Predictive Modelling using

Linear Regression

https://leaps.analyttica.com

Table of Contents

Concept of Regression Analysis

Simple and Multiple Linear Regression Evaluating a Linear Model

Variable Selection and Transformations

https://leaps.analyttica.com

Concept of Regression Analysis

Regression analysis is a predictive modelling technique which estimates the relationship between two or more variables. Recall that a correlation analysis makes no assumption about the causal relationship between two variables. Regression analysis focusses on the relationship between a dependent (target) variable and independent variable(s) (predictors). Here, dependent variable is assumed to be the effect of the independent variable(s). The value of predictors is used to estimate or predict the likely-value of the target variable.

For example, to describe the relationship between diesel consumption and industrial production, if it is assumed that “diesel consumption” is the effect of “industrial production”, we can do a regression analysis to predict value of “diesel consumption” for some specific value of “industrial production”

To do this, we first try to assume a mathematical relationship between the target and the predictor(s). The relationship can be a straight line (linear regression) or a polynomial curve (polynomial regression) or a non-linear relationship (non-linear regression). This can be done through various ways. The simplest and most popular way is to create a scatter plot of the target variable and predictor variable. (Refer to Figure 1 and Figure 2)

Figure 1: Linear Relationship Figure 2: Polynomial Relationship

Once the type of relationship is established, we try to find the most-likely values of the coefficients in the mathematical formula.

Regression analysis comprises of the entire process of identifying the target and predictors, finding

the relationship, estimating the coefficients, finding the predicted values of target, and finally

evaluating the accuracy of the fitted relationship.

https://leaps.analyttica.com

Why do we use Regression Analysis?

As discussed above, regression analysis estimates the relationship between two or more variables.

More specifically, regression analysis helps one understand how the typical value of the dependent variable changes when any one of the independent variables is varied, while the other independent variables are held fixed.

Let’s say, we want to estimate the credit card spend of the customers in the next quarter. For each customer, we have their demographic and transaction related data which indicate that the credit card spend is a factor of age, credit limit and total outstanding balance on their loans. Using this insight, we can predict future sales of the company based on current and past information.

What are the benefits of using Regression Analysis?

Regression explores significant relationships between dependent variable and independent variable.

It indicates the strength of impact of multiple independent variables on a dependent variable and helps to determine which variables in particular, are most significant predictors of the dependent variable. Their influence is quantified by the magnitude and sign of the beta estimates, which is nothing but the extent to which they impact the dependent variable.

It also allows us to compare the effect of variable measures on different scales and can consider nominal, interval, or categorical variables for analysis.

The simplest form of the equation with one dependent and one independent variable is defined by the formula:

y = c + b*x, where

y = estimated dependent score, c = constant,

b = regression coefficient, and

x = independent variable.

https://leaps.analyttica.com

Types of Regression Techniques

For predictions, there are many regression techniques available. The type of regression technique to be used is mostly driven by three metrics:

• Number of independent variables

• Type of dependent variables

• Shape of regression line

Let’s briefly discuss a few regression techniques. A more elaborate discussion of the most commonly used regression techniques will be covered later in the module.

Linear Regression

Linear regression is one of the most commonly used predictive modelling techniques. It establishes a relationship between dependent variable (Y) and one or more independent variables (X) using a best fit straight line (also known as a regression line).

It is represented by an equation 𝑌 = 𝑎 + 𝑏𝑋 + 𝑒, where a is the intercept, b is the slope of the line and e is the error term. This equation can be used to predict the value of a target variable based on given predictor variable(s).

Logistic Regression

Logistic regression is used to explain the relationship between one dependent binary variable and one or more nominal, ordinal, interval or ratio-level independent variables.

Polynomial Regression

A regression equation is a polynomial regression equation if the power of independent variable is more than 1. The equation below represents a polynomial equation.

𝑌 = 𝑎 + 𝑏𝑋 + 𝑐𝑋

In this regression technique, the best fit line is not a straight line. It is rather a curve that fits into the data points.

Ridge Regression

Ridge regression is suitable for analyzing multiple regression data that suffers from multicollinearity.

