Big Data Management System Solution Overview

(1)

Big Data Management System

Solution Overview

Pascal GUY

Pre Sales Architect

Business Unit Systems

Oracle France

(2)

Safe Harbor Statement

The following is intended to outline our general product direction. It is intended for

information purposes only, and may not be incorporated into any contract. It is not a

commitment to deliver any material, code, or functionality, and should not be relied upon

in making purchasing decisions. The development, release, and timing of any features or

functionality described for Oracle’s products remains at the sole discretion of Oracle.

(3)

Program Agenda

Oracle positioning

Technical proposition

Storage Treatment

Data Management

Visualization

Active domains

1

2

3

4

5

Oracle Confidential – Internal/Restricted/Highly Restricted 3

(4)

Enterprise Big Data Analytics Architecture

Enabling you to Create Value from Data

Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | BIG DATA MANAGEMENT BIG DATA ANALYTICS BIG DATA APPLICATIONS BIG DATA INTEGRATION CREATE VALUE FROM DATA

Streaming +

Batch

Data Reservoir +

Data Warehouse

Discovery +

Business Analytics

Mobile +

Web + On-device

(5)

Program Agenda

Oracle positioning

Technical proposition

Storage Treatment

Data Management

Visualization

Active domains

1

2

3

4

5

(6)

Getting Started with Big Data

Transform

Key Business Initiatives

Build Foundation

ETL Offload

ISV Platform Integration

Enrich

Enhance Existing Data

Warehouse and BI

(7)

Driving Business Value from Technology Innovation

Use the Right Tool for the Job and benefit from the Power of “AND”

7

Run the Business



Integrate existing systems



Support mission-critical tasks



Protect existing expenditures



Ensure skills relevance

Relational

Hadoop

Change the Business



Disrupt competitors



Disintermediate supply chains



Leverage new paradigms



Exploit new analyses

NoSQL

Scale the Business



Serve data faster



Meet mobile challenges

(8)

Oracle Big Data Management System

SOUR

C

ES

DATA RESERVOIR

DATA WAREHOUSE

Oracle Database

Oracle Industry

Models

Oracle Advanced

Analytics

Oracle Spatial & Graph

Big Data Appliance

Apache

Flume

Oracle

GoldenGate

Oracle Event

Processing

Cloudera Hadoop

Oracle NoSQL

Oracle R Advanced

Analytics for Hadoop

Oracle R Distribution

Oracle Database

In-Memory, Multi-tenant

Oracle Industry Models

Oracle Advanced

Analytics

Oracle Spatial & Graph

Exadata

Oracle

GoldenGate

Oracle Event

Processing

Oracle Data

Integrator

Oracle Big Data

Connectors

Oracle Data

Integrator

(9)

Program Agenda

Oracle positioning

Technical proposition

Storage Treatment

Data Management

Visualization

Active domains

1

2

3

4

5

(10)

Recap: Big Data Appliance Overview

Big Data Appliance X4-2

Sun Oracle X4-2L Servers with per server:

• 2 * 8 Core Intel Xeon E5 Processors

• 64 GB Memory

• 48TB Disk space

Integrated Software:

• Oracle Linux, Oracle Java VM

• Oracle Big Data SQL*

• Cloudera Distribution of Apache Hadoop – EDH Edition

• Cloudera Manager

• Oracle R Distribution

• Oracle NoSQL Database

10

(11)

Recap: Standard and Modular

11



Starter Rack is a fully cabled and

configured for growth with 6 servers



In-Rack Expansion delivers 6 server

modular expansion block



Full Rack delivers optimal blend of

capacity and expansion options



Grow by adding rack – up to 18 racks

(12)

Oracle Big Data SQL – A New Architecture

• Powerful, high-performance SQL on Hadoop

–

Full Oracle SQL capabilities on Hadoop

–

SQL query processing local to Hadoop nodes

• Simple data integration of Hadoop and Oracle Database

–

Single SQL point-of-entry to access all data

–

Scalable joins between Hadoop and RDBMS data

• Optimized hardware

–

High-speed Infiniband network between Hadoop and Exadata

(13)

Smart Scan for Fast Query Processing

(14)

Intelligent Query Optimization

One Query Spanning Oracle Database, Hadoop & NoSQL

Query Data in RDBMS,

Hadoop & NoSQL

Oracle SQL

Oracle NoSQL DB BDS Server HDFS Data Node BDS Server Oracle NoSQL DB BDS Server HDFS Data Node BDS Server Oracle Database Storage Server Oracle Database Storage Server

Fast

Massive Parallelism

Filtered Locally

(15)

Data Stored in Hadoop

Hadoop/NoSQL Ecosystem

_{{"custId":1185972,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:07","recommended":null,"activity":8}}

