33)

BASIC ENGINE

9 LOCK # LOCK GUIDE SEAL PLUG AS 5 ޓPLUG ޓSEALORING (ID=11.89mm) PLUG AS 5 ޓPLUG ޓSEALORING SPRING SPRING RETAINER SEAT VALVE (INTAKE) VALVE (EXHAUST) RETAINER SPRING SPRING SEAT GUIDE SEAL ; HEAD AS PLUG AS - ޓSEALORING (ID=16.36mm) 5 ޓPLUG 6 PLUG

H 9 0 6 1 0 E 0 0

2528439 CYLINDER HEAD GP

(34)

H 9 0 6 2 2 E 0 0

2528438 CYLINDER HEAD AS

(35)

BASIC ENGINE

8 PLUG / PLUG INSERT (EXHAUST) SLEEVE INSERT (INLET) % SEALORING (ID=31.47mm) H 9 0 6 2 2 E 0 0

2528438 CYLINDER HEAD AS

(36)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME ; FASTENER GP

% BOLT (L=150mm)

/ WASHER

H 9 0 6 1 4 E 0 0

2134363 FASTENER GPCYLINDER HEAD

(37)

BASIC ENGINE

BOLT

: WASHER

H 8 8 6 1 3 E 0 2

1670171 FASTENER GPCYLINDER HEAD

(38)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME PLATE PLATE 2 WASHER 8 BOLT (L=35mm) H 8 8 4 7 5 E 0 1

1913063 LIFTING GPENGINE

(39)

BASIC ENGINE

GUIDE ROD LIFTER AS ; MECHANISM GP BRIDGE BRIDGE

H 9 0 6 3 5 E 0 0

2420447 VALVE MECHANISM GP

(40)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME SHAFT AS ( ޓPLUG SPRING STAND STAND STAND ; ARM GP (EXHAUST) ; ARM GP (INLET) 2 WASHER 6 BOLT (L=110mm)

H 9 0 6 3 9 E 0 0

2128926 VALVE MECHANISM GP

(41)

BASIC ENGINE

ARM AS SCREW ; NUT H 8 8 6 1 6 E 0 3

2139320 ROCKER ARM GP

(42)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME SCREW ARM AS ; NUT H 9 0 6 4 1 E 0 0

2420329 ROCKER ARM GP

(43)

BASIC ENGINE

COVER GP ً ޓSEAL̖(23dm) CAP AS ( ޓSEALORING (ID=53.57mm) SLEEVE COVER SEAL AS

ً㧙ORDER BY THE DECIMETER

H 9 0 5 9 3 E 0 0

2588724 COVER GPVALVE MECHANISM

(44)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME HOUSING 8 BOLT (L=50mm) 8 BOLT (L=20mm) / WASHER $ 7 GASKET MAKER B㧙USE AS REQUIRED H 9 0 3 5 7 E 0 0

2453260 HOUSING GPFRONT

(45)

BASIC ENGINE

: STUD % COVER 6 WASHER GASKET SEALORING (ID=47.22mm) % NUT 8 BOLT (L=30mm) 6 BOLT (L=60mm) COVER AS ޓWASHER ޓSTUD H 9 0 6 0 7 E 0 1

2113285 COVER GPFRONT HOUSING

(46)

NOTE No. PART No. QTY PART NAME

NOTE No. PART No. QTY PART NAME 2 WASHER 8 BOLT (L=80mm) 9 COVER SEAL 8 NUT H 7 0 2 5 3 E 0 2

1181727 COVER GPFRONT HOUSING

8 BOLT (L=70mm)

2 WASHER

H 9 0 3 3 5 E 0 1

1164556 FASTENER GPFRONT HOUSING

(47)

(48)

H 9 0 3 4 6 E 0 2

2051321 GEAR GPFRONT

(49)

BASIC ENGINE

PLATE PLATE SHAFT GEAR AS ޓBEARING 8 BOLT (L=45mm) BOLT (L=30mm) H 9 0 3 4 6 E 0 2

2051321 GEAR GPFRONT

(50)

H 9 0 6 2 3 E 0 0

2293568 HOUSING GPFLYWHEEL

(51)

BASIC ENGINE

% COVER HOUSING SEALORING (ID=47.22mm) - PLUG 2 SEALORING (ID=29.74mm) 2 SEALORING (ID=10.52mm) 2 WASHER 8 BOLT (L=40mm) 8 BOLT (L=40mm) . SEALORING (ID=16.36mm) / WASHER 5 PLUG 5 PLUG $ 7 GASKET MAKER B㧙USE AS REQUIRED H 9 0 6 2 3 E 0 0

