Seed Processing Plant

Y

50 Years of Experience - Your Guarentee

Consultancy based on experience

At Cimbria, we have built up a profound and market leading specialist know-how within development and turn-key solutions. A know-how that has been achieved by intensive research and teamwork with clients from all over the world.

When we design process plants and complete solutions, such particular know-how is used to create a total overview.This results in solutions ensuring that all parts of a plant are co-ordinated in an optimum way - and that the daily operation as well as the subsequent maintenance is as unproblematic as possible.

Global references

More than 50 years of experience with designing plants on the global market is a fundamental part of the consultancy we give our clients in all matters concerning plant improvement.

Together with the thorough knowledge of crop handling, which is one of the Cimbria Unigrain features, this consultancy contributes to a successful project presentation. A well prepared project presentation is the actual foundation of a plant, which, during the daily operation 24 hours a day, is running satisfactorily.

Firm project control

A firm project control contributes to an anchoring of the security and quality that lies in our products and project presentation. From placing the order to expiry of guarantee the responsibility for the project imple-mentation lies with one senior project manager.

K

Grain Care - a Key Concept in Cimbria

•

Rye

Maize

Oats

Paddy Rice

Barley

Wheat

Cleaned Seed for Higher Returns

Ever since man began to cultivate the land it has been known that the sowing of healthy and well developed seed is one of the major pre-requisites for a good crop.

Over the years grain and seed species have been constantly improved and, in recent times, the pro-duction of grain and particularly seed has deve-loped within strict parameters.

The purity of particular strains has been safe-guarded by contract crop production through the seed companies. International regulations and certification agreements ensure that guaranteed quality and standards are maintained.

Buying a Seed Processing Plant is

a Matter of Trust

Unlike the grain and seed trade there is no inter-nationally accepted evaluation basis governing the performance of seed processing plants. Buying and selling these will thus particularly depend upon the establishment of trust between buyer and seller.

It is most important for any buyer to select the right kind of supplier; one able to offer a range of highly developed cleaners, extensive process and turn-key know-how, credibility, integrity and with solid company backing.

G

Garden and Grass Seeds

Background and Research

Ever since the middle of last century, Cimbria process engineers and designers have been working closely with grain and seed trade specialists from all over the world on research in the field of grains and seeds; the outcome being that our production of machinery for processing of grain and seed crops has been keeping the lead in our field of technology. Due to this thorough, persistent work, Cimbria projects are known all over the world for their optimal yield and cleaning capacity, and not least for simple, precise operation. Research and training take place in the complete state of the art seed cleaning plant adjacent to our main production facilities in Denmark, on Cimbria’s 10,000 tons test silo plant.

Operational Cleaners meeting the capacity and quality require-ments guaranteed are a must to you and of vital importance to us.

Garden seed processing plant, Italy

Parsnip

Melon

Chervil

Radishes

Viper’s grass

Carrot

Spinach

Lettuce

Parsley

Dill

Cress

Onion

Leek

Tomato

Chive

Beans

Salad

Alfalfa / Lucerne

Clover

Cocksfoot

Meadow grass

Timothy

C

Legumes and Commercial Seed

Cimbria supplying Your Complete Plant

Cimbria has supplied several thousands of complete seed and grain processing plants for clients all over the world. Cimbria has been in full control of all stages of the installation from initial design to the installation, commissioning, training of local staff and handling over of the complete operational system.

The experience thus gained and our knowledge on processes and system design will, of course, be available for you in your next project.

Seed processing plant, New Zealand

Beet

Coffee bean

Cabbage

Cocoa bean

Cotton seed

Rape seed

Groundnuts (unshelled)

Horsebean

Lin seed

Sunflower seed

Mustard

Peas

Potatoes

Sesame

Poppy

Soya beans

Sorghum (milo)

Vetch

Turnip

Peanuts

Broad beans

Lentil

S

Seed Plant Automation and Ma

All over the world the Seed Industry is moving towards a higher level of industrial production. Advanced technology is applied in order to produce better seed qualities, and to comply with the increasing need for yield and profit. Cimbria is among the leading companies in seed processing plants. Automation and indivi-dual Management Information Systems are integrated parts of a high level concept.

