Challenges Facing Data Center Networking

(1)

Jaime Lopez

(2)

Challenges Facing IT and Hosting Providers

2

Deliver cloud-scale networks that provide scale, openness and

simplicity

in a cost-effective architecture

The Challenge

User and Device Mobility

Application Mobility

IT Budgets and Move from

CAPEX to OPEX

Simplicity and Lower

Operating Costs

Multi-vendor Operation to

Enable Best of Breed

(3)

Cloud-Scale Data Center: The New Computer

Cloud Ready/Virtualization

– On Demand Provisioning

– Hardware Independence /

High Availability

– Automation

Consolidation

– High Computational Density

– Physical Location Consolidation

– Reducing Data Center Tiers

Cloud Scale

– 10G/40G/100G

– Low Latency / Low Oversubscription

Green

(4)

Gartner: 5 trends that will transform the data center

4

“The demand for IT as a service, combined with the

need to reduce costs, has pushed data centres to the

brink of a second transformation”

–

Hybrid IT:

Perhaps the greatest effect of public cloud computing on IT

concerns operations. IT organizations realize that not only do they need to

compete with public cloud service providers (CSPs), but also act as

intermediaries between internal customers and all IT services (internal or

external).

–

Internal clouds:

When businesses grow accustomed to consuming IT as

a service, IT organizations will be compelled to build internal clouds.

Unfortunately, building an internal cloud is hard work and few blueprints

exist.

–

Hybrid clouds:

Hybrid clouds are connections between two clouds,

usually an internal private cloud and an external public cloud

–

User-centric computing:

To compete in a global market and retain key

employees, organizations often have to accommodate staff who live in

remote locations and use personal devices for work.

–

Data center efficiency:

Competing with the external cloud requires IT

organizations to strive for hyper-efficiency in their data centers. If critical

data and applications are to be housed in an internal private cloud, IT

organizations must deliver internal IT services in an efficient, cost-effective

manner.

“

The new data centre:

In 2012, the data centre will

continue its transformation from a traditional, virtualised,

consolidated and centralised IT infrastructure into a

(5)

Open Fabric Architecture –

Best-of-Breed Data Center Switching

Agenda - Extreme Networks

®

_{Data Center Solution}

(6)

Extreme Networks OpenFabric

6

• Popular term to describe data center

networks

• High-speed, low-latency, multi-path

mesh, and resilient

• Managed as a single entity

• May be open or closed (Juniper

QFabric)

A Fabric

• Provides price-performance,

interoperability, flexibility, investment

protection, and scalability

• Targeted at cloud data center

providers (Internal or External)

where infrastructure is cost

• No vendor lock-in

(7)

Extreme Networks

®

_{Open Fabric Facts}

FABRIC-IN-A-BOX

768 10GbE & 192 40GbE

Latency 2.3 µsec

Any-to-Any Port

5W per 10GbE Port

FABRIC-SCALABILITY

4500 + 10GbE

Latency 4.1 µsec

Any-to-Any Port

5W per 10GbE Port

Best-of-Breed

Hardware

Platforms

Standards-Based, Open &

Interoperable

Automation &

Virtualization

Intelligence

Open Ecosystem

Powered by Single ExtremeXOS

®

(8)

Scalable Data Center Architectures –

Reducing Network Tiers

(9)

Data Centre Network Architecture Challenges

Data Centre Core

Aggregation

Access

Blade Switch

VSwitch

VSwitch Appliance

“50% of All Data Center

Network Ports Sold –

Connect to Other

Network Ports”

(10)

VSwitch

Blade Chassis Blade Chassis Blade Chassis

12 Racks

Blade Switch

ToR Switch

Aggregation

Switch

Core Switch

Sample 12

Rack DC

Network will

have

5 Layers!

• 384 vSwitches

• 24 Blade Switches

• 12 ToR Switches

• 2 Agg Switches

• 2 Core Switches

A total of 424

Switches!!!

384 Blade Servers

VSwitch

VM

(11)

Direct Attach™

Eliminate the vSwitch

“Virtually” Reducing Network Tiers

Data Center

Core

VM1

VM2

vSwitch

Minimal traffic

provisioning (if any) is

done at the vSwitch.

