Cabling solutions for networks

Cables, modules, applications and data centers

Passion for electricity

Intelligent system and switch components

I/O components, routers and switch cabinet components

System overview

Cat.6A, Cat.6

?

There is some confusion on the market as to the

designations and the specifications of the Cat.6

standard, as two valid standards apply to it.

The specifications of the TIA/EIA (American standard)

are characterized by less strict values and do not

distin-guish between the cabling section and the component.

Everything is referred to as a category (Cat.) here.

On the other hand, the ISO/IEC

(internatio-nal standard) distinguishes between cabling

sections (Class) and the component (Cat.),

and the specifications are more demanding.

In addition, the two standards differ in the spelling

of Cat.6A (TIA/EIA) and Cat.6

or Class E

(ISO/IEC).

The performance of a Cat.6

channel link according

to EIA/TIA is not comparable with the performance

of a Class E

channel link according to ISO/IEC! If

you want to make sure as a user that you obtain

optimum cabling according to Class E

, then you

must use the components of the Cat.6

specification

according to ISO/IEC.

Category 6

Independent certification

The connection system complies with the

international Cat.6

standard and has been tested

and certified by an independent accredited test

laboratory according to ISO/IEC 11801 Ed.2.2 5

(FPDAM 2009-04), TIA/EIA-568-C.2 (2009-08) and

IEC 60603-7-51 Ed.1 (12/2008).

The requirements for Class E

are also

complied with in the permanent and channel

link according to the standard specified above.

Installation cables

Category 6

, Category 7, Category 7

GC1500 pro22 Cat.7A S/FTP 4P LSHF-FR AWG22 S/FTP

• Applicable standards: EN 50173-1:2011-09; ISO/IEC 11801 Ed.2.2:2011-09; EN50288-4-1; IEC61156-5 and IEC61156-7 • Flame retardance: IEC60332-1; IEC60332-3-24; IEC 60754-2 and

IEC 30034

GC1200 pro22 Cat.7A S/FTP LSHF-FR AWG22 S/FTP

• Applicable standards: EN 50173-1:2011-09; ISO/IEC 11801 Ed.2.2:2011-09; IEC 61156-5 and IEC61156-7

GC1000 pro23 Cat.7 S/FTP 4P LSHF-FR AWG23 S/FTP

• Applicable standards: EN 50173-1:2011-09; ISO/IEC 11801 Ed.2.2:2011-09; EN50288-41; IEC61156-5 and IEC61156-7

GC1000 plus23 Cat.7 S/FTP LSHF AWG23 S/FTP

• Applicable standards: EN 50173-1:2011-09; ISO/IEC 11801 Ed.2.2:2011-09; IEC61156-5 and IEC61156-7

GC600 F1 23 Cat.6A U/FTP 4P LSHF AWG22 S/FTP

• Applicable standards: EN 50173; ISO/IEC 11801 and EIA/TIA 568A

C6

modul 180° and C6

modul K 180°

C6Amodul 180° and C6Amodul K 180

• Modular termination unit RJ45

• Certified GHMT Cat.6A re-embedded PVP

• Component testing for Cat.6A to ISO/IEC 11801 Ed.2.2:2011-06,

DIN EN 50173-1:2011-09, TIA/EIA-568-C.2 (2009-08) and IEC 60603-7-51 Ed.1 (12/2008), certified to GHMT

• Compliance with class EA up to 500 MHz to ISO/IEC 11801

Ed.2.2:2011-06, class EA EN 50173-1:2011-09

• Tested: component up to 600 MHz, link up to 800 MHz • For 10 GBit Ethernet (IEEE 802.3an)

• Suitable for Power over Ethernet (PoE, PoE plus and UPoE) • Easy to install connection of data lines AWG 26/1 to 22/1 (solid

wire) and AWG 26/7 to 22/7 (stranded wire) to insulation displacement connectors (IDC)

• Intelligent cable management in stuffer cap - also suitable for heavily twisted cables