Internal/

External

Connec-tions

Manuals

Service

&

Support

Seed

data

Field

data

Producer

data

Cim

Manag

Inform

Syst

angement Information Systems

PLC

SCADA

System

Video

Inventory

data

Laboratory

data

Intake

data

Cimbria

Seed

Processing

Plant

mbria

gement

mation

S

Range of Seed Processing Machines

Pre-cleaner

Various pre-celaners for cereals, oil seeds, legumes, grass seed, etc., for preconditioning before drying.

Seed dryer

Seed dryers for all kinds of free flowing seed, as well as fluid bed dryers

for non free flowing seed.

De-awner

For removal of sticks, break-up clusters for improving flow and appearance, de-awning of barley.

Fine cleaner

For high quality cleaning (air and thickness) of cereals, oil seeds,

legumes, grass seed, etc.

Indent Cylinder

Cylinder for length grading of cereals, rice and oil seeds, long and

short grain separation.

Rotary Screening Cylinder

Cylinder for thickness calibration of maize, sunflower and other seeds

Gravity separator

Gravity table for separating cereals, oil seeds, grass seed, etc. according to specific weight.

De-stoner

For separation of heavy materials from cereals such as stones, metallic particles, etc.

Maize sheller

Maize (corn) sheller specially designed for gently shelling of husked ear corn optimi-zed for minimum seed breakage.

Seed treater

Chemical treaters for liquid powder or slurry application of seed as well as of coating of seeds.

Dust control system

Dust control system on basis of bag filter, cyclofans, fan and cyclone system, all designed according to plant requirements.

Conveying equipment

Wide range of material handling equipment. Bucket elevators, chain conveyors, belt conveyors, Z elevators, screw conveyors and Q-piping system.

S

F

Cimbria Features,Advantages and Benefits

Features

Advantages and Benefits

Turn-key supplier Only one partner to negotiate with.

One partner responsible for all design and Engineering work.

One project manager as contact person for the client responsible for the entire project implementation.

One partner responsible for electrical- and mechanical commissio-ning. No dispute in split of responsibility.

Total output performance and process responsibility with one com-pany.

Turn-key supplier and State of the art machines and technology for seed processing plants manufactured in-house by the Cimbria Group secures constant high level of standard and development.

PC based automation and process monitoring, control panel and management information system developed and programmed in-house by Cimbria as supplier.

Multi level training facility Training of process operators at Cimbria University secures optimum skill of plant operators for the benefit of the clients.

Full scale operator training facilities available at Cimbria test plant in Denmark and Austria.

Process Engineering Highly skilled mechanical, electrical and process engineers are available for upgrading existing installations to maximize output performance and efficiency of the plant.

Process design consultation Partnership with clients ensures optimum project solution which meets the clients’ requirements and with minimum time of implemen-tation.

After sales service As the world´s largest producer of seed processing machinery Cimbria holds extensive in-house stock of spares and screens.

Efficient electrical-mechanical after sales service minimizing down time and production losses.

R

Cimbria Unigrain – Range of Activity

PORT TERMINALS - SILO PLANTS - FLAT STORE BUILDINGS - STEEL SILOS

• Temperature measurement and registration • Chain conveyor, elevator and belt conveyor • Grain drying and silo

• Process control, operation and temperature control

MALT HOUSE - BREWERY

• Fine cleaning and grading • Sorting by size

• Process operation and control • Malt drying and dosing

SEED - GRASS SEED - GRAIN - VEGETABLE SEED - BEANS

• Fine cleaning and polishing • Sorting by length and thickness • Sorting by colour and weight • Process operation and control

FEED MILLS - PROCESS PLANTS

• Raw material, silos for mixed food and dosing equipment • Hammer mills and pellet press machines

• Dust extraction and filters

• Process control, dosing and mixing

COFFEE PLANTS

• Drying, cleaning and storage • Coffee hulling, grading and sorting • Mixing, weighing and dosing equipment • Process control and operation

RICE AND FLOUR MILLS

• Drying, cleaning and storage • Hulling, polishing and milling • Sorting by size and shape

• Process control, operation and temperature control

VEGETABLE OIL EXTRACTION AND PROCESSING

• Silo, preparation and fine grading

• Process control, operation and laboratory control • Shelling, flaking and pressing
