FIXED CAMERA

SHC-750

Extreme Ultra Low Light Camera

• 1/2"EM-CCD (Electron Multiplying CCD) with 340K pixels • Full-frame motion image in color in extreme low light • Removed noise & ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 450TV lines (Color), 470TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Motion detection • RS-485 remote control • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 12V DC

SHC-740

Ultra Low Light High Resolution Camera • 1/2"Ex-view HAD color CCD with 410K pixels(N), 470K pixels(P) • Removed noise & ghost images with SSNR

• Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 530TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (Turbo) [email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Motion detection, WDR • RS-232C remote control • OSD (On Screen Display) • S/N ratio of 50dB • Dual voltage : 24V AC / 12V DC

SHC-735

Ultra High Resolution WDR Camera • 1/3"Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Built-in SVIV, the latest generation of SV DSP engine • Powerful 128X WDR function : Max. 52dB • Built-in SSNRII, Upgraded Noise Reduction technology • Day & Night with ICR (Infrared Cutfilter Removal) • Unmatched image resolution of 560TV lines (Color) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 8 zones • Highlight BLC with free position • Built-in DIS (Digital Image Stabilizer) • Intelligent MD : 8 areas • RS-485 remote control • Multi-language OSD • S/N ratio of 52dB • Voltage : 12V DC

SHC-730

Low Light High Resolution WDR Camera • 1/3"Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Enhanced WDR function (SVIII) : Max. 52dB • Removed noise & ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 520TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Motion detection • RS-232C remote control • OSD (On Screen Display) • S/N ratio of 50dB • Dual voltage : 24V AC / 12V DC

SHC-721A

Low Light WDR Camera

• 1/3"Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • WDR function (SVIIPLUS) : Wide Dynamic Range • Clear & Crisp image with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 500TV lines (Color), 550TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Motion detection • RS-232C remote control • OSD (On Screen Display) • S/N ratio of 50dB • Dual voltage : 24V AC / 12V DC, 230V AC

SDN-550

High Resolution Day & Night Camera • 1/3"Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Removed noise & ghost images with SSNR

• Day & Night with ICR (Infrared Cut filter Removal) • High resolution of 530TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Unique BLC function : Spotlight BLC

• Motion detection • OSD (On Screen Display) • S/N ratio of 50dB

• Dual voltage : 24V AC, 12V DC, 230V AC

SDC-415

High Resolution Day & Night Camera • 1/3"Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Removed noise & ghost images with SSNR

• Day & Night capability for 24/7 surveillance • High resolution of 530TV lines

• Min. illumination of [email protected] (Normal color mode) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Back light compensation

• Motion detection • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 24V AC, 12V DC, 240V AC

SDC-313B

High Resolution Camera

• 1/3"Interline Transfer CCD with 410K pixels(N), 470K pixels(P) • Removed noise & ghost images with SSNR

• High resolution of 530TV lines • Min. illumination of [email protected] (Color)

[email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Back light compensation

• Motion detection • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 24V AC, 12V DC

SOC-4030

High Resolution Built-in 3X Varifocal Lens Camera • 1/3"Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Removed noise & ghost images with SSNR

• Built-in 3X (f3 ~ 9mm) varifocal lens with auto iris • Quick & easy to install, Stylish design • Day & Night capability for 24/7 surveillance • High resolution of 530TV lines • Min. illumination of [email protected] (Color)

[email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Back light compensation • Motion detection • OSD (On Screen Display) • S/N ratio of 50dB • Dual voltage : 24V AC / 12V DC

SDZ-330

Low Light, WDR 30X Zoom Camera • 1/4"Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Outstanding 30X optical zoom (f3.3 ~ 99mm) &

8X digital zoom (240X total zoom) • Powerful 126X WDR function : Max. 52dB • Removed noise & Ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 520TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : Max. 32 zones • Motion detection • RS-485 remote control • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 12V DC

SDZ-300

High Resolution 30X Zoom Camera • 1/4"Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Powerful 300X zoom (Optical 30X zoom, Digital 10X zoom) • Removed noise & ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 520TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : Max. 32 zones • Built-in DIS (Digital Image Stabilizer)

• Motion detection • Digital flip • RS-485 remote control • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 24V AC / 12V DC

SIR-4150

High Resolution Day & Night IR Camera • 1/3" Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Built-in 4X (f3.8 ~ 9.5mm) varifocal lens with auto iris • Built-in high-performance IR LED, Exceptional night surveillance • Removed noise & ghost images with SSNR

• Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 520TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (LED on)