(12)

Direct Attach

12

Eliminate the vSwitch

“Virtually” Reducing Network Tiers

VM2

Direct Attach™ Enabled Switch

Host: Fedora 12

Hypervisor: QEMU-KVM

Guest OS:

Ubuntu

Active applications:

• gnome-system-monitor

for network

and CPU utilization

• tcpdump

to monitor

attack traffic from VM1

VM1

Guest OS:

Ubuntu

Active applications:

• gnome-system-monitor

for network

and CPU utilization

• hping

to generate DoS

attack targeted at VM2

VM2

Inter-VM traffic is transmitted and received on

the same network physical port. VM2 CPU and

network utilization severely impacted, due to

DoS attack.

CLEAR-Flow enabled to dynamically

provision/block DoS traffic. VM2 CPU

and network utilization reverts to healthy.

(13)

Direct Attach™ Architecture

Blade Chassis

VSwitch

Blade Chassis Blade Chassis Blade Chassis

12 Racks

Blade Switch

TOR Switch

Aggregation

Switch

Core Switch

Sample 12

Rack DC

Network will

have

5 Layers!

• 768 vSwitches

• 24 Blade Switches

• 12 TOR Switches

• 2 Agg Switches

• 2 Core Switches

A total of 808

Switches!!!

VSwitch

VM

12 Racks

Aggregation

Switch

Core Switch

Sample 12

Rack DC

Network w/

Direct Attach

Architecture:

2 Tiers Only

• 0 vSwitches

• 0 Blade Switches

• 0 ToR Switches

• 2 Agg Switches

• 2 Core Switches

4 switches vs.

424 switches

MRJ21

Passive

Patch

Panel

384 Blade Servers

(14)

Extreme Networks

®

Open Fabric – Data Center in a Box

14

– Single Tier Physical and Logical

Network

– Supports Up to 768 10 GbE Servers in

a Single Switch

– Supports 128,000 Virtual Machines in a

Single Switch

– Heterogeneous Hypervisor Integration

– M-LAG Support for “Multi-path”

Capability

– VEPA Support – Moving Switching Back

to the Network

– Data Center Bridging for data and

storage integration

– XNV (ExtremeXOS

®

_Network

Virtualization) for VM Mobility

Management

BlackDiamond

®

X8* –

Data Center in a Box

<3 µsec

Latency

ExtremeXOS

®

Data Center Bridging

M-LAG

Direct Attach™ / VEPA

XNV™

OpenFlow*

(15)

Extreme Networks

®

Open Fabric – 40G Standards Based

ExtremeXOS

®

Data Center Bridging

M-LAG

Direct Attach™ / VEPA

XNV™

Up to 2,256

10 GbE Servers

with only 3x

over-subscription

2x BlackDiamond

®

_X8*

94 x Summit

®

_X670*

OpenFlow*

(16)

Mobility – Dynamic Resource Allocation

Agenda - Extreme Networks

®

_{Data Center Solution}

(17)

Network Mobility of Virtual Machines

• Make the network “VM aware”

• Hypervisor independent

• “Zero-touch” network provisioning

• Dynamic Virtual Port Profiles

(18)

Virtual Machine Manager

NIC

Hypervisor

Switch Port

Config

IP:

1.1.1.2 MAC: 00:0A

QoS: QP7

ACL: Deny HTTP

Network Admin

When a virtual machine

move occurs automatically

or initiated by server admin,

the network admin has NO

visibility into VM location or

when the movement occur

Switch Port

Config

None or

Disabled

VM1

IP: 1.1.1.2

MAC: 00:0A

Initiate

Result:

The VM moves to a

destination switch port

that is incorrectly

configured to deliver

network services to the

specific VM

VM Mobility Issues

18

Today Network has Zero Visibility into VM Lifecycle

(19)

Virtual Machine Manager

NIC

Hypervisor

Network Admin

VM1

IP: 1.1.1.2

MAC: 00:0A

Switch Port

Config

IP:

1.1.1.2 MAC: 00:0A

QoS: QP7

ACL: Deny HTTP

Switch Port

Config

None or

Disabled

Location-based VM awareness at the network level for

efficient virtual machine mobility

VM info

Switch Port Config

Virtual Port Profile

IP:

1.1.1.2 MAC: 00:0A

QoS: QP7

ACL: Deny HTTP

XNV™-enabled

XNV-enabled

Switch Port Config

Virtual Port Profile

IP:

1.1.1.2 MAC: 00:0A

QoS: QP7

ACL: Deny HTTP

Result:

Both the VM and the

Virtual Port Profile

moves to the destination

switch port.

