A Practical Guide for WebLogic Server Domain Creation

(1)

www.bispsolutions.com | www.hyperionguru.com | weblogicexperts.wordpress.com| Page 1

A Hands-On Guide for

Creating WebLogic Server Domain

Description:

BISP is committed to provide BEST learning material to the beginners and advance learners.

In the same series, we have prepared a complete end-to end Hands-on Guide for WebLogic

Administration. The document focuses on how to create WebLogic Server Domain.

Join our

professional training program and learn from experts.

History:

Version

Description Change

Author

Publish Date

0.1 Initial Draft

Kuldeep Mishra

12th Aug 2012

0.1 Review#1

Amit Sharma

18

th

_{Aug 2012}

(2)

Creating WebLogic Server Domain

Step 1: Invoking Configuration Wizard

For Unix/Windows start configuration wizard using

Oracle/ Middleware/

wlserver_10.3/common/ bin/ config.cmd

(windows) or

config.sh

(Unix). Double Click on

config.cmd

(windows) or

config.sh

(Unix).

Create or Extend Domain-

If we wish to Create new WebLogic Domain or Extend an Existing WebLogic Domain.

Click Next.

(4)

Click Next.

Step 3: Specify Domain Name and Location Enter the name and location for the domain

(5)

Step 4: Configure Administrator

Define UserName and Password for WebLogic Domain and add/grant Administrator Role to that User. Using the administrator username and password, you can log in to the Administration Console to manage the Oracle WebLogic Server domain

Click Next

Step 5: Select JDK & Start Mode.

Define Mode in which you wish to start your domain and JDK (Sun, JRockit or any other JDK)

Production Mode- Domain is more secure, You need username password to start domain or

deploy application.

Development Mode- Not very secure, You can Autodeploy application and no need to

provide username/password to start Domain.

(6)

Click Next

Step 6:

Customize your domain

C

reate simple domain with Just one Administration Server (You can deploy your application in Administration Server but this is not recommended in Production Instance).

To create Advanced Domain (one Administration Server and two Managed Server and Cluster)go to step 10)

(7)

Click Next.

Step 7: Configure the Administration Server.

(8)

Click Next.

Step 8: Configuration Summary.

(9)

Step 9: Creating Domain-

Finally, If we are installing on Windows, you can select to “

Start Admin Server"

Click Done to finish Domain Installation.

Go to Start WebLogic and access

Domain Console

from browser.

Step 10: Select Optional Configuration

Create Domain with one Administration Server and two Managed Server Instance in

Cluster

. Here are to create new Domain with one Administration Server and two Managed Server.

(10)

Click Next.

Step 11: Configure the Administration Server.

Name – AdminServer, Listen Address – All IP address on machine, Listen port – 7003 ,SSL Listen Port – 7004.

(11)

Step 12: Configure Managed Server

Click Add.

Step 13: Configure Managed Server.

1) Name – WL_MS_1, Listen Address – All Local address, Listen port – 7005 ,SSL Listen Port – 7006.

2) Name – WL_MS_2, Listen Address – All Local address, Listen port – 7503 ,SSL Listen Port – 7004.

(12)

Click Next.

Step 14: Configure Cluster

Click on

Add

to create cluster and add Managed Server in Cluster. If we have NOT defined any managed server in previous screen, you will NOT get this screen.

(13)

Click Next.

Step 15: Configure Machine .

Use this screen if we have more than one machine in our system. In our configuration Administration Server and all Managed Server are on single machine.

Click Next.

(14)

Step 16 : Configure RDBMS Security Store Database.

In the Configure RDBMS Security Store Database step, retain the default values

.

Click Next.

Step 17: Review WebLogic Domain .

In the Configure RDBMS Security Store Database step, retain the default values.

(15)

www.bispsolutions.com | www.hyperionguru.com | weblogicexperts.wordpress.com| Page 15 Click Next.

Step 18 : Creating Domain.

In the Creating Domain screen, mark the checkbox “Start Admin Server” .

Click Done.

Step 19 : Start Weblogic.cmd.

It then starts the WebLogic Server instance in command prompt. Supply the user name and password when asked for.

(16)

Step 20 : Start Weblogic.cmd.

We can see the WebLogic Server instance in RUNNING mode.

Step 21 : To start the Web console

Open the browser, enter

http://localhost:7001/console

and click

Go.

Default Administration Port is 7001 so use port as 7001 (else use port we entered while

creating WebLogic Domain)

http://<servername>.domain:7001/console

or

http://localhost:7001/console (If we are accessing from server directly)

Login to WebLogic Admin Console supply the user name and password created during

WebLogic Domain Creation.

(17)
