1 Purpose

... 9

2 Scope

... 9

3 Analyzer inspection guidelines

... 9

3.1 Safety and health considerations during testing

... 9

3.2 Documentation availability and applicability

... 10

3.3 Maintainability

... 10

3.4 Interfacing compatibility of this system with external or

connective devices

... 10

3.5 Workmanship of tubing, wiring, conduit, supports, suitability for

transportation to site, personnel safety hazards

... 10

3.6 Mutually agreed tests and proofing methods

... 10

4 Checklists

...11

(8)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---Copyright The Instrumentation, Systems, and Automation Society

(9)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 9

1 Purpose

The purpose of this recommended practice is to establish procedures for analyzer, packaged analyzer system, and sample system inspection and testing. The guidelines are intended to provide minimum requirements for inspecting and testing analyzers, sample systems, and analyzer systems prior to final acceptance. In no instance is this recommended practice intended to override any established company procedures.

2 Scope

The attached inspection guidelines are recommended for use during structured analyzer system inspection. The inspection should be performed by qualified individuals. This recommended practice is intended to be a guide and not a "how to" document. These are guidelines and should be modified to include any special project requirements. These guidelines cover three basic areas, which are:

a) ANALYZER INSPECTION: Inspection of an analyzer and the analyzer-specific application

engineering.

b) PACKAGED ANALYZER SYSTEM INSPECTION: Inspection of an analyzer building, shelter,

enclosure, highway controllers, and any other equipment used to support the analyzer operation (other than the analyzer and its sample system).

c) SAMPLE SYSTEM INSPECTION: Inspection of all vendor-supplied equipment that will be installed between the process sample tap and the analyzer.

For the purposes of this document, STRUCTURED TESTING is defined as any witnessed test procedure that follows a predefined format.

3 Analyzer inspection guidelines

3.1 Safety and health considerations during testing

The test host (i.e., analyzer manufacturer or system integrator) should be responsible to ensure that the test site and all equipment meet all applicable electrical, safety and health requirements of the authority having jurisdiction.

(10)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---10 ISA-RP76.0.01-1998

3.2 Documentation availability and applicability

All documentation should be system specific, and the latest revisions of the applicable

documents should be used. Any documentation not pertinent to the project should be deleted (unless previously agreed to otherwise). All applicable documentation should be readily available at the time of the inspection. The documentation format should be as specified or agreed to beforehand (including language).

3.3 Maintainability

Wherever possible, all equipment should be installed in such a manner that any hardware items can be easily removed without the removal of any other hardware. Easy tool access to screws, nuts, fittings, etc. should be available. All equipment should be mounted so that removable covers are accessible and adequate clearance for removal is provided.

3.4 Interfacing compatibility of this system with external or connective

devices

Analog and serial signals should be tested. Analog signals should be tested for linearity and ground isolation. If specified, all externally interfaced equipment should be provided (i.e., printers, recorders, plotters, protocol converters, etc.). All discrete outputs should be verified, as per the specification.

3.5 Workmanship of tubing, wiring, conduit, supports, suitability for

trans-portation to site, personnel safety hazards

A small sample of tube fittings should be dismantled and checked for workmanship. All unfilled sealing fittings should be clearly identified with a red tag. Piping, wiring, and conduit should be sufficiently supported to withstand any anticipated vibration from site conditions or transportation. The inspector should check that there are no sharp edges, points or protrusions that could injure personnel during transportation, placement, or use.

3.6 Mutually agreed tests and proofing methods

The requirements for an inspection need to be agreed to early in the project (one of the purposes of this document). Vendor pre-inspection tests, the number of test and calibration samples, the proof of their content, and the duration of stability tests should be as specified and/or agreed to. Samples should contain all components of interest and all components that were identified on the application data sheet and that can interfere with this measurement. Whenever feasible, the customer should supply an acceptable analyzed standard for the inspection. Some portion of the stability test should be witnessed by the customer's representative. Test data should be

presented in the specified or agreed-to format (e.g., raw data, summaries, statistical evaluations, or SPC charts).

All outstanding action items should be resolved before the conclusion of the acceptance test. In the event that an open item cannot be resolved, an expected date should be identified by which the item will be resolved. An action log such as that at the end of Clause 4 is recommended for that purpose.