{"custId":1354924,"movieId":1948,"genreId":9,"time":"2012-07-01:00:00:22","recommended":"N","activity":7} {"custId":1083711,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:26","recommended":null,"activity":9} {"custId":1234182,"movieId":11547,"genreId":44,"time":"2012-07-01:00:00:32","recommended":"Y","activity":7} {"custId":1010220,"movieId":11547,"genreId":44,"time":"2012-07-01:00:00:42","recommended":"Y","activity":6} {"custId":1143971,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:43","recommended":null,"activity":8} {"custId":1253676,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:50","recommended":null,"activity":9} {"custId":1351777,"movieId":608,"genreId":6,"time":"2012-07-01:00:01:03","recommended":"N","activity":7} {"custId":1143971,"movieId":null,"genreId":null,"time":"2012-07-01:00:01:07","recommended":null,"activity":9} {"custId":1363545,"movieId":27205,"genreId":9,"time":"2012-07-01:00:01:18","recommended":"Y","activity":7} {"custId":1067283,"movieId":1124,"genreId":9,"time":"2012-07-01:00:01:26","recommended":"Y","activity":7} {"custId":1126174,"movieId":16309,"genreId":9,"time":"2012-07-01:00:01:35","recommended":"N","activity":7} {"custId":1234182,"movieId":11547,"genreId":44,"time":"2012-07-01:00:01:39","recommended":"Y","activity":7}} {"custId":1346299,"movieId":424,"genreId":1,"time":"2012-07-01:00:05:02","recommended":"Y","activity":4}

Example: 1TB File

Block B1

Block B2

Block B3

• 1 block = 256 MB

• Example File = 40 blocks

(16)

Enhance Oracle External Table Performance

• Previously external tables were “file-centric”

–

1 file == 1 unit of parallelism

• Enhanced external tables understand

parallelism

–

Automatically map external units of parallelism to

Oracle “Granules”

–

1 Input Split == 1 Oracle “Granule”

CREATE TABLE movieapp_log_json

(click VARCHAR2(4000))

ORGANIZATION EXTERNAL

(TYPE

ORACLE_HIVE

DEFAULT DIRECTORY DEFAULT_DIR

)

PARALLEL 20

(17)

Query Execution on Hadoop

select last_name, state,

movie, genre

from movielog m, customer c

where genre=‘comedy’

and c.custid = m.custid

1 Query compilation determines:

• Data locations

• Data structure

• Parallelism

1

2 Parallel reads using Big Data SQL Server:

• Parallel unit: PQ Slaves & InputSplits

• Filter rows and project columns

2

Hive Metastore HDFS

NameNode

3 Process filtered result

• Move relevant data to database

• Join with database tables

• Apply database security policies

3

HDFS Data Node BDS Server

(18)

Big Data SQL Server Minimizes Data Movement

Data Node

Disk

Big Data SQL Server

External Table Services

1. Read using Hadoop Classes

2. Convert to Oracle Data

Stream

Hadoop Smart Scan

1. Apply filter predicates

2. Apply column projections

3. Apply row-level functions

• JSON Parsing

• Work close to the data

–

Scans and serializations from Hadoop classes

–

Transformation into Oracle data stream

• Smart Scan: Emit only relevant data

–

Apply filter predicates

• Include complex predicates, e.g. JSON_EXISTS

• Bloom filters for faster joins

• Score Data Mining models

–

Project columns

(19)

Big Data SQL

Rich, comprehensive SQL access to all enterprise data

19

(20)

Program Agenda

Oracle positioning

Technical proposition

Storage Treatment

Data Management

Visualization

Active domains

1

2

3

4

5

(21)

Feedback Loop

Data Management

Big Data

Platform

(Hadoop/NoSQL)

Relational

Data Warehouse

(OCDM)

Analytic Apps

Customer

Experience

Operations

Monetization

Adapters

ETL/ELT

Adapters

Real-Time

Adapters

Third

Party

Data

Sources

Oracle Comms Apps (BSS/OSS)

Oracle Comms Ntwk Products (Tekelec

& Acme)

Other Oracle Apps (CRM, ERP, etc.)

