PORTABLE CONVEYOR SYSTEM

PORTABLE

CONVEYOR

MINIVEYOR

™

_{A WORLD LEADER IN SUPPLYING CONFINED SPACE}

EQUIPMENT TO THE CONSTRUCTION, BUILDING, LANDSCAPING

AND EVEN THE MINING INDUSTRY. OUR AIM IS TO SUPPLY A

CUSTOMER SERVICE OF RELIABILITY AND SATISFACTION.

NEW ZEALAND

INTRODUCTION

Having worked in the building industry for nearly 20 years, we thought there had to be a faster and cheaper way of shifting dirt and hardfill from job sites. After 12 months of investigation and a trip to the Miniveyor™ factory in the UK we have discovered the best solution.

“When you have seen the rest it’s time to choose the best” and so it was with Miniveyor. With an exclusive New Zealand licencing agreement we are recognised as the official New Zealand agent. Whether you need to hire our services for a small job, lease equipment long term or purchase the Miniveyor System we are here to help. We also offer a full maintenance and repair service.

ABOUT MINIVEYOR

The Miniveyor family of portable conveyor systems represents one of the most powerful and flexible solutions for the rapid deployment of a temporary conveyor system. Only 20cm high and capable of lying on the ground, it can be utilised to excavate below ground, through windows or in other confined spaces.

With an aircraft grade aluminium frame and a stainless steel bed, the Miniveyor is built to last. These are the only units in their class that have reversible belts and composite cores to add strength while saving weight.

WE WOULD LOVE TO HAVE THE OPPORTUNITY TO

TALK TO YOU ABOUT THE MINIVEYOR

™

_SYSTEM.

The Miniveyor portable conveyor system was created in the early 1990s to offer a light, portable and flexible conveying solution for confined space working such as underpinning and basement construction projects. The easy-to-operate Miniveyor conveyor is currently being successfully used worldwide in a multitude of applications. With offices in four continents, Miniveyor Products serves a global customer base through a worldwide distribution network.

Miniveyor will move up to 20 tonnes per hour, dependent on material. The use of Miniveyor on a project almost always increases productivity, while reducing manual handling, health and safety incidents. Miniveyors can be loaded by hand and by machine such as an excavator or Bobcat.

The Miniveyor portable conveyor material handling solution will add value to your business. Imagine moving over 10 times the amount of earth than a manual operation.

With the Miniveyor system you can set up the solution in a matter of minutes and complete your job in hours, not days.

ABOUT MINIVEYOR

INNOVATIVE CONSTRUCTION EQUIPMENT FOR CONFINED SPACE WORKING

MINIVEYORS CAN BE LOADED BY HAND,

EXCAVATOR AND BOBCATS. IF YOU CAN

BARROW IT, WE CAN CONVEY IT.

PORTABLE

Miniveyor can be carried into position and set-up in minutes. A composite core sandwiched between stainless steel plates means they are structurally strong, while light and durable. The units stack and lock for easy transport. The units are quick to install – 30m of conveyor can easily be assembled in only 15 minutes.

VERSATILE

Up a flight of stairs and turn 90 degrees, no problem. Run on a 40 degree slope, into a hopper or 100 metres across across a rooftop. In all these applications Miniveyor™ was the solution to difficult excavation or conveying problems.

RUGGED

Miniveyor are built for a tough and demanding environment and are corrosion free with a stainless steel and aluminium construction. The drive motors are sealed to IP65 standard. The impact resistant control box is waterproof and protected by a thermal overload circuit to guard against damage. They couldn’t be built any tougher!

POWERFUL

Miniveyor uses powerful 370 and 550 watt motors mounted inside the end rollers and specifically designed and manufactured for the application. With a high point load movement of 130kg the Miniveyor™ can move anything that is thrown at it.

MODULAR

Modular construction lends itself to customer designed installation. Miniveyor units can be locked together using a clamp kit and three modules can provide an eight metre unsupported span. For larger tonnage, run the units in tandem with a double wide hopper.

SAFE

Every part of the system has been designed with safety in mind. The control box circuit is 24V AC and has a monitored loop safety system to prevent electrical problems. The drive units are contained within the frame offering NO pinch or nip points and the belt edges are protected under guard.

HIRE OPTIONS

Subject to availability, within 24 hours we can offer

a full service rental with an operator and additional

manpower or separate units available for you to hire.

We can accommodate all your conveying requirements.

Please check out our options.

WE ARE YOUR ONE-STOP SHOP - IF YOU NEED

MATERIAL SHIFTED YOU NEED MINIVEYOR

We have a team of six specially trained operators available to help you with your conveying requirements, we are sure to put your mind at ease. Miniveyor has a purpose built pricing app that will enable us to price your job, within one hour of a site visit.