Network-level visibility into VM

movement is achieved to

deliver better SLA.

Ridgeline™:

Through XML integration

• Pull Inventory from

virtual machine manager

• Locate VMs on network switches

• Show Inventory VM



Switch Port Mapping

• Define Virtual Port Profile (VPP)

• Assign (VPP) to VMs

and Distribute

• Respond to VM

Initiate Query

Network Visibility into VM Lifecycle

Server Admin

(20)

ExtremeXOS

®

_Automation

20

• Ridgeline™ provisions across

multiple Extreme

Networks

®

_{switches and}

integrates with hypervisor

management

• Tightly integrates with

virtualization management

platforms

• XML based API

• Centralized network-level

inventory

• Network-level insight and

control of virtualization

(21)

Storage Convergence – Leverage Ethernet

to reduce cost and complexity

(22)

Network and Storage Convergence

22

Priority Based

Flow Control

(PFC)

Enhanced

Transmission

Standard(ETS

)

DCB Capabilities

Exchange

(DCBX)

Data Center Bridging (DCB) Protocols

Block Based Storage

iSCSI

FCoE

File Based Storage

NFS

CIFS

Dynamic

Scripting

ClearFlo

w

(23)

BDX

8 BDX

8

FCoE iSCSI

NAS

FC

SAN

M-LAGs

LAG

_LAG

LAG

LAGs

BlackDiamond® X8

Core Switch

QLogic UA5900

Converged Switch

Summit® X670

TOR Switch

BlackDiamond® X8

Core Switch

Summit® X670

TOR Switch

CNA

Servers

NIC

LAG

Any

FC

SAN

LAG

(24)

Extreme Networks

Open Architecture

to provide

best of breed

Scale

to address

the demands

of the cloud

Mobile

to enable

dynamic resource

allocation

Automate

to create

zero-touch services

(25)

Product Roadmap

This product roadmap represents Extreme Networks

®

_current

product direction. All product releases will be on a when-and-if

available basis.

Actual feature development and timing of releases will be at

the sole discretion of Extreme Networks. Not all features are

supported on all platforms.

Presentation of the product roadmap does not create a

commitment by Extreme Networks to deliver a specific feature.

Contents of this roadmap are subject to change without notice.

(26)

* Future availability.

Data Centre Switching Portfolio

SUMMIT

®

_{X670 & 650}

BLACKDIAMOND

®

₈₈₀₀

BLACKDIAMOND

®

_X8

Top-of-Rack

1G/10G Access

10G/40G Uplinks

End-of-Row/Mid-of-Row

1G/10G Access

10G/40G Uplinks

End-of-Row/Mid-of-Row

10G Access/Aggregation

40G Aggregation/Core

Mid-Large

Data Centre

Small-Large

Data Centre

Powered by Single ExtremeXOS

®

Data Center Bridging

M-LAG

Direct Attach™/VEPA

XNV™

OpenFlow*

Small-Mid

Data Centre

(27)

Summit X670 Top-of-Rack

Summit X670V

• 48x10G + 4x40G OR 64x10G

• Investment Protection through VIM

Summit X670

• 48x10G with lower latency

10G at 1G Price Points with Full

Features

Low Latency, Phy-less Design,

Cut-through Switching

DCB and Storage Convergence

Supports 128K Virtual Machines

Physical Security with Motion Detector

(28)