• Conductor assignment to T568A and T568B is directly printed on the stuffer cap

• Solid, one-piece and reusable module housing refined with zinc die-casting

• Mounting without special tools; strain relief directly snapped on to stuffer cap

• Mounting version:

• Modul cut-out, cable feed 180°, 270° or 90° • Keystone cut-out, cable fee 180°, 270° or 90°

Assembly scheme C6

modul 180° and C6

modul K 180°

1

Equipped and unequipped applications

Assignation des brins

PIN No. T568A T568B 1 WH-GN WH-OG 2 GN OG 3 WH-OG WH-GN 4 BU BU 5 WH-BU WH-BU 6 OG GN 7 WH-BN WH-BN 8 BN BN 2 3 4

REGplus IP20 C6Amodul 180° & C6Amodul 270°

19” Module frame 1RU aluminum/black unequipped

Modul IP44SG surface mounting housing unequipped

• Lockable flush-mounted IP44 outlet, with two keyswith lock with instantaneous locking action (identical locks and keys)

• Cover closes completely, even when patch cables are plugged in

• For two individual modules in Modul design (not suitable for OpDAT modules)

• Ball-throw proof according to DIN 18032 • Can be operated with standard patch cables • Clearly visible nomenclature panel

• Bottom section of housing can be turned 180°, with cable feed possible from top and bottom

• With space to install the required spare cable lengths • Gray

Keystone wall outlet AP | surface mounting unequipped

• Very compact 1-port surface-mounted termination unit for one individual Keystone module

• Module plug direction 90° downwards • Strain relief with cable tie at the module

• Label window for identification labels (labels included in the delivery)

• Integrated dust protection shutter

• Cover parts in color similar to pure white RAL 9010, glossy surface

• Not suitable for 180° couplers (anti-bend sleeves for patch cables usually too long)

• Variants: 1 port, 2 ports 5 4 3 6 8 7 2 1

Patch cable Cat. C6A AWG26

• Fully shielded Cat.6A patch cable AWG 26/7

• Two shielded RJ45 connectors; 1:1 assignment • Class EA Link up to 500 MHz to ISO/IEC 11801

Ed.2.2:2011-06, DIN EN 50173-1:2011-09 • Suitable for 10 GBit Ethernet (IEEE 802.3an)

• Molded snagless anti-bend sleeve -coated in cable color with integrated lock hook protection

• Halogen-free

• Colors may differ slightly due to different protection lots

Equipped and unequipped applications

Keystone wall outlet for 6/12 port surface mounting

• Very compact 6/12-port surface-mounted termination unit for six/twelve individual Keystone modules • Module plug direction 90° downwards • Strain relief with cable tie at the module

• Cover parts in color similar to pure white RAL 9010, glossy surface

• With shielded modules suitable for 6 modules

C6A RJ45 field plug pro 180°

• Cat.6A class EA RJ45 plug to be assembled in the field (fully shielded and multi-port capable)

• Compliance with class EA to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09 • 10 GBit suitable according to IEEE 802.3an • Straight (180°) cable feed

• Easy assembly - connection without special tools • Wire connection: stranded wire AWG 27/7 to 22/7, wire

diameter from 0.46 to 0.76 mm

• Wire connection: solid wire AWG 26/1 to 22/1, wire diameter from 0.4 to 0.64 mm

C6A Module 270°

• Surface-mount or flush-mount termination unit with C6A

modul 270°

• Certified to GHMT Cat.6A re-embedded PVP

• Component testing for Cat.6A to ISO/IEC 11801

E.2.2:2011-06, DIN EN 50173-1:2011-09, TIA/EIA-568-C.2 (2009-08) and IEC 60603-7-51 Ed.1 (12/2008), certified to GHMT

• Compliance with class E up to 500 MHz to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09

• Tested: component up to 600 MHz, link up to 800 MHz for 10 GBit Ethernet (IEEE 802.3an)

• Suitable for Power over Ethernet (PoE, PoE plus and UPoE) • Connection of data lines AWG 26/1 to 22/1 (solid wire)

and AWG 26/7 to 22/7 (stranded wire) to insulation dis-placement connectors (IDC)