2293568 HOUSING GPFLYWHEEL

(52)

NOTE No. PART No. QTY PART NAME ; GASKET 5 BOLT (L=44mm) & WASHER 0 COVER H 9 0 5 8 4 E 0 1

1275728 COVER GPFLYWHEEL HOUSING

(53)

BASIC ENGINE

9 WASHER DAMPER AS PULLEY 6 BOLT (L=60mm) H 9 0 6 0 8 E 0 0

1654557 DAMPER & PULLEY GP

(54)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME FLYWHEEL AS 0 GEAR (Z=113) : BOLT (L=45mm) 2 WASHER H 9 0 6 2 1 E 0 0

1023596 FLYWHEEL GP

(55)

(56)

H 9 0 8 0 5 E 0 0

2417605 PULLEY GP

(57)

BASIC ENGINE

SUPPORT TIGHTENER PULLEY AS BRACKET BELT ' PLATE 8 BOLT (L=35mm) 8 WASHER 8 BOLT (L=40mm) 6 BOLT (L=80mm) / WASHER H 9 0 8 0 5 E 0 0

2417605 PULLEY GP

(58)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME SPACER

8 BOLT (L=50mm)

H 9 0 6 1 5 E 0 0

2180859 FASTENER GPDAMPER & PULLEY

(59)

BASIC ENGINE

BOLT (L=40mm)

6 WASHER

H 9 0 6 1 9 E 0 0

2367315 FASTENER GPVALVE COVER

(60)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME SPRING

6 BOLT (L=60mm)

0 WASHER

H 9 0 6 2 0 E 0 0

2588728 FASTENER GPVALVE COVER

(61)

BASIC ENGINE

$ SEALANT 8 VALVE SWITCH AS ޓPIN ޓRECEPTACLE KIT ޓ(INCLUDES RECEPTACLE AS ޓޓ& WEDGE) SEALORING (ID=23.47mm) SEAL PAN AS - SEALORING (ID=16.36mm) BOLT (L=20mm) PLUG AS 6 ޓPLUG ޓPLUG KIT

ޓ(INCLUDES PLUG AS & WEDGE)

5 PLUG

B㧙USE AS REQUIRED

H 9 0 6 3 0 E 0 3

1870472 PAN GPOIL

(62)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME PLUG AS

5 ޓPLUG

8 ޓSEALORING (ID=11.89mm)

& SEALORING (ID=23.47mm)

. SEALORING (ID=16.36mm) 5 PLUG 5 PLUG H 9 0 6 4 5 E 0 5

1693105 PLUG GPENGINE

(63)

BASIC ENGINE

SHAFT SEAL HOUSING $ BEARING SPACER 8 RING RING H 8 0 5 0 1 E 0 4

1373750 DRIVE GPFAN

(64)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME WASHER MOUNT MOUNT SUPPORT AS MOUNT MOUNT BRACKET AS BRACKET BRACKET AS BRACKET AS : BOLT (L=40mm) : BOLT (L=70mm) : BOLT (L=160mm) 6 WASHER 6 WASHER 6 BOLT (L=45mm) : WASHER H 9 4 8 4 2 E 0 3

2396474 MOUNTING GPENGINE

(65)

LUBRICATION SYSTEM

PUMP GP ޓPUMP AS ޓGEAR AS 8 WASHER 8 BOLT (L=100mm) H 8 8 6 2 8 E 0 4

1958098 PUMP GPENGINE OIL

(66)

H 9 0 6 4 4 E 0 9

1870474 FILTER GPENGINE OIL

(67)

LUBRICATION SYSTEM

4 FILTER AS % VALVE % CAP SPRING COVER ADAPTER ELBOW BASE AS 2 ޓSTUD GASKET CONNECTOR SEALORING (ID=8.92mm) SEALORING (ID=23.52mm) HOSE AS HOSE AS / SEALORING (ID=19.18mm) , SEALORING (ID=8.92mm) 2 SEALORING (ID=29.74mm) 2 PLUG 8 SEALORING (ID=100.97mm) 8 BOLT (L=35mm) 8 CONNECTOR % VALVE / WASHER 5 PLUG 5 PLUG : SEALORING (ID=29.74mm) 2 STUD H 9 0 6 4 4 E 0 9

