CONVERGED VIRTUAL STORAGE

(1)

CONVERGED VIRTUAL

STORAGE

20th. July 2011

Dr. Dave Barnes, HP UK

Storage Specialist

(2)

CHANGING STORAGE MARKET

AND HP RESPONSE

(3)

3

HP Storage portfolio

Optimizing

Traditional Environments

(Thin Provisioning, Storage Tiering, Dedup)

P2000 EVA XP StoreOnce

Enable Seamless Transformation

To Hybrid Models

(Management and Services)

X9000 3PAR

• CloudSystem Matrix

EVA

Building and Managing

Cloud

(Secure Multi-tenancy, Adv. Virtualization)

StoreOnce P4800 X9000 3PAR

• Converged Utility Storage

• Converged Virtual Storage

(4)

Both Accelerating HP Converged Infrastructure

Two core

HP storage design centers

for the

future

Server-based

Storage

Platforms

HP Converged Storage Systems

Converged

Utility

Storage

• Secure Multi-tenancy

• HW Specialization

• Massive Scalability

• Federated

Converged

Virtual

Storage

• Compute/Storage

unified on one platform

• Converged HW

• App-appliance capable

• Modular scale-out

• Small/Medium Enterprise

• Remote Office

• Branch Office

• xSPs with controlled dev

environment (scale-out)

• Public Cloud (IaaS/SaaS)

• Private Cloud

• Medium/Large Open Data

Centers

(5)

(6)

(7)

contained herein is subject to change without notice. HP and HP Channel Partner Restricted.

P4000 Storage Clustering

Fully featured, scale-out architecture

All inclusive feature-set optimized

for virtualized environments

Granular scalability of capacity

and performance, online

Thin provision on-demand for

superior capacity utilization

Support for NFS and CIFS

• P4000 Unified NAS Gateway

Simple to install and

centrally managed

(8)

P4000 Network RAID

Real-time Data Protection

High availability for storage

• Would you use disk RAID 0 for your data?

• Stripping across arrays w/out protection is just as

careless!

Protect data from any SPOF including

the array

• RAID 10 (Mirroring)

−

Mixed workloads (email, DB, virtualization)

−

Can lose up to half of nodes and data remains

available

• RAID 5 and 6 (Parity Based)

−

Read intensive workloads (file shares)

Storage is as HA as the VMs

• Volume level granularity

• Change Network RAID levels on-the-fly

B A C D B A C D E E F F A D B C

P

₁ E A D B C E F

(9)

Site/Rack 1

Site/Rack2

P4000 Multi-site SAN

Real-time Protection from Site Failures

Physical separation for protection

from

• Component failure

• Node Failure

• Rack failure

• Building failure

The next level of high availability

for virtualized environments

• All NR10 volumes are online and

accessible simultaneously at both sites

• Separate both storage and VMs

for maximum protection

• Volumes and VMs remain online

in the event of a site failure

• Volumes automatically re-synch after

failed site comes back online

Single Cluster

Single SAN stretched between two sites or racks

A B C D E F B C D A E F B A C D B A C D E E F F

= or >

1 Gb

(10)

P4000 Remote Copy

Asynchronous Snapshot Replication

Thin provisioned snapshot

replication for efficiency in

disaster recovery

–

Simple to Manage

• Bandwidth management

• Failover / Failback Wizard

• Incremental failback

Support for VMware SRM

included

Site 2

Site 1

1:00 2:00 3:00 1:00 2:00 3:00

WAN

R

em

ot

e

Vo

l

Pr

im

ar

y

Vo

l

Pr

im

ar

y

Vo

l

(11)

(12)

Silo’ed Infrastructure

Storage needs to change!

Technology

shifts

Explosive

growth

Virtualization

Cloud

Computing

Power Cost/

Green

Compliance/

Regulations

Where

information

lives

Where

information

works

How

information

gets to and

from work

Converged

Infrastructure

(13)

HP BladeSystem + the HP P4800

Complete infrastructure convergence

• Common infrastructure for all of IT

• Application servers, networking and enterprise

scale-out storage within HP BladeSystem.

• Reduce network costs by 65%

• Virtual connect acts as both a LAN and SAN

within the c7000.

• Reduce unplanned downtime by 77%

• Use Onboard Administrator and Insight

Management for server, network and storage

hardware management

• Lower power/cooling costs by 30%

• HP Thermal Logic keeps server, storage,

networking equipment power cooling costs

low

(14)

Front/back view

MDS600

_MDS600

-

2 P4000sb nodes with

SAN/iQ 9.0, can expand up to

8 -

P700 Array controller / CCISS

-

Two 3Gb SAS switches

-

1 MDS600s per 2 P4000sb

nodes

-

70 15K LFF 450GB or 600GB

SAS per 2 P4000sb nodes

(15)

NEW storage flexibility

HP P4800 The industry’s first SAN converged with HP BladeSystem

More choices, higher storage density

•2 new starting capacity points

•Field installation for existing c7000’s

•Expand up to (8) P4800 nodes within 1 c7000

Start with a smaller

footprint

•15U vs 20U

•New 2 node configurations

•More space for application

servers

15U

Clustered Storage

Storage high availability across

racks or sites

Rack or Site B

(16)

HP P4800 Management

All tools allow for local and remote management.

Insight

Remote

Support

(IRS)

P4000

Central

Management

Console

(CMC)

Onboard

Administrator (OA)

System Insight Manager (SIM)

Insight Control (IC)

Integrated

Lights-out 200 (iLO)

HP

Storage

Essential

s

Required and

included

Optional and included

Optional

Storage Resource

Mgmt

(17)

HP P4000 Virtual SAN Appliance

Highly Available Storage for ROBO Sites

–

Virtual Machine running the P4000

software for VMware ESX and

Microsoft Hyper-V

–

Fully featured P4000 SAN

–

Create highly available SANs

on servers

• Support servers listed on

hypervisor’s HCL

• Convert existing SAN or

DAS into P4000 storage

–

Fully qualified by Microsoft

–

Affordable HA and DR for

small and/or remote site

–

Evaluation version

http://www.hp.com/go/tryvsa

B A C B A C A C B PB PB A

(18)

HP StorageWorks P4000 G2 SAN Solutions

P4300 G2

MDL SAS

Starter SAN

P4300 G2

SAS Starter

SAN

P4500 G2

Virtualization

SAN

P4500 G2

Multi-Site

SAN

P4500 G2

Scalable

Capacity SAN

P4800 SAN

for

BladeSystem

P4000 Virtual

SAN

Appliance

(VSA)

Features

Storage Clustering –

Network RAID 5/6/10 –

Thin Provisioning –

_Copy

App Integrated Snapshots –

SmartClone –

Remote

Starting

Capacity

7.2K MDL SAS

16.0 TB

15K SAS

7.2 TB

15K SAS

14.4 TB

15K SAS

28.8 TB

7.2K MDL SAS

120 TB

15K SAS

63TB

10 TB license

Max

Drives

256

384

384 1120

Varies

Support

coverage

Included: 3 years, next business day (NBD) support for HW and SW

Included 1

year SW

support, NBD

NAS

Support

P4000 Unified NAS Gateway

CIFS and NFS file services –

Single instance storage (SIS) –

VSS -

Microsoft Cluster Server (MSCS)

Site 1

Site 2

Replication for Remote Offices is optional via P4000 VSA for all

P4000 models. It is

included with 10 license (10TB each) with P4500 Multi-Site and Virtualization SAN.

(19)

VDI –

P4000 VDI Reference Architecture