• Module plug direction 45° downwards • Strain relief snapped on to stuffer cap

• With label window for enclosed identification labels • Label sheet 209 x 294 mm

• Integrated dust protection covers (also colored) • Cover parts in pure white RAL 9010, structured surface

with matt finish

C6A RJ45 field plug pro 360°

• Cat.6A class EA RJ45 plug to be assembled in the field (fully shielded and multi-port capable)

• Compliance with class EA to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09 • 10 GBit suitable according to IEEE 802.3an • Variable (360°) cable feed, freely selectable • Easy assembly - connection without special tools • wire connection: stranded wire AWG 27/7 to 22/7, wire

diameter from 0.46 to 0.76 mm

• wire connection: solid wire AWG 26/1 to 22/1, wire diameter from 0.4 to 0.64 mm

System overview

Fiber optic

Multimode Singlemode

Standard IEC 11801 OM2 OM3 OM4 OS2

IEC 60793-2-10 A1a.1 60793-2-10 A1a.2 6073-2-10 A1a.3 60793-2-50 B6_a / B6_b ITU-T G.657.A2/B2 Type of fiber 50/125 µm 50/125 µm 50/125 µm 9/125 µm Attentuation 850 nm ≤ 2,7 dB/km ≤ 3,0 dB/km ≤ 3,0 dB/km 1300 nm ≤ 0,8 dB/km ≤ 1,0 dB/km ≤ 1,0 dB/km 1310 nm ≤ 0,38 dB/km 1550 nm ≤ 0,23 dB/km Bandwidth (OFL) 850 nm ≥ 500 MHz.km ≥ 1500 MHz.km ≥ 3500 MHz.km 1300 nm ≥ 500 MHz.km ≥ 500 MHz.km ≥ 500 MHz.km Bandwidth EMB) 850 nm ≥ 2000 MHz.km ≥ 4700 MHz.km

Performance classes fiber optic cable

Fiber performace 10-gigabit transfer

Singlemode OS2 2000 m

Multimode OM1 33 m

Multimode OM2 86 m

Multimode OM3 300 m

Multimode OM4 550 m

OpDAT installation cables

• Universal cable (U-DQ(ZN)BH): Loose tube cable for interior and exterior with 4, 8, 12, 24 or 48 fibers (0.25 mm) • Mini breakout cable (U-VQ(ZN)H): Cable for interior and

exterior, with 4, 12 or 24 wires (0.9 mm)

• Breakout cable (I-V(ZN)HH): Interior cable with 2 cables • All cable jackets LSHF (low-smoke, halogen-free) • Fiber types: OM2, OM3, OM4, OS2. All fibers are bend

insensitive.

OpDAT patch cables & pigtails

• Assembly with all variations of plug types LC, SC and ST. Other plug types on request.

• Fiber types: OM2, OM3, OM4, OS2.

• Patch cable (Duplex, Figure 8) with outer diameter 2.0 x 4.2 mm. Cable jacket LSHF-FR (low-smoke, halogen-free, flame-retardant). Available in different lengths, maximum length 20 m

• Pigtails with compact wire 0.9 mm, length 2 m, primary and secondary coating (0.25 mm / 0.9 mm) same color. Available as individual pigtail or in a set of 12.

• 100% optically inspected for insertion and return loss. Test reports are enclosed.

OpDAT pre-assembled installation cables

• Assembly with all variations of plug types LC, SC and ST. Other plug types on request.

• Three cable versions:

Universal cable: Loose tube cables for interior and exterior with up to 48 fibers (0.25 mm),

Mini breakout cable: Cable for interior and exterior with 4, 12 or 24 wires (0.9 mm)

Breakout cable: Interior cable with 2 cables (2.1 mm) • Fiber types: OM2, OM3, OM4, OS2. All fibers are bend

insensitive.

• Customized manufacture, maximum length 1000 m. • 100% optically inspected for insertion and return loss. Test

reports are enclosed.