When multicollinearity occurs, least squares estimates are unbiased, but their variances are large so

they may be far from the true value. By adding a degree of bias to the regression estimates, ridge

regression reduces the standard errors. It is hoped that the net effect will be to give estimates that

are more reliable.

https://leaps.analyttica.com

Linear Regression

Linear Regression is a predictive modelling technique that establishes a relationship between dependent variable (Y) and one or more explanatory variables denoted by X, using a best fit straight line (also known as regression line).

It is represented by the equation, 𝑌 = 𝑎 + 𝑏 ∗ 𝑋 + 𝑒, where a is intercept, b is slope of the line and e is error term.

This equation can be used to predict the value of target variable based on given predictor variable(s).

The case of one explanatory variable is called simple linear regression. For more than one explanatory variables, the process is called multiple linear regression. In this technique, the dependent variable is continuous, independent variable(s) can be continuous or discrete, and nature of the regression line is linear.

The following sections discuss in detail, the process of developing and evaluating a regression model. An important concept to recall at this point, is that of Data Splitting, which requires the data to be randomly split into Training and Validation datasets. The rationale behind splitting the data is that the model is built on one dataset (training) and its performance is evaluated on the validation dataset to evaluate its performance on a new, unknown dataset.

In all following discussions, it is understood that the model building and evaluation process

(determining the best fitting line and estimating the accuracy of the model) is done on the training

dataset, and the model validation is done on the validation dataset.

https://leaps.analyttica.com

Determining the Best Fitting Line

Consider we have a random sample of 20 students with their height (x) and weight (y) and we need to establish a relationship between the two. One of the first and basic approach to fit a line through the data points is to create a scatter plot of (x,y) and draw a straight line that fits the experimental data.

Figure 3

Since there can be multiple lines that fit the data, the challenge arises in choosing the one that best fits. As we already know, the best fit line can be represented as

𝑦

̂

= 𝑏

+ 𝑏

𝑥

Where,

• 𝑦 denotes the observed response for experimental unit i

• 𝑥

denotes the predictor value for experimental unit i

•

̂

is the predicted response (or fitted value) for experimental unit i

When we predict height using the above equation, the predicted value of the prediction wouldn't be perfectly accurate. It has some "prediction error" (or "residual error"). This can be represented as

𝑒

= 𝑦

−

̂

A line that fits the data best will be one for which the n (i = 1 to n) prediction errors, one for each observed data point, are as small as possible in some overall sense.

One way to achieve this goal is to invoke the "least squares criterion," which says to "minimize the

sum of the squared prediction errors."

https://leaps.analyttica.com

̂

The equation of the best fitting line is:

ŷ

= 𝑏

+ 𝑏

𝑥

We need to find the values of b

and b

that make the sum of the squared prediction errors the smallest i.e.

Residual Squares = ∑

𝑒

= ∑

(𝑦

− ŷ

)

𝑖=1 𝑖=1

Because the deviations are first squared, then added, there is no cancelling out between positive and negative values.

Least Square Estimates

For the above equation 𝑏0 and 𝑏1 are determined using the following:

𝑏̂

= 𝑌̅ – 𝑏̂

𝑋̅ and 𝑏̂

=

∑^𝑛_𝑖=1(Xi−𝑋̅ )²

Because the formulas for b

and b

are derived using the least squares criterion, the resulting equation, 𝑦̂

= 𝑏

+ 𝑏

𝑥

, is often referred to as the "least squares regression line," or simply the "least squares line." It is also sometimes called the "estimated regression equation."

What Does the Equation Mean?

The equation above is a physical interpretation of each of the coefficients and hence it is very important to understand what the regression equation means.

• The coefficient 𝑏

, or the intercept, is the expected value of Y when X = 0

• The coefficient 𝑏

, or the slope, is the expected change in Y when X is increased by one unit.

https://leaps.analyttica.com

The following figure explains the interpretations clearly.

Figure 4

Example of Linear Regression: Factors affecting Credit Card Sales

An analyst wants to understand what factors (or independent variables) affect credit card sales. Here, the dependent variable is credit card sales for each customer, and the independent variables are income, age, current balance, socio-economic status, current spend, last month’s spend, loan outstanding balance, revolving credit balance, number of existing credit cards and credit limit. In order to understand what factors affect credit card sales, the analyst needs to build a linear regression model.

It is important to note that a linear regression cannot be applied to categorical variables, and is not recommended for ordinal variables, hence, the analyst may also need to check the variable type before running a model.