[email protected](Color) [email protected](Sens-up) • Privacy image masking with free position : 4 zones • Built-in Weather Proof Housing(IP65), Sunshield • Motion detection • RS-485 remote control • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 12V DC

SLA-880

1/2”10X Motorized Zoom Lens • F1.2 Video Type auto Iris • Motorized zoom 8 ~ 80mm, C-mount • Excellent low light performance • Simple to install and adjust

• Compatible with 1/2" and 1/3" CCD cameras

SLA-3580DN

1/3”Day & Night Varifocal Lens • F1.0 DC Type auto Iris

• Varifocal 3.5 ~ 8mm, CS-mount • IR-corrected lens for perfect Day & Night surveillance • Extra low dispersion & Aspherical lens for clearer images • Compact design

SLA-2985D

1/3”Varifocal Lens • F1.2 DC Type auto Iris • Varifocal 2.9 ~ 8.5mm, CS-mount • Excellent low light performance • Simple to install and adjust • High quality, compact design

SLA-2810D

1/3”Varifocal Lens • F1.4 DC Type auto Iris • Varifocal 2.8 ~ 10mm, CS-mount • Excellent low light performance • Simple to install and adjust • High quality, compact design

SLA-550D

1/3”Varifocal Lens • F1.8 DC Type auto Iris • Varifocal 5 ~ 50mm, CS-mount • Excellent low light performance • Simple to install and adjust • High quality, compact design

(3)

DOME CAMERA

MONITOR

SPD-3300

Low Light 30X PTZ Speed Dome Camera

• 1/4"Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Powerful 30X optical zoom (f3.3 ~ 99mm) and 8X digital zoom • Powerful 126X WDR function : Max. 52dB

• Removed noise & ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 520TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : Max. 32 zones • Multi protocols support • Simple installation • Programmable 128 preset positions• Auto surveillance functions • Max. 240˚/sec pan speed and 360˚ continuous rotation • Motion detection • RS-485/422, RS-232C remote control • S/N ratio of 50dB • OSD (On Screen Display) • Voltage : 24V AC

SPD-3000

High Resolution 30X PTZ Speed Dome Camera • 1/4"Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Powerful 30X optical zoom (f3.3 ~ 99mm) and 10X digital zoom • Removed noise & ghost images with SSNR

• Multi protocols support • Simple installation • Programmable 128 preset positions• Auto surveillance functions • Max. 240˚/sec pan speed and 360˚ continuous rotation • Motion detection • RS-485/422, RS-232C remote control • S/N ratio of 50dB • OSD (On Screen Display) • Voltage : 24V AC

SPD-2300

High Resolution 23X PTZ Speed Dome Camera • 1/4"Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Powerful 23X optical zoom (f3.84 ~ 88.4mm) and 10X digital zoom • Removed noise & ghost images with SSNR

• Multi protocols support • Simple installation • Programmable 128 preset positions• Auto surveillance functions • Max. 240˚/sec pan speed and 360˚ continuous rotation • Motion detection • RS-485/422, RS-232C remote control • S/N ratio of 50dB • OSD (On Screen Display) • Voltage : 24V AC

SPD-1000

High Resolution 10X Interior PTZ Dome Camera • 1/4"Interline Transfer color CCD with 410K pixels(N), 470K pixels(P) • Powerful 10X optical zoom (f3.8 ~ 38mm) and 10X digital zoom • Removed noise & ghost images with SSNR

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Multi protocols support • Simple installation • Programmable 128 preset positions• Auto surveillance functions • Motion detection • RS-485 remote control • S/N ratio of 50dB • Multi-Language OSD • Voltage : 12V DC

SVD-4300

High Resolution Vandal-Proof 10X Dome Camera • 1/4"Interline Transfer color CCD with 410K pixels(N), 470K pixels(P) • Built-in 10X (f3.8 ~ 38mm) zoom lens with auto focus • Protection against rain & Wind (IP66)

• Rugged, high impact polycarbonate dome cover and aluminium body • Removed noise & ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 500TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : Max. 32 zones • Two types of installation (Flush or Surface Mount) • Motion detection, Smart zoom • RS-485 remote control • S/N ratio of 50dB • OSD (On Screen Display) • Dual voltage : 24V AC / 12V DC

SVD-4120A

Low Light WDR Vandal-Proof Dome Camera • 1/3" Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Protection against rain & wind (IP66)

• Built-in auto iris varifocal lens 2.5X (f3.8 ~ 9.5mm) / 2.4X (f2.5 ~ 6mm) • Rugged, high impact polycarbonate dome cover and aluminium body • Crystal clear image with SSNR