Hire option can be from a single Miniveyor unit to a full scaffold supported system to load trucks with. We can help with any limited access or tight site requirements from digging a pool, or backfilling a retaining wall. From diggers and bobcats to hired manpower. We can provide soil removal or supply aggregate or landscaping and building supplies. With a full supply, install and operator, we can make your job easy.

NEED US TOMORROW, CALL US TODAY!

CONVEYOR HIRE

Look no further - we can get you up and running in with an operator within 15 minutes of arriving on site.

DIGGER HIRE

We have a digger and operator available to help increase productivity even further.

AGGREGATE

We can help supply all landscaping and building supplies.

SELF-HIRE OPTION

WANT TO USE THE MINIVEYORS YOURSELF?

WHY NOT HIRE A CUSTOM TRAILER UNIT FROM US!

Let us know what you have to shift and we will put together a trailer pack for you. We have custom trailer units holding up to 24 metres of conveyors, inclusive of all components, wrapped up and ready for you to drive away.

Flexible length of hire can be from one day, one month or until the job is complete.

DEMONSTRATION AND TRAINING

AVAILABLE, IF NEEDED.

SOIL REMOVAL

Yes, we can even take care of that.

AGGREGATE

We can help supply all landscaping and building supplies.

SCAFFOLD

We supply any required scaffold systems to support the Miniveyors.

WITH OUR EXTENSIVE EXPERIENCE IN

THE CONSTRUCTION INDUSTRY, WE HAVE

A RANGE OF TOOLS FROM DIGGERS TO

BREAKERS TO GET THE JOB DONE.

LEASE

Do you have a large ongoing job or you would like to add

the Miniveyors to your tool kit, without cutting into your

cash flow - talk to us!

We have leasing options from one month to one year. We can create a custom lease package to suit your needs. We also have lease-to-own options available, just ask and we’ll make an appointment to come out to you, to discuss your needs.

INCREASE PRODUCTIVITY AND

REDUCE HEALTH AND SAFETY

INCIDENTS THROUGH MANUAL

HANDLING. MINIVEYOR CAN

BE LOADED BY HAND,

EXCAVATOR AND BOBCATS.

IF YOU CAN BARROW IT

WE CAN CONVEY IT.

NATIONAL SALES

Such a great system, that you will want to own them!

MINIVEYOR NZ HAVE THE SOLE DISTRIBUTION RIGHTS TO SELL HERE

IN NEW ZEALAND, WITH THE FULL BACKING OF MINIVEYOR U.K.

We can design a conveyor package to suit any requirement and we can cost this within 24 hours. Once your order is placed and awaiting shipment, we can even supply you with conveyors from our stock should you need units prior to your order arriving. Need Finance? Miniveyors New Zealand has contacts with reputable finance companies who can help you obtain your finance easily and pain free. If you would like a finance option with your quote, please ask our team.

ASK US ABOUT WORK IN YOUR AREA FOR MINIVEYORS!

With your newly purchased Miniveyor system we can arrange for your contact details to be loaded onto our website for the public to contact you directly at no charge. We can assist you to set up a full Miniveyor service in your region, with this you will have the support of Miniveyor NZ and become a recommended preferred supplier of Miniveyors in your area.

Arrange a time to come in or we can come to you and discuss your options.

M i n i v e y o r • A c c e s s o r i e s

Support Feet Kit

Enables three Miniveyors to be supported from ground level to the

next floor level, using the scaffold tube location hole.

Slave Box

The Slave control Box enables additional Miniveyors to be

connected in-line, whilst stop/start control is from the Control Box.

An additional power supply is required.

Emergency Stop Box

This enables emergency stopping of all connected Miniveyor units

and can be connected at any point in the system. 110V

MVA-020600 230VMVA-021000

Electrical Safety Test Cable

For safety testing of all the 110 Volt Miniveyors and Control Box.

The cable enables connection to electrical safety testing machine

with a 3 pin, 110 volt socket. MVA-02740T

Reversing

Cable

This can be fitted between the control box and the first Miniveyor

and will reverse the direction of all the connected Miniveyors.

110V - MVA-02745R 230V - MVA-01205R

W h e e l s

A set of wheels enables one person to move units by themselves,

particularly useful when collecting them from site.

SERVICING

Belt Adjusting Tool

For adjusting the Miniveyors belt tension, with

the cam adjusters.

MVT-000100

Belt Jointing Machine

A special tool for fitting the stainless steel

fasteners to the end of the belt, we also supply a

large T square for accurately cutting the belt at

90 degrees. Important, the stainless steel

fasteners MVB-011130 are supplied in boxes of

12, suitable for 6 belts.

USING THE SLAVE BOX

This layout shows how the slave boxes work in conjunction with the

control box, in a line of Miniveyors. Miniveyors can be used to move

material over long distances, and we have been asked for installations

of 100 metres and more. With long Miniveyor installations that can

disappear round corners, it may be more convenient and safer if all

the Miniveyors are started from one position and stopped from any

position. A Control Box can start and stop all connected Miniveyors,

and subsequent Slave Boxes can stop all connected Miniveyors.