OpDAT patch panels

• Fiber optic patch panels for 19 inch technology, 1 rack unit (RU)

• Lightweight aluminum construction • Fitted with pigtails and couplers (screwed)

• Service-friendly mounting through snap-on cover or remo-vable drawer

• Splice trays with pigtails and crimp splice holders prepared ready-to-splic

• Pigtails cleaned and plugged into couplers • Assignment according to color code to IEC 60304 • Available with SC-Duplex, LC-Duplex and ST couplers.

Intelligent system composants

C|Logline stands for intelligent system composants for a highly communicative and

decentralized control in the application and products areas building automation,

measurement and monotoring relays, interface modules, industrial relays and

telecommunication.

Bus modules

Interface modules

Time, measurement and monotoring relays

• CAN-bus I/Os • M-Bus I/Os

Highly communicative and decentralized control

MR-DIO4/2-IP LF-AI8 FRAS 4/21 MOXA EtherDevice Switch 8 Port

KRA-SRA-F10/21 RM3-2W 24 V DC ADU-C12 R274 - 4 changeover contacts (DPST)

ADU-C12

Compact solutions for data centers

The heart of every network is its data center. The type of processed data ranges from simple text

documents up to complex design drawings, from production control systems up to building management

plans. And the requirements in terms of performance and capacity rise exponentially. Networks soon

reach their limits in the light of the extreme large data volumes that must be processed and archived

today so that they must again and again be extended. And in those cases compact, inexpensive and quick

solutions must be provided that use the available space in ideal fashion and reduce immobilization times

to the absolute minimum. The compact solutions from METZ CONNECT in copper (Cat.6A) and FO are

exactly tailored to the demands arising from data centers.

The DataCenterCompactSolution (DCCS) excels not only by its high packing density, its low installation

works and costs (pre-assembled RJ45 and FO plugs) but also by its Plug & Play design. This pre-assembled

and measured system prevents installation errors. With this solution also jammed cable lines are a matter

of the past. This optimizes the transparency and reduces the risk of heat accumulation. The use of DCCS

installation cables leads also to a significant reduction of the thermal load.

The following pages present all those numerous products and systems, which will help you to prepare also

your data center for the next challenges.

DCCS 6 x LC-D Link

• Prefabricated fiber optic link consisting of 2 subassembliesDC-CS2 with 6 LC-D couplers mounted to a 12 fiber mini breakout cable

• Port numbering of the DCCS2 19” subassembly frame remains in place when installing the FO subassemblies

• For 10 GBit Ethernet (IEEE 802.3an)

• The locking levers of patch cords connected to DCCS2 subas-semblies show upwards and are easy to handle at any time • Solid and refined assembly housing

• Cable diameter less than 6,5 mm

• Delivery with serial number and 12 attenuation measurements reports

• Mounting version: DCCS2

• Available in prefabricated, customer specific lengths • Maximum length: 500 m

• Configuration tool in Microsoft Excel available on request • Variants: SM (OS2), SM (OS2 APC), MM (OM4), MM (OM3)

DCCS2 fiber optic MPO link

• Pre-assembled fiber optic link consisting of one MPO plug on each side and a 24-fiber connection cable • For up to 10 GBit Ethernet (IEEE 802.3an)

9 = 12 fibers E9/125 OS2

5 = 12 fibers 50/125 OM3 7 = 12 fibers 50/125 OM4 0010 = 1.0 m 0015 = 1.5 m 0050 = 5.0 m 0100 = 10.0 m 0150 = 15.0 m 0200 = 20.0 m 0995 = 99.5 m 1000 = 100.0 m 5000 = 500.0 m Fiber type A = Polarity, method A B = Polarity, method B C = Polarity, method C Allocation

130D2F

X

MP

E

XXXXX

X

Polarity, method A

Polarity, method B

Polarity, method C

Module

Key up Key Down

A-to-B Patch cord

A-to-B Patch cord

Key up to Key up Position 1 Position 1 Position 12 Position 1 Position 12 Position 1 Module Module