• Day & Night capability for 24/7 surveillance • High resolution of 500TV lines • Min. illumination of [email protected] (Color)

[email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Additional service monitoring output • Easy adjustment with 3-Dimensional hinge • Two types of installation (Flush or surface mount) • WDR • Motion detection • Dual voltage : 24V AC / 12V DC

SID-560

Ultra High Resolution WDR Dome Camera • 1/3" Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Built-in SVIV, the latest generation of SV DSP engine • Built-in 4X (f3 ~ 12mm) varifocal lens with auto iris • Powerful 128X WDR function : Max. 52dB • Built-in SSNRII, Upgraded Noise Reduction technology • Day & Night with ICR (Infrared Cutfilter Removal) • Unmatched image resolution of 560TV lines (Color) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : 8 zones • Highlight BLC with free position • Built-in DIS (Digital Image Stabilizer) • Easy adjustment with 3-Dimensional hinge

• Intelligent MD : 8 areas • RS-485 remote control • Multi-language OSD • S/N ratio of 52dB • Dual voltage : 24V AC / 12V DC

SID-500

Day & Night 3-Axis 10X Dome Camera • 1/4" Interline Transfer color CCD with 410K pixels(N), 470K pixels(P) • Built-in 10X (f3.8 ~ 38mm) zoom lens with auto iris • Wall mountable with 3-Axis rotating camera construntion • Removed noise & ghost images with SSNR • Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 500TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Privacy image masking with free position : Max. 32 zones • Motion detection, Smart zoom • RS-485 remote control • S/N ratio of 50dB • OSD (On Screen Display) • Dual voltage : 24V AC / 12V DC

SID-450/452

High Resolution 3-Axis Dome Camera • 1/3" Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Built-in 3X (f3 ~ 9mm) varifocal lens with auto iris • Wall mountable with 3-Axis rotating camera construntion • Removed noise & ghost images with SSNR • 24/7 surveillance with Day & Night capability • High resolution of 530TV lines • Min. illumination of [email protected] (Color)

[email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Motion detection • OSD (On Screen Display) • S/N ratio of 50dB

• Voltage : 12V DC (SID-450) • Dual voltage : 24V AC / 12V DC (SID-452)

SID-45C/46C

High Resolution Dome Camera • 1/3" Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Built-in fixed lens : f3.7mm (SID-45C) / f8mm (SID-46C) • Compact, Stylish design for various indoor applications • Removed noise & ghost images with SSNR • 24/7 surveillance with Day & Night capability • High resolution of 530TV lines • Min. illumination of [email protected] (Color)

[email protected] (Sens-up) • Privacy image masking with free position : 4 zones • Motion detection

• OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 12V DC

SID-50

High Resolution Mini Dome Camera • 1/3" Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Built-in fixed lens : f3mm

• Compact, Light weight and stylish design • Removed noise & ghost images with SSNR • High resolution of 540TV lines • Min. illumination of [email protected] (Color)

[email protected] (Sens-up) • S/N ratio of 50dB

• Voltage : 12V DC

SIR-4250

High Resolution Day & Night IR Dome Camera • 1/3" Super HAD color CCD with 410K pixels(N), 470K pixels(P) • Built-in 4X (f3.8 ~ 9.5mm) varifocal lens with auto iris • Built-in high-performance IR LED, Exceptional night surveillance • Removed noise & ghost images with SSNR

• Day & Night with ICR (Infrared Cutfilter Removal) • High resolution of 520TV lines (Color), 570TV lines (B/W) • Min. illumination of [email protected] (LED on)

[email protected] (Color) [email protected](Sens-up) • Privacy image masking with free position : 4 zones • Additional service monitoring output • Easy adjustment with 3-Dimensional hinge • Motion detection • RS-485 remote control • OSD (On Screen Display) • S/N ratio of 50dB • Voltage : 12V DC

STM-17LV/19LV

19”, 17”TFT-LCD Color Monitor • 1280 x 1024@75Hz resolution • 1000 : 1 High contrast ratio • 300cd/m2_{High brightness} _•_{5ms Response time}

• BNC loop through, S-Video, RGB inputs • Built-in speakers • Protecting glass • Voltage : 12V DC

STM-17LP/19LP

19”, 17”TFT-LCD Color Monitor (RGB only) • 1280 x 1024@75Hz resolution • 1000 : 1 High contrast ratio • 300cd/m2_{High brightness} _•_{5ms Response time}