7

3kW

Inline Control

Box

PARTS & SERVICING

ACCESSORIES

At Miniveyor we hold stock of many components, we can even lend you one of our units, while

yours are being serviced. We can provide full service on units, with a 48 hour turnaround time.

All units are warranted for one year. We guarantee all of our products and components 100%.

We not only have conveyors, we have many accessories too.

M i n i v e y o r • A c c e s s o r i e s

LOADING

Hand Loading Hopper

For two people loading by hand and can be used with 2 x 2 metre side extensions.

Minidigger Hopper

For loading by Minidigger and includes 2 x 2 metre side extensions.

Double Miniveyor Hopper

The double hopper runs two Miniveyors side by side; doubling output.

Side Extensions

If you load with a Minidigger, 40cm deep side

side extensions are essential. extensions for Skid Steer 2.0 metre MVA-070400 loading MVA-070120 3.0 metre MVA-070480

Accessories

- we have developed a range of accessories to make your job easier.

SETTING

UP

6 Metre Kit

A kit to convert 2 x 3 Metre Miniveyors into 1 x 6 metre length. MVA-07300K

Clamp Kit

For linking two x 3 metre Miniveyors together in about 60 seconds. MVA-073010

3kW

Terminator Plug

3kW

6

MINIVEYOR

SUPPORT FEET KIT

(PART NO. MVA-072010)

The Miniveyor Support Feet Kit is an invaluable accessory allowing a user to set up multiple Miniveyor units quickly and simply without the need for tools. The kit consists of three pairs of telescopic legs, mounting tubes, cantilever link and fixed leg support.

DOUBLE HOPPER

The double hopper runs two Miniveyors side-by-side; doubling output.

M i n i v e y o r • A c c e s s o r i e s

LOADING

Hand Loading Hopper

For two people loading by hand and can be used with 2 x 2 metre side extensions.

Minidigger Hopper

For loading by Minidigger and includes 2 x 2 metre side extensions.

Double Miniveyor Hopper

The double hopper runs two Miniveyors side by side; doubling output.

Side Extensions

If you load with a Minidigger, 40cm deep side side extensions are essential. extensions for Skid Steer 2.0 metre MVA-070400 loading MVA-070120 3.0 metre MVA-070480

Accessories

- we have developed a range of accessories to make your job easier.

SETTING

UP

6 Metre Kit

A kit to convert 2 x 3 Metre Miniveyors into 1 x 6 metre length. MVA-07300K

Clamp Kit

For linking two x 3 metre Miniveyors together in about 60 seconds. MVA-073010 3kW Terminator Plug 3kW 6

SIDE EXTENSIONS

If you load with a minidigger, side extensions are essential – there is a range of different sizes and lengths available.

M i n i v e y o r • A c c e s s o r i e s

Support Feet Kit

Enables three Miniveyors to be supported from ground level to the

next floor level, using the scaffold tube location hole.

Slave Box

The Slave control Box enables additional Miniveyors to be

connected in-line, whilst stop/start control is from the Control Box.

An additional power supply is required.

Emergency Stop Box

This enables emergency stopping of all connected Miniveyor units

and can be connected at any point in the system. 110V

MVA-020600 230VMVA-021000

Electrical Safety Test Cable

For safety testing of all the 110 Volt Miniveyors and Control Box.

The cable enables connection to electrical safety testing machine

with a 3 pin, 110 volt socket. MVA-02740T

Reversing

Cable

This can be fitted between the control box and the first Miniveyor

and will reverse the direction of all the connected Miniveyors.

110V - MVA-02745R 230V - MVA-01205R

W h e e l s

A set of wheels enables one person to move units by themselves,

particularly useful when collecting them from site.

SERVICING

Belt Adjusting Tool

For adjusting the Miniveyors belt tension, with

the cam adjusters.

MVT-000100

Belt Jointing Machine

A special tool for fitting the stainless steel

fasteners to the end of the belt, we also supply a

large T square for accurately cutting the belt at

90 degrees. Important, the stainless steel

fasteners MVB-011130 are supplied in boxes of

12, suitable for 6 belts.

USING THE SLAVE BOX

This layout shows how the slave boxes work in conjunction with the

control box, in a line of Miniveyors. Miniveyors can be used to move

material over long distances, and we have been asked for installations

of 100 metres and more. With long Miniveyor installations that can

disappear round corners, it may be more convenient and safer if all

the Miniveyors are started from one position and stopped from any

position. A Control Box can start and stop all connected Miniveyors,

and subsequent Slave Boxes can stop all connected Miniveyors.

7

3kW

Inline Control

Box

NEED US ON SITE?

CALL US TODAY ON

O8OO 744 38

2

Miniveyor New Zealand

PO Box 38 485, Howick, Auckland 2145, New Zealand Tel: 0800 744 382, Cell: 021 494 802