Module 1 Simulation 1: Learn & Apply a Simple Linear Regression Model

In this simulation, the learner is exposed to a sample dataset comprising of telecom customer

accounts and their annual income, age along with their average monthly revenue (dependent

variable). The learner is expected to apply the linear regression model using annual income as the

single predictor variable.

https://leaps.analyttica.com

Evaluating a Linear Regression Model

Once we fit a linear regression model, we need to evaluate the accuracy of the model. In the following sections, we will discuss the various methods used to evaluate the accuracy of the model with respect to its predictive power.

For an in-depth understanding of all the topics covered in the coming sections, refer to the course

“Fundamentals of Data Analytics” on Analyttica TreasureHunt LEAPS

(https://leaps.analyttica.com/courses/overview/Fundamentals-of-Data-Analytics). You can also

refer to any of the standard Statistics books for more information on the same.

F-Statistics and p-value

The F-Test indicates whether a linear regression model provides a better fit to the data than a model that contains no independent variables. It consists of the null and alternate hypothesis and the test statistic helps to prove or disprove the null hypothesis.

The null hypothesis here is “The target variable cannot be significantly predicted using the predictor

variable(s)”. To do this we look at the F-statistic and its p-value. Mathematically, the null hypothesis

we test here is “All slope parameters are 0” (note the number of slope parameters will be the same

as the number of independent variables in the model). Hence, if the null hypothesis is accepted (or

not rejected) then it means we cannot predict target variable using the predictor variables and hence

regression is not possible.

https://leaps.analyttica.com

Coefficient of Determination

Next, we look at the R-squared value of the model, which is also called the “Coefficient of Determination”. This statistic calculates the percentage of variation in target variable explained by the model. The below illustration captures the explained vs. unexplained variation in data.

Figure 5 R-squared is calculated using the following formula:

R

=

Total Variance

=

∑^𝑛_𝑖=1(Y_i−𝑌̅)²

R-squared is always between 0 and 100%. As a guideline, the more the R-squared, the better is the model. The objective is not to maximize the R-squared, since the stability and applicability of the model are equally important. Next, check the Adjusted R-squared value. Ideally, the R-squared and adjusted R-squared values need to be in close proximity of each other. If this is not the case, then the analyst may have over fitted the model and may need to remove the insignificant variables from the model.

Module 1 Simulation 2: Learn & Apply the concept of R-Square

In this simulation, the learner is exposed to a sample dataset capturing telecom customer accounts

and their annual income, age, along with their average monthly revenue (dependent variable). The

dataset also contains predicted values of “average monthly revenue” from a regression model. The

learner is expected to apply the concept of calculation of coefficient of determination.

https://leaps.analyttica.com

Check the p-value of the Parameter Estimates

The p-value for each variable tests the null hypothesis that the coefficient is equal to zero (no effect).

A low p-value (<0.05) indicates that we can reject the null hypothesis. In other words, a predictor that has a low p-value can be included in the model because changes in the predictor's value are related to changes in the response variable. Conversely, a larger (insignificant) p-value suggests that changes in the predictor are not associated with changes in the response. This is an iterative process and the analyst may need to re-run the model until only significant variables remain. If there are hundreds of variables then the analyst may choose to automate the variable selection using the forward, backward or stepwise techniques. Automated variable selection is however, not recommended for small number of variables in the dataset.

Module 2 Simulation 1: Build a Multivariate Linear Regression Model and Evaluate Parameter Significance

In this simulation, the learner is exposed to a sample dataset capturing the flight status of flights with their delay in arrival, along with various possible predictor variables like departure delay, distance, air time, etc. The learner is expected to build a multiple regression model where all the variables are significant.

Residual Analysis

We can also evaluate a regression model based on various summary statistics on error or residuals.

Some of them are:

• Root Mean Square Error (RMSE): Where we find average of squared residuals as per the given formula:

RMSE =

n

∑

(Y

− Y ̅)

• Mean Absolute Percentage Error (MAPE): We find the average percentage deviation as per the given formula:

MAPE =

n

∑

Y_i 𝑛𝑖=1

We also often look at the distribution of absolute percentage deviation across all observations.

https://leaps.analyttica.com

Rank Ordering

Observations are grouped based on predicted values of the target variable. The average of the actual vs. predicted values of the target variable, across the groups, is observed to see if they move in the same direction across the groups (increase or decrease). This is called the rank ordering check.