1870474 FILTER GPENGINE OIL

(68)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME GASKET ELBOW TUBE AS SEALORING (ID=23.47mm) BOLT (L=25mm) 2 SEALORING (ID=28.24mm) 8 BOLT (L=25mm) 6 BOLT (L=90mm) / WASHER H 9 0 6 5 0 E 0 4

2026603 LINES GPENGINE OIL

(69)

LUBRICATION SYSTEM

HOSE AS TUBE AS CONNECTOR AS 8 ޓCONNECTOR 8 ޓSEALORING (ID=11.89mm) . ޓSEALORING (ID=9.25mm) ELBOW AS . ޓSEALORING (ID=9.25mm) . ޓSEALORING (ID=16.36mm) 2 SEALORING (ID=21.82mm) 8 BOLT (L=25mm) / WASHER H 9 0 6 5 6 E 0 5

1654465 LINES GPTURBOCHARGER OIL

(70)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME 2 CLAMP HOSE BRACKET 2 CLIP 2 NUT 8 BOLT (L=20mm) 8 WASHER 8 BOLT (L=20mm) / WASHER H 8 8 4 9 7 E 0 1

1961829 FUMES DISPOSAL GP

(71)

(72)

H 9 0 8 0 6 E 0 0

2421586 GAUGE GPOIL LEVEL (DIPSTICK)

(73)

LUBRICATION SYSTEM

BRACKET AS TUBE AS GAUGE BRACKET AS 2 WASHER 8 CLIP 8 WASHER 8 BOLT (L=20mm) 6 BOLT (L=20mm) H 9 0 8 0 6 E 0 0

2421586 GAUGE GPOIL LEVEL (DIPSTICK)

(74)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME PLATE SUPPORT AS & CLIP : WASHER 6 WASHER 6 NUT 6 BOLT (L=25mm) 6 BOLT (L=40mm) 6 BOLT (L=30mm) 6 BOLT (L=35mm) H 8 9 5 4 6 E 0 2

(75)

LUBRICATION SYSTEM

CLAMP

' 2 HOSE̖(27cm)

E㧙ORDER BY THE CENTIMETER

H 8 9 5 4 8 E 0 1

(76)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME CORE AS

GASKET

H 9 0 6 5 8 E 0 4

1883826 COOLER GPENGINE OIL

(77)

COOLING SYSTEM

; PUMP GP / SEALORING (ID=12.29mm) , SEALORING (ID=50.39mm) 6 BOLT (L=90mm)

H 9 0 6 6 7 E 0 4

2027674 PUMP GPWATER

(78)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME GASKET COVER 8 BOLT (L=50mm) / WASHER PUMP AS ޓHOUSING ޓSHAFT AS ޓPULLEY ޓIMPELLER ޓSEAL AS 5 PLUG - SEALORING (ID=16.36mm) H 8 8 5 9 4 E 0 0

2194452 PUMP GPWATER

(79)

COOLING SYSTEM

REGULATOR CAP HOSE HOUSING AS 5 ޓSEAL 6 CLAMP GASKET VALVE 5 WASHER $ BUSHING 6 BOLT (L=90mm) PLUG AS 5 ޓPLUG - ޓSEALORING (ID=16.36mm) H 9 0 6 5 1 E 0 0

2488835 LINES GPWATER

(80)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME TEE HOSE AS HOSE AS TEE - SEALORING (ID=16.36mm) 8 SEALORING (ID=16.36mm) / CONNECTOR 6 ADAPTER 5 PLUG H 9 0 6 4 9 E 0 0

2440989 LINES GPTURBOCHARGER WATER

(81)

(82)

H 9 3 0 8 2 E 0 6

2302896 RADIATOR & HYD OIL COOLER GP

2653553Page79.01

(83)

COOLING SYSTEM

+ STRAP 6 CLAMP CLIP CLAMP BAND HOSE HOSE SUPPORT AS SEAL SEAL TANK AS ޓCAP AS ޓCAP AS SEAL SEAL SEAL ; RADIATOR GP : BOLT (L=60mm) 6 WASHER 6 BOLT (L=25mm) 6 WASHER & GROMMET ' ; HOSE̖(56cm) 6 BOLT (L=40mm) & 2 SEAL̖(0.1m)

D㧙ORDER BY THE METER E㧙ORDER BY THE CENTIMETER

Y㧙SEE SEPARATE ILLUSTRATION H 9 3 0 8 2 E 0 6

2302896 RADIATOR & HYD OIL COOLER GP

(84)