Key down to Key down

Key up to Key up A-to-B Patch cord

Position 12 Position 1 Position 12 Position 1 Position 1 Position 1 Position 12 Position 12

A-to-B Patch cord

Module Position 1 Position 1 Position 1 Position 12 Position 12 Position 12 Position 12 Position 1 Key up to Key down

Key up to Key down Module

Position 12

Key up to Key up

Position 12 Key up Key Down

A-to-B Patch cord

Key up to Key up

Key down to Key down

Key up to Key up

A-to-B Patch cord Key up to Key up

Industrial cabling

IP protected connectors

The Fit-for-All principles

Benefit from maximum flexibility! This range of products does not only offer decisive advantages for your industrial applications but also for their planning, assembly and their daily use. All housings are designed to the protection degree IP67.

Simply select your type of application and your desired material. You may choose between plastic and metal. Same color dot = combination possible.

E-DAT Industry RJ45 plug insert *

E-DAT Industry RJ45 field plug insert *

E-DAT Industry RJ45 coupler insert *

E-DAT Industry RJ45 field jack *

OpDAT Industry SC-RJ/2SC adapter insert *

OpDAT Industry LC-D adapter insert *

OpDAT Industry 2LC plug insert *

Industry IP67 V1 plug

housing * Industry IP67 V1bulkhead *

Industry IP67 V4

plug housing * Industry IP67 V4bulkhead *

Industry IP67 V14

plug housing * Industry IP67 V14bulkhead * Industry IP67 V5

metal plug housing * metal bulkhead *Industry IP67 V5

Modul RJ45 Magnetics

E-DAT Industry USB A coupler insert * OpDAT Industry 2SC

plug insert *

Industry IP67 V1 metal

plug housing * metal bulkhead *Industry IP67 V1

LC-D SFP Transceiver

Ethernet M12

Ethernet M12 round connectors

The Ethernet M12 plug is an industrial plug of the

round plug category; it has a metrical M12 thread

× 1. The METZ CONNECT Ethernet M12 plug series

has been especially designed and compiled for data

transmission systems in industrial environments.

METZ CONNECT offers 2-pair twisted-pair

connectors M12 with D-coding and 4-pair twisted-pair

connectors M12 with X-coding. The 4-pole Ethernet

M12 plug with D-coding offers a transmission ratio

of 100 MBit/s. For higher data transmission ratios up

to some Gigabits (e. g. 10 Gigabit), we offer 8-pole

Ethernet M12 plugs with X-coding.

The rugged Ethernet M12 plugs excel by their

extremely strong mechanical and electrical resistance.

In addition they are resistant against dirt and

humidi-ty once they are plugged in (IP67). This ensures safe

contacts and a trouble-free data transmission.

M12 field plug straight

• M-coded plug based on IEC PAS 61076-2-109 and suitable for field packaging

• 10 GBit suitable according to IEEE 802.3an • Suitable for Power over Ethernet (PoE, PoE

plus and UPoE)

• 8-wire M12 plug for AWG 22 to be assembled in the field

• Connection of AWG 26/7 - 22/7; AWG 24/1 - 22/1 possible

• Solid copper wire diameter from 0.4 to 0.64 mm

• Stranded copper wire diameter from 0.48 to 0.76 mm

• Conductor diameter up to 1.6 mm • Cable jacket from 5.0 to 9.7 mm • Consists of only 2 parts

• Easy assembly - connection without special tools

Telec Belgium – Passion for electricity

Rue des Rivageois 1A 4000 Liège Belgium Phone: +32 (0)4 252 75 73 Fax: +32 (0)4 252 70 14 [email protected] www.telec.be

Telec Luxembourg – Passion for electricity

Rue de Marbourg 19 box 3 9764 Marnach Luxembourg Phone: +352 (0)245 193 21 Fax: +352 (0)245 193 33 [email protected] www.telec.lu

Passion for electricity

Logistics Passion for electricity