Third Party Sources

Oracle Communications Data Model

Reference Architecture

To Other Apps

(22)

Data Stored in Hadoop

Hadoop/NoSQL Ecosystem

_{{"custId":1185972,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:07","recommended":null,"activity":8}}

{"custId":1354924,"movieId":1948,"genreId":9,"time":"2012-07-01:00:00:22","recommended":"N","activity":7} {"custId":1083711,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:26","recommended":null,"activity":9} {"custId":1234182,"movieId":11547,"genreId":44,"time":"2012-07-01:00:00:32","recommended":"Y","activity":7} {"custId":1010220,"movieId":11547,"genreId":44,"time":"2012-07-01:00:00:42","recommended":"Y","activity":6} {"custId":1143971,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:43","recommended":null,"activity":8} {"custId":1253676,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:50","recommended":null,"activity":9} {"custId":1351777,"movieId":608,"genreId":6,"time":"2012-07-01:00:01:03","recommended":"N","activity":7} {"custId":1143971,"movieId":null,"genreId":null,"time":"2012-07-01:00:01:07","recommended":null,"activity":9} {"custId":1363545,"movieId":27205,"genreId":9,"time":"2012-07-01:00:01:18","recommended":"Y","activity":7} {"custId":1067283,"movieId":1124,"genreId":9,"time":"2012-07-01:00:01:26","recommended":"Y","activity":7} {"custId":1126174,"movieId":16309,"genreId":9,"time":"2012-07-01:00:01:35","recommended":"N","activity":7} {"custId":1234182,"movieId":11547,"genreId":44,"time":"2012-07-01:00:01:39","recommended":"Y","activity":7}} {"custId":1346299,"movieId":424,"genreId":1,"time":"2012-07-01:00:05:02","recommended":"Y","activity":4}

(23)

Hive

• Provides SQL-like interface to data stored in HDFS

• Allows applications to process data stored in any format

• Tables capture metadata required to locate and parse data

• SQL query generates a MapReduce job to process the data

• Big Data SQL uses Hive metadata to simplify

administration, but it’s not required.

(24)

Schema on Read: MapReduce and Hive

Simple Case: Single Column

> select * from movieapp_log_json

{"custId":1185972,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:07",… {"custId":1354924,"movieId":1948,"genreId":9,"time":"2012-07-01:00:00:22",… {"custId":1083711,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:26",… {"custId":1234182,"movieId":11547,"genreId":44,"time":"2012-07-01:00:00:32”,… {"custId":1010220,"movieId":11547,"genreId":44,"time":"2012-07-01:00:00:42",… {"custId":1143971,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:43",… {"custId":1253676,"movieId":null,"genreId":null,"time":"2012-07-01:00:00:50",… {"custId":1351777,"movieId":608,"genreId":6,"time":"2012-07-01:00:01:03”,…

HiveQL:

CREATE EXTERNAL TABLE movieapp_log_json

(

click STRING

)

ROW FORMAT

DELIMITED

LINES TERMINATED BY '\n'

STORED AS TEXTFILE

LOCATION '/user/oracle/applog';

(25)

Schema on Read: MapReduce and Hive

Same Source with Columns Derived Using SerDe

> select * from movielog_cols

HiveQL:

CREATE EXTERNAL TABLE movielog_cols (

custid int,

movieid int,

activity int, …)

ROW FORMAT SERDE

'org.apache.hive.hcatalog.data.JsonSerDe'

STORED AS INPUTFORMAT

'org.apache.hadoop.mapred.TextInputFormat'

OUTPUTFORMAT

'org.apache.hadoop.hive.ql.io.HiveIgnoreKeyTextOutputFormat'

LOCATION

'/user/oracle/applog_json';

(26)

Hive Metastore

SQL Execution Engines Share Metadata

Hive Metastore

Hive

Impala

Shark

Oracle Big Data SQL

…

Table Definitions:

movieapp_log_json

movielog

movieapp_log_avro

(27)

Unify Metadata: Publish Hive Metadata to Oracle Catalog

27

CREATE TABLE movieapp_log_json

(click VARCHAR2(4000))

ORGANIZATION EXTERNAL

(TYPE

ORACLE_HIVE

DEFAULT DIRECTORY DEFAULT_DIR

)

REJECT LIMIT UNLIMITED;

Big Data Appliance

+

Hadoop/NoSQL

Exadata

+

Oracle Database

Oracle Catalog

External Table

Hive metadata

External Table

Hive Metastore

(28)

Automation: Oracle Data Modeler

Import Hive definitions into model

Automatically generate Oracle DDL for

imported tables

(29)

New Data Sources for Oracle External Tables

CREATE TABLE movielog

(click VARCHAR2(4000))

ORGANIZATION EXTERNAL

( TYPE

ORACLE_HIVE

DEFAULT DIRECTORY Dir1

ACCESS PARAMETERS

(

com.oracle.bigdata.tablename logs

com.oracle.bigdata.cluster mycluster

)

REJECT LIMIT UNLIMITED

• New set of properties

–

ORACLE_HIVE and ORACLE_HDFS access drivers

–

Identify a Hadoop cluster, data source, column

mapping, error handling, overflow handling, logging

• New table metadata passed from Oracle DDL to

Hadoop readers at query execution

• Architected for extensibility

–

StorageHandler capability enables future support for

other data sources

(30)

Use Rich Oracle SQL Dialect Over

All

Data

Snapshot of Oracle SQL Analytic Functions

• Ranking functions

– rank, dense_rank, cume_dist, percent_rank, ntile

• Window Aggregate functions (moving and cumulative)

– Avg, sum, min, max, count, variance, stddev, first_value, last_value

• LAG/LEAD functions

– Direct inter-row reference using offsets

• Reporting Aggregate functions

– Sum, avg, min, max, variance, stddev, count, ratio_to_report

• Statistical Aggregates

– Correlation, linear regression family, covariance

• Linear regression

– Fitting of an ordinary-least-squares regression line to a set of number pairs.