• RGB input only • Protecting glass • Easy to install wall-mount type support • Voltage : 12V DC

STM-21F

21”Flat Color Monitor

• 21" Flat CRT monitor • NTSC / PAL multiple system • 450TV Lines of horizontal resolution

• Video (2 BNC inputs/outputs, S-Video) • Built-in speaker • Metal cabinet • Free voltage : 100 ~ 240V AC

SAM-14MV

14”Color Monitor

• 14" CRT monitor • High performance resolution • Automatic color switching system

• Front panel control • Y-C signals, S-VHS input • Builit-in speaker • Metal cabinet • Free voltage : 100 ~ 240V AC

(4)

DVR

16CH Stand-Alone Digital Video Recorder

SVR-1650E

• True real-time 480fps(N), 400fps(P) digital live image display 480fps(N), 400fps(P) digital video recording • MPEG-4 compression

• High resolution image [704 x 480, 704 x 240, 352 x 240(N)] [704 x 576, 704 x 288, 352 x 288(P)] • 250GB HDD internal capacity

• Easy back up with 3 USB ports and built-in DVD+RW • ATM/POS transaction data recording and search • Integrated network multi-view, multi-users remote viewing • Support convenient control with a remote controller • PC mouse - interfaced control • OSD (Multi-language) • User-friendly GUI menu • Pan / Tilt / Zoom control • 10/100 base-T network interface capability • RS-232 / RS-485 / RS-422 • Expandable upto 8TB with the SVS-5, external HDD extension units

SVR-1640E

• Easy back up with 3 USB ports and built-in DVD+RW • ATM/POS transaction data recording and search • Integrated network multi-view, multi-users remote viewing • Support convenient control with a remote controller • PC mouse - interfaced control • OSD (Multi-language) • User-friendly GUI menu • Pan / Tilt / Zoom control • 10/100 base-T network interface capability • 4 channel audio recording • Expandable upto 8TB with the SVS-5, external HDD extension units

SVR-1630

• True real-time 480fps(N), 400fps(P) digital live image display 240fps(N), 200fps(P) digital video recording • Maximum 4TB storage capacity (IEEE 1394 for external HDD) • Built-in motion detection with search function

• Various back up devices : Removable HDD, Optional CD-RW, USB • Dynamic IP (TCP/IP, DHCP, FTP, PPPoE) support • ATM/POS transaction data recording and search • Spot monitor for single channel monitoring and playback • One channel audio recording and playback • Easy remote control (IR)

NETWORK PRODUCT

4CH MPEG-4/JPEG Network Video Server

SNS-400

• Real-time MPEG-4 / JPEG selectable video compression • Max. CIF 120fps(N) / Max. CIF 100fps(P) image transmission • Bi-directional audio support

• Pre/post alarm images archiving with USB memory • High resolution image : 704 x 480, 704 x 240, 352 x 240(N)

704 x 576, 704 x 288, 352 x 288(P) • Static / Dynamic IP support

• Remote Pan / Tilt / Zoom control (RS-232C, RS-422, RS-485) • TCP/IP, DHCP, HTTP, DDNS etc protocol • FTP/HTTP server & E-mail sending

• Network management Software / Web viewer support • 4 sensor input, 4 alarm output

SVR-950E

• Easy back up with 3 USB ports and built-in DVD+RW • ATM/POS transaction data recording and search • Integrated network multi-view, multi-users remote viewing • Support convenient control with a remote controller • PC mouse - interfaced control • OSD (Multi-language) • User-friendly GUI menu • Pan / Tilt / Zoom control • 10/100 base-T network interface capability • 4 channel audio recording • Expandable upto 8TB with the SVS-5, external HDD extension units

SVR-440

• High quality real-time playback / recording / network • More than 1 month 1 HDD recording (160GB)

• Use of MPEG-4 high performance compression algorithm (2~3KB) • Powerful network transmission with fast and superb picture quality • 4 channel two-directional audio transmission via network • User-friendly GUI menu

• Various recording and retrieval modes • Full function control with remote contoller (IR) • Compact size and refined appearance • User friendly front button arrangement

DVR HDD Extension Unit

SVS-5

• Capable of CIF 480fps recording & playback • Max. 4 SATA HDDs support (500GB x 4 = Max.2TB) • Max. 3.0Gbps transfer rate (SATA II) • 1U 19"rack-mount type chassis • Can be used with SVR-1650E/1640E/950E • Available in 2 types