(11)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 11

4 Checklists

The following may be used as inspection checklists or as references to help prepare checklists. It is suggested that any deviations from a checklist would be accepted only if agreed to in writing by both the customer and the vendor. Each type of analyzer system and/or sample can have unique requirements. Several blanks have been left in the following inspection guides, so users may easily incorporate additional items. Some of the listed items may not be relevant and may be deleted from a particular checklist; they are intended only as guides.

(12)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---12 ISA-RP76.0.01-1998

ANALYZER INSPECTION GUIDE

MANUFACTURER: DATE: MFG. ID#: PURCHASE ORDER: ANALYZER TAG NO.: SERIAL NO.:

V* = Vendor C* = Client

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 1 MECHANICAL Dimensions Mounting Weight 2 ELECTRICAL Volts Hertz Power (VA) 2.1 Effect of interruption 2.2 Insulation (Volts) Grounding R. F. shielding

2.3 Termination and wire labels

3 PIPING

3.1 Sample inlet 3.2 Sample return 3.3 Vent

3.4 Drain

(13)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 13

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 3.5 Instrument air 3.6 Steam 3.7 Water 3.8 Reagent 3.9 Safety valve(s) 4 SAFETY Area classification Warning labels, signals, purge

Personnel protection Certification

Materials of construction

exposed to the process

5 FUNCTION Zero Span 5.1 Calibration Number of points Certified samples

Maximum deviation from curve (% of measured value) Response time rising

(14)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---14 ISA-RP76.0.01-1998

PARAMETER SPECIFIED _WITNESS V* C*

COMMENT Response time falling

Stability (hours) Repeatability Noise band (% full scale deviation) Standard deviation 5.2 Signals Output Fully floating? Linearity (# points) Minimum sensitivity Serial communications 5.3 Environment Effect of ambient temperature Effect of ambient pressure Materials of construction exposed to ambient atmosphere 6 DOCUMENTATION/ MANUALS

(15)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 15

This system has been Accepted By: Rejected By: Conditionally Accepted By:

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 7 INDICATION 7.1 Local indicators 7.2 Local recorders

(16)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---16 ISA-RP76.0.01-1998

SAMPLE SYSTEM INSPECTION GUIDE

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 1 MECHANICAL Dimensions Enclosure 2 ELECTRICAL 3 PIPING/TUBING Material compatibility 4 SAFETY Area classification Warning labels, signals, certification

Personnel safety Hydrostatic test(s) Gas leakage test Flow limiters

(17)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 17

MANUFACTURER: DATE: MFG. ID#:

PURCHASE ORDER: ANALYZER TAG NO.: SERIAL NO.:

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 5 ENVIRONMENT Effect of ambient temperature Effect of ambient pressure 6 DOCUMENTATION Identification tags/labels 7 COMPONENTS Filters Pressure gauges Flowmeters Relief valves Accessibility Maintainability Identification tags

(18)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---18 ISA-RP76.0.01-1998

All sample systems from entry of transport line should be tested at 1 - 1.5 times duty pressure.

COMMENT

8 OVERALL TEST

Sample loop(s)

Sample conditioning system Stream selection

Calibration system

(19)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 19

PACKAGED ANALYZER SYSTEM INSPECTION GUIDE**

** A separate “Inspection Guide” should be completed for each sample conditioning system or each analyzer.

COMMENT

1 MECHANICAL

Dimensions & layout Mounting Weight 2 ELECTRICAL Area classification Certificate(s) 3 UTILITIES Steam Air Water Power circuit Lighting Vent header Drain header

(20)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---20 ISA-RP76.0.01-1998

PACKAGED ANALYZER SYSTEM INSPECTION GUIDE

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 4 SAFETY L.E.L. (Combustible) Oxygen deficiency Toxic Flow limiters Escape equipment Isolation valve(s) 5 OVERALL FUNCTION TEST 6 DOCUMENTATION 7 TAGGING

8 FAST LOOP AND SAMPLING SYSTEM

(21)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---ISA-RP76.0.01-1998 21

PACKAGED ANALYZER SYSTEM INSPECTION GUIDE

PARAMETER SPECIFIED _WITNESS V* C* COMMENT 9 COMMON SAMPLE RECOVERY SYSTEM 10 LEAKAGE TEST Utility header(s) 11 VENTILATION SYSTEM Ventilation Heater Air conditioner Temperature control

Mechanical and finish inspection Control/alarm systems

(22)

--``,,`,,`,`,,``,,`,,``,```````-`-`,,`,,`,`,,`---22 ISA-RP76.0.01-1998

ACTION LOG

Item No.

Deviation Corrective Action Responsibility Witness

V* C*