– Frequently combined with the COVAR_POP, COVAR_SAMP, and CORR functions

• Descriptive Statistics

– DBMS_STAT_FUNCS: summarizes numerical columns of a table and returns count, min, max, range, mean, stats_mode, variance, standard deviation, median,

quantile values, +/- n sigma values, top/bottom 5 values

• Correlations

– Pearson’s correlation coefficients, Spearman's and Kendall's (both nonparametric).

• Cross Tabs

– Enhanced with % statistics: chi squared, phi coefficient, Cramer's V, contingency coefficient, Cohen's kappa

• Hypothesis Testing

– Student t-test , F-test, Binomial test, Wilcoxon Signed Ranks test, Chi-square, Mann Whitney test, Kolmogorov-Smirnov test, One-way ANOVA

• Distribution Fitting

– Kolmogorov-Smirnov Test, Anderson-Darling Test, Chi-Squared Test, Normal, Uniform, Weibull, Exponential

(31)

next = lineNext.getQuantity(); }

if (!q.isEmpty() && (prev.isEmpty() || (eq(q, prev) && gt(q, next)))) { state = "S";

return state; }

if (gt(q, prev) && gt(q, next)) { state = "T";

return state; }

if (lt(q, prev) && lt(q, next)) { state = "B";

return state; }

if (!q.isEmpty() && (next.isEmpty() || (gt(q, prev) && eq(q, next)))) { state = "E";

return state; }

if (q.isEmpty() || eq(q, prev)) { state = "F";

return state; }

private boolean eq(String a, String b) { if (a.isEmpty() || b.isEmpty()) { return false;

}

return a.equals(b); }

private boolean gt(String a, String b) { if (a.isEmpty() || b.isEmpty()) { return false;

}

return Double.parseDouble(a) > Double.parseDouble(b); }

private boolean lt(String a, String b) { if (a.isEmpty() || b.isEmpty()) { return false;

}

return Double.parseDouble(a) < Double.parseDouble(b); }

public String getState() { return this.state; }

}

BagFactory bagFactory = BagFactory.getInstance(); @Override

public Tuple exec(Tuple input) throws IOException { long c = 0; String line = ""; String pbkey = ""; V0Line nextLine; V0Line thisLine; V0Line processLine; V0Line evalLine = null; V0Line prevLine;

boolean noMoreValues = false; String matchList = "";

ArrayList<V0Line> lineFifo = new ArrayList<V0Line>(); boolean finished = false;

DataBag output = bagFactory.newDefaultBag(); if (input == null) { return null; } if (input.size() == 0) { return null; } Object o = input.get(0); if (o == null) { return null; } //Object o = input.get(0); if (!(o instanceof DataBag)) { int errCode = 2114;

String msg = "Expected input to be DataBag, but"

Pattern Matching With Oracle SQL

Snapshot of Oracle SQL Analytic Functions

Simplified, sophisticated, standards based syntax

SELECT first_x, last_z

FROM ticker MATCH_RECOGNIZE (

PARTITION BY name ORDER BY time MEASURES FIRST(x.time) AS first_x, LAST(z.time) AS last_z ONE ROW PER MATCH

PATTERN (X+ Y+ W+ Z+)

DEFINE X AS (price < PREV(price)), Y AS (price > PREV(price)), W AS (price < PREV(price)), Z AS (price > PREV(price) AND

z.time - FIRST(x.time) <= 7 ))

250+ Lines of Java UDF

12 Lines of SQL

20x less code

Finding Patterns in Stock Market Data - Double Bottom (W)

10:00 10:05 10:10 10:15 10:20 10:25

(32)

Govern

All

Data

32

Store JSON data unconverted

in Hadoop

Oracle Database 12c Oracle Big Data Appliance

SQL

Data analyzed via SQL

Store business-critical data in

Oracle

DBMS_REDACT.ADD_POLICY( object_schema => 'hr', object_name => 'employee', column_name => 'social_sec_num', policy_name => 'redact_ssn', function_type => DBMS_REDACT.FULL, expression => '1=1' );