SVS-5S : SATA board included SVS-5E : SATA board not included

1CH MPEG-4/JPEG Network Video Server

SNS-100

• Real-time MPEG-4 / JPEG selectable video compression • Max. VGA 30fps(N) / Max. VGA 25fps(P) image transmission • Bi-directional audio support

• Pre/post alarm images archiving with USB memory • High resolution image : 704 x 480, 704 x 240, 352 x 240(N)

704 x 576, 704 x 288, 352 x 288(P) • Static / Dynamic IP support

• Remote Pan / Tilt / Zoom control (RS-232C, RS-422, RS-485) • TCP/IP, DHCP, HTTP, DDNS etc protocol • FTP/HTTP server & E-mail sending

• Network management Software / Web viewer support • 2 sensor input, 2 alarm output

High Resolution Day & Night Network Camera

SNC-550

• Real-time MPEG-4 / JPEG selectable video compression • Max. VGA 30fps(N) / Max. VGA 25fps(P) image transmission • Power over Ethernet, Bi-directional audio support • High resolution image : 704 x 480, 704 x 240, 352 x 240(N)

704 x 576, 704 x 288, 352 x 288(P) • Static / Dynamic IP support / Ethernet 10/100 Base-T capability • TCP/IP, DHCP, HTTP, DDNS etc protocol • FTP/HTTP server & E-mail sending

• Network management Software / Web viewer support • 1/3" Super HAD color CCD with 410K pixels(N), 470K pixels(P) • High resolution of 530TV lines of a composite output • Day & Night with ICR (Infrared Cut filter Removal) • Removed noise & Ghost images with SSNR • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • 4 Privacy zone masking • Motion detection • Dual voltage : 24V AC / 12V DC, PoE

Low Light WDR 30X PTZ Network Dome Camera

SNP-3300

• Real-time MPEG-4 / JPEG selectable video compression • Max. VGA 30fps(N) / Max. VGA 25fps(P) image transmission • Power over Ethernet, Bi-directional audio support • High resolution image : 704 x 480, 704 x 240, 352 x 240(N)

704 x 576, 704 x 288, 352 x 288(P) • Static / Dynamic IP support / Ethernet 10/100 Base-T capability • TCP/IP, DHCP, HTTP, DDNS etc protocol • FTP/HTTP server & E-Mail sending, Analog output suppport • Network management Software / Web viewer support • 1/4" Vertical double density color CCD with 410K pixels(N), 470K pixels(P) • Powerful 30X optical zoom (f3.3 ~ 99mm) and 8X digital zoom • High resolution of 520TV lines of a composite output • Day & Night with ICR (Infrared Cut filter Removal) • Powerful 126X WDR function : Max. 52dB • Min. illumination of [email protected] (Color)

[email protected] (B/W) [email protected] (Sens-up) • Programmable 128 Presets, Digital Image Stabilizer • 8 Privacy zone masking • Motion detection • Dual voltage : 24V AC / 12V DC

(5)

STH-330PIV

Accessories for

PTZ Dome Camera

>

Accessories for

Vandal-proof

Dome Camera

Accessories for

Fixed Camera

Indoor Housing for PTZ Domes

• Can be used with various wall and ceiling mounts • Aluminium diecasting, Poly carbonate dome cover • IP67

• Dimensions : Ø242(W) x 284.5(H)mm

STB-496PPV

Pendant Bracket for PTZ Domes • Can be used with the STH-330/320 housings • Easy to install, Rugged and high strength • Dimensions : 150(W) x 496(H)mm

STB-340PCM

Corner Mount

• Can be used to install a camera and the STB-270PWV bracket on a wall corner • Easy to install, Rugged and high strength • Dimensions : 297(W) x 185(H) x 192(D)mm

STB-275VW

Vandal-proof Dome Wall Bracket • Can be used for installing vandal-proof dome camera (SVD-4120A/SVD-4300) • Water-proof with rugged aluminum • Quick and easy to install • Built-in mounting cap for easier connection with pipes • Dimensions : 154(H) x 252(D)mm

STH-330POV

Outdoor Housing for PTZ Domes • Can be used with various wall and ceiling mounts • Aluminium diecasting, Poly carbonate dome cover • Built-in fan / heater • IP67 • Easy to install with built-in housing connection plate • Dimensions : Ø242(W) x 284.5(H)mm

STB-270PWV

Indoor Housing for PTZ Domes • Can be used with the STH-330/320 housings • Easy to install, Rugged and high strength • Dimensions : 270(W) x 175(H) x 140(D)mm