H 9 3 0 8 3 E 0 1

2653553 RADIATOR & HYD OIL COOLER GP

(85)

COOLING SYSTEM

2 SLEEVE 2 BUSHING 6 VALVE CAP AS CLIP CORE AS (RADIATOR)

CORE AS (OIL COOLER)

AFTERCOOLER AS FRAME AS BRACKET AS BRACKET AS PLATE AS ISOLATOR SEAL SEAL SEAL SHROUD AS : WASHER : WASHER 6 BOLT (L=20mm) 6 BOLT (L=30mm) 6 BOLT (L=90mm) 6 BOLT (L=25mm) 6 WASHER 6 BOLT (L=35mm) 6 BOLT (L=120mm) ' ; HOSE̖(176cm) ' ; HOSE̖(21cm)

H 9 3 0 8 3 E 0 1

2653553 RADIATOR & HYD OIL COOLER GP

(86)

H 9 3 2 1 9 E 0 5

2302899 FAN GPSUCTION

1373750Page59

(87)

COOLING SYSTEM

; DRIVE GP LOCKWASHER ADAPTER SUPPORT AS BRACE SUPPORT AS SUPPORT AS MOTOR GP SEAL SUPPORT AS SPIDER AS GUARD AS SUPPORT AS BRACE BOLT (L=100mm) / SEALORING (ID=104.37mm) 2 WASHER : WASHER : BOLT (L=40mm) : WASHER 6 WASHER 6 NUT 6 BOLT (L=20mm) 6 BOLT (L=30mm) 6 BOLT (L=45mm) 6 BOLT (L=50mm) 6 BOLT (L=35mm) 6 WASHER 6 NUT 6 BOLT (L=35mm) 6 BOLT (L=35mm)

H 9 3 2 1 9 E 0 5

2302899 FAN GPSUCTION

1373750Page59

(88)

H 9 1 4 6 1 E 0 3

2302898 LINES GPCOOLING

(89)

COOLING SYSTEM

CLAMP HOSE HOSE PIPE AS BRACKET HOSE HOSE PIPE AS 6 WASHER 6 BOLT (L=25mm) SEAL H 9 1 4 6 1 E 0 3

2302898 LINES GPCOOLING

S/N KAB 100175, LDR 100244, PCK 100173, RDA 100209

(90)

H 9 3 9 6 0 E 0 4

2302898 LINES GPCOOLING

(91)

COOLING SYSTEM

CLAMP HOSE HOSE BRACKET HOSE SEAL PIPE AS PIPE AS HOSE 6 WASHER 6 BOLT (L=25mm) H 9 3 9 6 0 E 0 4

2302898 LINES GPCOOLING

(92)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME PLUG

6 PLUG

H 9 0 6 5 9 E 0 2

2054013 PLUG GPWATER LINES

(93)

AIR INLET AND EXHAUST SYSTEM

' LOCKNUT GASKET MANIFOLD MANIFOLD MANIFOLD STUD 2 SPACER 8 WASHER 6 STUD H 8 8 5 4 6 E 0 5

1654444 MANIFOLD GPEXHAUST

(94)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME . FITTING 6 CLAMP 6 CLAMP INDICATOR AS HOSE HOSE H 8 9 5 6 1 E 0 4

2396406 LINES GPAIR

(95)

AIR INLET AND EXHAUST SYSTEM

STUD ELBOW $ 7 GASKET MAKER ' WASHER % BOLT (L=55mm) 6 BOLT (L=60mm) / WASHER B㧙USE AS REQUIRED H 9 0 6 6 6 E 0 0

2421934 ELBOW GPAIR INLET

(96)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME 2 GASKET

' LOCKNUT

; TURBOCHARGER GP

H 9 0 8 0 7 E 0 0

2588337 TURBOCHARGER GP

(97)

AIR INLET AND EXHAUST SYSTEM

2 CLAMP AS / ޓNUT 2 ELBOW CLAMP AS / ޓNUT CLAMP COVER CARTRIDGE GP ' HOSE̖(28cm)

H 9 0 8 0 8 E 0 0

2507700 TURBOCHARGER GP

(98)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME ; CLEANER GP

6 WASHER

6 BOLT (L=20mm)

H 9 4 8 4 3 E 0 2

2396407 AIR CLEANER GP

2552914Page90.01

(99)

AIR INLET AND EXHAUST SYSTEM

. FITTING 4 CAP VALVE (VACUATOR) ELEMENT AS ELEMENT AS SEALORING (ID=301.00mm) FILM COVER AS ޓLATCH H 9 4 8 4 4 E 0 3

2552914 AIR CLEANER GP

(100)

(101)

Consists of :

Page

AIR INLET AND EXHAUST SYSTEM

HOOD GP ...