BlackDiamond X8 – News Summary

* Dell Oro Ethernet Switching Market - Fall 2011

Highest Consolidation

• 14.5 RU - 1/3

rd

_{of Rack}

• 768 x 10GbE wirespeed

• 192 x 40GbE wirespeed

Unmatched Performance

• 20+ Tbps Capacity/Switch

• 1.28 Tbps Bandwidth/Slot

Lowest Latency

• 2.3 ms – Port-to-Port

Superior Availability

• 1+1 Management

• N+1 Fabric, Power & Fan

• N+N Power GRID

Server Virtualization

• 128K Virtual Machines

• VM Lifecycle Management

• VPP & XNV

Storage Convergence

• iSCSI, NFS, CIFS

• DCBx (PFC, FS, ETS)

• FCoE Transit

Power & Cooling

• Front-to-Back Cooling

• Variable Fan Speed

• Only 5W per 10GbE port

• Intelligent Power Mgmt.

(29)

Best in Class Cloud Performance and Power

Best In Class

Latency

Best In Class Power

Consumption

Ensures Efficiency

The Lippis Report:

Recognized Independent Analytical

Product Testing

(30)

Vendor Comparison By Chassis

W

ir

esp

ee

d

10G

40G

O

v

ersub

10G

40G

BlackDiamond X8

is a Leader – Not a Follower!

• All 8 Slot Chassis “apples-to-apples” comparison

• All 10/40GE Capable

Arista

7508

384

0

0 N/A

Extreme

Networks

BlackDiamond

8800

64

16

48

192 HP

12508

64

0

256 Juniper

EX8208

64

0

320 Brocade

MLXE8

64

0

0 N/A

Dell/F10

E600i Exa

70

14

28

280 Cisco

NX7010

256

48 N/A

384 Extreme

Networks

BlackDiamond X8

768

192 N/A

N/A

Juniper

QFX3008

0

128 N/A

N/A

30

(31)

Vendor Comparison By 10 GE Rack DC Space for

WireSpeed 2304x10GE Ports

0

20

40

60

80

100

120

140 Total Power (KW)

Extreme Networks Arista Cisco Brocade Juniper Dell/F10 HP

HP 12508

18 Racks

Extreme Networks

BlackDiamond® X8

1 Rack (44RU)

Dell/F10 E600i

16.5 Racks

Juniper EX8208

12 Racks

Cisco NX7010

4.5 Racks

Brocade MLXE-8

6 Racks

Arista 7508

1.5 Racks

(32)

Dell/F10 E600i

20.5 Racks

32

Cisco NX7010

6 Racks

Juniper QFX3008

2.5 Racks

Numbers of Racks Required

to Deliver Nearly 600 40G

Data Trunk Connections

First to Market With 40G Connectivity Wire-Speed

576x40GE Ports

0

50

100

150

200

250 Total Power (KW)

Extreme BDX

Cisco N7K

Juniper QFX3K

Cisco 6K

Dell E600i

Extreme BlackDiamond X8

1 Rack (44RU)

Cisco Cat6509V

18 Racks

(33)

Partnerships Enable Best-of-Breed Solutions

Open Enterprise Cloud

Virtualization

Server & Storage Ecosystem Partners

Open Source Cloud Architecture

(34)

Ethernet Data Centre Solution Eco-System

34

Systems

Open Flow

Storage &

Security

Virtualization

Management &

Orchestration

Applications

(35)

Why Extreme?

• Thought Leadership & Innovation

• Standards-Based, Open & Interoperable

• Simplified Portfolio – Across Data Centre

Segments

• Open Eco-System

• It is Green

(36)

Thank You

(37)

What Analysts Are Saying

Independent tests by Lippis Report called our core

switch (BDX8) 3X-10X faster than competition

Dell’Oro, a leading analyst group, rated Extreme

Networks a top 5 data center vendor at core & edge

Goldman Sachs CIO survey of Cisco customers,

called Extreme a top 5 network vendor

Gartner report on Data Center rated Extreme Networks

a ‘data network specialist,’ joining JNPR & BRCD

Infotech, a research firm in Canada, rated Extreme

Networks a data center ‘champion’ and ‘exemplary’

November 2011 report

September 2011 report

November 2011 report

#1 and #2 in new high-growth 40G market

(38)

38 _{Extreme Networks Confidential and Proprietary. Not to be distributed outside of Extreme Networks, Inc.}