STB-350PPM

Parapet Mount

• Can be used to install the camera on a place higher above wall • Easy to install, Rugged and high strength • Dimensions : 680(W) x 920(H)mm

STH-150

Indoor Housing • For fixed lens application • All aluminum construction • Wall / Ceiling installations • Easy to install and service • Dimensions : 114(W) x 90(H) x 390(D)mm

STH-320PO

Outdoor Housing for PTZ Domes • Lightweight - Can be used with various wall

and ceiling mounts • IP67 • Aluminium diecasting, Poly carbonate dome cover • Easy to install with built-in housing connection plate • Dimensions : Ø243(W) x 281(H)mm

STB-30PF

Ceiling Flange

• Can be used to connect the STH-330/320 housings with a pole

• Easy to install, Rugged and high strength • Dimensions : Ø126(W) x 67(H)mm

STB-319VP

Vandal-proof Dome Ceiling Bracket • Can be used for installing vandal-proof dome camera (SVD-4120A/SVD-4300) • Indoor Applications

• Quick and easy to install • Dimensions : Ø154(W) x 319(H)mm

STH-330PEV

Flush-Mount Indoor Housing • Compact and lightweight • For indoor applications • Poly carbonate dome cover • Dimensions : Ø235(W) x 188.5(H)mm

STB-20PF

Indoor Flange

• Can be used to comnbine a camera and the STB-330PC with the STB-270PWV/496PPV brackets • Easy to install, Rugged and high strength • Dimensions : Ø183(W) x 3mm

STB-249VW

Vandal-proof Dome Wall Bracket • Can be used for installing vandal-proof dome camera (SVD-4120A/SVD-4300) • Indoor Applications

• Quick and easy to install • Dimensions : Ø154(W) x 249(D)mm

STB-330PC

Ceiling Attechment Bracket for PTZ Domes • Can be used to attech a camera on ceiling with ease • For indoor applications • Rugged aluminum

• Dimensions : Ø183(W) x 48.5(H)mm

STB-330PPM

Pole Mount

• Can be used to connect the STB-270PWV bracket with a pole

• Easy to install, Rugged and high strength • Dimensions : 155(W) x 185(H) x 50(D)mm

STB-225VW

Vandal-proof Dome Wall Bracket • Can be used for installing vandal-proof dome camera (SVD-4120A/SVD-4300) • Water-proof with rugged aluminum • Quick and easy to install • Dimensions : 154(H) x 211(D)mm

CONTROLLER

System Controller for Speed Dome Cameras, DVRs and Matrix Switchers

SCC-3100A

Dual Color Quad Switcher

SDQ-420

• Two page quad switching (8 channel camera input) • High resolution image (720 x 576) • Multiple displays and action on alarm support • Individual freeze function

• Adjustable date & time display

• Enhanced record and playback with 2X digital zoom • Automatic & manual pan / tilt controlling

256 Input / 32 Output Video Matrix Switcher

SMX-25632

• Max. 256 camera input, 32 monitor output connects up to 3 extension units (SME-25632), 16 video cards (SMV-25632) • Supports 32 alphabet letters

• Controllable by a system keyboard contoller (SCC-3100A) • Features prevention for screen-shakes caused by changes

in sync signal when switching between manual and auto camera • Built-in power unit for safer power supply

• Controlling of both speed dome cameras, DVRs and matrix switchers • Centralized control of up to 255 units from a single controller • Configurable to connect multiple system controllers up to 16 units • Ergonomic design and easy-to-use keypad

• 3D joystick control of PTZ functions • Large character LCD display (20 x 4 lines) • Multi-protocol support

ACCESSORIES

(6)

Design and specifications are subject to change without notice.

SAMSUNG TECHWIN CO., LTD.

333-1, Sangdaewon 1-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do Korea 462-807 Tel : +82-31-730-8931~3 Fax : +82-31-730-8950 www.samsungcctv.com

I.D-0707 DISTRIBUTED BY

The

Eco mark

represents Samsung Techwin’s will to create environment-friendly products, and indicates that the product satisfies the EU RoHS Directive.

SAMSUNG OPTO-ELECTRONICS UK, LTD. Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Surrey KT16 OPS Tel : +44-1932-45-5308 Fax : +44-1932-45-5325 TIANJIN SAMSUNG OPTO-ELECTRONICS CO., LTD.

7 Pingchang Rd., Nankai Dist. Tianjin 300190, P.R China Tel : +86-22-2761-4724(33821) Fax : +86-22-2761-6514