ATH Module 2 Simulation 2: Evaluating a Linear Model

In this simulation, the learner is exposed to a sample dataset capturing flight fare data. The objective is to predict fare between two locations. The data contains actual fare along with a predicted average fare. The learner is expected to evaluate the accuracy of the model using various statistics and measures.

Assumptions of Linear Regression

There are some basic but strong underlying assumptions behind the linear regression model estimation. After fitting a regression model, we should also test the validation of each of these assumptions.

• There must be a causal relationship between the dependent and the independent variable(s) which can be expressed as a linear function. A scatter plot of target variable vs. predictor variable can help us validate this.

• Error term of one observation is independent of that of the other. Otherwise we say the data has autocorrelation problem. We use Durbin-Watson test to check the presence of autocorrelation.

• The mean (or expected value) of errors is zero.

• The variance of errors does not depend on the value of any predictor variable. This means, errors have a constant variance along the regression line. This characteristic is often termed as Homoscedasticity. Breausch-Pagan test helps us to test if the data is homoscedastic or heteroscedastic.

• Errors follow normal distribution. We can use normality test on the errors here

The independent variables are not correlated or there is no multicollinearity in the data. Though this is not a mandatory condition, the problem of multicollinearity makes the estimated values unstable.

Variance Inflation Factor (VIF) helps us to identify any multicollinearity.

https://leaps.analyttica.com

Variable Selection and Transformations

Having multiple predictor variables introduces noise in the modeling process, affecting the estimates of other variables. The principle of Occam’s Razor states that among several plausible explanations for a phenomenon, the simplest is the best. Applied to regression analysis, this implies that the smallest model that fits the data is the best.

There are various techniques available to select the best set of variables. Variable reduction techniques vary depending on the kind of modeling technique used. For linear regression, we often use any one or more of the following techniques:

• Box-Cox transformations

• Variable multicollinearity through Variance Inflation Factor (VIF)

• Principal Component Analysis

• Stepwise/ Forward/ Backward variable selection technique Module 2 Simulation-3: Apply the concept of Variable Transformation

In this simulation, the learner is exposed to U. S. Census Bureau data on per capita retail sales along with some socio-economic variables for the year 1992, of 845 US Standard Metropolitan Statistical Areas (SMAS). The objective is to predict the “Per Capita Retail Sales” using other socio-economic variables as possible predictors. The socio-economic variables are not always linearly related and hence the learner is expected to try various transformations on the variables and try to see which fits the model better.

Here we need to discuss one more important aspect of regression model fitting. Often, we find one predictor variable to be exceptionally strong in a regression model compared to other predictors.

Such predictors also contribute to the extremely high accuracy of the model. This is known as the problem of overfitting.

The main problem of these models is the fact that these models become too dependent on a single variable. If there is any issue with the value of that specific variable the entire model fails. Sometimes, the selected variables are actually a part of the target variable.

For Example: Suppose we are trying to fit a regression model to predict “Household Expenditure” of

a household using various predictor variables like “Household Income”, “Household Size”, “City Cost

of Living Index”, etc. Now, note that “Household Income” is expected to have a very high impact on

https://leaps.analyttica.com

the model compared to any other predictor. Also, the model can be very high on efficiency. For a linear model, the R-square can be as high as 98-99%. On removing the variable from the model, the R-square will come down to may be 20% or 30%.

Now think about if “Household Income” is a right variable to predict “Household Expenditure”.

Expenditure is actually a part of income. Often, people are reluctant about revealing their actual income, introducing high levels of impurity in the data. Hence, we should not have included the variable in the model.

Also, 98% R-square is too high to believe in any real-life scenario. In general, any linear model with an R-square more that 75% or 80% must be subjected to detailed inspection and checked for overfitting. Models with an R-square of 40% - 50% are deemed acceptable in most practical cases.

Module 2 Simulation-4: Learn & Apply concepts of Variable Selection & Overfitting

In this simulation, the learner is exposed to a sample dataset capturing flight fares where the

objective is to predict fare between two locations. The learner is expected to select the significant

variable for the model first and then check if there is any problem of overfitting. If found, learner

should remove the requisite variable(s) and iterate through the variable selection process.