AIR CLEANER GP...

H 8 9 8 3 3 E 0 1

2403769 AIR CLEANER AR

Precleaner

An Attachment

(102)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME 6 CLAMP PRECLEANER AS ޓCLAMP HOSE ; CLEANER GP 2 WASHER ; CLAMP 6 NUT PIPE AS 6 BOLT (L=50mm) 6 BOLT (L=25mm)

H 9 2 3 2 4 E 0 3

2396411 AIR CLEANER GP

Precleaner

Part of 2403769Page91 2666190Page93

(103)

AIR INLET AND EXHAUST SYSTEM

ELEMENT AS ELEMENT AS COVER AS 4 CAP . FITTING FILM H 9 4 8 4 5 E 0 1

2666190 AIR CLEANER GP

An Attachment

(104)

H 9 2 4 0 0 E 0 1

2724759 MUFFLER GP

(105)

AIR INLET AND EXHAUST SYSTEM

PIPE AS PLATE PLATE MUFFLER AS SUPPORT AS BRACKET AS UBOLT CLAMP AS 2 WASHER : WASHER WASHER ; GASKET 6 WASHER 6 BOLT (L=25mm) 6 BOLT (L=45mm) 6 BOLT (L=50mm) 6 BOLT (L=35mm) 6 WASHER 6 NUT 6 BOLT (L=35mm) 0 CLAMP NUT BOLT (L=60mm) PIPE AS ' CLAMP H 9 2 4 0 0 E 0 1

2724759 MUFFLER GP

(106)

(107)

AIR INLET AND EXHAUST SYSTEM

2 CLAMP - STRAP CLIP PIPE AS 6 WASHER 6 BOLT (L=16mm) ' 2 HOSE̖(113cm)

H 8 9 6 6 3 E 0 1

(108)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME TUBE AS CONNECTOR AS 8 ޓCONNECTOR ޓSEALORING (ID=11.89mm) ޓSEALORING (OD=12.83mm) TUBE AS SEALORING (ID=104.00mm) ; PUMP GP ELBOW PLUG AS 5 ޓPLUG ޓSEALORING (ID=11.89mm) ' DOWEL 2 ELBOW 8 SEALORING (ID=19.18mm) 8 SEALORING (ID=23.47mm) 8 WASHER 8 BOLT (L=70mm)

H 9 0 6 6 5 E 0 0

2588745 PUMP GPUNIT INJECTOR HYD

(109)

NOTE No. PART No. QTY PART NAME

FUEL SYSTEM

PUMP GP

SEALORING (ID=31.47mm)

H 9 0 3 8 1 E 0 0

2544357 PUMP GPUNIT INJECTOR HYD

(110)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME ; PUMP GP

H 9 0 6 6 4 E 0 0

2673362 PUMP GPFUEL INJECTION

(111)

FUEL SYSTEM

BOLT

; INJECTOR GP

H 9 0 6 6 3 E 0 0

2673361 PUMP GPFUEL INJECTION

(112)

NOTE No. PART No. QTY PART NAME NOTE No. PART No. QTY PART NAME RING RING SEAL RING SEALORING (ID=23.39mm) SEALORING (ID=31.34mm) H 9 0 6 6 1 E 0 0

2673360 INJECTOR GPFUEL

(113)

(114)

H 9 0 8 0 4 E 0 0

2313039 LINES GPFUEL

(115)

FUEL SYSTEM

SPACER 8 BOLT (L=40mm) HOSE AS TUBE AS TUBE AS REGULATOR GP ELBOW CONNECTOR CONNECTOR AS , ޓSEALORING (ID=11.89mm) 8 ޓSEALORING (OD=12.83mm) 8 ޓCONNECTOR ELBOW AS , ޓSEALORING (ID=11.89mm) 8 ޓSEALORING (OD=12.83mm) 8 ޓELBOW CLIP 4 CONNECTOR , SEALORING (ID=11.89mm) - SEALORING (ID=16.36mm) 2 CLIP 8 WASHER H 9 0 8 0 4 E 0 0
